The 27,000 km of railway track in France represents approximately 100 million tonnes of ballast. This ballast requires maintenance approximately every 7 years, screening and partial renewal every 20 years, and complete replacement every 40 years. Despite its shortcomings, ballast is still widely used on railways worldwide, as there is no better or more efficient solution currently available. In an effort to conserve resources, companies such as SNCF (French national railway company) are implementing initiatives to move towards zero waste. In order to achieve the goal of promoting the recycling and recovery of end-of-life material flows, it is necessary to develop specific studies and models for production, such as direct and reverse logistics systems. This article proposes a generic material flow analysis model applied to a track and ballast renewal site, aiming to fill a gap in the literature. It is based on data from eleven track and ballast renewal sites. A flow diagram generated by STAN software presents a detailed diagnosis of ballast inputs, outputs, and stocks, including data uncertainty. The distribution of the material flows through the model is characterized by transfer coefficients in various transformation processes. Furthermore, by varying the quantities in this model, it is possible to study different scenarios based on the current situation. This will facilitate the projection and analysis of future management strategies aimed at achieving zero waste and reducing the discharge of toxic substances based on specific performance indicators. Full article

Railway lines require a significant amount of natural raw materials. Industrial by-products can be used instead, reducing the costs of natural aggregate exploration. This work analyzes a ballasted track’s short- and long-term performances when replacing conventional sub-ballast aggregate with steel slag. After an extensive laboratory characterization of the steel slag, the material performance was analyzed in a 3D numerical model of a ballasted track when included in a railway track. An empirical model was implemented and calibrated to predict the long-term permanent deformation induced in the track after many train passages. The results are compared with the allowable deformation limits required for conventional high-speed ballasted track railway lines. An additional analysis was conducted to assess the influence of steel slags on the critical speed of conventional railway tracks when used. The results show a residual impact on the critical speed value compared to the conventional sub-ballast made with natural aggregates. Full article

The use of raw materials from the recovery of construction waste is frequent. In this study, the waste is obtained from degraded railway ballast, made up of siliceous minerals. This material is added directly to the mixtures to replace part of the cement, forming a good quality cementitious product. The pozzolanic reaction is studied within the waste/lime system in a solid phase and water system for one year. Reaction products such as stratlingite, layered double hydroxide-type compounds, hydrated tetracalcic aluminate, and gels appear. The formation of stratlingite and gels was favored throughout the reaction. The reaction was monitored, calculating the saturation index. Full article

This study assesses and compares lifecycle (LC) greenhouse gas (GHG) emissions from the two main railway track construction types: ballasted track and slab track. In this study, preexisting soil conditions are considered, as they significantly influence necessary measures during the construction phase for each type. This study is executed for Austrian boundary conditions with speeds up to 250 km/h. The results show that ballasted track is associated with 11–20% lower LC GHG emissions, whereby the variation in relative emission reduction is associated with additional soil reinforcement treatments due to varying preexisting soil conditions. Poor preexisting soil conditions increase LC GHG emissions by 26%, underlying the necessity to integrate this parameter into the lifecycle assessment of railway track. In contrast to the higher service life of slab track construction, this type amounts to higher masses of concrete and demands more extensive measures for soil enhancement due to the higher stiffness of the track panel. Only in tunnel areas does slab track cause lower GHG emissions since soil reinforcements are not necessary due to an existing concrete base layer after tunnel construction. For both construction types, over 80% of the GHG emissions stem from material production. Hence, circular economy as well as innovations within steel and concrete production processes hold significant potential for reducing GHG emissions. Full article

The international commitment to achieve carbon neutrality in the next few decades has oriented human activities towards the preservation of natural and non-renewable resources. In this context, a great research effort has been devoted to the search for sustainable solutions for the infrastructure construction sector, based on a thorough assessment of the environmental impact (EI). In this regards, Life Cycle Assessment (LCA) is considered one of the main components of Environmental Impact Assessment (EIA) and, for a comprehensive analysis, all the costs incurred by stakeholders during the useful life of the infrastructure should also be taken into account, applying the Life Cycle Cost (LCC) methodology. So far, there is a lack of combined LCA and LCC analyses of railway projects to support a proper sustainable decision-making process at a project level. Therefore, this study aimed to contributed to this topic by determining the environmental effect and related costs of different planning and construction choices in terms of material and maintenance strategies. For this purpose, first, an LCA of typical railway infrastructures with a ballasted track was developed. The case study considered two different functional units of a double-track railway line: 1 km of embankment section and 1 km of a cut section, in straight alignment. After defining five alternative railway infrastructure scenarios with different materials (virgin or recycled material) and construction methods (e.g., lime stabilization), two different railway track maintenance approaches were analysed. SimaPro was used to analyse the case study, and the results were compared with those obtained using the PaLATE software, suitably adapted for use in the railway sector. Finally, a cost analysis was carried out using Life Cycle Cost (LCC) methodology for all the scenarios analysed. The results obtained in terms of EI and related costs of each scenario provide useful information, allowing a sustainable planning approach: as a general result, the initial construction phase always involves the larger part of the total environmental impact while the material production is the most polluting phase, reaching percentages always higher than 50% of the total. Full article

The current paper concerns the investigation of CC (Concrete Canvas), a unique building material from the GCCM (geosynthetic cementitious composite mat) product group. The material is suitable for trench lining, trench paving, or even military construction activities, while the authors’ purpose is to investigate the application of the material to road and railway substructure improvement. This research was carried out to verify the material’s suitability for transport infrastructure and its beneficial effects. The authors’ previous study reported that the primary measurements were puncture, compression, and the parameters evaluated in four-point bending (laboratory) tests. However, based on the results, finite element modeling was not feasible because the testing of the composite material in a single layer did not provide an accurate indication. For this reason, the material characteristics required for modeling were investigated. A unique, novel testing procedure and assembly were performed, wherein the material was loaded under quasi-realistic conditions with a crushed stone ballast sample and other continuous particle size distribution samples in a closed polyethylene tube. In addition, the deformation of the material following deformed bonding was measured by computed tomography scanning, and the results were evaluated. Full article

Environmental safeguards promote innovative construction technologies for sustainable pavements. On these premises, this study investigated four hot mix asphalt (HMA) mixtures—i.e., A, B, C, and D—for the railway sub-ballast layer with 0%, 10%, 20%, and 30% reclaimed asphalt pavement (RAP) by total aggregate mass and a rejuvenator additive, varying the bitumen content between 3.5% and 5.0%. Both Marshall and gyratory compactor design methods have been performed, matching the stability, indirect tensile strength, and volumetric properties of each mixture. Dynamic stiffness and fatigue resistance tests provided mechanical performances. Laboratory results highlighted that the RAP and the rejuvenator additive increase the mechanical properties of the mixtures. In addition, the comparative analysis of production costs revealed up to 20% savings as the RAP content increased, and the life cycle impact analysis (LCIA) proved a reduction of the environmental impacts (up to 2% for resource use-fossils, up to 7% for climate change, and up to 13% for water use). The experimental results confirm that HMA containing RAP has mechanical performances higher than the reference mixture with only virgin raw materials. These findings could contribute to waste management and reduce the environmental and economic costs, since the use of RAP in the sub-ballast is not, so far, provided in the Italian specifications for railway construction. Full article

Slags and rubber from end-of-life tires represent a liability to the steel and tire industry, causing economic and environmental problems that are difficult to manage. Transport infrastructures can use these industrial by-products instead of extracting natural raw materials, but the adequate mechanical performance of the materials needs to be assured. This paper addresses the mechanical behaviour of slag–rubber mixtures in the laboratory with CBR, monotonic and cyclic triaxial tests. In addition, light falling weight deflectometer tests were also performed in a physical model. The results were analysed to meet technical specifications from Brazil, Portugal and Australia using railway sub-ballast layers, capping layers or road pavement layers as the base and sub-base to identify the applicability range of slag–rubber mixtures for transport infrastructures. Concerning the analysed parameters, it was demonstrated that slag–rubber mixtures can show resilient behaviour and strength adequate for the support layers of transport infrastructures provided that the rubber content is below 5% in weight and that the slag is milled to comply with the grain size distribution ranges available in the technical specifications of the cited countries. Full article

Prestressed concrete sleepers are an important track component that is widely used in railway ballast track. Prestressed concrete sleepers have high strength, strong stability, and good durability; thus, their operation and use in railways are beneficial. However, in different countries and regions, certain damage to sleepers typically appears. Existing research on concrete sleepers focuses primarily on the structural design method, the application of new materials, theoretical analysis, and bearing strength test research, while ignoring sleeper damage. There are a few sleeper damage studies, but they look at only one type of damage; thus, there is no comprehensive study of prestressed concrete sleeper damage. The damage forms of prestressed concrete sleeper damage are thus summarized in this study, and the theory of the causes of prestressed concrete sleepers is analyzed based on the limit state method for the first time. The findings indicate that sleeper structure design is the primary cause of its operation and use status, and that special measures should be considered based on sleeper use conditions. In addition to meeting design requirements, materials, curing systems, product inspection, and other factors must be considered during manufacturing to improve the sleepers’ long-term performance. Keeping the track in good condition, including but not limited to the state of fasteners, ballast bed, and track geometry is also an important aspect of preventing sleeper damage. The outcomes of this study provide better insights into the influences of damage to railway prestressed concrete sleepers and can be used to improve track maintenance and inspection criteria. Full article

Prestressed concrete sleeper is a safety-critical track component widely used in ballasted railway tracks. The performance, endurance and quality of prestressed concrete sleepers can detrimentally affect the serviceability and durability of a railway track. An optimal production method is an important criterion underpinning quality and durability over the entire service life of prestressed concrete sleepers. At present, the research work of the sleeper mainly focuses on the dynamic load, bearing capacity and structural design method, etc. However, there exists a lack of research on the specific advantages and disadvantages of the sleeper production process and the improvement of the sleeper process research. This study is the world’s first to collect and analyse the technical data and characteristics of modern production methods of prestressed concrete sleepers, including the long-line system method, pre-tensioned long-mould flow method, pre-tensioned short-mould flow method, post-tensioned short-mould flow method and instant-demoulded short-mould flow method. The precautions for these prestressed concrete sleepers are highlighted in the paper as well. The research results show that the long-line system method, pre-tensioned short-mould flow method, post-tensioned short-mould flow method and instant-demoulded short-mould flow method have a higher automation level and lower efficiency than the pre-tensioned long-mould flow method. The production method of the pre-tensioned long-mould flow method has high efficiency and low cost of equipment, but more workers are needed. Through a comparative analysis, this paper also determines the environmental impacts and provide new references and suggestions for the development and progress of sleeper production technologies. Full article

The characterization of a quarry site which is suitable for railway ballast aggregate production represents a big challenge for the mining industry. The knowledge of structural discontinuities within local geological materials is fundamental to guide mining operations, optimize investments, and guarantee quarry security. This research work presents an innovative methodology for the subsurface investigation of a quarry excavation area down to a depth of about 50 m in Falconara Albanese, Calabria, Italy. The proposed methodological approach incorporates photogrammetry, drone technology, and GPR data acquisition and processing. Photogrammetry represents the first step for obtaining a 3D topographical model reconstruction of the whole quarry, helping to detail the acquisition approach and properly plan the subsequent drone survey. In particular, two 120 MHz antennas have been mounted on the drone and two profiles have been acquired above and across the quarry. Results show the presence of fractured material and demonstrate the applicability of the method for identification of areas that are more suitable for railway ballast production. The presented method is therefore capable of detecting subsurficial fractures at a quarry site by means of a relatively fast and cost-effective procedure. Results are achieved within the framework of an industry project. Full article

Railway tracks are conventionally built on compacted ballast and structural fill layers placed above the natural (subgrade) foundation. However, during train operations, track deteriorations occur progressively due to ballast degradation. The associated track deformation is usually accompanied by a reduction in both load bearing capacity and drainage, apart from imposing frequent track maintenance. Suitable ground improvement techniques involving plastic inclusions (e.g., geogrids) and energy absorbing materials (e.g., rubber products) to enhance the stability and longevity of tracks have become increasingly popular. This paper presents the outcomes from innovative research and development measures into the use of plastic and rubber elements in rail tracks undertaken at the University of Wollongong, Australia, over the past twenty years. The results obtained from laboratory tests, mathematical modelling and numerical modelling reveal that track performance can be improved significantly by using geogrid and energy absorbing rubber products (e.g., rubber crumbs, waste tire-cell and rubber mats). Test results show that the addition of rubber materials can efficiently improve the energy absorption of the structural layer and also reduce ballast breakage. Furthermore, by incorporating the work input parameters, the energy absorbing property of the newly developed synthetic capping layer is captured by correct modelling of dilatancy. In addition, the laboratory behavior of tire cells and geogrids has been validated by numerical modelling (i.e., Finite Element Modelling-FEM, Discrete Element—DEM), and a coupled DEM-FEM modelling approach is also introduced to simulate ballast deformation. Full article

Railway ballast, for which natural crushed stone aggregates have been generally used, is an essential track component for the distribution of train loads along the rails and sleepers to the roadbed. However, the use of natural crushed stone aggregate causes environmental destruction as well as dust production in train service. This paper evaluates the feasibility of using the basic oxygen furnace (BOF) steel slag as railway ballast material. A series of physical and chemical quality tests are performed to investigate the characteristics of the materials associated with the effect of aging period due to the remaining free CaO and MgO in the BOF steel slag. Three different aging periods (i.e., 0, 3, and 6 months) are used to compare with various standards and the properties of the crushed stone aggregates. It is demonstrated that the physical and chemical properties of the BOF steel slag with different aging periods satisfy all requirements of standards sufficiently. Especially, the BOF steel slag without aging (i.e., 0 month) provides the similar physical and chemical properties, when compared to the BOF steel slag with aging (i.e., 3 and 6 months). Thus, it is possible to apply the BOF steel slag regardless of aging periods to the railway ballast materials instead of natural crushed stone aggregates. Full article

Elastic elements such as rail pads, under sleeper pads and under ballast mats are railway components that allow for a reduction in track deterioration and vibrations. And they are furthermore commonly used to obtain an optimal vertical stiffness of the infrastructure. However, the use of elastomeric materials can increase construction costs and the consumption of raw materials. Thus, the utilization of used tire layers offers an alternative to reuse an abundant waste reducing the cost of elastic elements. In addition, an innovator technique allows deconstructing tire layers without grinding up the material, reducing production costs at the same time that tire properties are remained. This research is focused on the study of the viability of developing elastic components from used tire layers by evaluating the influence of thickness, the resistance capacity of the elements and their behavior in a ballast box. Results indicate the ability of tire pads to manufacture elastic elements (rail pads, under sleeper pads and under ballast mats) to be used in railway tracks. Full article
