This article investigates energy harvesting methods designed to capture energy from the alternating magnetic field surrounding a current-carrying conductor. The study focuses on the use of piezoelectric transducers in both monolithic and bimorph configurations. Experimental tests were conducted using vibrating beam structures composed of a single-layer piezoelectric material as well as bimorph piezoelectric composites, both utilizing lead zirconate titanate (PZT) as the active material. The results demonstrate a significant improvement in energy harvesting efficiency when using the bimorph configuration. Specifically, the bimorph-based system generated a peak voltage of 4.26 V and a current of 127.16 μA, resulting in an RMS power output of 272.48 μW. The operating principles, signal conditioning strategies, and structural differences in the evaluated designs are discussed in detail. The outcomes indicate the potential of such systems for powering autonomous sensors in low-power industrial monitoring applications. Full article

With the development of technology, MEMS microphones, which are small-sized and highly uniform, have been applied extensively. To improve their reliability in extreme environment and overcome the constraints of traditional microphones, this article presents a piezoelectric bimorph MEMS microphone using ${\mathrm{Al}}_{0.8}{\mathrm{Sc}}_{0.2}\mathrm{N}$. In the article, the high robustness of piezoelectric microphones and the reasons for choosing ${\mathrm{Al}}_{0.8}{\mathrm{Sc}}_{0.2}\mathrm{N}$ as piezoelectric materials are described. The sensitivity of an ${\mathrm{Al}}_{0.8}{\mathrm{Sc}}_{0.2}\mathrm{N}$-based piezoelectric bimorph compared with the traditional structure are revealed through FEA. Subsequently, a lumped element microphone model is constructed and all noise sources are evaluated comprehensively. The difference in output noise caused by different structures is calculated. The designed piezoelectric microphone, which comprises eight triangular cantilever beams, was fabricated on a chip with an area of 900 $\mu$m × 900 $\mathrm{\mu }$m. The sensitivity of the designed microphone achieves 1.68 mV/Pa, with a noise floor of −110 dBA and SNR of 54.5 dB. The acoustic overload point of the microphone stands at 147 dB SPL, and following the impact test, the survival rate was 100%. Compared to traditional MEMS microphones, the microphone achieves a dynamic range of 107.5 dB. Full article

This paper presents the design, development, and investigation of a novel piezoelectric inertial motor whose target application is the low Earth orbit (LEO) temperature conditions. The motor utilizes the inertial stick–slip principle, driven by the first bending mode of three piezoelectric bimorph plates, and is compact and lightweight, with a total volume of 443 cm³ and a mass of 28.14 g. Numerical simulations and experimental investigations were conducted to assess the mechanical and electromechanical performance of the motor in a temperature range from −20 °C to 40 °C. The results show that the motor’s resonant frequency decreases from 12,810 Hz at −20 °C to 12,640 Hz at 40 °C, with a total deviation of 170 Hz. The displacement amplitude increased from 12.61 μm to 13.31 μm across the same temperature range, indicating an improved mechanical response at higher temperatures. The motor achieved a maximum angular speed up to 1200 RPM and a stall torque of 13.1 N·mm at an excitation voltage amplitude of 180 V_p-p. The simple and scalable design, combined with its stability under varying temperature conditions, makes it well suited for small satellite applications, particularly in precision positioning tasks such as satellite orientation and free-space optical (FSO) communications. Full article

The presented article is about the axisymmetric deformation of an annular one-dimensional hexagonal piezoelectric quasicrystal actuator/sensor with different configurations, analyzed by the three-dimensional theory of piezoelectricity coupled with phonon and phason fields. The state space method is utilized to recast the basic equations of one-dimensional hexagonal piezoelectric quasicrystals into the transfer matrix form, and the state space equations of a laminated annular piezoelectric quasicrystal actuator/sensor are obtained. By virtue of the finite Hankel transform, the ordinary differential equations with constant coefficients for an annular quasicrystal actuator/sensor with a generalized elastic simple support boundary condition are derived. Subsequently, the propagator matrix method and inverse Hankel transform are used together to achieve the exact axisymmetric solution for the annular one-dimensional hexagonal piezoelectric quasicrystal actuator/sensor. Numerical illustrations are presented to investigate the influences of the thickness-to-span ratio on a single-layer annular piezoelectric quasicrystal actuator/sensor subjected to different top surface loads, and the effect of material parameters is also presented. Afterward, the present model is applied to compare the performance of different piezoelectric quasicrystal actuator/sensor configurations: the quasicrystal multilayer, quasicrystal unimorph, and quasicrystal bimorph. Full article

This work describes a self-powered wireless temperature sensor platform that can be used for foot ulceration monitoring for diabetic patients. The proposed self-powered sensor platform consists of a piezoelectric bimorph, a power conditioning circuit, a temperature sensor readout circuit, and a wireless module. The piezoelectric bimorph mounted inside the shoe effectively converts the foot movement into electric energy that can power the entire sensor platform. Furthermore, a sensor platform was designed, considering the energy requirement of 4.826 mJ for transmitting one data packet of 18 bytes. The self-powered sensor platform prototype was evaluated with five test subjects with different weights and foot shapes; the test results show the subjects had to walk an average of 119.6 s to transmit the first data packet and an additional average of 71.2 s to transmit the subsequent data packet. The temperature sensor showed a resolution of 0.1 °C and a sensitivity of 56.7 mV/°C with a power conditioning circuit efficiency of 74.5%. Full article

This research presents the development and evaluation of a miniature autonomous robot inspired by insect locomotion, capable of bidirectional movement. The robot incorporates two piezoelectric bimorph resonators, 3D-printed legs, an electronic power circuit, and a battery-operated microcontroller. Each piezoelectric motor features ceramic plates measuring 15 × 1.5 × 0.6 ${\mathrm{m}\mathrm{m}}^3$ and weighing 0.1 g, with an optimized electrode layout. The bimorphs vibrate at two flexural modes with resonant frequencies of approximately 70 and 100 kHz. The strategic placement of the 3D-printed legs converts out-of-plane motion into effective forward or backward propulsion, depending on the vibration mode. A differential drive configuration, using the two parallel piezoelectric motors and calibrated excitation signals from the microcontroller, allows for arbitrary path navigation. The fully assembled robot measures 29 × 17 × 18 ${\mathrm{m}\mathrm{m}}^3$ and weighs 7.4 g. The robot was tested on a glass surface, reaching a maximum speed of 70 mm/s and a rotational speed of up to 190 deg./s, with power consumption of 50 mW, a cost of transport of 10, and an estimated continuous operation time of approximately 6.7 h. The robot successfully followed pre-programmed paths, demonstrating its precise control and agility in navigating complex environments, marking a significant advancement in insect-scale autonomous robotics. Full article

Electrical devices are integral to daily life, but limited battery life remains a significant issue. A proposed solution is to convert dissipated energy from human motion into electricity using piezoelectric materials. This study investigates lead–zirconate–titanate (PZT) piezoelectric materials in bimorph configuration, conducts performance tests to understand their characteristics and determine the optimal load resistance, and develops an energy-harvesting prototype. Performance tests adjusted input parameters and varied load resistance and input magnitude to optimize power gained from the PZT bimorph. A suitable human movement for the application of the bimorph is a mouse-clicking motion by fingers. A prototype was created by integrating the bimorph into a computer mouse to capture energy from clicks. The results showed that the deformation rate of the PZTs, input magnitude, and resistance load were key factors in optimization. The bimorph configuration produced 0.34 mW of power and 5.5 V at an optimum load of 5072 Ω, requiring less effort to generate electricity. For the computer mouse energy harvester case, it yielded a total average power of approximately 38.4 μW per click with a click frequency of 4 Hz. This power could be used to support IoT devices such as human sensors (e.g., CO₂, temperature, and pulse sensors) and smart home sensors, enabling comprehensive health and environmental monitoring. In conclusion, input specifications, magnitude, and load resistance are essential for optimizing piezoelectric energy harvesters. Full article

A typical piezoelectric energy harvester is a bimorph cantilever with two layers of piezoelectric material on both sides of a flexible substrate. Piezoelectric layers of lead-based materials, typically lead zirconate titanate, have been mainly used due to their outstanding piezoelectric properties. However, due to lead toxicity and environmental problems, there is a need to replace them with environmentally benign materials. Here, our main efforts were focused on the preparation of hafnium-doped barium titanate (BaHf_xTi_1−xO₃; BHT) sol–gel materials. The original process developed makes it possible to obtain a highly concentrated sol without strong organic complexing agents. Sol aging and concentration can be controlled to obtain a time-stable sol for a few months at room temperature, with desired viscosity and colloidal sizes. Densified bulk materials obtained from this optimized sol are compared with a solid-state synthesis, and both show good electromechanical properties: their thickness coupling factor k_t values are around 53% and 47%, respectively, and their converse piezoelectric coefficient $d_{33}^{\ast }$ values are around 420 and 330 pm/V, respectively. According to the electromechanical properties, the theoretical behavior in a bimorph configuration can be simulated to predict the resonance and anti-resonance frequencies and the corresponding output power values to help to design the final device. In the present case, the bimorph configuration based on BHT sol–gel material is designed to harvest ambient vibrations at low frequency (<200 Hz). It gives a maximum normalized volumetric power density of 0.03 µW/mm³/Hz/g² at 154 Hz under an acceleration of 0.05 m/s². Full article

In order to solve the problem of low response frequency and poor consistency of conventional yarn grippers in weft accumulators, in this study, a piezoelectric yarn gripper is used instead of conventional yarn grippers and the motion characteristics of its actuator are studied. This gripper uses a bimorph piezoelectric bending actuator with a low-cost, well integrated self-sensing method based on charge measurement. The modeling of the piezoelectric micromanipulator is based on the piezoelectric and Euler–Bernoulli beam equations. The static and dynamic characteristics of the piezoelectric actuator as well as the self-sensing capability were experimentally tested. The experimental results show that the maximum output displacement at the end of the piezoelectric actuator is 834 μm, and the maximum output force is 388 μN at 150 V driving voltage. The stability and consistency of its response are also very good, with a response speed of 24 ms. The self-sensing test of the output force also proved the feasibility of the self-sensing method used, with an error of 0.74%. The piezoelectric yarn gripper studied in this paper is promising for practical clamping applications. Full article

In this paper, we present research on a novel low-profile piezoelectric rotary motor with a triangle-shaped stator. The stator of the motor comprises three interconnected piezoelectric bimorph plates forming an equilateral triangle. Bimorph plates consist of a passive layer fabricated from stainless steel and four piezo ceramic plates glued to the upper and lower surfaces. Furthermore, spherical contacts are positioned on each bimorph plate at an offset from the plate’s center. Vibrations from the stator are induced by a single sawtooth-type electric signal while the frequency of the excitation signal is close to the resonant frequency of the second out-of-plane bending mode of the bimorph plate. The offset of the spherical contacts allows for a half-elliptical motion trajectory. By contrast, the forward and backward motion velocities of the contacts differ due to the asymmetrical excitation signal. The inertial principle of the motor and the angular motion of the rotor were obtained. Numerical and experimental investigations showed that the motor operates at a frequency of 21.18 kHz and achieves a maximum angular speed of 118 RPM at a voltage of 200 V_p-p. Additionally, an output torque of 18.3 mN·mm was obtained under the same voltage. The ratio between motor torque and weight is 36 mN·mm/g, while the ratio of angular speed and weight is 28.09 RPM/g. Full article

The subject of this article is an experimental analysis of the control system of a composite-based piezoelectric actuator and an aluminum-based piezoelectric actuator. Analysis was performed for both the unimorph and bimorph structures. To carry out laboratory research, two piezoelectric actuators with a cantilever sandwich beam structure were manufactured. In the first beam, the carrier layer was made of glass-reinforced epoxy composite (FR4), and in the second beam, it was made of 1050 aluminum. A linear mathematical model of both actuators was also developed. A modification of the method of selecting weights in the LQR control algorithm for a cantilever-type piezoelectric actuator was proposed. The weights in the R matrix for the actuator containing a carrier layer made of stiffer material should be smaller than those for the actuator containing a carrier layer made of less stiff material. Additionally, regardless of the carrier layer material, in the case of a bimorph, the weight in the R matrix that corresponds to the control voltage of the compressing MFC patch should be smaller than the weight corresponding to the control voltage of the stretching MFC patch. Full article

Mechanical vibrational energy, which is provided by continuous or discontinuous motion, is an infinite source of energy that may be found anywhere. This source may be utilized to generate electricity to replenish batteries or directly power electrical equipment thanks to energy harvesters. The new gadgets are based on the utilization of piezoelectric materials, which can transform vibrating mechanical energy into useable electrical energy owing to their intrinsic qualities. The purpose of this article is to highlight developments in three independent but closely connected multidisciplinary domains, starting with the piezoelectric materials and related manufacturing technologies related to the structure and specific application; the paper presents the state of the art of materials that possess the piezoelectric property, from classic inorganics such as PZT to lead-free materials, including biodegradable and biocompatible materials. The second domain is the choice of harvester structure, which allows the piezoelectric material to flex or deform while retaining mechanical dependability. Finally, developments in the design of electrical interface circuits for readout and storage of electrical energy given by piezoelectric to improve charge management efficiency are discussed. Full article

To align a pair of optical fibers, it is required that the micro actuators used be small and have the characteristics of high accuracy and fast response time. A trapezoidal piezoelectric bimorph actuator was proposed for pushing and pulling an optical fiber. Based on a mathematical model and finite element model established in this paper, we analyzed the output displacement and output force of the proposed trapezoidal piezoelectric actuator under the influence of structural parameters. Since the piezoelectric bimorph actuator had a hysteresis effect, we applied particle swarm optimization to establish a Prandtl–Ishlinskii (PI) model for actuator and parameter identification. Then, two control methods, namely feedforward control considering hysteresis effects and fuzzy proportional-integral-derivative (PID) control employing feedback, were proposed. Finally, a composite control model combining the two control methods with fewer tracking errors was designed. The results show that the output displacement of this actuator is larger than that of a rectangular one. Additionally, the fuzzy PID control has a lower response time (15 ms) and an overshoot (5%). Full article

This paper reports two piezoelectric materials of lead zirconium titanate (PZT) and aluminum nitride (AlN) used to simulate microelectromechanical system (MEMS) speakers, which inevitably suffered deflections as induced via the stress gradient during the fabrication processes. The main issue is the vibrated deflection from the diaphragm that influences the sound pressure level (SPL) of MEMS speakers. To comprehend the correlation between the geometry of the diaphragm and vibration deflection in cantilevers with the same condition of activated voltage and frequency, we compared four types of geometries of cantilevers including square, hexagon, octagon, and decagon in triangular membranes with unimorphic and bimorphic composition by utilizing finite element method (FEM) for physical and structural analyses. The size of different geometric speakers did not exceed 10.39 mm²; the simulation results reveal that under the same condition of activated voltage, the associated acoustic performance, such as SPL for AlN, is in good comparison with the simulation results of the published literature. These FEM simulation results of different types of cantilever geometries provide a methodology design toward practical applications of piezoelectric MEMS speakers in the acoustic performance of stress gradient-induced deflection in triangular bimorphic membranes. Full article

This work presents a novel development of the impact-based mechanism for piezoelectric vibration energy harvesters. More precisely, the effect of an impacting mass on a cantilever piezoelectric transducer is studied both in terms of the tip mass value attached to the cantilever and impact position to find an optimal condition for power extraction. At first, the study is carried out by means of parametric analyses at varying tip mass and impact position on a unimorph MEMS cantilever, and a suitable physical interpretation of the associated electromechanical response is given. The effect of multiple impacts is also considered. From the analysis, it emerges that the most effective configuration, in terms of power output, is an impact at the cantilever tip without a tip mass. By changing the value of the tip mass, a sub-optimal impact position along the beam axis can also be identified. Moreover, the effect of a tip mass is deleterious on the power performance, contrary to the well-known case of a resonant energy harvester. A mesoscale prototype with a bimorph transducer is fabricated and tested to validate the computational models. The comparison shows a good agreement between numerical models and the experiments. The proposed approach is promising in the field of consumer electronics, such as wearable devices, in which the impact-based device moves at the frequencies of human movement and is much lower than those of microsystems. Full article
