The main function of triangulation-based laser profile sensors—also referred to as laser profilometers or profilers—is the three-dimensional scanning of moving objects using laser triangulation. In addition to capturing 3D data, these profilometers simultaneously generate grayscale images of the scanned objects. However, the quality of these images is often degraded due to interference of the laser light, manifesting as speckle noise. In profilometer images, this noise typically appears as vertical stripes. Unlike the column fixed pattern noise commonly observed in TDI CMOS cameras, the positions of these stripes are not stationary. Consequently, conventional algorithms for removing fixed pattern noise yield unsatisfactory results when applied to profilometer images. In this article, we propose an effective method for suppressing speckle noise in profilometer images of flat surfaces, based on local column median vectors. The method was evaluated across a variety of surface types and compared against existing approaches using several metrics, including the standard deviation of the column mean vector (SDCMV), frequency spectrum analysis, and standard image quality assessment measures. Our results demonstrate a substantial improvement in reducing column speckle noise: the SDCMV value achieved with our method is 2.5 to 5 times lower than that obtained using global column median values, and the root mean square (RMS) of the frequency spectrum in the noise-relevant region is reduced by nearly an order of magnitude. General image quality metrics also indicate moderate enhancement: peak signal-to-noise ratio (PSNR) increased by 2.12 dB, and the structural similarity index (SSIM) improved from 0.929 to 0.953. The primary limitation of the proposed method is its applicability only to flat surfaces. Nonetheless, we successfully implemented it in an optical inspection system for the furniture industry, where the post-processed image quality was sufficient to detect surface defects as small as 0.1 mm. Full article

This study presents a cutting-edge imaging technique for special unmanned vehicles (UAVs) designed to enhance tunnel inspection capabilities. This technique integrates ghost imaging inspired by the human visual system with lateral inhibition and variable resolution to improve environmental perception in challenging conditions, such as poor lighting and dust. By emulating the high-resolution foveal vision of the human eye, this method significantly enhances the efficiency and quality of image reconstruction for fine targets within the region of interest (ROI). This method utilizes non-uniform speckle patterns coupled with lateral inhibition to augment optical nonlinearity, leading to superior image quality and contrast. Lateral inhibition effectively suppresses background noise, thereby improving the imaging efficiency and substantially increasing the signal-to-noise ratio (SNR) in noisy environments. Extensive indoor experiments and field tests in actual tunnel settings validated the performance of this method. Variable-resolution sampling reduced the number of samples required by 50%, enhancing the reconstruction efficiency without compromising image quality. Field tests demonstrated the system’s ability to successfully image fine targets, such as cables, under dim and dusty conditions, achieving SNRs from 13.5 dB at 10% sampling to 27.7 dB at full sampling. The results underscore the potential of this technique for enhancing environmental perception in special unmanned vehicles, especially in GPS-denied environments with poor lighting and dust. Full article

This paper presents an analysis of different despeckling filters applied on both synthetically corrupted optical images and actual Synthetic Aperture Radar (SAR) images. Several authors use optical images as ground truth and then the images are corrupted by using a Gamma model to simulate the speckle, while other approaches use methods like multitemporal fusion to generate a ground truth using actual SAR images, which provides a result somehow equivalent to the one from the common multi look technique. Well-known filters, like local, and non-local and some of them based on artificial intelligence and deep learning, are applied to these two types of images and their performance is assessed by a quantitative analysis. One last validation is performed with a newly proposed method by using ratio images, resulting from the mathematical division (Hadamard division) of filtered and noisy images, to measure how similar the initial and the remaining speckle are by considering its Gamma distribution and divergence measurement. Our findings suggest that despeckling models relying on artificial intelligence exhibit notable efficiency, albeit concurrently displaying inflexibility when applied to particular image types based on the training dataset. Additionally, our experiments underscore the utility of the divergence measurement in ratio images in facilitating both visual inspection and quantitative evaluation of residual speckles within the filtered images. Full article

Electronic speckle pattern interferometry (ESPI) is widely used in fields such as materials science, biomedical research, surface morphology analysis, and optical component inspection because of its high measurement accuracy, broad frequency range, and ease of measurement. Phase extraction is a critical stage in ESPI. However, conventional phase extraction methods exhibit problems such as low accuracy, slow processing speed, and poor generalization. With the continuous development of deep learning in image processing, the application of deep learning in phase extraction from electronic speckle interferometry images has become a critical topic of research. This paper reviews the principles and characteristics of ESPI and comprehensively analyzes the phase extraction processes for fringe patterns and wrapped phase maps. The application, advantages, and limitations of deep learning techniques in filtering, fringe skeleton line extraction, and phase unwrapping algorithms are discussed based on the representation of measurement results. Finally, this paper provides a perspective on future trends, such as the construction of physical models for electronic speckle interferometry, improvement and optimization of deep learning models, and quantitative evaluation of phase extraction quality, in this field. Full article

In this paper, we propose a grain volume measurement method based on binocular structured light to address the need for fast and high-precision grain volume measurement in grain stocks. Firstly, we utilize speckle structured light imaging to tackle the image matching problem caused by non-uniform illumination in the grain depot environment and the similar texture of the grain pile surface. Secondly, we employ a semi-global stereo matching algorithm with census transformation to obtain disparity maps in grain bins, which are then converted into depth maps using the triangulation principle. Subsequently, each pixel in the depth map is transformed from camera coordinates to world coordinates using the internal and external parameter information of the camera. This allows us to construct 3D cloud data of the grain pile, including the grain warehouse scene. Thirdly, the improved European clustering method is used to achieve the segmentation of the three-dimensional point cloud data of the grain pile and the scene of the grain depot, and the pass-through filtering method is used to eliminate some outliers and poor segmentation points generated by segmentation to obtain more accurate three-dimensional point cloud data of the grain pile. Finally, the improved Delaunay triangulation method was used to construct the optimal topology of the grain surface continuous triangular mesh, and the nodes of the grain surface triangular mesh were projected vertically to the bottom of the grain warehouse to form several irregular triangular prisms; then, the cut and complement method was used to convert these non-plane triangular prisms into regular triangular prisms that could directly calculate the volume. The measured volume of the pile is then obtained by calculating the volume of the triangular prism. The experimental results indicate that the measured volume has a relative error of less than 1.5% and an average relative error of less than 0.5%. By selecting an appropriate threshold, the relative standard deviation can be maintained within 0.6%. The test results obtained from the laboratory test platform meet the requirements for field inspection of the granary. Full article

In the manufacturing industry, inspection systems play a crucial role in ensuring product quality. High-resolution profilometric sensors have become increasingly popular for inspection due to their ability to provide detailed surface information. However, the development and testing of inspection systems can be costly and time-consuming. This paper presents the development of a simulation of an inspection system using a high-resolution profilometric sensor. A geometrical and noise model is proposed to simulate the readings of any actual profilometric sensor. The model replicates the sensor’s movement on the CAD model of the inspected part. The model incorporates the physical properties of the sensor and combines noise sources from sensor uncertainty and speckle noise induced by the roughness of the material. Our contribution lies in noise modeling. This work proposes a combination of Perlin noise to simulate the speckle noise and Gaussian noise for the uncertainty-related noise. Perlin noise is generated based on the surface roughness parameters of the inspected part. The accuracy of the simulation system is evaluated by comparing the simulated scans with real scans. The results highlight the ability to simulate real scans of different parts, using commercial sensor specifications and the CAD model of the inspected part. Full article

Optical coherence tomography (OCT) is used in various fields such, as medical diagnosis and material inspection, as a non-invasive and high-resolution optical imaging modality. However, an OCT image is damaged by speckle noise during its generation, thus reducing the image quality. To address this problem, a non-local means (NLM) algorithm based on the fractional compact finite difference scheme (FCFDS) is proposed to remove the speckle noise in OCT images. FCFDS uses more local pixel information when compared to integer-order difference operators. The FCFDS operator is introduced into the NLM algorithm to construct a high-precision weight calculation so that the proposed algorithm can effectively reduce the speckle noise in the OCT images. Experiments on simulations and real OCT images show that the proposed method is comparable to other state-of-the-art despeckling methods and can substantially reduce noise and preserve image details such as edges and structures. Speckle noise removal can further promote the application of the proposed algorithm in medical diagnosis and industrial detection, as it has key research value. Full article

Speckle is an unavoidable noise-like phenomenon in Synthetic Aperture Radar (SAR) imaging. In order to remove speckle, many despeckling methods have been proposed during the past three decades, including spatial-based methods, transform domain-based methods, and non-local filtering methods. However, SAR images usually contain many different types of regions, including homogeneous and heterogeneous regions. Some filters could despeckle effectively in homogeneous regions but could not preserve structures in heterogeneous regions. Some filters preserve structures well but do not suppress speckle effectively. Following this theory, we design a combination of two state-of-the-art despeckling tools that can overcome their respective shortcomings. In order to select the best filter output for each area in the image, the clustering and Gray Level Co-Occurrence Matrices (GLCM) are used for image classification and weighting, respectively. Clustering and GLCM use the co-registered optical images of SAR images because their structure information is consistent, and the optical images are much cleaner than SAR images. The experimental results on synthetic and real-world SAR images show that our proposed method can provide a better objective performance index under a strong noise level. Subjective visual inspection demonstrates that the proposed method has great potential in preserving structural details and suppressing speckle noise. Full article

Electroluminescence (EL) imaging is a widely adopted method in quality assurance of the photovoltaic (PV) manufacturing industry. With the growing demand for high-quality PV products, automatic inspection methods based on machine vision have become an emerging area concern to replace manual inspectors. Therefore, this paper presents an automatic defect-inspection method for multi-cell monocrystalline PV modules with EL images. A processing routine is designed to extract the defect features of the PV module, eliminating the influence of the intrinsic structural features. Spectrum domain analysis is applied to effectively reconstruct an improved PV layout from a defective one by spectrum filtering in a certain direction. The reconstructed image is used to segment the PV module into cells and slices. Based on the segmentation, defect detection is carried out on individual cells or slices to detect cracks, breaks, and speckles. Robust performance has been achieved from experiments on many samples with varying illumination conditions and defect shapes/sizes, which shows the proposed method can efficiently distinguish intrinsic structural features from the defect features, enabling precise and speedy defect detections on multi-cell PV modules. Full article

In this research, we aim to propose an image sharpening method to make it easy to identify concrete cracks from blurred images captured by a moving camera. This study is expected to help realize social infrastructure maintenance using a wide range of robotic technologies, and to solve the future labor shortage and shortage of engineers. In this paper, a method to estimate parameters of motion blur for Point Spread Function (PSF) is mainly discussed, where we assume that there are two main degradation factors caused by the camera, out-of-focus blur and motion blur. A major contribution of this paper is that the parameters can properly be estimated from a sub-image of the object under inspection if the sub-image contains uniform speckled texture. Here, the cepstrum of the sub-image is fully utilized. Then, a filter convoluted PSF which consists of convolution with PSF (motion blur) and PSF (out-of focus blur) can be utilized for deconvolution of the blurred image for sharpening with significant effect. PSF (out-of-focus blur) is a constant function unique to each camera and lens, and can be confirmed before or after shooting. PSF (motion blur), on the other hand, needs to be estimated on a case-by-case basis since the amount and direction of camera movement varies depending on the time of shooting. Previous research papers have sometimes encountered difficulties in estimating the parameters of motion blur because of the emphasis on generality. In this paper, the main object is made of concrete, and on the surface of it there are speckled textures. We hypothesized that we can narrow down the candidates of parameters of motion blur by using these speckled patterns. To verify this hypothesis, we conducted experiments to confirm and examine the following two points using a general-purpose camera used in actual bridge inspections: 1. Influence on the cepstrum when the isolated point-like texture unique to concrete structures is used as a feature point. 2. Selection method of multiple images to narrow down the candidate minima of the cepstrum. It is novel that the parameters of motion blur can be well estimated by using the unique speckled pattern on the surface of the object. Full article

It is estimated that, in the Brazilian Amazon, forest degradation contributes three times more than deforestation for the loss of gross above-ground biomass. Degradation, in particular those caused by selective logging, result in features whose detection is a challenge to remote sensing, due to its size, space configuration, and geographical distribution. From the available remote sensing technologies, SAR data allow monitoring even during adverse atmospheric conditions. The aim of this study was to test different pre-trained models of Convolutional Neural Networks (CNNs) for change detection associated with forest degradation in bitemporal products obtained from a pair of SAR COSMO-SkyMed images acquired before and after logging in the Jamari National Forest. This area contains areas of legal and illegal logging, and to test the influence of the speckle effect on the result of this classification by applying the classification methodology on previously filtered and unfiltered images, comparing the results. A method of cluster detections was also presented, based on density-based spatial clustering of applications with noise (DBSCAN), which would make it possible, for example, to guide inspection actions and allow the calculation of the intensity of exploitation (IEX). Although the differences between the tested models were in the order of less than 5%, the tests on the RGB composition (where R = coefficient of variation; G = minimum values; and B = gradient) presented a slightly better performance compared to the others in terms of the number of correct classifications for selective logging, in particular using the model Painters (accuracy = 92%) even in the generalization tests, which presented an overall accuracy of 87%, and in the test on RGB from the unfiltered image pair (accuracy of 90%). These results indicate that multitemporal X-band SAR data have the potential for monitoring selective logging in tropical forests, especially in combination with CNN techniques. Full article

Accurate and automatic railhead inspection is crucial for the operational safety of railway systems. Deep learning on visual images is effective in the automatic detection of railhead defects, but either intensive data requirements or ignoring defect sizes reduce its applicability. This paper developed a machine learning framework based on wavelet scattering networks (WSNs) and neural networks (NNs) for identifying railhead defects. WSNs are functionally equivalent to deep convolutional neural networks while containing no parameters, thus suitable for non-intensive datasets. NNs can restore location and size information. The publicly available rail surface discrete defects (RSDD) datasets were analyzed, including 67 Type-I railhead images acquired from express tracks and 128 Type-II images captured from ordinary/heavy haul tracks. The ultimate validation accuracy reached 99.80% and 99.44%, respectively. WSNs can extract implicit signal features, and the support vector machine classifier can improve the learning accuracy of NNs by over 6%. Three criteria, namely the precision, recall, and F-measure, were calculated for comparison with the literature. At the pixel level, the developed approach achieved three criteria of around 90%, outperforming former methods. At the defect level, the recall rates reached 100%, indicating all labeled defects were identified. The precision rates were around 75%, affected by the insignificant misidentified speckles (smaller than 20 pixels). Nonetheless, the developed learning framework was effective in identifying railhead defects. Full article

This paper is a critical review of in situ full-field measurements provided by digital image correlation (DIC) for inspecting and enhancing additive manufacturing (AM) processes. The principle of DIC is firstly recalled and its applicability during different AM processes systematically addressed. Relevant customisations of DIC in AM processes are highlighted regarding optical system, lighting and speckled pattern procedures. A perspective is given in view of the impact of in situ monitoring regarding AM processes based on target subjects concerning defect characterisation, evaluation of residual stresses, geometric distortions, strain measurements, numerical modelling validation and material characterisation. Finally, a case study on in situ measurements with DIC for wire and arc additive manufacturing (WAAM) is presented emphasizing opportunities, challenges and solutions. Full article

Offshore oil and gas platforms present a harsh environment for their installed infrastructure, with pipelines that are subjected to both a corrosive atmosphere and transport of aggressive chemicals being the most critical. These conditions have prompted the industry to substitute metallic pipelines for composite counterparts, often made from fiber-reinforced plastics assembled with bonded joints. Various technologies have emerged in recent years to assess the health of these composite pipelines. In particular, robust speckle metrology techniques such as shearography, although not capable of long-term monitoring, have produced very satisfactory results. However, these inspection techniques require specialized equipment and trained personnel to be flown to offshore platforms, which can incur in non-trivial inspection costs. In this paper, we propose and demonstrate a robust and cost-effective approach to monitor pipeline bonded joints during assembly and operation using fiber Bragg grating (FBG) sensors embedded into the joints’ adhesive layer. This approach allows for informed decisions on when to perform targeted in-depth inspections (e.g., with shearography) based on both real-time and long-term feedback of the FBG sensors data, resulting in lower monitoring costs, a severe increase in monitoring uptime (up to full uptime), and increased operational security. Full article

Synthetic aperture radar (SAR) images contain severe speckle noise and weak texture, which are unsuitable for visual interpretation. Many studies have been undertaken so far toward exploring the use of SAR-to-optical image translation to obtain near optical representations. However, how to evaluate the translation quality is a challenge. In this paper, we combine image quality assessment (IQA) with SAR-to-optical image translation to pursue a suitable evaluation approach. Firstly, several machine-learning baselines for SAR-to-optical image translation are established and evaluated. Then, extensive comparisons of perceptual IQA models are performed in terms of their use as objective functions for the optimization of image restoration. In order to study feature extraction of the images translated from SAR to optical modes, an application in scene classification is presented. Finally, the attributes of the translated image representations are evaluated using visual inspection and the proposed IQA methods. Full article
