Severe shocks and vibrations are common in industrial settings (such as oil drilling at 200–300 °C and heavy machinery); high-temperature piezoelectric gyroscopes’ solid-state architecture provides remarkable shock and vibration tolerance as well as great reliability. This review covers the most recent advances in the creation of high-temperature piezoelectric gyroscopes from three angles: materials, structural design, and circuit design. First, it emphasises how optimising microstructures can greatly improve the materials’ temperature stability (e.g., PZT with d₃₃ = 562 pC/N and LiNbO₃ with Curie temperature ~1210 °C) and piezoelectric coefficient; second, it examines the structural design of piezoelectric gyroscopes based on MEMS/NEMS technology (such as disc-type, ring-type, and beam-type), showing that optimising resonance frequency matching and modal isolation techniques greatly improves the gyroscope’s zero-bias stability (down to 5°/h) and immunity to interference; and third, it summarises the efficacy of optimisation techniques like temperature self-compensation circuit design and structural symmetry design. According to research, problems like high-temperature material ageing (e.g., degradation above 120 °C for silicon-based devices) and the difficulty of system integration continue to limit current technology; in the future, performance bottlenecks will need to be removed through advancements in cross-scale manufacturing technologies and intelligent sensor fusion design. From a multidisciplinary standpoint, this study offers theoretical references and technical recommendations for the industrial use of high-temperature piezoelectric gyroscopes. Full article

Piezoelectric pressure sensors for dynamic monitoring face a trade-off between charge output and measurement range, and existing high-sensitivity designs are largely confined to narrow ranges. This study presents a composite layered piezoelectric pressure sensor in which a 316L stainless-steel diaphragm drives a centrally suspended PZT-5H wafer supported by a perforated alumina gasket, with the wafer thickness and cavity radius optimized under a 10 MPa full-scale stress constraint. Over 0–10 MPa, quasi-static calibration gave a highly repeatable quadratic pressure–charge relationship ($R^2=0.99995$) with a maximum residual below 1% FS. The sensitivity is pressure-dependent: the secant sensitivity increased monotonically from 3.16 pC/kPa at 1 MPa to 5.36 pC/kPa at 10 MPa, reflecting a stress-stiffening response rather than a measurement tolerance band. The output deviation remained within 3% from 25 °C to 150 °C. Shock-tube testing yielded a resonance of ∼50 kHz and a mutually consistent 10–90% leading-edge interval of 10.12 $\mathsf{\mu }$s. Combining high charge sensitivity over a wide 0–10 MPa range with a fast transient response and stable operation up to 150 °C, the proposed sensor is suited to dynamic pressure-pulsation monitoring in fluid-power and thermal and power-plant fluid systems. Full article

Ultrasonic thickness resonance can be effectively used to detect and quantify the level of corrosion in steel nuclear storage containers as well as other corrosion-prone thin-walled structures, such as pipes and storage tanks. Electro-Magnetic Acoustic Transducers (EMATs) have several advantages over more traditional piezoelectric-based transducers; namely, they can be used in a non-contact fashion on robotic platforms, allowing for measurements regardless of surface conditions or temperature. The major challenge of EMAT application is the power required to counteract the low actuation efficiency, which is achieved with a high-power ultrasonic pulse generator and a transformer circuit. Resonance techniques, in which most of the energy is concentrated near structural resonance frequencies, are preferable to improve efficiency of electro-magnetic acoustic measurements. This methodology was applied to 316L stainless steel thin plates subjected to uniform corrosion as well as pitting corrosion imitating different damage scenarios in a nuclear waste container. The resonant peak frequency shift was found to be proportional to the severity of corrosion for minimally corroded samples. However, the complete disappearance of the resonance peak was observed in the samples with severe corrosion damage. The EMAT liftoff distance was studied to quantify its effect on the amplitude, spread, and frequency of resonant peaks. Recommendations for use of EMATs for assessing corrosion damage are presented. The study demonstrates the success of frequency-based detection of corrosion damage in 316L stainless steel used in fabrication of nuclear waste storage containers. Full article

To address the issues of pronounced resonance, limited control bandwidth, and insufficient trajectory tracking accuracy in piezoelectric-driven elliptical vibration-assisted cutting (EVC) systems under high-frequency vibration, this paper proposes a trajectory tracking control strategy combining damping control with frequency-domain shaping. First, a damping-control strategy is integrated into the control system to refine the plant’s inherent dynamic properties, suppressing the resonance peak and elevating the system’s stability margin. Second, to enhance the system bandwidth and dynamic response, a high-gain PID controller is designed via frequency shaping. Additionally, given that the nominal model becomes high-order after implementing the damping controller, proportional gain is used for approximate equivalence with the system transfer function, lowering the model order and streamlining controller design. Next, a disturbance observer (DOB) is introduced to estimate and compensate for the unmodeled dynamics in the feedforward path in real time, further improving the trajectory tracking accuracy. Finally, taking the designed piezoelectric-driven EVC device as the controlled plant, the system frequency response is obtained through sweep excitation experiments, based on which the nominal model is identified, and the controller parameters are determined. The experimental results demonstrate that the proposed control strategy effectively suppresses resonance effects, increases system bandwidth, and reduces the trajectory tracking error. In the complex harmonic superposition trajectory tracking experiment, the steady-state tracking error is maintained within ±0.09 μm. These results demonstrate that the proposed approach markedly improves the system’s dynamic response and trajectory tracking performance, thereby providing technical support for high-precision fabrication of micro/nano-structured surfaces. Full article

Potassium sodium niobate (KNN) lead-free piezoelectric ceramics feature eco-friendliness and low density, coupled with superior high-frequency driving efficiency, albeit with inferior low-frequency performance. Conversely, Terfenol-D exhibits outstanding low-frequency driving capability but suffers from high density and poor high-frequency efficiency. This work proposes a ternary symmetric driving structure that integrates the complementary advantages of KNN and Terfenol-D, developing an underwater acoustic transducer with excellent lightweight design, low-frequency response, and broadband performance. The ternary symmetrically excited transducer maintains stable nodal planes across different operating frequencies and exhibits two distinct resonant frequencies. The vibration equation is analytically solved, and modal analysis is performed to clarify the evolution of the dual-resonance frequencies. A prototype transducer weighing 2.8 kg is fabricated and tested in an anechoic water tank. It delivers a maximum transmitting voltage response of 145 dB at 1.7 kHz with a broad operating bandwidth of 1–6 kHz. Compared with previously reported transducers, its weight is reduced by 26% to 93%. Benefiting from the double-ended radiation structure, the transducer yields a nearly omnidirectional radiation pattern. This ternary symmetrically excited transducer holds promising application prospects for underwater acoustic detection, communication, and navigation systems on unmanned underwater vehicle platforms. Full article

Cobalt ferrite (CoFe₂O₄) magnetostrictive ultrasonic elliptical vibration cutting (UEVC) tools have recently emerged as a low-cost, low-eddy-loss alternative to piezoelectric and rare-earth-driven cutting heads. The structural design and resonance characterisation of such a dual-bending CoFe₂O₄ UEVC tool was reported in our previous work. The present paper builds directly on that platform and addresses a different objective: to determine how the four primary process variables—feed rate, cutting speed, cutting depth, and inter-channel phase difference—should be set to obtain the best surface quality on a representative ductile metal. Using H62 brass as the workpiece and a single-crystal diamond tool with a 0.2 mm nose radius and 60° included angle, single-factor experiments are run on a custom 5-axis precision lathe, and surface roughness is mapped in both the cutting and the feed direction with a Keyence VK-X1000 confocal microscope (Keyence, Osaka, Japan). The speed ratio K = Vc/(2πfA) is computed for every test point so that each result can be classified as belonging to the continuous-contact or to the intermittent-contact UEVC regime. The results show: (i) feed rate has a non-monotonic effect, with an optimum at 1 μm where ductile-mode separation is achieved without secondary tool-trajectory overlap, reducing the cutting direction roughness by up to 45% with respect to conventional cutting (CC); (ii) the UEVC advantage shrinks at high cutting speeds because the speed ratio approaches unity and the intermittent regime collapses, but is still 12.6%–38% over the 50–375 mm/s range tested; (iii) the relative improvement is largest at low depth and decreases as the depth grows, retaining 11.5%–49% gain over CC across 0.5–10 μm; (iv) the inter-channel phase difference, which controls the geometry of the tool-tip ellipse, is the strongest single lever—at 60°, the trajectory becomes an oblique ellipse whose major axis is tilted with respect to the cutting direction, bringing the cutting direction roughness down to 1.21 μm against 2.82 μm for CC, a 57% reduction. A simple kinematic argument links this optimum to a maximum effective separation duration per cycle and offers a design rule for analogous UEVC tools. Full article

In this work, the effect of liquids with different dielectric permittivities and acoustic impedances on the characteristics of the backward antisymmetric A1 Lamb wave propagating in a YX LiNbO3 plate was investigated theoretically, numerically and experimentally for the first time. It was found that the dielectric constant and acoustic impedance (density) of a liquid make independent and separable contributions to measured parameters of interdigital transducers, such as the resonant frequency and Q-factor. It was shown that the backward A1 Lamb wave in a YX LiNbO3 plate can be effectively used as a basis for multiparametric liquid sensors. The results obtained are both of fundamental importance for understanding the physics of propagation of backward acoustic waves in piezoelectric plates with a liquid load and of applied value for the development of a new generation of acousto-electronic sensors based on such waves. Full article

Low-frequency traffic noise below 500 Hz is difficult to mitigate because its long wavelengths require impractically large conventional resonators. Here, we report an active-learning-guided inverse-design approach for scalable phononic-crystal-based acoustic metamaterial resonators that simultaneously suppress low-frequency noise transmission and harvest acoustic energy. The approach combines Gaussian process regression surrogate modeling with genetic algorithm optimization to efficiently explore high-dimensional cavity geometries. By iteratively retraining the surrogate with FEM-validated designs, the active-learning process guides the search toward high-performance structures while reducing costly FEM evaluations compared with conventional GA optimization. After geometric scaling, the 2.5D prototype derived from the nine-point optimized cavity achieved a pressure amplification factor of approximately 20 near 490 Hz, while the revolved 3D cavity exhibited amplification exceeding 30 and a transmission loss of approximately 14 dB near the target frequency. Integrated with a mass-loaded five-PZT stack, the device generated 5.5 V_pp and 0.25 mW under 100 dB SPL, corresponding to a normalized power density of 0.58 μW Pa⁻² cm⁻³. These results demonstrate a route toward multifunctional piezoelectric acoustic devices for noise mitigation, localized energy harvesting, and self-powered sensing. Full article

This study aims to demonstrate the feasibility of controlling particle size through a mathematical model in the design of industrially applicable ultrasonic spray nozzles by utilizing the vibrational characteristics of piezoelectric ceramics. A piezoelectric ceramic composition with a low sintering temperature and excellent thermal stability (Curie temperature above 300 °C) was developed and used as a ceramic vibrator. Furthermore, the resonance frequency and nozzle displacement were calculated using the COMSOL program and applied to a mathematical model to design an ultrasonic nozzle capable of producing a spray particle diameter of approximately 30 μm. The designed ultrasonic nozzle was fabricated, and its spray characteristics were analyzed. The consistency of the spray characteristics was examined by comparing them with the mathematical model based on changes in ultrasonic nozzle length, resonance frequency, and fluid viscosity. When the ultrasonic nozzle horn length was 22 mm, the resonance frequency was found to be 42.1 kHz, and at a flow rate of 65 mL/min. the average spray particle size was approximately 30–40 μm, indicating fine and uniform particles. In addition, it can be seen that as the length of the nozzle horn increases, the resonance frequency decreases, reducing the supply energy delivered to the liquid, and the particle size increases as shown in the mathematical analysis. The theoretical separation energy required to atomize pure water at a flow rate of 65 mL/min. is 2100 J, which was found to be greater than all energy loss occurring during the atomization process. However, it can be seen that as the length of the ultrasonic nozzle increases, the maximum atomization volume increases, and as viscosity increases, the energy required to separate a single atomized particle becomes greater. Full article

The open fan as a highly efficient propulsion concept is a promising approach to reduce climate-damaging emissions in aviation. However, the increased vibroacoustic emissions of the fan resulting from the open design lead to elevated cabin noise. Energy harvesting resonators can be used to leverage the piezoelectric effect and to attenuate structural vibrations caused by the acoustic loading simultaneously. To evaluate the potential of a specific configuration of energy harvesting resonators, an investigation of the dynamic interaction between the airframe and the resonators is necessary. Therefore, the eigenmodes and eigenfrequencies of a representative stiffened plate are determined experimentally using modal analysis via laser scanning vibrometry. A finite element model of the stiffened plate with the resonator idealized as a mass–spring element is implemented. The stiffness of this simplified resonator model is calibrated by correlating simulated with experimental results following a model updating approach. Finally, an optimization framework designed to determine the optimal quantity and placement of resonators using the experimentally validated model and representative loads is implemented to maximize both vibroacoustic attenuation and energy harvesting efficiency. The resulting framework serves as a generalized optimization tool capable of systematically optimizing the resonator configuration based on airframe geometry and specified vibroacoustic loading scenarios. Full article

In the context of reducing air transport emissions, operational costs and transitioning to more electric aircraft, there is a growing need to develop new ice protection systems. Resonant electromechanical de-icing (EM-DI) systems take advantage of the resonance to amplify vibration amplitudes applied through piezoelectric actuators, generating stress in the ice layer, enabling its removal. Research conducted on such systems has been focused on simplified or reduced models, and assessment of aircraft-level requirements has seldom been conducted. To overcome this shortcoming, this work proposes a pre-sizing methodology to evaluate the requirements (power consumption and piezoelectric mass) of EM-DI systems. After dividing the protected area into modules to cycle the aircraft de-icing, finite element models including the ice and the modules’ structure are developed. A modal analysis is performed to identify the extensional resonance modes that enable de-icing, and to calculate the necessary power and piezoelectric mass based on shedding criteria. The methodology is illustrated for two typical aircraft configurations: a jet engine single-aisle aircraft (SA) and a regional turboprop aircraft (TP). The results obtained for the EM-DI technology are promising, with apparent power estimates of as little as $2.7\mathrm{kVA}/{\mathrm{m}}^2$ for the SA and $1.28\mathrm{kVA}/{\mathrm{m}}^2$ for the TP. Full article

Resonant electromechanical de-icing uses piezoelectric actuators to generate stresses high enough to fracture and shed ice, offering an energy-efficient alternative to conventional systems. This work focuses on prestressed piezoelectric actuators composed of a ceramic stack clamped between two brackets, addressing limitations of previous designs such as mechanical losses and screw fatigue. A new architecture is proposed, featuring a variable-cross-section screw that concentrates deformation in a thinned central region and brackets bonded to the structure to reduce losses. An analytical sizing method is developed using multi-beam longitudinal vibration modelling and two de-icing criteria, including a newly introduced one. The analysis shows how actuator geometry and modal shapes influence de-icing performance, required voltage, and mechanical stresses, highlighting key trade-offs. A dedicated prototype is designed and experimentally tested, with results in good agreement with the analytical predictions. Full article

To address the need for high electrical insulation, strong immunity to electromagnetic interference, and miniaturized AC electrical-signal detection in complex electromagnetic environments, we propose and experimentally demonstrate a fiber-optic sensor based on a piezoelectric ceramic (PZT)-driven ring tapered-fiber resonator. The applied AC excitation is converted into periodic mechanical deformation through the inverse piezoelectric effect of the PZT, and the resulting strain modulates the resonator response, enabling optical demodulation of the input frequency and amplitude. A comprehensive figure of merit was introduced to optimize the tapered-fiber geometry, yielding an optimal waist diameter of approximately 10 μm. The sensor can effectively distinguish both single- and dual-frequency AC signals. Over the range of 50–500 Hz, the demodulated frequency agrees closely with the input frequency, with a linear fitting coefficient of 0.9999. At a fixed driving frequency of 250 Hz, the amplitude of the characteristic spectral peak increases nearly linearly with the input voltage amplitude, with a fitting coefficient of 0.9945. The device also exhibits good stability over 30–150 °C and during 70 h of continuous operation. With its simple structure, low cost, and strong immunity to electromagnetic interference, this sensor provides a practical solution for AC electrical-signal detection in complex environments. Full article

High-frequency surface acoustic wave (SAW) devices require piezoelectric thin films combining strong electromechanical coupling, high acoustic velocity, and compatibility with scalable fabrication. Lithium niobate (LiNbO₃) is a promising material, but the growth of high-quality thin films remains challenging because of lithium volatility and process-control issues. In this work, chemical beam epitaxy (CBE) was investigated as an alternative route for the deposition of c-axis-oriented LiNbO₃ thin films on C-plane sapphire at a relatively low growth temperature of 400 °C. Structural characterization confirmed high crystalline quality, with clear (006) and (0012) XRD reflections and a rocking-curve full width at half maximum of 0.04°. To evaluate acoustic performance, a SAW delay line and a one-port resonator were fabricated on 350 nm thick films using e-beam lithography. The devices operated in the 1–3 GHz range and exhibited electromechanical coupling factors of about 0.3% for the Rayleigh mode at 1.7 GHz and 3% for the Sezawa mode at 2.75 GHz. Propagation velocities ranged from 5094 to 8250 m/s, and the Rayleigh-mode resonator quality factor reached about 500. These results demonstrate the feasibility of CBE-grown LiNbO₃ films for SAW device applications. Full article

To address the issue of traditional bistable vibration energy harvesters (BVEHs) being prone to becoming trapped in a single potential well—which results in a narrowed energy harvesting bandwidth and reduced efficiency—this paper proposes a method that utilizes the nonlinear electromagnetic force generated during the induction process to modulate the kinematic behavior of the oscillator. The characteristics and influencing factors of the nonlinear force produced during electromagnetic induction are analyzed. A dual-cantilever beam structure is designed, with an iron-core coil and a magnet placed at the respective free ends. A mathematical model of a piezoelectric–electromagnetic coupled bimodal broadband vibration energy harvester is established and numerically simulated. Furthermore, a vertical vibration experimental platform is constructed to conduct frequency sweep tests. The experimental results demonstrate that the proposed piezoelectric–electromagnetic coupled bimodal broadband vibration energy harvester effectively improves energy harvesting efficiency. Within the frequency range of 5–20 Hz, the system exhibits two vibration modes, with resonant frequencies of approximately 7.7 Hz and 15.7 Hz. For a single-layer PVDF piezoelectric film, the maximum output power at the first and second resonance points is 8.9 μW and 9.7 μW, respectively. The electromagnetic module achieves maximum output powers of 0.39 W and 0.71 W. Moreover, within the frequency ranges of 6.3–9.8 Hz and 14–17.7 Hz (a total bandwidth of 7.2 Hz), the device maintains a stable power output. The effective bandwidth is broadened by approximately 80%, demonstrating excellent broadband performance. Full article
