Search Results (26)

Wearable sensors have rapidly advanced, enabling applications such as human activity monitoring, electronic skin, and biomimetic robotics. To meet the growing demands of these applications, multifunctional sensing has become essential for wearable devices. However, most existing studies predominantly focus on enhancing single-function sensing capabilities. This study introduces a multifunctional sensor that combines high stretchability for strain and pressure detection with ultraviolet (UV) sensing capability. To achieve simultaneous detection of strain, pressure, and UV light, a multi-sensing approach was employed: a capacitive method for strain and pressure detections and a resistive method utilizing a pn-heterojunction diode for UV detection. In the capacitive method, polyaniline (PANI) served as parallel-plate electrodes, while silicon-based elastomer acted as the dielectric layer. This configuration enabled up to 100% elongation and enhanced operational stability through encapsulation. The sensor demonstrated a strong linear relationship between capacitance value changes reasonably based on the area of PANI, and showed a good linearity with an R-squared value of 0.9918. It also detected pressure across a wide range, from low (0.4 kPa) to high (9.4 kPa). Furthermore, for wearable applications, the sensor reliably captured capacitance variations during finger bending at different angles. For UV detection, a pn-heterojunction diode composed of p-type silicon and n-type zinc oxide nanorods exhibited a rapid response time of 6.1 s and an on/off ratio of 13.8 at −10 V. Durability under 100% tensile strain was confirmed through Von Mises stress calculations using finite element modeling. Overall, this multifunctional sensor offers significant potential for a variety of applications, including human motion detection, wearable technology, and robotics. Full article

With the improvement of the energy density and sensing accuracy of wearable devices, there is increasing interest in applying wearable electronics in daily life. However, traditional rigid plate-structured wearable devices cannot meet the human body’s wearing habits and make users may feel uncomfortable after wearing them for a long time. Fabric-type wearable electronics can be conformably coated on human skin without discomfort from mismatches in mechanical properties between the human body and electronics. Although state-of-the-art textile-based wearable devices have shown unique advantages in the field of e-textiles, real-world scenarios often involve stretching, bending, and wetting. Further efforts should be made to achieve “comfortable wearing” due to the great challenge of achieving both promising electrical properties and comfort in a single device. This review presents a comprehensive overview of the advances in smart fabric-based wearable electronics toward comfortable wearing, emphasizing their stretchability, hydrophobicity, air permeability, stability, and color-change abilities. Through addressing the challenges that persist in fabric-type wearable electronics, we are optimistic that these will be soon ubiquitous in our daily lives, offering exceptionally comfortable wearing experiences for health monitoring, sports performance tracking, and even fashion, paving the way for a more comfortable and technologically advanced future. Full article

For signal transmission and sensing in stretchable structures for human motion monitoring or proprioception of soft robots, textiles with electronically conductive yarns are a promising option. Many recent publications employ silver-plated yarns in knits, braids, wovens for strain or pressure sensing purposes as well as heating fabrics or twisted string actuators. Silver-plated yarns are available in a wide range of base materials, yarn counts and twists. These structural properties significantly influence the electrical and electromechanical behavior of such yarns. However, until now little research has been carried out on the yarns themselves. To close this research gap, several variations of a single yarn type are electromechanically characterized. Additionally, tensile tests with synchronous resistance measurements are performed. From these measurements, sensor metrics are derived and calculated to compare the different variants quantitatively. Full article

In this paper, a new synthesis of carbon nanofibers (CNFs)/carbon nanowalls (CNWs) was performed to improve the characteristics of anode materials of lithium-ion batteries by using the advantages offered by CNWs and CNFs. Among the carbon-based nanomaterials, CNWs provide low resistance and high specific surface area. CNFs have the advantage of being stretchable and durable. The CNWs were grown using a microwave plasma-enhanced chemical vapor deposition (PECVD) system with a mixture of methane (CH₄) and hydrogen (H₂) gases. Polyacrylonitrile (PAN) and N,N-Dimethyl Formamide (DMF) were stirred to prepare a solution and then nanofibers were fabricated using an electrospinning method. Heat treatment in air was then performed using a hot plate for stabilization. In addition, heat treatment was performed at 800 °C for 2 h using rapid thermal annealing (RTA) to produce CNFs. A field emission scanning electron microscope (FE-SEM) was used to confirm surface and cross-sectional images of the CNFs/CNWs anode materials. Raman spectroscopy was used to examine structural characteristics and defects. Cyclic voltammetry (CV), electrochemical impedance spectroscopy (EIS), and constant current charge/discharge tests were performed to analyze the electrical characteristics. The synthesized CNFs/CNWs anode material had a CV value in which oxidation and reduction reactions were easily performed, and a low Rct value of 93 Ω was confirmed. Full article

Recent advances in soft polymer materials have enabled the design of soft machines and devices at multiple scales. Their intrinsic compliance and robust mechanical properties and the potential for a rapid scaling of the production process make them ideal candidates for flexible and stretchable electronics and sensors. Large-area electronics (LAE) made from soft polymer materials that are capable of sustaining large deformations and covering large surfaces and are applicable to complex and irregular surfaces and transducing deformations into readable signals have been explored for structural health monitoring (SHM) applications. The authors have previously proposed and developed an LAE consisting of a corrugated soft elastomeric capacitor (cSEC). The corrugation is used to engineer the directional strain sensitivity by using a thermoplastic styrene-ethylene-butadiene-styrene (SEBS). A key limitation of the SEBS-cSEC technology is the need of an epoxy for reliable bonding of the sensor onto the monitored surface, mainly attributable to the sensor’s fabrication process that comprises a solvent that limits its direct deployment through a painting process. Here, with the objective to produce a paintable cSEC, we study an improved solvent-free fabrication method by using a commercial room-temperature-vulcanizing silicone as the host matrix. The matrix is filled with titania particles to form the dielectric layer, yielding a permittivity of 4.05. Carbon black powder is brushed onto the dielectric and encapsulated with the same silicone to form the conductive stretchable electrodes. The sensor is deployed by directly painting a layer of the silicone onto the monitored surface and then depositing the parallel plate capacitor. The electromechanical behavior of the painted silicone-cSEC was characterized and exhibited good linearity, with an R${}^2$ value of 0.9901, a gauge factor of 1.58, and a resolution of 70 $\mathsf{\mu }\mathsf{\epsilon }$. This resolution compared well with that of the epoxied SEBS-cSEC reported in previous work (25 $\mathsf{\mu }\mathsf{\epsilon }$). Its performance was compared against that of its more mature version, the SEBS-cSEC, in a network configuration on a cantilever plate subjected to a step-deformation and to free vibrations. Results showed that the performance of the painted silicone-sCEC compared well with that of the SEBS-cSEC, but that the use of a silicone paint instead of an epoxy could be responsible for larger noise and the under-estimation of the dominating frequency by 6.7%, likely attributable to slippage. Full article

The application of soft actuators has become increasingly common in wearable devices. In this study, we investigated the force characteristics of soft actuators made entirely of elastic material, when equipped with solid external chamber plates of varying thickness that can be attached from the outside. This study examines the effect of these plates on the force characteristics of a fully silicone-based fifteen-chamber soft actuator without any non-stretchable internal components. The parameters of the actuator were determined with consideration of wearable applications, such as rehabilitation devices and exoskeletons. The observed differences in the behavior of the actuator at various pressure levels and plate thicknesses were measured. Furthermore, the effect of the externally inserted plates between the chambers on the passive bending of the actuator was examined. The obtained results were evaluated and compared to determine how external chamber plates of given thicknesses affect the operational performance of a soft actuator. Full article

The current investigation aims to analyze the nanofluid flow between two infinite rotating horizontal channels. The lower plate is porous and stretchable. The impact of physical parameters such as Hall current, thermal characteristics, heat source/sink, chemical reaction on velocity, temperature, and concentration profiles are discussed through graphs. The governing equations are transformed to ordinary differential equations using suitable transformations and then solved numerically using the RK4 approach along with the shooting technique. For varying values of the Schmidt number (SN) and the chemical reaction factor (CRF), the concentration profile declines, but decreases for the activation energy. It is observed that the velocity profile declines with the increasing values of the suction factor. The velocity profile increases when the values of the rotation factors are increased. The temperature field exhibits a rising behavior with increasing values of the thermophoresis factor, Brownian motion, and the thermal radiation factor. It is also observed that the heat transfer rate is significant at the lower wall with the increasing values of the Prandtl number (PN). For the numerical solution, the error estimation and the residue error are calculated for the stability and confirmation of the mathematical model. The novelty of the present work is to investigate the irregular heat source and chemical reaction over the porous rotating channel. A growing performance is revealed by the temperature field, with the increase in the Brownian motion (BM), thermophoresis factor (TF), thermal conductivity factor (TCF), and the radiation factor (RF). Full article

The aim of this study is to examine the Darcy–Forchheimer flow = of $H_{2}O$-based $Al-A{l}_2{O}_3/$$Cu-A{l}_2{O}_3$ hybrid nanofluid past a heated stretchable plate including heat consumption/ generation and non-linear radiation impacts. The governing flow equations are formulated using the Naiver–Stokes equation. These flow equations are re-framed by using the befitted transformations. The MATLAB bvp4c scheme is utilized to compute the converted flow equations numerically. The graphs, tables, and charts display the vicissitudes in the hybrid nanofluid velocity, hybrid nanofluid temperature, skin friction coefficient, and local Nusselt number via relevant flow factors. It can be seen that the hybrid nanofluid velocity decreased as the magnetic field parameter was increased. The hybrid nanofluid temperature tended to rise as the heat absorption/generation, nanoparticle volume friction, and nonlinear radiation parameters were increased. The surface drag force decreased when the quantity of the magnetic parameter increased. The larger size of the radiation parameter led to enrichment of the heat transmission gradient. Full article

This research investigates the two different hybrid nanofluid flows between two parallel plates placed at two different heights, $y_0$and $y_h$, respectively. Water-based hybrid nanofluids are obtained by using $A{l}_2{O}_3$, $Ti{O}_2$ and $Cu$ as nanoparticles, respectively. The upper-level plate is fixed, while the lower-level plate is stretchable. The fluid rotates along the y-axis. The governing equations of momentum, energy and concentration are transformed into partial differential equations by using similarity transformations. These transformed equations are grasped numerically at MATLAB by using the boundary value problem technique. The influence of different parameters are presented through graphs. The numerical outcomes for rotation, Nusselt, Prandtl, and Schmidt numbers are obtained in the form of tables. The heat transfer rate increases by augmentation in the thermophoresis parameter, while it decays by increasing the Reynolds number. Oxide nanoparticles hybrid nanofluid proved more efficient as compared to mixed nanoparticles hybrid nanofluid. This research suggests using oxide nanoparticles for good heat transfer. Full article

In (Al₂O₃-Cu/H₂O) hybridized nanofluid (HYNF) is an unsteady electro-hydrodynamic stagnation point flow. A stretchable (shrinkable) surface that was convectively heated was studied in the past. In addition to the traditional nonslip surface, the heat generating (absorbing) and the velocity slippage constraints are deliberated in this research. An obtained nonlinear scheme is resolved by the homotopy analysis method. Governing parameters are the electric field parameters, that is, the dimensionless parameters including the magnetic parameter, Prandtl quantity, heat generating factor, Eckert quantity, and unsteady factor. We discuss in detail the effects of these variables on the movement of problems and thermal transmission characteristics. Increasing the values of the magneto and electric force parameters increased the temperature. Increasing the Prandtl number lowered the temperature. For the Eckert parameter, an increase in temperature was recognized. The symmetric form of the geometry model displayed improved the fluid flow by the same amount both above and below the stagnation streamline, while it decreased the flow pressure by the same level. The more heat source uses to increase the temperature of the HYNF over the entire area, the more heat is supplied to the plate, but with a heat sink, the opposite effect is observed. Full article

Elastic knitted fabrics find numerous applications in the industry for compression stockings, sports and leisure wear, swimwear, ballet wear, etc. During its use, knitwear is subjected to dynamic loading due to body movements. The loading and unloading of the knitted fabric affect the size of the elastic region in which unrecovered deformation completely disappears. This paper deals with the influence of the elastane percentage in the knitted fabric on the elastic properties of the knitted fabric under dynamic loading. For this experiment, three types of yarn were used in different combinations: polyamide (PA), wrapped elastane yarn and bare elastane. The mentioned yarns were used to knit three different groups of plated weft-knitted fabrics (two yarns in a knitted fabric row): without elastane, knitted fabric with a percentage of wrapped elastane, and knitted fabric with a percentage of bare elastane. The percentage of elastane ranged between 0% and 43%. First, standard uniaxial tensile tests were performed on knitted fabric samples until breakage under static load. The force–elongation diagrams obtained are used to determine the elastic limit up to which Hook’s law applies. All knitted fabrics were cyclically tested to the elastic limit. From the obtained loading and unloading curves, unrecovered deformation (unrecovered elongation), elastic elongation and hysteresis index were determined and calculated. The results showed that the percentage of elastane significantly affects the size of the elastic region of the knitted fabric and has no effect on the hysteresis index. Therefore, it is necessary to optimize the elastane percentage for different knitted fabric designs to achieve the best dynamic recovery of the knitted fabric and to design a more stretchable knitted garment that fits the body as well as possible. Full article

The present work discusses the 2D unsteady flow of second grade hybrid nanofluid in terms of heat transfer and MHD effects over a stretchable moving flat horizontal porous plate. The entropy of system is taken into account. The magnetic field and the Joule heating effects are also considered. Tiny-sized nanoparticles of silicon carbide and titanium oxide dispersed in a base fluid, kerosene oil. Furthermore, the shape factors of tiny-sized particles (sphere, bricks, tetrahedron, and platelets) are explored and discussed in detail. The mathematical representation in expressions of PDEs is built by considering the heat transfer mechanism owing to the effects of Joule heating and viscous dissipation. The present set of PDEs (partial differential equations) are converted into ODEs (ordinary differential equations) by introducing suitable transformations, which are then resolved with the bvp4c (shooting) scheme in MATLAB. Graphical expressions and numerical data are obtained to scrutinize the variations of momentum and temperature fields versus different physical constraints. Full article

Zein is renewable plant protein with valuable film-forming properties that can be used as a packaging material. It is known that the addition of natural cross-linkers can enhance a film’s tensile properties. In this study, we aimed to prepare antimicrobial zein-based films enriched with monolaurin, eugenol, oregano, and thyme essential oil. Films were prepared using the solvent casting technique from ethanol solution. Their physicochemical properties were investigated using structural, morphological, and thermal techniques. Polar and dispersive components were analyzed using two models to evaluate the effects on the surface free energy values. The antimicrobial activity was proven using a disk diffusion method and the suppression of bacterial growth was confirmed via a growth kinetics study with the Gompertz function. The films’ morphological characteristics led to systems with uniform distribution of essential oils or eugenol droplets combined with a flat-plated structure of monolaurin. A unique combination of polyphenolic eugenol and amphiphilic monoglyceride provided highly stretchable films with enhanced barrier properties and efficiency against Gram-positive and Gram-negative bacteria, yeasts, and molds. The prepared zein-based films with tunable surface properties represent an alternative to non-renewable resources with a potential application as active packaging materials. Full article

Recently, the stretchable piezoresistive composites have become a focus in the fields of the biomechanical sensing and human posture recognition because they can be directly and conformally attached to bodies and clothes. Here, we present a stretchable piezoresistive thread sensor (SPTS) based on Ag plated glass microspheres (Ag@GMs)/solid rubber (SR) composite, which was prepared using new shear dispersion and extrusion vulcanization technology. The SPTS has the high gauge factors (7.8~11.1) over a large stretching range (0–50%) and approximate linear curves about the relative change of resistance versus the applied strain. Meanwhile, the SPTS demonstrates that the hysteresis is as low as 2.6% and has great stability during 1000 stretching/releasing cycles at 50% strain. Considering the excellent mechanical strain-driven characteristic, the SPTS was carried out to monitor posture recognitions and facial movements. Moreover, the novel SPTS can be successfully integrated with software and hardware information modules to realize an intelligent gesture recognition system, which can promptly and accurately reflect the produced electrical signals about digital gestures, and successfully be translated into text and voice. This work demonstrates great progress in stretchable piezoresistive sensors and provides a new strategy for achieving a real-time and effective-communication intelligent gesture recognition system. Full article

Flexible pressure sensors are widely used in different fields, especially in human motion, robot monitoring and medical treatment. Herein, a flexible pressure sensor consists of the flat top plate, and the microstructured bottom plate is developed. Both plates are made of polydimethylsiloxane (PDMS) by molding from the 3D printed template. The contact surfaces of the top and bottom plates are coated with a mixture of poly (3,4-ethylenedioxythiophene) poly (styrene sulfonate) (PEDOT:PSS) and polyurethane dispersion (PUD) as stretchable film electrodes with carbon nanotubes on the electrode surface. By employing 3D printing technology, using digital light processing (DLP), the fabrication of the sensor is low-cost and fast. The sensor models with different microstructures are first analyzed by the Finite Element Method (FEM), and then the models are fabricated and tested. The sensor with 5 × 5 hemispheres has a sensitivity of 3.54 × 10⁻³ S/kPa in the range of 0–22.2 kPa. The zero-temperature coefficient is −0.0064%FS/°C. The durability test is carried out for 2000 cycles, and it remains stable during the whole test. This work represents progress in flexible pressure sensing and demonstrates the advantages of 3D printing technology in sensor processing. Full article
