This research presents a lens-based light collection system that integrates a handmade glass conical waveguide (GCW) with a single silica multimodal optical fiber (SMMF) and a concentrator Fresnel lens (FL). The GCW functions as a secondary optical element (SOE), effectively expanding the fiber’s receptive area and enabling efficient coupling of concentrated light. Calibrated ray-tracing simulations confirm that the complete FL + GCW + SMMF configuration maintains low transmission losses, thereby validating efficient coupling into the SMMF. Experimental results demonstrated a maximum net optical efficiency of 41% at an FL numerical aperture (NA) of 0.08, with GCW transmission reaching 60% and splice losses to the SMMF around 34%. With a luminous flux input of 155 lumens, the system delivered up to 63 lumens at the fiber output. Importantly, the FL + GCW + SMMF configuration combines reproducible fabrication, straightforward assembly, and reliable characterization, establishing a scalable pathway for daylight harvesting. The major contribution of this work is the demonstration that a simple, manufacturable GCW can substantially expand the effective collection area of multimodal fibers while preserving low optical losses, thereby bridging practical design with efficient energy transfer for sustainable photonics applications. Full article

A multimode magneto-optical fiber based on Tb³⁺-containing borogermanate glass was designed, fabricated, and characterized, aiming at potential sensing applications. There are continuing challenges in the development of single-mode (SMF) or multimode (MMF) optical fibers doped with rare-earth (RE) ions and exhibiting high Verdet constants, related to devitrification of the precursor glass. Most RE-doped glass compositions are not suitable as precursors for core-cladding fiber production due to devitrification processes and consequent poor optical quality. Application as Faraday rotators is limited by the intrinsically low Verdet constant of silica (~0.589 rad T⁻¹ m⁻¹ at 1550 nm and 0.876 rad T⁻¹ m⁻¹ at 1310 nm). Borogermanate glasses are good candidates for manufacturing optical fibers due to their excellent potential to solubilize high concentrations of Tb³⁺ ions as well as satisfactory thermal stability. In this work, a magneto-optical core-cladding borogermanate fiber with a 227 μm diameter was fabricated, with characterization using differential scanning calorimetry (DSC), thermomechanical analysis (TMA), viscosity measurements, M-lines spectroscopy, UV-Vis-NIR absorption spectroscopy, the cut-back technique, and magneto-optical measurements. The measured numerical aperture (NA) was 0.183, with minimum attenuation of 13 dB m⁻¹ at 1270 nm. The Verdet constant (V_B) reached −6.74 rad T⁻¹ m⁻¹ at 1330 nm. Full article

A sensitivity-enhanced temperature sensor based on a Mach–Zehnder interferometer (MZI) coated by polydimethylsiloxane (PDMS) film is proposed and investigated. The MZI with a compact size of 2.28 mm is fabricated by embedding a tapered single-mode fiber (SMF) between two multimode fibers (MMFs). Since PDMS has a higher thermo-optical coefficient than silica, the proposed sensor has better temperature sensing performance than the case without PDMS coating, which is demonstrated by simulation and experiment. The experimental results show that the sensitivity of the proposed sensor is as high as −1.06 nm/°C in the range from −5 °C to 45 °C. Full article

Waveguided beam splitters were microfabricated by using a commercial two-photon lithography system (Nanoscribe), Ip-Dip as the waveguides and fused silica as the substrate, and they were covered with Loctite. The gap between the waveguides in the coupler was used to determine the transmission and reflection coefficients, and our results were compared with simulation results (using OptiFDTD software). The input and output ports of the beam splitters were spliced with multimode optical fibers in a robust system that can easily be handled. Then, they were tested by leading single photons (from an SPDC) to the beam splitters to produce different quantum statistics that were rated using the Fano factor. Full article

Gaseous pollutants such as hydrogen gas (H₂) are emitted in daily human activities. They have been massively studied owing to their high explosivity and widespread usage in many domains. The current research is designed to analyse optical fiber-based H₂ gas sensors by incorporating palladium/graphene oxide (Pd/GO) nanocomposite coating as sensing layers. The fabricated multimode silica fiber (MMF) sensors were used as a transducing platform. The tapering process is essential to improve the sensitivity to the environment through the interaction of the evanescent field over the area of the tapered surface area. Several characterization methods including FESEM, EDX, AFM, and XRD were adopted to examine the structure properties of the materials and achieve more understandable facts about their functional performance of the optical sensor. Characterisation results demonstrated structures with a higher surface for analyte gas reaction to the optical sensor performance. Results indicated an observed increment in the Pd/GO nanocomposite-based sensor responses subjected to the H₂ concentrations increased from 0.125% to 2.00%. The achieved sensitivities were 33.22/vol% with a response time of 48 s and recovery time of 7 min. The developed optical fiber sensors achieved excellent selectivity and stability toward H₂ gas upon exposure to other gases such as ammonia and methane. Full article

The investigation of optical microcavity solitons is in demand both for applications and basic science. Despite the tremendous progress in the study of microresonator solitons, there is still no complete understanding of all features of their nonlinear dynamics in various regimes. Controlling soliton properties is also of great interest. We proposed and investigated experimentally and theoretically a simple and easily reproducible way to generate Raman solitons with controllable spectral width in an anomalous dispersion region in a functionalized silica microsphere with whispering gallery modes (WGMs) driven in a normal dispersion regime. To functionalize the microsphere, coating (TiO₂ + graphite powder) was applied at the pole. The coating is used for effective thermalization of the radiation of an auxiliary laser diode launched through the fiber stem holding the microsphere to control detuning of the pump frequency from exact resonance due to the thermo-optical shift of the WGM frequencies. We demonstrated that the thermo-optical control by changing the power of an auxiliary diode makes it possible to switch on/off the generation of Raman solitons and control their spectral width, as well as to switch Raman generation to multimode or single-mode. We also performed a detailed theoretical analysis based on the Raman-modified Lugiato–Lefever equation and explained peculiarities of intracavity nonlinear dynamics of Raman solitons. All experimental and numerically simulated results are in excellent agreement. Full article

This work demonstrated a ZnO-coated optical fiber sensor for the detection of a volatile organic compound (VOC) biomarker for diabetes for detecting isopropanol (IPA) markers. A coreless silica fiber (CSF) was connected to a single-mode fiber (SMF) at both ends to achieve a SMF–CSF–SMF structure. CSF is the sensing region where multimode interference (MMI) generates higher light interaction at the interface between the fiber and sensing medium, leading to enhanced sensitivity. Optimization of the CSF length was conducted numerically to attain the highest possible coupling efficiency at the output. Surface functionalization was achieved via hydrothermal growth of ZnO nanorods directly onto the CSF at low temperatures. The optical fiber-based sensor was successfully fabricated and tested with 20%, 40%, 60%, 80%, and 100% of IPA. The sensor response was recorded using an optical spectrometer and analyzed for sensor sensitivity. The fabricated sensor shows the potential to detect isopropanol with the sensitivity of 0.053 nm/%IPA vapor. Further improvement of the sensor sensitivity and selectivity is also proposed for future work. Full article

Optical fibers were previously demonstrated to propagate and detect acoustic modes that were converted from Lamb waves for structural health-monitoring applications; typically, a fiber Bragg grating sensor in the optical fiber is used to detect acoustic modes. Acoustic modes can transfer from one fiber to another through a simple adhesive bond coupler, preserving the waveform of the acoustic mode. This paper experimentally investigates the coherence of acoustic waves through the adhesive coupler, using a fiber ring resonator (FRR) configuration. This configuration was chosen because the wave coupled to the second fiber interferes with the original wave after it encircles the fiber ring. We performed this experiment using different geometries of optical fibers in the ring, including a standard single-mode optical fiber, a hollow silica capillary tube, and a large-diameter multi-mode fiber. The results demonstrate that the acoustic wave, when transferring through an adhesive coupler, interferes coherently even when the main and ring fibers are of different types. Finally, we demonstrate that the FRR can be applied for sensing applications by measuring the mode attenuations in the ring due to a changing external environment (water-level sensing) and measuring the optical-path length change in the ring (temperature sensing). Full article

A fiber-optic refractometer for various liquids with refractive indices in the range from 1.33 to 1.43 has been manufactured and tested. The sensor is based on a thin silicon oxynitride (Si₃N_4-xO_x) film coated thinned optic fiber section (taper) obtained in a multimode all-silica optical fiber by chemical etching of the reflective cladding. The film was deposited on the cylindrical surface of the thinned fiber by the surface plasma chemical vapor deposition method (SPCVD). Lossy mode resonance (LMR) was observed in the transmission spectrum of the coated taper at a wavelength dependent on the refractive index of the liquid in which the taper was immersed. We tested the obtained sensors in distilled water, isopropyl alcohol, dimethylformamide, and their aqueous solutions. It was found that with the help of the SPCVD, one can obtain a set of sensors in a single deposition run with the dispersion of sensitivity and spectral position of LMR no more than 5%. Maximum sensitivity of the manufactured sensors to surrounding media refractive index (SMRI) variation exceeds 1090 nm/RIU, which is the highest value recorded to date for a sensor with a non-oxide coating. Full article

Mode coupling and power diffusion in multimode step-index (SI) organic glass-clad (OGC) PMMA fiber is examined in this study using the power flow equation (PFE). Using our previously proposed approach we determine the coupling coefficient D for this fiber. When compared to standard multimode SI PMMA fibers, the multimode SI OGC PMMA fiber has similar mode coupling strength. As a result, the fiber length required to achieve the steady-state distribution (SSD) in SI OGC PMMA fibers is similar to that required in standard SI PMMA fibers. We have confirmed that optical fibers with a plastic core show more intense mode coupling than those with a glass core, regardless of the cladding material. These findings could be valuable in communication and sensory systems that use multimode SI OGC PMMA fiber. In this work, we have demonstrated a successful employment of our previously proposed method for determination of the coupling coefficient D in multimode SI OGC PMMA fiber. This method has already been successfully employed in the previous research of mode coupling in multimode SI glass optical fibers, SI PMMA fibers and SI plastic-clad silica optical fibers. Full article

We exploited the potential of radiation-induced emissions (RIEs) in the visible domain of a nitrogen-doped, silica-based, multimode optical fiber to monitor the very high dose rates associated with experiments at different pulsed X-ray facilities. We also tested this sensor at lower dose rates associated with steady-state X-ray irradiation machines (up to 100 keV photon energy, mean energy of 40 keV). For transient exposures, dedicated experimental campaigns were performed at ELSA (Electron et Laser, Source X et Applications) and ASTERIX facilities from CEA (Commissariat à l’Energie Atomique—France) to characterize the RIE of this fiber when exposed to X-ray pulses with durations of a few µs or ns. These facilities provide very large dose rates: in the order of MGy(SiO₂)/s for the ELSA facility (up to 19 MeV photon energy) and GGy(SiO₂)/s for the ASTERIX facility (up to 1 MeV). In both cases, the RIE intensities, mostly explained by the fiber radioluminescence (RIL) around 550 nm, with a contribution from Cerenkov at higher fluxes, linearly depend on the dose rates normalized to the pulse duration delivered by the facilities. By comparing these high dose rate results and those acquired under low-dose rate steady-state X-rays (only RIL was present), we showed that the RIE of this multimode optical fiber linearly depends on the dose rate over an ultra-wide dose rate range from 10⁻² Gy(SiO₂)/s to a few 10⁹ Gy(SiO₂)/s and photons with energy in the range from 40 keV to 19 MeV. These results demonstrate the high potential of this class of radiation monitors for beam monitoring at very high dose rates in a very large variety of facilities as future FLASH therapy facilities. Full article

We studied the effect of mode coupling on the space division multiplexing (SDM) capabilities of multimode step-index (SI) air-clad silica optical fibers by numerically solving the power flow equation. Mode coupling considerably reduces the length of these fibers at which space division multiplexing may be achieved with minimal crosstalk between neighboring optical channels, according to the findings. Up to 120 m and 30 m, respectively, the two and three spatially multiplexed channels in the investigated multimode step-index silica optical fibers can be used with low crosstalk. When building a space division multiplexing-based optical fiber transmission system, such characterization of optical fibers should be taken into account. Full article

We investigated in this work the radioluminescence properties of a Ce-doped multimode silica-based optical fiber (core diameter of 50 µm) manufactured by the sol–gel technique when exposed to the high-energy X-rays (~600 keV) of the ORIATRON facility of CEA. We demonstrated its potential to monitor in real-time the beam characteristics of this facility that can either operate in a pulsed regime (pulse duration of 4.8 µs, maximum repetition rate of 250 Hz) or in a quasi-continuous mode. The radiation-induced emission (radioluminescence and a minor Cerenkov contribution) linearly grew with the dose rate in the 15–130 mGy(SiO₂)/s range, and the afterglow measured after each pulse was sufficiently limited to allow a clear measurement of pulse trains. A sensor with ~11 cm of sensitive Ce-doped fiber spliced to rad-hard fluorine-doped optical fiber, for the emitted light transport to the photomultiplier tube, exhibited interesting beam monitoring performance, even if the Cerenkov emission in the transport fiber was also considered (~5% of the signal). The beam monitoring potential of this class of optical fiber was demonstrated for such facilities and the possibilities of extending the dose rate range are discussed based on possible architecture choices such as fiber type, length or size. Full article

Signal transmission over optical fibers in the ultraviolet to near-infrared domains remains very challenging due to their high intrinsic losses. In radiation-rich environments, this is made even more difficult due to the radiation-induced attenuation (RIA) phenomenon. We investigated here how the number of hydroxyl groups (OH) present in multi-mode (MM) pure-silica core (PSC) optical fibers influences the RIA levels and kinetics. For this, we tested three different fiber samples: one “wet”, one “dry” and one with an intermediate “medium” OH content. The RIA of the three samples was measured in the 400–900 nm (~3 eV to ~1.4 eV) spectral range during and after an X-ray irradiation at a dose rate of 6 Gy(SiO₂) s⁻¹ up to a total accumulated dose of 300 kGy(SiO₂). Furthermore, we evaluated the H₂-pre-loading efficiency in the medium OH sample to permanently improve both its intrinsic losses and radiation response in the visible domain. Finally, the spectral decomposition of the various RIA responses allows us to better understand the basic mechanisms related to the point defects causing the excess of optical losses. Particularly, it reveals the relationship between the initial OH groups content and the generation of non-bridging oxygen hole centers (NBOHCs). Moreover, the presence of hydroxyl groups also affects the contribution from other intrinsic defects such as the self-trapped holes (STHs) to the RIA in this spectral domain. Full article

Experimental development of a compact optical emission detector based on the assembly of a polymer-metal and a standard silica fiber is presented in this paper. This device is exploited in a proof-of-principle experiment for gas detection application by means of plasma spectroscopy in the visible-Near Infrared spectral region. A multimode fiber (MMF) is associated with a functional hollow dual-electrodes elongated structure fabricated by the direct preform-to-fiber homothetic co-drawing. A potential of 1.5 kV is applied between the two electrodes embedded inside the composite cladding, which generates an atmospheric pressure dc glow discharge at the tip of the fiber bundle. The emitted light is then collected by the MMF for optical diagnostics. Probing of different atmospheres is presented at the end of this study. Full article
