Search Results (27)

To address the critical challenges of wellbore instability in deep coal seam drilling operations, this investigation developed an innovative organic–inorganic composite nanosealing agent (NS) through chemical modification of nano-silica. Advanced characterization techniques including Fourier Transform Infrared Spectroscopy, laser particle size analysis, and Scanning Electron Microscopy revealed that the optimized NS possessed a uniform particle distribution (mean diameter 86 nm) and enhanced surface hydrophobicity, effectively mitigating particle agglomeration. Systematic experimental evaluation demonstrated the material’s multifunctional performance: the NS-enriched drilling fluid achieved an 88.7% reduction in sand bed invasion depth and 76.4% decrease in filtrate loss at optimal concentration. Notably, comparative inhibition tests showed the NS outperformed conventional KCl and KPAM inhibitors, achieving 91.2% shale rolling recovery rate and 65.3% lower swelling rate than deionized water baseline. Core flooding experiments further confirmed superior sealing capability, with 2% NS addition attaining 88% sealing efficiency for low-permeability cores (0.5 mD) and establishing a 10 MPa breakthrough pressure threshold. Field implementation in the SSM1 well at Shenmu Huineng Liangshui Coal Mine validated the technical efficacy, the NS-enhanced drilling fluid system achieved 86.7% coal seam encounter rate with zero wellbore collapse incidents, while core recovery rate improved by 32.6% to 90.4% compared to conventional systems. This research breakthrough provides a scientific foundation for developing next-generation intelligent drilling fluids, demonstrating significant potential for ensuring drilling safety and enhancing gas recovery efficiency in deep coalbed methane reservoirs. Full article

Wellbore instability caused by hydration during the development of shale gas reservoirs poses significant challenges to drilling engineering. In this study, a novel and environmentally friendly shale inhibitor, TIL-NH₂, was synthesized via free radical polymerization using 1-vinylimidazole and N-(2-bromoethyl)-1,3-propanediamine dihydrobromide as the main raw materials. The molecular structure of TIL-NH₂ was characterized by infrared spectroscopy and nuclear magnetic resonance. Incorporating imidazole cations and amino bifunctional groups, TIL-NH₂ exhibits excellent inhibitory performance and environmental friendliness. Its performance was systematically evaluated through linear swelling tests, shale cuttings rolling recovery tests, permeability recovery experiments, and dynamic adsorption analyses. The results indicate the following: (1) At a concentration of 1.2 wt%, TIL-NH₂ reduced the linear swelling height of shale by 65.69%, significantly outperforming traditional inhibitors like KCl and NW-1. (2) Under conditions of 140 °C, the cuttings rolling recovery rate of TIL-NH₂ reached 88.12%, demonstrating excellent high-temperature resistance. (3) Permeability recovery experiments showed that at a concentration of 2.0 wt%, TIL-NH₂ achieved a permeability recovery rate of 90.58%, effectively mitigating formation damage. (4) Dynamic adsorption experiments indicated that at a concentration of 2.5 wt%, the adsorption capacity tended toward saturation, reaching 26.00 mg/g, demonstrating stable adsorption capability. Additionally, environmental friendliness evaluations revealed that TIL-NH₂ has a degradation rate exceeding 90% within 28 days, and its acute toxicity is significantly lower than that of traditional inhibitors like KCl (the LC₅₀ of TIL-NH₂ is 1080.3 mg/L, whereas KCl is only 385.4 mg/L). This research provides a high-efficiency and environmentally friendly new inhibitor for green drilling fluid systems in horizontal shale gas wells, offering important references for technological advancements in unconventional energy development. Full article

Wellbore instability, particularly in shale formations, presents a great challenge to modern drilling operations. Although conventional chemical inhibitors are frequently employed in water-based drilling fluids, they may not always function in highly reactive or naturally fractured shale formations. In recent years, mechanical inhibitors have attracted attention as a complementary solution to chemical methods. These inhibitors, which include carbon-based, silicon-based, metal-based, and mineral-based particle materials, provide structural support to the wellbore by physically plugging fractures and sealing microfractures. This paper presents a comprehensive review of the mineral types associated with shale wellbore instability as well as a critical analysis of the mechanisms, categories, and effectiveness of mechanical inhibitors in enhancing wellbore stability. The development challenges and prospects of mechanical inhibitors in water-based drilling fluids are also discussed. This review emphasizes the potential of mechanical inhibitors in reducing fluid invasion, preventing wellbore collapse, and improving overall drilling efficiency, which will help facilitate the development and large-scale application of mechanical inhibitors in drilling fluids. Full article

In this paper, small-molecule quaternary ammonium salts were synthesized by N-alkylation to inhibit hydration swelling and hydration dispersion. The prepared small-molecule quaternary ammonium salt was characterized by Fourier transform infrared (FTIR) spectroscopy, Thermogravimetric analysis (TGA), particle size analysis and Scanning electron microscopy (SEM), and its performance as an inhibitor in clay was evaluated by an anti-swelling test and a linear swelling test. The results show that small-molecule quaternary ammonium salt (TEE-2) synthesized by triethanolamine and epichlorohydrin in ethanol with a molar ratio of 1:1.5 can successfully inhibit the hydration swelling and dispersion of clay. The anti-swelling rate of TEE-2 was 84.94%, the linear swelling rate was 36.42%, and the linear swelling rate of 0.5% TEE-2 was only 29.34%. The hydration swelling of clay in 0.5% TEE-2 solution was significantly inhibited. The hydration inhibition mechanism of the small-molecule quaternary ammonium salt inhibitor 0.5% TEE-2 was analyzed by FTIR, SEM and TGA. It was considered that 0.5% TEE-2 has strong hydration inhibition, which was realized by infiltration and adsorption on the clay surface. Small-molecule quaternary ammonium salts were beneficial for maintaining wellbore stability and reducing the risk of wellbore instability. Full article

In this study, a new polyionic polymer inhibitor, TIL-NH₂, was developed to address the instability of shale gas horizontal wells caused by water-based drilling fluids. The structural characteristics and inhibition effects of TIL-NH₂ on mud shale were comprehensively analyzed using infrared spectroscopy, NMR spectroscopy, contact angle measurements, particle size distribution, zeta potential, X-ray diffraction, thermogravimetric analysis, and scanning electron microscopy. The results demonstrated that TIL-NH₂ significantly enhances the thermal stability of shale, with a decomposition temperature exceeding 300 °C, indicating excellent high-temperature resistance. At a concentration of 0.9%, TIL-NH₂ increased the median particle size of shale powder from 5.2871 μm to over 320 μm, effectively inhibiting hydration expansion and dispersion. The zeta potential measurements showed a reduction in the absolute value of illite’s zeta potential from −38.2 mV to 22.1 mV at 0.6% concentration, highlighting a significant decrease in surface charge density. Infrared spectroscopy and X-ray diffraction confirmed the formation of a close adsorption layer between TIL-NH₂ and the illite surface through electrostatic and hydrogen bonding, which reduced the weakly bound water content to 0.0951% and maintained layer spacing of 1.032 nm and 1.354 nm in dry and wet states, respectively. Thermogravimetric analysis indicated a marked reduction in heat loss, particularly in the strongly bound water content. Scanning electron microscopy revealed that shale powder treated with TIL-NH₂ exhibited an irregular bulk shape with strong inter-particle bonding and low hydration degree. These findings suggest that TIL-NH₂ effectively inhibits hydration swelling and dispersion of shale through the synergistic effects of cationic imidazole rings and primary amine groups, offering excellent temperature and salt resistance. This provides a technical foundation for the low-cost and efficient extraction of shale gas in horizontal wells. Full article

Drilling through shale formations can be expensive and time-consuming due to the instability of the wellbore. Further, there is a need to develop inhibitors that are environmentally friendly. Our study discovered a cost-effective solution to this problem using Gum Arabic (ArG). We evaluated the inhibition potential of an ArG clay swelling inhibitor and fluid loss controller in water-based mud (WBM) by conducting a linear swelling test, capillary suction timer test, and zeta potential, fluid loss, and rheology tests. Our results displayed a significant reduction in linear swelling of bentonite clay (Na-Ben) by up to 36.1% at a concentration of 1.0 wt. % ArG. The capillary suction timer (CST) showed that capillary suction time also increased with the increase in the concentration of ArG, which indicates the fluid-loss-controlling potential of ArG. Adding ArG to the drilling mud prominently decreased fluid loss by up to 50%. Further, ArG reduced the shear stresses of the base mud, showing its inhibition and friction-reducing effect. These findings suggest that ArG is a strong candidate for an alternate green swelling inhibitor and fluid loss controller in WBM. Introducing this new green additive could significantly reduce non-productive time and costs associated with wellbore instability while drilling. Further, a dynamic linear swelling model, based on machine learning (ML), was created to forecast the linear swelling capacity of clay samples treated with ArG. The ML model proposed demonstrates exceptional accuracy (R² score = 0.998 on testing) in predicting the swelling properties of ArG in drilling mud. Full article

Shale hydration dispersion and swelling are primary causes of wellbore instability in oil and gas reservoir exploration. In this study, inulin, a fructo-oligosaccharide extracted from Jerusalem artichoke roots, was modified by acylation with three acyl chlorides, and the products (C10-, C12-, and C14-inulin) were investigated for their use as novel shale hydration inhibitors. The inhibition properties were evaluated through the shale cuttings hot-rolling dispersion test, the sodium-based bentonite hydration test, and capillary suction. The three acylated inulins exhibited superb hydration-inhibiting performance at low concentrations, compared to the commonly used inhibitors of KCl and poly (ester amine). An inhibition mechanism was proposed based on surface tension measurements, contact angle measurements, Fourier-transform infrared analysis, and scanning electron microscopy. The acylated inulin reduced the water surface tension significantly, thus, retarding the invasion of water into the shale formation. Then, the acylated inulin was adsorbed onto the shale surface by hydrogen bonding to form a compact, sealed, hydrophobic membrane. Furthermore, the acylated inulins are non-toxic and biodegradable, which meet the increasingly stringent environmental regulations in this field. This method might provide a new avenue for developing high-performance and ecofriendly shale hydration inhibitors. Full article

Drilling fluids play an essential role in shale gas development. It is not possible to scale up the use of water-based drilling fluid in shale gas drilling in Yunnan, China, because conventional inhibitors cannot effectively inhibit the hydration of the illite-rich shale formed. In this study, the inhibition performance of modified asphalt was evaluated using the plugging test, expansion test, shale recovery experiment, and rock compressive strength test. The experimental results show that in a 3% modified asphalt solution, the expansion of shale is reduced by 56.3%, the recovery is as high as 97.8%, water absorption is reduced by 24.3%, and the compression resistance is doubled compared with those in water. Moreover, the modified asphalt can effectively reduce the fluid loss of the drilling fluid. Modified asphalt can form a hydrophobic membrane through a large amount of adsorption on the shale surface, consequently inhibiting shale hydration. Simultaneously, modified asphalt can reduce the entrance of water into the shale through blocking pores, micro-cracks, and cracks and further inhibit the hydration expansion of shale. This demonstrates that modified asphalt will be an ideal choice for drilling shale gas formations in Yunnan through water-based drilling fluids. Full article

An inhibitor that can effectively inhibit shale hydration is necessary for the safe and efficient development of shale gas. In this study, a novel ionic liquid copolymer shale inhibitor (PIL) was prepared by polymerizing the ionic liquid monomers 1-vinyl-3-aminopropylimidazolium bromide, acrylamide, and methacryloyloxyethyl trimethyl ammonium chloride. The chemical structure was characterized using fourier transform infrared spectroscopy (FT-IR) and hydrogen-nuclear magnetic resonance (H-NMR), and the inhibition performance was evaluated using the inhibition of slurrying test, bentonite flocculation test, linear expansion test, and rolling recovery test. The experimental results showed that bentonite had a linear expansion of 27.9% in 1 wt% PIL solution, 18% lower than that in the polyether amine inhibitor. The recovery rate of shale in 1 wt% PIL was 87.4%. The ionic liquid copolymer could work synergistically with the filtrate reducer, reducing filtration loss to 7.2 mL with the addition of 1%. Mechanism analysis showed that PIL adsorbed negatively charged clay particles through cationic groups, which reduced the electrostatic repulsion between particles. Thus, the stability of the bentonite gel systems was destroyed, and the hydration dispersion and expansion of bentonite were inhibited. PIL formed a hydrophobic film on the surface of clay and prevented water from entering into the interlayer of clay. In addition, PIL lowered the surface tension of water, which prevented the water from intruding into the rock under the action of capillary force. These are also the reasons for the superior suppression performance of PIL. Full article

Wellbore instability caused by the hydration of shale formations during drilling is a major problem in drilling engineering. In this paper, the shale inhibition performance of polyhydroxy-alkanolamine was evaluated using an anti-swelling test, linear swelling test, wash-durable test and montmorillonite hydration and dispersion experiment. Additionally, the shale inhibition mechanism of polyhydroxy-alkanolamine was studied via Fourier transform infrared spectroscopy (FTIR), particle size, zeta potential, thermogravimetric analysis (TGA) and scanning electron microscopy (SEM). The results show that the use of polyhydroxy-alkanolamine (EGP-2) could result in a relatively lower linear swelling rate of montmorillonite, and the linear swelling rate of 0.3% EGP-2 is 26.98%, which is stronger than that of 4% KCl. The anti-swelling rate of 0.3% EGP-2 is 43.54%, and the shrinkage–swelling rate of 0.3% EGP-2 is 34.62%. The study on the inhibition mechanism revealed that EGP-2 can permeate and adsorb on the surface of montmorillonite. The rolling recovery rate of easily hydrated shale was as high as 79.36%, which greatly reduces the dispersion ability of water to easily hydrated shale. The results of this study can be used to maintain the stability of a wellbore, which is conducive to related research. Full article

Shale rock swelling poses a significant challenge during drilling a well, leading to issues related to wellbore instability. Water-based mud with specific shale inhibitors is preferred over oil-based drilling mud due to its lower environmental impact. Recently, ionic liquids (ILs) have emerged as potential shale inhibitors due to their adjustable properties and strong electrostatic attraction. However, research has shown that the most commonly used class of ILs (imidazolium) in drilling mud are toxic, non-biodegradable, and expensive. Deep Eutectic Solvents (DESs), the fourth generation of ionic liquids, have been proposed as a cheaper and non-toxic alternative to ILs. However, ammonium salt-based DESs are not truly environmentally friendly. This research explores the utilization of Natural Deep Eutectic Solvent (NADES) based on Epsom salt (a naturally occurring salt) and glycerine as a drilling fluid additive. The drilling mud is prepared according to API 13B-1 standards. Various concentrations of NADES-based mud are tested for yield point, plastic viscosity, and filtration properties for both aged and non-aged samples. The linear swell meter is used to determine the percentage swelling of the NADES-based mud, and the results are compared with the swelling caused by KCl- and EMIM-Cl-based mud. FTIR analysis is conducted to understand the interaction between NADES and clay, while surface tension, d-spacing (XRD), and zeta potential are measured to comprehend the mechanism of swelling inhibition by NADES. The findings reveal that NADES improves the yield point and plastic viscosity of the mud, resulting in a 26% reduction in mudcake thickness and a 30.1% decrease in filtrate volume at a concentration of 1%. NADES achieves a significant 49.14% inhibition of swelling at the optimal concentration of 1%, attributed to its ability to modify surface activity, zeta potential of clay surfaces, and d-spacing of clay layers. Consequently, NADES emerges as a non-toxic, cost-effective, and efficient shale inhibitor that can replace ILs and DESs. Full article

Designing an effective drilling mud is a critical aspect of the drilling process. A well-designed drilling mud should not only provide efficient mud hydraulics but also fulfill three important functions: enhancing mud rheology, inhibiting hydrate formation in deepwater drilling, and suppressing shale swelling when drilling through shale formations. Achieving these functions often requires the use of various additives, but these additives are often expensive, non-biodegradable, and have significant environmental impacts. To address these concerns, researchers have explored the potential applications of ionic liquids and deep eutectic solvents in drilling mud design, which have shown promising results. However, an even more environmentally friendly alternative has emerged in the form of natural deep eutectic solvents (NADES). This research focuses on an in-house-prepared NADES based on calcium chloride and glycerine, with a ratio of 1:4, prepared at 60 °C, and utilizes it as a drilling mud additive following the API 13 B-1 standards and checks its candidacy as a rheology modifier, hydrates, and shale inhibitor. The findings of the study demonstrate that the NADES-based mud significantly improves the overall yield point to plastic viscosity ratio (YP/PV) of the mud, provides good gel strength, and inhibits hydrate formation by up to 80%. Additionally, it has shown an impressive 62.8% inhibition of shale swelling while allowing for 84.1% improved shale recovery. Moreover, the NADES-based mud exhibits a 28% and 25% reduction in mud filtrate and mud cake thickness, respectively, which is further supported by the results of XRD, zeta potential, and surface tension. Based on these positive outcomes, the calcium chloride–glycerine NADES-based mud is recommended as a versatile drilling mud additive suitable for various industrial applications. Furthermore, it presents a more environmentally friendly option compared to traditional additives, addressing concerns about cost, biodegradability, and environmental impact in the drilling process for an ultimate global impact. Full article

During drilling, almost 70% of wellbore instability issues result from the encountering of shale formations. Various additives such as salts, silicates, and polymers are used in water-based mud to enhance its shale-inhibition capability; however, such additives have certain limitations. Lately, ionic liquids and deep eutectic solvents (DES) have been used by various research groups as shale inhibitors in drilling fluid due to their biodegradability and efficacy. However, their popularity faded when a natural derivative of DES, i.e., Natural Deep Eutectic solvent (NADES), came into the picture. This research utilizes the in-house-prepared Ascorbic acid and Glycerine (AA:Gly)-based NADES as a drilling fluid additive for shale inhibition and compares its efficacy with counterpart inhibitors such as KCl, imidazolium-based ionic liquid, and Choline Chloride-based DES. The results show that 3% NADES improved the overall Yield point to Plastic viscosity ratio, with a 39.69% decline in mud cake thickness and a 28% decline in the filtrate volume of drilling mud. Along with improved drilling fluid properties, 3% NADES resulted in 77.77% shale inhibition and 87% shale recovery. Surface tension, d-spacing, zeta potential, and FESEM have been conducted to justify and elucidate the inherent mechanism behind the working of NADES as a drilling fluid additive and clay stabilizer. Thus, Ascorbic acid-based NADES is recommended as a potential non-toxic and cheap drilling fluid additive to improve drilling fluid properties and clay stability. Full article

One of the foremost causes of wellbore instability during drilling operations is shale swelling and hydration induced by the interaction of clay with water-based mud (WBM). Recently, the use of surfactants has received great interest for preventing shale swelling, bit-balling problems, and providing lubricity. Herein, a novel synthesized magnetic surfactant was investigated for its performance as a shale swelling inhibitor in drilling mud. The conventional WBM and magnetic surfactant mixed WBM (MS–WBM) were formulated and characterized using Fourier Transform Infrared (FTIR) and Thermogravimetric analyzer (TGA). Subsequently, the performance of 0.4 wt% magnetic surfactant as shale swelling and clay hydration inhibitor in drilling mud was investigated by conducting linear swelling and capillary suction timer (CST) tests. Afterward, the rheological and filtration properties of the MS–WBM were measured and compared to conventional WBM. Lastly, the swelling mechanism was investigated by conducting a scanning electron microscope (SEM), zeta potential measurement, and particle size distribution analysis of bentonite-based drilling mud. Experimental results revealed that the addition of 0.4 wt% magnetic surfactant to WBM caused a significant reduction (~30%) in linear swelling. SEM analysis, contact angle measurements, and XRD analysis confirmed that the presence of magnetic surfactant provides long-term swelling inhibition via hydrophobic interaction with the bentonite particles and intercalation into bentonite clay layers. Furthermore, the inhibition effect showed an increase in fluid loss and a decrease in rheological parameters of bentonite mixed mud. Overall, the use of magnetic surfactant exhibits sterling clay swelling inhibition potential and is hereby proffered for use as a drilling fluid additive. Full article

During drilling in deep shale gas reservoirs, drilling fluid losses, hole wall collapses, and additional problems occur frequently due to the development of natural fractures in the shale formation, resulting in a high number of engineering accidents such as drilling fluid leaks, sticking, mud packings, and buried drilling tools. Moreover, the horizontal section of horizontal well is long (about 1500 m), and the problems of friction, rock carrying, and reservoir pollution are extremely prominent. The performance of drilling fluids directly affects drilling efficiency, the rate of engineering accidents, and the reservoir protection effect. In order to overcome the problems of high filtration in deep shale formations, collapse of borehole walls, sticking of pipes, mud inclusions, etc., optimization studies of water-based drilling fluid systems have been conducted with the primary purpose of controlling the rheology and water loss of drilling fluid. The experimental evaluation of the adsorption characteristics of “KCl + polyamine” anti-collapse inhibitor on the surface of clay particles and its influence on the morphology of bentonite was carried out, and the mechanism of inhibiting clay mineral hydration expansion was discussed. The idea of controlling the rheology and water loss of drilling fluid with high temperature resistant modified starch and strengthening the inhibition performance of drilling fluid with “KCl + polyamine” was put forward, and a high temperature-resistant modified starch polyamine anti-sloughing drilling fluid system with stable performance and strong plugging and strong inhibition was optimized. The temperature resistance of the optimized water-based drilling fluid system can reach 180 °C. Applied to on-site drilling of deep shale gas horizontal wells, it effectively reduces the rate of complex accidents such as sticking, mud bagging, and reaming that occur when resistance is encountered during shale formation drilling. The time for a single well to trip when encountering resistance decreases from 2–3 d in the early stages to 3–10 h. The re-use rate of the second spudded slurry is 100 percent, significantly reducing the rate of complex drilling accidents and saving drilling costs. It firmly supports the optimal and rapid construction of deep shale gas horizontal wells. Full article
