The equivalent factor (EF) of adaptive equivalent consumption minimization strategy (A-ECMS) has a direct impact on the performance of hybrid electric trucks (HETs). Although EF on the state of charge (SoC) can effectively achieve fuel economy and SoC maintenance, battery life issues still need to be considered. Battery replacement costs are extremely high, directly affecting the operational costs of HETs. Thus, A-ECMS with enhanced battery life (A-ECMS-EBL) is proposed. Firstly, the near-optimal boundary of EF is determined to ensure the fuel economy of A-ECMS-EBL by analyzing the working mechanism of the HET powertrain. Secondly, a new EF calculation method is developed to enhance battery life. This method utilizes accelerator pedal opening (APO) feedback to optimize the power distribution between the engine and battery under high load conditions, thereby reducing the ratio of battery output power and number of battery cycle (NBC). Finally, the simulation results show that under typical cycle conditions, the equivalent fuel consumption (EFC) of A-ECMS-EBL increased by only 2.3% compared to the dynamic programming (DP), decreased by 1.1% compared to the A-ECMS, and the NBC significantly decreased by 6.12%. The results indicate that A-ECMS-EBL has significant advantages in improving fuel economy and enhancing battery life. Full article

Regenerative braking energy recovery is of critical importance for electric vehicles due to their range limitations. To further enhance regenerative braking energy recovery, a dual-fuzzy regenerative braking control strategy based on braking intention recognition is proposed. Firstly, the distribution strategy for braking force is devised by considering classical curves like ideal braking force allocation and ECE regulations; secondly, taking the brake pedal opening and its opening change rate as inputs, the braking intention recognition fuzzy controller is designed for outputting braking strength. Based on the recognized braking strength, and considering the battery charging state and the speed of the vehicle as inputs, a regenerative braking duty ratio fuzzy controller is developed for regenerative braking force regulation to improve energy recovery. Furthermore, a control experiment is established to evaluate and compare the four models and their respective nine braking modes, aiming to define the dual fuzzy logic controller model. Ultimately, simulation validation is conducted using Matlab/Simulink R2019b and CRUISE 2019. The results show that the strategy in this paper has higher energy savings compared to the single fuzzy control and parallel control methods, with energy recovery improved by 26.26 kJ and 96.13 kJ under a single New European Driving Cycle (NEDC), respectively. Full article

To further improve the braking energy recovery efficiency of battery electric vehicles and increase the range of the cars, this paper proposes a multi-mode switching braking energy recovery control strategy based on fuzzy control. The control strategy is divided into three modes: single-pedal energy recovery, coasting energy recovery, and conventional braking energy recovery. It takes the accelerator pedal and brake pedal opening as the switching conditions. It calculates the front and rear wheel braking ratio allocation coefficients and the motor braking ratio through fuzzy control to recover braking energy. The genetic algorithm (GA) is used to update the optimized affiliation function to optimize the motor braking allocation ratio through fuzzy control, and joint simulation is carried out based on the NEDC (New European Driving Cycle) and CLTC-P (China Light-duty Vehicle Test Cycle for Passenger vehicles) cycle conditions. The results show that the multi-mode braking energy recovery control strategy proposed in this paper improves the energy recovery rate and range contribution rate by 4% and 9.6%, respectively, and increases the range by 22.5 km under NEDC cycle conditions. It also improves the energy recovery rate and range contribution rate by 8.7% and 5.5%, respectively, and increases the range by 13 km under CLTC-P cycle conditions, which can effectively improve the energy recovery efficiency of the vehicle and increase the range of battery electric vehicles. Full article

An identification technique is proposed to create a relation between the accelerator pedal position and the corresponding driving moment. This step is beneficial to replace the complex physical model of the vehicle control unit, especially when the sufficient information needed to model certain functionalities of the vehicle control unit are unavailable. We utilized the nonlinear autoregressive exogenous model to regenerate the electric motor torque demand, given the accelerator pedal position, the motor’s angular speed, and the vehicle’s speed. This model proved to be extremely efficient in representing this highly complex relationship. The data employed for the identification process were chosen from an actual three-dimensional route with sudden changes of a dynamic nature in the driving mode, different speed limits, and elevations, as an attempt to thoroughly cover the driving moment scope based on the alternation of the given inputs. Analyzing the selected route data points showed the widespread coverage of the motor’s operational scope compared to a standard driving cycle. The training outcome revealed that linear modeling is inadequate for identifying the targeted system, and has a substantial estimation error. Adding the nonlinearity feature to the model led to an exceptionally high accuracy for the estimation and validation datasets. The main finding of this work is that the combined model from the nonlinear autoregressive exogenous and the sigmoid network enables the accurate modeling of highly nonlinear dynamic systems. Accordingly, the maximum absolute estimation error for the motor’s moment was less than 10 Nm during the real-world driving maneuver. The highest errors are found around the maximum motor’s moment. Finally, the model is validated with measurements from an actual field test maneuver. The identified model predicted the driving moment with a correlation of 0.994. Full article

Mountain bikes with electric assistance (e-bikes) have gained popularity recently by allowing riders to increase their pedaling power through an electric motor. This innovation has raised questions about how e-bikes compare to traditional mountain bikes regarding physical effort, speed, and physiological demands. By examining these factors, the study aims to compare and characterize differences in performance-related parameters when using an electric-assisted mountain bike compared to a conventional mountain bike on different types of terrain (uphill, downhill, flat section, technically demanding terrain) concerning power output, velocity, cardiorespiratory parameters, and energy expenditure. Six experienced mountain bikers (mean age: 44.6 ± 6.4 years, mean body height: 173.3 ± 5.6 cm, mean body weight: 70.6 ± 4.9 kg) cycled 4.5 km on varying off-road terrain at their own race pace, once with and once without electrical assistance, in randomized order. The results of the study indicate significantly faster (24.3 ± 1.85 to 17.2 ± 1.22 km/h (p < 0.001)) cycling on an electric-assisted mountain bike, which reduces cardiorespiratory parameters and metabolic effort as well as results in less demanding workload (138.5 ± 31.8 W) during the cycling with an electric-assisted mountain bike in comparison to a conventional mountain bike (217.5 ± 24.3 W (p < 0.001)). The results indicate significant differences especially when riding uphill. The performance advantage of an electrically assisted mountain bike diminishes compared to a conventional mountain bike on downhill, flat, or technically challenging terrain. The highlighted advantages of electric-assisted mountain bikes could represent a novel strategy for cycling in different terrains to optimize efficiency. Full article

The loader has a lot of recoverable braking energy due to its larger mass and frequent starts/stops. For a 5-ton pure electric drive loader, an emergency braking intention recognition strategy based on hydraulic braking pressure was proposed. The braking intention recognition strategy of an acceleration pedal and brake pedal was used to distinguish different braking intentions, and the hydraulic braking system pressure was used as a feedback parameter for emergency braking intention recognition to improve braking safety. Aiming at electro-hydraulic composite braking mode switching, a collaborative control strategy of walking regenerative braking and mechanical braking is proposed. Simulation analysis by AMESim and vehicle test results show that the proposed control strategy can realize driver braking intention recognition and electro-hydraulic braking force distribution under different working conditions and improve braking smoothness. According to the calculation of the energy recovery effect evaluation index, the energy recovery efficiency is up to 71.64%, the braking recovery rate is above 42.50%, and the maximum energy saving for the whole vehicle is 7.58% under one cycle condition. The proposed strategy has a good energy-saving effect. Full article

This paper proposes a novel torque measurement and control technique for cycling-assisted electric bikes (E-bikes) considering various external load conditions. For assisted E-bikes, the electromagnetic torque from the permanent magnet (PM) motor can be controlled to reduce the pedaling torque generated by the human rider. However, the overall cycling torque is affected by external loads, including the cyclist’s weight, wind resistance, rolling resistance, and the road slope. With knowledge of these external loads, the motor torque can be adaptively controlled for these riding conditions. In this paper, key E-bike riding parameters are analyzed to find a suitable assisted motor torque. Four different motor torque control methods are proposed to improve the E-bike’s dynamic response with minimal variation in acceleration. It is concluded that the wheel acceleration is important to determine the E-bike’s synergetic torque performance. A comprehensive E-bike simulation environment is developed with MATLAB/Simulink to evaluate these adaptive torque control methods. In this paper, an integrated E-bike sensor hardware system is built to verify the proposed adaptive torque control. Full article

Dynamic loads have short and long-term effects in the rehabilitation of lower limb joints. However, an effective exercise program for lower limb rehabilitation has been debated for a long time. Cycling ergometers were instrumented and used as a tool to mechanically load the lower limbs and track the joint mechano-physiological response in rehabilitation programs. Current cycling ergometers apply symmetrical loading to the limbs, which may not reflect the actual load-bearing capacity of each limb, as in Parkinson’s and Multiple Sclerosis diseases. Therefore, the present study aimed to develop a new cycling ergometer capable of applying asymmetric loads to the limbs and validate its function using human tests. The instrumented force sensor and crank position sensing system recorded the kinetics and kinematics of pedaling. This information was used to apply an asymmetric assistive torque only to the target leg using an electric motor. The performance of the proposed cycling ergometer was studied during a cycling task at three different intensities. It was shown that the proposed device reduced the pedaling force of the target leg by 19% to 40%, depending on the exercise intensity. This reduction in pedal force caused a significant reduction in the muscle activity of the target leg (p < 0.001), without affecting the muscle activity of the non-target leg. These results demonstrated that the proposed cycling ergometer device is capable of applying asymmetric loading to lower limbs, and thus has the potential to improve the outcome of exercise interventions in patients with asymmetric function in lower limbs. Full article

The performance of electric vehicle (EV) drivetrains depends on the power capability of individual components, including the battery pack, motor drive, and electric motor. To ensure safety, maximum power must be limited by considering the constraint of the weakest component in the drivetrain. While there exists a large body of work that discusses state-of-power (SoP) estimation for individual components, there is no work that considers all the components’ limiting factors at once. Moreover, research on how to use these limits to adjust the performance at the system level has been rare. In this paper, the SoPs of the components are used to estimate the state-of-function (SoF) of the EV drivetrain. The SoF is defined as the maximum charge/discharge power that can be sourced and/or sunk by the drivetrain without violating the safety limits of its components. The component-level SoP estimations are fulfilled using several digital algorithms based on recursive least-squares (RLS) and Kalman filters (KFs), as well as by taking into account specific limiting conditions such as high driving altitude and ambient temperatures. An EV driven by a hybrid energy storage system based on a battery/supercapacitor, and a permanent-magnet synchronous motor is considered the use case. Based on the drivetrain SoF estimation, we propose two de-rating schemes to ensure that the drivetrain safety limits will be respected: adaptive cruise control and adaptive adjustment of pedal sensitivity. The de-rating schemes are introduced to a so-called recommender system that is implemented in MATLAB/STATEFLOW. The recommender system provides advisory feedback to the driver to switch to a different driving mode to ensure safety. The simulation results over a standard drive cycle using MATLAB/SIMULINK and STATEFLOW show the effectiveness of the proposed design at both component and system levels. The paper also proposes an implementation concept for the integration of the proposed recommender system into the advanced driver assistance system (ASAS). Full article

This study introduces a novel controller based on a Reinforcement Learning (RL) algorithm for real-time adaptation of the stimulation pattern during FES-cycling. Core to our approach is the introduction of an RL agent that interacts with the cycling environment and learns through trial and error how to modulate the electrical charge applied to the stimulated muscle groups according to a predefined policy and while tracking a reference cadence. Instead of a static stimulation pattern to be modified by a control law, we hypothesized that a non-stationary baseline set of parameters would better adjust the amount of injected electrical charge to the time-varying characteristics of the musculature. Overground FES-assisted cycling sessions were performed by a subject with spinal cord injury (SCI AIS-A, T8). For tracking a predefined pedaling cadence, two closed-loop control laws were simultaneously used to modulate the pulse intensity of the stimulation channels responsible for evoking the muscle contractions. First, a Proportional-Integral (PI) controller was used to control the current amplitude of the stimulation channels over an initial parameter setting with predefined pulse amplitude, width and fixed frequency parameters. In parallel, an RL algorithm with a decayed-epsilon-greedy strategy was implemented to randomly explore nine different variations of pulse amplitude and width parameters over the same stimulation setting, aiming to adjust the injected electrical charge according to a predefined policy. The performance of this global control strategy was evaluated in two different RL settings and explored in two different cycling scenarios. The participant was able to pedal overground for distances over 3.5 km, and the results evidenced the RL agent learned to modify the stimulation pattern according to the predefined policy and was simultaneously able to track a predefined pedaling cadence. Despite the simplicity of our approach and the existence of more sophisticated RL algorithms, our method can be used to reduce the time needed to define stimulation patterns. Our results suggest interesting research possibilities to be explored in the future to improve cycling performance since more efficient stimulation cost dynamics can be explored and implemented for the agent to learn. Full article

The aim of this paper is to solve the problem for battery electric vehicles of low-precision and time-consuming inspection. A novel method of driving cycle development for battery electric vehicles’ operational safety is proposed in this paper. First, three inspection items are proposed based on relevant testing standards. The inspection calculation method of operational safety is developed based on the acceleration changing rate. Then the multi-cycle inspection method with the stable pedal mode is developed, and the Gauss filtering algorithm is applied for data preprocessing. A rapid inspection driving cycle construction method based on support vector machine is proposed, and a driving cycle is built with a total time of 204 s by fusing and splicing kinematic fragments. Finally, the proposed inspection calculation method is used to validate the operational safety inspection items by tracking the established rapid inspection driving cycle based on the test bench. The results shown are those that qualified the range of acceleration changing rate for driving stability [−0.35, −0.04]. The range for gliding smoothness is [0.05, 0.09]. The range for braking coordination is [−0.04, 0.095]. The maximum RMSE between the constructed rapid inspection segments is 9%, and the maximum RMSE between the tested driving segments is 6%. Test results meet design requirements. The thresholds for operational safety inspection items are evaluated based on the test results. We set less than 0.5 as the safety threshold for driving stability. During the experiment, gliding was less than 0.1 as the safety threshold for gliding comfort, and during braking it was less than 0.1 as the safety threshold for vehicle braking coordination. Full article

A modal shift to electric pedal-assisted cycles (EPACs) can help with reaching the transport emission goals of the European Green Deal. With the rising sales of EPACs in Europe, a lack of appropriate (electric) cycling infrastructure remains a major barrier for many potential users. This paper discusses the results of a survey about the requirements of (potential) cyclists to design a better cycling infrastructure. The differences in requirements for non-cyclists vs. cyclists and electric cyclists vs. conventional cyclists are discussed using statistical analysis. The key findings are that cyclists and non-cyclists both require wide quality cycling infrastructure with safe crossing points, secure bicycle parking and smart traffic lights. Non-cyclists’ requirements significantly differ from cyclists’ on 12 items, of which rain cover while cycling and parking spots for the car are the most noteworthy. There is (but) one significant difference between the requirements of EPAC users and conventional cyclists: the need for charging points for EPACs along the cycle route. Full article

Since the first Cybathlon 2016, when twelve teams competed in the FES bike race, we have witnessed a global effort towards the development of stimulation and control strategies to improve FES-assisted devices, particularly for cycling, as a means to practice a recreational physical activity. As a result, a set of technical notes and research paved the way for many other studies and the potential behind FES-assisted cycling has been consolidated. However, engineering research needs instrumented devices to support novel developments and enable precise assessment. Therefore, some researchers struggle to develop their own FES-assisted devices or find it challenging to implement their instrumentation using commercial devices, which often limits the implementation of advanced control strategies and the possibility to connect different types of sensor. In this regard, we hypothesize that it would be advantageous for some researchers in our community to enjoy access to an entire open-source FES platform that allows different control strategies to be implemented, offers greater adaptability and power capacity than commercial devices, and can be used to assist different functional activities in addition to cycling. Hence, it appears to be of interest to make our proprietary electrical stimulation system an open-source device and to prove its capabilities by addressing all the aspects necessary to implement a FES cycling system. The high-power capacity stimulation device is based on a constant current topology that allows the creation of biphasic electrical pulses with amplitude, width, and frequency up to 150 mA, 1000 µs, and 100 Hz, respectively. A mobile application (Android) was developed to set and modify the stimulation parameters of up to eight stimulation channels. A proportional-integral controller was implemented for cadence tracking with the aim to improve the overall cycling performance. A volunteer with complete paraplegia participated in the functional testing of the system. He was able to cycle indoors for 45 min, accomplish distances of more than 5 km using a passive cycling trainer, and pedal 2400 m overground in 32 min. The results evidenced the capacity of our FES cycling system to be employed as a cycling tool for individuals with spinal cord injury. The methodological strategies used to improve FES efficiency suggest the possibility of maximizing pedaling duration through more advanced control techniques. Full article

Functional electrical stimulation (FES) is a technique used in rehabilitation, allowing the recreation or facilitation of a movement or function, by electrically inducing the activation of targeted muscles. FES during cycling often uses activation patterns which are based on the crank angle of the pedals. Dynamic changes in their underlying predefined geometrical models (e.g., change in seating position) can lead to desynchronised contractions. Adaptive algorithms with a real-time interpretation of anatomical segments can avoid this and open new possibilities for the automatic design of stimulation patterns. However, their ability to accurately and precisely detect stimulation triggering events has to be evaluated in order to ensure their adaptability to real-case applications in various conditions. In this study, three algorithms (Hilbert, BSgonio, and Gait Cycle Index (GCI) Observer) were evaluated on passive cycling inertial data of six participants with spinal cord injury (SCI). For standardised comparison, a linear phase reference baseline was used to define target events (i.e., 10%, 40%, 60%, and 90% of the cycle’s progress). Limits of agreement (LoA) of ±10% of the cycle’s duration and Lin’s concordance correlation coefficient (CCC) were used to evaluate the accuracy and precision of the algorithm’s event detections. The delays in the detection were determined for each algorithm over 780 events. Analysis showed that the Hilbert and BSgonio algorithms validated the selected criteria (LoA: +5.17/−6.34% and +2.25/−2.51%, respectively), while the GCI Observer did not (LoA: +8.59/−27.89%). When evaluating control algorithms, it is paramount to define appropriate criteria in the context of the targeted practical application. To this end, normalising delays in event detection to the cycle’s duration enables the use of a criterion that stays invariable to changes in cadence. Lin’s CCC, comparing both linear correlation and strength of agreement between methods, also provides a reliable way of confirming comparisons between new control methods and an existing reference. Full article

Bicycles with electrically powered pedal assistance (PA) show great potential as ecological alternatives for engine-based vehicles. There is plenty of research available about the influence of various bicycle parameters on cycling technique. Though, to the best of the authors’ knowledge, there is none about the influence of PA. In this study, a recreational bicycle is equipped with PA and unique instrumentation to measure the user-induced loads on seat, steer and pedals. Joint loading is derived in the sagittal plane from inverse dynamics and muscle activity of the lower limbs is recorded with an electromyography system integrated in cycling pants. An experiment is set up, in which volunteers cycle on an athletics track, with a varying level of PA and a varying seat height. An ANOVA is conducted to determine significant differences due to the level of PA and seat height and to analyze the interaction effect. No interaction effect was found and only differences due to the level of PA were significant. Knowledge about the influence of PA provides insights into (i) electric bicycle design; (ii) the usage of electric bicycle for physically challenged people; (iii) the usage of electric bicycles as a rehabilitation tool. Full article
