Search Results (37)

Achieving a best-fit prosthetic socket is essential to comfort, functional performance, and long-term residual limb health in lower-limb amputees. To our knowledge, no previous study has quantitatively compared in vivo residual limb geometry under vacuum versus non-vacuum conditions using high-resolution computed tomography (CT). In this patient-specific case study of a bilateral knee-disarticulation (KD) amputee, both residual limbs were scanned under standardized conditions: one enclosed in a vacuum-compressed sleeve and the contralateral limb untreated as a natural control, thereby minimizing inter-subject variability. CT-based 3D reconstructions enabled volumetric and cross-sectional quantification, including symmetry/asymmetry analysis of paired limbs, while finite element analysis (FEA) assessed the biomechanical consequences for socket performance. Vacuum application resulted in a 4.1% reduction in total limb volume and a 5.3% reduction in mid-thigh cross-sectional area, with regionally asymmetric displacement of soft tissues. FEA demonstrated that vacuum-induced geometry reduced peak Von Mises stresses (27.43 MPa to 15.83 MPa), minimized maximum displacement (1.72 mm to 0.88 mm), and improved minimum factor of safety (~2.0 to ~3.0), while homogenizing contact pressure distribution (peak fell from 2.42 to 1.28 N/mm²). These findings provide preliminary CT-based evidence that vacuum application induces measurable morphological adaptations with implications for socket conformity, comfort, and load transfer. While limited to a single patient, this study highlights the potential of vacuum-induced modeling to inform personalized prosthetic socket design. Full article

Background/Objective: Changes in limb volume affect prosthetic socket fit and limb health, which in turn affects the comfort, stability, and usability of a prosthesis. The objective of this research was to identify and evaluate residual limb fluid volume metrics that could be used to identify the need for a prosthetic socket modification or replacement. Methods: A prospective observational study was conducted with transtibial prosthesis users undergoing socket modification or replacement. Participants performed a morning and afternoon 20 min structured activity protocol and self-reported their average socket comfort and other health outcomes before and after their socket was modified or replaced. Limb fluid volume changes across the protocol were recorded using bioimpedance analysis. Results: Anterior region residual limb fluid volume loss was low when the socket comfort score was high. Participants with ESCS_ave increases of ≥2 points pre- to post-modification experienced less limb fluid volume loss post-modification minus pre-modification (mean +0.6%) compared to participants with ESCS_ave increases of <2 points (mean −0.9%) (p = 0.0002). Conclusions: The percentage of fluid volume in the anterior limb may be a useful quantitative metric to explore for the application of bioimpedance monitoring in clinical care, helping to identify when sufficient change has occurred such that a new socket is warranted. Full article

Limb amputation remains a significant global health issue, affecting millions of individuals annually. A substantial proportion of these patients struggle with the inadequate fit and discomfort of conventional prosthetic sockets, leading to diminished quality of life. Osseointegration surgery, a promising alternative, offers the direct skeletal attachment of bone, implant, and prosthetic, providing a more stable and functional interface. Osseointegration remains an emerging procedure, and while exact global figures are difficult to pinpoint, estimates suggest that over 10,000 patients worldwide have received osseointegration implants since the technique was first introduced. This perspective article analyzes recent advancements in the field of limb osseointegration, highlighting key achievements such as improved implant materials, surgical techniques, and comprehensive prosthetic integration strategies. Additionally, it explores future directions for development and discusses the latest research trends shaping the evolution of this field. Despite these developments, the widespread adoption of osseointegration faces significant barriers, including complications, limited access to multidisciplinary care, economic constraints, and the need for further long-term clinical evidence. In this paper, we present an extensive perspective on the current state of osseointegration, discuss the challenges impeding its broader implementation, and offer recommendations to address these obstacles, with the goal of enhancing patient outcomes and facilitating the integration of osseointegration into mainstream clinical practice. Full article

Standardizing socket design and maintaining a default socket alignment in transtibial prostheses are innovations that aim to simplify fitting procedures and reduce prosthetic service costs, particularly in low-income countries. Objectives: This study evaluated the Mercer Universal Prosthesis (MUP) with a standardized “neutral alignment” against custom-made conventional prostheses (CVPs). Methods: Twenty transtibial amputees (n = 20) completed gait assessments using their CVP and immediately after fitting with an MUP. Temporal–spatial and sagittal plane kinematics (hip, knee, and ankle angles) were analyzed, along with a gait symmetry index. Results: the MUP group reported a significant difference between the prosthetic and the intact limb for both hip and knee kinematics (p < 0.05), but there was no change in the CVP group. When compared with the sound limb in the MUP group, post hoc analysis showed that both hip flexion and the hip range of motion (ROM) in the MUP limb significantly increased by 5.7° and 7.3° (p = 0.002 and p < 0.001, respectively). Spatial and temporal gait parameters were comparable between the MUP and CVP groups, and gait symmetry showed no significant differences. The CVP showed greater symmetry in terms of hip (19%, p = 0.012) and knee flexion (8%, p = 0.026) compared to the MUP, while the MUP had higher plantarflexion symmetry (24.4%, p = 0.013). Conclusions: Immediately post fitting, MUP improved joint mobility in the prosthetic limb, potentially enhancing kinematics. While short-term benefits are evident, further research is needed to assess long-term gait adaptation and quality of life impacts. Full article

Our limb prostheses aim to restore Activities of Daily Living (ADLs) for amputees, with the socket being a critical component of trans-tibial prostheses influencing both comfort and functionality. Despite technological advancements, challenges such as fit, weight, and durability remain. This study investigates an additive manufacturing method for Total Surface Bearing (TSB) sockets, leveraging CT scans to create a Computer-Aided Design (CAD) and finite element (FE) model. Biomechanical behavior under static loading conditions were analyzed using FE analysis and resistive-based pressure sensors. The study found consistent pressure distribution across the residual limb, with deviations of 8.53 kPa and 4.46 kPa between FE analysis and experimental measurements. Mean pressures of 44.6 kPa and 22.11 kPa were observed under Full Body Weight (FBW) and Half Body Weight (HBW) conditions, respectively. The FE analysis demonstrated a uniform stress distribution in the prosthetic socket, with a maximum stress of 0.15 MPa and a deformation of 0.008 mm, highlighting the effectiveness of this approach in enhancing socket design. Full article

The socket is the most important, patient-specific element of a prosthesis. Conventionally, the process of making a custom socket involves manually rectifying a plaster model of the residual limb. This process is time-consuming and often inconsistent among prosthetists because it is based on implicit knowledge. Hence, the aim of this work was to describe a novel process of generating a prosthetist-specific, digital “global” template and to illustrate that it can be automatically applied to rectify the shape of a transtibial residual limb. The process involved (1) the acquisition of a “training” dataset of unrectified and rectified positive models through manual data collection and digital 3D scanning, and (2) the unsupervised learning of the prosthetist’s rectifications by an artificial intelligence (AI) algorithm. The assessment of the process involved (1) evaluating whether the rectification rule learned by the AI was consistent with the prosthetist’s expectations, and (2) evaluating the template feasibility by applying the AI rectification process to a new residual limb and comparing the results to the prosthetist’s manual rectification for the same residual limb. The results suggest that the AI-rectified positive was consistent with the approach described by the prosthetist, with only small radial and angle errors and similar dimensions (volume and cross-sectional perimeters) as the hand-rectified positive. This study provides a proof-of-concept of the ability to integrate an AI algorithm into the fabrication process for transtibial prosthetic sockets. Once refined, this approach may provide a time-saving tool for prosthetists by automatically implementing typical rectifications and providing a good starting socket fit for individuals with amputation. Full article

Background: The company Ethnocare has developed the Overlay, a new pneumatic solution for managing volumetric variations (VVs) of the residual limb (RL) in transtibial amputees (TTAs), which improves socket fitting. However, the impact of the Overlay during functional tasks and on the comfort and pain felt in the RL is unknown. Methods: 8 TTAs participated in two evaluations, separated by two weeks. We measured compensatory strategies (CS) using spatio-temporal parameters and three-dimensional lower limb kinematics and kinetics during gait and sit-to-stand (STS) tasks. During each visit, the participant carried out our protocol while wearing the Overlay and prosthetic folds (PFs), the most common solution to VV. Between each task, comfort and pain felt were assessed using visual analog scales. Results: While walking, the cadence with the Overlay was 105 steps/min, while it was 101 steps/min with PFs (p = 0.021). During 35% and 55% of the STS cycle, less hip flexion was observed while wearing the Overlay compared to PFs (p = 0.004). We found asymmetry coefficients of 13.9% with the Overlay and 17% with PFs during the STS (p = 0.016) task. Pain (p = 0.031), comfort (p = 0.017), and satisfaction (p = 0.041) were better with the Overlay during the second visit. Conclusion: The Overlay’s impact is similar to PFs’ but provides less pain and better comfort. Full article

Prosthetic socket manufacturing is experiencing a revolutionary shift towards using digital methods, such as 3D scanning and 3D printing. However, using digital methods requires the clinician to transfer their skills from making sockets by hand to making sockets with a computer. This shift in practice may change the socket geometry and fit; however, to what extent is unknown. Thus, the aim of this study was to explore the feasibility of analyzing geometric and clinical differences between digitally- and manually-designed sockets. Nine adult inpatients with below-knee amputation were recruited. Two sockets were 3D printed for each participant from 3D socket models that were developed from: (1) 3D scanning a manually-modified hand-casted positive mold of the residuum; and (2) a digitally-modified 3D scan of the residuum. Manual and digital procedures were compared for three measures: final socket geometry, the Socket Comfort Score, and a patient experience survey. Feasibility data were collected to measure protocol implementation fidelity to inform a future larger study. These data revealed that 89% of participants followed the intended protocol, no participants dropped out, and only one adverse event was report. As no significant geometric differences were found and participants experienced similar comfort scores between manually- and digitally-designed sockets, study feasibility was determined to be successful. Thus, a randomized control trial study will be conducted to draw statistically relevant conclusions from these outcome measures that may provide meaningful information for improving digital design procedures. Full article

Achieving a comfortable socket residual limb interface is crucial for effective prosthetic rehabilitation, depending on the precise characterisation and fluctuations in the shape and volume of residual limbs. Clinicians rely on subjective and iterative methods for shaping sockets, often involving a trial-and-error approach. This study introduces a framework for measuring, analysing, and comparing residual limb shape and volume using scanned data to facilitate more informed clinical decision-making. Surface scans of 44 transtibial residual limb casts of various sizes and lengths were examined. All scans were spatially aligned to a mid-patella and subjected to analysis using a shape analysis toolbox. Geometric measurements were extracted, with particular attention to significant rectified regions during the cast rectification process. Following PTB guidelines, our analysis revealed substantial alterations, primarily in the mid-patella region, followed by the patellar tendon area. Notably, there was a significant volume change of 6.02% in the region spanning from mid-patella to 25% of the cast length. Beyond this point, linear cast modifications were observed for most amputees up to 60% of the cast length, followed by individual-specific deviations beyond this region. Regardless of residual limb size and length, the modifications applied to positive casts suggested categorising patients into five major groups. This study employs the AmpScan shape analysis tool, to comprehend the cast rectification process used for capturing and assessing the extent of rectification on patients’ residual limb casts. The clinical implications of our research are threefold: (a) the comparison data can serve as training resources for junior prosthetists; (b) this will aid prosthetists in identifying specific regions for rectification and assessing socket fit; (c) it will help in determining optimal timing for prosthetic fitting or replacement. Full article

Amputees typically experience changes in residual limb volume in their daily lives. It causes an uncomfortable fit of the socket by applying high pressure on the sensitive area of the residual limb or by loosening the socket. In this study, we developed a transfemoral prosthetic socket for above-the-knee amputees that ensures a good socket fit by maintaining uniform and constant contact pressure despite volume changes in the residual limb. The socket has two air bladders in the posterior femoral region, and the pneumatic controller is located on the tibia of the prosthesis. The pneumatic system aims to minimize unstable fitting of the socket and improve walking performance by inflating or deflating the air bladder. The developed socket autonomously maintains the air pressure inside the prosthetic socket at a steady-state error of 3 mmHg or less by adjusting the amount of air in the air bladder via closed-loop control. In the clinical trial, amputee participants walked on flat and inclined surfaces. The displacement between the residual limb and socket during the gait cycle was reduced by up to 33.4% after air injection into the socket. The inflatable bladder increased the knee flexion angle on the affected side, resulting in increased stride length and gait velocity. The pneumatic socket provides a stable and comfortable walking experience not only when walking on flat ground but also on slopes. Full article

Digitising prosthetic sockets and moulds is critical for advanced fabrication techniques enabling reduced lead times, advanced computer modelling, and personalised design history. Current 3D scanners are expensive (>GBP 5000) and difficult to use, restricting their use by prosthetists. In this paper, we explore the use and accuracy of smartphone photogrammetry (<GBP 1000) as an accessible means of digitising rectified socket moulds. A reversed digital twin method was used for evaluating accuracy, in addition to simplified genetic algorithms to identify an optimal technique. The identified method achieved an accuracy of 99.65% and 99.13% for surface area and volume, respectively, with an interclass coefficient of 0.81. The method presented is simple, requiring less than ten minutes to capture using twenty-six photos. However, image processing time can take hours, depending on the software used. This method falls within clinical limits for accuracy, requires minimal training, and is non-destructive; thus, it can be integrated into existing workflows. This technique could bridge the gap between digital and physical workflows, helping to revolutionise the prosthetics fitting process and supporting the inclusion of additive manufactured sockets. Full article

The design and fitting of prosthetic sockets can significantly affect the acceptance of an artificial limb by persons with lower limb amputations. Clinical fitting is typically an iterative process, which requires patients’ feedback and professional assessment. When feedback is unreliable due to the patient’s physical or psychological conditions, quantitative measures can support decision-making. Specifically, monitoring the skin temperature of the residual limb can provide valuable information regarding unwanted mechanical stresses and reduced vascularization, which can lead to inflammation, skin sores and ulcerations. Multiple 2D images to examine a real-life 3D limb can be cumbersome and might only offer a partial assessment of critical areas. To overcome these issues, we developed a workflow for integrating thermographic information on the 3D scan of a residual limb, with intrinsic reconstruction quality measures. Specifically, workflow allows us to calculate a 3D thermal map of the skin of the stump at rest and after walking, and summarize this information with a single 3D differential map. The workflow was tested on a person with transtibial amputation, with a reconstruction accuracy lower than 3 mm, which is adequate for socket adaptation. We expect the workflow to improve socket acceptance and patients’ quality of life. Full article

Achievement of fit between the residual limb and prosthetic socket during socket manufacture is a priority for clinicians and is essential for safety. Clinicians have recognised the potential benefits of having a sensor system that can provide objective socket-limb interface pressure measurements during socket fitting, but the cost of existing systems makes current technology prohibitive. This study will report on the characterisation, validation and preliminary clinical implementation of a low cost, portable, wireless sensor system designed for use during socket manufacture. Characterisation and benchtop testing demonstrated acceptable accuracy, behaviour at variable temperature, and dynamic response for use in prosthetic socket applications. Our sensor system was validated with simultaneous measurement by a commercial sensor system in the sockets of three transtibial prosthesis users during a fitting session in the clinic. There were no statistically significant differences between the sensor system and the commercial sensor for a variety of functional activities. The sensor system was found to be valid in this clinical context. Future work should explore how pressure data relates to ratings of fit and comfort, and how objective pressure data might be used to assist in clinical decision making. Full article

The well-established finite element method (FEM) has been used successfully to evaluate and develop medical devices for lower-limb prosthetics over recent decades. Most numerical models are based on a specific 3D geometry, which, although allowing for an accurate analysis of a specific case, may differ significantly from the target group that is often geometrically closer to the average residual limb. In order to address this issue, a generic numerical transtibial model was developed with the corresponding definitive socket and silicone liner. Three load cases were performed to analyse the applicability of the model: donning, single-leg stance, and the static P5 test according to ISO 10328. While the first two cases were used commonly in previous studies, the ISO test was only used in physical tests and not in a numerical environment. The results of the simulations in terms of contact pressure, as well as the relative deformation of the socket, fit into the range reported in the literature for similar boundary conditions, thus verifying the model in biomechanical terms. The generic transtibial model serves as a numerical tool for the relative comparison of different socket-liner designs prior to the fabrication, providing insights into results that are otherwise difficult to obtain. Full article

A suction or elevated vacuum prosthetic socket that loses vacuum pressure may cause excessive limb motion, putting the user at risk of skin irritation, gait instability and injury. The purpose of this research was to develop a method to monitor distal limb motion and then test a small group of participants wearing suction sockets to identify variables that strongly influenced motion. A thin plastic insert holding two inductive sensor antennae was designed and printed. Inserts were placed in suction sockets made for four participants who regularly used suction or elevated vacuum suspension. Participants wore a liner with a trace amount of iron powder in the elastomer that served as a distance target for the sensors. In-lab testing demonstrated that the sensed distance increased when participants added socks and decreased when they removed socks, demonstrating proper sensor performance. Results from take-home testing (3–5 days) suggest that research investigation into cyclic limb motion for sock presence v. absence should be pursued, as should the influence of bodily position between bouts of walking. These variables may have an important influence on suspension. Long-term monitoring may provide clinical insight to improve fit and to enhance suction and elevated vacuum technology. Full article
