Establishing digital twin scenes facilitates the understanding of geospatial phenomena, representing a significant research focus for GIS scientists and engineers. However, current research on digital twin scenes modeling relies on manual intervention or the overlay of static models, resulting in low modeling efficiency and poor standardization. To address these challenges, this paper proposes a knowledge graph-guided and multimodal data fusion-driven rapid modeling method for digital twin scenes, using bridge tower construction as an illustrative example. We first constructed a knowledge graph linking the three domains of “event-object-data” in bridge tower construction. Guided by this graph, we designed a knowledge graph-guided multimodal data association and fusion algorithm. Then a rapid modeling method for bridge tower construction scenes based on dynamic data was established. Finally, a prototype system was developed, and a case study area was selected for analysis. Experimental results show that the knowledge graph we built clearly captures all elements and their relationships in bridge tower construction scenes. Our method enables precise fusion of 5 types of multimodal data: BIM, DEM, images, videos, and point clouds. It improves spatial registration accuracy by 21.83%, increases temporal fusion efficiency by 65.6%, and reduces feature fusion error rates by 70.9%. Local updates of the 3D geographic scene take less than 30 ms, supporting millisecond-level digital twin modeling. This provides a practical reference for building geographic digital twin scenes. Full article

Existing 3D reconstruction algorithms commonly struggle with modeling specific local objects within large-scale scenes, often resulting in a lack of local detail and incomplete geometric structures. While current mainstream point cloud completion methods can restore these missing structures to some degree, they are fundamentally based on generative in-filling, a process that relies on geometric priors learned from large-scale datasets. Consequently, the physical realism and geometric accuracy of the results cannot be guaranteed. To address these limitations, this paper proposes a novel, data-driven framework for point cloud completion. Our core method involves the high-precision, heterogeneous data registration and seamless fusion of an object-level point cloud—reconstructed with high-fidelity appearance and geometry by our optimized Neural Radiance Fields (NeRF) framework—with our target large-scale scene point cloud. By using high-precision, physically based data as a strong prior for geometric completion, we offer an alternative route to conventional generative completion methods. Concurrently, we employ unsupervised evaluation metrics to assess the intrinsic quality of the final results. This work provides a robust and high-fidelity solution to the problem of completing local objects within large-scale scenes. Evaluated on our self-constructed UAV-Recon dataset, the proposed method achieved a Structural Plausibility ≥ 0.995, Geometric Smoothness ≤ 0.19, and Distribution Uniformity ≈ 1.2, offering a robust solution for the high-fidelity completion of local objects within large-scale scenes. Full article

Accurate point cloud registration is a fundamental prerequisite for reality-based 3D reconstruction and large-scale spatial modeling. Despite significant international progress, reliable registration in architectural and urban scenes remains challenging due to geometric intricacies arising from repetitive and strongly symmetric structures and photometric variability caused by illumination inconsistencies. Conventional ICP-based and color-augmented methods often suffer from local convergence and color drift, limiting their robustness in large-scale real-world applications. To address these challenges, we propose Hybrid Adaptive Residual Optimization (HARO), a unified framework that organically integrates geometric cues with hue-robust color features. Specifically, RGB data are transformed into a decoupled HSV representation with histogram-matched hue correction applied in overlapping regions, enabling illumination-invariant color modeling. Furthermore, a novel adaptive residual kernel dynamically balances geometric and chromatic constraints, ensuring stable convergence even in structurally complex or partially overlapping scenes. Extensive experiments conducted on diverse real-world datasets, including Subway, Railway, urban, and Office environments, demonstrate that HARO consistently achieves sub-degree rotational accuracy (0.11°) and negligible translation errors relative to the scene scale. These results indicate that HARO provides an effective and generalizable solution for large-scale point cloud registration, successfully bridging geometric complexity and photometric variability in reality-based reconstruction tasks. Full article

To address the accuracy calibration issue of the high-precision FMCW laser scanning measurement system for the large-aperture antenna of the Fengyun-4 microwave sounding satellite in orbit, this paper proposes a system calibration method based on space ranging correction. First, by analyzing the geometric structure and optical axis offset errors of the FMCW measurement system, a comprehensive error model comprising 13 key parameters was established. Second, a calibration field was constructed using a high-precision reference scale and planar targets. The spatial ranging correction method was employed to eliminate reliance on the accuracy of reference point coordinates inherent in traditional approaches, and nonlinear least-squares optimization was used to estimate the error parameters. Finally, a calibration scheme involving four operational conditions was implemented, with validation performed under three independent operational conditions. Experimental results show that the RMS error in relative distance between two points decreased from 17.5 mm to 2.3 mm after calibration. The ICP registration residual for the spatial point cloud was reduced to 2.5 mm, and point cloud shape fidelity improved by 86.6%. This validates the effectiveness and generalization capability of the proposed method. This research provides a reliable technical approach for spatial 3D calibration of lidar systems. Full article

Reliability assessment of conical shells in the chemical industry commonly relies on point cloud registration. Thus, accurate edge detection from 3D laser scan data is crucial for high-precision registration. However, existing edge detection methods often misclassify or omit gradual edge points on conical shell structures, significantly compromising registration accuracy and subsequent integrity assessment. This paper proposes an edge point detection method integrating Principal Component Analysis (PCA) and wavelet transform. First, characteristic curves are constructed by computing the ratio of PCA eigenvalues at all points to generate preliminary candidates for gradual edge points. Subsequently, distance vectors are calculated between the centroid of each characteristic curve and its sampled points. These vectors are then encoded via multi-level wavelet transform to produce mapping vectors that capture curvature variations. Finally, gradual edge points are discriminated effectively using these mapping vectors. Experimental results demonstrate that the proposed method achieves superior edge detection performance on complex conical shell surfaces and significantly enhances the accuracy of point cloud registration. Full article

In operations involving the replacement of shield machine disc cutters, challenges such as limited space, poor lighting, and slurry contamination frequently lead to occlusions and incomplete data when using direct point cloud-based localization for disc cutter bolts. To overcome these issues, this study introduces an indirect visual localization technique for bolts that utilizes image-point cloud fusion. Initially, an SCMamba-YOLO instance segmentation model is developed to extract feature surface masks from the cutterbox. This model, trained on the self-constructed HCB-Dataset, delivers a mAP50 of 90.7% and a mAP50-95 of 82.2%, which indicates a strong balance between its accuracy and real-time performance. Following this, a non-overlapping point cloud registration framework that integrates image and point cloud data is established. By linking dual-camera coordinate systems and applying filtering through feature surface masks, essential corner coordinates are identified for pose calibration, allowing for the estimation of the three-dimensional coordinates of the bolts. Experimental results demonstrate that the proposed method achieves a localization error of less than 2 mm in both ideal and simulated tunnel environments, significantly enhancing stability in low-overlap and complex settings. This approach offers a viable technical foundation for the precise operation of shield disc cutter changing robots and the intelligent advancement of tunnel boring equipment. Full article

Terrestrial laser scanning (TLS) point clouds require high-precision registration and georeferencing to be used effectively. Only then can data from multiple stations be integrated and transformed from the instrument’s local coordinate system into a common, stable reference frame that ensures temporal consistency for further analyses of displacement and deformation. The article demonstrates the validation of an innovative referencing system devised to improve the reliability and accuracy of registering and georeferencing TLS point clouds. The primary component of the system is openable reference spheres, whose centroids can be directly and precisely determined using surveying methods. It also includes dedicated adapters: tripods and adjustable F-clamps with which the spheres can be securely mounted on various structural components, facilitating the optimal distribution of the reference markers. Laboratory tests with four modern laser scanners (Z+F Imager 5010C, Riegl VZ-400, Leica ScanStation P40, and Trimble TX8) revealed sub-millimetre accuracy of sphere fit and form errors, along with the sphere distance error within the acceptance threshold. This confirms that there are no significant systematic errors and that the system is fully compatible with various TLS technologies. The registration and georeferencing quality parameters demonstrate the system’s stability and repeatability. They were additionally verified with independent control points and geodetic levelling of the centres of the spheres. The system overcomes the critical limitations of traditional reference spheres because their centres can be measured directly using surveying methods. This facilitates registration and georeferencing accuracy on par with, or even better than, that of commercial targets. The proposed system serves as a stable and repeatable reference frame suitable for high-precision engineering applications, deformation monitoring, and longitudinal analyses. Full article

To enhance the efficiency and accuracy of partial-to-whole point cloud registration for complex workpieces, this paper presents a novel method based on the Mean Feature Descriptor (MFD). The proposed approach extracts geometric features from key points in the scanned point cloud, constructs local feature descriptors using a localized coordinate system, and performs coarse registration. Compared to conventional local descriptor-based methods, the MFD algorithm not only effectively captures local geometric characteristics but also significantly improves computational efficiency while maintaining high registration accuracy. Experimental results demonstrate that the MFD-based method substantially accelerates registration and measurement processes for complex workpieces. It exhibits strong robustness against noise and varying point cloud resolutions, outperforming existing descriptors such as PFH, FPFH, and HoPPF in terms of F1 score and matching precision. The method achieves reliable registration even under challenging conditions, such as partial overlap and geometric feature sparsity. Notably, the MFD descriptor inherently captures geometric symmetry-invariant features of local point cloud regions especially symmetric interfaces of complex workpieces. This ensures stable registration performance even when partial scans only preserve part of the workpiece’s symmetric structure. Full article

Aiming at the technical challenges of large dust interference, complex measurement parameters, and high real-time requirements in the automated sampling scenario of iron powder transportation vehicles, a method for external dimension detection that integrates laser radar and multi-algorithm collaboration is proposed. By improving ICP point cloud registration, Moving Least Squares surface reconstruction (MLS+), and Gaussian mixture model (GMM-EM) algorithms, the full process automation measurement of carriage length/width/height, top angle coordinates, and reinforcement positions is achieved. Experiments have shown that the system maintains a stable measurement error within ±5 cm and a single-frame processing time of ≤2.1 s in environments with PM2.5 ≤ 500 μg/m³, providing an innovative solution for intelligent detection in industrial scenarios. Full article

State estimation plays a vital role in UAV navigation and control. With the continuous decrease in sensor cost and size, UAVs equipped with multiple LiDARs, Inertial Measurement Units (IMUs), and cameras have attracted increasing attention. Such systems can acquire rich environmental and motion information from multiple perspectives, thereby enabling more precise navigation and mapping in complex environments. However, efficiently utilizing multi-sensor data for state estimation remains challenging. There is a complex coupling relationship between IMUs’ bias and UAV state. To address these challenges, this paper proposes an efficient and accurate UAV state estimation method tailored for multi-LiDAR–IMU–camera systems. Specifically, we first construct an efficient distributed state estimation model. It decomposes the multi-LiDAR–IMU–camera system into a series of single LiDAR–IMU–camera subsystems, reformulating the complex coupling problem as an efficient distributed state estimation problem. Then, we derive an accurate feedback function to constrain and optimize the UAV state using estimated subsystem states, thus enhancing overall estimation accuracy. Based on this model, we design an efficient distributed state estimation algorithm with multi-LiDAR-IMU-Camerafusion, termed DLIC. DLIC achieves robust multi-sensor data fusion via shared feature maps, effectively improving both estimation robustness and accuracy. In addition, we design an accelerated image-to-point cloud registration module (A-I2P) to provide reliable visual measurements, further boosting state estimation efficiency. Extensive experiments are conducted on 18 real-world indoor and outdoor scenarios from the public NTU VIRAL dataset. The results demonstrate that DLIC consistently outperforms existing multi-sensor methods across key evaluation metrics, including RMSE, MAE, SD, and SSE. More importantly, our method runs in real time on a resource-constrained embedded device equipped with only an 8-core CPU, while maintaining low memory consumption. Full article

Aiming at the problems of insufficient environmental perception capability of autonomous mobile robots and low multi-modal data fusion efficiency in the complex underground coal mine environment featuring low illumination, high dust, and dynamic obstacles, a reliable passable region identification method for autonomous mobile robots operating in underground coal mine is proposed in this paper. Through the spatial synchronous installation strategy of dual 4D millimeter-wave radars and dynamic coordinate system registration technology, it increases point cloud density and effectively enhances the spatial characterization of roadway structures and obstacles. Combining the characteristics of infrared thermal imaging and the penetration advantage of millimeter-wave radar, a multi-modal data complementary mechanism based on decision-level fusion is proposed to solve the perceptual blind zones of single sensors in extreme environments. Integrated with lightweight model optimization and system integration technology, an intelligent environmental perception system adaptable to harsh working conditions is constructed. The experiments were carried out in the simulated tunnel. The experiments were carried out in the simulated tunnel. The experimental results indicate that the robot can utilize the data collected by the infrared camera and the radar to identify the specific distance to obstacles, and can smoothly achieve the recognition and marking of passable areas. Full article

The three-dimensional documentation of hypogean structures poses significant methodological challenges due to the absence of natural light, confined spaces, and the presence of fragile painted surfaces. This study presents an integrated workflow for the survey of the Tomba dell’Orco (Tarquinia), combining terrestrial laser scanning, photogrammetry, and the light painting technique. Borrowed from photographic practice, light painting was employed as a dynamic lighting strategy during photogrammetric acquisition to overcome issues of uneven illumination and harsh shadows typical of underground environments. By moving handheld LED sources throughout long-exposure shots, operators produced evenly illuminated images suitable for feature extraction and high-resolution texture generation. These image datasets were subsequently integrated with laser scanning point clouds through a structured pipeline encompassing registration, optimization, and texture reprojection, culminating in web dissemination via the ATON framework. The methodological focus demonstrates that light painting provides a scalable and replicable solution for documenting complex hypogean contexts, improving the photometric quality and surface readability of 3D models while reducing acquisition time compared to static lighting setups. The results highlight the potential of dynamic illumination as an operational enhancement for 3D recording workflows in low-light cultural heritage environments. Full article

Laser scanning allows for the rapid acquisition of three-dimensional data in the form of 3D point clouds. However, due to the accumulation of errors in the registration of multiple pairs of point clouds along the sensor’s trajectory, the generated 3D reconstructions exhibit drift, which creates global inconsistencies in the scan. To address this error, there are drift correction models that distribute the error along a closed circuit of stations. In this work, we present a model of this nature based on the linear interpolation of dual quaternions. This linear solution simultaneously refines rotations and translations in a closed trajectory without iterative computations or matrix decomposition. Experimental evaluations on eight TLS datasets indicate that the proposed drift correction model provides a robust average error reduction of 26%, with a maximum reduction of 41% in circuits with large drift. This simultaneous solution improves pose accuracy in closed trajectories with theoretical advantages that translate into efficient and fast implementation. Although validated using TLS data, the proposed pose-circuit correction model is sensor-agnostic and can be applied to other 3D mapping systems. Full article

Monitoring the deformation of rock surrounding deep coal mine roadways is critical for operational safety, yet conventional methods are often inefficient and lack the precision to capture complex geomechanical behavior. To address this challenge, we developed and validated a high-precision analysis workflow utilizing 3D laser scanning. This methodology integrates a multi-stage point cloud filtering process with a hybrid Principal Component Analysis and Iterative Closest Point (PCA-ICP) algorithm for high-fidelity registration of multi-temporal datasets, enabling deformation analysis via cloud-to-cloud (C2C) distance calculations. Applied to the No. 20105 belt conveyor roadway in the Dahaize coal mine, our method achieved a registration root mean square error (RMSE) of only 0.0136 m. The analysis revealed a distinct pattern of asymmetric deformation; while the roof and floor remained stable, the right wall exhibited significant convergence, with displacement in the lower section being substantially greater than in the upper section. This study establishes a robust methodology capable of rapidly generating comprehensive, centimeter-scale 3D deformation maps for entire roadway sections, providing a timely and quantitative basis for evaluating support performance, forecasting geohazard risks, and optimizing stability control in deep mining operations. Full article
