Shield tunnel construction inevitably disturbs existing upper buildings. This paper takes the section from Zhongyi Road Station to Housihu Fourth Road Station of Wuhan Metro Line 12 as the engineering background, where twin shield tunnels pass beneath Zizhu Kindergarten. Based on field monitoring data, this paper systematically analyzes the development laws of surface settlement and building settlement. Numerical simulation is adopted and compared with measured data to verify the reliability of the model. With the validated numerical model, this paper investigates the influencing factors of building settlement. The results show that the maximum ground surface settlement during shield construction is approximately 6.84 mm, and the maximum building settlement is about 4.63 mm. The horizontal relative position between piles and tunnels changes the superposition mode of ground settlement troughs. Building settlement reaches the minimum when twin tunnels pass beneath symmetrically. Eccentric crossing aggravates building settlement to a certain extent. The maximum building settlement increases with the rise of tunnel buried depth. The research results can provide a reference for deformation control and construction optimization of similar twin shield tunnels crossing beneath buildings with piled-raft foundations. Full article

Shield tunneling in urban areas can generate ground vibrations that may threaten adjacent buildings, especially in hard rock strata. However, the effect of foundation type on the vibration response of multi-story buildings is not yet fully understood. This study investigates this issue through a combined approach of field monitoring and three-dimensional numerical simulation based on the Jinan Metro Line 4 project. Five-story frame buildings with pile, raft, and isolated footing foundations were analyzed, and the numerical model was validated against measured data to ensure reliability. The results show that vibration waves attenuate in an approximately symmetric elliptical pattern and are amplified by the presence of buildings. A significant vertical amplification effect is observed, with peak particle velocity at the top floor reaching up to 2.11 times that at the ground surface. Foundation type exerts a significant influence on vibration transmission. Raft foundations exhibit a more uniform vibration distribution, whereas isolated footings demonstrate a weaker attenuation capacity, with only 23.6% attenuation and a first-floor response approximately 3.3 times greater than that of pile foundations. Although the structural safety requirements are satisfied, the vibration levels at upper floors may still exceed the human comfort limit of 75 dB, with the pile-founded building reaching 85.38 dB. These findings improve the understanding of vibration transmission mechanisms under symmetric disturbance conditions and provide a scientific basis for foundation selection and vibration mitigation in urban tunneling projects. Full article

In the small-deformation scenario of high-speed railway (HSR) rigid pile–raft composite foundations, the coupled effects of non-equidistant and non-stationary (NENS) characteristics in observational data significantly affect the system response of prediction models. Existing research has predominantly focused on single evaluation metrics or large-deformation scenarios, lacking a comprehensive evaluation system for the multidimensional performance of these models under small-deformation conditions. NENS time-series data were generated via Monte Carlo simulation. The coupled effect was quantified through a process involving “theoretical curve extraction–non-equidistant sampling–random disturbance injection”. Parameters such as pile length, displacement ratio, and pile–soil modulus ratio were normalized using the composite modulus (CMA) method to uniformly characterize the influence of foundation stiffness on time-varying settlement characteristics. A robust entropy-weighted method was then used to construct a comprehensive evaluation index (CEI), which integrates goodness-of-fit (36%), prediction accuracy (26%), and stability (38%) to systematically assess four empirical models: the hyperbolic method, exponential curve method, Asaoka method, and Hoshino method. The results indicate that when CMA ≤ 100 MPa, settlement curves exhibit nonlinearity, and the Hoshino and hyperbolic methods perform optimally. Between 100 and 1000 MPa, pile–soil interaction intensifies, highlighting the Hoshino method’s superior stability. When CMA ≥ 1000 MPa, pile–soil interaction becomes load-dominated, with the Hoshino method remaining optimal while the hyperbolic and exponential curve methods exhibit significantly increased errors. The proposed NENS time-series simulation–multi-criteria coupling evaluation framework resolves model selection challenges in small-deformation scenarios and provides robust decision support for HSR settlement prediction. Full article

Urban geological complexities induce asymmetric differential settlement of high-rise buildings, threatening structural stability and necessitating sustainable remediation. This study combines field monitoring with geotechnical simulations to diagnose karst void-induced foundation failures in the Zhongyi Park Wangfu Community (Guizhou karst urban area), proposing a low-carbon grouting strategy for subsurface spatial reinforcement. Key findings include the following: (1) Field monitoring identified significant asymmetric settlement and lateral displacement of the structure, primarily caused by the presence of voids in the strata and piles not founded on bedrock. (2) Theoretical modeling reveals that geotechnical properties of soil at the pile tip and along the pile shaft are the most critical factors controlling settlement magnitude, with larger cavity heights further intensifying the asymmetric deformation. (3) A novel grouting lifting strategy was implemented, involving layered reinforcement of weak soil above the pile end and grout-based compaction to generate controlled uplift force, targeting the mitigation of asymmetric settlement. (4) Post-intervention monitoring confirmed the strategy’s effectiveness, achieving a final deviation of only 2 cm in compliance with national standards (with asymmetric characteristics effectively controlled), while utilizing environmentally sustainable materials. Full article

The extensive development of urban underground space increases the risk of deformation to adjacent structures during deep excavations. This study investigates the response of three low-strength strip-foundation buildings (#4, #8, and #11 of the Ninggong Apartment) in Nanjing, China, affected by the excavation of an adjacent super-long, narrow subway station. The site is located in a typical soft alluvial area of the Yangtze River, characterized by highly compressible and sensitive soil, which poses substantial challenges. Pre-construction ground improvement was implemented to mitigate the impacts of diaphragm wall trenching; however, monitoring data indicated that buildings’ settlements of this stage still reached 28.2%, 24.8%, and 27.2% of their final values, with extensive influence zones. Subsequent excavation of the eastern and middle sections induced further cumulative and differential settlements, raising safety concerns and necessitating structural strengthening before adjacent western excavation. An integrated underpinning system, combining anchor static pressure steel pipe piles with a raft foundation, was adopted. Although short-term settlement increased during pile and raft installation, post-strengthening settlement rates decreased significantly. The adjacent western excavation caused only 13.3% of the settlement to be observed during the middle section’s excavation. All buildings were ultimately protected from excessive deformation. The protective strategies and lessons learned provide practical guidance for similar projects. Full article

Designing deep foundations in densely urbanized areas presents significant challenges due to complex soil conditions, high groundwater levels, and the proximity of sensitive infrastructure. This study addresses these challenges through the development and numerical analysis of a combined pile–raft foundation (CPRF) system for a 75 m tall hotel tower in Frankfurt am Main, Germany. The construction site is characterized by heterogeneous soil layers and is located adjacent to a historic quay wall and bridge abutments, necessitating strict deformation control and robust structural performance. A comprehensive three-dimensional finite element model was developed using P_LAXIS 3D to simulate staged construction and soil–structure interaction (SSI). The CPRF system comprises a 2 m thick triangular raft and 34 large-diameter bored piles (1.5 m in diameter, 40–45 m in length), designed to achieve a load-sharing ratio of 0.89. The raft contributes significantly to the overall bearing capacity, reducing bending moments and settlement. The predicted settlement of the high-rise structure remains within 45 mm, while displacement of adjacent heritage structures does not exceed critical thresholds (≤30 mm), ensuring compliance with serviceability criteria. The study provides validated stiffness parameters for superstructure design and demonstrates the effectiveness of CPRF systems in mitigating geotechnical risks in historically sensitive urban environments. By integrating advanced numerical modeling with staged construction simulation and heritage preservation criteria, the research contributes to the evolving practice of performance-based foundation design. The findings support the broader applicability of CPRFs in infrastructure-dense settings and offer a methodological framework for future projects involving complex SSI and cultural heritage constraints. Full article

To address the issue of structural tilting caused by uneven foundation settlement in soft soil areas, this study combined a specific engineering case to conduct numerical simulations of the rectification process for an inclined reinforced concrete building using ABAQUS finite element software. Micropile-raft combined jacking technology was employed, applying staged jacking forces (2400 kN for Axis A, 2200 kN for Axis B, and 1700 kN for Axis C) with precise control through 20 incremental steps. The results demonstrate that this technology effectively halted structural tilting, reducing the maximum inclination rate from 0.51% to 0.05%, significantly below the standard limit. Post-rectification, the peak structural stress decreased by 42%, and displacements were markedly reduced. However, the jacking process led to a notable increase in the column axial forces and directional changes in beam bending moments, reflecting the dynamic redistribution of internal forces. The study confirms that micropile-raft combined jacking technology offers both controllability and safety, while optimized counterforce pile layouts enhance the long-term stability of the rectification system. Based on stress and displacement cloud analysis, a monitoring scheme is proposed, forming an integrated “rectification-monitoring-reinforcement” solution, which provides a technical framework for building rectification in soft soil regions. Full article

Pile–raft foundations are widely used in soft soil engineering due to their good integrity and high stiffness. However, traditional design methods independently design pile–raft foundations and superstructures, ignoring their interaction. This leads to significant deviations from actual conditions when the superstructure height increases, resulting in excessive costs and adverse effects on building stability. This study experimentally investigates the interaction characteristics of pile–raft foundations and superstructures in soft soil under different working conditions using a 1:10 geometric similarity model. The superstructure is a cast-in-place frame structure (beams, columns, and slabs) with bamboo skeletons with the same cross-sectional area as the piles and rafts, cast with concrete. The piles in the foundation use rectangular bamboo strips (side length ~0.2 cm) instead of steel bars, with M1.5 mortar replacing C30 concrete. The raft is also made of similar materials. The results show that the soil settlement significantly increases under the combined action of the pile–raft and superstructure with increasing load. The superstructure stiffness constrains foundation deformation, enhances bearing capacity, and controls differential settlement. The pile top reaction force exhibits a logarithmic relationship with the number of floors, coordinating the pile bearing performance. Designers should consider the superstructure’s constraint of the foundation deformation and strengthen the flexural capacity of inner pile tops and bottom columns for safety and economy. Full article

Understanding the complex phenomena of interactions between the elements of a combined piled raft foundation (CPRF) is essential for the proper design of such foundations. To evaluate the effects of mutual influence among the CPRF’s elements, a series of long-term measurements of selected physical quantities related to the performance of the foundation were conducted on a building with a frame structure, stiffening walls, and monolithic technology, consisting of seven aboveground stories and one underground story. The analysis distinguishes the real deformations resulting from temperature changes and from stress strains resulting from load changes. The two types of deformations were subjected to further interpretation of only changes in the stress and strain over time. Changes in stress values in the subsoil, as well as strain measurements in the vertical direction of concrete columns, were recorded to assess the load distribution between the CPRF’s components. The numerical analysis results obtained for a fragment of the monitored foundation were compared with actual measurement results to verify the numerical model of interaction between the structure and the soil. Field monitoring and FEA methods were used to compare the long-term deformation analysis, and they helped to minimize the monitoring time. This comparison also served to supplement and simultaneously expand the dataset of test results on a real-world scale. Full article

The traditional design of foundations in soft clay often relies on large-diameter piles, which, although effective, are costly and impractical for low- to medium-rise buildings. Micropiles have emerged as a cost-effective alternative, offering an efficient solution to these challenges. To advance the adoption of micropiles in geotechnical practice, this study employs a multi-objective genetic algorithm-based evolutionary polynomial regression (EPR-MOGA), a hybrid artificial intelligence method, to develop a robust and straightforward model for predicting the load–settlement response of micropiled rafts in cohesive soils under vertical loads. The model was created using an extensive database comprising 458 data points derived from field tests, centrifuge experiments, laboratory studies, and numerical simulations reported in the literature. This comprehensive database covers a wide range of scenarios by varying key parameters of micropiles within a group, including their length, diameter, number, spacing, construction method, and raft thickness. The proposed EPR model could deliver accurate predictions, providing a practical approach for geotechnical applications. In addition, the predictions of the model could support the conclusion that pressure-grouted micropiles are more efficient than gravity-grouted ones in enhancing the performance of micropiled rafts. Full article

Structural damages occurred during any earthquake arise not only from structural design flaw but also from the variability of sub-base soil behavior and the foundation system. For this reason, structure–soil–pile interaction has an important place in evaluating the behavior of a structure under dynamic effects. Bored pile application, which is one of the deep foundation systems, is a widely used method in the world to transfer the loads coming from the structure to the ground safely in problematic grounds. For this reason, in pile foundation system designs, how bored pile foundation systems will affect the structural design under earthquake loads is considered an important issue. In particular, how diagonally braced steel structures with piled raft foundation systems will behave under earthquake effects has been evaluated as a subject that needs to be examined. For this reason, this situation was evaluated as the main purpose of this study. The effect of the bored pile systems designed in different orientations on the behavior of diagonally braced steel structures during an earthquake under kinematic and inertial effects was investigated in detail within the scope of this study. Numerical analyses, based on data from shake table experiments on a scaled superstructure, examine various pile design scenarios. Experimental base shear force measurements informed the development of numerical scenarios, which varied pile lengths and inter-pile distances while maintaining constant pile diameters. This study analyzed the kinematic and inertial effects on the piles, offering insights into their structural behavior under seismic conditions. The increase in pile length and the increase in the distance between the piles caused a significant increase in the bending moment and shear force, which have an important place in pile design. Full article

The degradation of complex geological structures due to thermo-mechanical cycling results in a reduction in bearing capacity, which can readily induce engineering issues such as uneven settlement, cracking, and even the destabilization of the foundations of molten salt storage tanks. This study establishes a foundational model for a molten salt storage tank through the use of COMSOL Multiphysics and conducts a numerical simulation analysis to evaluate the settlement deformation and temperature distribution of the foundation under the influence of thermo-mechanical coupling. Concurrently, the research proposes two distinct design approaches for the tank’s foundational structure. A comparative analysis of the results indicates that the use of a pile raft foundation in conjunction with a traditional foundation mode results in a reduction of settlement at the center of the foundation’s top surface by 380.1 mm, while also decreasing the maximum effective stress in the steel ring wall by 240.7 MPa. The thermal effects impact a depth of 10 m in the foundation soil and an influence radius of 20 m. Additionally, the foundation soil exhibits optimal thermal insulation properties, resulting in minimal energy loss. These findings indicate that the pile raft foundation in conjunction with a traditional foundation mode displays remarkable adaptability to complex geological conditions, with both settlement and temperature distribution of the foundation maintained within acceptable limits. Full article

The population surge has led to a corresponding increase in the demand for high-rise buildings, bridges, and other heavy structures. In addition to gravity loads, these structures must withstand lateral loads from earthquakes, wind, ships, vehicles, etc. A piled raft foundation (PRF) has emerged as the most favored system for high-rise buildings due to its ability to resist lateral loads. An experimental study was conducted on three different piled raft model configurations with three different relative densities (D_r) to determine the effect of D_r on the lateral response of a PRF. A model raft was constructed using a 25 mm thick aluminum plate with dimensions of 304.8 mm × 304.8 mm, and galvanized iron (GI) pipes, each 457.2 mm in length, were used to represent the piles. The lateral and vertical load cells were connected to measure the applied loads. It was found that an increase in D_r increased the soil stiffness and led to a decrease in the lateral displacement for all three PRF models. Additionally, the contribution of the piles in resisting the lateral load decreased, whereas the contribution of the raft portion in resisting the lateral load increased. With an increase in D_r from 30% to 90%, the percentage contribution of the raft increased from 42% to 66% for 2PRF, 38% to 61% for 4PRF, and 46% to 70% for 6PRF. Full article

Micropiles were first used to repair the damaged structures of “Scuola Angiulli” in Naples after World War II. They are known as small versions of regular piles, with a diameter of less than 30 cm, and are made of high-strength, steel casing and/or threaded bars, produce minimal noise and vibration during installation, and use lightweight machinery. They are capable to withstand axial loads and moderate lateral loads. They are used for underpinning existing foundations and to restore historical buildings and to support moderate structures. In the literature, several reports can be found dealing with micropiles, yet little has been reported on Micropiled-Raft Foundations (MPR). This technology did not receive the recognition it deserved until the 1970s when its technical and economic benefits were noted. A series of laboratory tests and numerical modeling were developed to examine the parameters governing the performance of MPR, including the relative density of the sand, the micropile spacing, and the rigidity of the raft. The numerical model, after being validated with the present experimental results, was used to generate data for a wide range of governing parameters. The theory developed by Poulos (2001) (PDR) to predict the capacity of pile-raft foundations was adopted for the design of MPR. The PDR method is widely used by geotechnical engineers because of its simplicity. Full article

Despite numerous studies of single piles and practical experience with their application, methods for calculating settlements of pile foundations remain limited. The existing objective need for specialized methods of pile foundation settlement calculation that take into account the rheological properties of the base soils is becoming more and more important, especially in the construction of unique objects in complex ground conditions. When predicting the stress–strain state of the pile–raft-surrounding soil mass system, it is allowed to consider not the entire pile foundation as a whole, but only a part of it—the computational cell. In the present work, we have solved the problems of determining the strains of the computational cell consisting of the pile, the raft and the surrounding soil according to the column pile scheme and hanging pile scheme, on the basis of the Kelvin–Voigt rheological model, which is a model of a viscoelastic body consisting of parallel connected elements: Hooke’s elastic spring and Newtonian fluid. According to our results, we obtained graphs of the dependence of strains of the computational cell on time at different pile spacing and different values of coefficients of viscosity of the surrounding soil, and a formula for calculating the reduced modulus of deformation of the pile. The results of the present study can significantly improve the accuracy of calculations during construction on clayey soils with pronounced rheological properties and, as a result, increase the reliability of pile structures in general. Full article
