Search Results (43)

Resonators are passive components that respond to an excitation signal by oscillating at their natural frequency with an exponentially decreasing amplitude. When combined with antennas, resonators enable purely passive chipless sensors that can be read wirelessly. In this contribution, we investigate the properties of dielectric resonators, which combine the following functionalities: They store the readout signal for a sufficiently long time and couple to free space electromagnetic waves to act as antennas. Their mode spectrum, along with their resonant frequencies, quality factor, and coupling to electromagnetic waves, is investigated using a commercial finite element program. The fundamental mode exhibits a too-low overall Q factor. However, some higher modes feature overall Q factors of several thousand, which allows them to act as transponders operating without integrated circuits, batteries, or antennas. To experimentally verify the simulations, isolated dielectric resonators exhibiting modes with similarly high radiation-induced and dissipative quality factors were placed on a low-loss, low permittivity ceramic holder, allowing their far-field radiation properties to be measured. The radiation patterns investigated in the laboratory and outdoors agree well with the simulations. The resulting radiation patterns show a directivity of approximately 7.5 dBi at 2.5 GHz. The sensor was then heated in a ceramic furnace with the readout antenna located outside at room temperature. Wireless temperature measurements up to 700 °C with a resolution of 0.5 °C from a distance of 1 m demonstrated the performance of dielectric resonators for practical applications. Full article

With improvements in medical environments and the widespread use of smartphones, interest in wearable biosensors for continuous body monitoring is growing. We developed a wearable multiplexed bio-sensing system that non-invasively monitors body fluids and integrates with a smartphone application. The system includes sensors, readout circuits, and a microcontroller unit (MCU) for signal processing and wireless communication. Potentiometric and amperometric measurement methods were used, with calibration capabilities added to ensure accurate readings of analyte concentrations and temperature. Laser-induced graphene (LIG)-based sensors for glucose, lactate, Na⁺, K⁺, and temperature were developed for fast, cost-effective production. The LIG electrode’s 3D porous structure provided an active surface area 16 times larger than its apparent area, resulting in enhanced sensor performance. The glucose and lactate sensors exhibited high sensitivity (168.15 and 872.08 μAmM⁻¹cm⁻², respectively) and low detection limits (0.191 and 0.167 μM, respectively). The Na⁺ and K⁺ sensors demonstrated sensitivities of 65.26 and 62.19 mVdec⁻¹, respectively, in a concentration range of 0.01–100 mM. Temperature sensors showed an average rate of resistance change per °C of 0.25%/°C, within a temperature range of 20–40 °C, providing accurate body temperature monitoring. Full article

This document provides a design description of a data acquisition device that allows an alert to be issued to suggest to the driver to take a break after having subjected his body to a certain amount of acceleration and pressure changes after driving on a road with too many curves. The tests were carried out using sensors based on microelectromechanical systems. The system was strategically installed at specific points on the body of the driver and car. Several electronic arrays were carried out, like the design of a printed circuit board. The establishment of an inter-integrated circuit communication and its multiplexing to work with several devices with the same address simultaneously. Finally, in this context, the document also presents the critical velocity for each curve in the Hakone roadway, which was obtained by using a mathematical model and contrasted with data acquisition values for acceleration. The risk of skidding on a curve increases when the driver does not reduce driving velocity; only a slight variance in acceleration or environmental conditions is enough. The value of acceleration was acquired for the analysis of each curve; there is a greater possibility of skidding in curves 2 and 4 because their radius is smaller and the critical speed is approximately 60 km/h, which is very close to the driving speed. On the other hand, the deceleration value of −0.65 G read on the head accelerometer can increase fatigue symptoms such as blurry vision or dizziness. Full article

This research demonstrates a method for the repeatable passive fiber optic coupling of single-mode waveguides with a micron-scale accuracy for high-precision disposables. The aim is to broaden the application of photonic integrated circuits (PICs) from traditional fiber optic communication systems to include medical, life science, and environmental sensing applications. The proposed passive coupling system enables the straightforward and reliable interchange of disposable photonic chips without manual read-out unit adjustments. Robustness is attributed to the chip-side grating couplers with 3 dB coupling tolerances exceeding ± 25 µm and a mechanical three-groove kinematic method ensuring precise alignment. The system simplicity is highlighted by the simple manual insertion and fixation of silicon nitride (Si₃N₄) PICs on a carrier using magnetic force and passive alignment features. Testing on a batch of 99 identical yet independent units revealed a standard deviation (SD) of 5.1 dB in coupling loss, without realignment post-calibration. This eliminates the need for active alignment processes, showing its potential for enabling field use. A usability assessment with five untrained operators confirms the suitability for various end-users, with consistent performance in engaging and disengaging disposable PICs. The research significantly advances the integration of photonic sensor technology into practical applications, particularly for chemical and biological fluid analysis in point-of-care settings. Full article

This paper investigates optimizing the power exchange between electric vehicles (EVs) and the grid, with a specific focus on the DC-DC converters utilized in vehicle-to-grid (V2G) systems. It specifically explores using model predictive control (MPC) in synchronous boost converters to enhance efficiency and performance. Through experiments and simulations, this paper shows that replacing diodes with SIC MOSFETs in boost converters significantly improves efficiency, particularly in synchronous mode, by minimizing the deadtime of SIC MOSFETs during switching. Additionally, this study evaluates MPC’s effectiveness in controlling boost converters, highlighting its advantages over traditional control methods. Real-world validations further validate the robustness and applicability of MPC in V2G systems. This study utilizes TMS320F28379D, one of Texas Instruments’ leading digital signal processors, enabling the implementation of MPC with a high PWM frequency of up to 200 MHz. This processor features dual 32-bit CPUs and a 16-bit ADC, allowing for high-resolution readings from sensors. Leveraging digital signal processing technologies and advanced electronic circuits, this study advances the development of high-performance boost converters, achieving power outputs of up to 48 watts and output voltages of 24 volts. Electronic circuits (PCB boards) have been devised, implemented, and evaluated to showcase their significance in advancing efficient V2G integration. Full article

Magnetic Scanning Microscopy (MSM) emerged with the aim of allowing the visualization of magnetic fields of a sample or material through scanning and proved particularly useful for geology, biomedicine, characterization of magnetic materials, and in the steel industry. In this regard, the reading system of an MSM was modified using a μ-metal magnetic shielding structure to analyze remanent fields. The MSM was adapted to perform readings using two different types of sensors. The sensitive area of the sensors was evaluated, and the HQ-0811 (AKM—Asahi KaseiTM Microdevices) and STJ-010 (Micro MagneticsTM) sensors were chosen, with the HQ-0811 standardized on Printed Circuit Boards (PCBs) to facilitate handling and increase the system’s robustness. In the shielded chamber, two piezoelectric ANC-150 stepper motors (Attocube Systems) were used, arranged planarly, to allow the movement of the analyzed samples under the mounted sensors. To acquire data from the sensors, the Precision Current Source Model 6220 and the Nanovoltmeter Model 2182A (both from Keithley) were used, along with Keithley’s Delta-Mode integrated system. To analyze the system’s effectiveness, three distinct samples were analyzed for calibration, and a MATLAB program was written to analyze the images and extract the material’s magnetization. Additionally, a rock sample from the Parnaíba Basin was mapped to demonstrate the system’s capabilities. Full article

The quartz tuning fork used as an acoustic sensor in quartz-enhanced photo-acoustic spectroscopy gas detection systems is usually read out by means of a transimpedance preamplifier based on a low-noise operational amplifier closed in a feedback loop. The gain–bandwidth product of the operational amplifier used in the circuit is a key parameter which must be properly chosen to guarantee that the circuit works as expected. Here, we demonstrate that if the value of this parameter is not sufficiently large, the response of the preamplifier exhibits a peak at a frequency which does not coincide with the series resonant frequency of the quartz tuning fork. If this peak frequency is selected for modulating the laser bias current and is also used as the reference frequency of the lock-in amplifier, a penalty results in terms of signal-to-noise ratio at the output of the QEPAS sensor. This worsens the performance of the gas sensing system in terms of ultimate detection limits. We show that this happens when the front-end preamplifier of the quartz tuning fork is based on some amplifier models that are typically used for such application, both when the integration time of the lock-in amplifier filter is long, to boost noise rejection, and when it is short, in order to comply with a relevant measurement rate. Full article

Structural fiber-reinforced polymer (FRP) composite materials consisting of a polymer matrix reinforced with layers of high-strength fibers are used in numerous applications, including but not limited to spacecraft, vehicles, buildings, and bridges. Researchers in the past few decades have suggested the necessary integration of sensors (e.g., fiber optic sensors) in polymer composites to enable health monitoring of composites’ performance over their service lives. This work introduces an innovative cognizant composite that can self-sense, compute, and implement decisions based on sensed values. It is a critical step towards smart, resilient infrastructure. We describe a method to fabricate textile sensors with flexible circuitry and a microcontroller within the polymer composite, enabling computational operations to take place in the composite without impacting its integrity. A microstructural investigation of the sensors showed that the amount of oxidative agent and soaking time of the fabric play a major role in the adsorption of polypyrrole (PPy) on fiberglass (FG). XPS results showed that the 10 g ferric chloride solution with 6 h of soaking time had the highest degree of protonation (28%) and, therefore, higher adsorption of PPy on FG. A strain range of 30% was achieved by examining different circuitry and sensor designs for their resistance and strain resolution under mechanical loading. A microcontroller was added to the circuit and then embedded within a composite material. This composite system was tested under flexural loading to demonstrate its self-sensing, computing, and actuation capabilities. The resulting cognizant composite demonstrated the ability to read resistance values and measure strain using the embedded microcontroller and autonomously actuate an LED light when the strain exceeds a predefined limit of 2000 µε. The application of the proposed FRP system would provide in situ monitoring of structural composite components with autonomous response capabilities, as well as reduce manufacturing, production, and maintenance costs. Full article

Bridge sensors are widely used in military and civilian fields, and their demand gradually increases each year. Digital sensors are widely used in the military and civilian fields. High-precision and low-power analog-to-digital converters (ADCs) as sensor read-out circuits are a research hotspot. Sigma-delta ADC circuits based on switched-capacitor topology have the advantages of high signal-to-noise ratio (SNR), good linearity, and better compatibility with CMOS processes. In this work, a fourth-order feed-forward sigma-delta modulator and a digital decimation filter are designed and implemented with a correlated double sampling technique (CDS) to suppress pre-integrator low-frequency noise. This work used an active pre-compensator circuit for deep phase compensation to improve the system’s stability in the sigma-delta modulator. The modulator’s local feedback factor is designed to be adjustable off-chip to eliminate the effect of process errors. A three-stage cascade structure was chosen for the post-stage digital filter, significantly reducing the number of operations and the required memory cells in the digital circuit. Finally, the layout design and engineering circuit were fabricated by a standard 0.35 μm CMOS process from Shanghai Hua Hong with a chip area of 9 mm². At a 5 V voltage supply and sampling frequency of 6.144 MHz, the modulator power consumption is 13 mW, the maximum input signal amplitude is −3 dBFs, the 1 Hz dynamic range is about 118 dB, the modulator signal-to-noise ratio can reach 110.5 dB when the signal bandwidth is 24 kHz, the practical bit is about 18.05 bits, and the harmonic distortion is about −113 dB, which meets the design requirements. The output bit stream is 24 bits. Full article

One of the threats to nanometric CMOS analog circuit reliability is circuit performance degradation due to transistor aging. To extend circuit operating life, the bias of the main devices within the circuit must be adjusted while the aging degradation process affects them by using a monitor circuit that tracks the evolution of the circuit performance. In this paper, we propose the use of DC temperature measurements in the proximity of the circuit to perform the monitoring of circuit performance degradation and as an observable variable to adjust the bias of the main devices to restore the degraded performance to the original values. To this end, we present experimental results obtained from nine samples of a standard CMOS integrated circuit containing a high-frequency class-A power amplifier and a differential temperature sensor. After accelerated aging, the gain of the amplifier is degraded up to 50%. We propose two different procedures to perform DC temperature measurements that allow tracking of the amplifier gain degradation due to aging and, by uniquely observing temperature readings, automatically set a new bias for the amplifier devices that restores the original amplifier gain. Whereas one of the procedures is able to restore the gain up to a certain limit, the second allows full gain restoration. Full article

This article reviews the recent advances in the field of batteryless near-field communication (NFC) sensors for chemical sensing and biosensing. The commercial availability of low-cost commercial NFC integrated circuits (ICs) and their massive integration in smartphones, used as readers and cloud interfaces, have aroused great interest in new batteryless NFC sensors. The fact that coil antennas are not importantly affected by the body compared with other wireless sensors based on far-field communications makes this technology suitable for future wearable point-of-care testing (PoCT) devices. This review first compares energy harvesting based on NFC to other energy-harvesting technologies. Next, some practical recommendations for designing and tuning NFC-based tags are described. Power transfer is key because in most cases, the energy harvested has to be stable for several seconds and not contaminated by undesired signals. For this reason, the effect of the dimensions of the coils and the conductivity on the wireless power transfer is thoroughly discussed. In the last part of the review, the state of the art in NFC-based chemical and biosensors is presented. NFC-based tags (or sensor tags) are mainly based on commercial or custom NFC ICs, which are used to harvest the energy from the RF field generated by the smartphone to power the electronics. Low-consumption colorimeters and potentiostats can be integrated into these NFC tags, opening the door to the integration of chemical sensors and biosensors, which can be harvested and read from a smartphone. The smartphone is also used to upload the acquired information to the cloud to facilitate the internet of medical things (IoMT) paradigm. Finally, several chipless sensors recently proposed in the literature as a low-cost alternative for chemical applications are discussed. Full article

Wireless sensor tags in flexible formats have numerous applications; some are commercially available for specific target applications. However, most of these wireless sensor tags have been used for single-sensing applications. In this study, we designed a printed circuit board (PCB) module (13 mm × 13 mm) for near-field communication-enabled sensor tags with both electrical resistance and capacitance read-out channels that enables dual-channel sensing. As part of the wireless sensor tag, a square antenna pattern was printed directly on a flexible poly(ethylene terephthalate) (PET) substrate and integrated into the PCB module to demonstrate a dual-channel temperature and ethylene gas sensor. The temperature and ethylene sensors were printed using a positive temperature coefficient ink and a tin oxide (SnO₂) nanoparticle ink, respectively. With dual sensing capabilities, this type of sensor tag can be used in smart packaging for the quality monitoring of fresh produce (e.g., bananas) by tracking temperature and ethylene concentration in the storage/transport environment. Full article

A three-phase GaN-based motor inverter IC with three integrated phase current mirror sensors (sense-FETs or sense-HEMTs, 1200:1 ratio), a temperature sensor, and an amplifier is presented and experimentally operated. The three low-side currents are read out by virtual grounding transimpedance amplifiers. A modified summed DC current readout circuit using only one amplifier is also discussed. During continuous 24 V motor operation with space-vector pulse width modulation (SVPWM), the sensor signal is measured and a bidirectional measurement capability is verified. The measured risetime of the sensor signal is 51 ns, indicating around 7 MHz bandwidth (without intentional optimization for high bandwidth). The IC is operated up to 32 V on DC-biased semi-floating substrate to limit negative static back-gating of the high-side transistors to around −7% of the DC-link voltage. Analysis of the capacitive coupling from the three switch-nodes to the substrate is calculated for SVPWM based on capacitance measurement, resulting in four discrete semi-floating substrate voltage levels, which is experimentally verified. Integrated advanced power converter topologies with sensors improve the power density of power electronics applications, such as for low-voltage motor drive. Full article

The solution processibility of colloidal quantum dots (CQDs) promises a straightforward integration with Si readout integrated circuits (Si-ROCIs), which enables a near-infrared (NIR) CMOS image sensor (CIS; CMOS stands for complementary metal-oxide semiconductor). Previously demonstrated CQD NIR CISs were achieved through integrating CQD photodiode or PhotoFET with Si-ROCIs. Here, we conduct a simulation study to investigate the feasibility of a NIR CIS enabled by another integration strategy, that is, by forming a CQD-Si heterojunction. Simulation results clearly show that each active pixel made of CQD-Si heterojunction photodiode on the CIS sensitively responds to NIR light, and generated photocarriers induce changes in electrostatic potentials in the active pixel. The potential changes are read out through the integrated circuits as validated by the readout timing sequence simulation. Full article

A lateral overflow integration capacitor (LOFIC) complementary metal oxide semiconductor (CMOS) image sensor can realize high-dynamic-range (HDR) imaging with combination of a low-conversion-gain (LCG) signal for large maximum signal electrons and a high-conversion-gain (HCG) signal for electron-referred noise floor. However, LOFIC-CMOS image sensor requires a two-channel read-out chain for LCG and HCG signals whose polarities are inverted. In order to provide an area-efficient LOFIC-CMOS image sensor, a one-channel read-out chain that can process both HCG and LCG signals is presented in this paper. An up/down double-sampling circuit composed of an inverting amplifier for HCG signals and a non-inverting attenuator for LCG signals can reduce the area of the read-out chain by half compared to the conventional two-channel read-out chain. A test chip is fabricated in a 0.18 $\mathsf{\mu }$m CMOS process with a metal–insulator–metal (MIM) capacitor, achieving a readout noise of 130 $\mathsf{\mu }$${\mathrm{V}}_{\mathrm{rms}}$ for the HCG signal and 1.19 V for the LCG input window. The performance is equivalent to 103 dB of the dynamic range with our previous LOFIC pixel in which HCG and LCG conversion gains are, respectively, 160 $\mathsf{\mu }{\mathrm{V}/\mathrm{e}}^{-}$ and 10 $\mathsf{\mu }{\mathrm{V}/\mathrm{e}}^{-}$. Full article
