Search Results (47)

The inter-shaft bearing is an important component of aero-engine rotor systems. It works between a high-pressure rotor and a low-pressure rotor. Effective fault diagnosis of it is significant for an aero-engine. The casing vibration signals can promptly and intuitively reflect changes in the operational health status of an aero-engine’s support system. However, affected by a complex vibration transmission path and vibration of the dual-rotor, the intrinsic vibration information of the inter-shaft bearing is faced with strong noise and a dual-frequency excitation problem. This excitation is caused by the wide span of vibration source frequency distribution that results from the quite different rotational speeds of the high-pressure rotor and low-pressure rotor. Consequently, most existing fault diagnosis methods cannot effectively extract inter-shaft bearing characteristic frequency information from the casing signal. To solve this problem, this paper proposed the denoised improved envelope spectrum (DIES) method. First, an improved envelope spectrum generated by a spectrum subtraction method is proposed. This method is applied to solve the multi-source interference with wide-band distribution problem under dual-frequency excitation. Then, an improved adaptive-thresholding approach is subsequently applied to the resultant subtracted spectrum, so as to eliminate the influence of random noise in the spectrum. An experiment on a public run-to-failure bearing dataset validates that the proposed method can effectively extract an incipient bearing fault characteristic frequency (FCF) from strong background noise. Furthermore, the experiment on the inter-shaft bearing of an aero-engine test platform validates the effectiveness and superiority of the proposed DIES method. The experimental results demonstrate that this proposed method can clearly extract fault-related information from dual-frequency excitation interference. Even amid strong background noise, it precisely reveals the inter-shaft bearing’s fault-related spectral components. Full article

Large turbine generators rely on shaft earthing brushes to safely divert harmful shaft currents to ground, protecting bearings from electrical damage. This paper presents a novel deep learning-based diagnostic framework to detect and classify faults in shaft earthing brushes of large turbine generators. A key innovation lies in the use of FFT-derived spectrograms from both voltage and current waveforms as dual-channel inputs to the CNN, enabling automatic feature extraction of time–frequency patterns associated with different SEB fault types. The proposed framework combines advanced signal processing and convolutional neural networks (CNNs) to automatically recognize fault-related patterns in shaft grounding current and voltage signals. In the approach, raw time-domain signals are converted into informative time–frequency representations, which serve as input to a CNN model trained to distinguish normal and faulty conditions. The framework was evaluated using data from a fleet of large-scale generators under various brush fault scenarios (e.g., increased brush contact resistance, loss of brush contact, worn out brushes, and brush contamination). Experimental results demonstrate high fault detection accuracy (exceeding 98%) and the reliable identification of different fault types, outperforming conventional threshold-based monitoring techniques. The proposed deep learning framework offers a novel intelligent monitoring solution for predictive maintenance of turbine generators. The contributions include the following: (1) the development of a specialized deep learning model for shaft earthing brush fault diagnosis, (2) a systematic methodology for feature extraction from shaft current signals, and (3) the validation of the framework on real-world fault data. This work enables the early detection of brush degradation, thereby reducing unplanned downtime and maintenance costs in power generation facilities. Full article

Harmonics are a common phenomenon widely present in power systems. The presence of harmonics not only increases the energy consumption of equipment but also poses hidden risks to the safety and stealth performance of large ships. Thus, there is an urgent need for a detection method for the harmonic characteristics of time series. We propose a novel harmonic feature estimation method, termed Harmonic Aggregation Entropy (HaAgEn), which effectively discriminates against background noise. The method is based on bispectrum analysis; utilizing the distribution characteristics of harmonic signals in the bispectrum matrix, a new Diagonal Bi-directional Integral Bispectrum (DBIB) method is employed to effectively extract harmonic features within the bispectrum matrix. This approach addresses the issues associated with traditional time–frequency analysis methods, such as the large computational burden and lack of specificity in feature extraction. The integration results, $I_x$ and $I_y$, of DBIB on different frequency axes are calculated using cross-entropy to derive HaAgEn. It is verified that HaAgEn is significantly more sensitive to harmonic components in the signal compared to other types of entropy, thereby better addressing harmonic detection issues and reducing feature redundancy. The detection accuracy of harmonic components in the shaft-rate electromagnetic field signal, as evidenced by sea trial data, reaches 96.8%, which is significantly higher than that of other detection methods. This provides a novel technical approach for addressing the issue of harmonic detection in industrial applications. Full article

To address the challenge of detecting low-frequency electric field signals from vessels in complex marine environments, a vessel shaft frequency electric field feature extraction method based on intrinsic mode function energy arrangement entropy values is proposed, building upon a scaled model. This study initially establishes a measurement system for shaft frequency electric fields, utilizing a titanium-based oxide electrode to construct an equivalent dipole source simulating the shaft frequency electric field signals of different types of vessels. Subsequently, a comparative analysis of the time-domain and frequency-domain characteristics of signals after modal decomposition is conducted. A feature extraction method is then proposed that combines the maximum average energy of intrinsic mode functions with arrangement entropy values to achieve discrimination of target signals. Finally, the feasibility of the proposed method is validated through sea trials. The results indicate that the method can successfully screen different types of typical vessels and address the target screening failure caused by slight differences in the characteristic parameters of the shaft frequency electric field signal. The entropy difference has been improved from 0.05 to about 0.2, and the difference rate of the shaft frequency electric field signal has been improved by 75%. This has effectively reduced the false alarm rate of target detection. Full article

Active magnetic bearings (AMBs) are a class of electromechanical equipment that effectively integrate Magnetic Bearing technology with PMSM technology, particularly for applications involving high-power and high-speed permanent magnet motors. However, as the rotor operates in a suspended state, the motor’s trajectory changes continuously. The installation of a speed sensor poses a risk of collisions with the shaft, which inevitably leads to rotor damage due to imbalance, shaft wear, or other mechanical effects. Consequently, for the rotor control system of PMSM, it is crucial to adopt a sensorless speed estimation method to achieve high-performance speed and position closed-loop control. This study uses the rotor system of a 75 kW AMB high-speed motor as a case study to provide a detailed analysis of the principles of high-frequency square wave signal injection (HFSWSII) and current signal injection for speed estimation. The high-frequency current response signal is derived, and a speed observer is designed based on signal extraction and processing methods. Subsequently, a speed estimation model for PMSM is constructed based on HFSWSII, and the issue of “filter bandwidth limitations and lagging effects in signal processing” within the observer is analyzed. A scheme based on the high-frequency pulse array current injection method is then proposed to enhance the observer’s performance. Finally, to assess the system’s anti-interference capability as well as the motor’s static and dynamic tracking performance, its dynamic behavior is tested under conditions of increasing and decreasing speed and load. Simulation and experimental results demonstrate that the PMSM control system based on HFSWSII achieves accurate speed estimation and shows excellent static and dynamic performance. Full article

Misalignment faults in drive systems occur when the motor and load are not properly aligned, leading to deviations in the centerlines of the coupled shafts. These faults can cause significant damage to bearings, shafts, and couplings, making early detection essential. Traditional diagnostic techniques rely on vibration monitoring, which provides insights into both mechanical and electromagnetic fault signatures. However, its main drawback is the need for external sensors, which may not be feasible in certain applications. Alternatively, motor current signature analysis (MCSA) has proven effective in detecting faults without requiring additional sensors. This study investigates misalignment faults in synchronous reluctance motors (SynRMs) by analyzing both vibration and current signals under different load conditions and operating speeds. Fast Fourier transform (FFT) is applied to extract characteristic frequency components linked to misalignment. Experimental results reveal that the amplitudes of rotational frequency harmonics ($1x{f}_r$, $2x{f}_r$, and $3x{f}_r$) increase in the presence of misalignment, with $1x{f}_r$ exhibiting the most stable progression. Additionally, acceleration-based vibration analysis proves to be a more reliable diagnostic tool compared to velocity measurements. These findings highlight the potential of combining current and vibration analysis to enhance misalignment detection in SynRMs, improving predictive maintenance strategies in industrial applications. Full article

Due to the complex operating environment of combine harvesters, uneven terrain, multiple vibration sources, and complex transmission systems, failures easily occur in critical working components, especially the bolted connections of the vibrating screen. To address these issues, this study first established a bolt-tightening mechanical model. Secondly, a finite element simulation of the preload force was performed using Ansys Workbench software (2023R2). The simulation results showed that the bolt head area exhibits a ring-shaped strain distribution. To determine the critical state of bolt loosening, a single-bolt loosening test was conducted. The experimental results indicated that when the bolt pressure decreased to 78.4 N and the torque decreased to 0.5 N·m, bolt loosening intensified, and the pressure value showed a sharp decreasing trend. These pressure and torque values can be defined as the bolt loosening threshold, providing an important reference basis for subsequent monitoring and early warning. Finally, to more realistically simulate actual working conditions, a combine harvester field vibration test was conducted. By arranging triaxial acceleration sensors on the bolted connections of the vibrating screen, acceleration signals were collected under both low-speed and high-speed field operating conditions. Time–frequency analysis was performed on the signals to extract characteristic values for each measurement point. The field vibration test results showed that the characteristic values of the transmission shaft bolt structure of the vibrating screen were at a relatively high level, indicating that this part is subjected to a large vibration load. Furthermore, frequency domain feature analysis revealed that the vibration frequency components in this area are complex, which further increases the risk of bolt loosening. This study provides an in-depth analysis of the loosening characteristics and vibration characteristics of the vibrating screen’s bolted connections in combine harvesters. The results provide an important theoretical basis and technical support for the online monitoring of failures in the vibrating screen’s bolt structure. Full article

Rotating machines are vital for ensuring reliability, safety, and operational availability across various industrial sectors. Among the faults that can affect these machines, shaft misalignment is particularly critical due to its impact on other components connected to the shaft, making it a key focus for diagnostic systems. Misalignment can lead to significant energy losses, and therefore, early detection is crucial. Vibration analysis is an effective method for identifying misalignment at an early stage, enabling corrective actions before it negatively impacts equipment efficiency and energy consumption. To improve monitoring efficiency, it is essential that the diagnostic system is not only intelligent but also capable of operating in real-time. This study proposes a methodology for diagnosing shaft misalignment faults by combining wavelet transform for feature extraction and transfer learning for fault classification. The accuracy of the proposed soft real-time solution is validated through a comparison with other time-frequency transformation techniques and transfer learning networks. The methodology also includes an experimental procedure for simulating misalignment faults using a laser measurement tool. Additionally, the study evaluates the thermal impacts and vibration signature of each type of misalignment fault through multi-sensor monitoring, highlighting the effectiveness and robustness of the approach. First, wavelet transform is used to obtain a good representation of the signal in the time-frequency domain. This step allows for the extraction of key features from multi-sensor vibration signals. Then, the transfer learning network processes these features through its different layers to identify the faults and their severity. This combination provides an intelligent decision-support tool for diagnosing misalignment faults, enabling early detection and real-time monitoring. The proposed methodology is tested on two datasets: the first is a public dataset, while the second was created in the laboratory to simulate shaft misalignment using a laser alignment tool and to demonstrate the effect of this defect on other components through thermal imaging. The evaluation is carried out using various criteria to demonstrate the effectiveness of the methodology. The results highlight the potential of implementing the proposed soft real-time solution for diagnosing shaft misalignment faults. Full article

Fluid–structure interaction introduces critical failure modes due to varying stiffness and changing contact states in rotor-stator systems. This is further aggravated by stress fluctuations due to shaft impact with a fixed stator when the shaft rotates. In this paper, the investigation of imbalance and rotor-stator contact on a rotating shaft was carried out in viscous fluid. The shaft was modelled as a vertical elastic rotor system based on a vertically oriented elastic rotor operating in an incompressible medium. Implicit representation of the rotating system including the rotor-stator contact and the hydrodynamic resistance was formulated for the coupled system using the energy principle and the Navier–Stokes equations. Additionally, the monolithic approach included an implicit strategy of the rotor-stator fluid interaction interface conditions in the solution methodology. Advanced time-frequency methods, such as Hilbert transform, continuous wavelet transform, and estimated instantaneous frequency maps, were applied to extract the vibration features of the dynamic response of the faulted rotor. Time-varying stiffness due to friction is thought to be the main reason for the frequency fluctuation, as indicated by historical records of the vibration displacement, whirling orbit patterns of the centre shaft, and the amplitude–frequency curve. It has also been demonstrated that the augmented mass associated with the rotor and stator decreases the natural frequencies, while the amplitude signal remains relatively constant. This behaviour indicates a quasi-steady-state oscillatory condition, which minimises the energy fluctuations caused by viscous effects. Full article

This study presents an efficient vibration-based fault detection method for rotating machines utilising the poly-coherent composite spectrum (pCCS) and machine learning techniques. pCCS combines vibration measurements from multiple bearing locations into a single spectrum, retaining amplitude and phase information while reducing background noise. The use of pCCS significantly reduces the number of extracted parameters in the frequency domain compared to using individual spectra at each measurement location. This reduction in parameters is crucial, especially for large industrial rotating machines, as processing and analysing extensive datasets demand significant computational resources, increasing the time and cost of fault detection. An artificial neural network (ANN)-based machine learning model is then employed for fault detection using these reduced extracted parameters. The methodology is developed and validated on an experimental rotating machine at three different speeds: below the first critical speed, between the first and second critical speeds, and above the second critical speed. This range of speeds represents the diverse dynamic conditions commonly encountered in industrial settings. This study examines both healthy machine conditions and various simulated fault conditions, including misalignment, rotor-to-stator rub, shaft cracks, and bearing faults. By combining the pCCS technique with machine learning, this study enhances the reliability, efficiency, and practical applicability of fault detection in rotating machines under varying dynamic conditions and different machine conditions. Full article

Centrifugal pumps are important equipment in industrial production, and their safe and reliable operation is of great significance to water supply and industrial safety. During the use of centrifugal pumps, faults such as bearing damage, blade wear, shaft imbalance, shaft misalignment and water hammer often occur. Among them, although water hammer faults occur at a low frequency, they are difficult to monitor and pose significant risks to valve and pipeline interfaces. This article analyzes the causes, mechanisms and phenomena of water hammer faults in centrifugal pumps, designs a monitoring method to effectively monitor the vibration signal of the centrifugal pumps, extracts vibration characteristics to determine and record water hammer events, designs monitoring and diagnostic models for the edge layer and server side, and establishes an experimental verification testing system. The test results show that, under the conditions of simulating water hammer faults, after high-pass filtering of the collected vibration data, the kurtosis index, pulse index and margin index all exceed twice the threshold, and both sensors emit water hammer alarms. The designed data acquisition method can capture water hammer signals in a timely manner, and the analysis model can automatically identify water hammer faults based on existing fault knowledge and rules. This fully demonstrates the scientific and effective nature of the proposed centrifugal pump fault monitoring method and system, which is of great significance for ensuring the safe operation and improving the design of centrifugal pumps. Full article

Effective real-time health condition monitoring of the roller table and through shaft bearings in the annealing kiln roller system of glass production lines is crucial for maintaining their operational safety and stability for the quality and production efficiency of glass products. However, the collected vibration signal of the roller bearing system is affected by the low rotating frequency and strong mechanical background noise, which shows the width impact interval and non-stationary multi-component characteristics. Moreover, the distribution characteristics of monitoring data and probability of fault occurrence of the roller bearing and through shaft bearing improve the difficulty of the fault diagnosis and condition monitoring of the annealing kiln roller system, as well as the reliance on professional experience and prior knowledge. Therefore, this paper proposes a variable-scale attention mechanism guided time-frequency feature fusion transfer learning method for a bearing fault diagnosis at different installation positions in an annealing kiln roller system. Firstly, the instinct time decomposition method and the Gini–Kurtosis composed index are used to decompose and reconstruct the signal for noise reduction, wavelet transform with the Morlet basic function is used to extract the time-frequency features, and histogram equalization is introduced to reform the time-frequency map for the blur and implicit time-frequency features. Secondly, a variable-scale attention mechanism guided time-frequency feature fusion framework is established to extract multiscale time-dependency features from the time-frequency representation for the distinguished fault diagnosis of roller table bearings. Then, for through shaft bearings, the vibration signal of the roller table bearing is used as the source domain and the signal of the through shaft bearing is used as the target domain, based on the feature fusion framework and the multi-kernel maximum mean differences metric function, and the transfer diagnosis method is proposed to reduce the distribution differences and extract the across-domain invariant feature to diagnose the through shaft bearing fault speed under different working conditions, using a small sample. Finally, the effectiveness of the proposed method is verified based on the vibration signal from the experimental platform and the roller bearing system of the glass production line. Results show that the proposed method can effectively diagnose roller table and through shaft bearings’ fault information in the annealing kiln roller system. Full article

The presence of complex electromagnetic noise in the ocean significantly impacts the accuracy of ship shaft-rate electric field signal detection, necessitating the development of an effective denoising method to enhance detection precision. Nevertheless, traditional denoising methods encounter issues like low frequency resolution, challenging threshold configuration, and mode mixing. This study introduces a method that integrates variational mode decomposition (VMD) with multi-window spectral subtraction (MSS). The intrinsic mode functions (IMFs) of noisy signals are extracted using VMD, and the noise components within different IMFs are identified. The spectral features of both signal and noise within different IMFs are leveraged to eliminate noise signals via MSS. Subsequently, the denoised components of IMFs are rearranged to derive the denoised ship shaft-rate electric field signals, achieving noise reduction across various frequency bands. Following validation using simulation signals and empirical data, the noise reduction efficacy of VMD-MSS surpasses that of alternative methods, demonstrating robust performance even at low signal-to-noise ratios. The marine electromagnetic noise is effectively suppressed in the empirical data, while preserving the characteristics of ship’s shaft-rate signals, thereby validating the method’s efficacy and demonstrating its practical engineering value. Full article

Data-based equipment fault detection and diagnosis is an important research area in the smart factory era, which began with the Fourth Industrial Revolution. Steel manufacturing is a typical processing industry, and efficient equipment operation can improve product quality and cost. Steel production systems require precise control of the equipment, which is a complex process. A gearbox transmits power between shafts and is an essential piece of mechanical equipment. A gearbox malfunction can cause serious problems not only in production, quality, and delivery but in safety. Many researchers are developing methods for monitoring gearbox condition and for diagnosing failures in order to resolve problems. In most data-driven methods, the analysis data set is derived from a distribution of identical data with failure mode labels. Industrial sites, however, often collect data without information on the failure type or failure status due to varying operating conditions and periodic repair. Therefore, the data sets not only include frequent false alarms, but they cannot explain the causes of the alarms. In this paper, a framework called the Reduced Lagrange Method (R-LM) periodically assigns pseudolabels to vibration signals collected without labels and creates an input data set. In order to monitor the status of equipment and to diagnose failures, the input data set is fed into a supervised learning classifier. To verify the proposed method, we build a test rig using motors and gearboxes that are used on production sites in order to artificially simulate defects in the gears and to operate them to collect vibration data. Data features are extracted from the frequency domain and time domain, and pseudolabeling is applied. There were fewer false alarms when applying R-LM, and it was possible to explain which features were responsible for equipment status changes, which improved field applicability. It was possible to detect changes in equipment conditions before a catastrophic failure, thus providing meaningful alarm and warning information, as well as further promising research topics. Full article

Accurate shaft speed extraction is crucial for synchronous sampling in the fault diagnosis of wind turbines. However, traditional narrow-bandpass filtering techniques face limitations when dealing with large fluctuations in rotational speed, hindering the accurate construction of an instantaneous phase for synchronous resampling of a shaft. To overcome this, we propose a tachometer-less synchronous sampling based on Scaling-Basis Chirplet Transform, tailored to a wind turbine’s structure and operating conditions. The algorithm generates a time–frequency representation of the vibration response, revealing time-varying characteristics even under large speed fluctuations. Using maximum tracking on the time–frequency spectrum, we extract instantaneous speed and compare its accuracy with tachometer-acquired results. The instantaneous phase is obtained through numerical integration, and vibration data are resampled synchronously using inverse function interpolation in the digital domain. Numerical simulations and practical cases of wind turbines demonstrate the effectiveness and the engineering applicability of our methodology. Full article
