This article addresses the challenges of the reduced efficiency in phase-shifted full-bridge series resonant converters (PSFB-SRCs) used within micro-inverters (MIs), especially under light load and high input voltage conditions. To enhance performance, first-order and second-order time-domain equivalent models that accurately predict the output gain across a wide range of operating conditions are developed. A novel control strategy is proposed, featuring turn-on time as a feedback variable, with phase shift angle and dead time as feedforward variables, enabling precise computation of frequency, duty cycle, and phase shift time for digital controllers. This ensures optimal efficiency, stability, and dynamic response, regardless of the load conditions. Experimental results from the prototype confirmed zero-voltage switching under heavy loads and efficient frequency limiting under light loads, achieving a peak efficiency of 97.8% at a 25 V input. Notably, the light load efficiency remained above 90% even at a 50 V input. These contributions significantly advance PSFB-SRC technology, providing robust solutions for high-efficiency MI applications in photovoltaic systems. Full article

This paper proposes a steady-state analysis of the asymmetrical pulse-width-modulated series resonant converter, commonly employed under light load conditions for effective voltage regulation. The proposed method achieves precise and explicit converter waveforms by applying the Laplace-based theorem to the converter’s ordinary differential equation with periodic and discontinuous inputs, without relying on approximations. By numerically determining the intermediate variables that define converter waveforms, the analysis provides accurate steady-state results based on system parameters. Furthermore, it derives an analytical solution to identify the load conditions suitable for asymmetrical pulse-width modulation operation, as well as the boundary load conditions for discontinuous conduction mode within this mode. The mathematical expressions derived for the converter waveforms and operational modes are validated through simulations using a switching model in PSIM software, as well as through experimental results. Full article

Nowadays, power converters with reduced cost, compact size and high efficiency are evolving to overcome the emergent challenges of renewable energy integrations. In this context, there is an increased demand for well-designed power converters in renewable energy applications to reduce energy utilization and handle a variety of loads. This paper proposes a center-tapped bridge cascaded series-resonant LC dual active bridge (DAB) converter for DC-DC conversion. The low part count of the proposed converter enables a high-power density design with reduced cost. The proposed converter offers reduced conduction losses as the reverse current is eliminated by adopting current blocking characteristics. Reverse current blocking also enables zero voltage switching (ZVS) and zero current switching (ZCS) over a wide operating range. Therefore, using a simple fixed frequency modulation (FFM) scheme offers a wide operating range compared to a conventional DAB converter. A thorough comparison of the proposed converter and a conventional DAB converter is provided based on conduction losses and switching losses to illustrate the performance improvement. Lastly, the effectiveness of the proposed converter is validated through simulation and experimental results. Full article

Recently, three-phase series-resonant converters (SRCs) have been proposed for high power applications. Three-phase SRCs can achieve zero-voltage-switching (ZVS) of the primary power switches and regulate the output voltage by pulse-frequency modulation. The interleaving technique is also a conventional method for DC-DC converters to achieve a high power level, reducing the output voltage ripples due to operating out of phase at the same frequency between the two converters. However, an interleaved three-phase SRC cannot easily synchronize switching instants between the two modules due to the component tolerances of circuits. In the proposed control method, phase shift modulation (PSM) is used to solve the output current imbalance caused by component tolerances. The power switches of the converter can also maintain synchronizing switching instants between the two modules. Therefore, the lower output voltage ripple can be achieved. A detailed analysis and design of this new control method for interleaved three-phase SRCs are described. Finally, prototype converters with a 2.4 kW total output were built and successfully tested to verify the feasibility of the current sharing modulation. Full article

This paper proposes a galvanically isolated dc-dc converter that can regulate the input voltage in a wide range. It is based on the series resonance dc-dc converter (SRC) topology and a novel boost rectifier. The proposed topology has a smaller number of semiconductors than its SRC-based existing topologies employing an ac-switch in the boost rectifier. The proposed dc-dc converter comprises only two diodes and one switch at the output side, while the existing solutions use two switches and two diodes to step up the voltage. The proposed converter boosts the input voltage within a single boosting interval in the positive half-cycle of the switching period. In addition, the resonant current in the negative half-cycle is sinusoidal, which could enhance the converter efficiency. The resonant capacitor voltage is clamped at the level of the output voltage. Therefore, the voltage stress of the capacitor could significantly reduce at various input voltage and power levels. This makes it perfect for distributed generation applications such as photovoltaics with wide variations of input voltage and power. The converter operates at the fixed switching frequency close to the resonance frequency to obtain the maximum efficiency at the nominal input voltage. The zero-voltage switching (ZVS) feature is achieved in the primary semiconductors, while the diodes in the output-side rectifier turn off at nearly zero current switching. The mathematical model and design guidelines of the proposed converter are discussed in the paper. The experimental results confirmed the theoretical analysis based on a 300 W prototype. The maximum efficiency of the converter was 96.8% at the nominal input voltage, and the converter has achieved a wider input voltage regulation range than that with the boosting cell comprising an ac-switch. Full article

The paper is focused on galvanically isolated series resonant DC–DC converters (SRCs) with a low quality factor of the resonant tank. These converters provide input voltage regulation at fixed switching frequency and good power density. Different modulation methods at the fixed switching frequency enable the implementation of the voltage buck functionality in these converters. The SRC under study is considered as a step-up front-end DC–DC converter for the integration of renewable energy sources in DC microgrids. The paper evaluates the voltage buck performance of the SRC achieved by using different pulse-width modulation (PWM) methods including conventional PWM and shifted PWM. Moreover, the new PWM methods, i.e., the hybrid shifted PWM (HSPWM), improved shifted PWM (ISPWM), and hybrid PWM (HPWM), are proposed to overcome the disadvantages of the existing methods. They improve the power conversion efficiency in the buck mode by reducing the power losses in the semiconductor switches and the isolating transformer of the SRC. The proposed and the existing methods are benchmarked in terms of the components stresses and power conversion efficiency. The presented findings have been experimentally validated by the help of a 200 W prototype, which demonstrated the lowest power loss in the case of the HPWM. Full article

This paper presents a tightly regulated multi-output isolated converter that employs only an independently regulated synchronous Single-Switched Post-Regulator (SSPR). The proposed converter is a highly accurate single-ended secondary side post-regulator based on a Series Resonant Converter (SRC); furthermore, it has a voltage-doubler characteristic. The proposed post-regulator requires only one auxiliary switch, in contrast with a bulky and expensive non-isolated DC–DC converter. Moreover, the added voltage-doubler can tightly regulate the slave output current. In addition, the voltage-doubler can improve electromagnetic interference characteristics and reduce switching losses arising from the Zero Current Switching (ZCS) operation of all power switches. The validity of the proposed converter is verified using experimental results obtained via a prototype converter applicable to an LED 3D TV power supply. Full article

The series resonant DC-DC converter (SRC) can regulate the input voltage in a wide range at a fixed switching frequency. In this work, the bridgeless rectifier, which is utilized intensively in the applications of the power factor correction, has been integrated into the SRC as a voltage step-up cell at the output-side of the SRC. It is shown that the conventional overlapping pulse-width modulation (PWM) of the two metal oxide semiconductor field-effect transistors MOSFETs in this rectification cell limits the input voltage regulation range of the converter due to excessive power losses in abnormal operating conditions. The abnormal operating conditions occur when the instantaneous voltage across the resonant capacitor is larger than the secondary voltage of the isolation transformer. This happens at high values of the DC voltage gain, i.e., low input voltages and high currents, which causes the resonant current to flow in the reverse direction in the same half-cycle through a parasitic path formed by overlapping PWM of the rectifier MOSFETs. The abnormal operation results in additional conduction loss in the converter as the MOSFETs of the bridgeless boost rectifier turn on at high current at the beginning of each half of the switching period. Accordingly, the overall efficiency of the converter significantly deteriorates. This paper proposes the hybrid PWM aiming to improve the efficiency of the SRC with a bridgeless boost rectifier in a wide input voltage regulation range. The converter swaps between the overlapping and the proposed short-pulse PWM schemes to drive the MOSFETs in the bridgeless boost rectifier. The transition between the two PWM schemes is defined according to the boundary condition that relies upon the operating point of the converter power and the input voltage. The proposed hybrid PWM scheme is analyzed and compared to the overlapping PWM at different levels of the input voltage and the load power. A 300 W prototype was studied in the laboratory to show the feasibility of the proposed hybrid PWM scheme with the closed-loop control system to switch between the two PWM schemes. Full article

This paper proposes a high gain DC–DC converter based on the series resonant converter (SRC) for photovoltaic (PV) applications. This study considers low power applications, where the resonant inductance is usually relatively small to reduce the cost of the converter realization, which results in low-quality factor values. On the other hand, these SRCs can be controlled at a fixed switching frequency. The proposed topology utilizes a bidirectional switch (AC switch) to regulate the input voltage in a wide range. This study shows that the existing topology with a bidirectional switch has a limited input voltage regulation range. To avoid this issue, the resonant tank is rearranged in the proposed converter to the resonance capacitor before the bidirectional switch. By this rearrangement, the dependence of the DC voltage gain on the duty cycle is changed, so the proposed converter requires a smaller duty cycle than that of the existing counterpart at the same gain. Theoretical analysis shows that the input voltage regulation range is extended to the region of high DC voltage gain values at the maximum input current. Contrary to the existing counterpart, the proposed converter can be realized with a wide range of the resonant inductance values without compromising the input voltage regulation range. Nevertheless, the proposed converter maintains advantages of the SRC, such as zero voltage switching (ZVS) turn-on of the primary-side semiconductor switches. In addition, the output-side diodes are turned off at zero current. The proposed converter is analyzed and compared with the existing counterpart theoretically and experimentally. A 300 W experimental prototype is used to validate the theoretical analysis of the proposed converter. The peak efficiency of the converter is 96.5%. Full article

This paper presents a new self-tuning loop for a bidirectional dual-active bridge (DAB) series resonant converter (SRC). For different loading conditions, the two active bridges can be controlled with a minimum time displacement between them to assure zero voltage switching (ZVS) and minimum circulation current conditions. The tuning loop can instantly reverse the power direction with a fast dynamics. Moreover, the tuning loop is not sensitive to series resonant tank tolerances and deviations, which makes it a robust solution for power tuning of the SRCs. For simplicity, the power is controlled based on the power-frequency control method with a fixed time displacement between the active bridges. The main design criteria of the bidirectional SRC are the time displacement, operating frequency bandwidth, and the minimum and maximum power, which are simply derived and formulated based on the self-tuning loop’s parameters. Based on the parameters of the tuning loop, a simplified power equation and power control method is proposed for DAB-SRCs. The proposed control method is simulated in static and dynamic conditions for different loadings. The analysis and simulation results show the effectiveness of the new tuning method. Full article

Typical domestic induction cooktops can only heat ferromagnetic pots/vessels. However, to increase the availability and marketability of induction heating (IH) cooktop products, heating techniques for all types of metallic pots (i.e., created from metals such as aluminum, copper, and stainless steel) are required. To satisfy the requirements of induction cooktops, this paper proposes the design of an all-metal domestic IH system that can heat any type of metallic pot while considering the temperature variation of the working-coil. A control algorithm using a power curve-fitting method (CFM) is presented to quickly respond to load parameter variations in the IH. In addition, the CFM control algorithm is established to compensate for the power reference value by reflecting the increase in the working-coil temperature during the heating of the non-ferromagnetic pot. To evaluate the performance of the proposed system, the control algorithm strategy and experimental results based on a 3.2 kW all-metal IH cooktop are presented. Full article

This paper proposes the use of a control algorithm that can yield soft switching both at turn-on and turn-off of the inverter of series resonance converter (SRC) gas metal arc welding (GMAW) machines. The technique takes advantage of the band-pass filter characteristics of the SRC and controls the power by using switching frequencies that are subharmonics of the resonance frequency. The design and the experimental results for a 5 kW prototype system are given to prove that the algorithm can be used in GMAW systems. Full article
