Search Results (84)

Traditional exterior walls are heavy, offer insufficient insulation, and have poor durability, making it challenging to meet the combined requirements of energy efficiency and structural enclosure performance. To address the issues of excessive weight and inadequate insulation in conventional concrete exterior wall panels, alternative materials and designs are being adopted. A novel double-layer composite wall panel structure is proposed, arranging normal concrete (NC) on the exterior side to ensure the panel’s durability and ceramsite foam concrete (CFC) on the interior side to enhance thermal insulation and reduce thermal bridging effects. To address the scenario where the wall panel is subjected to out-of-plane loads during service, causing stress in the CFC layer, bending performance tests were conducted on CFC-NC double-layer composite panels under load applied on the CFC side. Research shows that CFC-NC double-layer composite wall panels exhibit bending performance under four-point bending conditions that is basically consistent with that of monolithic wall panels. As the thickness of the CFC layer increases, cracks may appear near the interface in the CFC layer that do not extend from NC cracking, and may even occur earlier than NC cracking. As the density grade of CFC decreases, the compressive deformation of CFC becomes more pronounced; however, no crushing of the CFC occurs at the ultimate bearing capacity stage. Under four-point bending conditions, the strain at the mid-span section of the composite wall panel along the thickness direction is basically linearly distributed. Under the same conditions of wall panel thickness, reinforcement ratio, and shear span ratio, the flexural bearing capacity of CFC-NC double-layer composite wall panels with CFC density grades A8, A6, and A4 is approximately 12.5%, 25.03%, and 18.29% lower, respectively, compared to C30 cast-in-place wall panels. The flexural bearing capacity of the composite panels increases correspondingly with the increase in CFC layer thickness and reinforcement ratio. Specimens with smaller shear span ratios exhibit more pronounced shear effects. Based on the stress–strain relationship of CFC, a modified calculation method for the flexural capacity of ordinary concrete sections is presented. Referring to the ACI 318-14 code, a calculation method for the bending deformation of composite wall panels is provided. The research results can offer a theoretical basis for the design and application of CFC-NC double-layer composite wall panels. Full article

Currently, unreinforced steel fiber-reinforced concrete (USFRC) has not been widely adopted in underground engineering within China. However, extensive research has demonstrated that incorporating steel fibers can effectively enhance the mechanical properties of concrete, such as tensile strength, shear strength, residual flexural tensile strength, and also improve its durability. This study, based on the Qiandong experimental section of Dalian Metro Line 4, aims to investigate the failure modes, bearing capacity, and calculation methods for reinforced concrete (RC) and USFRC lining segment joints under compression-bending loading. The objective is to provide a reference for the application of USFRC lining segments in domestic underground engineering. The main conclusions are as follows: (1) The primary failure mode of RC segment joints is large-area crushing of concrete on the outer curved surface, with tensile crack widths on the inner curved surface less than 0.20 mm. The failure mode of USFRC segment joints is characterized by a 2.50 mm wide tensile crack below the loading point. (2) The bolt strain at failure for RC segment joints is approximately twice that of USFRC joints, with both reaching the yield strength and entering the plastic deformation stage. The bolt stress versus bending moment curve exhibits two distinct growth stages. USFRC can effectively control bolt deformation and stress, thereby enhancing bearing capacity. (3) The joint rotation angle versus bending moment curve follows a bilinear model. Under identical bending moments, the rotation angle of RC segment joints is significantly larger than that of USFRC joints. In the two stages, the rotational stiffness of USFRC joints is 367.13% and 763.82% of that of RC joints, respectively. (4) Bolts do not influence the bearing capacity of the segment joints. Existing calculation models in current design codes can accurately predict the ultimate bearing capacity of both RC and USFRC segment joints, demonstrating high prediction accuracy. Full article

Steel fiber reinforced concrete (SFRC) has become a feasible alternative material for traditional reinforced concrete (RC) segments in shield tunnel engineering due to its excellent crack resistance, toughness, and durability. However, its design parameters have not yet been standardized, and research at the material and structural scales remains relatively fragmented, lacking a unified design framework, which limits the widespread application of SFRC segments. This paper provides a comprehensive review of the mechanical performance and design methods of SFRC segments, focusing on four aspects: (1) research methods for mechanical performance, including experimental analysis, numerical simulation, and artificial intelligence algorithms; (2) theoretical calculation methods for flexural and shear bearing capacity and crack width; (3) mechanical response characteristics, including deformation modes and crack propagation patterns; (4) key influencing factors, such as matrix strength, steel fiber types, dosages, and aspect ratios. The study systematically reviews relevant research methods on the mechanical performance of SFRC segments, evaluates the applicability and limitations of existing theoretical calculation methods, and ranks the factors affecting the mechanical performance of SFRC segments from the perspective of material composition. Finally, based on the review, future research directions for SFRC segments are proposed, providing a systematic reference for the development of design standards, improvement of mechanical performance, and full-lifecycle reliability assurance of SFRC segments. Full article

The need to strengthen existing load-bearing elements (slabs, girders, columns, etc.) is often encountered in practice mainly because existing reinforced concrete structures were previously designed according to provisions and standards that were valid decades ago and no longer comply with currently valid Eurocodes, which provide new load levels and cross-section resistance calculations and, thus, a new level of reliability. Another reason is that the purpose behind the use of existing structures is changing, with these structures often now needing to withstand greater loads than were considered during the design. Many methods of strengthening elements stressed by axial force (pressure, tension), bending, shear, and their combination exist, with a common one being the addition of a new, more load-bearing layer of concrete, fibreconcrete, or ultra-high-performance concrete (UHPC). This experimental study focuses on the point of contact between two concrete surfaces and their modification to increase the bearing capacity of the bonded concrete-to-concrete cross-section. To strengthen the cross-section of the reinforced concrete (RC), a decisive condition is contact between individual layers, which is dependent on the resistance of the new, strengthened member. Connection occurs at the cross-section when the elements placed on top of each other are prevented by any suitable method from moving at the level of their contact surface. In this study, experimental tests were carried out to determine shear resistance using beams with dimensions of 100 × 100 × 300 mm, which consisted of two parts connected diagonally at an angle of 30°. To compare the increase in bearing capacity, the modifications of the contact surfaces and the characteristics of the material used for individual added layers were taken into account. The contact surfaces were either untreated, such as stamping from formwork, or smooth surfaces soaked in water for 48 h. For the modified surfaces, modifications included notches, indents, the use of an adhesive layer, and modifications of surface roughness using a steel brush. All base layers were concreted with the same class of concrete and processed according to the mentioned modifications. Different recipes were used for the upper (over-concreted) layer (part). The most effective processing methods were determined from the obtained results, and the coefficient of cohesion was determined through reverse calculation for individual surface treatments and subsequently compared with the Eurocode values. Full article

The main goal of this work is to analyse the thermo-mechanical effect in single shear dowelled timber connections under fire conditions. This research includes the development of numerical models using the finite element method. The numerical methodology was validated using previously published experimental and numerical data. New models were developed to evaluate the temperature evolution, charring rate, and load-bearing capacity of the connections throughout exposure to fire. The calculations based on Eurocode 5 are conservative in the dimensioning of connections at room temperature but have less impact on the design of fire resistance, as they do not consider factors such as geometric parameters or passive protection influence on structural performance. Finally, based on the results obtained, two useful design equations are proposed, allowing the calculation of the load-bearing capacity of single shear timber connections, with or without protection, as a function of fire exposure. Full article

Corrugated steel–concrete (CSC) composite arches, an innovative structural system with simplified construction and enhanced stiffness, are widely used in bridge and tunnel modular engineering. However, insufficient research on their shear performance limits prefabricated applications. Similarly to beams, their shear behavior is significantly affected by loading location. Specifically, as a parameter significantly affected by the loading location, the shear–compression ratio exerts a notable influence on the shear bearing capacity of CSC arches by altering the development pattern of cracks and the inclination angle of shear cracks. To investigate the influence mechanism of the loading location, this study is the first to systematically link shear–compression ratio variation to load location in CSC arches. In this context, shear performance tests were conducted on two CSC specimens with different loading locations (mid-span and quarter-point) to investigate the influence of loading locations on the shear behavior of CSC arches. To further investigate the impact of key parameters on the shear bearing capacity of CSC arches, a validated finite element model was employed to support the parametric analysis. The parameters involved include the span-to-rise ratio, shear connector spacing, strength and thickness of corrugated steel, as well as strength and thickness of concrete. Theoretical calculations for internal forces under varying rise-to-span ratios and loading methods are conducted, proposing an analytical solution method. Validation using 2 experiments and 96 finite element results show that a modified method is applicable, with a mean value of 1.066, corresponding to a standard deviation of 0.071, and all relative errors within 15%. By introducing the shear–compression ratio, this study extends existing methods to make them applicable under single-point loading, thereby enabling their use for guiding engineering. Similarly, the internal force analysis method proposed herein can serve as a theoretical foundation, providing a valuable reference for future research on shear capacity calculation methods for CSC arches with varying cross-sectional configurations and those where bending moments play a more significant role. Full article

In subway stations constructed using the cut-and-cover method, an increasing number of projects are adopting the form of precast components combined with on-site assembly. However, analysis of the novel structural elements within such overlapped subway stations remains inadequate. To simulate the shear failure mechanism at slab–wall joints, the structural behavior of these joints in overlapped subway stations is idealized as a rigid die stamping problem. An admissible failure mechanism is constructed, comprising a rigid wedge zone and a vertical tensile fracture perpendicular to a smooth base. The limit analysis approach is adopted, a two-dimensional velocity field is constructed, and the upper-bound theorem is applied to determine the bearing capacity of these joints under strip loading, utilizing a modified Coulomb yield criterion incorporating a small tensile stress cutoff. The failure mechanism proposed on the basis of an engineering case is validated through analytical calculations and parametric studies. Finally, a parametric analysis is conducted to investigate the influence of factors such as the geometric configuration of the slab–wall joints and the tensile and compressive strengths of concrete on their ultimate bearing capacity. The results obtained can provide an effective reference for the design and construction of precast slab–wall joints in future overlapped subway station projects. Full article

This study introduces a novel method for evaluating pile–soil interaction based solely on Dilatometer Test (DMT) results, enhancing and extending the established approach originally developed using Menard Pressuremeter Test (PMT) data. Currently, transfer functions utilizing DMT sounding results are in the early stages of development. Presented research fills the gap in DMT-based methods for pile design by introducing transfer functions for reversal loadings to calculate the unit shaft friction of screw displacement piles in Controlled Modulus Columns (CMC) technology. The proposed method utilizes DMT-derived soil parameters, offering a practical and accurate alternative to PMT-based models. Testing research fields were located in the Vistula Marshlands, Northern Poland. Site characterization consisted of piezocone (CPTU) and DMT soundings to characterize the soil profile and estimate soil parameters relevant for pile design. CMCs were installed and statically load tested under various loading schemes. Laboratory direct shear tests on smooth and rough soil-concrete interfaces were performed in both forward and backward directions (reversal loading) to simulate pile loading conditions. Results demonstrate improved adaptability of DMT-based transfer curves to local soil conditions and provide a reliable framework for predicting pile performance in soft soils. Proposed DMT-model returns similar ultimate bearing capacities of the pile to CPT 2012 method for first loading, simultaneously offering better agreement for reversal loading, a situation not accounted for in CPTU 2012 or most other CPT-based methods. Full article

This study introduces and validates a comparative experiment-based method for determining the effective thickness of composite glass, including polymeric laminated glass (with polyvinyl butyral (PVB) and SentryGlas^® (SGP) interlayers) and vacuum glazing. This method employs comparative four-point bending tests, defining effective thickness by equating the bending stress of a composite specimen to that of a reference monolithic glass specimen under identical loading and boundary conditions. Specimens with varying configurations (glass thicknesses of 5 mm, 6 mm and 8 mm) were tested using non-destructive four-point bending tests under a multi-stage loading protocol (100 N–1000 N). Strain rosettes measured maximum strains at each loading stage to calculate bending stress. Analysis of the bending stress state revealed that vacuum glazing and SGP laminated glass exhibit superior load-bearing capacity compared to PVB laminated glass. The proposed method successfully determined the effective thickness for both laminated glass and vacuum glazing. Furthermore, results demonstrate that employing a 12 mm monolithic reference glass provides the highest accuracy for effective thickness determination. Theoretical bending stress calculations using the effective thickness derived from the 12 mm reference glass showed less than 10% deviation from experimental values. Conversely, compared to established standards and empirical formulas, the proposed method offers superior accuracy, particularly for vacuum glazing. Additionally, the mechanical properties of the viscoelastic interlayers (PVB and SGP) were investigated through static tensile tests and dynamic thermomechanical analysis (DMA). Distinct tensile behaviors and differing time-dependent shear transfer capacities between the two interlayer materials are found out. Key factors influencing the reliability of the method are also discussed and analyzed. This study provides a universally practical and applicable solution for accurate and effective thickness estimation in composite glass design. Full article

The screw piles used in permafrost regions represent a new type of pile, and their vertical bearing characteristics play a crucial role in ensuring the normal operation of engineering buildings. This study establishes a numerical calculation model to simulate the interaction between screw piles and soil in permafrost regions and verifies the numerical simulation results through model tests. The bearing mechanism of screw piles in permafrost areas is studied and compared with common, bored, cast-in-place piles widely used. Finally, a method for estimating the bearing capacity of screw piles in permafrost regions is proposed. The research indicates that approximately 90% of the bearing capacity of screw piles in permafrost regions is derived from the mechanical interaction between the concrete pile’s side and the permafrost soil. The shear strength of the permafrost is the primary determinant of the pile foundation’s bearing capacity, while the seasonally active layer has a minimal impact on its bearing capacity, resulting in a stable year-round performance. In permafrost regions, the equivalent friction resistance of screw piles is significantly greater than that of the conventional cast-in-place piles. When the pile reaches its ultimate bearing capacity, the plastic zone on the pile’s side becomes connected, and shear failure occurs in the surrounding soil. The design value of the bearing capacity of a single pile can be effectively estimated in engineering practice by improving the formula of the code for calculating the vertical bearing capacity. Full article

Current research on the stress mechanisms of composite connectors within steel–concrete structures of bridge towers is sparse, and there is a lack of established experimental methods and finite element modeling techniques for studying these mechanisms. This study focuses on a specific type of composite shear connector within the steel–concrete section of the Shunde Bridge tower. By employing proposed experimental methods and finite element model analysis, this research examines the load–slip curves and stress distribution of these shear connectors. It aims to elucidate the stress mechanisms and mechanical relationships between the composite connectors and the individual perforated plate connectors and shear stud connectors that comprise them. The results demonstrate that the proposed experimental methods and finite element modeling approaches effectively analyze the stress mechanisms of composite connectors, revealing that the ultimate load-bearing capacity and elastic stiffness of the composite connectors are approximately the sum of those of the individual connectors configured in parallel; The mechanical performance of the composite connectors in the steel–concrete section of the bridge tower is approximately the additive sum of the mechanical performances of the individual connectors comprising them. By comparing the experimentally measured load–slip curves with those calculated from the finite element models, it validates the modeling approach of the finite element model, and the material parameters established through material characteristic tests and literature review are reasonable. Full article

In order to improve the efficiency of highway tunnel construction and ensure the construction quality, the design concept of a prefabricated inverted arch and partial cast-in-place lining of highway tunnels by a mining method is put forward. During the assembly of prefabricated tunnel invert arches, the longitudinal joints between adjacent invert sections were subjected to shear forces due to the combined effects of the invert’s self-weight and construction equipment loads. This study investigated the shear performance of these longitudinal joints under construction loads, with a particular focus on the influence of bolt-tightening torque. Three longitudinal joint specimens were designed and fabricated, varying the bolt-tightening torque as a key parameter, and subjected to shear tests. The failure modes, load–slip behavior, and shear capacity of the joints were analyzed in relation to the tightening torque of high-strength bolts. The results indicate that when the bolt-tightening torque was set to 50% and 70% of the standard torque, the upper bolts of the joint sheared off, while the threads of the lower bolts were damaged. When the torque reached the standard value, all bolts were sheared off. The ultimate shear capacity of the longitudinal joints increased with higher bolt-tightening torque, with the optimal torque range identified as 70% to 85% of the specified standard. Ultimately, a method of calculation for evaluating the shear-bearing capacity of inverted arch longitudinal joints was proposed, with computational outcomes demonstrating a conservative bias that aligns with structural safety requirements. Full article

This study proposes a novel hybrid connection method for precast concrete shear walls, where the edge walls are connected using grouting splice sleeves and the middle walls are connected using grouted corrugated metallic ducts. To investigate the effects of connection type and axial compression ratio on structural performance, five shear wall specimens were tested under low-cycle reversed loading, with detailed analysis of their failure modes and hysteretic behavior. Based on experimental results and theoretical derivation, a restoring force model incorporating connection type was developed. The results demonstrate that hybrid-connected specimens exhibit significantly improved load-bearing capacity, ductility, and seismic performance compared to those with only grouted corrugated metallic duct connections. A higher axial compression ratio enhances structural strength but also accelerates damage progression, particularly after peak loading. A three-line skeleton curve model was established to describe the load, displacement, and stiffness relationships at key characteristic points, and unloading stiffness expressions for different loading stages were proposed. The calculated skeleton and hysteresis curves align well with the experimental results, accurately capturing the cyclic behavior of the hybrid-connected precast shear walls. Full article

The use of steel-concrete composite slim-floor beams with dowel shear connectors is uncommon, and the design rules provided in Eurocode 4 for composite construction are not directly applicable to the slim-floor composite beam. In this paper, a finite element model is developed, followed by a parametric study that examines the effects of various shear connector parameters on the structural behaviour of composite beams. The comparison and analysis show that the load-bearing capacity increases with a bigger concrete dowel, as long as the shear connection degree is less than 100% and the dowel diameter is not greater than 80 mm; the load-bearing capacity goes up about 5–10% for every 10 N/mm² increase in concrete strength and about 2% for every 4 mm increase in rebar diameter in the dowel; also, the dowel central spacing has a big impact on the structural behaviour. The composite beams showed great flexibility, with the end slip at the highest load being more than 6 mm and the maximum load declining by less than 15% when the midspan deflection reached L/30. The proposed calculation method for bending moment resistance is more than 90% accurate for composite beams that have a shear connection degree greater than 40%. The findings from this research provided more profound insights into the behaviour of this type of slim-floor composite beam. Full article

The connection zones between precast concrete composite slabs and composite walls commonly experience severe reinforcement conflicts due to protruding rebars, significantly reducing construction efficiency. To address this, a novel slotted concrete composite slab–composite shear wall (SCS-CW) connection without protruding rebars is proposed in this study. In this novel connection, rectangular slots are introduced at the ends of the precast slabs, and lap-spliced reinforcement is placed within the slots to enable force transfer across the joint region. To investigate the static performance of SCS-CW connections, four groups of connection specimens were designed and fabricated. Using the structural detailing of the connection zone as the variable parameter, the mechanical performance of each specimen group was analyzed. The results show that the specimens demonstrated bending failure behavior. The key failure modes were yielding of the longitudinal reinforcement in the post-cast layer, yielding of the lap-spliced reinforcement, and concrete crushing at the precast slab ends within the plastic hinge zone. Compared to composite slab–composite wall connections with protruding rebars, the SCS-CW connections demonstrated superior ductility and a higher load-carrying capacity, satisfying the design requirements. Additionally, it was revealed that the anchorage length of lap-spliced reinforcement significantly affected the ultimate load-carrying capacity and ductility of SCS-CW connections, thus highlighting anchorage length as a critical design parameter for these connections. This study also presents methods for calculating the flexural bearing capacity and flexural stiffness of SCS-CW connections. Finally, finite element modeling was conducted on the connections to further investigate the influences of the lap-spliced reinforcement quantity, diameter, and anchorage length on the mechanical performance of the connections, and corresponding design recommendations are provided. Full article
