Search Results (62)

This study introduces a novel approach for minimizing assembly errors in wind turbine gearboxes using a hybrid optimization algorithm, Particle Swarm-Bacteria Foraging Optimization (PSBFO). By integrating error-driven task sequencing and real-time error feedback with the PSBFO algorithm, we developed a comprehensive framework tailored to the unique challenges of gearbox assembly. The PSBFO algorithm combines the global search capabilities of PSO with the local refinement of BFO, creating a unified framework that efficiently explores task sequencing, minimizing misalignment and torque misapplication assembly errors. The methodology results in a 38% reduction in total assembly errors, improving both process accuracy and efficiency. Specifically, the PSBFO algorithm reduced errors from an initial value of 50 to a final value of 5 across 20 iterations, with components such as the low-speed shaft and planetary gear system showing the most substantial reductions. The 50 to 5 error reduction represents a significant decrease in assembly errors from an unoptimized (50) to an optimized (5) sequence, achieved through the PSBFO algorithm, by minimizing dimensional deviations, torque mismatches, and alignment errors across 26 critical gearbox components. While the primary focus is on wind turbine gearbox applications, this approach has the potential for broader applicability in error-prone assembly processes in industries such as automotive and aerospace, warranting further validation in future studies. Full article

The scope of this paper is the development of a cost-effective wireless torque measurement system for vehicle drivetrain shafts. The prototype integrates strain gauges, an HX711 conditioner, a Wemos D1 Mini ESP8266, and a rechargeable battery directly on the rotating shaft, forming a self-contained sensor node. Calibration against a certified dynamometric wrench confirmed an operating span of ±5–50 N·m. Within this range, the device achieved a mean absolute error of 0.559 N·m. It also maintained precision better than ±2.5 N·m at 95% confidence, while real-time data were transmitted via Wi-Fi. The total component cost is below EUR 30 based on current prices. The novelty of this proof-of-concept implementation demonstrates that reliable, IoT-enabled torque sensing can be realized with low-cost, readily available parts. The paper details assembly, calibration, and deployment procedures, providing a transparent pathway for replication. By aligning with Industry 4.0 requirements for smart, connected equipment, the proposed torque measurement system offers an affordable solution for process monitoring and predictive maintenance in automotive and industrial settings. Full article

Double-suction centrifugal pumps are extensively employed in industrial applications owing to their high efficiency, low vibration, superior cavitation resistance, and operational durability. This study analyzes how impeller oblique cutting angles (0°, 6°, 9°, 12°) affect a double-suction pump at a fixed 4% trimming ratio and constant average post-trim diameter. Numerical simulations and tests reveal that under low-flow (0.7Q_d) and design-flow conditions, the flat-cut (0°) minimizes reflux ratio and maximizes efficiency by aligning blade outlet flow with the mainstream. Increasing oblique cutting angles disrupts this alignment, elevating reflux and reducing efficiency. Conversely, at high flow (1.3Q_d), the 12° bevel optimizes outlet flow, achieving peak efficiency. Pressure pulsation at the volute tongue (P11) peaks at the blade-passing frequency, with amplitudes significantly higher for 9°/12° bevels than for 0°/6°. The flat-cut suppresses wake vortices and static–rotor interaction, but oblique cutting angle choice critically influences shaft-frequency pulsation. Entropy analysis identifies the volute as the primary loss source. Larger oblique cutting angles intensify wall effects, increasing total entropy; pump chamber losses rise most sharply due to worsened outlet velocity non-uniformity and turbulent dissipation. The flat-cut yields minimal entropy at Q_d. These findings provide a basis for tailoring impeller trimming to specific operational requirements. Furthermore, the systematic analysis provides critical guidance for impeller trimming strategies in other double-suction pumps and pumps as turbines in micro hydropower plants. Full article

This paper presents a comparative analysis of machine learning-based methods for predicting shaft power in ships, a key factor in optimizing ship performance. Accurate shaft power prediction facilitates efficient operations, reducing fuel consumption, emissions, and maintenance costs, aligning with environmental regulations and promoting sustainable maritime practices. The proposed approach evaluates three machine learning methods, analyzing 431 models to determine the most accurate and reliable option for VLCC tankers. XGBoost emerged as the top-performing model, delivering a 13% improvement in accuracy over traditional methods. Using the SHAP framework, key factors influencing shaft power predictions—such as GPS speed, draft, days from dry dock, and wave height—were identified, enhancing model transparency and decision-making clarity. This explainability fosters trust in the use of AI within marine engineering. The results demonstrate that machine learning can optimize maintenance scheduling by reducing unnecessary cleaning procedures, mitigating propulsion system wear, and improving reliability. By using predictive insights, ship operators can achieve better fuel efficiency, lower emissions, and cost savings. The study underscores the potential of explainable machine learning models as transformative tools for ship performance monitoring, supporting greener and more efficient maritime operations. Full article

The flight feather rachis is a lightweight, anisotropic structure that must withstand asymmetric aerodynamic loads generated during flapping flight—particularly under unidirectional compression during the wing downstroke. To accommodate this spatiotemporal loading regime, the rachis exhibits refined internal organization, especially along the dorsoventral axis. In this study, we used finite element modeling (FEM) to investigate how dorsoventral polarization in cortical keratin allocation modulates the mechanical performance of shaft-like structures under bending. All models were constructed with conserved second moments of area and identical material properties to isolate the effects of spatial material placement. We found that dorsal-biased reinforcement delays yield onset, enhances strain dispersion, and promotes elastic recovery, while ventral polarization leads to premature strain localization and plastic deformation. These outcomes align with the dorsally thickened rachises observed in flight-specialized birds and reflect their adaptation to asymmetric aerodynamic forces. In addition, we conducted a conceptual exploration of radial (cortex–medulla) redistribution, suggesting that even inner–outer asymmetry may contribute to directional stiffness tuning. Together, our findings highlight how the flight feather rachis integrates cortical material asymmetry to meet directional mechanical demands, offering a symmetry-informed framework for understanding biological shaft performance. Full article

The rapid advancement of modern megapolises has led to a dearth of surface space, and, in response, engineers have begun to trial substitutes below ground level. Shafts are generally used to provide temporary access and permanent work to the subsurface for tunnelling, as well as for lifts or ventilation purposes. In urban areas, one important design issue is the prediction of the excavation-induced displacements by open caisson shaft construction. Settlements and ground movements associated with open caisson shafts are influenced by the choice of construction method, soil composition, and excavation geometry. Compared with other geotechnical construction events, for instance, tunnelling, the literature relating to the ground deformations induced from open caisson shafts are comparatively limited. This review offers an evaluation of several case studies that utilize experimental and computational modeling techniques to provide clearer insights into earth pressure distribution and induced surface and subsurface soil displacements, as well as the associated ground deformations during open caisson shaft construction. The modeling test results are compared to the state of the practice ground deformation prediction theories and measured results from field monitoring data. Findings indicate that the lateral earth pressure distribution aligns closely with the theoretical predictions based on Terzaghi’s and Berezantzev’s models, and lateral earth pressure diminishes gradually until the onset of active wall displacement. Current modeling techniques generally fail to properly represent in situ stress states and large-scale complexities, emphasizing the need for hybrid approaches that combine physical and numerical methodologies. In future studies, modern approaches, including artificial intelligence (AI) monitoring (e.g., PINNs, ACPP), multi-field coupling models (e.g., THMC), and transparent soil testing, hold profound potential for real-time prediction, optimization, and visualization of soil deformation. Numerical–physical coupling tests will integrate theory and practice. Improving prediction reliability in complicated soil conditions such as composite and heterogenous strata using different modeling techniques is still unclear, and further investigation is therefore needed. Full article

Under alternating loads, the contact situation for self-aligning roller bearings in the main shaft of a wind turbine is complex. Few methodologies exist for calculating the contact stress of main shaft bearings. We propose a method for calculating the contact stress of main shaft bearings in wind turbines; by simulating alternating loads that affect the turbine’s lifespan with a probability of 99%, analyzing the operational characteristics of the bearings under these loads using the roller slice method, and establishing a load–displacement model, this model serves as the boundary condition for contact stress simulation. We present the approach for building a three-dimensional finite element simulation model of contact stress, followed by model validation. The findings reveal that the maximum stress within the spindle bearing is concentrated in the contact zone, taking on an elliptical configuration. The maximum contact stress, as computed by the proposed method, amounts to 1356.3 MPa, and the bearing’s load-bearing performance adequately fulfills the design requirements. A comparative analysis with the calculation results documented in the existing literature shows that the average discrepancies in the computed outcomes for the roller’s contact with the inner and outer rings are 2.55% and 2.48%, respectively, and this validates the high reliability of the proposed approach. The research conducted in this thesis can further enhance the credibility of the contact stress calculation method for large-scale wind turbine spindle bearings. Full article

The International Maritime Organization (IMO) mandates a reduction in carbon dioxide emissions from 2008 levels by at least 40% by 2030, prompting the widespread adoption of slow steaming and engine de-rating strategies. This study investigates the fatigue life of marine propulsion shafts under slow steaming conditions, focusing on the interplay between torsional and bending vibrations. A finite element (FE) model of a low-speed two-stroke propulsion system is developed, incorporating torsional and lateral excitation sources from both the engine and propeller. Vibrational stresses are computed for multiple operating conditions, and fatigue life is assessed using both the conventional Det Norske Veritas (DNV) methodology and a proposed biaxial stress approach. Results indicate that while torsional vibrations remain the primary fatigue driver, bending-induced stresses contribute marginally to the overall fatigue life. The proposed methodology refines high-cycle fatigue (HCF) assessment by incorporating a corrected S-N curve and equivalent von Mises stress criteria. Comparisons with classification society standards demonstrate that existing guidelines remain valid for most cases, though further studies on extreme alignment deviations and dynamic bending effects are recommended. This study enhances understanding of fatigue mechanisms in marine shafting and proposes a refined methodology for improved fatigue life prediction. Full article

To address the issues of low shear strength, susceptibility to eccentricity, and alignment difficulties in post-inserted core piles, a new type of steel tube concrete integrated mixing composite pile has been independently developed. This pile type replaces the conventional mixing pile shaft with a larger diameter steel tube equipped with mixing blades. After forming the external annular cement mixing pile, the steel tube is retained, and the hollow core is filled with concrete. To thoroughly explore the vertical compressive bearing characteristics of the steel tube concrete mixing composite pile and clarify its vertical compressive behavior, static load field tests and PLAXIS 3D finite element numerical simulations were conducted on four test piles of different sizes to analyze the vertical bearing performance of the steel tube concrete mixing composite pile. The research results indicate that for a composite pile with a length of 40 m, an outer diameter of 1000 mm, and a steel tube diameter of 273 mm, the ultimate bearing capacity of a single pile is 7200 kN, with the steel tube concrete core contributing approximately 81% of the vertical bearing capacity, while the cement mixing pile contributes around 19%. Based on the characteristic that the maximum axial force is concentrated in the upper half of the pile length, an innovative variable-diameter design with a reduced wall thickness of the steel pipe in the lower part of the pile was proposed. Practical verification has shown that, despite the reduced material usage, the load-bearing capacity remains largely unchanged. This effectively validates the feasibility of the “strong upper part and weak lower part” design concept and provides an effective way to reduce construction costs. Full article

Nonunion of the second metatarsal presents a significant clinical challenge, often leading to pain, functional impairment, and deformity. Various treatment strategies have been described in the literature, tailored to the patient’s specific characteristics. To provide a comprehensive overview of the available therapeutic options, a literature review was conducted. In this context, this article aims to present an innovative and personalized surgical technique for patients with nonunion and an altered metatarsal formula following a proximal shaft fracture of the second metatarsal. This technique enables the simultaneous consolidation of the nonunion and restoration of metatarsal alignment, with favorable clinical, functional, and radiological outcomes observed over a three-year follow-up period. Full article

The design scheme of elastically supported submarine propulsion shafting can effectively realize the attenuation of the vibration energy and improve the stealth performance of the whole submarine. However, the elastic deformation generated by the system will affect the alignment state of shafting, thus affecting its safety and reliability. Aiming at this problem, taking a certain elastically supported submarine propulsion shafting as the study object of this paper, the alignment calculation model of the shafting was established and validated, and an equivalent line-surface method was proposed to measure the elastic bearing displacement. On this basis, the concept of the dynamic bearing load influence numbers (BLINs) was elicited, and a response surface method using Gaussian process regression (GPR) was designed to establish the mapping relationship between the elastic displacement and the dynamic BLINs. Taking the equivalent displacements of the bearings as variables, the alignment optimization of the shafting was achieved by combining the genetic algorithm and the response surfaces. After optimization, the load of the rear stern bearing was reduced by 16.67%, and the standard deviation of the bearing loads was reduced by 37.19%. Hence, the alignment state of the shafting was improved. The studied results can provide theoretical and technical support for the analysis and optimization of the alignment characteristics of elastically supported submarine propulsion shafting. Full article

Misalignment faults in drive systems occur when the motor and load are not properly aligned, leading to deviations in the centerlines of the coupled shafts. These faults can cause significant damage to bearings, shafts, and couplings, making early detection essential. Traditional diagnostic techniques rely on vibration monitoring, which provides insights into both mechanical and electromagnetic fault signatures. However, its main drawback is the need for external sensors, which may not be feasible in certain applications. Alternatively, motor current signature analysis (MCSA) has proven effective in detecting faults without requiring additional sensors. This study investigates misalignment faults in synchronous reluctance motors (SynRMs) by analyzing both vibration and current signals under different load conditions and operating speeds. Fast Fourier transform (FFT) is applied to extract characteristic frequency components linked to misalignment. Experimental results reveal that the amplitudes of rotational frequency harmonics ($1x{f}_r$, $2x{f}_r$, and $3x{f}_r$) increase in the presence of misalignment, with $1x{f}_r$ exhibiting the most stable progression. Additionally, acceleration-based vibration analysis proves to be a more reliable diagnostic tool compared to velocity measurements. These findings highlight the potential of combining current and vibration analysis to enhance misalignment detection in SynRMs, improving predictive maintenance strategies in industrial applications. Full article

Monteggia fractures represent complex injuries requiring careful assessment and surgical intervention. This case report presents a rare variation of a Bado type I Monteggia fracture–dislocation that resembles features from the Jupiter subclassification type IID. A 39-year-old male sustained a high-energy injury while riding an all-terrain vehicle, resulting in a proximal segmental ulnar shaft fracture with anterior radial head dislocation. Open reduction and internal fixation (ORIF) of the ulna using a pre-contoured proximal ulna low-contact dynamic compression plate (LC-DCP) successfully restored alignment, leading to spontaneous reduction of the radial head. The postoperative course was uneventful, with satisfactory healing and functional recovery. This case underscores the importance of meticulous ulnar reconstruction in Monteggia fracture–dislocations and contributes to the limited literature on anterior radial head dislocation patterns. Full article

Splined assemblies ensure precise torque transmission and alignment in mechanical systems. Three-dimensional printing, especially FDM, enables fast production of customized components with complex geometries, reducing material waste and costs. Optimized printing parameters improve dimensional accuracy and performance. Dimensional accuracy is a critical aspect in the additive manufacturing of mechanical components, especially for splined shafts and hubs, where deviations can impact assembly precision and functionality. This study investigates the influence of key FDM 3D printing parameters—layer thickness, infill density, and nominal diameter—on the dimensional deviations of splined components. A full factorial experimental design was implemented, and measurements were conducted using a high-precision coordinate measuring machine (CMM). To optimize dimensional accuracy, artificial neural networks (ANNs) were trained using experimental data, and a genetic algorithm (GA) was employed for multi-objective optimization. Three ANN models were developed to predict dimensional deviations for different parameters, achieving high correlation coefficients (R² values of 0.961, 0.947, and 0.910). The optimization process resulted in an optimal set of printing conditions that minimize dimensional errors. The findings provide valuable insights into improving precision in FDM-printed splined components, contributing to enhanced design tolerances and manufacturing quality. Full article

Background: In reverse shoulder arthroplasty (RSA), the neck–shaft angle (NSA) has trended downward from 155° to 135° to reduce scapular notching, but concerns about instability persist. To assess superior–lateral stability, we developed the intraoperative two-hand lever test (2HLT). The primary objective was to evaluate the effectiveness of the 2HLT, analyze the learning curve in this first study reporting on the new Perform stem, and compare the liner characteristics of 155° and 135° systems. Methods: In a single-surgeon learning curve study, 81 RSA procedures with the new Perform stem (Stryker) were included. The outcomes included the 2HLT test applied in 65 cases, early dislocations, stem alignment, stem length, liner type/thickness, and complications. The early dislocation rate was compared to 167 prior Ascend Flex RSA procedures (Stryker). The liner characteristics of three 135° systems (Perform/Stryker, Univers/Arthrex, and Altivate/Enovis) were compared to traditional 155° Grammont systems (Delta Xtend/DePuy, Affinis Metal/Mathys, SMR 150/Lima, and Aequalis Reversed/Stryker), focusing on jump height (JH) and the liner stability ratio (LSR). Results: In 63% (31/49) of the cases, the 2HLT detected superior–lateral instability, necessitating a retentive 135° liner. The early dislocation rate in the Perform cohort was 4.9% (0% for retentive liners, 8% for standard liners) versus 0% in the Ascend Flex cohort. The mean effective NSA was 133° (127–144°) for short Perform stems and 135° (129–143°) for long stems. Long Perform stems significantly reduced varus outlier density below 132° and 130° (p = 0.006, 0.002). The 36 mm Perform 135° standard liner has a JH of 8.1 mm and an LSR of 152%, markedly lower than the Altivate (10.0 mm/202%) and Univers (9.7 mm/193%) and similar to traditional 155° Grammont liners (8.1–8.9 mm/147–152%). Perform retentive liners have LSR values of 185–219%, comparable to the established 135° design standard liners (195–202%). In the Perform cohort, early complications included four superior–lateral dislocations (all standard liners, LSR 147–152%) requiring four revisions. Conclusions: Perform standard liners have a lower LSR than the established 135° designs. Retentive Perform liners (LSR > 184%) are comparable to standard liners of established 135° designs and effectively mitigate instability. We recommend discontinuing non-retentive Perform standard liners (NSA 135°, LSR < 158%) due to the 63% superior–lateral instability rate detected with the novel 2HLT, necessitating retentive liners, the documented LSR-NSA implant mismatch, and an early clinical dislocation rate of up to 8%. Full article
