Search Results (40)

Electric Vehicles (EV) significantly contribute to reducing carbon emissions and promoting sustainable transportation. Among EV technologies, hybrid energy storage systems (HESS), which combine fuel cells, power batteries, and supercapacitors, have been widely adopted to enhance energy density, power density, and system efficiency. Bidirectional DC-DC converters are pivotal in HESS, enabling efficient energy management, voltage matching, and bidirectional energy flow between storage devices and vehicle systems. This paper provides a comprehensive review of bidirectional DC-DC converter topologies for EV applications, which focuses on both non-isolated and isolated designs. Non-isolated topologies, such as Buck-Boost, Ćuk, and interleaved converters, are featured for their simplicity, efficiency, and compactness. Isolated topologies, such as dual active bridge (DAB) and push-pull converters, are featured for their high voltage gain and electrical isolation. An evaluation framework is proposed, incorporating key performance metrics such as voltage stress, current stress, power density, and switching frequency. The results highlight the strengths and limitations of various converter topologies, offering insights into their optimization for EV applications. Future research directions include integrating wide-bandgap devices, advanced control strategies, and novel topologies to address challenges such as wide voltage gain, high efficiency, and compact design. This work underscores the critical role of bidirectional DC-DC converters in advancing energy-efficient and sustainable EV technologies. Full article

The COVID-19 pandemic has precipitated several challenges, prompting the Indonesian government to enact rules aimed at minimizing direct contact to mitigate the spread of COVID-19, which has also affected transactional activities. Transactions conducted using a digital wallet represent a technological advancement that facilitates a cashless society lifestyle. Bank Indonesia established the Quick Response Code Indonesian Standard (QRIS) as a QR Code standard for digital payments using Electronic Money-Based (EU) servers, electronic wallets, or Mobile Banking. This study aims to identify the elements that affect consumer willingness to convert from cash payments to the QRIS during the COVID-19 epidemic. This study collected data through an online survey, distributing a 17-item questionnaire to QRIS users, yielding 568 valid responses. This research used a modified version of the Push-Pull-Mooring theory and an adaptation of the Unified Theory of Acceptance and Use of Technology (UTAUT2) model, concentrating on consumers’ intentions to transition from cash payments to QRIS utilization. This study employed the Hybrid SEM-ANN methodology with the SmartPLS and IBM SPSS Statistics 27 applications for data analysis. This investigation had 11 hypotheses, of which 4 were accepted. The findings indicated that alternative attractiveness, trust, critical mass, and traditional payment habits significantly influenced the intention to transition from cash payments to QRIS payments during the COVID-19 pandemic. Full article

Power converters are the basic elements of any power electronics system in many areas and applications. Among them, the push–pull converter topology is one of the most widespread due to its high efficiency, versatility, galvanic isolation, reduced number of switching devices and the possibility of implementing high conversion ratios with respect to non-isolated topologies. Optimal design and control requires very accurate models that consider all the non-idealities associated with the actual converter. However, this leads to the use of high-order models, which are impractical for the design of model-based controllers in real-time applications. To obtain a trade-off model that combines the criteria of simplicity and accuracy, it is appropriate to assess whether it is necessary to consider all non-idealities to accurately model the dynamic response of the converter. For this purpose, this paper proposes a methodology based on a sensitivity analysis that allows quantifying the impact of each non-ideality on the converter behaviour response as a function of the converter topology, power and frequency. As a result of the study, practical models that combine the trade-off between precision and simplicity are obtained. The behaviour of the simplified models for each topology was evaluated and validated by simulation against the most complete and accurate non-ideal model found in the literature. The results have been excellent, with an error rate of less than 5% in all cases. Full article

This paper proposes a fast transient load response capacitor-less low-dropout regulator (CL-LDO) for digital analog hybrid circuits in the 180 nm process, capable of converting input voltages from 1.2 V to 1.8 V into an output voltage of 1 V. The design incorporates a rail-to-rail input and push–pull output (RIPO) amplifier to enhance the gain while satisfying the requirement for low power consumption. A super source follower buffer (SSFB) with internal stability is introduced to ensure loop stability. The proposed structure ensures the steady-state performance of the LDO without an on-chip capacitor. The auxiliary circuit, or transient enhancement circuit, does not compromise the steady-state stability and effectively enhances the transient performance during sudden load current steps. The proposed LDO consumes a quiescent current of 47 µA and achieves 25 µV/mA load regulation with a load current ranging from 0 to 20 mA. The simulation results demonstrate that a settling time of 0.2 µs is achieved for load steps ranging from 0 mA to 20 mA, while a settling time of 0.5 µs is attained for load steps ranging from 20 mA to 0 mA, with an edge time of 0.1 µs. Full article

Power converters are a basic element for the control and design of any power electronic system. Among the many available topologies, the push–pull converter is widely used due to its versatility, safety and efficiency. For its correct analysis, sizing, simulation and control, models that meet the characteristics of generality, accuracy and simplicity are required, especially if its control is to be optimized by means of some analytical technique. This requires models that consider the practical non-idealities intrinsic to the converter, as well as being intuitive and easy to handle analytically in a control loop. In general, the models reviewed in the scientific literature adopt simplifications in their definition that are detrimental to their accuracy. In response to the posed problem, this work presents a generalized, complete, accurate and versatile model of real (non-ideal) push–pull converters, ideal for the analysis, simulation, and control of power systems. Following the premise of general and complete converters, the proposed model includes all the practical non-idealities of the converter elements, and it is accurate because it faithfully reflects its dynamics. Furthermore, the model is versatile, as its state space formulation allows for its easy adaptability to the converter operating conditions (voltage, current and temperature) for each sampling time. Also, the model is excellent for use in model-based control techniques, as well as for making very accurate simulators. The behavior of the developed model has been contrasted with a real push–pull converter, as well as with reference models present in the scientific literature for both dynamic and steady-state response tests. The results show excellent performance in all the studied cases, with behavior faithful to the real converter and with relative errors that are much lower than those obtained for the reference models. It follows that the model behaves like a digital twin of a real push–pull converter. Full article

This paper presents a new control method for a bidirectional DC–DC LLC resonant topology converter. The proposed converter can be applied to power the conversion between an energy storage system and a DC bus in a DC microgrid or bidirectional power flow conversion between vehicle-to-grid (V2G) behavior and grid-to-vehicle (G2V) behavior. Furthermore, such a converter can be applied to energy storage systems for decentralized renewable energy generation systems, such as solar and wind power. In addition, this converter can be combined with a bidirectional inverter to allow energy storage in the system to improve the safety, stability, and power quality of the microgrid. In the proposed circuit structure, we use a bidirectional DC–DC LLC, which has the advantages of a higher voltage conversion ratio, lower part count, simpler control than similar converters such as DAB, CLLC, and L–LLC converters, and bidirectional power flow and electrical isolation. Specifically, to extend the battery life, it can be employed as a control strategy for discharging the energy stored in the battery (SOC) and reducing the temperature rise generated by the internal solid electrolyte interphase (SEI) when discharging the battery under the variation in distributed energy resource (DER) generation and load demand. To realize the bidirectional power conversion without using any auxiliary inductor and only changing the control strategy, the forward step-down power conversion was based on pulse frequency modulation (PFM) control, and the reverse step-up power conversion was based on pulse width modulation (PWM) control. In this paper, we introduce the bidirectional converter topology and its control strategy for the DC microgrid battery energy storage system. Finally, a 500 W prototype is built to verify the effectiveness of the proposed converter. Full article

This paper aims to investigate the state-of-the-art isolated high-step-up DC–DC topologies developed for photovoltaic (PV) systems. This study categorises the topologies into transformer-based and coupled inductor-based converters, as well as compares them in terms of various parameters such as component count, cost, voltage conversion ratio, efficiency, voltage stress, input current ripple, switching mode, and power rating. The majority of the topologies examined exhibit peak efficiencies of 90% to 97%, with voltage conversions in excess of eight, as well as power ratings ranging from 100 W to 2 kW. The existing literature has found that most isolated DC–DC converters increase their turn ratios in order to achieve high step-up ratios. As a result, voltage spikes have increased significantly in switches, resulting in a decrease in overall system efficiency. In this research, the use of passive and active snubbers to provide soft switching in isolated step-up DC–DC converters is investigated. Moreover, a comprehensive analysis of the three most widely used boost techniques is provided. A reduction in turn ratio and a decrease in voltage stress were the results of this process. The main purpose of this study is to provide a comprehensive overview of the most used high-boost isolated DC–DC topologies in PV systems, including flyback, isolated SEPIC, forward, push-pull, half- and full-bridge, and resonant converter, with a focus on the recent research in the field and the recent advancements in these topologies. This study aims to guide further research and analysis in selecting appropriately isolated topologies for PV systems. Full article

This work presents a modified version of the current-fed dc–dc push–pull converter associated with an active clamping circuit for mitigating voltage spikes on the primary-side switches. Unlike the traditional push–pull topology, saturation due to asymmetrical gating signals applied to the active switches is not likely to occur in the high-frequency transformer because the converter allows for connecting a blocking capacitor in series with the primary winding. In addition, the leakage inductance will not cause high voltage spikes on the primary-side semiconductors owing to the clamping capacitors. Since all active switches operate under the zero-voltage switching (ZVS) condition, one can obtain a high efficiency over a wide load range when comparing the structure with its hard-switching counterpart. Experimental results obtained from a laboratory prototype rated at 1 kW are presented and discussed to validate the theoretical claims. Full article

This paper presents a versatile, low-cost real-time control platform with embedded isolated inputs and outputs for direct usage in electrical applications. The inputs correspond to voltage and current measurements, while the outputs are digital signals with isolated power supply. The validation for the platform considers the implementation of the power electronics topologies where the control algorithms are implemented in Simulink. The topologies are the interleaved three-phase buck converter, push–pull converter, H-bridge, and thyristor-based AC load controller. The control for them involves voltage feedback, current feedback, linear control algorithms, and the implementation of a discrete PLL algorithm for the last topology. Hence, the platform demonstrates the effectiveness of performing real-time control for some power electronics topologies. Full article

Amplifiers are among the most commonly used circuits in electronics, performing a variety of functions in a wide range of electronic systems. Depending on the application and design, each amplifier generates waste heat. For power amplifiers that operate at low efficiency and high output power, the amount of wasted energy can be significant. This paper presents an energy harvesting system based on the application of thermoelectric generators on the output transistors of the AB-Class power amplifier. The converted electrical energy can be used in several ways, feeding the energy back into the power supply (increasing the “efficiency”) or powering surrounding sensors and sub-circuits. In this work, a comparative analysis of the successfully converted energy obtained from different generator models in various thermal configurations was carried out. All measurements are performed on an experimentally established setup. Due to the low thermoelectric efficiency of the generators as well as the realized low temperature gradient, only 0.84% of the waste heat can be converted into electrical energy in the best case scenario. Finally, a new thermal push–pull concept was presented, the main purpose of which is to generate additional energy and protect semiconductor components from overheating. Full article

Over the last few years, the study of the SARS-CoV-2 spike protein and its mutations has become essential in understanding how it interacts with human host receptors. Since the crystallized structure of the spike protein bound to the angiotensin-converting enzyme 2 (ACE2) receptor was released (PDB code 6M0J), in silico studies have been performed to understand the interactions between these two proteins. Specifically, in this study, heterocyclic compounds with different chemical characteristics were examined to highlight the possibility of interaction with the spike protein and the disruption of the interaction between ACE2 and the spike protein. Our results showed that these compounds interacted with the spike protein and interposed in the interaction zone with ACE2. Although further studies are needed, this work points to these heterocyclic push–pull compounds as possible agents capable of interacting with the spike protein, with the potential for the inhibition of spike protein–ACE2 binding. Full article

The effects of partial shading or dust accumulation on the panels of photovoltaic systems connected to the grid can generate a considerable reduction in energy performance, being necessary to provide the appropriate voltage to the grid regardless of the irradiance level. This paper addresses this problem and presents a comprehensive control strategy and its implementation for a grid-connected microinverter composed of a push–pull converter followed by an H-bridge inverter. In the push–pull converter, a hybrid MPPT algorithm and a PI control enable work in the MPP of the PV panel. In the H-bridge inverter, a cascade control consisting of a PI control and a predictive control allows the connection to the grid. A proof-of-concept prototype is implemented in order to validate the proposal. Experimental tests were performed by connecting the microinverter to a PV panel and a programmable photovoltaic panel emulator to check the MPPT performance. Furthermore, partial shading conditions were simulated on the dc source to check if the global maximum power point is reached. Experimental results demonstrate the feasibility of the topology and the control approach, obtaining MPPT performance in the topology above 99% at different power and voltage levels on the MPPT, even in the presence of partial shading conditions. Full article

In this paper, a novel soft switching push-pull LC resonant DC-DC converter for energy sources is presented. In a high step-up converter, the input of primary side possesses low voltage and high current, so the losses caused by the current account for most of the total power loss. At the same time, the high-voltage stress of the high-voltage output components on the secondary side is also a major problem. Therefore, a high-gain isolated push-pull converter with a secondary-side resonant circuit is proposed, so that the primary-side switches have zero voltage switching (ZVS) and the secondary-side diodes have zero current switching (ZCS). The push-pull structure can reduce the number of active switches, so that the total power loss on the primary side can be reduced. The converter has a resonant tank circuit arranged between the secondary side of isolation transformer and the high-voltage output rectification module. The high-voltage output rectifier module adopts a full-bridge architecture suitable for high-voltage coupling connection. The low-side power switching module adopts a push-pull architecture suitable for low-voltage and high-current applications. The resonant tank circuit uses an inductor–capacitor (LC) structure to improve the resonant tank circuit, which achieves soft switching during power transfer, increasing the efficiency of the converter and improving the electromagnetic compatibility. The main advantage of this technology is that the secondary-side leakage inductance of transformer and the resonant capacitance are connected in series to achieve ZVS for switches and ZCS for diodes. Finally, a prototype of a high-gain push-pull resonant converter was established. The converter was operated at a fixed switching frequency of 135 kHz and a duty cycle of approximately 0.5. The efficiency of the converter can reach 97.1% under experimental tests at an output voltage of 400 V and a rated output power of 500 W. Full article

This paper is intended to examine the efficiency of utilizing the FRP composite material with an externally bonded technique in enhancing the behavior of the damaged B-C joints and controlling their failure mode using the NLFEA approach. At first, the modeled Beam-Column joint was validated as per the previously-attained experimentally-attained results. Later, the model was widened to experiment with the impact of axial-column load and the concrete compressive strength on the reinforced and un-reinforced models with FRP. To run the experiment, there were three cases of applying the axial column load: no load applied (0%), applying 25%, applying 50%, and applying 75%, while the concrete compressive strength degradation level was (0% damage), (25% damage), and (50% damage). All models were evaluated for structural performance, considering: the failure mode, stresses distribution, and the ultimate capacities in pulling and pushing with its corresponding displacements. However, the horizontal load-displacement hysteretic loops and envelopes, stiffness degradation, displacement ductility, and energy dissipation were reported. The experimental results revealed that using FRP to externally-reinforce B-C joints improved overall cyclic performance, as the FRP caused a rise in the ultimate load capacity, horizontal displacement, ductility of displacement, and displacement energy dissipation, while it slowed down the stiffness degradation. In addition, the FRP material converted the failure mode of the region between the joint and column from brittle to ductile due to the formation of a plastic hinge only on the side of the beam when the axial column load exceeded 25%. It must be noticed that when the column’s axial load is less than 25%, the ultimate capacity of axial load and resultant deflection is solely improved. However, it has been stated that increasing the column’s axial loading by 25% increases the resulting stiffness degradation by 3% for undamaged joints, which further increases by 16% for each increased damage level. In contrast, the absorbed energy is increased by 170% under axial loading, increasing by 25%, which is reduced to only one-fourth under the various damage levels. Generally, the resulting observations help specialized engineers retrofit appropriate B-C joints in already-standing buildings due to their accuracy. Full article

This paper presents a four-stage DC/DC converter with high precision and a small ripple utilized in an electronic power conditioner (EPC). The galvanically isolated four-stage topology contains four cascade connections: a buck circuit, a push–pull circuit, a power converter, and a voltage regulator. The push–pull switches, as well as the diodes in the output-side rectifier, operate in zero-voltage switching (ZVS) and zero-current switching (ZCS) modes at both switch off and switch on, which helps increase the efficiency. The maximum efficiency of the converter can reach 94.5%. The buck circuit and voltage regulator operate in a two-stage closed-loop condition and, thus, the precision is greater than 0.02%. Due to the voltage regulator, the ripple is less than 1 V when the output voltage reaches 7000 V. Full article
