Search Results (19)

The New Space movement led to an exponential increase in the number of the smallest satellites in orbit in the last two decades. The number of required communication channels increased with that as well and revealed the limitations of classical radio frequency channels. Free-space optical communication overcomes these challenges and has been successfully demonstrated, with operational systems in orbit on large and small satellites. The next step is to miniaturize the technology of laser communication to make it usable on CubeSats. Thus, the German Aerospace Center (DLR) developed, together with Tesat-Spacecom GmbH & Co. KG in Backnang, Germany, a highly miniaturized and power-efficient laser terminal, which is based on a potential customer’s use case. OSIRIS4CubeSat uses a new patented design that combines electronics and optomechanics into a single system architecture to achieve a high compactness following the CubeSat standard. Interfaces and software protocols that follow established standards allowed for an easy transition to the industry for a commercial mass market. The successful demonstration of OSIRIS4CubeSat during the PIXL-1 mission proved its capabilities and the advantages of free-space optical communication in the final environment. This paper gives an overview of the system architecture and the development of the single subsystems. The system’s capabilities are verified by the already published in-orbit demonstration results. Full article

Future manned and deep space missions require an Electrical Power System (EPS) that can deliver high power while overcoming challenges like weight and volume constraints and the harsh space environment. A variety of DC-DC converters are employed to supply, store, and transmit power to various satellite subsystems. This paper identifies the design specifications of DC-DC converters for a range of satellite applications and offers a state-of-the-art review of non-isolated, isolated, and integrated topologies. Foreseeing the future of electric propulsion, various sources for electric propulsion are compared, and converters for electric propulsion are studied. The topologies are compared regarding practical parameters like reliability, modularity, redundancy, efficiency, and power density. Furthermore, an application-wise comparison of the topologies and the type of satellite they are suitable for is provided. Finally, the research gaps pertaining to various space applications, such as the design of DC-DC converters, electric propulsion, deep space exploration, electronic component selection, and space-based power satellites, are presented. Full article

CubeSats have emerged as a promising alternative to satellite missions for studying remote areas where satellite data are scarce and insufficient, such as coastal and marine environments. However, their standard size and weight limitations make integrating remote sensing optical instruments challenging. This work presents the development of Bentayga-I, a CubeSat designed to validate PANDORA, a self-made, lightweight, cost-effective multispectral camera with interchangeable spectral optical filters, in near-space conditions. Its four selected spectral bands are relevant for ocean studies. Alongside the camera, Bentayga-I integrates a power system for short-time operation capacity; a thermal subsystem to maintain battery function; environmental sensors to monitor the CubeSat’s internal and external conditions; and a communication subsystem to transmit acquired data to a ground station. The first helium balloon launch with B2Space proved that Bentayga-I electronics worked correctly in near-space environments. During this launch, the spectral capabilities of PANDORA alongside the spectrum were validated using a hyperspectral camera. Its scientific applicability was also tested by capturing images of coastal areas. A second launch is planned to further validate the multispectral camera in a real-world scenario. The integration of Bentayga-I and PANDORA presents promising results for future low-cost CubeSats missions. Full article

In a worldwide scenario which sees an increasing number of small satellite launches, novel mission concepts may be unlocked providing the spacecrafts with the very precise and rapid maneuvering capability that electric thrusters cannot guarantee. In this context, chemical thrusters appear to be a possible solution. This work aimed to experimentally study and solve the problem of ignition for 10 N hybrid rockets based on hydrogen peroxide. Firstly, the study analyzed the performance of a monopropellant engine capable of functioning as a hybrid injection system. In particular, the effects of the liquid mass injected, the initial temperature, and the supply pressure on the pulsed engine performance were experimentally investigated. The injected mass showed a greater impact on the performance with respect to the starting chamber temperature and injection pressure. This thruster also showed a good potential for space applications. In the second part of the work, the objective was to find an ignition procedure that reduced propellant consumption and eliminated the need for a glow plug. This is important because the electrical power consumption in real applications significantly affects other subsystems and is undesirable for chemical engines. Different ignition procedures were tested to emphasize their respective advantages and disadvantages, and the findings indicated that the concept of pulsed preheating is feasible with only a small amount of propellant consumption, while substantially decreasing the ignition duration from approximately 45 min to a maximum of just 3 min. Finally, similar ignition procedures were adopted using different fuels. The results showed that PVC and ABS, under the same operating conditions, ignite more easily than HDPE, which requires an oxidizer consumption approximately double that of the other two fuels. Considerations about the effect of chamber pressure and oxidizer mass flow rate on engine ignition were also included. Full article

This paper presents the design of a digital twin for a 6U CubeSat electrical power system, including the solar arrays, solar array regulators, battery, power distribution unit, and load subsystems. The digital twin is validated by comparing its real-time outputs with those of the physical system. Experimental tests confirm its feasibility, showing that the digital twin’s real-time outputs closely match those of the physical system. Additionally, the digital twin can be used for control-hardware-in-the-loop and power-hardware-in-the-loop tests, allowing the real-time integration of simulated subsystems with hardware. This capability facilitates testing of new subsystems and optimization during the project’s development phases. Additionally, to demonstrate the advanced capabilities of this model, the digital twin is used to simulate the CubeSat electrical power system behavior in real time throughout a complete orbital cycle in low Earth orbit conditions. This simulation provides valuable insights into the CubeSat operation by capturing the transient and steady-state responses of the EPS components under real orbital conditions. The results obtained indicate that the digital twin significantly enhances the testing and optimization process of new subsystems during the development phases of the project. Moreover, the capabilities of the digital twin can be further augmented by incorporating real-time telemetry data from the CubeSat, resulting in a highly accurate replication of the satellite’s in-orbit behavior. This approach is crucial for identifying and diagnosing failures or malfunctions in the electrical power system, ensuring the robust and reliable operation of the CubeSat. Full article

The goal of this research is to define a lunar-orbiting system that provides power to the lunar surface through wireless power transmission. To meet the power demand of a lunar base, a constellation of satellites placed in stable orbits is used. Each satellite of this constellation consists of solar arrays and batteries that supply a power transmission system. This system is composed of a laser that transmits power to receivers on the lunar surface. The receivers are photonic power converters, photovoltaic cells optimized for the laser’s monochromatic light. The outputs of this work will cover the architecture of the system by studying different orbits, specifically analyzing some subsystems such as the laser, the battery pack and the receiver placed on the lunar ground. The study is conducted considering two different energy demands and thus two different receivers location: first, at the strategic location of the Artemis missions’ landing site, the Shackleton Crater near the lunar south pole; second, on the lunar equator, in anticipation of future and new explorations. The goal is to evaluate the possible configurations to satisfy the power required for a lunar base, estimated at approximately 100 kW. To do this, several cases were analyzed: three different orbits, one polar, one frozen and one equatorial (Earth–Moon distant retrograde orbit) with different numbers of satellites and different angles of the receiver’s cone of transmission. The main objective of this paper is to perform a comprehensive feasibility study of the aforementioned system, with specific emphasis placed on selected subsystems. While thermal control, laser targeting, and attitude control subsystems are briefly introduced and discussed, further investigation is required to delve deeper into these areas and gain a more comprehensive understanding of their implementation and performance within the system. Full article

In dual-band RF front-end systems, to transmit different frequency signals in different paths, each path requires the power to be divided along two transmission channels. In such systems, a circuit is created in which the input ports of power dividers with different frequency bands are connected to the output ports of a diplexing circuit in a cascade form. These circuits often contain different band filters in their schemes and have a complicated design. In this paper, an innovative technique for designing a diplexing power divider for Ku-band applications is presented. The proposed structure is designed on multilayer printed circuit boards (PCBs) and the utilization of a transition based on an extended SMA connector. The extended SMA connector provides two separate paths for the transmission of the RF signals. Hence, the proposed structure eliminates the need for intricate and bulky bandpass filters, allowing seamless integration with other planar devices and components within Ku-band satellite subsystems. In fact, the proposed architecture channelizes the divided output electromagnetic signals into two separate frequency spectrums. With the presented technique, two frequency ranges are envisaged, covering Ku-band applications at 13–15.8 GHz and 16.6–18.2 GHz. With the proposed structure, an insertion loss as low as 1.5 dB was achieved. A prototype of the proposed power-divider diplexing device was fabricated and measured. It exhibits a good performance in terms of return loss, isolation, and insertion losses. Full article

Space technology for small satellites has made significant progress in the academic and industrial fields, and an alternative focused on educational institutions is the CubeSat standard, created to promote various scientific projects of space exploration. In this context, a fundamental module of any satellite is the telemetry subsystem, which controls the communication with the Earth through electronic circuits dedicated to remote communication; also, the measurement and power supply modules are integrated into a CubeSat. Its construction costs range from USD 2500 to 55,000, with suppliers from Europe and the United States. This motivates the development of the present project, aimed at an academic–experimental CubeSat-1U prototype, to limit this technological dependence, focusing on the measurement generated by the acceleration sensors, angular velocity, magnetic fields, barometric pressure, temperature and ultraviolet light intensity, and the energization of each of them. For this, the main objective of the research is to identify the four basic subsystems of the CubeSat-1U: (a) energization subsystem, (b) sensing subsystem, (c) transmission and reception subsystem, and (d) control subsystem. To describe in detail the construction of (a) and (b), a set of diagrams is performed, defining their operation and its interaction. To explain the subsystem’s construction, the components selection and integration are presented. As a result, the electrical measurements generated by the power system, the output of the sensors in laboratory conditions, and images of the developed circuits are presented, having as a contribution to the methodology of design, integration, and development of the four subsystems, the feasibility of construction and its implementation in an academic satellite. Full article

With the continuous development of satellite payload and system-on-chip (SoC) technology, spaceborne real-time synthetic aperture radar (SAR) imaging systems play a crucial role in various defense and civilian domains, including Earth remote sensing, military reconnaissance, disaster mitigation, and resource exploration. However, designing high-performance and high-reliability SAR imaging systems that operate in harsh environmental conditions while adhering to strict size, weight, and power consumption constraints remains a significant challenge. In this paper, we introduce a spaceborne SAR imaging chip based on a SoC architecture with system fault-tolerant technology. The fault-tolerant SAR SoC architecture has a CPU, interface subsystem, memory subsystem, data transit subsystem, and data processing subsystem. The data processing subsystem, which includes fast Fourier transform (FFT) modules, coordinated rotation digital computer (CORDIC) modules (for phase factor calculation), and complex multiplication modules, is the most critical component and can achieve various modes of SAR imaging. Through analyzing the computational requirements of various modes of SAR, we found that FFT accounted for over 50% of the total computational workload in SAR imaging processing, while the CORDIC modules for phase factor generation accounted for around 30%. Therefore, ensuring the fault tolerance of these two modules is crucial. To address this issue, we propose a word-length optimization redundancy (WLOR) method to make the fixed-point pipelined FFT processors in FFT modules fault tolerant. Additionally, we propose a fault-tolerant pipeline CORDIC architecture utilizing error correction code (ECC) and sum of squares (SOS) check. For other parts of the SoC architecture, we propose a generic partial triple modular redundancy (TMR) hardening method based on the HITS algorithm to improve fault tolerance. Finally, we developed a fully automated FPGA-based fault injection platform to test the design’s effectiveness by injecting errors at arbitrary locations. The simulation results demonstrate that the proposed methods significantly improved the chip’s fault tolerance, making the SAR imaging chip safer and more reliable. We also implemented a prototype measurement system with a chip-included board and demonstrated the proposed design’s performance on the Chinese Gaofen-3 strip-map continuous imaging system. The chip requires 9.2 s, 50.6 s, and 7.4 s for a strip-map with 16,384 × 16,384 granularity, multi-channel strip-map with 65,536 × 8192 granularity, and multi-channel scan mode with 32,768 × 4096 granularity, respectively, and the system hardware consumes 6.9 W of power to process the SAR raw data. Full article

Electric propulsion is of great significance to the development of high-efficiency and long-life satellites, and digital twins have gradually become a powerful tool for satellite engineering. Being affected by uncertainty factors such as the complexity and variability of the space environment and the satellite system, the digital twin model cannot accurately reflect the real physical properties. Therefore, it is crucial to update the satellite model to improve prediction accuracy. However, the complex structure and multi-physics process coupling of vector electric-propulsion satellites bring great challenges to model updating. According to the characteristics of the vector electric-propulsion satellite, this paper establishes mathematical models of the whole satellite. Additionally, a hierarchical model updating method is proposed and applied to the model updating case of a satellite with multiple subsystems. The simulation results show that the method is suitable for the model updating of the vector electric-propulsion satellite. Through multiple iterations of closed-loop cycles, the residual errors between the simulation values and the telemetry values can be decreased, and the errors between the estimated values and the true values of state variables can also be decreased by an order of magnitude. Full article

The goal of this paper is to demonstrate the capability of the 1U CubeSat to study the radiation spectra on LEO. The research was realized by the Lucky-7 mission with the primary goal of testing electronics such as a power supply, piNAV L1 GPS receiver, UHF communication system, and other subsystems in the natural space environment, and the secondary goal of testing the possibility of using 1U CubSat class satellites for scientific tasks. The satellite is equipped with a piNAV GPS receiver and piDOSE radiation detector, silicon diode radiation spectrometer, camera, and other sensors. The on-board computer enables storage of 34 h of measurements of the radiation spectrum. These measurements can be downloaded by the UHF communication system during four satellite passes over the monitoring ground station. We successfully verified all necessary instruments and their cooperation and measurement procedure. The UHF communication was identified as the most critical subsystem because of its low capacity, which slowed down the satellite operation. We needed four zenith passes to upload 34 h of measurement. Full article

The satellite power subsystem is responsible for all power supply in a satellite, and is an important component of it. The system’s performance has a direct impact on the operations of other systems as well as the satellite’s lifespan. Sequence to sequence (seq2seq) learning has recently advanced, gaining even more power in evaluating complicated and large-scale data. The potential of the seq2seq model in detecting anomalies in the satellite power subsystem is investigated in this work. A seq2seq-based scheme is given, with a thorough comparison of different neural-network cell types and levels of data smoothness. Three specific approaches were created to evaluate the seq2seq model performance, taking into account the unsupervised learning mechanism. The findings reveal that a CNN-based seq2seq with attention model under suitable data-smoothing conditions has a better ability to detect anomalies in the satellite power subsystem. Full article

Given the pervasive use of satellite and over the horizon wireless communication technology in modern society, ionospheric disturbances that can disrupt such services are a crucial consideration. Ionospheric irregularities, plasma bubbles and other phenomena can have a great impact on satellite navigation and communications, impacting other systems reliant on such technologies. The Ionospheric Dynamics and Attitude Subsystem Satellite (IDEASSat) was a 3U developed by National Central University (NCU) to measure irregularities in the ionosphere, as well as to establish spacecraft engineering and operations capacity at NCU. The onboard Compact Ionospheric Probe (CIP) could measure high-resolution plasma parameters, which can be used for identifying ionospheric irregularities that can cause scintillation in satellite navigation and communications signals. Part of the spacecraft sub-systems were independently designed and developed by students, who were also responsible for integration, testing, and operations. IDEASSat was successfully launched into low Earth orbit on 24 January 2021, and then began mission operations. The spacecraft successfully demonstrated three-axis attitude stabilization and control, tracking, telemetry and command (TT&C), as well as flight software and ground systems that could support autonomous operation. The spacecraft experienced a critical anomaly 22 days after launch, followed by a 1.5-month communications blackout. The spacecraft briefly recovered from the blackout for long enough to replay flight data, which allowed for the cause of the blackout to be determined as an inability of the electrical power subsystem reset circuit to recover from an ionizing radiation induced single event latch-up. Although the mission was not completed, flight data obtained during the mission will help to improve the designs of future spacecraft in development at NCU. This paper will introduce IDEASSat’s final flight model design and implementation, integration, testing, environmental verification, and failure analysis, and will review the performance of the spacecraft during on-orbit operations. The results and experiences encountered in implementation and operations of the IDEASSat mission are presented here as a reference for other university small satellite teams. Full article

The capability to orient the solar arrays of a spacecraft toward the Sun is an ultimate asset for any attitude determination and control subsystem (ADCS). This ability should be maintained in any operative circumstance, either nominal or off-nominal, to avoid the loss of the entire space-borne system. The safe mode implementation should guarantee a positive power generation from the solar arrays, regardless of the health status of the satellite platform. This paper presents a solar array pointing algorithm, to be executed on-board, with a minimal set of sensors and actuators. In fact, the sensors are limited to the solar arrays, exploiting the current/voltage sensing capacity of the electrical power subsystem to measure the Sun angle with respect to the arrays normal, and to the angular rates sensors. The actuators are required to provide a torque only along two axes and, thus, a reduced actuation capacity is still manageable by the proposed algorithm. The paper describes the algorithm, both in the Sun direction determination and in the Sun pointing control capacity. The achieved performance is outlined, considering either an ideal system or a realistic one, being the latter affected by sensors and actuators limitations. The actuation by means of momentum exchange devices or magnetic torquers is discussed, with the purpose to prove the wide applicability range of the presented algorithm, which is capable to guarantee solar array orientation with a minimal hardware set. Full article

Current small satellite platforms such as CubeSats require robust and versatile communication subsystems that allow the reconfiguration of the critical operating parameters such as carrier frequency, transmission power, bandwidth, or filter roll-off factor. A reconfigurable Analog Back-End for the space segment of a satellite communication subsystem is presented in this work. This prototype is implemented on a 9.5 cm² 6-layer PCB, and it operates from 0.070 to 6 GHz and complies with CubeSat and IPC-2221 standards. The processing, control, and synchronizing stages are carried out on a Software-Defined Radio approach executed on a baseband processor. Results showed that the signal power at the output of the proposed Analog Back-End is suitable for feeding the following antenna subsystem. Furthermore, the emitted radiation levels by the transmission lines do not generate electromagnetic interference. Full article
