Vortex tubes are used in specialized scenarios where conventional refrigeration systems are impractical, such as tool cooling in CNC machines. The internal flow within a vortex tube is highly complex, with numerous factors influencing its energy separation process, and the coefficient of performance for refrigeration is relatively low. To investigate the impact of nozzle type on energy separation performance, vortex tubes with straight-type, converging-type, and converging–diverging-type nozzles were designed. Numerical simulation was conducted to explore their velocity, pressure, and temperature distribution at an inlet pressure of 0.7 MPa and a cold mass fraction of 0.1~0.9. The cooling effect, temperature separation effect, cold outlet mass flow rate, and refrigeration capacity of vortex tubes were assessed. The converging–diverging nozzle increases the gas velocity at the nozzle outlet while it does not significantly enlarge the airflow velocity in the vortex chamber. As the cold mass fraction rises, the cooling performance and cooling capacity of three vortex tubes first increase and then decrease. The maximum cooling effect and cooling capacity of vortex tubes are achieved at cold mass fractions of 0.3 and 0.7, respectively. Under identical conditions, the vortex tube with a converging nozzle achieves the highest cooling effect with a temperature drop of 36.6 K, whereas the vortex tube with converging–diverging nozzles possesses the largest gas flow rate, and the cooling capacity reaches 542.4 W. The vortex tube with straight nozzles exhibits the worst refrigeration performance with a cooling effect of 33.6 K and a cooling capacity of 465.9 W. It is indicated that optimizing the nozzle structure of the vortex tube to reduce flow resistance contributes to enhancing both the gas velocity entering the swirl chamber and the resultant refrigeration performance. Full article

The primary atomization of planar liquid sheets near nozzle exits plays a critical role in the study of pressure-swirl atomizers, yet its intrinsic destabilization and breakup mechanisms remain insufficiently characterized due to the multi-scale nature of gas–liquid interactions, significantly limiting the predictive capacity of current widely adopted atomization models. This study utilizes three-dimensional direct numerical simulations (DNSs) with adaptive mesh refinement and the Volume-of-Fluid (VOF) method to examine the instability and disintegration of a spatially developing planar liquid sheet under operating conditions representative of aero-engine combustors (thickness $h=100 \mathsf{\mu }\mathrm{m}$, $We=2544$, $Re=886$). Adaptive grid resolution (minimum cell size $2.5 \mathsf{\mu }\mathrm{m}$) enables precise resolution of multi-scale interface dynamics while maintaining mass conservation errors below 0.1‱. High-fidelity simulations reveal distinct atomization cascades originating from the jet tip, characterized by liquid sheet roll-up, interface expanding, interface tearing, and ligament/droplet formation. Through extraction and surface characterization of representative shed liquid ligaments, we quantify temporal and spatial variations between ligaments propagating toward and away from the jet core region. Key findings demonstrate that ligament impingement on the liquid core serves as the dominant mechanism for surface wave destabilization, surpassing the influence of initial gas–liquid shear at the nozzle exit. Spectral analysis of upstream surface waves reveals a pronounced correlation between high-wavenumber disturbances and the mean diameter of shed ligaments. These results challenge assumptions in classical atomization models (e.g., LISA) by highlighting self-destabilization mechanisms driven by droplet–ligament interactions. This work provides critical insights for refining engineering atomization models through physics-based ligament diameter prediction criteria. Full article

With the widespread application of ozone technology in agricultural plant protection, developing an ozonated water atomizer that integrates efficient mixing and precise spraying has been recognized as a significant challenge. Swirling flow is considered a method to enhance hydrodynamics and mass transfer in gas–liquid mixing. This study innovatively combines an axial nozzle with a swirling mixing chamber, utilizing the negative pressure generated by the high-speed central airflow at the nozzle throat as the driving force for swirling mixing and initial atomization, completing mass transfer and preliminary atomization before the formation of the mist, thereby improving gas–liquid contact and mass transfer efficiency. Through numerical simulations, the impact of geometric parameters at key locations on the internal flow of the atomizer was analyzed. The optimized inlet diameter of the atomizer was found to be 9 mm, with a throat length of 3 mm and a self-priming hole diameter of 1.5 mm. Experimental results on droplet size and ozone droplet concentration verified that at the optimal spraying pressure of 0.6 MPa, a concentration of up to 3.73 mg·L⁻¹ with an average droplet size of 102 µm, evenly distributed, could be generated at a distance of 40 cm from the target. This work provides a technological framework for advancing precision ozone-based plant protection, aligning with global efforts to reduce agrochemical footprints through innovative application systems. It offers theoretical guidance and data support for the development and design of high-efficiency ozone atomizers in agricultural applications, aiming to minimize the use of agricultural chemicals and promote the growth of green plant protection technologies. Full article

Combustion instability is one of the prominent and unavoidable problems in the design of high-performance propulsion systems. This study investigates the heat release rate (HRR) responses in a triple-nozzle swirling nonpremixed combustor under various thermoacoustic self-excited instability modes. Dynamic pressure sensors and high-speed imaging were employed to capture the pressure oscillations within the combustion chamber and the characteristics of flame dynamics, respectively. The results reveal nonlinear bifurcations in the self-excited thermoacoustic instabilities at different equivalence ratios. Significant differences in flame dynamics were observed across the instability modes. In lower frequency modes, the fluctuations in flame length contribute to the driving force of thermoacoustic instability. In relatively high-frequency modes, HRR fluctuations are dominated by the rolling up and convective processes of wrinkles on the flame surface. Alternating regions of gain and damping are observed on the flame surface. At even higher frequencies, both aforementioned HRR fluctuation patterns are simultaneously observed. These findings provide a deeper understanding of the complex interactions between flame dynamics and thermoacoustic instabilities, offering new insights into the design and optimization of nonpremixed combustion systems. The study underscores the importance of considering the spatial and temporal variations in flame behavior to effectively predict and control thermoacoustic instabilities. Full article

Droplet size and distribution uniformity of sprinklers significantly affect production safety in the processes of steam temperature and pressure reduction within nuclear power, and other high-temperature, high-pressure industries. In industrial sprays with high flow rates and low pressure drops, reducing droplet size poses additional challenges, making improved spray uniformity essential for enhancing heat transfer. This study designed and produced a set of swirling-straight sprinklers, tested their flow characteristics and liquid distribution, and proposed a highly uniform spray mode involving swirl jet interaction mixing. The discharge coefficient (C_d) changes indicated that enlarging the jet channel area diminishes the amplification effect, suggesting a trade-off in industrial high flow sprinkler design. A detailed evaluation and analysis method of the spray process, which is superior to the use of a single uniformity parameter, is proposed based on Gaussian function peak fitting method. It has been observed that the relationship between the Gaussian fitting parameters and the pressure drop of the sprinkler tends to be linear. This discovery provides a new basis for designing nozzles with low pressure drop, high flow rates, and uniform distribution. The findings contribute to the optimization of spray performance and provide valuable data for computational fluid dynamics model verification. Full article

In this study, the authors carried out a multiparametric assessment of the influence of swirl patterns during aerosol flow on the shape of the interfacial area that forms the cone based on data obtained from experimental measurements using the PIV and LLS methods. The results were correlated with the disinfection process occurring in the near and far fields of the aerosol (direct surface disinfection and volume fogging). In this study, parameters such as turbulent kinetic energy (TKE), swirl strength (SS), pressure fields, and Sauter mean diameter (d₃₂) are used to investigate the relationship between aerosol spray morphology and flow dynamics under different operating conditions. Three different geometrical settings of the aerosol-generating system and two different pressures corresponding to the air supply to the spray nozzle have been adopted. By evaluating the results obtained, the influence of each parameter on the formation of the aerosol displacement trajectory, the stabilization of the spray cone, and its degradation was identified. The shape of the boundary between the dynamically moving aerosol and the surrounding air was also evaluated. The conditions for swirling and straight-line flows within the aerosol cone, and, thus, the conditions for the volumetric development of swirling phenomena, were further clarified. Full article

The supersonic swirling device is a new apparatus that can be used for natural-gas liquefaction. The structure of the supersonic swirling device has an important impact on the liquefaction efficiency. Therefore, this study presents a structural design method for supersonic cyclones based on CFD theory. Using the production parameters of a liquefied natural gas (LNG) peak-shaving station as the study case, a detailed design and design comparison of each part of the supersonic swirling separator are carried out. An optimum LNG supersonic swirling separator design was obtained. To ensure that the designed supersonic swirling separator achieved better liquefaction effectiveness, it was ascertained that no large shockwaves were generated in the de Laval nozzle, the pressure loss on the swirler was small, and the swirler was able to produce a large centripetal acceleration. The opening angle of the diffuser and the length of the straight tube were designed considering the location at which normal shockwaves were generated. The location at which shockwaves are generated and the friction effect are important parameters that determine the gap size. With this design guidance, the optimal structural dimensions of the supersonic swirling device for a given processing capacity were determined as follows: a swirler with six vanes and an 8 mm wide channel; a 10D-long straight tube, an opening angle of 20° between the straight tube and the divergent section, and a gap size of 2 mm. Compared with “Twister II”, the new device has better liquefaction efficiency. Full article

This study introduces a novel predictive model for atomization droplet size, developed using comprehensive data collected under elevated temperature and pressure conditions using a twin swirl airblast nozzle. The model, grounded in flow instability theory, has been meticulously parameterized using the Particle Swarm Optimization (PSO) algorithm. Through rigorous analysis, including analysis of variance (ANOVA), the model has demonstrated robust reliability and precision, with a maximum relative error of 19.3% and an average relative error of 6.8%. Compared to the classical atomization model by Rizkalla and Lefebvre, this model leverages theoretical insights and incorporates a range of interacting variables, enhancing its applicability and accuracy. Spearman correlation analysis reveals that air pressure and the air pressure drop ratio significantly negatively impact droplet size, whereas the fuel–air ratio (FAR) shows a positive correlation. Experimental validation at ambient conditions shows that the model is applicable with a reliability threshold of We₁/Re₁ ≥ 0.13 and highlights the predominance of the pressure swirl mechanism over aerodynamic atomization at higher fuel flow rates (q > 1.25 kg/h). This research effectively bridges theoretical and practical perspectives, offering critical insights for the optimization of airblast nozzle design. Full article

Enhancing thermal efficiency and minimizing weight are prevailing issues in aero engines. Owing to its hollow structure, the twin-web turbine disc exhibits remarkable weight reduction properties, while its enhanced cooling constitutes a novel challenge. In this study, a twin-web turbine disc cavity system is numerically investigated. To enhance the cooling effect and minimize pressure loss, a multi-objective genetic algorithm and Kriging surrogate model are employed to optimize the radial height of the pre-swirl nozzle and receiver hole in the disc cavity system. The results indicate that the overall performance of Opt-3, derived from the Technique for Order Preference by Similarity to the Ideal Solution method within the Pareto frontier, is superior. This configuration achieves a uniform low distribution of rotor temperatures while maintaining moderate pressure losses. Notably, the maximum temperature is reduced by 21.1 K compared to the basic model, with pressure losses remaining largely unchanged. Additionally, an increase in the flow ratio leads to a reduction in both the maximum temperature and average temperature of the back web while simultaneously increasing the temperature of the front web and augmenting pressure losses. However, it is important to note that the degree of variation in these parameters diminishes with increasing flow ratios. Full article

Spray drying of oil-in-water emulsions is a widespread encapsulation technique. The oil droplet size (ODS) significantly impacts encapsulation efficiency and other powder properties. The ODS is commonly set to a specific value during homogenization, assuming that it remains unchanged throughout the process, which is often inaccurate. This study investigated the impact of atomizer geometry and nozzle dimensions on oil droplet breakup during atomization using pressure-swirl atomizers. Subject of the investigation were nozzles that differ in the way the liquid is set in motion, as well as different inlet port and outlet orifice dimensions. The results indicate that nozzle inlet port area may have a significant impact on oil droplet breakup, with x_90,3 values of the oil droplet size distribution decreasing from 5.29 to 2.30 µm with a decrease of the inlet area from 2.0 to 0.6 mm. Good scalability of the findings from pilot to industrial-scale was shown using larger nozzles. A simplified theoretical model, aiming to predict the ODS as a function of calculated shear rates, showed reasonable agreement to the experimental data for different atomization pressures with coefficients of determination of up to 0.99. However, it was not able to predict the impact of different nozzle dimensions, most likely due to changes in flow characteristics. These results suggest that the stress history of the oil droplets might have a larger influence than expected. Further studies will need to consider other zones of high stress in addition to the outlet orifice. Full article

Currently, nasal administration of active pharmaceutical ingredients is most commonly performed using swirl-nozzle-based pump devices or pressurized syringes. However, they lead to limited deposition in the more active regions of the nasal cavity, especially the olfactory region, which is crucial for nose-to-brain drug delivery. This research proposes to improve deposition in the olfactory region by replacing the swirl nozzle with a nanoengineered nozzle chip containing micrometer-sized holes, which generates smaller droplets of 10–50 μm travelling at a lower plume velocity. Two nanotech nozzle chips with different hole sizes were tested at different inhalation flow rates to examine the deposition patterns of theophylline, a hyposmia treatment formulation, using a nasal cavity model. A user study was also conducted and showed that the patient instructions influenced the inhalation flow rate characteristics. Targeted flow rates of between 0 and 25 L/min were used for the in vitro deposition study, yielding 21.5–31.5% olfactory coverage. In contrast, the traditional swirl nozzle provided only 10.8% coverage at a similar flow rate. This work highlights the potential of the nanotech soft mist nozzle for improved intranasal drug delivery, particularly to the olfactory region. Full article

Pesticide application is an essential means of controlling plant diseases and pests in citrus orchards. In recent years, fixed spraying systems have gradually been used as alternatives to traditional sprayers and manual sprayers in some hilly citrus orchards. In this paper, influences of fixed system spraying parameters, such as droplet size and spraying height, on spraying quality were elucidated and analyzed. The performances of two nozzle types, pressure-swirl nozzles and fixed spray plate sprinklers, were assessed and compared by effective droplet coverage ratio (DCR), droplet distribution uniformity coefficient of variation (CV), and droplet penetration ratio (DPR). The results showed that appropriately increasing droplet size and spraying height could improve the DCR and distribution uniformity of pressure-swirl nozzles. The DCR and distribution uniformity of fixed spray plate sprinklers had a positive correlation with droplet size, while spraying height had no significant effect on these variables. Additionally, with the increase in droplet size, DPR initially increased and then gradually decreased. The optimized results showed that the optimal parameters for pressure-swirl nozzles were a droplet size of 240 μm and spraying height of 100 cm, while for fixed spray plate sprinklers, the results were a droplet size of 240 μm and spraying height of 50 cm. Comparison results showed that the spraying quality of fixed spray plate sprinklers was better overall, with values of DCR, CV, and DPR being 37.15%, 24.20%, and 71.67%, respectively, while the corresponding values for pressure-swirl nozzles were 39.65%, 35.41%, and 56.02%. Based on the above results and the occurrence rule of citrus pests and disease, the optimal spraying parameters of fixed spraying systems were selected to control the Asian citrus psyllid Diaphorina citri. Furthermore, the effect of fixed spraying systems on controlling Diaphorina citri reached the maximum at 3 days after spraying, which was 97.83%, and the effect declined at 14 days after spraying, which was 85.47%. This study provides valuable scientific references for guiding the application of fixed spraying systems in hilly citrus orchards. Full article

In modern civil aeroengines, the hot streak and swirl at the exit of the combustor have a significant impact on the aerothermal performance of the high-pressure turbine (HPT). Due to the different design purposes of the combustor and the turbine, hot streak (HS) and swirl (SW) have different spatial distributions at the turbine inlet. This paper conducts a transient simulation of the GE E3 first-stage HPT, considering the swirl and hot streak facing the middle of the passage and the leading edge of the nozzle guide vane, respectively, and also explores the impact of positive and negative swirl. The results show that different clocking positions and swirl directions will change the incident angle and streamline distribution of the vane, thereby affecting the migration of the hot streak, the temperature and the Nusselt number distribution on the stator surface. In positive cases, the hot streak gathers in the upper part of the passage, and in negative cases, it is in the lower part. In middle cases, high-temperature areas appear in both vanes, and the distributions are opposite. Affected by the swirl, when facing the passage center, the pressure side stagnation lines of the two vanes are also different, so the Nusselt number distribution is opposite. When facing the leading edge, only one vane appears. Due to the insensitive interference of the rotor–stator, the transient migration of the hot streak in the rotor is mainly affected by the inherent secondary flow and the temperature at the inlet of the rotor (especially the conditions facing the leading edge), while the upstream residual swirl is less affected. Unlike the middle case, in leading edge cases, the hot streak is separated and needs to be re-mixed before entering the blade passage, so the temperature change in the blade cascade is relatively gentle. Based on this, the Nusselt number distribution on the surface of the blade is similar. In order to obtain the most favorable operating conditions for the engine, the turbine efficiency is used to compare the aerothermal performance under different conditions. Ultimately, it was found that the turbine with the hot streak and positive swirl directly facing the leading edge was the most efficient. Full article

This study delves into the examination of internal flow characteristics within closed (with nozzles) and open-end pressure-swirl atomizers (lacking nozzles). The number of inlet channels “n” and the opening parameter “C” were manipulated in this study, as they play a pivotal role in understanding various atomizer attributes, such as uniformity of the air-core diameter, the discharge coefficient, spray angle, and more, all of which hold significance in the design of bipropellant atomizers for liquid rocket engines (LREs). To validate our findings, six distinct hexahedral meshes were generated using Ansys ICEM software 2023. Subsequently, we employed Ansys Fluent, considering the RNG k-ε turbulence model and the VOF (volume-of-fluid) multiphase model to identify the liquid–gas interface, to aid in analyzing the uniformity of the air core, which is directly linked to the even distribution of mass, the mixing ratio of propellants, combustion efficiency, and stability. The results indicate that the uniformity of the air core is not solely contingent on an increase in parameter “n” but is also influenced by an increase in the parameter “C”. It is worth noting that the key dimensions of these six atomizers were determined using a mathematical model based on Abramovich and Kliachko theories. Full article

A wide range of commercial powdered products are manufactured by spray drying emulsions. Some product properties are dependent on the oil droplet size, which can be affected by fluid mechanics inside the spray nozzle. However, most of the key flow parameters inside the nozzles are difficult to measure experimentally, and theoretical estimations present deviations at high shear rates and viscosities. Therefore, the purpose of this study was to develop a computational model that could represent the multiphase flow in pressure swirl nozzles and could determine the deformation stresses and residence times that oil droplets experience. The multiphase flow was modelled using the Volume-of-Fluid method under a laminar regime. The model was validated with experimental data using the operating conditions and the spray angle. The numerically calculated shear stresses were found to provide a better prediction of the final oil droplet size than previous theoretical estimations. A two-step breakup mechanism inside of the nozzle was also proposed. Additionally, some of the assumptions used in the theoretical estimations could not be confirmed for the nozzles investigated: No complete air core developed inside of the nozzle during atomization, and the shear stress at the nozzle outlet is not the only stress that can affect oil droplet size. Elongation stresses cannot be neglected in all cases. Full article
