Search Results (22)

Search Parameters:
Keywords = photoresistor

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
19 pages, 7457 KiB
Article
Preparation and Photoelectric Properties of Nanostructured Native Oxide of Gallium Monoselenide with Applications in Gas Sensors
by Veaceslav Sprincean, Alexandru Macovei, Liviu Leontie, Aurelian Carlescu, Silviu Gurlui and Mihail Caraman
J. Compos. Sci. 2025, 9(4), 194; https://doi.org/10.3390/jcs9040194 - 19 Apr 2025
Viewed by 725
Abstract
Using the Bridgman technique, GaSe single crystals were obtained which were mechanically split into plane-parallel plates with a wide range of thicknesses. By heat treatment in air at 820 °C and 900 °C, for 30 min and 6 h, micro- and nanocomposite layers [...] Read more.
Using the Bridgman technique, GaSe single crystals were obtained which were mechanically split into plane-parallel plates with a wide range of thicknesses. By heat treatment in air at 820 °C and 900 °C, for 30 min and 6 h, micro- and nanocomposite layers of Ga2Se3–Ga2O3 and β–Ga2O3 (native oxide) with surfaces made of nanowires/nanoribbons were obtained. The obtained composite Ga2Se3–Ga2O3 and nanostructured β–Ga2O3 are semiconductor materials with band gaps of 2.21 eV and 4.60 eV (gallium oxide) and photosensitivity bands in the green–red and ultraviolet-C regions that peaked at 590 nm and 262 nm. For an applied voltage of 50 V, the dark current in the photodetector based on the nanostructured β–Ga2O3 layer was of 8.0 × 10−13 A and increased to 9.5 × 10−8 A upon 200 s excitation with 254 nm-wavelength radiation with a power density of 15 mW/cm2. The increase and decrease in the photocurrent are described by an exponential function with time constants of τ1r = 0.92 s, τ2r = 14.0 s, τ1d = 2.18 s, τ2d = 24 s, τ1r = 0.88 s, τ2r = 12.2 s, τ1d = 1.69 s, and τ2d = 16.3 s, respectively, for the photodetector based on the Ga2Se3–Ga2S3–GaSe composite. Photoresistors based on the obtained Ga2Se3–Ga2O3 composite and nanostructured β–Ga2O3 layers show photosensitivity bands in the spectral range of electronic absorption bands of ozone in the same green–red and ultraviolet-C regions, and can serve as ozone sensors (detectors). Full article
Show Figures

Figure 1

15 pages, 7114 KiB
Article
Effects of the Interface Properties on the Performance of UV-C Photoresistors: Gallium Oxide as Case Study
by Maura Pavesi, Antonella Parisini, Pietro Calvi, Alessio Bosio and Roberto Fornari
Sensors 2025, 25(2), 345; https://doi.org/10.3390/s25020345 - 9 Jan 2025
Viewed by 884
Abstract
Electrical contacts are of the greatest importance as they decisively contribute to the overall performance of photoresistors. Undoped κ-Ga2O3 is an ideal material for photoresistors with high performance in the UV-C spectral region thanks to its intrinsic solar blindness and [...] Read more.
Electrical contacts are of the greatest importance as they decisively contribute to the overall performance of photoresistors. Undoped κ-Ga2O3 is an ideal material for photoresistors with high performance in the UV-C spectral region thanks to its intrinsic solar blindness and extremely low dark current. The quality assessment of the contact/κ-Ga2O3 interface is therefore of paramount importance. The transfer length method is not applicable to undoped Ga2O3 because the interface with several metals shows a non-ohmic character, and a non-equivalent contact resistance could restrict its applicability. In this work, a new methodological procedure to evaluate the quality of contact interface and its effect on the sensing performance of UV-C photoresistors is presented, using the SnO2−x/κ-Ga2O3 contact interface as a case study. The proposed method includes a critical comparison between two-point and four-point probe measurements, over a wide range of voltages. The investigation showed that the effect of contact resistance is more pronounced at low voltages. The presented method can be easily extended to any kind of metal/semiconductor or degenerate-semiconductor/semiconductor interface. Full article
(This article belongs to the Special Issue Recent Advances of Optoelectronic Devices and Semiconductor Sensors)
Show Figures

Figure 1

15 pages, 4222 KiB
Article
Development and Evaluation of Regolith Mass Estimation Sensor Based on Photoresist Effect
by Arkadiusz Tkacz and Karol Seweryn
Aerospace 2024, 11(12), 963; https://doi.org/10.3390/aerospace11120963 - 23 Nov 2024
Viewed by 818
Abstract
This paper presents the design, implementation, and laboratory validation of an optoelectronic-based mass estimation sensor for regolith sampling devices. The sensor integrates multiple photoresistors into the walls of a shovel of a sampling device, where the sensors detect varying levels of light occlusion [...] Read more.
This paper presents the design, implementation, and laboratory validation of an optoelectronic-based mass estimation sensor for regolith sampling devices. The sensor integrates multiple photoresistors into the walls of a shovel of a sampling device, where the sensors detect varying levels of light occlusion caused by the deposited regolith. By analyzing the output signals from these photoresistors, the sensor estimates the mass of the sampled regolith. The device is designed to handle a typical sample mass range of 100–300 g. Laboratory tests demonstrated that the sensor can estimate the regolith mass with a relative error of approximately 23%, which is suitable for early-stage applications where rapid, non-invasive mass estimation is essential. The shown level of accuracy underscores the potential for further refining the calibration process, enhancing sensor sensitivity, and integrating multi-sensor approaches to improve performance. This conceptual study highlights the feasibility of using optoelectronic sensors for regolith mass estimation, paving the way for future innovations in ISRU missions and other granular material sampling applications. Future work will focus on the optimization of photoresistor placements, refining the calibration process, and enhancing sensor sensitivity to improve the accuracy of mass estimation. Full article
(This article belongs to the Special Issue Planetary Exploration)
Show Figures

Figure 1

37 pages, 10262 KiB
Article
Dependability Assessment of a Dual-Axis Solar Tracking Prototype Using a Maintenance-Oriented Metric System
by Raul Rotar, Flavius Maxim Petcuț, Robert Susany, Flavius Oprițoiu and Mircea Vlăduțiu
Appl. Syst. Innov. 2024, 7(4), 67; https://doi.org/10.3390/asi7040067 - 31 Jul 2024
Cited by 6 | Viewed by 3495
Abstract
This study presents a numerical method for evaluating the maintainability of a dual-axis solar tracking system that can be deployed in residential areas for improved energy production. The purpose of this research manuscript is threefold. It targets the following objectives: (i) First, we [...] Read more.
This study presents a numerical method for evaluating the maintainability of a dual-axis solar tracking system that can be deployed in residential areas for improved energy production. The purpose of this research manuscript is threefold. It targets the following objectives: (i) First, we present the construction of a self-sufficient dual-axis solar tracking system based on a low-power electronic schematic that requires only one motor driver to control the azimuth and elevation angles of the photovoltaic (PV) panel. The automated system’s main electronic equipment comprises 1 × Arduino Mega2560 microcontroller unit (MCU), 1 × TB6560 stepper driver module, 2 × stepper motors, 2 × relay modules, 1 × solar charge controller, 1 × accumulator, and 1 × voltage convertor. Additional hardware components such as photoresistors, mechanical limit switches, rotary encoders, voltage, and current sensors are also included to complete the automation cycle of the solar tracking system. (ii) Second, the Arduino Mega 2560 prototyping board is replaced by a custom-made and low-cost application-specific printed circuit board (ASPCB) based on the AVR controller. The MCU’s possible fault domain is then further defined by examining the risks of the poor manufacturing process, which can lead to stuck-at-0 (Sa0) and stuck-at-1 (Sa1) defects. Besides these issues, other challenges such as component modularity, installation accessibility, and hardware failures can affect the automated system’s serviceability. (iii) Third, we propose a novel set of maintenance-oriented metrics that combine the previously identified variables to provide a maintainability index (MI), which serves as a valuable tool for evaluating, optimizing, and maintaining complex systems such as solar tracking devices. The experimental data show that the computed MI improves the system’s maintainability and enhances repair operations, increasing uptime. Full article
Show Figures

Figure 1

5 pages, 840 KiB
Proceeding Paper
RGB LED Sensor for Fat Quantification in Milk
by Marina Salukova, Anastasiia Surkova, Yana Shmakova, Natalya Samokhina, Julia Kostyuchenko, Alina Parshina, Ildar Ibatullin and Andrey Bogomolov
Eng. Proc. 2023, 48(1), 17; https://doi.org/10.3390/CSAC2023-14927 - 7 Oct 2023
Viewed by 1226
Abstract
In this study, a portable desktop analyzer for the determination of fat content in milk is introduced. The prototype of the sensor consists of three light-emitting diodes (red, green, and blue) as a light source. The transmitted light is detected by a photoresistor [...] Read more.
In this study, a portable desktop analyzer for the determination of fat content in milk is introduced. The prototype of the sensor consists of three light-emitting diodes (red, green, and blue) as a light source. The transmitted light is detected by a photoresistor and continuous voltage measurements provided by the microcontroller, and is recorded by a computer. The resulting univariate and multivariate models show that the developed analytical device is capable of determining fat content in raw and homogenized milk with sufficient accuracy. Full article
Show Figures

Figure 1

15 pages, 4818 KiB
Article
An Optoelectronics-Based Compressive Force Sensor with Scalable Sensitivity
by Zachary Pennel, Michael McGeehan and Keat Ghee Ong
Sensors 2023, 23(14), 6513; https://doi.org/10.3390/s23146513 - 19 Jul 2023
Cited by 1 | Viewed by 1953
Abstract
There is an increasing need to accurately measure compressive force for biomedical and industrial applications. However, this need has not been fully addressed, as many sensors are bulky, have high power requirements, and/or are susceptible to electromagnetic interference. This paper presents an optoelectronics-based [...] Read more.
There is an increasing need to accurately measure compressive force for biomedical and industrial applications. However, this need has not been fully addressed, as many sensors are bulky, have high power requirements, and/or are susceptible to electromagnetic interference. This paper presents an optoelectronics-based force sensor that can overcome the limitations of many sensors in the market. The sensor uses a light emitting diode (LED) to transmit visible broad-spectrum light into a photoresistor through an optically clear spacer on top of an elastomeric medium. In the absence of an external force, the light path is mostly blocked by the opaque elastomeric medium. Under a compressive force, the clear spacer compresses the elastomer, moving itself into the light path, and thus increasing the overall light transmission. The amount of light received by the photoresistor is used to quantify compressive force based on elastomer displacement/compression and a priori knowledge of elastomer stiffness. This sensing scheme was tested under eight different configurations: two different sized sensors with four types of elastomers per size (20A neoprene, 30A neoprene, 50A neoprene, and 75A styrene–butadiene rubber (SBR)). All configurations measured force with R2 > 0.97, RMSE < 1.9 N, and sensitivity values ranging from 17 to 485 N/V. This sensing scheme provides a low-cost, low-power method for accurate force sensing with a wide force range. Full article
(This article belongs to the Special Issue Wearable Sensors and Mobile Apps in Human Health Monitoring)
Show Figures

Figure 1

9 pages, 2025 KiB
Article
Effect of Manganese Alloying on Infrared Detectors Made of Pb1−xMnxTe/CdTe Multilayer Composite
by Sergij Chusnutdinow, Alexander Kazakov, Rafał Jakieła, Michał Szot, Steffen Schreyeck, Karl Brunner and Grzegorz Karczewski
Materials 2023, 16(12), 4211; https://doi.org/10.3390/ma16124211 - 6 Jun 2023
Cited by 2 | Viewed by 1532
Abstract
The properties of Pb1−xMnxTe/CdTe multilayer composite grown by molecular beam epitaxy on a GaAs substrate were studied. The study included morphological characterization by X-ray diffraction, scanning electron microscopy, secondary ion mass spectroscopy, as well as electron transport and optical [...] Read more.
The properties of Pb1−xMnxTe/CdTe multilayer composite grown by molecular beam epitaxy on a GaAs substrate were studied. The study included morphological characterization by X-ray diffraction, scanning electron microscopy, secondary ion mass spectroscopy, as well as electron transport and optical spectroscopy measurements. The main focus of the study was on the sensing properties of photoresistors made of Pb1−xMnxTe/CdTe in the infrared spectral region. It was shown that the presence of Mn in the Pb1−xMnxTe conductive layers shifted the cut-off wavelength toward blue and weakened the spectral sensitivity of the photoresistors. The first effect was due to an increase in the energy gap of Pb1−xMnxTe with an increase in Mn concentration, and the second was due to a pronounced deterioration in the crystal quality of the multilayers owing to the presence of Mn atoms, as shown by the morphological analysis. Full article
Show Figures

Figure 1

6 pages, 2224 KiB
Proceeding Paper
Study of Photoresistor Fabrication Based on Mercury Chalcogenides Applying Various Ligand Exchanges
by Teodora Milenkovich, Ivan Alekseevich Shuklov, Alaa Alddin Mardini and Victor Sergeevich Popov
Mater. Proc. 2023, 14(1), 21; https://doi.org/10.3390/IOCN2023-14500 - 5 May 2023
Cited by 2 | Viewed by 1320
Abstract
The presented paper describes the study of ligand-exchange dependent properties of mercury chalcogenides (HgS, HgTe) colloidal quantum-dot thin films. Thin films of colloidal quantum dots of mercury telluride and mercury sulfide were prepared using a layer-by-layer deposition technique applying dip-coating and spin-coating methods. [...] Read more.
The presented paper describes the study of ligand-exchange dependent properties of mercury chalcogenides (HgS, HgTe) colloidal quantum-dot thin films. Thin films of colloidal quantum dots of mercury telluride and mercury sulfide were prepared using a layer-by-layer deposition technique applying dip-coating and spin-coating methods. The impact of the synthetic procedure of quantum dots, solvent and concentration of colloidal solution on the thin films’ properties was analyzed. By using concentrated colloidal solutions in tetrachloroethylene, we succeeded in the preparation of homogeneous thin films with minimal roughness. The surface morphology and thickness of the thin films were determined using AFM. The voltage–current characteristics of photosensitive devices applying various ligand exchanges were investigated. Full article
(This article belongs to the Proceedings of The 4th International Online Conference on Nanomaterials)
Show Figures

Figure 1

15 pages, 7307 KiB
Article
A Grip Strength Estimation Method Using a Novel Flexible Sensor under Different Wrist Angles
by Yina Wang, Liwei Zheng, Junyou Yang and Shuoyu Wang
Sensors 2022, 22(5), 2002; https://doi.org/10.3390/s22052002 - 4 Mar 2022
Cited by 4 | Viewed by 3671
Abstract
It is a considerable challenge to realize the accurate, continuous detection of handgrip strength due to its complexity and uncertainty. To address this issue, a novel grip strength estimation method oriented toward the multi-wrist angle based on the development of a flexible deformation [...] Read more.
It is a considerable challenge to realize the accurate, continuous detection of handgrip strength due to its complexity and uncertainty. To address this issue, a novel grip strength estimation method oriented toward the multi-wrist angle based on the development of a flexible deformation sensor is proposed. The flexible deformation sensor consists of a foaming sponge, a Hall sensor, an LED, and photoresistors (PRs), which can measure the deformation of muscles with grip strength. When the external deformation squeezes the foaming sponge, its density and light intensity change, which is detected by a light-sensitive resistor. The light-sensitive resistor extended to the internal foaming sponge with illuminance complies with the extrusion of muscle deformation to enable relative muscle deformation measurement. Furthermore, to achieve the speed, accuracy, and continuous detection of grip strength with different wrist angles, a new grip strength-arm muscle model is adopted and a one-dimensional convolutional neural network based on the dynamic window is proposed to recognize wrist joints. Finally, all the experimental results demonstrate that our proposed flexible deformation sensor can accurately detect the muscle deformation of the arm, and the designed muscle model and convolutional neural network can continuously predict hand grip at different wrist angles in real-time. Full article
(This article belongs to the Topic Human–Machine Interaction)
Show Figures

Figure 1

13 pages, 2685 KiB
Article
A Study on the Possibility of Measuring Sludge Sedimentation Using Contrast Detection Characteristics of CdS Photoresistors
by Seong-Min Hong, Hyun-Ook Kim and Choong-Gon Kim
Energies 2021, 14(22), 7817; https://doi.org/10.3390/en14227817 - 22 Nov 2021
Viewed by 2276
Abstract
Although operators periodically measure the sludge volume index (SVI) to stabilize the bioreactor and solid–liquid separation during the wastewater treatment process, there is a problem of inconsistency attributed to the subjective judgment of the operator. This study aims to investigate the possibility of [...] Read more.
Although operators periodically measure the sludge volume index (SVI) to stabilize the bioreactor and solid–liquid separation during the wastewater treatment process, there is a problem of inconsistency attributed to the subjective judgment of the operator. This study aims to investigate the possibility of securing objective data by employing CdS (cadmium–sulfur) photoresistors for SVI measurements. The sedimentation velocity of settling sludge was measured using LED (Light Emitting Diode) lights at the same level as the installed CdS photoresistors. As a result of the experiment, the settling velocity of sludge in the CdS photoresistors’ installation position H1 to H8 (non-flocculent settling), H9 to H12 (discrete flocculent settling) and H13 to H18 (zone settling and compressive settling), was 0.594 mm/s, 0.180 mm/s and 0.056 mm/s, respectively. Through this study, it was confirmed that measuring sludge sedimentation using the CdS photoresistors is possible. If the measurement of solid matter in sludge using several sludge sedimentation measurements is enabled in the future, it will be possible to develop calculation algorithms to measure the SVI. Full article
(This article belongs to the Special Issue Sustainable Management of Waste for Renewable Energy Resources)
Show Figures

Figure 1

12 pages, 3104 KiB
Article
A Passive, Skin-Attachable Multi-Sensing Patch Based on Semi-Liquid Alloy Ni-GaIn for Wireless Epidermal Signal Monitoring and Body Motion Capturing
by Shipeng Lin, Jiming Fang, Tianchen Ye, Yan Tao, Shengshun Duan and Jun Wu
Electronics 2021, 10(22), 2778; https://doi.org/10.3390/electronics10222778 - 13 Nov 2021
Cited by 2 | Viewed by 3238
Abstract
Wearable integrated systems that rely on liquid metal commonly require an extremely complicated, high-cost fabrication process, while lacking multiple sensing functions without conductive wires connected to external electronic systems. A multi-sensing wearable patch independent from sophisticated manufacturing method and excessive use of wires [...] Read more.
Wearable integrated systems that rely on liquid metal commonly require an extremely complicated, high-cost fabrication process, while lacking multiple sensing functions without conductive wires connected to external electronic systems. A multi-sensing wearable patch independent from sophisticated manufacturing method and excessive use of wires has yet to be developed. Herein, we introduce a wireless, battery-free, and skin-attachable patch with multiple sensing capacities, utilizing a low-budget, less time-consuming and design-customizable fabrication method. In an effort to achieve our goal, the general sensing system architecture is promoted, which consists of a semi-liquid alloy Ni-GaIn based strain sensor and a co-designed near-field-communication (NFC) tag integrating thermistor, photoresistor, as well as sensor interface circuits, enabling energy-autonomous power supply and wireless data transmission. In human volunteers, the patch was mounted on the skin surface to demonstrate real-time temperature and light intensity signal monitoring. Further evaluation of body motion capturing involved finger bending and swallowing, demonstrating the feasibility of practical applications in different scenarios. Continuous and simultaneous multi-type signal sensing using the wearable patch should enrich the dimensions of measurements of body response to daily activities, unveiling the potential for remote human health monitoring, advanced human–machine interfaces, and other applications of interest. Full article
Show Figures

Figure 1

19 pages, 6003 KiB
Article
Artificial Eyes with Emotion and Light Responsive Pupils for Realistic Humanoid Robots
by Carl Strathearn
Informatics 2021, 8(4), 64; https://doi.org/10.3390/informatics8040064 - 23 Sep 2021
Cited by 2 | Viewed by 6588
Abstract
This study employs a novel 3D engineered robotic eye system with dielectric elastomer actuator (DEA) pupils and a 3D sculpted and colourised gelatin iris membrane to replicate the appearance and materiality of the human eye. A camera system for facial expression analysis (FEA) [...] Read more.
This study employs a novel 3D engineered robotic eye system with dielectric elastomer actuator (DEA) pupils and a 3D sculpted and colourised gelatin iris membrane to replicate the appearance and materiality of the human eye. A camera system for facial expression analysis (FEA) was installed in the left eye, and a photo-resistor for measuring light frequencies in the right. Unlike previous prototypes, this configuration permits the robotic eyes to respond to both light and emotion proximal to a human eye. A series of experiments were undertaken using a pupil tracking headset to monitor test subjects when observing positive and negative video stimuli. A second test measured pupil dilation ranges to high and low light frequencies using a high-powered artificial light. This data was converted into a series of algorithms for servomotor triangulation to control the photosensitive and emotive pupil dilation sequences. The robotic eyes were evaluated against the pupillometric data and video feeds of the human eyes to determine operational accuracy. Finally, the dilating robotic eye system was installed in a realistic humanoid robot (RHR) and comparatively evaluated in a human-robot interaction (HRI) experiment. The results of this study show that the robotic eyes can emulate the average pupil reflex of the human eye under typical light conditions and to positive and negative emotive stimuli. However, the results of the HRI experiment indicate that replicating natural eye contact behaviour was more significant than emulating pupil dilation. Full article
(This article belongs to the Section Human-Computer Interaction)
Show Figures

Figure 1

11 pages, 5833 KiB
Article
MAPbI3 Microrods-Based Photo Resistor Switches: Fabrication and Electrical Characterization
by Ehsan Raza, Fakhra Aziz, Arti Mishra, Noora Jabor Al-Thani and Zubair Ahmad
Materials 2021, 14(16), 4385; https://doi.org/10.3390/ma14164385 - 5 Aug 2021
Cited by 2 | Viewed by 2152
Abstract
The current work proposed the application of methylammonium lead iodide (MAPbI3) perovskite microrods toward photo resistor switches. A metal-semiconductor-metal (MSM) configuration with a structure of silver-MAPbI3(rods)-silver (Ag/MAPbI3/Ag) based photo-resistor was fabricated. The MAPbI3 microrods were prepared [...] Read more.
The current work proposed the application of methylammonium lead iodide (MAPbI3) perovskite microrods toward photo resistor switches. A metal-semiconductor-metal (MSM) configuration with a structure of silver-MAPbI3(rods)-silver (Ag/MAPbI3/Ag) based photo-resistor was fabricated. The MAPbI3 microrods were prepared by adopting a facile low-temperature solution process, and then an independent MAPbI3 microrod was employed to the two-terminal device. The morphological and elemental compositional studies of the fabricated MAPbI3 microrods were performed using FESEM and EDS, respectively. The voltage-dependent electrical behavior and electronic conduction mechanisms of the fabricated photo-resistors were studied using current–voltage (I–V) characteristics. Different conduction mechanisms were observed at different voltage ranges in dark and under illumination. In dark conditions, the conduction behavior was dominated by typical trap-controlled charge transport mechanisms within the investigated voltage range. However, under illumination, the carrier transport is dominated by the current photogenerated mechanism. This study could extend the promising application of perovskite microrods in photo-induced resistor switches and beyond. Full article
(This article belongs to the Special Issue Interfaces in Memristor)
Show Figures

Figure 1

16 pages, 4371 KiB
Article
Studies on the Content of Selected Technology Critical Elements (Germanium, Tellurium and Thallium) in Electronic Waste
by Joanna Willner, Agnieszka Fornalczyk, Magdalena Jablonska-Czapla, Katarzyna Grygoyc and Marzena Rachwal
Materials 2021, 14(13), 3722; https://doi.org/10.3390/ma14133722 - 2 Jul 2021
Cited by 22 | Viewed by 4547
Abstract
The article draws attention to the problem of the presence of metals: germanium (Ge), tellurium (Te), thallium (Tl), and others (Cd, Ba, Co, Mn, Cr, Cu, Ni, Pb, Sr, and Zn) in selected waste of electrical and electronic equipment (WEEE). As a result [...] Read more.
The article draws attention to the problem of the presence of metals: germanium (Ge), tellurium (Te), thallium (Tl), and others (Cd, Ba, Co, Mn, Cr, Cu, Ni, Pb, Sr, and Zn) in selected waste of electrical and electronic equipment (WEEE). As a result of the growing demand for new technologies, the global consumption of TECs has also been increasing. Thus, the amount of metals in circulation, of which the impacts on the environment have not yet been fully understood, is constantly increasing. Due to the low content of these metals in WEEE, they are usually ignored during e-waste analyses. The main aim of this study was to determine the distribution of Ge, Te, and Tl (and other elements) in ground sieve fractions (1.0, 0.5, 0.2, and 0.1 mm) of selected electronic components (solar lamps, solar cell, LED TV screens, LCD screens, photoresistors, photodiodes, phototransistors) and to determine the possible tendency of the concentrations of these metals in fractions. This problem is particularly important because WEEE recycling processes (crushing, grinding, and even collection and transport operations) can lead to dispersion and migration of TCE pollutants into the environment. The quantitative composition of e-waste was identified and confirmed by ICP-MS, ICP-OES and SEM-EDS, and XRD analyses. It was found that Ge, Te, and Tl are concentrated in the finest fractions of ground e-waste, together with Cd and Cr, which may favor the migration of these pollutants in the form of dust during storage and processing of e-waste. Full article
(This article belongs to the Special Issue Research Progress on the Extractive Metallurgy)
Show Figures

Graphical abstract

12 pages, 4899 KiB
Letter
Development and Validation of an Autonomous System for Measurement of Sunshine Duration
by Álvaro B. da Rocha, Eisenhawer de M. Fernandes, Carlos A. C. dos Santos, Júlio M. T. Diniz and Wanderley F. A. Junior
Sensors 2020, 20(16), 4606; https://doi.org/10.3390/s20164606 - 16 Aug 2020
Cited by 88 | Viewed by 2989
Abstract
This paper presented an autonomous electronic system for sunshine duration (SD) monitoring based on the contrast method and developed to operate on a horizontal surface. The prototype uses four photoresistors arranged at 90° in a 20 mm diameter circumference separated by a shading [...] Read more.
This paper presented an autonomous electronic system for sunshine duration (SD) monitoring based on the contrast method and developed to operate on a horizontal surface. The prototype uses four photoresistors arranged at 90° in a 20 mm diameter circumference separated by a shading structure used to create a shadow pattern on the detection element. Photoresistors are inserted in individual signal conditioning circuits based on the association between Wheatstone bridges and operational amplifiers to provide an analog signal to the microcontroller unit. The determination of SD occurs through the implementation of fuzzy logic with numerical calculation methods to estimate the probability (f) of solar disk obstruction and estimate SD values. The system does not require additional adjustments after installation or use of energy sources for operation due to the use of an internal battery with charge recovery by solar panels. Experimental results of the proposed system were validated with the ones provided by a government meteorology station. Statistical analysis of the results showed a confidence index (c) greater than 90%, with a precision of 94.26%. The proposed system is a feasible low-cost solution to the available commercial systems for the measurement of sunshine duration. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1
