Search Results (27)

In response to the urgent demands of the Internet of Things for precise indoor target positioning and information interaction, this paper proposes a multi-band analog radio-over-fiber mobile fronthaul system. The objective is to obtain the target’s location in indoor environments while integrating remote beamforming capabilities to achieve wireless access to the targets. Vector signals centered at 3, 4, 5, and 6 GHz for indoor positioning and centered at 30 GHz for wireless access are generated centrally in the distributed unit (DU) and fiber-distributed to the active antenna unit (AAU) in the multi-band analog radio-over-fiber mobile fronthaul system. Target positioning is achieved by radiating electromagnetic waves indoors through four omnidirectional antennas in conjunction with a pre-trained neural network, while high-speed wireless communication is realized through a phased array antenna (PAA) comprising four antenna elements. Remote beamforming for the PAA is implemented through the integration of an optical true time delay pool in the multi-band analog radio-over-fiber mobile fronthaul system. This integration decouples the weight control of beamforming from the AAU, enabling centralized control of beam direction at the DU and thereby reducing the complexity and cost of the AAU. Simulation results show that the average accuracy of localization classification can reach 86.92%, and six discrete beam directions are achieved via the optical true time delay pool. In the optical transmission layer, when the received optical power is 10 dBm, the error vector magnitudes (EVMs) of vector signals in all frequency bands remain below 3%. In the wireless transmission layer, two beam directions were selected for verification. Once the beam is aligned with the target device at maximum gain and the received signal is properly processed, the EVM of millimeter-wave vector signals remains below 11%. Full article

Conceptually, this paper aims to help reduce the communication blind spots originating from the design of millimeter-wave (mmW) beamforming by deploying radio units of an open radio access network (O-RAN) with free-space optics (FSOs) as the backhaul and the fiber-optic link as the fronthaul. At frequencies exceeding 24 GHz, the transmission reach of 5G/6G beamforming is limited to a few hundred meters, and the periphery area of the sector operational range of beamforming introduces a communication blind spot. Using FSOs as the backhaul and a fiber-optic link as the fronthaul, O-RAN empowers the radio unit to extend over greater distances to supplement the communication range that mmW beamforming cannot adequately cover. Notably, O-RAN is a prime example of next-generation wireless networks renowned for their adaptability and open architecture to enhance the cost-effectiveness of this integration. A 200 meter-long FSO link for backhaul and a fiber-optic link of up to 10 km for fronthaul were erected, thereby enabling the reach of communication services from urban centers to suburban and remote rural areas. Furthermore, in the context of beamforming, reinforcement learning (RL) was employed to optimize the error vector magnitude (EVM) by dynamically adjusting the beamforming phase based on the communication user’s location. In summary, the integration of RL-based mmW beamforming with the proposed O-RAN communication setup is operational. It lends scalability and cost-effectiveness to current and future communication infrastructures in urban, peri-urban, and rural areas. Full article

Distributed radar networks have emerged as a key technology in remote sensing and surveillance due to their high transmission power and robustness against node failures. When performing coherent beamforming with multiple radars, frequency and phase deviations introduced by independent oscillators lead to a decrease in transmission power. This paper proposes an optimized diffuse Kalman filter (ODKF) for the frequency and phase synchronization. Specifically, each radar locally estimates its frequency and phase, then shares this information with neighboring nodes, which are used for incremental update and diffusion update to adjust local estimates. To further reduce synchronization errors, we incorporate a self-feedback strategy in the diffusion step, in which each node balances its own estimate with neighbor information by optimizing the diagonal weights in the diffusion matrix. Numerical simulations demonstrate the superior performance of the proposed method in terms of mean squared deviation (MSD) and convergence speed. Full article

Understanding the characteristics of underwater sound channels is essential for various remote sensing applications. Typically, the time-domain Green’s function or channel impulse response (CIR) is obtained using computationally intensive acoustic propagation models that rely on accurate environmental data, such as sound speed profiles and bathymetry. Ray-based blind deconvolution (RBD) offers a less computationally demanding alternative using plane-wave beamforming to estimate the Green’s function. However, the presence of noise can obscure low coherence ray arrivals, making accurate estimation challenging. This paper introduces a method using the waveguide invariant to improve the signal-to-noise ratio (SNR) of broadband Green’s functions for a moving source without prior knowledge of range. By utilizing RBD and the frequency shifts from the striation slope, we coherently combine individual Green’s functions at adjacent ranges, significantly improving the SNR. In this study, we demonstrated the proposed method via simulation and broadband noise data (200–900 Hz) collected from a moving ship in 100 m deep shallow water. Full article

A horizontal towed linear coherent hydrophone array is often employed to estimate the spatial intensity distribution of incident plane waves scattered from the geological and biological features in an ocean acoustic waveguide using conventional beamforming. However, due to the physical limitations of the array aperture, the spatial resolution after conventional beamforming is often limited by the fat main lobe and the high sidelobes. Here, we propose a method originated from computer vision deblurring based on deep learning to enhance the spatial resolution of beamformed images. The effect of image blurring after conventional beamforming can be considered a convolution of beam pattern, which acts as a point spread function (PSF), and the original spatial intensity distributions of incident plane waves. A modified U-Net-like network is trained on a simulated dataset. The instantaneous acoustic complex amplitude is assumed following circular complex Gaussian random (CCGR) statistics. Both synthetic data and experimental data collected from the South China Sea Experiment in 2021 are used to illustrate the effectiveness of this approach, showing a maximum 700% reduction in a 3 dB width over conventional beamforming. A lower normalized mean square error (NMSE) is provided compared with other deconvolution-based algorithms, such as the Richardson–Lucy algorithm and the approximate likelihood model-based deconvolution algorithm. The method is applicable in various acoustic imaging applications that employ linear coherent hydrophone arrays with one-dimensional conventional beamforming, such as ocean acoustic waveguide remote sensing (OAWRS). Full article

In this paper, a downlink energy efficiency maximization problem is investigated in an intelligent reflective surface (IRS)-assisted visible light communication system. In order to extend wireless communication coverage of the onshore base station, an IRS mounted on a unmanned aerial vehicle (UAV) is introduced to assist an onshore lighthouse with simultaneously providing remote ship users wireless communication services and illumination. Aiming to maximizing the energy efficiency of the proposed system, a resource allocation problem is formulated as the ratio of the achievable system sum rate to the total power consumption under the constraints of the user’s data requirement and transmit power budget. Due to the non-convexity of the proposed problem, the Dinkelbach method and mean-square error (MSE) method are adopted to turn the non-convex origin problem into two equivalent problems, namely transmit beamforming and reflected phase shifting. The Lagrangian method and semidefinite relaxation technique are used to obtain the closed-form solutions of these two subproblems. Accordingly, an alternative optimization-based resource allocation scheme is proposed to obtain the optimal system energy efficiency. The simulation results show that the proposed scheme performs better in terms of energy efficiency over benchmark schemes. Full article

Ocean Acoustic Waveguide Remote Sensing (OAWRS) typically utilizes large-aperture linear arrays combined with coherent beamforming to estimate the spatial distribution of acoustic scattering echoes. The conventional maximum likelihood deconvolution (DCV) method uses a likelihood model that is inaccurate in the presence of multiple adjacent targets with significant intensity differences. In this study, we propose a deconvolution algorithm based on a modified likelihood model of beamformed intensities (M-DCV) for estimation of the spatial intensity distribution. The simulated annealing iterative scheme is used to obtain the maximum likelihood estimation. An approximate expression based on the generalized negative binomial (GNB) distribution is introduced to calculate the conditional probability distribution of the beamformed intensity. The deconvolution algorithm is further simplified with an approximate likelihood model (AM-DCV) that can reduce the computational complexity for each iteration. We employ a direct deconvolution method based on the Fourier transform to enhance the initial solution, thereby reducing the number of iterations required for convergence. The M-DCV and AM-DCV algorithms are validated using synthetic and experimental data, demonstrating a maximum improvement of 73% in angular resolution and a sidelobe suppression of 15 dB. Experimental examples demonstrate that the imaging performance of the deconvolution algorithm based on a linear small-aperture array consisting of 16 array elements is comparable to that obtained through conventional beamforming using a linear large-aperture array consisting of 96 array elements. The proposed algorithm is applicable for Ocean Acoustic Waveguide Remote Sensing (OAWRS) and other sensing applications using linear arrays. Full article

In satellite remote sensing (SRS), there is a demand for large-power microwave components. A Butler matrix is essential to a transmitting antenna array in SRS. This article illustrates the electrical and mechanical design, simulation, and test results of a large-power planar beamforming network for SRS at C-band. It is a 4 × 4 Butler matrix based on square coaxial lines. Short-ended stubs are used in the Butler matrix to broaden its bandwidth by 10%, support inner conductors, and enhance heat transfer in vacuum environments. The simulation results are consistent with the measured results. The reflection coefficient is less than −18 dB, and the isolation is more than 23 dB from 3.8 GHz to 4.2 GHz. The insertion losses are less than 0.6 dB, and the phase errors are better than ±6°. The measured peak microwave power of the proposed Butler matrix is 9 kW. Its size is 440 × 400 × 40 mm³. The proposed Butler matrix beamforming network can be applied to SRS systems. Full article

With the booming rollout of 5G communication, abundant new technologies have been proposed for quality of service requirements. In terms of the betterment in transmission coverage, mobile edge caching (MEC) has shown potential in reducing the transmission outage. The performance of MEC, meanwhile, can be promisingly enhanced by reconfigurable intelligent surfaces (RIS). Under this context, we explore a system comprising a small base-station (SBS) with limited cache capacity, two users, and one RIS. The SBS transmits the contents from the cache or fetches them from the remote backhaul hub to communicate with users through directional and possibly reflective channels. In this point-to-multipoint connection, non-orthogonal multiple access (NOMA) is applied, improving the capacity of the system. To minimize the outage probability, we first propose a caching policy from entropy perspective, based on which we investigate the beamforming and power allocation problem. The issue, however, is non-convex and involves multi-dimensional optimization. To address this, we introduce an efficient block successive upper-bound minimization algorithm, grounded in Gershgorin’s circle theorem. This algorithm aims to find the globally optimal solution for power allocation and RIS beamformer, considering both the channel condition and content popularity. Numerical studies are performed to verify the effectiveness of the proposed algorithm. Full article

Autonomous remote sensing systems establish communication links between nodes. Ensuring coverage and seamless communication in highly dense environments is not a trivial task as localization, separation, and tracking of targets, as well as interference suppression, are challenging. Therefore, smart antenna systems fulfill these requirements by employing beamforming algorithms and are considered a key technology for autonomous remote sensing applications. Among many beamforming algorithms, the recursive least square (RLS) algorithm has proven superior convergence and convergence rate performances. However, the tracking performance of RLS degrades in the case of dynamic targets. The forgetting factor in RLS needs to be updated constantly for fast target tracking. Additionally, multiple beamforming algorithms can be combined to increase tracking performance. An improved hybrid constant modulus RLS beamforming algorithm with an adaptive forgetting factor and a variable regularization factor is proposed. The forgetting factor is updated using the low-complexity yet robust adaptive moment estimation method (ADAM). The sliding-window technique is applied to the proposed algorithm to mitigate the steady-state noise. The proposed algorithm is compared with existing RLS-based algorithms in terms of convergence, convergence rate, and computational complexity. Based on the results, the proposed algorithm has at least 10 times better convergence (accuracy) and a convergence rate two times faster than the compared RLS-based algorithms. Full article

Wideband beamformers have been widely studied in wireless communication, remote sensing and so on. Generally speaking, to improve the spatial filtering ability of beamformers, there usually needs more sensors, which implies increased computational complexity and hardware costs. Besides that, wideband beamformers are known to be exceedingly sensitive to sensor mismatches in practice. Nevertheless, there is still a gap in research on the design of robust sparse wideband beamformers. In this paper, a two-step design of this topic is proposed. Firstly, a robust design based on the worst-case performance optimization (WCPO) using circular-model (CM) sensor mismatches is reformulated to address shortcomings of constraint sensitivity. Secondly, inspired by the joint sparse technology in compressive sensing theory, we focus on the sparse design of wideband beamformer. The constraints for the response characteristics and robustness are set from first step, and an iterative algorithm based on reweighted ${\ell }_{2,1}$ optimization is adopted to achieve maximum sparsity of the sensor array. The mainly advantages of the work are that the proposed design exhibits accordant performance in terms of response and robustness, but few sensors compared with the counterpart with uniform array. Moreover, we surprisingly find that the optimized sparse array is also applicable to other design based on WCPO criterion. Simulation results are provided to verify the superior of the proposed methods compared to the existing counterparts. Full article

High-accuracy level underwater acoustical surveying plays an important role in ocean engineering applications, such as subaqueous tunnel construction, oil and gas exploration, and resources prospecting. This novel imaging method is eager to break through the existing theory to achieve a higher accuracy level of surveying. Multibeam Synthetic Aperture Sonar (MBSAS) is a kind of underwater acoustical imaging theory that can achieve 3D high-resolution detecting and overcome the disadvantages of traditional imaging methods, such as Multibeam Echo Sounder (MBES) and Synthetic Aperture Sonar (SAS). However, the resolution in the across-track direction inevitably decreases with increasing range, limited by the beamwidth of the transducer array of MBES. Furthermore, the sidelobe problem is also a significant interference of imaging sonar that introduces image noise and false peaks, which reduces the accuracy of the underwater images. Therefore, we proposed an accelerated deconvolved MBSAS beamforming method that introduces exponential acceleration and vector extrapolation to improve the convergence velocity of the classical Richardson-Lucy (R-L) iteration. The method proposed achieves a narrow beamwidth with a high sidelobe ratio in a few iterations. It can be applied to actual engineering applications, which breaks through the limitation of the actual transducer array scale. Simulations, tank, and field experiments also demonstrate the feasibility and advantages of the method proposed. 3D high-accuracy level underwater acoustical surveying can be achieved through this 2D MBES transducer array system, which can be widely promoted in the field of underwater acoustical remote sensing. Full article

Wireless power transfer provides a most convenient solution to charge devices remotely and without contacts. R&D has advanced the capabilities, variety, and maturity of solutions greatly in recent years. This survey provides a comprehensive overview of the state of the art on different technological concepts, including electromagnetic coupled and uncoupled systems and acoustic technologies. Solutions to transfer mW to MW of power, over distances ranging from millimeters to kilometers, and exploiting wave concepts from kHz to THz, are covered. It is an attractive charging option for many existing applications and moreover opens new opportunities. Various technologies are proposed to provide wireless power to these devices. The main challenges reside in the efficiency and range of the transfer. We highlight innovation in beamforming and UV-assisted approaches. Of particular interest for designers is the discussion of implementation and operational aspects, standards, and safety relating to regulations. A high-level catalog of potential applications maps these to adequate technological options for wireless power transfer. Full article

Satellite communication is expected to play a vital role in realizing Internet of Remote Things (IoRT) applications. This article considers an intelligent reflecting surface (IRS)-assisted downlink low Earth orbit (LEO) satellite communication network, where IRS provides additional reflective links to enhance the intended signal power. We aim to maximize the sum-rate of all the terrestrial users by jointly optimizing the satellite’s precoding matrix and IRS’s phase shifts. However, it is difficult to directly acquire the instantaneous channel state information (CSI) and optimal phase shifts of IRS due to the high mobility of LEO and the passive nature of reflective elements. Moreover, most conventional solution algorithms suffer from high computational complexity and are not applicable to these dynamic scenarios. A robust beamforming design based on graph attention networks (RBF-GAT) is proposed to establish a direct mapping from the received pilots and dynamic network topology to the satellite and IRS’s beamforming, which is trained offline using the unsupervised learning approach. The simulation results corroborate that the proposed RBF-GAT approach can achieve more than 95% of the performance provided by the upper bound with low complexity. Full article

This paper presents an estimation method for a sound source of pre-recorded mallard calls from acoustic information using two microphone arrays combined with delay-and-sum beamforming. Rice farming using mallards saves labor because mallards work instead of farmers. Nevertheless, the number of mallards declines when they are preyed upon by natural enemies such as crows, kites, and weasels. We consider that efficient management can be achieved by locating and identifying the locations of mallards and their natural enemies using acoustic information that can be widely sensed in a paddy field. For this study, we developed a prototype system that comprises two sets of microphone arrays. We used 64 microphones in all installed on our originally designed and assembled sensor mounts. We obtained three acoustic datasets in an outdoor environment for our benchmark evaluation. The experimentally obtained results demonstrated that the proposed system provides adequate accuracy for application to rice–duck farming. Full article
