The growing demand for low-emission maritime transport and efficient onboard energy management has intensified research into advanced control strategies for hybrid shipboard microgrids. These systems integrate both AC and DC power domains, incorporating renewable energy sources and battery storage to enhance fuel efficiency, reduce greenhouse gas emissions, and support operational flexibility. However, integrating renewable energy into shipboard microgrids introduces challenges, such as power fluctuations, varying line impedances, and disturbances caused by AC/DC load transitions, harmonics, and mismatches in demand and supply. These issues impact system stability and the seamless coordination of multiple distributed generators. To address these challenges, we proposed a hierarchical control strategy that supports sustainable operation by improving the voltage and frequency regulation under dynamic conditions, as demonstrated through both MATLAB/Simulink simulations and real-time hardware validation. Simulation results show that the proposed controller reduces the frequency deviation by up to 25.5% and power variation improved by 20.1% compared with conventional PI-based secondary control during load transition scenarios. Hardware implementation on the NVIDIA Jetson Nano confirms real-time feasibility, maintaining power and frequency tracking errors below 5% under dynamic loading. A comparative analysis of the classical PI and sliding mode control-based designs is conducted under various grid conditions, such as cold ironing mode of the shipboard microgrid, and load variations, considering both the AC and DC loads. The system stability and control law formulation are verified through simulations in MATLAB/SIMULINK and practical implementation. The experimental results demonstrate that the proposed secondary control architecture enhances the system robustness and ensures sustainable operation, making it a viable solution for modern shipboard microgrids transitioning towards green energy. Full article

The increasing penetration of renewable energy sources (RESs) has significantly altered the operational characteristics of modern power systems, resulting in reduced system inertia and fault current capacity. These developments introduce new challenges for maintaining frequency and voltage stability, particularly in low-inertia grids that are dominated by inverter-based resources (IBRs). This paper presents a hierarchical control framework that integrates synchronous condensers (SCs) and grid-forming (GFM) inverters through a leader–follower consensus control architecture to address these issues. In this approach, selected GFMs act as leaders to restore nominal voltage and frequency, while follower GFMs and SCs collaboratively share active and reactive power. The primary control employs droop-based regulation, and a distributed secondary layer enables proportional power sharing via peer-to-peer communication. A modified IEEE 14-bus test system is implemented in PSCAD to validate the proposed strategy under scenarios including load disturbances, reactive demand variations, and plug-and-play operations. Compared to conventional droop-based control, the proposed framework reduces frequency nadir by up to 0.3 Hz and voltage deviation by 1.1%, achieving optimised sharing indices. Results demonstrate that consensus-based coordination enhances dynamic stability and power-sharing fairness and supports the flexible integration of heterogeneous assets without requiring centralised control. Full article

To fully utilize the reactive power resources of distributed photovoltaic (PV) systems, this study proposes a coordinated var-voltage control strategy for the main distribution network, incorporating the reactive power regulation capability of distributed PV. Firstly, the Automatic Voltage Control (AVC) tertiary and secondary voltage control methods and optimization models in the main and distribution networks area are analyzed, and the physical equivalence of the reactive power compensation equipment involved is carried out. In this study, a coordinated local var-voltage control method is proposed, which integrates AVC primary voltage control and divides the control scheme into feeder and station areas, respectively. Through the analysis of actual operation cases in a regional power grid, the results demonstrate a reduction in network loss by 171.14 kW through voltage adjustment, validating the effectiveness of the proposed strategy. This method fully leverages the reactive power regulation capability of distributed renewable energy sources, reduces the operational frequency of reactive power equipment in substations, and synergizes with the AVC system to achieve optimal power grid operation. Full article

This paper proposes a half-bridge parallel dual LLC resonant converter with wide output voltage range. The proposed converter uses a conventional parallel double half-bridge LLC resonant converter. On the primary side of the converter, only one of the two half bridges is used to control the two resonant loops. Due to the resonance of the converter, the active switches can achieve ZVS (zero-voltage switching), and the rectifier diode can also achieve ZCS (zero-current switching), and thus the switching loss is reduced. The current stress can be reduced and power can be distributed on both of the primary side and/or the secondary side. A voltage regulation circuit is designed on the secondary side to achieve the function of wide output voltage. The operation and analysis of the proposed converter are described in detail. The experiments were carried out on a circuit prototype, which is a converter with DC input voltage of 384 V and output voltage of 24–40 V and operating at a switching frequency of 107 kHz. The feasibility and performance of the proposed converter were verified by simulation and experimental results. Full article

This article proposes a bidirectional half-bridge resonant converter based on partial power regulation. The converter adopts an LLC converter as a DC-DC transformer (LLC-DCX) in the main power circuit and works in the open loop at the resonant frequency to give full play to the performance advantages of the LLC resonant converter. The partial power regulation circuit incorporates a synchronous Buck converter, enabling forward and backward power transmission by controlling the power flow direction. The converter achieves soft switching in both forward and backward directions, thereby reducing switching losses and enhancing conversion efficiency. Compared with the LLC-DCX converter, this converter can achieve wide voltage gain regulation while having high efficiency, which makes it suitable for charge–discharge applications between energy storage systems and DC Buses. In order to verify the performance of the proposed converter, a 1 kW prototype was constructed, maintaining a constant primary voltage of 400 V and a secondary voltage range of 350 V to 450 V. Experimental results indicate that the prototype achieves peak efficiencies of 97.74% in forward operation and 96.92% in backward operation, thoroughly demonstrating the feasibility and effectiveness of the proposed converter. Full article

With the increasing proportion of renewable energy in power grids, the inertia level and frequency regulation capability of modern power systems have declined. In response, this paper proposes a coordinated frequency regulation strategy integrating power generation, energy storage, and DC transmission for offshore wind power MMC-HVDC transmission systems, aimed at improving the frequency stability of onshore power grids. First, considering the inability of the receiving-end MMC-HVDC converter station under constant DC voltage control to directly respond to AC system frequency variations, a frequency regulation method is developed based on constant DC voltage control. The approach employs DC voltage as a transmission signal to coordinate the responses of wind turbines and energy storage systems. Subsequently, based on the energy storage configuration of the onshore renewable energy aggregation station, a secondary frequency regulation strategy is proposed. This strategy integrates offshore wind power, MMC-HVDC transmission system, and energy storage systems, balancing AC frequency regulation and the recovery of the state of charge (SOC) of the energy storage system. Finally, the proposed method is tested on a modified IEEE 39-bus system, the results demonstrate that the minimum frequency value can be in-creased by 37.5%, the system frequency can be restored to the initial state after secondary FM, and the results demonstrate its effectiveness. Full article

The gradual replacement of conventional generators with variable renewable energy sources (RES) will reduce their online frequency regulation (FR) resources and degrade their overall frequency control capabilities. Although various inertia emulation methods exist, shaping load consumption is considered a more effective strategy during emergency conditions than under-frequency load shedding. Managing loads following frequency excursions can support grid stability owing to rapid power response. In this context, a Smart Transformer (ST)-based FR framework for a RES-penetrated power system is studied in this paper. The ST, with its distinctive features, effectively shapes the load profile through online load sensitivity identification-based control, aiding in the stabilization of grid frequency. This paper also proposes a tilt integral second-order double derivative (TIDD²) controller for a secondary loop whose parameters are optimized using the Learner Performance-based Behavior (LPB) algorithm. A thorough investigation reveals that the response from ST controlling the voltage-dependent load in the presence of TIDD² controllers can greatly enhance system performance by damping oscillations and peak deviations. In addition, the performance of Proportional–Integral–Derivative and TIDD² considering ST in the primary loop is compared to delineate the robustness of the LPB-based TIDD² controller. It is found that the proposed control scheme offers greater controllability and flexibility, enhancing the system’s dynamic performance. Full article

This work presents an islanded microgrid energy system that uses backstepping control applied to neutral point clamped (NPC) multilevel converters coupled with batteries to behave as virtual generators, able to absorb surplus renewable energy, therefore increasing the penetration of renewable energy sources. Additionally, on a charged battery the virtual generator allows turning-off the backup diesel generator set (GenSet). Aside from improving energy efficiency, the battery-connected multilevel converter aims to regulate frequency, improves power quality, and keeps the microgrid operational in the event of a GenSet failure. The backstepping controlled NPC multilevel converter emulates a virtual generator injecting power to perform as the primary and secondary microgrid frequency controller. Additionally, AC voltage control is implemented, which enables running the islanded microgrid only with multilevel converters, supplied by the battery while integrating solar and wind energy sources. Energy demand and renewable energy forecasts are used to manage the battery state-of-charge. Simulation results, obtained from switched and phasor models show that energy storage and the backstepping frequency control enables the compensation of power fluctuations from renewable energy sources. Furthermore, in the event of the main GenSet failure, the controlled virtual generator keeps the microgrid running for a few minutes, until another GenSet is ready to supply the microgrid. Therefore, the microgrid integration of the battery-connected multilevel converter results in a significant boost in energy efficiency by allowing the disconnection of the backup GenSet. Full article

Effective communication networks are crucial for ensuring reliable and stable operation and control in smart microgrids (MGs). This paper proposes a comprehensive analysis of the interdependence between power and communication networks in the real-time control of a standalone AC microgrid to address this vital need. Thus, the role of communication network design is emphasized in facilitating an effective centralized secondary control to regulate the voltage and frequency of an MG. Consequently, voltage and frequency deviations from the droop-based primary control should be eliminated. This study employs a real-time co-simulation testbed setup that integrates OPAL-RT and network simulator (ns-3), supporting a rigorous evaluation of the interplay between the communication networks and control within the MG. Experiments have been conducted to demonstrate the effectiveness of the designed communication infrastructure in seamlessly enabling real-time data exchange among the primary and secondary control layers. Testing scenarios have been implemented, encompassing low-traffic patterns with minimal load variations and high traffic characterized by more frequent and severe load changes. The experimental results highlight the significant impact of traffic variations on communication network performance. Despite the increase in traffic, the effectiveness and reliability of the designed communication network have been validated, underscoring the vital role of communication in ensuring the resilient and stable operation of cyber–physical standalone AC microgrids. Full article

In power systems, nonlinear loads cause harmonic distortion, adversely affecting sensitive equipment such as induction motors, power electronics, and variable-speed drives. This paper presents a novel control strategy that integrates with existing hierarchical control systems to mitigate voltage imbalances and harmonic disturbances in AC-islanded microgrids. The proposed method utilizes selective harmonic order filtering through multiple second-order generalized integrators (MSOGI) to extract negative, positive, and harmonic order components. The distributed generation (DG) unit control mechanism is designed to immediately correct voltage imbalances and harmonic disruptions, distributing the compensatory load evenly to rectify real and reactive power imbalances and harmonic disturbances. The microgrid’s control architecture primarily includes droop controllers for real and reactive power of positive sequences, voltage and current regulation inner control loops, an additional loop for correcting imbalances and harmonics, and secondary controllers to maintain voltage magnitude and frequency at nominal levels, ensuring high-quality voltage at the point of common coupling (PCC). The effectiveness of this approach is demonstrated through simulation results on the MATLAB/Simulink platform, proving its ability to effectively mitigate voltage imbalances and harmonic issues with the total harmonic of voltage reduced to approximately THDv = 0.5% and voltage unbalance factor (VUF) within approximately 0.1%. Full article

This paper investigates the secondary control problem of shipboard microgrids (SMGs) with a high percentage of new energy sources under general noise. Firstly, a polymorphic SMG model is constructed, which enables the software-defined functionality of the control strategy and allows heterogeneous distributed generators (DGs) in AC SMGs to exchange packets of different types. Secondly, due to the presence of highly dynamic and high-power loads in the SMGs, a containment-based distributed secondary control strategy is proposed to improve the flexibility of the DG voltage regulation. Then, considering the complexity and diversity of disturbances during ship navigation, general noise is introduced instead of white noise to describe various disturbances. Furthermore, based on the random differential equations (RDEs), the NOS stability of the proposed strategy is proved using Lyapunov theory, which proves the effectiveness of the containment-based distributed secondary control strategy under general noise. And, the containment error is obtained to prove that the voltage and frequency of the system converge to the convex hull spanned by the virtual leaders, ensuring the high quality of the power supply. Finally, the validity of the proposed containment-based strategy is verified by an AC SMG model with four DGs in three cases. Full article

In this research, an innovative electric vehicle (EV) charger is designed and presented for xEV charging stations. The key feature of our system is a scalable, interleaved inductor–inductor–capacitor (iL²C) DC-DC converter operation. The proposed system employs two parallel L²C converters with 8-GaN switches on the primary side and a shared rectifier circuit on the secondary side. This configuration not only amplifies the resonant tank internal currents and losses generated by the switches but also improves current sharing. A novel closed-loop technique is proposed with a constant-voltage method of operation, along with a hybrid control scheme of variable frequency + phase shift modulation (VFPSM). To examine the controller and converter’s performance, an experimental demonstration is conducted under varying load conditions, including full load, half load, and light load, where the source voltage and load voltage are maintained at constant levels of 400 V_in and 48 V₀, respectively. Furthermore, line regulation is conducted and verified to accommodate a broad input voltage range of 300 V_in–500 V_in and 500 V_in–300 V_in while maintaining an output voltage of 48 V₀ at 3.3 kW, 1.65 kW, and 0.33 kW with a peak efficiency of 98.2%. Full article

Hybrid Distribution Transformers (HDTs) offer a compelling alternative to traditional low-frequency transformers (LFTs), providing auxiliary services in addition to standard functionalities. By integrating LFTs with power converters, HDTs enhance the operational capabilities of the system. The specific configuration in which converters are connected to the transformer allows for the provision of multiple services. This can not only prevent network failures but also extend the lifespan of its components, an outcome that is highly desirable in a distribution grid. This article discusses an HDT developed to mitigate voltage fluctuations in the grid and to decrease the reactive power drawn from the secondary side of traditional LFTs. A finite-control-set model predictive control (FCS-MPC), in conjunction with linear controllers, is utilized for the effective management of the HDT converters. Two separate control loops are established to regulate voltage and reactive power on the secondary side of the transformer. Results from Hardware-in-the-Loop (HIL) testing affirm the proficiency of HDT in reducing grid voltage variations by 15% and in cutting reactive power consumption by up to 94%. The adopted control strategy and topology are demonstrated to be effective in stabilizing voltage and reactive power fluctuations while concurrently facilitating the charging of the converters’ DC link directly from the grid. Full article

Frequency tracking and amplitude control are essential for piezoelectric transducers. Frequency tracking ensures the piezoelectric transducer operates at the resonant frequency for maximum power output, and amplitude control regulates the mechanical motion of the output. This paper presents a novel driver based on a push–pull inverter for piezoelectric transducers. The proposed driver realizes the frequency tracking and amplitude control scheme by a voltage sensing bridge in the case of transformer secondary matching, guaranteeing automatic frequency tracking and precise mechanical functions regardless of environmental and load variations. The proposed scheme is verified by the ultrasonic scalpel and the ultrasonic motor (USM). The experimental results show that this scheme reduces the build-up time from 10 ms to 3 ms and loaded frequency variations from 250 Hz to 200 Hz. In addition, the amplitude control performance was further observed on USM for various loads. The overshoot is less than 5.4% under different load torques. Therefore, the proposed scheme improves the load adaptability and stability of piezoelectric transducers and promotes the application of piezoelectric transducers under various conditions. Full article

This study introduces novel stochastic distributed cooperative control (SDCC) in the context of island microgrids (MGs). A proportional resonant (PR) controller and virtual impedance droop control in stationary reference frames are employed in cooperation with distributed averaging secondary control optimized by the dragonfly algorithm (DA). The suggested approach demonstrates the capability to achieve mean-square synchronization for the voltage and frequency restoration of distributed generators (DGs) to ensure efficient active power sharing. Therefore, a sparse communication network has been used to avoid data congestion and reduce the need for extensive communication and information exchange. The proposed system offers an instinctive compromise between voltage regulation and reactive power sharing. A conventional centralized secondary control with PR droop control is simulated for performance evaluation and comparison purposes. In this study, empirical evidence is demonstrated to support the MG’s ability to confront communication failure and its ability to work reliably during plug-and-play operations. Full article
