With the continued development of spatial information technologies, Digital Surface Models (DSMs) have become fundamental data products for urban planning, virtual reality, geographic information systems, and digital-earth applications. Neural Radiance Fields (NeRFs) have achieved remarkable success in multi-view 3D reconstruction in computer vision. Still, their application to DSM generation from satellite imagery remains challenging because of differences in imaging geometry, complex surface structure, and varying illumination conditions. To address these issues, this paper proposes a Shading and Geometric Constraint (SGC) method tailored to satellite photogrammetry and designed to integrate with existing NeRF-based frameworks such as Sat-NeRF and EO-NeRF. First, a physical imaging model based on Lambertian reflectance and spherical harmonics is introduced to represent the complex illumination variations in satellite images. Synthetic images generated by this model provide auxiliary supervision that improves robustness to illumination inconsistency. Second, inspired by classical shading-based refinement methods, we introduce a bilateral edge-preserving geometric constraint. Unlike standard smoothness terms, this constraint uses photometric discrepancies to weight geometric smoothing, thereby preserving sharp building boundaries while smoothing flat surfaces. We integrate the method into two state-of-the-art baselines, Sat-NeRF and EO-NeRF. EO-NeRF+SGC achieves up to a 57.93% reduction in elevation MAE relative to EO-NeRF, which is the largest relative MAE reduction reported in this study. The method also recovers finer structural details and sharper edges than recently published NeRF-based DSM reconstruction methods. Full article

Precise modeling of narrow gorges is challenging due to extreme confinement, hindering visibility and accessibility. These environments often render Global Navigation Satellite Systems (GNSS)-based positioning unfeasible, a difficulty compounded by water and dense vegetation. Consequently, multi-technique data fusion is required. This study proposes a robust methodology to generate high-resolution 3D models of such complex environments by integrating multiple aerial (e.g., Unmanned Aerial Vehicles, UAVs) and terrestrial techniques. A multi-sensor approach combined UAV-Light Detection and Ranging (LiDAR) and UAV-photogrammetry for external areas with Terrestrial laser scanning (TLS), Mobile Mapping System (MMS), and Spherical Photogrammetry (SP) for the canyon floor. Furthermore, the representativeness of these 3D models was analyzed against standard Digital Terrain Models (DTMs) for determining water height levels during flood events. A one-dimensional hydraulic (1DH) model compared the 3D mesh approach with the traditional 2.5D perspective in a challenging, narrow canyon prone to flooding. Our results show that traditional 2.5D DTMs significantly over- or underestimate water levels in narrow sections—failing to account for overhangs and vertical wall irregularities—whereas high-resolution 3D meshes provide a more realistic representation of hydraulic behavior. This work demonstrates that multi-sensor data fusion is essential for accurate flood risk management and infrastructure planning in complex fluvial environments. Full article

Heritage buildings pose persistent challenges for documentation and conservation due to their geometric complexity, material heterogeneity, and the fragmentation of spatial and semantic datasets. To address these limitations, this study proposes a geospatially enabled HBIM–GIS framework that integrates hybrid photogrammetric survey data with semantic modeling and spatial analysis to support evidence-based conservation planning. A multi-source acquisition strategy combining terrestrial digital photogrammetry (TDP), Unmanned aerial vehicle digital photogrammetry (UAVDP), and spherical photogrammetry (SP) was employed to capture accurate geometric and semantic information across multiple spatial scales. Staged point-cloud fusion (UAVDP → TDP via ICP; SP → UAV–TDP via SICP) generated a high-density, georeferenced composite, achieving RMS residuals below 0.013 m and resulting in an integrated dataset exceeding 360 million points. From this composite, authoritative 2D drawings and a reality-based 3D HBIM model were developed, while GIS thematic mapping translated heterogeneous observations into structured, queryable layers representing materials, cracks, detachments, deformations, and construction phases. The proposed framework enabled the spatial diagnosis of deterioration mechanisms, revealing moisture-driven decay from plinth to mid-wall and concentrated cracking at openings and architectural transitions; side-to-side cracks accounted for approximately 55% and 65% of mapped fissures on the most affected façades. By embedding these diagnostics as element-level attributes within the HBIM environment, the framework supports precise localization, quantification, and prioritization of conservation interventions, ensuring material-compatible and location-specific decision making. The applicability of the framework is demonstrated through its implementation on a complex historic mosque in Yemen, validating its robustness under constrained access and resource-limited conditions. Overall, the study demonstrates that geospatially integrated HBIM–GIS workflows provide a reproducible, scalable, and transferable solution for the sustainable documentation and conservation of heritage buildings, supporting long-term monitoring and informed management of cultural heritage assets worldwide. Full article

The article addresses the issue of panoramic photogrammetry for the reconstruction of interior spaces. Such environments often present challenges, including poor lighting conditions and surfaces with variable texture for photogrammetric scanning. In this case study, we reconstruct the interior spaces of the historical house of Samuel Mikovíni, which represents these unfavorable conditions. The 3D reconstruction of interior spaces is performed using the Ricoh Theta Z1 spherical camera (Ricoh Company, Ltd.; Tokyo, Japan) in six variants, each employing a different number of images and different camera networks. Scale is introduced into the reconstructions based on significant dimensions measured with a measuring tape. A comparison is carried out using a point cloud obtained from terrestrial laser scanning and difference point clouds are generated for each variant. Based on the results, reconstructions produced from a reduced number of spherical images can serve as a basic source for simple documentation with accuracy up to 0.15 m. When the number of spherical images is increased and images from different height levels are included, the reconstruction accuracy improves markedly, achieving positional accuracy of up to 0.05 m, even in areas affected by poor lighting conditions or low-texture surfaces. The results confirm that for interior reconstruction, a higher number of images not only increases the density of the reconstructed point cloud but also enhances its positional accuracy. Full article

The use of digital photogrammetry and laser data acquisition systems, along with the ability to mount these sensors on unmanned aerial vehicles (UAVs), has revolutionized rockfall assessment. While these techniques have facilitated numerous studies across diverse scenarios, complex environments like narrow gorges necessitate the integration of various geomatic techniques to achieve complete and accurate spatial products. To address the critical gap in the literature regarding standardized multi-sensor integration in narrow gorges, this study presents a novel methodology for the cohesive integration of data from these techniques, leveraging their respective strengths to generate reliable products for rockfalls risk assessment. To validate the methodology, we applied this approach to a challenging rockfall susceptibility study at the Caminito del Rey in Málaga, Spain. The site presented significant complexities, including vertical walls hundreds of meters high with abundant overhangs, and canyons as narrow as 10 m, severely limiting single-technique approaches. The successful integration of these diverse datasets yielded a comprehensive, very high-resolution point cloud (1–10 cm density), among other products, covering the entire study area, making it ideal for detailed rockfall assessment and simulation. The approach has demonstrated that data fusion from multiple techniques supposes an advantage because one supports the other both in data coverage and in processing. Although processing the extensive acquired information presented a significant challenge, a successful balance between data volume and processing capacity was achieved, ensuring the outputs met the specific requirements for these studies. Full article

The evolution of photogrammetry has been significantly influenced by advancements in camera technology, particularly the emergence of spherical cameras. These devices offer extensive photographic coverage and are increasingly utilised in many photogrammetry applications due to their significant user-friendly configuration, especially in their low-cost versions. Despite their advantages, these cameras are subject to high image distortion. This necessitates specialised calibration solutions related to fisheye images, which represent the primary geometry of the raw files. This paper evaluates fisheye calibration processes for the effective utilisation of low-cost spherical cameras, for the purpose of 3D reconstruction and the verification of geometric stability. Calibration optical parameters include focal length, pixel positions, and distortion coefficients. Emphasis was placed on the evaluation of solutions for camera calibration, calibration network design, and the assessment of software or toolboxes that support the correspondent geometry and calibration for processing. The efficiency in accuracy, correctness, computational time, and stability parameters was assessed with the influence of calibration parameters based on the accuracy of the 3D reconstruction. The assessment was conducted using a previous case study of graffiti on an underpass in Wiesbaden, Germany. The robust calibration solution is a two-step calibration process, including a pre-calibration stage and the consideration of the best possible network design. Fisheye undistortion was performed using OpenCV, and finally, calibration parameters were optimized with self-calibration through bundle adjustment to achieve both calibration parameters and 3D reconstruction using Agisoft Metashape software. In comparison to 3D calibration, self-calibration, and a pre-calibration strategy, the two-step calibration process has demonstrated an average improvement of 2826 points in the 3D sparse point cloud and a 0.22 m decrease in the re-projection error value derived from the front lens images of two individual spherical cameras. The accuracy and correctness of the 3D point cloud and the statistical analysis of parameters in the two-step calibration solution are presented as a result of the quality assessment of this paper and in comparison with the 3D point cloud produced by a laser scanner. Full article

This study compares the photogrammetric performance of three multi-camera systems—two spherical cameras (INSTA 360 Pro2 and MG1) and one multi-camera rig (ANT3D)—to evaluate their accuracy and precision in confined environments. These systems are particularly suited for indoor surveys, such as narrow spaces, where traditional methods face limitations. The instruments were tested for the survey of a narrow spiral staircase within Milan Cathedral and the results were analyzed based on different processing strategies, including different relative constraints between sensors, various calibration sets for distortion parameters, interior orientation (IO), and relative orientation (RO), as well as two different ground control solutions. This study also included a repeatability test. The findings showed that, with appropriate ground control, all systems achieved the target accuracy of 1 cm. In partially unconstrained scenarios, the drift errors ranged between 5 and 10 cm. Performance varied depending on the processing pipelines; however, the results suggest that imposing a multi-camera constraint between sensors and estimating both IO and RO parameters during the Bundle Block Adjustment yields the best outcomes. In less stable environments, it might be preferable to pre-calibrate and fix the IO parameters. Full article

The 3D modeling of urban buildings has become a common research area in various disciplines such as photogrammetry and computer vision, with different applications such as intelligent city management, navigation of self-driving cars and architecture, just to name a few. The objective of this study is to produce a 3D model of the external facade of the buildings with the required precision, accuracy and level of detail according to the user’s requirements, while minimizing time and cost. This research focuses on the production of 3D models for blocks of residential buildings in Tehran, Iran. The Insta 360 One X2 spherical camera is selected to capture the data due to its low cost and 360 × 180° field of view. The camera specifications have facilitated more efficient data collection in terms of both time and cost. The proposed modeling method is based on extracting lines of external walls through the utilization of the point cloud density concept. Initially, photogrammetric point clouds are generated in with a reconstruction precision of 0.24 m from spherical camera images. In the next step, the 3D point cloud is projected into a 2D point cloud by setting the height component to zero. The 2D point cloud is then rotated based on the direction angle determined by the Hough transform so that the perpendicular walls are parallel to the axes of the coordinate system. Next, a 2D point cloud density analysis is performed by voxelizing the point cloud and counting the number of points in each voxel in both the horizontal and vertical directions. By determining the peaks in the density plot, the lines of the external vertical and horizontal walls are extracted. To extract the diagonal external walls, the density analysis is performed in the direction of the first principal component. Finally, by determining the height of each wall in the point cloud, a 3D model is created at the level of detail one. The resulting model has a precision of 0.32 m compared to real sizes, and the 2D plan has a precision of 0.31 m compared to the ground truth map. The use of the spherical camera and point cloud density analysis makes this method efficient and cost-effective, making it a promising approach for future urban modeling projects. Full article

Vehicle-borne mobile mapping systems (MMSs) have been proven as an efficient means of photogrammetry and remote sensing, as they simultaneously acquire panoramic images, point clouds, and positional information along the collection route from a ground-based perspective. Obtaining accurate matching results between point clouds and images is a key issue in data application from vehicle-borne MMSs. Traditional matching methods, such as point cloud projection, depth map generation, and point cloud coloring, are significantly affected by the processing methods of point clouds and matching logic. In this study, we propose a method for generating matching relationships based on panoramic images, utilizing the raw point cloud map, a series of trajectory points, and the corresponding panoramic images acquired using a vehicle-borne MMS as input data. Through a point-cloud-processing workflow, irrelevant points in the point cloud map are removed, and the point cloud scenes corresponding to the trajectory points are extracted. A collinear model based on spherical projection is employed during the matching process to project the point cloud scenes to the panoramic images. An algorithm for vectorial angle selection is also designed to address filtering out the occluded point cloud projections during the matching process, generating a series of matching results between point clouds and panoramic images corresponding to the trajectory points. Experimental verification indicates that the method generates matching results with an average pixel error of approximately 2.82 pixels, and an average positional error of approximately 4 cm, thus demonstrating efficient processing. This method is suitable for the data fusion of panoramic images and point clouds acquired using vehicle-borne MMSs in road scenes, provides support for various algorithms based on visual features, and has promising applications in fields such as navigation, positioning, surveying, and mapping. Full article

Due to ever-accelerating urbanization in recent decades, exploring the contributions of trees in mitigating atmospheric carbon in urban areas has become one of the paramount concerns. Remote sensing-based approaches have been primarily implemented to estimate the tree-stand atmospheric carbon stock (CS) for the trees in parks and streets. However, a convenient yet high-accuracy computation methodology is hardly available. This study introduces an approach that has been tested for a small urban area. A data fusion approach based on a three-dimensional (3D) computation methodology was applied to calibrate the individual tree CS. This photogrammetry-based technique employed an unmanned aerial vehicle (UAV) and spherical image data to compute the total height (H) and diameter at breast height (DBH) for each tree, consequently estimating the tree-stand CS. A regression analysis was conducted to compare the results with the ones obtained with high-cost laser scanner data. Our study demonstrates the applicability of this method, highlighting its advantages even for large city areas in contrast to other approaches that are often more expensive. This approach could serve as an efficient tool for assisting urban planners in ensuring the proper utilization of the available green space, especially in a complex urban environment. Full article

This study describes the methodology and main results obtained after applying several geomatic techniques, based on the fusion of data acquired by several sensors, to document the recovery works carried out in an abandoned church. A century ago, the façade was moved to a museum to ensure its preservation. In addition to documentary purposes, a secondary goal is the virtual repositioning of a model of this element on that of the church. The method takes advantage of the potential of each technique, considering the acquisition of geometry based mainly on laser scanning techniques and radiometry on photogrammetry. The results include 3D models and orthoimages, which are used to perform a stratigraphic study. The 3D model of the façade has been repositioned in the general one, considering common geometries previously fitted in both models and repeating part of the photogrammetric process, using masks to define the image areas related to the church and the façade. Therefore, we obtained a 3D model with the façade included in it. This procedure has demonstrated its feasibility despite the existence of different environmental conditions in both areas. Using these results, we have also developed a BIM to allow for the management of future restoration works. Full article

Three-dimensional point cloud evaluation is used in photogrammetry to validate and assess the accuracy of data acquisition in order to generate various three-dimensional products. This paper determines the optimal accuracy and correctness of a 3D point cloud produced by a low-cost spherical camera in comparison to the 3D point cloud produced by laser scanner. The fisheye images were captured from a chessboard using a spherical camera, which was calibrated using the commercial Agisoft Metashape software (version 2.1). For this purpose, the results of different calibration methods are compared. In order to achieve data acquisition, multiple images were captured from the inside area of our case study structure (an underpass in Wiesbaden, Germany) in different configurations with the aim of optimal network design for camera location and orientation. The relative orientation was generated from multiple images obtained by removing the point cloud noise. For assessment purposes, the same scene was captured with a laser scanner to generate a metric comparison between the correspondence point cloud and the spherical one. The geometric features of both point clouds were analyzed for a complete geometric quality assessment. In conclusion, this study highlights the promising capabilities of low-cost spherical cameras for capturing and generating high-quality 3D point clouds by conducting a thorough analysis of the geometric features and accuracy assessments of the absolute and relative orientations of the generated clouds. This research demonstrated the applicability of spherical camera-based photogrammetry to challenging structures, such as underpasses with limited space for data acquisition, and achieved a 0.34 RMS re-projection error in the relative orientation step and a ground control point accuracy of nearly 1 mm. Compared to the laser scanner point cloud, the spherical point cloud reached an average distance of 0.05 m and acceptable geometric consistency. Full article

The segmentation of airborne laser scanning (ALS) point clouds remains a challenge in remote sensing and photogrammetry. Deep learning methods, such as KPCONV, have proven effective on various datasets. However, the rigid convolutional kernel strategy of KPCONV limits its potential use for 3D object segmentation due to its uniform approach. To address this issue, we propose an Integrated Point Convolution (IPCONV) based on KPCONV, which utilizes two different convolution kernel point generation strategies, one cylindrical and one a spherical cone, for more efficient learning of point cloud data features. We propose a customizable Multi-Shape Neighborhood System (MSNS) to balance the relationship between these convolution kernel point generations. Experiments on the ISPRS benchmark dataset, LASDU dataset, and DFC2019 dataset demonstrate the validity of our method. Full article

Urban forests, parks, and gardens are fundamental components of urban sustainability, resilience, and regenerative dynamics. Designers, architects, and landscape architects could smartly manage these dynamic ecosystems if efficiently provided with design-oriented digital tools, technologies, and techniques. However, practitioners lack knowledge and standardized procedures for their uses. The rise of low-cost sensors to generate 3D data (e.g., point clouds) in forestry can also effectively support monitoring, analysis, and visualization purposes for greenery in urban contexts. Adopting an interdisciplinary approach—involving the fields of forestry, geomatics, and computer science—this contribution addresses these issues and proposes a low-cost workflow for 3D virtual reconstructions of urban forests to support information management activities and thus landscape architecture applications. By connecting a wide range of methods (i.e., spherical photogrammetry, point cloud modeling), tools (i.e., 360° camera, tablet with lidar sensor), and software (i.e., Agisoft Metashape, CloudCompare, Autodesk AutoCAD), the proposed workflow is defined and tested in the development of dynamic virtual representations for a plot of the Mesiano University park in Trento (Italy). Finally, comparing acquisition, processing, and elaboration methodologies and their results, the possibility of developing digital twins of urban forests is envisioned. Full article

Spline functions are a useful tool for modelling the shape of shell structures. They have curvature continuity that allows good approximation accuracy for various objects, including hyperboloid cooling towers, spherical domes, paraboloid bowls of radio telescopes, or many other types of smooth free surfaces. Spline models can be used to determine the displacement of structures based on point clouds from laser scanning or photogrammetry. The curvature continuity of splines may, however, cause local distortions in models that have edges. Edges may appear in point clouds where surface patches are joined, on surfaces equipped with additional technical infrastructure or with cracks and shifts in the structure. Taking the properties of spline functions into account, several characteristic types of edge configurations can be distinguished, which may, to a different extent, affect the values of modelling errors. The research conducted below was aimed at identifying such configurations based on theoretical considerations and then assessing their effect on the accuracy of modelling shell structures measured by laser scanning. It turned out to be possible to distinguish between edge configurations, based on the deviation values. Full article
