Self-made agglomerated nanometer CeO₂-Y₂O₃-ZrO₂ (CYSZ) powders for plasma spray–physical vapor deposition (PS-PVD) were prepared by spray-drying, followed by calcination treatment at four different temperatures (600 °C, 700 °C, 800 °C, 900 °C). The physical properties, microstructure, and phase composition of the calcined powders were investigated using a laser particle size analyzer, scanning electron microscopy (SEM), and X-ray diffraction (XRD). The results showed that compared to the agglomerated powders obtained through spray-drying, the particle size of the agglomerated powders changed with increasing calcination temperature, accompanied by an increase in the self-bonding force of the agglomerated powder particles. The proper calcination temperature improved the sprayability of the powders. Additionally, with the increase in the calcination temperature, a transformation from the m-phase to the t-phase occurred in the powder, with Ce⁴⁺ partially entering the Zr lattice to form the t-Zr_0.84Ce_0.16O₂ phase, which facilitated the suppression of the m-phase and improved the high-temperature phase stability. It was also found that the PS-PVD coatings prepared using the aforementioned powders exhibited coarser columnar structures with increasing powder calcination temperature. Full article

With the rising demands of industry to increase the working temperature of gas turbine blades and internal combustion engines, thermal barrier coatings (TBC) were found to be an effective way to further enhance the lifetime of aero components through the improvement of mechanical properties and oxidation-resistance. Thus, this paper aims to review coating technologies with special emphasis on plasma-sprayed thermal barrier coatings (PS), and those produced by physical vapor deposition (PVD) and chemical vapor deposition (CVD) methods. Each technology was assessed in terms of its effectiveness to enhance the mechanical response and oxidation resistance of nickel-based parts working at high temperature. The effect of coating technology on mechanical strength, hardness, fatigue and creep of nickel alloys was discussed to reveal the potential candidates for future applications in aggressive environments. Full article

Environmental barrier coatings (EBCs) are increasingly being used in the high-temperature sections of gas turbines because of their protective effects on SiC fiber-reinforced SiC ceramic matrix composites (SiC_f/SiC CMCs) when subjected to high-temperature water oxygen corrosion. The objective of this study was to investigate the failure behavior of EBCs prepared on SiC_f/SiC CMC matrix materials under coupled high-temperature and load conditions. A plasma spray-physical vapor deposition (PS-PVD) method was used to prepare Si/3Al₂O₃·2SiO₂/Yb₂SiO₅ EBC composite coatings on the surface of SiC_f/SiC ceramic matrix composites. In situ scanning electron microscopy was used to study the evolutionary behavior of the coating surface cracks at different temperatures and the failure and fracture mechanism of the coating/substrate when held at 766 °C and subjected to different loading conditions. The results show that no significant crack extension occurred on the coating surface as the temperature of the coated specimen increased from room temperature to 766 °C in the absence of an applied tensile load, indicating that the effect of a single temperature factor on the failure of the specimen was negligible. However, under coupled high-temperature and load conditions, the specimens fractured at a load of 340 N when subjected to 766 °C, indicating that the coated sample is more likely to fail when subjected to high-temperature and tensile loading. The step-like fracture exhibits features consistent with the coating fracture and spalling caused by surface cracks extending from the coating surface to the interior. The spalling, large crack formation and step-like shape of the fracture in the coating and the substrate indicate that cracks were generated between the coating and the substrate under the coupled high-temperature and load conditions. The generation and extension of cracks in both parts eventually led to full specimen rupture. Full article

In this study, (Gd_0.9Yb_0.1)₂Zr₂O₇ (GYbZ)/yttria-stabilized zirconia (YSZ) double-ceramic-layer (DCL) thermal barrier coatings (TBCs) were prepared by plasma spray-physical vapor deposition (PS-PVD). The microstructure, mechanical performance, and thermal shock behavior of coatings prepared with spraying distances of 600, 800, and 1000 mm were investigated. The GYbZ coating prepared with a spraying distance of 600 mm showed a closely packed columnar structure. However, the GYbZ coatings prepared with spraying distances of 800 and 1000 mm showed a quasi-columnar structure. The GYbZ coating prepared with a spraying distance of 800 mm had the thickest columnar crystals with obvious inter-columnar gaps. In addition, this coating exhibited excellent mechanical performance and the best thermal shock resistance. The primary failure patterns appearing during thermal shocking on the surface of TBCs can be classified into the following five types: caves, exfoliation, delamination cracks, spalled areas, and radiate cracks. Furthermore, the failure behavior of these coatings in water-quenching tests is clarified. Full article

Ytterbium zirconate (Yb₂Zr₂O₇) is one of the most promising materials for yttria-stabilized zirconia (YSZ) replacement as a thermal barrier coating (TBCs) application. In the presented report, the experimental synthesis of Yb₂Zr₂O₇ coating using novel Reactive Plasma Spray Physical Vapor Deposition (Reactive PS-PVD) is described. The obtained coating, irrespective of the power current (1800, 2000 and 2200 A), was characterized by a hybrid structure and a thickness of about 80–110 μm. The results of XRD phase analysis showed the formation of ytterbium zirconate in the coating but the presence of ytterbium and zirconium oxides was also detected. The oxides were not observed in calcinated powder. The decrease in thermal conductivity with power current increase was observed. It was the result of higher thickness and better columnar structure of the coating obtained using higher power current of the plasma torch. Full article

A patient’s body accepting a bone implant depends not only on the biomaterial used, but also on its surface, which allows it to properly interact with bone cells. Therefore, research has focused on improving the bioactive and tribological properties of titanium and its alloys. Commercially pure titanium (cp-Ti) is widely used as a biomedical material. However, it is characterized by unsuitable tribological properties. In this work, yttria-stabilized zirconia (YSZ) was deposited on a cp-Ti substrate via plasma spray–physical vapor deposition (PS-PVD). The structural characteristics were determined using X-ray analysis (XRD). Additionally, the lattice parameters of each phase were determined using Rietveld’s method. High-resolution scanning microscopy (HR-SEM) showed a typical column structure of coatings that can be used with PS-PVD. Depending on the process parameters, the coatings differed in thickness in the range of 2.4–9.0 µm. The surface roughness also varied. The samples were subjected to nano-indenter testing. A slight change in hardness after deposition of the coating was observed, in addition to a significant decrease in the Young’s modulus. The Young’s modulus in relation to the metallic substrate was reduced to 58 or 78 GPa depending on the parameters of the spray-coating process. Full article

Ceramic topcoats of thermal barrier coatings (TBCs) make it possible to increase the working temperature of the hot sections of jet engines. Yttria-stabilized zirconia oxide (YSZ) is usually used to protect the turbine blades and vanes against high temperature and oxidation. It is necessary to develop new materials which can operate at higher temperatures in a highly oxidizing gas atmosphere. Re₂Zr₂O₇-type pyrochlores are promising YSZ replacements. Usually, they are produced by mixing pure oxides in the calcination process at higher temperatures. In a recent article, the new concept of pyrochlore synthesis during the deposition process was presented. The new technology, called reactive plasma spray physical vapor deposition (reactive PS-PVD), was developed and a Gd₂Zr₂O₇ (GZO) coating was achieved. The reactive PS-PVD process allowed for the use of a mixture of untreated ZrO₂ and Gd₂O₃ powders as reactants, instead of the commercially available gadolinium zirconate powders used in other types of processes. The results of microstructure observations revealed a columnar microstructure in the produced ceramic layer. The phase composition indicated the presence of gadolinium zirconate. Thermal analysis showed a decrease in the thermal conductivity in the range of 700 to 1200 °C of the produced layers, as compared to the layer made of the currently used conventional YSZ. Full article

Plasma spray-physical vapor deposition (PS-PVD) refers to a very low-pressure (~100 Pa) deposition process in which a powder is injected in a high-enthalpy plasma jet, and mostly vaporized and recondensed onto a substrate to form a coating with a specific microstructure (e.g., columnar). A key issue is the selection of the powder particle size that could be evaporated under specific spray conditions. Powder evaporation takes place, first, in the plasma torch between the injection location and nozzle exit and, then, in the deposition chamber from the nozzle exit to the substrate location. This work aims to calculate the size of the particles that can be evaporated in both stages of the process. It deals with an yttria-stabilized zirconia powder and two commercial plasma torches operated at different arc powers with gas mixtures of argon and helium or argon and hydrogen. First, it used computational fluid dynamics simulations to calculate the velocity and temperature fields of the plasma jets under very low-pressure plasma conditions. Then, it estimated the evaporation of the particles injected in both plasma jets assuming an isothermal evaporation process coupled with momentum and heat transfer plasma-particle models in a rarefied plasma. The calculations showed that, for different powers of the Ar–H₂ and the Ar–He operating conditions of this study, the heat flux from the plasma jet to particles inside the torch is much higher than that transferred in the deposition chamber while the specific enthalpy transferred to particles is comparable. The argon-helium mixture is more efficient than the argon-hydrogen mixture to evaporate the particles. Particles less than 2 μm in diameter could be fully evaporated in the Ar–He plasma jet while they should be less than 1 µm in diameter in the Ar–H₂ plasma jet. Full article

SiC fiber-reinforced SiC ceramic matrix composites (SiC_f/SiC CMCs) are being increasingly used in the hot sections of gas turbines because of their light weight and mechanical properties at high temperatures. The objective of this investigation was the development of a thermal/environmental barrier coating (T/EBC) composite coating system consisting of an environmental barrier coating (EBC) to protect the ceramic matrix composites from chemical attack and a thermal barrier coating (TBC) that insulates and reduces the ceramic matrix composites substrate temperature for increased lifetime. In this paper, a plasma spray-physical vapor deposition (PS-PVD) method was used to prepare multilayer Si–HfO₂/Yb₂Si₂O₇/Yb₂SiO₅/Gd₂Zr₂O₇ composite coatings on the surface of SiC_f/SiC ceramic matrix composites. The purpose of this study is to develop a coating with resistance to high temperatures and chemical attack. Different process parameters are adopted, and their influence on the microstructure characteristics of the coating is discussed. The water quenching thermal cycle of the coating at high temperatures was tested. The results show that the structure of the thermal/environmental barrier composite coating changes after water quenching because point defects and dislocations appear in the Gd₂Zr₂O₇ and Yb₂SiO₅ coatings. A phase transition was found to occur in the Yb₂SiO₅ and Yb₂Si₂O₇ coatings. The failure mechanism of the T/EBC composite coating is mainly spalling when the top layer penetrates cracks and cracking occurs in the interface of the Si–HfO₂/Yb₂Si₂O₇ coating. Full article

Plasma spray-physical vapor deposition (PS-PVD) is an emerging technology for the deposition of uniform and large area coatings. As the characteristics of plasma jet are difficult to measure in the whole chamber, computational fluid dynamics (CFD) simulations could predict the plasma jet temperature, velocity and pressure fields. However, as PS-PVD is generally operated at pressures below 500 Pa, a question rises about the validity of the CFD predictions that are based on the continuum assumption. This study dealt with CFD simulations for a PS-PVD system operated either with an argon-hydrogen plasma jet at low-power (<50 kW) or with an argon-helium plasma jet at high-power (≥50 kW). The effect of the net arc power and chamber pressure on the plasma jet characteristics and local gradient Knudsen number (Kn) was systematically investigated. The Kn was found to be lower than 0.2, except in the region corresponding to the first expansion shock wave. The peak value in this region decreased rapidly with an increase in the arc net power and the width of this region decreased with an increase in the deposition chamber pressure. Based on the results of the study, the local Knudsen number was introduced for detecting conditions where the continuum approach is valid under PS-PVD conditions for the first time and the CFD simulations could be reasonably used to determine a process parameter window under the conditions of this study. Full article

Yttria-stabilized zirconia (YSZ) coatings with typical pyramid columnar and dense layered structure were prepared by plasma spray-physical vapor deposition (PS-PVD). The evolution behavior of microstructure and crystallography of the coatings before and after thermal aging treatment were observed by electron backscatter diffraction (EBSD) and field emission scanning electron microscopy (FE-SEM). Results showed that the as-deposited coatings exhibited many types of structures and were mainly composed of a nonequilibrium tetragonal (t’-ZrO₂) phase. With the prolonging of thermal exposure time, the initial nonequilibrium tetragonal phase of YSZ coatings gradually transformed into a monoclinic (m-ZrO₂) phase. During the process of stationary deposition, at a proper spraying distance, each column exhibited a certain preferred orientation, but the ceramic topcoat did not exhibit distinct preferred orientation statistically. Full article

Tri-layer Si/mullite/Yb₂SiO₅ environmental barrier coating (EBC) was prepared on the SiCf/SiC ceramic matrix composite (CMC) by plasma spray-physical vapor deposition (PS-PVD). The EBC samples were carried out with water vapor corrosion at 1300 °C for 200 h. After steam corrosion, Yb₂SiO₅ layer forms a gradient porous structure. This is mainly due to the inclusion of SiO₂-rich layer which is precipitated from the gasification inside the coating and existing a small amount of Yb₂O₃ separately. During the corrosion process, water vapor infiltrates into the coating and reacts with the SiO₂ and Yb₂O₃ to generate volatile substances. This forms a porous structure to make the coating brittle, resulting in mud cracks finally. In addition, the results show that the Yb₂SiO₅ can react with the water vapor at the coating surface, forming an Yb₂Si₂O₇ top layer. Full article

Ytterbium silicate coatings were deposited on SiCf/SiC ceramics matrix composite (CMC) substrates by plasma spray-physical vapor deposition (PS-PVD), and the microstructures and phase constituents of the coatings were studied. The results show that the Yb₂SiO₅ coating prepared with high power and low pressure (65 kW/2 mbar) had quasi-columnar structure, mainly deposited from the vapor phase, whereas the coating prepared with low power and high pressure (40 kW/10 mbar) had a typical layered structure, mainly deposited from the liquid phase. The deposition efficiency of parameter A (~2 μm/min) was also significantly lower than that of parameter B (~20 μm/min). After annealing at 1300 °C for 20 h, the coating prepared by 65 kW/2 mbar was mainly composed of ytterbium disilicate phase (77.2 wt %). The coating also contained some silicon-rich phase. The coating prepared by 40 kW/10 mbar basically consisted of ytterbium monosilicate (63.6 wt %). In addition, a small amount of silicon-rich phase and ytterbium-rich phase were also present in the coating. Accompanied with calculation results by the FactSage software, the cause of deviations in phase compositions was analyzed. Full article

By virtue of plasma spray-physical vapor deposition (PS-PVD) process, coatings in possession of columnar structures can be obtained by suitable processing parameters coupled with specially designed powder feedstock. In this paper, the influence of powder characteristics on the La₂Ce₂O₇ (LC) coating microstructures was investigated by using three kinds of feedstock powders with same PS-PVD processing parameters. It was found that small agglomerated feedstock, weak binding strength, and small primary particle sizes can enhance the feedstock evaporation rate, thus obtaining well columnar structured coatings. X-ray diffraction (XRD) patterns revealed that except for a very small amount of La₂O₃ the main phase of all the coatings is LC. The La/Ce atomic ratios reduced in the coatings compared to the feedstocks, especially the coatings with better columnar structure. Super-lattice patterns were observed by transmission electron microscope (TEM), which means that the LC phase is supposed to be pyrochlore structure. Furthermore, the mechanical properties evaluated by nano-indentation tests indicated that both the hardness and Young’s modulus of each coating show negative correlations with the porosity inside the columns. Full article

Gadolinia-doped ceria (GDC) is a promising electrolyte material for low-temperature solid oxide fuel cells (LT-SOFCs). Many works used ceramic sintering methods to prepare the GDC electrolyte, which was mature and reliable but presented difficulties in rapidly preparing a large area of GDC electrolyte without cracks. The low-pressure plasma spray (LPPS) process has the potential to solve this problem, but few studies have been conducted to date. In this work, submicron GDC powder was agglomerated by a spray drying method to achieve the proper granularity with D₅₀ about 10 μm, and then two dense GDC coatings were fabricated with this agglomerated GDC powder using very-low-pressure plasma spray (VLPPS) and plasma spray–physical vapor deposition (PS-PVD), respectively. The results indicate that the two GDC coatings exhibited similar microstructure but with different densification mechanisms. The VLPPS coating was mainly built up in the form of liquid splats, which had lower mechanical properties due to the lower density and crystallinity, while the PS-PVD coating was co-deposited with the vapor clusters and liquid splats, which had higher density, crystallinity, and mechanical properties. It can therefore be concluded that the GDC coating prepared by PS-PVD is more appropriate for the LT-SOFC application. Full article
