Search Results (118)

The microstructure and mechanical properties of welded joints of API 5L X-52 steel plates cladded with AISI 316L-Si austenitic stainless steel were evaluated. The gas metal arc welding process with pulsed arc (GMAW-P) and controlled arc oscillation were used to join the bimetallic plates. After the root welding pass, buttering with an ERNiCrMo-3 filler wire was performed and multi-pass welding followed using an ER70S-6 electrode. The results obtained by optical and scanning electron microscopy indicated that the shielding atmosphere, welding parameters, and electric arc oscillation enabled good arc stability and proper molten metal transfer from the filler wire to the sidewalls of the joint during welding. Vickers microhardness (HV) and tensile tests were performed for correlating microstructural and mechanical properties. The mixture of ERNiCrMo-3 and ER70S-6 filler materials presented fine interlocked grains with a honeycomb network shape of the Ni–Fe mixture with Ni-rich grain boundaries and a cellular-dendritic and equiaxed solidification. Variation of microhardness at the weld metal (WM) in the middle zone of the bimetallic welded joints (BWJ) is associated with the manipulation of the welding parameters, promoting precipitation of carbides in the austenitic matrix and formation of martensite during solidification of the weld pool and cooling of the WM. The BWJ exhibited a mechanical strength of 380 and 520 MPa for the yield stress and ultimate tensile strength, respectively. These values are close to those of the as-received API 5L X-52 steel. Full article

Traditional narrow gap welding of thick titanium alloy plates easily produces dynamic molten pool flow instability, poor sidewall fusion, and excessive residual stress after welding, which leads to defects such as pores, cracks, and large welding deformations. In view of the above problems, this study takes 16-mm-thick TC4 titanium alloy as the research object, uses low-power pulsed laser-GTA flexible heat source welding technology, and uses the flexible regulation of space between the laser, arc, and wire to promote good fusion of the molten pool and side wall metal. By implementing instant ultrasonic impact treatment on the weld surface, the residual stress of the welded specimen is controlled within a certain range to reduce deformation after welding. The results show that the new welding process makes the joint stable, the side wall is well fused, and there are no defects such as pores and cracks. The weld zone is composed of a large number of α′ martensites interlaced with each other to form a basketweave structure. The tensile fracture of the joint occurs at the base metal. The joint tensile strength is 870 MPa, and the elongation after fracture can reach 17.1%, which is 92.4% of that of the base metal. The impact toughness at the weld is 35 J/cm², reaching 81.8% of that of the base metal. After applying ultrasound, the average residual stress decreased by 96% and the peak residual stress decreased by 94.8% within 10 mm from the weld toe. The average residual stress decreased by 95% and the peak residual stress decreased by 95.5% within 10 mm from the weld root. The residual stress on the surface of the whole welded test plate could be controlled within 200 MPa. Finally, a high-performance thick Ti-alloy plate welded joint with good forming and low residual stress was obtained. Full article

Welding of maraging steels leads to a microstructural gradient from base material (BM) to weld metal (WM). During post-weld heat treatment (PWHT) the precipitation and reverted austenite (γ_r) reactions will occur defining the mechanical properties. These reactions are affected by the microstructure and local chemical composition of each zone in the “as welded” (AW) condition. This effect has not been clearly described yet nor the evolution of the microstructure. The objective of this work was to analyse the phase transformations at the different zones of the welded joint during the PWHT to explain the microstructure obtained at each zone. Samples of C250 maraging steel were butt-welded by GTAW-P (Gas Tungsten Arc Welding—Pulsed) process without filler material. The AW condition showed an inhomogeneous microhardness profile, associated with a partial precipitation hardening in the subcritical heat affected zone (SC-HAZ) followed by a softening in the intercritical (IC-HAZ) and recrystallized heat affected zone (R-HAZ). A loop-shaped phase was observed between low temperature IC-HAZ and SC-HAZ, associated with γ_r, as well as microsegregation at the weld metal (WM). The microstructural evolution during PWHT (480 °C) was evaluated on samples treated to different times (1–360 min). Microhardness profile along the welded joint was mostly homogeneous after 5 min of PWHT due to precipitation reaction. The microhardness in the WM was lower than in the rest of the joint due to the depletion of Ni, Ti and Mo in the martensite matrix related with the γ_r formation. The isothermal kinetics of precipitation reaction at 480 °C was studied using Differential Scanning Calorimetry (DSC), obtaining a JMAK expression. The average microhardness for each weld zone was proposed for monitoring the precipitation during PWHT, showing a different behaviour for the WM. γ_r in the WM was also quantified and modelled, while in the IC-HAZ tends to increase with PWHT time, affecting the microhardness. Full article

During the cold metal transfer plus pulse (CMT+P) welding process of medium-thick plates, problems such as incomplete penetration (IP) and burn-through (BT) are prone to occur, and weld pool morphology is important information reflecting the penetration states. In order to acquire high-quality weld pool images under complex welding conditions, such as smoke and arc light, a welding monitoring system was designed. For the purpose of predicting weld penetration states, the improved Inception-ResNet prediction model was proposed. Squeeze-and-Excitation (SE) block was added after each Inception-ResNet block to further extract key feature information from weld pool images, increasing the weight of key features beneficial for predicting the penetration states. The model has been trained, validated, and tested. The results demonstrate that the improved model has an accuracy of over 96% in predicting penetration states of aluminum alloy medium-thick plates compared to the original model. The model was applied in welding experiments and achieved an accurate prediction. Full article

This study investigated the control of porosity during gas metal arc welding with pulsed arc (GMAW-P) of complex-phase 780 (CP780) galvanized steel. Due to the Zn coating on this type of steel, porosity forms during welding as a result of Zn vaporization. The objective was to optimize the welding parameters to minimize porosity with a design of experiments using an L9 orthogonal array to analyze the effects of peak current (I_p), pulse time (t_p), and pulse frequency (f) in high-speed welding conditions. The results showed that porosity was significantly reduced with a peak current of 313 A, a frequency of 10 Hz, and a pulse time of 10 ms, achieving ~0% porosity in the validation welding trials. A microstructural analysis identified allotriomorphic ferrite, Widmanstätten ferrite, acicular ferrite, bainite, and martensite in the heat-affected zone (HAZ). A predictive model to anticipate the percentage of porosity with an R² of 99.97% was developed, and an ANOVA determined the peak current as the most critical factor in porosity formation. Full article

One of the prospective methods of robotic welding with a consumable electrode in shield gas metal arc welding is the GMAW Rapid HF process (GRHF, HF-high frequency), in which welded joints with deep penetration welds are obtained thanks to the specially programmed welding characteristics of the arc. A pulsed frequency equalized to 5000 Hz was used to achieve consumable electrode arc stabilization and improve penetration. This work consists of two main sections, including the research and analysis of wire electrode melting and weld pool formation in the innovative GRHF process and its influences on joint strength and the economic advantages of welding. As a result of our research and strength tests, as well as an image analysis of phenomena occurring in the welding arc and weld pool, assumptions were developed about the use of the GRHF process, which is characterized by deep penetration welds without welding imperfections that reduce the quality of the welded joints and their strength. Welding conditions and parameters leading to welded joints characterized by high relative strength related to the weight of the used filler material were proposed. As a result of our research, it was found that the use of welding processes with deep penetration leads to material savings related to the reduced consumption of filler materials while maintaining the required high strength of welded joints. Savings of filler materials reaching 80% were achieved compared with hitherto used methods. At the same time, the maximum load-carrying capacity of welding joints was maintained. Full article

To address anisotropy challenges in electric arc-based additive manufacturing of Inconel 718 alloy, this study develops a novel wire feeding oscillated double-pulsed gas tungsten arc welding additive manufacturing method (DP-GTA-AM) enabling precise thermal-mass transfer control. Series of crack-free thin-walled Inconel 718 alloy parts were successfully obtained by this proposed approach, and the microstructure and mechanical properties of the parts were thoroughly studied. The results indicate that the microstructure changes from dendrites and cellular crystals in the bottom to equiaxed grains in the midsection and entirely equiaxed crystals in the top, resulting in notable grain refinement. With an average grain size of 61.76 μm and an average length of 83.31 μm of large angle grain boundaries, the density of the <001> direction reaches 19.45. The difference in tensile strength and ductility between the horizontal and the vertical directions decreases to 6.3 MPa and 0.38%, which significantly diminishes anisotropy. Fractographic analysis confirms quasi-cleavage failure with homogeneous dimple distribution, demonstrating effective anisotropy mitigation through controlled solidification dynamics. Full article

This research study aims to study and investigate the corrosion rate, hot tensile properties, and microstructures of SSDS 2507 and AISI 316 gas tungsten arc dissimilar weldments. Three separate samples were developed with frequencies of 2, 4, and 6 Hz using the pulse arc mode technique. The tensile characteristics were assessed at two distinct temperatures (27 °C and 350 °C) in order to examine the behavior of the welded structure. Mechanical characterization such as hardness measurement and corrosion behavior were studied. The metallurgical characteristics of pulsed and continuous current weldments were examined using microscopes (optical and scanning), revealing variations across different zones. At the 4 Hz pulse frequency, the material exhibited improved tensile qualities compared to constant arc welding. The microstructures indicated that the fusion zone in the pulsed arc weldment consisted of a balanced mixture of inter-granular austenite and ferrite phases. A better corrosion resistance rate of 0.0487 mm/year was observed in the pulsed arc weldment compared to both the SSDS2507 base metal and the constant arc weldment. Specifically, at a temperature of 27 °C, the ultimate tensile strength was 695 MPa, whereas at a temperature of 350 °C, the tensile strength was 475 MPa. The weld strength of the pulsed arc weldment exhibited a 15.8% improvement in comparison to the constant arc weldment. The surface hardness value increased to 240 HV compared to the constant arc weldment, which had an HV of 225. Full article

The welding of the bottom-locking structure in a detector receptacle plays an essential role in ensuring the safety of nuclear equipment. A pulsed TIG–laser hybrid welding method is proposed to address the problem of welding pores in locking structural parts. The effects of the pulse frequency on the escape of porosity and of porosity on the mechanical properties of the hybrid welding joint were investigated. The results were compared to those of direct current (0 Hz), showing that the pulse frequency affects the stability of the arc. With an increase in pulse frequency, the grain size of the fusion zone gradually decreases, and the flow in the middle area of the molten pool increases. This subjects bubbles in the molten pool to a thrust force, which causes the bubbles to escape to the surface of the molten pool. Compared with 0 Hz, the tensile strength of the joint increased by 67%. This provides a new solution for obtaining reliable welded joints for the bottom-locking structure of detector storage tanks. Full article

The synthesis of special photocatalysts of nanostructured functional ceramics (PNFC) under the ZKHM brand under the influence of concentrated solar radiation showed the effectiveness of these ceramic materials in multifunctional use, in particular as additives for coatings of welding electrodes. However, problems with producing these materials in solar ovens on an industrial scale did not allow the widespread use of this method. This problem was solved using the technique of PNFC synthesis, followed by activation by pulsed radiation generated by functional ceramics. The ceramic material obtained by this method under the brand name ZB-1 also showed its effectiveness when used as an additive in welding electrode coatings. A comparative analysis of the effectiveness of the actions of additives from the ZKHM and ZB-1 brands on the welding and technological properties of welding electrodes from the MR-3 brand was carried out. Comparative results for the formation of weld beads showed that beads with high-quality formation without external defects were achieved when surfaced with electrodes with additives from both brands at concentrations up to 1%. Also, at concentrations up to 1%, these additives increased the breaking length of the arc and the stability of arc welding. The different effects of these additives were observed in a comparative analysis of their impacts on the size of the visor at the end of the electrode, the coefficients of melting and surfacing, and the loss factor for fumes and splashing of electrode metal. Full article

Arc quenching has many advantages, including generating large amounts of heat in a short time, a self-quenching ability, and simple equipment. The electric arc energy from a TIG welding machine was used to modify the surface properties of S45C Carbon Steel Cylinders. The study focuses on the impact of arc length, current intensity, travel speed, gas flow rate, heating angle, and pulse on surface hardness after arc quenching an S45C steel tube with a cylinder surface. The study found that the hardness reduces from 45.1 HRC to 41.2 HRC as the current intensity increases from 125 A to 140 A. According to Taguchi’s results, the ranking of factors which have the greatest impact on surface hardness are pulse time, travel speed, intensity, gas flow rate, arc length, and heating angle. The pulse time has the highest impact because it directly influences the heating input, followed by the travel speed. Arc length and heating angle, on the other hand, have the least effect. The base metal, heat-affected area, and hardened area are the three distinct areas that make up the microstructure structure. After the arc quenching process, the case hardening depth is represented by the heat-affected zone at 1536 μm. A highly colored residual austenite and a needle-shaped martensite phase make up the hardened region. The hardened region is 1200 μm thick and has a hardness of more than 300 HV0.3. The study’s findings may improve the application and understanding of the arc quenching treatment procedure in the industrial sector. Full article

Butt welding experiments on 6061 Al alloy and Q235B steel of 2 mm thickness were conducted using an ER4047F flux-cored wire as the filler metal, after adding a pulsed magnetic field into the process of cold metal transfer (CMT) welding. The effect of the pulsed magnetic field intensity on the macro morphology, microstructure, tensile strength and corrosion resistance of the welding–brazing joint was analyzed. The results showed that when the pulsed magnetic field intensity increased from 0 to 60 mT, the wettability and spreadability of the liquid metal were improved. As a result, the appearance of the Al alloy/steel joint was nice. However, when the pulsed magnetic field intensity was 80 mT, the stability of the arc and the forming quality of the joint decreased, which resulted in a deterioration in the appearance of the joint. A pulsed magnetic field with different intensities did not alter the microstructure of the joint. All of the joint was composed of θ-Fe₂(Al,Si)₅ and τ₅-Al_7.2Fe_1.8Si at the interface and Al-Si eutectic phase and α-Al solid solution at the weld seam zone. Actually, with the pulsed magnetic field intensity increasing from 0 mT to 60 mT, the IMC thickness in the interfacial layer gradually reduced under the action of electromagnetic stirring. Also, the grain in the weld seam was refined, and elements were distributed uniformly. But when the pulsed magnetic field intensity was 80 mT, the grain in the weld seam began to coarsen, and the intermetallic compound (IMC) thickness was too small, which was unfavorable for the metallurgical bonding of Al alloy and steel. Therefore, with the increase in pulsed magnetic field intensity, the tensile strength of the joints first increased and then decreased, and it reached its maximum of 187.7 MPa with a pulsed magnetic field intensity of 60 mT. Similarly, the corrosion resistance of the joint first increased and then decreased, and it was best when the pulse magnetic field intensity was 60 mT. The Nyquist plot and Bode plot confirmed this result. The addition of a pulsed magnetic field caused less fluctuation in the anode current density, resulting in less localized corrosion of the joint using the scanning vibrating electrode technique (SVET). The XPS analysis showed the Al-Fe-Si compounds replacing the Fe-Al compounds in the joint was the main reason for improving its corrosion resistance under the action of a pulsed magnetic field. Full article

This paper deals with the influence of micro-pulsed direct current on microstructure and mechanical properties of gas tungsten arc welding (GTAW) weldments of Ti-6Al-4V (Ti-64). Bead-on-plate GTA welds were made on the samples in the un-pulsed and micro-pulsed (125 Hz and 250 Hz) conditions. Post-weld heat treatment (PWHT) was performed on a few coupons at 700 °C for 3 h in an inert atmosphere, followed by furnace cooling. In the microstructure, the fusion zone (FZ), base metal (BM), and heat-affected zone (HAZ) can be easily distinguished. The top surface of the FZ has large columnar grains because of lower heat loss to the surrounding atmosphere, and the bottom region of the FZ has comparatively smaller equiaxed grains. The micro-pulsed samples’ FZ grain size was lower than that of those made without pulsing. This shows that high-frequency current has substantially refined prior β grains. The microstructure of the FZ is characterized by an acicular morphology composed of α, martensitic α′, and retained β phases. The FZ’s hardness was higher than the BM due to the presence of martensitic α′. Additionally, the hardness in the HAZ was elevated due to the formation of finer martensitic α′. Micro-pulsed DC welding led to improved mechanical properties, including higher hardness, ultimate tensile strength (UTS), and ductility compared to un-pulsed welding. This enhancement is attributed to the grain refinement achieved with micro-pulsed DC. After PWHT, the prior β grain size remained relatively unchanged compared to the as-welded condition. However, the hardness in the FZ decreased due to the decomposition of α′ into α and β phases. The ductility of all samples improved as a result of the widening of the diffusional α phase. Full article

As a result of the thermo-mechanical impact during welding, distortions are generated in welded structures. These distortions significantly influence the geometric and dimensional accuracy of welded structures, in many cases lowering their working characteristics and reliability. An optimal design for welded structures is a prerequisite for increased reliability and reduction in manufacturing cost, and such an optimal design can be achieved knowing the distortions in weldments. Despite the fact that pulsed metal inert gas welding and metal active gas welding have been broadly applied in the last few decades, nowadays, few manufacturers, for instance, Fronius, EWM, Redco, and Perfect Power Welders, offer such an option for manual arc welding. This work aims to determine the influence of the parameters of pulsed welding modes on distortions that are generated during manual arc welding. Two different inverter welding power sources were used, and the welding distortions were measured by 3D scanning. The results showed that the pulsed mode during manual arc welding led to a reduction in distortions compared to the conventional welding mode. The crucial part of the manual welding system proved to be the qualification and performance of the welder. Full article

Copper-based alloys are widely known for their high thermal and electrical conductivity. Although the use of these alloys in powder-based additive manufacturing (AM) shows significant promise, applying this method in wire arc additive manufacturing (WAAM) processes poses various considerable challenges, including porosity, delamination, surface oxidation, etc. The limited research on WAAM of copper alloys, especially Cu1897, highlights the need for a more in-depth investigation. This study addresses the effects of process parameters in pulse cold metal transfer (CMT)-based WAAM of Cu1897, i.e., pulse correction (PC) and arc length correction (ALC), on bead penetration and porosity. The results showed that as PC was increased from −5 to +5, weld bead penetration increased from 2.38 mm to 3.87 mm. To further enhance penetration and reduce the porosity, the ALC was varied from +30% to −30% with a step size of 15%. The results showed that weld bead penetration increased to 4.47 mm by altering the ALC from +30% to −30%. Additionally, as the ALC varied within this range, porosity decreased significantly from 3.98% to 0.28%. Overall, it is concluded that a lower value of ALC is recommended to improve bead penetration and reduce porosity in WAAM of Cu1897. Full article
