Multiphase permanent-magnet motors are very attractive solutions for a large variety of applications, and specifically for electric vehicle applications. However, with a higher number of stator phases, multiphase permanent-magnet motors are more subjected to stator failures. Thus, diagnosing the stator status is necessary to guarantee the required efficiency of the motor. This paper deals with two techniques suitable for detecting and localizing open-phase faults in closed-loop controlled six-phase AC permanent-magnet motors. More specifically, this paper is aimed at assessing the diagnosis of open-phase faults based on current and voltage signature analysis. It is shown that the presence of specific harmonics can significantly affect the diagnosis process. Here, two diagnostic space vectors elaborated in the fifth α-β plane, based on the current and voltage signals, are proposed to cope with this limitation. The main contributions of the proposed approach are its implementation simplicity, and the effective immunity of the current-based analysis and voltage-based analysis against harmonic disturbances. The effectiveness of the proposed diagnostic space vector has been analyzed by numerical simulations, then experimentally validated. Full article

This paper proposes a current harmonic suppression strategy that combines harmonic synchronous rotating frame (HSRF) current feedback control and back-electromotive force harmonic (BEMFH) feedforward compensation to suppress the fifth and seventh current harmonics of a six-phase permanent magnet synchronous motor (PMSM). The current harmonics of six-phase PMSMs vary with the current due to manufacturing imperfections and the inverter nonlinearity effect. Using fixed-parameter BEMFH feedforward compensation cannot completely eliminate current harmonics. This paper integrates a closed-loop harmonic current control strategy, using HSRF in the differential mode of the six-phase PMSM rotor rotating frame to effectively mitigate current harmonic variations caused by load changes. The controller adapts a Texas Instrument microcontroller featuring encoder interfaces, complementary pulse width modulation (PWM), and analog–digital converters (ADC) to simplify the board design. The rotor angle feedback is provided by a 12-pole resolver in conjunction with an Analog Device resolver-to-digital converter (RDC). The specifications of the six-phase PMSM are as follows: 12 poles, 1200 rpm, 200 A (rms), and 600 V DC bus. The total harmonic distortion (THD) of the phase current for harmonics below the 21st order was reduced from 31.71% to 4.84% under the test conditions of 1200 rpm rotor speed and 200 A peak phase current. Specifically, the fifth and seventh harmonics were reduced from 29.98% and 9.72% to 2.74% and 1.21%, respectively. These results validate the feasibility of the proposed current harmonic suppression strategy. Full article

This paper investigates a back-electromotive force (EMF) harmonic compensation strategy for six-phase permanent-magnet synchronous motors (PMSMs) to reduce current harmonics and improve system performance. Ideally, the back-EMF waveform should be perfectly sinusoidal. However, manufacturing imperfections such as suboptimal magnetic circuit design, uneven winding distribution, and mechanical eccentricity introduce low-order spatial harmonics, particularly the 5th, 7th, 11th, and 13th orders, which distort the back-EMF, increase current harmonics, complicate control, and reduce efficiency. To address these issues, this study proposes a compensation strategy utilizing common-mode and differential-mode current control. By injecting the 6th and 12th harmonics into the decoupled voltage commands along the d-axis and q-axis, the strategy significantly reduces current harmonic distortion. Experimental validation was conducted using a TMS320F28386D microcontroller, which controlled dual inverters via PWM signals and processed real-time current feedback. Rotor position feedback was provided by a resolver to ensure precise and responsive motor control. At a rotational speed of 900 rpm, with a peak phase current $I_m$ of 200 A and an IGBT switching frequency of 10 kHz, the phase-a current total harmonic distortion (THD) was reduced from 11.86% (without compensation) to 6.83% (with compensation). This study focused on mitigating harmonics below the 14th order. The experimental results demonstrate that the proposed back-EMF harmonic compensation strategy effectively minimizes current THD, highlighting its potential for improving the performance and efficiency of multi-phase motor systems. Full article

The application of finite control set model predictive control (FCS-MPC) in six-phase permanent magnet synchronous motors (PMSMs) often faces a trade-off between computational burden and accurate voltage vector selection, as well as challenges related to harmonic components and torque generation. This paper introduces an improved model predictive current control (MPCC) method to address these problems. Firstly, 12 virtual voltage vectors are synthesized to improve torque output performance while suppressing harmonic currents. Then, to generate symmetrical switching signals and reduce switching loss, the largest basic vector used to synthesize the virtual vector is replaced by two medium vectors. Secondly, to solve the problem of the increased computational burden caused by the increase in discrete virtual vectors, a two-step vector selection method is proposed. In this method, each part is divided into several parts according to N, and the traditional cost function is also replaced by two-step functions. Different control performances can be achieved according to different values of N. Experimental results show that the proposed control scheme not only achieves stable current quality but also significantly improves steady-state performance throughout the entire speed range. Full article

In electric machine design, efficient methods for the optimization of the geometry and associated parameters are essential. Nowadays, it is necessary to address the uncertainty caused by manufacturing or material tolerances. This work presents a robust optimization strategy to address uncertainty in the design of a three-phase, six-pole permanent magnet synchronous motor (PMSM). The geometry is constructed in a two-dimensional framework within MATLAB^®, employing isogeometric analysis (IGA) to enable flexible shape optimization. The main contributions of this research are twofold. First, we integrate shape optimization with parameter optimization to enhance the performance of PMSM designs. Second, we use robust optimization, which creates a min–max problem, to ensure that the motor maintains its performance when facing uncertainties. To solve this bilevel problem, we work with the maximal value functions of the lower-level maximization problems and apply a version of Danskin’s theorem for the computation of generalized derivatives. Additionally, the adjoint method is employed to efficiently solve the lower-level problems with gradient-based optimization. The paper concludes by presenting numerical results showcasing the efficacy of the proposed robust optimization framework. The results indicate that the optimized PMSM designs not only perform competitively compared to their non-robust counterparts but also show resilience to operational and manufacturing uncertainties, making them attractive for industrial applications. Full article

The paper deals with the development of a model-based current-signature algorithm for the detection and isolation of power switch faults in three-phase Permanent Magnet Synchronous Motors (PMSMs). The algorithm, by elaborating the motor currents feedbacks, reconstructs the current phasor trajectories in the Clarke plane through elliptical fittings, up to detecting and isolating the fault depending on the characteristics of the signature deviation from the nominal one. As a rough approximation, as typically proposed in the literature, the fault of one out of six power switches implies that, at constant speed operation, the phasor trajectory deviates from the nominal circular path up to a semi-circular “D-shape” signature, the inclination of which depends on the failed converter leg. However, this evolution can significantly deviate in practical cases, due to the dynamics related to the transition of motor phase connections from failed to active switches. The study demonstrates that an online ellipse fitting of the current signature can be effective for diagnosis, through correlating the ellipse centre to the location of the failed switch. The performances of the proposed monitoring technique are here assessed via the nonlinear simulation of a PMSM employed for the propulsion of a lightweight fixed-wing Unmanned Aerial Vehicle (UAV), by quantifying the fault latencies and the related transients. Full article

There has been growing interest in using permanent magnet synchronous motors (PMSMs) for pumping applications to improve energy efficiency. One promising approach for powering these motors in variable speed applications is using an M3C due to its inherent fault tolerance capability. However, M3C converters require a more complex control system than simpler converters. For instance, a basic M3C control system for power transmission requires seventeen PI controllers, whose fixed adjustment depends on the M3C’s dynamical model parameters’ value knowledge, needing initial extensive and time-consuming testing to obtain it. As an alternative, we propose an adaptive M3C control system for variable speed drives powering multiple PMSM-driven centrifugal pumps that reduces the number of controllers to six. Furthermore, the proposal does not require initial knowledge of the converter, motor, or load parameters, making it more practical and versatile. The proposal introduces an ad hoc hybrid passivity-based model reference adaptive controller in cascade with a passivity-based control. It was validated through theoretical stability proof and comparative simulation results with a basic control system under normal and fault operations. As a result, the proposal effectively follows the required rotor speed while enhancing performance by decreasing the current consumption and recovering from a $10\%$ input phase imbalance, a cell short circuit, an open cell, and parameters changes of the motor–pump set. Full article

Irreversible demagnetization of permanent magnets (PMs) in PM synchronous motors (PMSMs) degrades the performance and efficiency of a machine and its drive system. There are numerous fault diagnosis methods for detecting demagnetization under steady-state conditions. However, only a few works could be found on fault diagnosis under dynamic conditions, whereas the dynamic operation of a motor is a very common scenario, e.g., electric vehicles. The voltage and current signal-based traditional fault detection method is not only affected by the structure of the motor, but it also becomes complicated to extract signals involving fault characteristics. Hence, this paper proposes a search coil-based online method for detecting demagnetization faults in PMSMs under dynamic conditions, which are not affected by the motor structure. To gather the flux of the stator tooth, flexible Printed circuit board (FPCB) search coils are positioned at the stator slot. The search coil is made up of two branches that are one pole apart and arranged in reverse sequence. In this installation option, the output signal in the fault state cannot be eliminated, and the output signal in the health state is zero. This paper defines only that characteristic value related to the position angle of the rotor. Further, the aim was to simultaneously eliminate the influence of elements like the search coil installation error and the inherent dispersion of the permanent magnet on the detection results. To characterize the fault degree, the measurement differential between the health state and the fault state is further integrated according to a predetermined angle range. Last but not least, speed-independent detection of individual permanent magnet demagnetization faults is possible using rotor position and stator tooth flux. A six-phase PMSM was used in experiments to show the efficiency of the suggested approach. The findings of the experiment demonstrate that the suggested strategy may precisely ascertain when a defect will occur. Full article

Interturn short circuit (ITSC) fault is a common fault in electric machines, which may severely damage the machines if no protective measure is taken in time. There are numerous fault diagnosis methods under a steady-state condition. However, there is relatively limited research on fault diagnosis under dynamic conditions. The dynamic operation of motors, such as in electric cars, is a very common scenario. Hence, this paper proposes a search-coil based online method for detecting ITSC fault in permanent magnet synchronous machine (PMSM) under a dynamic condition. The search coils are placed on the stator circumference at equal intervals. Each search coil reflects the information about the magnetic field in its vicinity and also contains the fault information. In this paper, the voltage induced by the odd sideband harmonics around the even carrier (2ωc±ω0) is selected as the fault characteristic to be used in effectively improving the detected signal-to-noise ratio by excluding the interference of the counter-potential of the permanent magnet. Since two adjacent search coils are placed one pole apart, a set of quadrature signals can be acquired. The Digital Lock-In Amplifier (DLIA) technology is applied to extract the amplitude of the characteristic voltage, which overcomes the shortcomings of the traditional spectrum analysis in applying to non-stationary conditions. The amplitudes of the voltage at different search coils can be compared to further determine the occurrence of a fault and also its rough location if occurred. Experiments were conducted with a six-phase PMSM for demonstrating the effectiveness of the proposed method. The obtained results show that the proposed method can accurately determine the occurrence of a fault. Full article

One innovative composite fault-tolerant control tactic is presented for the reliable operation of a power transmission system, which consists of both an asymmetric six-phase permanent magnet synchronous motor (PMSM) and a T-type mid-point clamp type (T-NPC) three-level inverter. First, in order to inherit the better harmonic property of simplified space vector modulation (SVM) and the rapid dynamic capability of direct torque control (DTC), the SVM-DTC control scheme was determined, and the harmonic electric current suppression unit was added to the basic control scheme to obtain good harmonic electric current suppression. In addition, a strategy for open-circuit fault-tolerant control under the SVM-DTC scheme was designed by analyzing the mutual influence between the stator flux linkage and the stator voltage of each phase under an open-circuit fault. Finally, the PMSM drive system principle prototype was tested. By comparing the waveforms of output torque and current of each phase before and after fault tolerance, it shows that the large torque fluctuation (±5%) before fault tolerance was suppressed to ±2% and smoothed out, verifying the effectiveness of fault tolerance control. Full article

This paper proposes a method to improve the output torque of a six-phase permanent-magnet synchronous machine (PMSM) within the same current peak limit through a fifth-harmonic injection into each phase current of the stator. Compared to the fifth + seventh-harmonic current-injection method used to improve the output torque of the six-phase PMSM, the control system can be stably controlled, and the controller design complexity decreased. This is because the harmonic component was converted into a direct current (DC) component and controlled by a proportional-integral (PI) controller instead of the fifth + seventh-harmonic injection method, which converts the harmonic component into an alternating current (AC) component and controls it with a resonance controller. The appropriate fifth-harmonic ratio for maximum output torque through fifth-harmonic injection was selected through optimization using values analyzed via fast Fourier transform (FFT) for stator phase harmonic current terms caused by inverter nonlinearity and motor design errors. Therefore, it was possible to optimize the fifth-harmonic ratio to be injected without requiring torque modeling using the physical properties of the motor. The experimental results were obtained under the rated current condition with six-phase PMSM in the laboratory, and the average output torque increase under fifth-harmonic injection was about 5% compared to the method without harmonic injection. Full article

Compared with the three-phase motor, the six-phase motor has lower torque ripple and higher fault tolerance performance, which makes it widely used in aviation, ships, industrial manufacturing, and other application fields. However, the probability of failure of the polyphase motor system increases with the increase in the number of phases. In order to deal with the open phase fault and power switch fault of the six-phase inverter, a fault diagnosis method for the six-phase inverter based on vector space decoupling (VSD) is proposed. The open phase fault index is first determined according to the VSD decoupling inverse transform and the current constraints. The fault index is then optimized from the perspective of preventing misdiagnosis and improving reliability, and the open phase fault can be diagnosed in one fundamental cycle. In addition, the current trajectory of harmonic plane after switch fault is analyzed, and the back propagation (BP) neural network is used to identify the harmonic plane current trajectory of different types of switch fault. Finally, the correctness and feasibility of the proposed fault diagnosis method are verified by simulations and experiments. The obtained results demonstrate that the proposed method can quickly and accurately locate the open phase fault and switch fault without additional hardware. The proposed method is simple, efficient, and robust. Full article

The six-phase motor control system has low torque ripple, low harmonic content, and high reliability; therefore, it is suitable for electric vehicles, aerospace, and other applications requiring high power output and reliability. This study presents a superior sensorless control system for a six-phase permanent magnet synchronous motor (PMSM). The mathematical model of a PMSM in a stationary coordinate system is presented. The information of motor speed and position is obtained by using a sliding mode observer (SMO). As torque ripple and harmonic components affect the back electromotive force (BEMF) estimated value through the traditional SMO, the function of the frequency-variable tracker of the stator current (FVTSC) is used instead of the traditional switching function. By improving the SMO method, the BEMF is estimated independently, and its precision is maintained under startup or variable-speed states. In order to improve the estimation accuracy and resistance ability of the observer, the rotor position error was taken as the disturbance term, and the third-order extended state observer (ESO) was constructed to estimate the rotational speed and rotor position through the motor mechanical motion equation. Finally, the effectiveness of the method is verified by simulation and experiment results. The proposed control strategy can effectively improve the dynamic and static performance of PMSM. Full article

Multi-phase motors and generators are regarded with great fault tolerance capability, especially on open-circuit faults. Various mathematics analytical methods are applied for their fault control. In this paper, a fault-tolerant control strategy with asymmetric phase current for the open-circuit faults with arbitrary phases in the six-phase PMSM (six-phase permanent magnetic synchronous motor, 6P-PMSM) system, is proposed for better electrical and dynamical performance of the machine. An innovative mathematical model for PMSM under one to four-phase-open circuit faults are established considering the asymmetry of the machine. Combining with time-varying relations in machines’ working conditions, targeted decoupling transformation matrixes of every kind of open-circuit faults are settled by voltage equations under different faults. Modified control strategy with a connection between the neutral point and the inverter’s DC side is presented, which aims at increasing the system redundancy and reducing the amplitude of phase currents. Besides, improved control loops with two layers are put forward as well, with which the PMSM system acquires fewer harmonics in phase current and smoother electromagnetic torque. Simulation and experimental results of open-circuit faults are provided for verification of the theoretical analysis. Full article

Nowadays, in aeronautical applications, rigorous reliability requirements are high constraints for embedded systems. Therefore, material redundancy is adopted to ensure safety whatever operation conditions may be. In the design of a direct-drive actuator for a specific application, redundancy is taken into account using a compound of four three-phase permanent magnet synchronous machines (PMSM). Each two electric machines are mounted in series sharing the same rotor with a common through shaft. The stators of each two electric machines are designed and manufactured as a six-phase machine. For each machine, power supply, sensors, and control loops are independent. In the characterization of the designed actuator and in the validation of its specific control in healthy operation mode and in faulty operation mode, taking into account the force fight phenomenon between the motor lanes, a specific test bench is developed. The aim of this paper is to highlight this phenomenon in faulty operation mode and to develop an easily implementable monitoring architecture, in order to eliminate it. Finally, with the proposed approach of monitoring, the force fight phenomenon is eliminated in faulty operation mode keeping the same performance as in healthy operation mode. Full article
