With the rapid expansion of wind energy infrastructure, there is an increasing accumulation of wind turbine blade waste (WTBW), which is mainly composed of glass fiber-reinforced thermosetting composites. Due to the irreversible nature of polymer crosslinking, conventional recycling methods remain limited. In this study, plasma vitrification was employed to convert WTBW into a reactive calcium-aluminum-silicate slag suitable for use in geopolymer materials. Plasma treatment at a temperature of approximately 2750 K resulted in the formation of predominantly amorphous vitrified slag (VS). Structural characterization using X-ray diffraction (XRD), Fourier transform infrared spectroscopy (FTIR), and scanning electron microscopy with energy-dispersive X-ray spectroscopy (SEM-EDS) revealed the spatial heterogeneity of the VS. This heterogeneity was influenced by thermal gradients and varied between samples collected from different slag discharge zones, both vertically and horizontally from the reactor. All VS samples contained between 30 and 89% amorphous phase and 10–55% anorthite, with the proportions varying by sampling location. Chemical stability tests showed the dissolution of calcium and aluminum in acidic media, resulting in a silica-enriched residual structure in which the Ca and Al content decreased to less than 0.5 at.% after 100 days. In contrast, exposure to alkaline media caused only minimal surface reorganization—the addition of 5 wt.% VS to acid-based geopolymers made with two metakaolin precursors resulted in a 35% decrease in the mechanical strength of pure metakaolin-based systems. In contrast, when metakaolin containing illite impurities was used, strength values were similar to those of the reference geopolymer. The results quantitatively demonstrate that plasma-derived slag exhibits composition-dependent reactivity, directly linked to its amorphous content and dissolution behavior. Full article

With the development of distributed energy sources such as photovoltaic and wind power, power grids have imposed increasingly higher requirements on power quality. As common nonlinear loads in power grids, multi-pulse rectifiers (MPRs) inject significant harmonics into the grid side. To reduce harmonic pollution at the source, this paper proposes a novel triple-passive harmonic suppression method to reduce the input current harmonics of MPRs. The proposed 48-pulse rectifier comprises a main circuit based on delta-connected auto-transformer (DCT) and a triple-passive harmonic suppression circuit (TPHSC). The TPHSC consists of two interphase reactors (IPRs) and eight diodes. Based on Kirchhoff’s Current Law (KCL), the output currents of the main circuit are calculated, and the operating modes of the TPHSC are analyzed. From the main circuit’s output currents and the DCT topology, the rectifier’s input currents are derived, and the optimal turns ratio of the IPRs for minimizing the input current total harmonic distortion (THD) is determined. The total capacity of the IPRs accounts for only 2.3% of the output load power. Experimental results show that the measured input current THD is close to the theoretical value of 3.8%. Overall, the proposed rectifier offers a cost-effective solution with stronger harmonic suppression capability, making it suitable for applications requiring low grid harmonic pollution. Full article

Dry-type air-core reactors (DAR) are critical components in power systems but are prone to inter-turn short circuit faults which interrupt the symmetry of the winding structure. Inspired by the online detection of transformer winding deformation, the V-I method has been adapted to diagnose short circuit faults in reactors. However, the diagnostic criteria and thresholds of V-I method remain unclear. This paper presents a novel method for determining the threshold for detecting inter-turn short circuit faults in DAR, integrating V-I analysis with machine learning techniques. Specifically, Gradient Boosting Regression (GBR) is used to compute a standard diagnostic criterion value, and curve fitting is also used to define the threshold for identifying inter-turn short circuit faults. The experimental results demonstrate that this method effectively identifies fault conditions in DAR. Full article

The integration of advanced nuclear technologies like the System-Integrated Modular Advanced Reactor (SMART) offers a transformative approach to enhancing grid reliability in developing countries. This study focuses on the Nairobi distribution network in Kenya, a critical region characterized by an evolving energy mix of geothermal, hydro, solar, and wind power sources, comprising 220 kV and 132 kV transmission lines feeding 66 kV, 33 kV, and 11 kV distribution lines to various load centers. Using ETAP 22 simulation software, the research evaluates the impact of SMART integration through three scenarios: baseline operation, grid compensator-only operation, and SMART-SMR integration. Key reliability indices such as the System Average Interruption Frequency Index (SAIFI), System Average Interruption Duration Index (SAIDI), and Expected Energy Not Supplied (EENS) were analyzed. Results reveal that integrating a 100 MW SMART reactor reduces SAIDI by 2.8% (5.0433 h/customer-year) and SAIFI by 5.1% (0.0516 interruptions/customer-year), while maintaining voltage profiles within 98.21–98.91% of nominal. This analysis bridges gaps in prior research by demonstrating SMART’s ability to stabilize power grids in emerging economies, providing critical insights for policymakers aiming to achieve reliable and sustainable energy systems. Full article

In this paper, variable reactance (VR) criteria are proposed to mitigate voltage deviations in power transformers under light-load inductive and capacitive conditions, as well as for over-load conditions. Under capacitive load conditions, power transformers are affected by the Ferranti effect as much as AC lines are and can suffer damage if a large over-voltage is present at the secondary winding. A classical solution for this is the installation of expensive and bulky inductive reactors at different locations of the AC lines to absorb the reactive power. Instead, this paper addresses VR techniques focused on power transformer reactance modification to compensate for the over-voltage. With these techniques, the Ferranti effect on power lines can also be reduced. Another benefit is the cancellation of over-voltages whose cause is different from the Ferranti effect, namely under inductive load conditions. In addition, they can also enhance the parallel operation of power transformers by allowing more flexibility for overload sharing among transformers. The VR techniques are derived from the Kapp phasor-diagram theory and have been validated experimentally at a small scale in the laboratory. When implemented in a big network, they can also improve the load-flow voltage and AC line-loading profiles and even increase the power factor of certain generators. Full article

The well-known circuit for the generation of lightning impulse voltage (LIV) on low-inductance loads was introduced by Glaninger in 1975, and the circuit component selection was proposed by Feser. However, the circuit and the approach for the component selection have some difficulties for which further adjustment is required for obtaining the waveform parameters according to the standard requirement. In this paper, an extended Glaninger’s circuit with an additional series resistor is proposed. Furthermore, a systematic design and circuit analysis of LIV generation for low-inductance loads are developed. With the help of a circuit simulator, the circuit analysis for the component selection is described. The validity of the proposed circuit was confirmed by some experimental results in comparison with the simulated ones. The proposed circuit and component selection provide not only the generation waveform according to the standard requirement but also other promising performances in terms of the wide inductance load range from 400 μH to 4 mH, a voltage efficiency of over 80%, an overshoot voltage of below 5%, an undershoot voltage of below 40%, and a maximum charging capacitance of 10 μF. From the simulated and experimental results, the proposed circuit and component selection approach is very useful for the LIV tests on low-inductance loads instead of using the conventional approach based on trial and error. Full article

Endowing wind farms (WFs) with fault ride through (FRT) capability is crucial to their continuous availability under various operating conditions. This paper proposes a dynamic adaptive multi-cell fault current limiter (MCFCL) topology to enhance the FRT capability of grid connected WFs. The proposed MCFCL consists of one transient cell (TC) and multi resistive cells (RCs) directly connected to the grid’s high voltage without using any series injection transformers nor any series connection of semiconductor switches. The transient cell of the MCFCL includes two transient limiting reactors (TLRs) to mitigate the transient fault current and limit the rate of change of the currents of the semiconductor switches during fault occurrence. The number of RCs in the MCFCL is determined based on voltage sag level. These latter are inserted in the fault path to provide an adaptive voltage sag compensation mechanism according to the voltage sag level. Assessment of the MCFCL under various sag conditions, showed that the MCFCL is able to effectively compensate for a wide range of voltage sags without any over voltage at the WF’s terminal. Comparison analysis with the conventional single-cell bridge-type FCL (SBFCL) showed the superior performance of the proposed MCFCL. Full article

In this paper, an effective simulation method for lightning impulse voltage tests of reactor and transformer windings is presented. The method is started from the determination of the realized equivalent circuit of the considered winding in the wide frequency range from 10 Hz to 10 MHz. From the determined equivalent circuit and with the use of the circuit simulator, the circuit parameters in the impulse generator circuit are adjusted to obtain the waveform parameters according to the standard requirement. The realized equivalent circuits of windings for impulse voltage tests have been identified. The identification approach starts from equivalent circuit determination based on a vector fitting algorithm. However, the vector fitting algorithm with the equivalent circuit extraction is not guaranteed to obtain the realized equivalent circuit. From the equivalent circuit, it is possible that there are some negative parameters of resistance, inductance, and capacitance. Using such circuit parameters from the vector fitting approach as the beginning circuit parameters, a genetic algorithm is employed for searching equivalent circuit parameters with the constraints of positive values. The realized equivalent circuits of the windings can be determined. The validity of the combined algorithm is confirmed by comparison of the simulated results by the determined circuit model and the experimental results, and good agreement is observed. The proposed approach is very useful in lightning impulse tests on the reactor and transformer windings. Full article

The Ferranti effect could cause a rise in voltage along the cables on a wind farm if the circuit breakers at the receiving ends are switched off. Ferroresonance could also occur due to stuck pole(s) of the circuit breaker during de-energization. This paper reports on the temporary overvoltage (TOV) arising from the de-energization of the circuit breaker connecting the wind turbine to the feeder, the feeder breaker connecting an array of wind turbines to the point of common coupling (PCC), and the opening of the circuit breaker connecting the onshore to the offshore substation. Ferroresonance was characterized using a phase plane diagram and Poincaré map and was identified to be chaotic. The effect of the nonlinear characteristic of the wind transformer core on the ferroresonant overvoltage was examined and increased with the steepness of slope of the transformer curve. A damping resistor, shunt reactor and surge arrester were used to mitigate the overvoltage experienced during the ferroresonant event. The damping resistor was able to reduce the overvoltage to 1.24 P.U. and damped the ferroresonance from chaotic to fundamental mode. Full article

This paper presents an effective technique based on an artificial neural network algorithm utilized for circuit parameter identification in lightning impulse generation for low inductance loads such as low voltage windings of a power transformer, a large distribution transformer and an air core reactor. The limitation of the combination between Glaninger’s circuit and the circuit parameter selection from Feser’s suggestions in term of producing an impulse waveform to be compliant with standard requirements when working with a low inductance load is discussed. In Feser’s approach, the circuit parameters of the generation circuit need to be further adjusted to obtain the waveform compliant with the standard requirement. In this process, trial and error approaches based on test engineers’ experience are employed in the circuit parameter selection. To avoid the unintentional damage from electrical field stress during the voltage waveform adjustment process, circuit simulators, such as Pspice and EMTP/ATP, are very useful to examine the generated voltage waveform before the experiments on the test object are carried out. In this paper, a system parameter identification based on an artificial neural network algorithm is applied to determine the appropriate circuit parameters in the test circuit. This impulse voltage generation with the selected circuit parameters was verified by simulations and an experiment. It was found that the generation circuit gives satisfactory impulse voltage waveforms in accordance with the standard requirement for the maximum charging capacitance of 10 µF and the load inductance from 400 µH to 4 mH. From the simulation and experimental results of all cases, the approach proposed in this paper is useful for test engineers in selection of appropriate circuit components for impulse voltage tests with low inductance loads instead of employing conventional trial and error in circuit component selection. Full article

Electroreduction allows for the transformation of a chemically inert molecule such as CO₂ into a wide variety of useful carbon products. Unlike other approaches operating at higher temperatures, electrochemical reduction holds great promise since it achieves reduction under ambient conditions, thereby providing more control over the reaction selectivity. By controlling basic parameters such as the potential and the composition of the electrode, CO₂ can be transformed into a variety of products including carbon monoxide, syngas (CO/H₂), methane, and methanol. This reduction process takes place without external hydrogen, since water can be used as a source of both electrons and protons. Furthermore, this technology, when combined with renewable wind- or solar-derived electricity, has the potential to serve as a storage system for excess electricity. Despite these advantages, a number of challenges need to be overcome before reaching commercialization. New (and cheaper) electrocatalyst formulations with high faradaic selectivities are required. Impressive progress has been made on carbon-doped materials, which, in certain cases, have outperformed expensive noble metal-based materials. Research is also needed on new electrochemical reactor configurations able to overcome kinetic/mass transport limitations, which are crucial to reduce overpotentials. Fine control over the nature of the active sites and the reaction conditions is important to avoid parasitic reactions such as the hydrogen evolution reaction (HER), and therefore increases the faradaic efficiency towards the desired products. Full article

In this early 21st century, our societies have to face a tremendous and increasing energy need while mitigating the global climate change and preserving the environment. Addressing this challenge requires an energy transition from the current fossil energy-based system to a carbon-free energy production system, based on a relevant energy mix combining renewables and nuclear energy. However, such an energy transition will only occur if it is accepted by the population. Powerful and reliable tools, such as life cycle assessments (LCA), aiming at assessing the respective merits of the different energy mix for most of the environmental impact indicators are therefore mandatory for supporting a risk-informed decision-process at the societal level. Before studying the deployment of a given energy mix, a prerequisite is to perform LCAs on each of the components of the mix. This paper addresses two potential nuclear energy components: a nuclear fuel cycle based on the Generation III European Pressurized Reactors (EPR) and a nuclear fuel cycle based on the Generation IV Sodium Fast Reactors (SFR). The basis of this study relies on the previous work done on the current French nuclear fuel cycle using the bespoke NELCAS tool specifically developed for studying nuclear fuel cycle environmental impacts. Our study highlights that the EPR already brings a limited improvement to the current fuel cycle thanks to a higher efficiency of the energy transformation and a higher burn-up of the nuclear fuel (−20% on most of the chosen indicators) whereas the introduction of the GEN IV fast reactors will bring a significant breakthrough by suppressing the current front-end of the fuel cycle thanks to the use of depleted uranium instead of natural enriched uranium (this leads to a decrease of the impact from 17% on water consumption and withdrawal and up to 96% on SO_x emissions). The specific case of the radioactive waste is also studied, showing that only the partitioning and transmutation of the americium in the blanket fuel of the SFR can reduce the footprint of the geological disposal (saving up to a factor of 7 on the total repository volume). Having now at disposition five models (open fuel cycle, current French twice through fuel cycle, EPR twice through fuel cycle, multi-recycling SFR fuel cycle and at a longer term, multi-recycling SFR fuel cycle including americium transmutation), it is possible to model the environmental impact of any fuel cycle combining these technologies. In the next step, these models will be combined with those of other carbon-free energies (wind, solar, biomass…) in order to estimate the environmental impact of future energy mixes and also to analyze the impact on the way these scenarios are deployed (transition pathways). Full article
