A metasurface capable of flexibly manipulating electromagnetic waves to realize holograms presents significant potential in millimeter-wave imaging systems and data storage domains. In this study, full-space three-dimensional holograms are realized from a reflection–transmission integrated reconfigurable metasurface, which can achieve nearly 360° phase coverage in reflection space and 180° phase coverage in transmission space. By adjusting the voltage applied to the constituting electronically tunable meta-atoms of the metasurface, an octahedron hologram constituted by three hologram images in different focal planes is generated in the reflection space at 6.25 GHz. Moreover, a diamond hologram, also composed of three hologram images in different focal planes, is achieved in the transmission space at 6.75 GHz. Both the numerical simulation and experimental measurement are performed to validate the full-space holograms implemented by the modified weighted Gerchberg–Saxton (WGS) algorithm with specific phase distribution in different imaging planes. The obtained results pave the way for a wide range of new applications, such as next-generation three-dimensional displays for immersive viewing experiences, high-capacity optical communication systems with enhanced data encoding capabilities, and ultra-secure anti-counterfeiting solutions that are extremely difficult to replicate. Full article

Acoustic metamaterials (AMs) are artificially structured materials composed of subwavelength units that enable acoustic phenomena not achievable with conventional materials and structures. This review defines and presents a distinct category referred to as soft acoustic metamaterials (SAMs), which use soft materials or reconfigurable structures to achieve enhanced acoustic functionality. These systems make use of the inherent flexibility of their materials or the deformability of their geometry to support passive, active, and adaptive functions. To capture this structural and functional diversity, we introduce a three-dimensional classification that considers geometry, acoustic control mechanisms, and functional responsiveness as interrelated aspects. The geometry is classified into two-dimensional metasurfaces and three-dimensional bulk structures. The control mechanisms include local resonance, phase modulation, attenuation, and structural reconfiguration. The response type refers to whether the system behaves passively, actively, or adaptively. Using this approach, we provide an overview of representative implementations and compare different design approaches to highlight their working principles and application areas. This review presents a structured classification for soft acoustic metamaterials and offers a foundation for future research, with broad potential in intelligent sound systems, wearable acoustics, and architectural applications. Full article

Millimeter-wave (mmWave) antennas and antenna arrays have gained significant attention due to their pivotal role in emerging wireless communication, sensing, and imaging technologies. With the rapid deployment of 5G and the transition toward 6G networks, the demand for compact, high-gain, and reconfigurable mmWave antennas has intensified. This article highlights recent advancements in mmWave antenna technologies, including hybrid beamforming using phased arrays, dynamic beam-steering enabled by liquid crystal and MEMS-based structures, and high-capacity MIMO architectures. We also examine the integration of metamaterials and metasurfaces for miniaturization and gain enhancement. Applications covered include wearable antennas with low-SAR textile substrates, conformal antennas for UAV-based mmWave relays, and high-resolution radar arrays for autonomous vehicles. The study further analyzes innovative fabrication methods such as inkjet and aerosol jet printing, micromachining, and laser direct structuring, along with advanced materials like Kapton, PDMS, and graphene. Numerical modeling techniques such as full-wave EM simulation and machine learning-based optimization are discussed alongside experimental validation approaches. Beyond communications, we assess mmWave systems for biomedical imaging, security screening, and industrial sensing. Key challenges addressed include efficiency degradation at high frequencies, interference mitigation in dense environments, and system-level integration. Finally, future directions, including AI-driven design automation, intelligent reconfigurable surfaces, and integration with quantum and terahertz technologies, are outlined. This comprehensive synthesis aims to serve as a valuable reference for advancing next-generation mmWave antenna systems. Full article

Structural symmetry preservation and breaking play important roles in optical manipulation at subwavelength scales. By precisely engineering the symmetry of the nanostructures, metasurfaces can effectively realize various optical functions such as polarization control, wavefront shaping, and on-chip optical integration, with promising applications in information photonics, bio-detection, and flexible devices. In this article, we review the recent advances in chiral and achiral metasurfaces based on symmetry manipulation. We first introduce the fundamental principles of chiral and achiral metasurfaces, including methods for characterizing chirality and mechanisms for phase modulation. Then, we review the research on chiral metasurfaces based on material type and structural dimensions and related applications in high-sensitivity chiral sensing, reconfigurable chiral modulation, and polarization-selective imaging. We then describe the developments in the application of achiral metasurfaces, particularly in polarization-multiplexed holography, phase-gradient imaging, and polarization-insensitive metalenses. Finally, we provide an outlook on the future development of chiral and achiral metasurfaces. Full article

Millimeter-wave signals experience substantial path loss when penetrating common building materials, hindering seamless indoor coverage from outdoor networks. To address this limitation, we present the 28-GHz “Meta-Window”, a mass-producible, visible transparent device designed to enhance millimeter-wave signal focusing. Fabricated via metal sputtering and etching on a standard soda-lime glass substrate, the meta-window incorporates subwavelength metallic structures arranged in a rotating pattern based on the Pancharatnam–Berry phase principle, enabling 0–360$°$ phase control within the 25–32 GHz frequency band. A 210 mm × 210 mm prototype operating at 28 GHz was constructed using a 69 × 69 array of metasurface unit cells, leveraging planar electromagnetic lens principles. Experimental results demonstrate that the meta-window achieves greater than 20 dB signal focusing gain between 26 and 30 GHz, consistent with full-wave electromagnetic simulations, while maintaining up to 74.93% visible transmittance. This dual transparency—for both visible light and millimeter-wave frequencies—was further validated by a communication prototype system exhibiting a greater than 20 dB signal-to-noise ratio improvement and successful demodulation of a 64-QAM single-carrier signal (1 GHz bandwidth, 28 GHz) with an error vector magnitude of 4.11%. Moreover, cascading the meta-window with a reconfigurable reflecting metasurface antenna array facilitates large-angle beam steering; stable demodulation (error vector magnitude within 6.32%) was achieved within a ±40$°$ range using the same signal parameters. Compared to conventional transmissive metasurfaces, this approach leverages established glass manufacturing techniques and offers potential for direct building integration, providing a promising solution for improving millimeter-wave indoor penetration and coverage. Full article

Artificial metasurfaces can rapidly modulate their electromagnetic scattering properties and the characteristics of echo signals, which can lead to different imaging features in synthetic aperture radar (SAR) imaging results. Based on this, for the first time, this paper proposes an approach for SAR feature reconfiguring based on periodic phase modulation with inter-pulse time bias. Considering the position and energy requirements of the expected reconfigured imaging target, this approach optimizes the metasurface modulation parameters via a dual algorithm collaborative optimization system, i.e., a modulation parameter generation algorithm (MPGA) and a parameter mapping matching algorithm (PMMA). Time-modulated metasurface targets can reconfigure imaging features of different targets at SAR reconnaissance moments under the guidance of optimized modulation parameters obtained using this approach. Compared with the previous single-point target research on the combination of SAR and metasurfaces, this method is expanded to include the combined analysis of multi-point targets and the reconfigurability of SAR features. Experiments have proved that the programmable reconfigurability of different target features (such as passenger plane targets and truck targets) can be achieved in SAR imaging results through dynamic adjustment of the modulation parameter set. The reconfigured imaging features maintain geometric consistency within the resolution error range, and the size and position of the target can be set as required. Full article

With their compact design and versatility, CubeSats have emerged as critical platforms for advancing space exploration and communication technologies. However, achieving reliable and efficient communication in the dynamic and constrained environment of low Earth orbit (LEO) remains a significant challenge. Beam-steering antenna systems offer a promising solution to address these limitations, enabling adaptive communication links with improved gain and coverage. This review article provides a comprehensive analysis of the state-of-the-art in CubeSat communication, concentrating on the latest developments in beam-steering antennas. By synthesizing the findings from recent studies, the key challenges are highlighted, including power constraints, miniaturization, and integration with CubeSat platforms. Furthermore, this paper investigates cutting-edge techniques, such as phased array systems, metasurface-based designs, and reconfigurable antennas, which pave the way for enhanced performance. This study can serve as a resource for researchers and engineers, offering insights into current trends and future opportunities for advancing CubeSat communications through innovative antenna systems. Full article

We present a novel photoreconfigurable metasurface designed for independent and efficient control of electromagnetic waves with identical incident polarization and frequency across the entire spatial domain. The proposed metasurface features a three-layer architecture: a top layer incorporating a gold circular split ring resonator (CSRR) filled with perovskite material and dual C-shaped perovskite resonators; a middle layer of polyimide dielectric; and a bottom layer comprising a perovskite substrate with an oppositely oriented circular split ring resonator filled with gold. By modulating the intensity of a laser beam, we achieve autonomous manipulation of incident circularly polarized terahertz waves in both transmission and reflection modes. Simulation results demonstrate that the metasurface achieves a cross-polarized transmission coefficient of 0.82 without laser illumination and a co-polarization reflection coefficient of 0.8 under laser illumination. Leveraging the geometric phase principle, adjustments to the rotational orientation of the reverse split ring and dual C-shaped perovskite structures enable independent control of transmission and reflection phases. Furthermore, the proposed metasurface induces a +1 order orbital angular momentum in transmission and +2 order in reflection, facilitating beam deflection through metasurface convolution principles. Imaging using metasurface digital imaging technology showcases patterns “NUIST” in reflection and “LOONG” in transmission, illustrating the metasurface design principles via the proposed metasurface. The proposed metasurface’s capability for full-space control and reconfigurability presents promising applications in advanced imaging systems, dynamic beam steering, and tunable terahertz devices, highlighting its potential for future technological advancements. Full article

In order to implement multiple electromagnetic (EM) wave front control, a reconfigurable multifunctional metasurface (RMM) has been investigated in this paper. It can meet the requirements for 6G communication systems. Considering the full-space working modes simultaneously, both reflection and transmission modes, the flexible transmission-reflection-integrated RMM with p-i-n diodes and anisotropic structures is proposed. By introducing a 45°-inclined H-shaped AS and grating-like micro-structure, the polarization conversion of linear to circular polarization (LP-to-CP) is achieved with good angular stability, in the transmission mode from top to bottom. Meanwhile, reflection beam patterns can be tuned by switching four p-i-n diodes to achieve a 1-bit reflection phase, which are embedded in the bottom of unit cells. To demonstrate the multiple reconfigurable abilities of RMMs to regulate EM waves, the RMMs working in polarization conversion mode, transmitted mode, reflected mode, and transmission-reflection-integrated mode are designed and simulated. Furthermore, by encoding two proper reflection sequences with $13\times 13$ elements, reflection beam patterns with two beams and four beams can be achieved, respectively. The simulation results are consistent with the theoretical method. The suggested metasurface is helpful for radar and wireless communications because of its compact size, simple construction, angular stability, and multi-functionality. Full article

Metasurfaces, which are ultrathin planar metamaterials arranged in certain global sequences, interact uniquely with the surrounding light field and exhibit unusual effects of light modulation. Many interesting applications have been discovered based on metasurfaces, particularly in invisibility cloaks. However, most invisibility cloaks are limited to working in specific directions. Achieving effectiveness in multiple directions requires the metasurface to be designed with both perception and modulation capabilities. Current multi-directional metasurface cloak systems are implemented with discrete components rather than an integrated sensing component. Here, we propose an intelligent metasurface cloak system that integrates sensing units, resulting in the cloaking effect with the help of a real-time direction sensor and an adaptive feedback control system. A reconfigurable reflective meta-atom based on phase modulation is presented. Sensing units replace parts of the meta-atoms in the designed tunable metasurface, integrating with an FPGA responsible for measuring the direction and frequency of the incident wave, constituting a closed-loop system together with the feedback parts. Experimental results demonstrate that the metasurface cloak system can recognize the different directions of the incoming wave, and can adaptively manipulate the reflected phase of EM waves to conceal objects without any human participation. Full article

Metasurfaces are considered the most promising technologies for holographic imaging applications due to their exceptional optical properties and capabilities. However, the work on terahertz (THz) metasurface holographic imaging is relatively limited. Here, we propose a THz dielectric geometric-propagation phase metasurface that can operate in dual modes (reflection and transmission) and enable reconfigurable multifunctional holographic imaging. The dual-mode operation is realized by controlling the Fermi energy level (E_f) of the graphene integrated into the metasurface unit, and the reconfigurable three-channel holographic imaging in reflection or transmission mode are achieved by switching the feed polarization among left-handed circular polarization (LCP), right-handed circular polarization (RCP), and linear polarization (LP). The metasurface is designed based on the transmission mode, and a physical model for switching to the reflection mode is established. For the first time, to the best of our knowledge, a reflection–transmission dynamic modulation THz holographic imaging metasurface has been developed. The holographic metasurface operates in transmission mode at E_f = 0.1 eV and in reflection mode at E_f = 0.9 eV. Compared with recently published holographic imaging metasurfaces, the proposed metasurface offers the following advantages: high holographic efficiencies (42.5% to 49%), more holographic imaging channels, dynamic modulation dual-mode operations, and reconfigurability. The simulation results match the theory. Full article

The deployment of wireless communication networks in the E band (60–90 GHz) requires highly flexible, real-time, and precise tunability to optimize power transmission amidst diffraction, obstacles, and scattering challenges. This paper proposes an innovative reconfigurable metasurface reflect array design capable of achieving a dynamic phase range of 312 degrees with less than 1 dB of loss. The design integrates two types of unit cells and employs piezoelectric crystal as the tuning element. Simulation results illustrate the feasibility of beam focusing and accurate beam steering within a range of ±3 degrees. Furthermore, the proposed reconfigurable metasurface reflector demonstrates an antenna gain comparable to that of a dish antenna with the same aperture size. Full article

Conventional beamforming methods for reconfigurable reflector antennas assume full control over the amplitude and phase of the reflected field. Here, we develop a novel beamforming methodology for reflecting Programmable Metasurfaces (PMS) with capacitive memory. Although utilizing such fully reactive PMS simplifies antenna design and reduces energy consumption, the PMS reflection magnitude is unity and thus a global optimization of the reflection phases over the PMS unit cells is required in each beamforming scenario. We propose an implementation of such an optimization method rooted in the traditional Fourier transform-based beamforming and evaluate its performance. Additionally, we show that a pair of trained feed-forward neural networks (FFNN) with one input, one hidden, and one output layer can replace time-consuming global optimizations in the case of a PMS comprising $3\times 10$ unit cells. We train the FFNNs on a dataset obtained for typical single- and dual-beam beamforming scenarios. After training, the FFNNs perform requested beamforming tasks within a fraction of second and with about the same accuracy as the original optimization algorithm. The proposed methodology may find applications in future mobile telecommunication systems that require real-time beamforming on low-end hardware. The same beamforming methodology can be also employed in short-range wireless power transfer systems. Full article

In the background of 6G communication requiring a high data rate and energy efficiency, global coverage and connectivity, as well as high reliability and low latency, most existing reconfigurable metasurfaces face limitations in flexibility, integrability, energy consumption, and cost. This paper proposes a dual-polarized intelligent reflection surface (IRS) based on a paper-based flexible substrate as a solution. The proposed design uniquely enables the independent control of two orthogonally polarized electromagnetic waves to achieve customized scattering effects. Compared to conventional reconfigurable intelligent surfaces using PCB technology and active components, this design utilizes paper as the substrate material combined with conductive ink and silver ink, significantly reducing production costs and process complexity. The manufacturing cost is only about one-tenth of the traditional PCB solutions. This approach is not only cost-effective but also excels in both flexibility and portability. These attributes signify its suitability for a broader range of potential applications, encompassing areas where traditional RIS may be impractical due to cost, rigidity, or complexity constraints. By drawing rotationally symmetric small metal block structures on paper using silver ink, four structures are designed that achieve a phase difference of 90 degrees for both x-polarized and y-polarized wave incidences at the resonant frequency of 4.5754 GHz, realizing independent phase modulation. The dual-polarized flexible 2-bit intelligent reflection surface consists of $20\times 20$ unit cells, and six different coding patterns are designed for single-beam and dual-beam design based on different scattering angles. The experimental results show that this polarization-independent flexible 2-bit intelligent reflection surface structure successfully allows independent control of two orthogonally polarized electromagnetic waves, enabling customized scattering effects. The experimental results are highly consistent with the simulation results. The independent control of two orthogonal polarized electromagnetic waves is a key feature of our design, enabling more flexible and effective signal coverage in complex urban environments. This precise control over polarization not only enhances the adaptability of the system but also offers practical solutions for real-world applications, particularly in meeting the growing demands of urban communication. The proposed metasurface based on paper-based flexible substrate is low-cost and highly portable, and the polarization independence provides more degrees of freedom for the metasurface, which is beneficial for more precise and efficient beam control and can be applied in the field of communication, especially 6G communication and IRS wireless communication. In addition, it also has broad application prospects in radar systems and remote sensing applications. Full article

A reconfigurable metasurface constitutes an important block of future adaptive and smart nanophotonic applications, such as adaptive cooling in spacecraft. In this paper, we introduce a new modeling approach for the fast design of tunable and reconfigurable metasurface structures using a convolutional deep learning network. The metasurface structure is modeled as a multilayer image tensor to model material properties as image maps. We avoid the dimensionality mismatch problem using the operating wavelength as an input to the network. As a case study, we model the response of a reconfigurable absorber that employs the phase transition of vanadium dioxide in the mid-infrared spectrum. The feed-forward model is used as a surrogate model and is subsequently employed within a pattern search optimization process to design a passive adaptive cooling surface leveraging the phase transition of vanadium dioxide. The results indicate that our model delivers an accurate prediction of the metasurface response using a relatively small training dataset. The proposed patterned vanadium dioxide metasurface achieved a 28% saving in coating thickness compared to the literature while maintaining reasonable emissivity contrast at 0.43. Moreover, our design approach was able to overcome the non-uniqueness problem by generating multiple patterns that satisfy the design objectives. The proposed adaptive metasurface can potentially serve as a core block for passive spacecraft cooling applications. We also believe that our design approach can be extended to cover a wider range of applications. Full article
