Three-dimensional reconstruction using monocular camera images is a well-established research topic. While multi-image approaches like Structure from Motion produce sparse point clouds, single-image depth estimation via machine learning promises denser results. However, many models estimate relative depth, and even those providing metric depth often struggle with unseen data due to unfamiliar camera parameters or domain-specific challenges. Accurate metric 3D reconstruction is critical for railway applications, such as ensuring structural gauge clearance from vegetation to meet legal requirements. We propose a novel method to scale 3D point clouds using the track gauge, which typically only varies in very limited values between large areas or countries worldwide (e.g., $1.435$ m in Europe). Our approach leverages state-of-the-art image segmentation to detect rails and measure the track gauge from a train driver’s perspective. Additionally, we extend our method to estimate a reasonable railway-specific extrinsic camera calibration. Evaluations show that our method reduces the average Chamfer distance to LiDAR point clouds from $1.94$ m (benchmark UniDepth) to $0.41$ m for image-wise calibration and $0.71$ m for average calibration. Full article

Rail infrastructure plays an important role in fulfilling the demand for freight and passenger transportation. Increases in traffic volume, heavier axles and vehicles, higher speeds, and increasing climate extremes all contribute to the constant strain on the infrastructure. Due to their major importance in the transportation of people and freight, they are subject to continuous condition monitoring. This is an essential requirement for the selective planning of maintenance tasks and ultimately for safe and reliable operation. Various measuring systems have been developed for this purpose. These must measure precisely, quickly, and robustly under difficult conditions. Whether installed from mobile or stationary platforms, they have to cope with a wide range of ambient temperatures and lighting conditions, harsh environmental influences, and varying degrees of reflection. Despite these circumstances, railway operators require precise measurement data, high data densities even at high traveling speeds, and a user-friendly presentation of the results. Photogrammetry, laser scanning, and fiber optics are light-based measurement methods that are used in this sector. They are able to record with high precision rail infrastructure such as overhead contact systems, clearance profiles, rail tracks, and much more. This article provides an overview of the established and modern optical sensing methods, as well as the use of artificial intelligence as an evaluation method, and highlights their advantages and disadvantages. Full article

The China Railway Express (CR Express) is an important component of the Belt and Road Initiative (BRI). The sustainable development of CR Express provides critical support for regional economic integration and promotes a balanced development of the supply chain. Infrastructure reliability and trade facilitation greatly impact the operation of CR Express and are crucial for improving the competitiveness of transnational trade and cross-border efficiency. Inconsistent transportation infrastructure standards and low-efficient transportation service procedures affect the cross-border movement of cargo among countries. This paper integrates quantified metrics of infrastructure reliability and trade facilitation into a spatial friction model based on the electrical resistance theory, estimating the impact of these factors on the transportation flow of CR Express. Additionally, three scenarios of infrastructure reliability and trade facilitation are established for the four trade routes from Zhengzhou to Hamburg. Numerical experiments show that compared with inland river routes and traditional ocean routes, infrastructure reliability and trade facilitation significantly influence the transport flow of CR Express. These research results can provide a reference for the improvements of CR Express transportation efficiency and the simplification of customs clearance processes, potentially promoting the sustainable development of the CR Express supply chain to some extent. Full article

Reasonable excavation step footage and lining support timing are highly important for improving tunnel construction efficiency and ensuring construction safety. Taking the Huanxian No. 1 Tunnel of the Xi-Yin railway as the basis of this study, a 3D numerical model was established using MIDAS GTS NX290 finite element software. This model was used to investigate the deformation and force characteristics of the tunnel-surrounding rock and support structures under three different excavation footages and four different lining construction timings; the numerical results were then compared with the on-site monitoring results. This research aimed to determine reasonable excavation parameters for the three-bench seven-step excavation method used in shallowly buried loess tunnels. The results revealed positive correlations between the excavation step footage and surface subsidence, crown subsidence, and clearance convergence. An excavation footage of 3 m could balance construction efficiency and safety effectively. Keeping the secondary lining construction time unchanged, the early closure of the initial support was beneficial for reducing the force on the secondary lining. Keeping the early closure time of the initial support unchanged, the early construction of the secondary lining would lead to an increase in the force on the secondary lining. The initial support of the tunnel is recommended to be closed as early as possible, and the construction of the secondary lining should be shifted by 21 m behind the upper step palm surface. By comparing the on-site monitoring data with the numerical simulation results, similar trends were observed, providing reference and guidance for the subsequent construction of large-section tunnels in shallowly buried loess formations. Full article

Remote condition monitoring (RCM) aims to ensure the availability of railway assets. Previous work has indicated the importance of a user-centred RCM design approach based on cognitive principles, but there has been no known demonstration of the application of these principles. The following paper takes this theory-based approach and applies it to the design of an RCM system for the rail pantograph/Overhead Line (OHL) system. The paper first presents a high-level conceptual architecture, based on four stages of cognitive decision-making (notification, acceptance, analysis and clearance), linked to the wider monitoring architecture. Second, the paper uses cognitive principles to propose demonstration Human–Machine Interface designs for the OHL system. These HMIs were presented in an evaluation with subject matter experts. The outcomes of the process generated user-centred design recommendations for RCM. Furthermore, the evaluation suggested the importance of multiple paths through the HMI dependent on the type and urgency of fault. Finally, the outcomes of the evaluation also highlighted the importance of considering context when deploying user-centred RCM. Full article

To achieve safety, accessibility, and technical compatibility in the operation of rail systems, technical specifications for interoperability are adopted to be complied with. This paper presents a study of the essential interoperability requirement ʺStructure Gaugeʺ within the framework of the regulations applicable to new, upgraded, or renewed infrastructure in the rail system within the European Union. Full article

Adjacent tunnel excavation has an adverse impact on existing structures. Based on the engineering project of the Donghuashan Tunnel under-crossing an existing tunnel, this paper designed 25 sets of orthogonal numerical simulation tests to investigate the influential mechanisms of five parameters on ground displacement and deformation. The influential factors are skew angle ($\mathsf{\alpha }$), proximity distance (l), buried depth (h), clearance (D), and ratio of tunnel clearances ($\mathsf{\nu }$). The orthogonal test results revealed that (1) the new tunnel clearance is the main impact factor of both ground settlement and curvature deformation, (2) ground horizontal movement is most significantly influenced by the skew angle between the existing tunnel and the new tunnel, and (3) the new tunnel buried depth is the key influential parameter for ground tilt deformation as well as horizontal deformation. The conclusions of this research suggest that during the period of railway planning, it is very important to plan the buried depths and spans of new tunnels rationally to minimize disturbance to existing tunnels. Full article

The article analyzes the aerodynamic processes initiated by the piston effect in extra-long railway tunnels. The authors numerically modelled the movement of a freight train, 1 km long, in tunnels 3 and 6 km long. The analysis used the ANSYS Fluent environment. The modeling determined the air pressure at the front and back faces of the train, the draught loss in the tunnel clearance, as well as the air velocity in the tunnel clearance and in the tunnel. These data are used to develop a quasi-dynamic model of the piston effect for solving problems concerning air distribution with the application of network models. The air flow rates calculated in ANSYS Fluent and using the network models agree quite well. The time of the problem solving for a tunnel 3 km long using the network model is shorter by 5 orders of magnitude, which is of significant importance for both the study and multivariate design of ventilations systems for railway tunnels. Full article

To prevent the problem of safety accidents caused by the intrusion of obstacles into railway clearance, this paper proposes an obstacle detection method based on Light Detection and Ranging (LiDAR) to obtain and process rich three-dimensional (3D) information and depth information of the railway scene. The method first preprocesses the point cloud of the railway scenario collected by LiDAR to divide a basic area containing the rails. Then, the method divides the roadbed plane and fits the rails with the random sample consensus (RANSAC) algorithm, dividing the detection area according to the position of the rails. To address the issue of over or under-segmentation in the traditional Euclidean clustering method, which is due to sparser point clouds the farther the object is from the LiDAR, this paper improves the conventional Euclidean clustering. It introduces an adaptive distance threshold to categorize obstacles. Finally, compared with traditional Euclidean clustering, K-means clustering, and density-based spatial clustering of applications with noise (DBSCAN) clustering, the improved Euclidean cluster has achieved better results in terms of computing time and segmentation accuracy. Experimental results show the ability of the method to detect railway obstacles successfully. Full article

The efficiency and the effectiveness of railway intrusion detection are crucial to the safety of railway transportation. Most current methods of railway intrusion detection or obstacle detection are inappropriate for large-scale applications due to their high cost or limited coverage. In this study, we present a fast and low-cost solution to intrusion detection of high-speed railways. As the solution to heavy computational burdens in the current convolutional-neural-network-based detection methods, the proposed method is mainly a novel neural network based on the SSD framework, which includes a feature extractor using an improved MobileNet and a lightweight and efficient feature fusion module. In addition, aiming to improve the detection accuracy of small objects, the feature map weights are introduced through convolution operation to fuse features at different scales. TensorRT is employed to optimize and deploy the proposed network in the low-cost embedded GPU platform, NVIDIA Jetson TX2, to enhance the efficiency. The experimental results show that the proposed methods achieved 89% mAP on the railway intrusion detection dataset, and the average processing time for a single frame was 38.6 ms on the Jetson TX2 module, which satisfies the need of real-time processing. Full article

Transport networks need periodic inspections to increase their safety and improve their management. In the last few years, LiDAR (light detection and ranging) technology has become a tool for helping to create a precise database of almost any type of infrastructure. Mobile laser scanning (MLS) systems use a laser beam to collect dense three dimensional (3D) point clouds, which include geometric and radiometric data of the environment in which they are placed. In the context of this paper, a methodology for automatically inspecting the clearance gauge and the deflection of the aerial contact line in railway tunnels is presented. The main objective is to compare results and verify their compliance with the Spanish norm. The 3D data are provided by a LYNX Mobile Mapper System (MMS). First, the area is surveyed and then the obtained (3D) point cloud is classified into contact wire, suspension wire, and remaining points. Finally, the inspection of the railway’s power line is performed. The validation of the proposed methodology has been carried out in three different tunnel point clouds, obtaining both qualitative and quantitative results for points’ classification, together with the results of the measures performed. Full article

With the rapid development of high-speed railways, any objects intruding railway clearance will do great threat to railway operations. Accurate and effective intrusion detection is very important. An original Single Shot multibox Detector (SSD) can be used to detect intruding objects except small ones. In this paper, high-level features are deconvolved to low-level and fused with original low-level features to enhance their semantic information. By this way, the mean average precision (mAP) of the improved SSD algorithm is increased. In order to decrease the parameters of the improved SSD network, the L1 norm of convolution kernel is used to prune the network. Under this criterion, both the model size and calculation load are greatly reduced within the permitted precision loss. Experiments show that the mAP of our method on PASCAL VOC public dataset and our railway datasets have increased by 2.52% and 4.74% respectively, when compared to the original SSD. With our method, the elapsed time of each frame is only 31 ms on GeForce GTX1060. Full article

In Europe, the attention to efficiency and safety of international railway freight transport has grown in recent years and this has drawn attention to the importance of verifying the clearance between vehicle and lining, mostly when different and variable rolling stock types are expected. This work consists of defining an innovative methodology, with the objective of surveying the tunnel structures, verifying the clearance conditions, and designing a retrofitting work if necessary. The method provides for the use of laser scanner, thermocameras, and ground penetrating radar to survey the geometrical and structural conditions of the tunnel; an algorithm written by the authors permits to verify the clearances. Two different types of works are possible if the inner tunnel surfaces interfere with the profile of the rolling stock passing through: modification of the railroad track or modification of the tunnel intrados by mean milling of its lining. The presented case study demonstrates that the proposed methodology is useful for verifying compatibility between the design vehicle gauge and the existing tunnel intrados, and to investigate the chance to admit rolling stocks from different states. Consequently, the results give the railway management body a chance to perform appropriate measurements in those cases where the minimum clearance requirements are not achieved. Full article

Railway tunnel clearance is directly related to the safe operation of trains and upgrading of freight capacity. As more and more railway are put into operation and the operation is continuously becoming faster, the railway tunnel clearance inspection should be more precise and efficient. In view of the problems existing in traditional tunnel clearance inspection methods, such as low density, slow speed and a lot of manual operations, this paper proposes a tunnel clearance inspection approach based on 3D point clouds obtained by a mobile laser scanning system (MLS). First, a dynamic coordinate system for railway tunnel clearance inspection has been proposed. A rail line extraction algorithm based on 3D linear fitting is implemented from the segmented point cloud to establish a dynamic clearance coordinate system. Second, a method to seamlessly connect all rail segments based on the railway clearance restrictions, and a seamless rail alignment is formed sequentially from the middle tunnel section to both ends. Finally, based on the rail alignment and the track clearance coordinate system, different types of clearance frames are introduced for intrusion operation with the tunnel section to realize the tunnel clearance inspection. By taking the Shuanghekou Tunnel of the Chengdu–Kunming Railway as an example, when the clearance inspection is carried out by the method mentioned herein, its precision can reach 0.03 m, and difference types of clearances can be effectively calculated. This method has a wide application prospects. Full article

The paper contains a survey of mobile scanning systems for measuring the railway clearance gauge. The research was completed as part of the project carried out for the PKP (PKP Polish Railway Lines S.A., Warsaw, Poland) in 2011–2013. The authors conducted experiments, including a search for the latest solutions relating to mobile measurement systems that meet the basic requirement. At the very least, these solutions needed to be accurate and have the ability for quick retrieval of data. In the paper, specifications and the characteristics of the component devices of the scanning systems are described. Based on experiments, the authors did some examination of the selected mobile systems to be applied for measuring the clearance gauge. The Riegl (VMX-250) and Z+F (Zoller + Fröhlich) Solution were tested. Additional test measurements were carried out within a 30-kilometer section of the Warsaw-Kraków route. These measurements were designed so as to provide various elements of the railway infrastructure, the track geometry and the installed geodetic control network. This ultimately made it possible to reduce the time for the preparation of geodetic reference measurements for the testing of the accuracy of the selected systems. Reference measurements included the use of the polar method to select profiles perpendicular to the axis of the track. In addition, the coordinates selected were well defined as measuring points of the objects of the infrastructure of the clearance gauge. All of the tested systems meet the accuracy requirements initially established (within the range of 2 cm as required by the PKP). The tested systems have shown their advantages and disadvantages. Full article
