Search Results (49)

The article presents an approach to designing a low-orbit remote Earth sensing spacecraft. The low operational orbit of the satellite is maintained using a corrective electric propulsion system. The comprises an optical imaging system based on the Richey-Cretien telescope design augmented with an additional swivel reflection mirror. The optical system’s layout was optimized to minimize the spacecraft’s midsection area. This reduction in the frontal cross-sectional area decreases the aerodynamic drag forces exerted by the upper atmosphere, thereby reducing the propellant mass required for orbit maintenance. The article presents a model of constraints imposed by the satellite’s power supply system on the operating modes of the electric propulsion system and the orbit correction modes. Finally, a preliminary design of a low-orbit satellite, derived from the proposed approach, is presented. Full article

The aim of this paper is to analyze the transfer performance of a spacecraft equipped with a TANDEM electric propulsion system in a classical interplanetary mission scenario targeting Mars, Venus, or a near-Earth asteroid. The TANDEM concept is a coaxial, two-channel Hall-effect thruster recently proposed under ESA’s Technology Development Element program. This innovative propulsion system, currently undergoing experimental characterization, is designed to operate at power levels between $3\mathrm{kW}$ and $25\mathrm{kW}$, delivering a maximum thrust of approximately $1\mathrm{N}$. Its architecture allows operation using a single channel (internal or external) or both channels simultaneously to achieve maximum thrust. This inherent flexibility enables the definition of advanced control strategies for future missions employing such a propulsion system. In the context of a heliocentric mission scenario, this paper adopts a simplified thrust model based on actual thruster characteristics and a semi-analytical model for spacecraft mass breakdown. Transfer performance is evaluated within an optimization framework in terms of time of flight and the corresponding propellant mass consumption as functions of the main spacecraft design parameters. Full article

We study thrust production in a single-fluid magnetohydrodynamic (MHD) thruster with Hall-type coaxial geometry and show how velocity–field alignment and magnetic topology set the operating regime. Starting from the momentum equation with anisotropic conductivity, the axial Lorentz force density reduces to $f_z={\sigma }_{\theta z}{E}_z{B}_r(\chi -1)$, with the motional-field ratio $\chi \equiv \left(u{B}_r\right)/E_z$. Hence, net accelerating force ($f_z>0$) is achieved if and only if the motional electric field $E_m=u{B}_r$ exceeds the applied axial bias $E_z$ ($\chi >1$), providing a compact, testable design rule. We separate alignment diagnostics (cross-helicity $h_c=\mathit{u}·\mathit{B}$) from the thrust criterion ($\chi$) and generate equation-only axial profiles for $\chi \left(z\right)$, $j_{\theta }\left(z\right)$, and $f_z\left(z\right)$ for representative parameters. In a baseline case $(E_z=150\mathrm{V}{\mathrm{m}}^{-1},{\sigma }_{\theta z}=50\mathrm{S}{\mathrm{m}}^{-1},u_0=12\mathrm{km}{\mathrm{s}}^{-1},B_{r0}=0.02\mathrm{T},L=0.10\mathrm{m})$, the $\chi >1$ band spans $\approx 21.2\%$ of the channel; a lagged correlation peaks at $\Delta z^{★}\approx 8.82\mathrm{mm}$$(C_{HU}=0.979)$, and ${\int }_0^L{f}_z\mathrm{d}z$ is slightly negative—indicating that enlarging the $\chi >1$ region or raising ${\sigma }_{\theta z}$ are effective levers. We propose a reproducible validation pathway (finite-volume MHD simulations and laboratory measurements: PIV, Hall probes, and thrust stand) to map $f_z$ versus $\chi$ and verify the response length. The framework yields concrete design strategies—$B_r\left(z\right)$ shaping where u is high, conductivity control, and modest $E_z$ tuning—supporting applications from station-keeping to deep-space cruise. Full article

A Multimode Propulsion System (MPS) is an innovative spacecraft thruster concept that integrates two or more propulsion modes sharing the same type of propellant. A spacecraft equipped with an MPS can potentially combine the advantages of continuous-thrust electric propulsion and medium-to-high-thrust chemical propulsion within a single vehicle, while reducing the overall mass compared to traditional configurations where each propulsion system uses a different propellant. This feature makes the MPS concept particularly attractive for small spacecraft, such as the well-known CubeSats, which have now reached a high level of technological maturity and are employed not only in geocentric environments but also in interplanetary missions as support elements for conventional deep-space vehicles. Within the MPS framework, a Monopropellant-Electrospray Multimode Propulsion System (MEMPS) represents a specific type of micropropulsion technology that enables a single miniaturized propulsion unit to operate in either catalytic-chemical or electrospray-electric mode. This paper investigates the flight performance of a MEMPS-equipped CubeSat in a classical circle-to-circle orbit-raising (or lowering) maneuver within a two-dimensional mission scenario. Specifically, the study derives the optimal guidance law that allows the CubeSat to follow a transfer trajectory optimized either for minimum flight time or minimum propellant consumption, starting from a parking orbit of assigned radius and targeting a final circular orbit. Numerical simulations indicate that a heliocentric orbit raising, increasing the initial solar distance by $20\%$, can be achieved with a flight time of approximately 11 months and a propellant consumption slightly below 6 kg. The proposed method is applied to a heliocentric case study, although the procedure can be readily extended to geocentric transfer missions, which represent a more common application scenario for current CubeSat-based scientific missions. Full article

The use of continuous-thrust propulsion systems allows spacecraft to cover complex space trajectories and to complete missions that would be difficult using chemical thrusters. Among the continuous-thrust propulsion systems proposed in recent decades, solar electric thrusters occupy an important position thanks to the maturity reached by this technology. Technological advances in the miniaturization of spacecraft components allow an electric thruster to be installed even in a small and standardized vehicle such as a CubeSat. In this context, the BIT-3 RF ion thruster is an interesting option that has been recently employed in some space missions for the study of the lunar surface. In the recent literature, the performance of a CubeSat equipped with a propulsion system based on the BIT-3 has been studied considering a simplified model in which the thrust magnitude has a fixed value or varies continuously within a prescribed range. However, the operating levels of a BIT-3 are finite in number. This paper studies the transfer performance of a BIT-3-propelled CubeSat considering the actual operating levels that can be provided by such a thruster. The work analyzes the optimal transfer towards asteroid 2000 SG344 when the electric power is obtained through solar arrays. Full article

The electric solar wind sail (E-sail) is a propellantless propulsion system concept based on the use of a system of very long and thin conducting tethers, which create an artificial electric field that is able to deflect the solar-wind-charged particles in order to generate a net propulsive acceleration outside the planetary magnetospheres. The radial rig of conducting tethers is deployed and stretched by rotating the spacecraft about an axis perpendicular to the nominal plane of the sail. This rapid rotation complicates the thrust vectoring of the E-sail-based spacecraft, which is achieved by changing the orientation of the sail nominal plane with respect to an orbital reference frame. For this reason, some interesting steering techniques have recently been proposed which are based, for example, on maintaining the inertial direction of the spacecraft spin axis or on limiting the excursion of the so-called pitch angle, which is defined as the angle formed by the unit vector perpendicular to the sail nominal plane with the (radial) direction of propagation of the solar wind. In this paper, a different control strategy based on maintaining the pitch angle value constant during a typical interplanetary flight is investigated. In this highly constrained configuration, the spacecraft spin axis can rotate freely around the radial direction, performing a sort of conical motion around the Sun-vehicle line. Considering an interplanetary Earth–Venus or Earth–Mars mission scenario, the flight performance is here compared with a typical unconstrained optimal transfer, aiming to quantify the flight time variation due to the pitch angle value constraint. In this regard, simulation results indicate that the proposed control law provides a rather limited (percentage) performance variation in the case where the reference propulsive acceleration of the E-sail-based spacecraft is compatible with a medium- or low-performance propellantless propulsion system. Full article

Hohmann transfer is the classical approach used in astrodynamics to analyze the optimal bi-impulsive transfer, from the point of view of the total velocity change, between two circular, coplanar orbits of assigned radius. The Hohmann transfer is characterized by an elliptical trajectory tangent to both circular orbits at the points where the transfer begins or ends and can be used to simply model, in a Kepler problem, a possible optimal transfer of a spacecraft equipped with a high-thrust propulsion system. Recent literature has proposed a sort of extension of the Hohmann transfer to a heliocentric mission scenario, where the total velocity change is reduced compared to the classical result by employing a photonic solar sail operating along the deep-space transfer trajectory. The study of this so-called augmented Hohmann transfer, where the spacecraft uses both two tangential impulses (one at the beginning and one at the end of the flight) provided by a high-thrust propulsion system and the propulsive acceleration (during the flight) provided by a low-thrust propulsion system, is extended in this paper by considering a more general case where the spacecraft moves around a generic primary body and uses, along the transfer, a freely orientable propulsive acceleration vector with constant and assigned magnitude. This scenario is consistent, for example, with the use of a typical electric thruster instead of the photonic solar sail considered in recent literature. In particular, the paper studies the impact of the continuous-thrust propulsion system on the transfer performance between the two circular orbits, analyzing the variation of the total velocity change as a function of the propulsive acceleration magnitude. The procedure, which uses an optimal approach to performance estimation, can be used both in a heliocentric and planetocentric mission scenario and can also be employed to analyze the performance of a spacecraft equipped with a multimode propulsion system. Full article

The study of the Earth’s magnetosphere through in situ observations is an important step in understanding the evolution of the Sun–Earth interaction. In this context, the long-term observation of the Earth’s magnetotail using a scientific probe in a high elliptical orbit is a challenging mission scenario due to the alignment of the magnetotail direction with the Sun–Earth line, which requires a continuous rotation of the apse line of the spacecraft’s geocentric orbit. This aspect makes the mission scenario particularly suitable for space vehicles equipped with propellantless propulsion systems, such as the classic solar sails which convert the solar radiation pressure into propulsive acceleration without propellant expenditure. However, a continuous rotation of the apse line of the osculating orbit can be achieved using a more conventional solar electric thruster, which introduces an additional constraint on the duration of the scientific mission due to the finite mass of the propellant stored on board the spacecraft. This paper analyzes the potential of a typical CubeSat equipped with a commercial miniaturized electric thruster in performing the rotation of the apse line of a geocentric orbit suitable for the in situ observation of the Earth’s magnetotail. The paper also analyzes the impact of the size of a thruster array on the flight performance for an assigned value of the payload mass and the science orbit’s characteristics. In particular, this work illustrates the optimal guidance laws that allow us to maximize the duration of the scientific mission for an assigned CubeSat’s configuration. In this sense, this paper expands the literature regarding the study of this interesting mission scenario by extending the study to conventional propulsion systems that use a propellant to provide a continuous and steerable thrust vector. Full article

This paper outlines the development phases of a wave-driven Helicon Plasma Thruster for cutting-edge Low Earth Orbit (LEO) constellations. The two-stage ambipolar electric propulsion (EP) system combines the efficient ionization of an ultra-compact helicon reactor with plasma acceleration based on an ambipolar electric field provided by a magnetic nozzle. This paper reveals maturation challenges associated with an emerging EP system in the hundreds-watt class, followed by outlook strategies. A 3 cm diameter helicon reactor was operated using argon gas under a time-modulated RF power envelope ranging from 250 W to 500 W with a fixed magnetic field strength of 400 G. Magnetically enhanced inductively coupled plasma reactor characteristics based on half-wavelength right helical and Nagoya Type III antennas under capacitive (E-mode), inductive (W-mode), and wave coupling (W-mode) were systematically investigated based on Optical Emission Spectroscopy. The operation characteristics of a wave-heated reactor based on helicon configuration were investigated as a function of different operating parameters. This work demonstrates the ability of two-stage HPT using a compact helicon reactor and a cusped magnetic field to outperform today’s LEO spacecraft propulsion. Full article

Propellantless propulsion systems, such as the well-known photonic solar sails that provide thrust by exploiting the solar radiation pressure, theoretically allow for extremely complex space missions that require a high value of velocity variation to be carried out. Such challenging space missions typically need the application of continuous thrust for a very long period of time, compared to the classic operational life of a space vehicle equipped with a more conventional propulsion system as, for example, an electric thruster. In this context, an interesting application of this propellantless thruster consists of using the solar sail-induced acceleration to artificially precess the apse line of a planetocentric elliptic orbit. This specific mission application was thoroughly investigated about twenty years ago in the context of the GeoSail Technology Reference Study, which analyzed the potential use of a spacecraft equipped with a small solar sail to perform an in situ study of the Earth’s upper magnetosphere. Taking inspiration from the GeoSail concept, this study analyzes the performance of a solar sail-based spacecraft in (artificially) precessing the apse line of a high elliptic orbit around Venus with the aim of exploring the planet’s induced magnetotail. In particular, during flight, the solar sail orientation is assumed to be Sun-facing, and the required thruster’s performance is evaluated as a function of the elliptic orbit’s characteristics by using both a simplified mathematical model of the spacecraft’s planetocentric dynamics and an approximate analytical approach. Numerical results show that a medium–low-performance sail is able to artificially precess the apse line of a Venus-centered orbit in order to ensure the long-term sensing of the planet’s induced magnetotail. Full article

The Electric Solar Wind Sail (E-sail) deflects charged particles from the solar wind through an artificial electric field to generate thrust in interplanetary space. The structure of a spacecraft equipped with a typical E-sail essentially consists in a number of long conducting tethers deployed from a main central body, which contains the classical spacecraft subsystems. During flight, the reference plane that formally contains the conducting tethers, i.e., the sail nominal plane, is inclined with respect to the direction of propagation of the solar wind (approximately coinciding with the Sun–spacecraft direction in a preliminary trajectory analysis) in such a way as to vary both the direction and the module of the thrust vector provided by the propellantless propulsion system. The generation of a sail pitch angle different from zero (i.e., a non-zero angle between the Sun–spacecraft line and the direction perpendicular to the sail nominal plane) allows a transverse component of the thrust vector to be obtained. From the perspective of attitude control system design, a small value of the sail pitch angle could improve the effectiveness of the E-sail attitude maneuver at the expense, however, of a worsening of the orbital transfer performance. The aim of this paper is to investigate the effects of a constraint on the maximum value of the sail pitch angle, on the performance of a spacecraft equipped with an E-sail propulsion system in a typical interplanetary mission scenario. During flight, the E-sail propulsion system is considered to be always on so that the entire transfer can be considered a single propelled arc. A heliocentric orbit-to-orbit transfer without ephemeris constraints is analyzed, while the performance analysis is conducted in a parametric form as a function of both the maximum admissible sail pitch angle and the propulsion system’s characteristic acceleration value. Full article

The recent technology advancements in miniaturizing the primary components of spacecraft allow the classic CubeSats to be considered as a valid option in the design of a deep space scientific mission, not just to support a main typical interplanetary spacecraft. In this context, the proposed ESA M-ARGO mission, whose launch is currently planned in 2026, will use the electric thruster installed onboard of a 12U CubeSat to transfer the small satellite from the Sun–Earth second Lagrangian point to the orbit of a small and rapidly spinning asteroid. Starting from the surrogate model of the M-ARGO propulsion system proposed in the recent literature, this paper analyzes a simplified thrust vector model that can be used to study the heliocentric optimal transfer trajectory with a classical indirect approach. This simplified thrust model is a variation of the surrogate one used to complete the preliminary design of the trajectory of the M-ARGO mission, and it allows to calculate, in an analytical form, the typical Euler–Lagrange equations without singularities. The thrust model is then used to study the performance of a M-ARGO-type CubeSat (MTC) in a different scenario (compared to that of the real mission), in which the small satellite moves along a circular heliocentric orbit in the context of a classic phasing maneuver. In this regard, the work discusses a simplified study of the optimal constrained MTC transfer towards one of the two Sun–Earth triangular Lagrangian points. Therefore, the contributions of this paper are essentially two: the first is the simplified thrust model that can be used to analyze the heliocentric trajectory of a MTC; the second is a novel mission application of a CubeSat, equipped with an electric thruster, moving along a circular heliocentric orbit in a phasing maneuver. Full article

This paper discusses the optimal control law, in a three-dimensional (3D) heliocentric orbit transfer, of a spacecraft whose primary propulsion system is a Solar Wind Ion Focusing Thruster (SWIFT). A SWIFT is an interesting concept of a propellantless thruster, proposed ten years ago by Gemmer and Mazzoleni, which deflects, collects, and accelerates the charged particles of solar wind to generate thrust in the interplanetary space. To this end, the SWIFT uses a large conical structure made of thin metallic wires, which is positively charged with the aid of an electron gun. In this sense, a SWIFT can be considered as a sort of evolution of the Janhunen’s E-Sail, which also uses a (nominally flat) mesh of electrically charged tethers to deflect the solar wind stream. In the recent literature, the optimal performance of a SWIFT-based vehicle has been studied by assuming a coplanar orbit transfer and a two-dimensional scenario. The mathematical model proposed in this paper extends that result by discussing the optimal guidance laws in the general context of a 3D heliocentric transfer. In this regard, a number of different forms of the spacecraft state vectors are considered. The validity of the obtained optimal control law is tested in a simplified Earth–Venus and Earth–Mars transfer by comparing the simulation results with the literature data in terms of minimum flight time. Full article

Orifice Hollow Cathodes are electric devices necessary for the functioning of common plasma thrusters for space applications. Their reliability mainly depends on the success of a spacecraft’s mission equipped with electric propulsion. The development of plasma models is crucial in the evaluation of plasma properties within the cathodes that are difficult to measure due to the small dimensions. Many models, based on non-linear systems of plasma equations, have been proposed in the openiterature. These are solved commonly by means of iterative procedures. This paper investigates the possibility of solving them by means of the Particle Swarm Optimization method. The results of the validation tests confirm the expected trends for all the unknowns; the confidence bound of the discharge current as a function of mass flow rate is very narrow (2 ÷ 5) V); moreover, the results match very well the experimental data except at theowest mass flow rate (0.08 mg/s) and discharge current (1A), where the computations underpredict the discharge current to the utmost by 40%. The highest data dispersion regards the plasma density in the emitter region (±20% of the average value) and the wall temperatures (±50 K with respect to the average values) of the orifice and insert; those of the others variables are very tiny. Full article

The Electric Solar Wind Sail (E-sail) is a propellantless propulsion system that converts solar wind dynamic pressure into a deep-space thrust through a grid of long conducting tethers. The first flight test, needed to experience the true potential of the E-sail concept, is likely to be carried out using a single spinning cable deployed from a small satellite, such as a CubeSat. This specific configuration poses severe limitations to both the performance and the maneuverability of the spacecraft used to analyze the actual in situ thruster capabilities. In fact, the direction of the spin axis in a single-tether configuration can be considered fixed in an inertial reference frame, so that the classic sail pitch angle is no longer a control variable during the interplanetary flight. This paper aims to determine the polar form of the propelled trajectory and the characteristics of the osculating orbit of a spacecraft propelled by a low-performance spinning E-sail with an inertially fixed axis of rotation. Assuming that the spacecraft starts the trajectory from a parking orbit that coincides with the Earth’s heliocentric orbit and that its spin axis belongs to the plane of the ecliptic, a procedure is illustrated to solve the problem accurately with a set of simple analytical relations. Full article
