In order to explore the influence of wheel surface structure on the trafficability of planetary rovers on soft ground, three kinds of wheels with different rigid wheel surface structures were selected for research. The basic performance parameters of the wheel on simulated planetary soil are measured and tested to explore the law of the wheel’s sinkage, slip rate and traction coefficient. The results show that the wheel grouser increases the sinkage and slip rate of the wheel. The tread reduces the sinkage of the wheel, but it also reduces the traction performance of the wheel at a higher slip rate. Considering the complex working conditions of the planetary rover on the soft ground, the six-wheeled three-rocker-arm planetary rover is used to carry out passability tests in three terrains: obstacle crossing, out of sinkage and climbing. The results show that the grousers can cause disturbance and damage to the soft soil and have significant passing advantages. There may also be a slip phenomenon when crossing the obstacle, but it does not affect passing. The completely closed tread structure will cause soil accumulation between the tread and the grouser, affecting the wheel’s ability to escape sinkage. This study provides a reference for the design of a rigid wheel surface structure for planetary rovers from the perspective of passing performance. Full article

In the exploration missions for Mars and the Moon, rovers with legs as mobility mechanisms are necessitated owing to their high mobility. However, the surface of Mars and the Moon is loose, leading the rovers to slip by virtue of the ground easily deforming due to the leg movements of the rover. A walking method aimed at preventing slippage was proposed to address this issue. Prior studies have confirmed that applying vibrations increases the shear strength of the ground and sinkage of the rover legs, thereby enhancing bearing capacity, that is, the resistance force exerted on the legs of the rover by the ground. Identifying the optimal vibration is crucial for maximizing performance. This study investigated the relationship between bearing capacity and vibration acceleration, revealing a correlation between the peak bearing capacity and the main vibration acceleration spectra. This finding provides insight into determining the optimal time for imparting vibrations to the ground, thereby improving the performance of space exploration rovers. Full article

Small wheeled lunar rovers tend to dig into surfaces via wheel rotation, causing them to slip and get stuck on regolith. Additionally, reducing power consumption remains a longstanding challenge. This study created a small two-wheeled rover and conducted tests at various wheel rotation speeds to assess the effects of rotation speed on its running performance. Through running tests and the measurement of reaction force, the influence of different wheel rotation speeds on running performance was clarified. Running at low rotation speeds prevented slipping and sinking. Additionally, the amount of sinkage was shown to converge to a certain level even at higher rotation speeds. These findings suggest that the maximum wheel rotation speed at which the rover avoids getting stuck allows the rover to achieve running with low-power consumption. Full article

It is very easy for a small lunar rover to slip on the regolith of the lunar surface and become stuck. Previous studies have quantitatively evaluated the effects of wheel geometry, such as elliptical or eccentric wheels, on the performance of a rover when climbing up slopes. These studies reported that the rovers were able to run on a 30-degree slope made of silica sand. In this study, a small rover was designed and created, and running tests were conducted using lunar soil simulant and silica sand to predict its performance on the lunar surface. The effects of soil differences on the performance of the rover were clarified through the running tests and the measurement of reaction force on the lug. Although the rover exhibited a greater slip ratio on the lunar soil simulant than on the silica sand, the rover with eccentric wheels was able to climb up to a 30-degree angle on the lunar soil simulant. The results for the sinkage measurement of the rover showed that the eccentric wheels prevented sinkage with their up-and-down motion, enabling the rover to climb steep slopes. Furthermore, the tests for measuring the reaction force on the lug indicated that the density change in the lunar soil simulant did not provide sufficient reaction force, and that the running performance on the lunar soil simulant was lower than that on the silica sand. Full article

Trafficability gives tracked vehicles adaptability, stability, and propulsion for various purposes, including deep-sea research in rough terrain. Terrain characteristics affect tracked vehicle mobility. This paper investigates the soil mechanical interaction dynamics between rubber-tracked vehicles and sedimental soils through controlled laboratory-simulated experiments. Focusing on Bentonite and Diatom sedimental soils, which possess distinct shear properties from typical land soils, the study employs innovative user-written subroutines to characterize mechanical models linked to the RecurDyn simulation environment. The experiment is centered around a dual-tracked crawler, which in itself represents a fully independent vehicle. A new three-dimensional multi-body dynamic simulation model of the tracked vehicle is developed, integrating the moist terrain’s mechanical model. Simulations assess the vehicle’s trafficability and performance, revealing optimal slip ratios for maximum traction force. Additionally, a mathematical model evaluates the vehicle’s tractive trafficability based on slip ratio and primary design parameters. The study offers valuable insights and a practical simulation modeling approach for assessing trafficability, predicting locomotion, optimizing design, and controlling the motion of tracked vehicles across diverse moist terrain conditions. The focus is on the critical factors influencing the mobility of tracked vehicles, precisely the sinkage speed and its relationship with pressure. The study introduces a rubber-tracked vehicle, pressure, and moisture sensors to monitor pressure sinkage and moisture, evaluating cohesive soils (Bentonite/Diatom) in combination with sand and gravel mixtures. Findings reveal that higher moisture content in Bentonite correlates with increased track slippage and sinkage, contrasting with Diatom’s notable compaction and sinkage characteristics. This research enhances precision in terrain assessment, improves tracked vehicle design, and advances terrain mechanics comprehension for off-road exploration, offering valuable insights for vehicle design practices and exploration endeavors. Full article

When traversing soft and rugged terrain, a planetary rover is susceptible to slipping and sinking, which impedes its movement. The real-time detection of wheel sinkage in the planetary wheel-on-limb system is crucial for enhancing motion safety and passability on such terrain. Initially, this study establishes a measurement of wheel sinkage under complex terrain conditions. Subsequently, a monocular vision-based wheel sinkage detection method is presented by combining the wheel–terrain boundary with the wheel center position (WTB-WCP). The method enables the efficient and accurate detection of wheel sinkage through two-stage parallel computation of the wheel–terrain boundary fitting and wheel center localization. Finally, this study establishes an experimental platform based on a monocular camera and the planetary rover wheel-on-limb system to experimentally validate and comparatively analyze the proposed method. The experimental results demonstrate that the method effectively provides information on the wheel sinkage of the planetary rover wheel-on-limb system, and the relative errors of the method do not exceed 4%. The method has high accuracy and reliability and is greatly significant for the safety and passability of planetary rovers in soft and rugged terrain. Full article

The surface of the Moon and planets have been covered with loose soil called regolith, and there is a risk that the rovers may stack, so it is necessary for them to recognize the traveling state such as its posture, slip behavior, and sinkage. There are several methods for recognizing the traveling state such as a system using cameras and Lidar, and they are used in real exploration missions like Mars Exploration Rovers of NASA/JPL. When a rover travels and travels across loose soil with steep slopes like a side wall of a crater on the lunar surface, the rover has side slipping. It means that its behavior makes the rover slip down to the valley direction. Even if this detection uses sensors like a camera and Lidar or other controlling systems like SLAM (Simultaneous Localization and Mapping), it would be too difficult for the rover to avoid slipping down to valley direction, because it is not able to detect the traction or resistance given from ground by individual wheel of the rover, as the traction of individual wheel of the rover is not clear. This means that the movement of the rover appeared by integrating the traction of all wheels mounted on the rover. Even if the localization by sensors is carried out, the location would be the location after slipping down. This is because when traveling on unstable ground, the driving force of each individual wheel cannot be accurately predicted, and the sum of the driving force of all wheels is the motion of the rover, which is detected after the position changes. Therefore, if the rover obtains information on the traction of each wheel, its maneuver to change its posture would work sooner and it would be able to travel more efficiently than in a state without that information. Because the onboard computer of rovers can identify their location and state from the information of the traction of each wheel, they can decide the next work carefully and in detail. From these tasks, we focused on the intrinsic sensation of a biological function like a human body and aimed to develop a system that recognizes the traveling state (slip condition) from the shape deformation of the chassis. In this study, we experimentally verified the relationship between the change in strain, which is the amount of deformation acting on the chassis, and the traveling state while the wheel is traveling. From the experimental results, we confirmed that the strain in the chassis was displaced dynamically and that the strain changed oscillatory while the wheel was traveling. In addition, based on the function of muscle spindles as mechanoreceptors, we discussed two methods of analyzing strain change: nuclear chain fiber analysis and nuclear bag fiber analysis. These analyses mean that the raw data of the strain are updated to detect the characteristic strain elements of a chassis while the wheel is traveling through loose soil. Eventually, the slipping state could be estimated by updating the data of a lot of strain raw data, and it was confirmed that the traveling state could be detected. Full article

Whether the subsea micro-drilling vehicle (SMDV) can perform its subsequent operations safely depends on the quality of the landing procedure. RecurDyn creates the SMDV dynamic model for this study. A model of the interaction between the SMDV and deep-sea sediment is built, and a simulation of the SMDV falling on the sea’s sediment substrate is developed. The water resistance is applied to the model by equivalent height replacement, and the in-situ soil data is measured with a triaxial undrained unconsolidated (UU) compression test and a load-sinkage experiment. When the landing surface is a flat sediment substrate, the release height is 5 m, the sinkage amount is 347 mm, and the center of mass’s impact acceleration is less than seven gravitational accelerations. Three states can occur when the vehicle lands on a sloped surface: stability, slip, and overturning. The risk of slipping and overturning is the least when the vehicle is landing on the ground in the forward direction, and the risk is equal when it lands on the ground in the backward and sideways directions. The ultimate overturning angle drops, and the final slip angle remains relatively constant as the vehicle’s release height increases. Our findings offer a theoretical foundation for the SMDV’s safe landing and the scientific formulation of rational release intervals. Full article

In view of the problems that the fuselage inclines and the driving straightness is difficult to guarantee due to the sinking and sliding of the wheels when the high-clearance plant protection machine is working in the paddy field, this paper takes high-clearance wheels as the research object, based on the paddy field driving environment, establishes a prediction model of the wheel subsidence through derivation, and explores the influence of different wheel parameters on the subsidence characteristics through experiments, so as to improve the chassis trafficability. At the same time, using the test data under different wheel parameters, the prediction model of the settlement of the working chassis with high clearance is correspondingly modified. Finally, the paddy field trafficability of the working chassis is compared and analyzed based on different tire parameters. The results show that when the wheel slip rate is 0.5, the traction force of the solid tire is 37% higher than that of the pneumatic tire; when the height of the wheel spike increases, the traction force increases, and the settlement decreases obviously; proper increase of the wheel diameter can improve the passing performance of the chassis; with the increase of the tire width, the angle of soil penetration decreases while the tire is driving, and the angle of the slope climbing increases; and when the load changes, the driving coefficient is proportional to the traction coefficient, and the tire resistance coefficient is inversely proportional to the traction coefficient. Through the research on the settlement mechanism of the high-clearance operation chassis and the analysis of the paddy field trafficability, the stability of the high-clearance plant protection machine in the paddy field has been improved, providing a platform and guarantee for subsequent precision operation. Full article

The driving performance of an off-road vehicle is closely related to soil strength. A bevameter is used to measure the soil strength, and it usually consists of two independent devices: a pressure–sinkage test device and a shear test device. However, its development and measurement processes have not been standardized; thus, researchers apply it in various fields according to their own discretion. In this study, a new bevameter was developed, and experiments were conducted to clarify the factors that affect the measurement performance of the bevameter. The pressure–sinkage test device was tested with circular plates of different sizes, and the results confirmed that the pressure–sinkage parameters decreased with the plate size. For the shear-test device, normal pressure was applied using a dead load to prevent normal-pressure variation due to displacement and speed. In addition, a spline was installed on top of the shaft connected to the shear ring to measure slip sinkage during the shear test. The results showed that the slip sinkage increased in proportion to the normal pressure and slip displacement, but the increase gradually decreased and converged to a certain point. Full article

In this work, a multibody model of a small size farming tracked vehicle is shown. Detailed models of each track were coupled with the rigid body model of the vehicle. To describe the interaction between the track and the ground in case of deformable soil, custom defined forces were applied on each link of the track model. Their definition derived from deformable soil mechanics equations implemented with a specifically designed routine within the multibody code. According to the proposed model, it is assumed that the main terrain deformation is concentrated around the vehicle tracks elements. The custom defined forces included also the effects of the track grousers which strongly affect the traction availability for the vehicle. A passive soil failure model was considered to describe the terrain behaviour subjected to the grousers action. A so developed model in a multibody code can investigate vehicle performance and limit operating conditions related to the vehicle and soil characteristics. In this work, particular attention was focused on the results in terms of traction force, slip and sinkage on different types of terrain. Tests performed in the multibody environment show how the proposed model is able to obtain tractive performance similar to equivalent analytical solutions and how the grousers improve the availability of tractive force for certain type of soil characteristics. Full article

When an off-road tracked vehicle travels, shearing action and ground sinkage occur on the soil–track interface, severely affecting the tractive performance of the vehicle. Notably, ground sinkage, which is induced by the vehicle’s weight (static sinkage) and longitudinal forces in the direction of travel producing slip (slip sinkage), develops motion resistance, directly restricting the tracked vehicle’s performance. Thus, it is critical to consider both static sinkage and slip sinkage to assess the tractive performance of a tracked vehicle. In this research, model track experiments were conducted to investigate slip sinkage. The experimental results showed that the slip sinkage increased as the slip ratio increased, but the rate of increase decreased. The slip sinkage was found to increase as the density of the ground decreased and imposed vertical load increased. The experimental results were used to calculate normalized slip sinkage, and an empirical equation for slip sinkage in terms of slip ratio was developed. This equation will allow vehicle operators to predict the slip sinkage and associated motion resistance for given soil and vehicle conditions. Full article
