This paper proposes a novel reconfigurable intelligent surface (RIS)-assisted downlink hybrid free-space optics (FSO)/radio frequency (RF) space–air–ground integrated network (SAGIN) architecture, where the high altitude platform (HAP) converts the optical signal sent by the satellite into an electrical signal through optoelectronic conversion. The drone equipped with RIS dynamically adjusts the signal path to serve ground users, thereby addressing communication challenges caused by RF link blockages from clouds or buildings. To improve the security performance of SAGIN, this paper maximizes the sum secrecy rate (SSR) by optimizing the power allocation, RIS phase shift, and drone trajectory. Then, an alternating iterative framework is proposed for a joint solution using the simulated annealing algorithm, semi-definite programming, and the designed deep deterministic policy gradient (DDPG) algorithm. The simulation results show that the proposed scheme can significantly enhance security performance. Specifically, compared with the NOMA and SDMA schemes, the SSR of the proposed scheme is increased by 39.7% and 286.7%, respectively. Full article

Precision beam pointing plays a critical role in free-space optical communications terminals in uplink, downlink and inter-satellite link scenarios. Among the various methods of beam steering, the use of fast steering mirrors (FSM) is widely adopted, with many commercial solutions employing diverse technologies, particularly focusing on small, high-bandwidth mirrors. This paper introduces a method using lightweight, commercial off-the-shelf components to construct a custom closed-loop steering mirror platform, suitable for mirror apertures exceeding 100 mm. The approach involves integrating optical encoders into two off-the-shelf open-loop actuators. These encoders read the signal reflected on purposefully diamond-machined knurled screw knobs, providing maximum contrast between light and dark lines. The resulting steering mirror has the potential to complement or replace FSM in applications requiring a larger stroke, at the expense of motion speed. In the presented setup, the mirror tilt resolution achieved based on the encoder closed-loop signal feedback is 45 $\mathsf{\mu }$rad, with a mean slew rate of 1.5 mrad/s. Importantly, the steering assembly is self-locking, requiring no power to maintain a steady pointing angle. Using the mirror to actively correct for a constantly moving incoming beam, a 5-fold increase in concentration of the beam spot on the center of the detector was obtained compared to a fixed position mirror, demonstrating the mirrors ability to correct for satellite platform jitter and drift. Full article

Optical satellite communications (OSC) downlinks can support much higher bandwidths than radio-frequency channels. However, atmospheric turbulence degrades the optical beam wavefront, leading to reduced data transfer rates. In this study, we propose using reinforcement learning (RL) as a lower-cost alternative to standard wavefront sensor-based solutions. We estimate that RL has the potential to reduce system latency, while lowering system costs by omitting the wavefront sensor and low-latency wavefront processing electronics. This is achieved by adopting a control policy learned through interactions with a cost-effective and ultra-fast readout of a low-dimensional photodetector array, rather than relying on a wavefront phase profiling camera. However, RL-based wavefront sensorless adaptive optics (AO) for OSC downlinks faces challenges relating to prediction latency, sample efficiency, and adaptability. To gain a deeper insight into these challenges, we have developed and shared the first OSC downlink RL environment and evaluated a diverse set of deep RL algorithms in the environment. Our results indicate that the Proximal Policy Optimization (PPO) algorithm outperforms the Soft Actor–Critic (SAC) and Deep Deterministic Policy Gradient (DDPG) algorithms. Moreover, PPO converges to within $86\%$ of the maximum performance achievable by the predominant Shack–Hartmann wavefront sensor-based AO system. Our findings indicate the potential of RL in replacing wavefront sensor-based AO while reducing the cost of OSC downlinks. Full article

The optical signal propagation used in satellite uplinks and downlinks is influenced by absorption, scattering, and changes in the atmospheric refractive index or turbulence, causing optical signal attenuation. A free space optics (FSO) communications system using coherent communication can improve the link sensitivity and reach higher distances. This article proposes a new architecture for the phase detector in an all-digital optical phase-locked loop (OPLL) for coherent optical detection. Firstly, the performance of the proposed phase detector is evaluated under Gaussian noise, where the best operation point is found for the OPLL working with two sample rates: 625 MSa/s and 10 GSa/s. The system analyses also take a non-negligible delay into account. Then, it will be evaluated and compared with an OPLL using an analog phase detector in the presence of atmospheric turbulence. Finally, in three different atmospheric turbulence conditions, the effect of wind speed on communication quality is investigated through the obtained bit error rate (BER) from the recovered data for a bit rate of 20 Gbps. The results show that the proposed digital phase detector can track a signal under longer feedback loop delays and fading signals. Full article

This paper reports on the design and experimental validation of a fully-metallic double-ridged waveguide 10 × 10 Rotman lens additively manufactured as a single part. The wide band operation of this quasi-optical beamformer enables us to cover the uplink and downlink frequencies allocated to satellite communications in the K/K${}_{\mathrm{a}}$-band, from 17.3 GHz to 30 GHz. The feeding port design was adjusted to enable vertical printing, thus minimizing the use of supporting structures. A prototype was manufactured and tested. The reported results indicate losses in the range of 0.5 dB in the lower-frequency band and 0.8 dB in the upper-frequency band, including the waveguide transitions added for test purposes. The measured reflection and coupling coefficients remain below −11.5 dB over the operating band. The standard deviation of the residual phase error across the array ports is below $5°$ in simulation and below $10°$ in measurements. Array factors synthesized using the scattering parameters confirm the good stability of the beamforming functionality over the wide frequency band analyzed. This monolithic design is a promising step toward more integrated antenna systems, such as a compact dual-stack configuration for planar array design. Full article

In recent years, optical wireless communication has promised several benefits over radio frequency communication in atmospheric, deep space and underwater communications. Satellite-to-underwater communication technology can be applied to commercial, naval, scientific and engineering operations because of its high data rate, high security, long-reach and low cost. In this paper, a high-speed, long-reach integrated free space optics (FSO)-passive optical network (PON) system using non-orthogonal multiple access visible light communication (NOMA-VLC) is proposed. It poses a 10/2.5 Gbps per channel bit rate for satellite-to-underwater applications. Numerically calculated results provide the splitter power budget of −35 dBm in the downlink and −32 dBm in the uplink. Additionally, a receiver sensitivity of 23 dB in the downlink and 10 dB in the uplink direction can be obtained in the system using a modified new zero cross-correlation (MNZCC) code under clear environment conditions. Again, the simulative analyses indicate that the suggested system supports 290 underwater devices successfully and offers a high 10 dBm signal-to-noise ratio over 10 km FSO, 100 km fiber and 5 m VLC range. Moreover, it provides a signal-to-noise ratio of 39 dB, with −9 dBm received optical power at 300 fields of view under fiber-wireless channels’ impairments. We argue that the suggested system is a symmetric system adapted to different link distances and which offers improved receiver sensitivity and high received optical power at a 10⁻⁹ bit error rate (BER). The comparative analysis shows the advantages of the suggested system over previously reported works. Full article

Free space optical (FSO) communications have the potential to be one of the most essential technologies for solving the high-bandwidth demands of communications between satellites and ground stations. In this study, we examine the impact of the atmosphere on satellite–ground FSO uplink and downlink communications. To consider diverse atmospheric conditions on both uplink and downlink, we derive FSO channel elements such as the fog attenuation coefficient, refractive index parameter, coherence length, turbulence model, and angle-of-arrival fluctuation. Unlike conventional work, we provide FSO channel analysis based on variations in the Fried parameter, zenith angle, scintillation index, and Rytov variance. Using simulation results from the optical settings, we examine the influence on channel performance of conditions such as atmospheric attenuation and intensity fluctuation. Based on this examination, we determine that 1550 nm is the preferred wavelength for both uplink and downlink FSO channels to mitigate the impact of turbulence and that larger receiver apertures lessen angle-of-arrival changes. Full article

By analyzing the effect of the degree of polarization (DoP) of the partially coherent Gaussian Schell-model (GSM) beam on a heterodyne system of an uplink path and a downlink path, we developed an innovative and noteworthy theory according to which σ_sy (signal beam waist radius in the y direction component) and δ_Syy (coherence length of the signal beam in the yy direction component) had a more significant impact on heterodyne efficiency and DoP than the turbulence term on uplink and downlink paths. Namely, the DoP and heterodyne efficiency of an uplink path are higher than that of a downlink path when σ_sy > 0.02 m or δ_Syy ≥ 0.03 m. This innovative rule provides an efficient way for increasing the heterodyne efficiency of a signal beam propagating along an uplink or a downlink path channel in satellite-ground communication links in free-space optical heterodyne detection communication. Full article

The Japanese National Institute of Information and Communications Technology (NICT) is currently developing a high-performance laser-communication terminal for CubeSats aimed at providing a high-datarate communication solution for LEO satellites requiring transmission of large volumes of data from orbit. A key aspect of the communication system is a high-power optical amplifier capable of providing enough gain to the transmitted signals to be able to close the link on its counterpart’s receiver with the smallest impact in terms of energy and power on the CubeSat’s platform. This manuscript describes the development of a miniaturized 2-W space-grade 2-stage erbium-doped fiber amplifier (EDFA) compatible with the CubeSat form factor, showing the best power-to-size ratio for a space-qualified EDFA to the best of the authors’ knowledge. Performance results under realistic conditions as well as full space qualification and test are presented, proving that this module can support short-duration LEO-ground downlinks as well as long-duration intersatellite links. Full article

Coherent detection provides the optimum performance for free space optical (FSO) communication systems. However, such detection systems are expensive and require digital phase noise compensation. In this paper, the transmission performance of long-haul FSO system for ground-to-satellite communication based on a Kramers–Kronig (KK) transceiver is evaluated. KK transceivers utilize inexpensive direct detection receivers and the signal phase is retrieved from the received current using the well-known KK relations. KK transceivers are not sensitive to the laser phase noise and, hence, inexpensive lasers with large linewidths can be used at the transmitter. The transmission performance of coherent and KK transceivers is compared in various scenarios such as satellite-to-ground, satellite-to-satellite, and ground-to-satellite for weak, moderate, and strong turbulence. The results show that the transmission performance of a system based on the KK transceiver is comparable to that based on a coherent transceiver, but at a significantly lower system cost and complexity. It is shown that in the absence of turbulence, the coherent receiver has a ~3 dB performance advantage over the KK receiver. However, in the presence of strong turbulence, this performance advantage becomes negligible. Full article

Free Space Optics (FSO) technology enabling next-generation near-Earth communication is prone to severe propagation losses due to atmospheric-turbulence-induced fading and Mie scattering (clouds). As an alternative to the real-time evaluation of the weather effects over optical signal, a state-of-the-art laboratory testbed for verification of slant APD-based (Avalanche Photodiode) FSO links in laboratory conditions is proposed. In particular, a hardware channel emulator representing an FSO channel by means of fiber-coupled Variable Optical Attenuator (VOA) controlled by driver board and software is utilized. While atmospheric scintillation data are generated based on Radiosonde Observation (RAOB) databases combined with a statistical design approach, cloud attenuation is introduced using Mie theory together with empirical Log-Normal modeling. The estimation of atmospheric-turbulence-induced losses within the emulated optical downlink is done with an FSO IM/DD prototype (Intensity Modulation/Direct Detection) relying on two different data throughputs using a transmitter with external and internal modulation. Moreover, the receiver under-test is a high-speed 10 Gbps APD photodetector with integrated Transimpedance Amplifier (TIA) typically installed in OGSs (Optical Ground Stations) for LEO/GEO satellite communication. The overall testbed performance is addressed by a BER tester and a digital oscilloscope, providing BER graphs and eye diagrams that prove the applied approach for testing APD-TIA in the presence of weather-based disruptions. Furthermore, the testbed benefits from the used beam camera that measures the quality of the generated FSO beam. Full article

Satellites in low earth orbit (LEO) are currently being deployed for numerous communication, positioning, space and Earth-imaging missions. To provide higher data rates in direct-to-user links and earth observation downlinks, the free-space optics technology can be employed for LEO-to-ground downlinks. Moreover, the hybrid automatic repeat request (HARQ) can be adopted since the propagation latency is low for LEO satellites. In this work, a power allocation methodology is proposed for optical LEO-to-ground downlinks under weak turbulence employing HARQ retransmission schemes. Specifically, the average power consumption is minimized given a maximum transmitted power constraint and a target outage probability threshold to ensure energy efficiency and reliability, respectively. The optimization problem is formulated as a constrained nonlinear programming problem and solved for Type I HARQ, chase combining (CC) and incremental redundancy (IR) schemes. The solutions are derived numerically via iterative algorithms, namely interior-point (IP) and sequential quadratic programming (SQP), and validated through an exhaustive (brute-force) search. The numerical simulations provide insight into the performance of the retransmission schemes regarding average power. More specifically, Type I HARQ has the worst output, CC has a moderate one, and IR exhibits the best performance. Finally, the IP algorithm is a slower but more accurate solver, and SQP is faster but slightly less accurate. Full article

The use of Light Amplification by Stimulated Emission of Radiation (i.e., LASERs or lasers) by the U.S. Department of Defense is not new and includes laser weapons guidance, laser-aided measurements, and even lasers as weapons (e.g., Airborne Laser). Lasers in the support of telecommunications is also not new. The use of laser light in fiber optics has shattered thoughts on communications bandwidth and throughput. Even the use of lasers in space is no longer new. Lasers are being used for satellite-to-satellite crosslinking. Laser communication can transmit orders-of-magnitude more data using orders-of-magnitude less power and can do so with minimal risk of exposure to the sending and receiving terminals. What is new is using lasers as the uplink and downlink between the terrestrial segment and the space segment of satellite systems. More so, the use of lasers to transmit and receive data between moving terrestrial segments (e.g., ships at sea, airplanes in flight) and geosynchronous satellites is burgeoning. This manuscript examines the technological maturation of employing lasers as the signal carrier for satellite communications linking terrestrial and space systems. The purpose of the manuscript is to develop key performance parameters (KPPs) to inform the U.S. Department of Defense initial capabilities documents (ICDs) for near-future satellite acquisition and development. By appreciating the history and technological challenges of employing lasers, rather than traditional radio frequency sources for satellite uplink and downlink signal carriers, this manuscript recommends ways for the U.S. Department of Defense to employ lasers to transmit and receive high bandwidth, and large-throughput data from moving platforms that need to retain low probabilities of detection, intercept, and exploit (e.g., carrier battle group transiting to a hostile area of operations, unmanned aerial vehicle collecting over adversary areas). The manuscript also intends to identify commercial sector early-adopter fields and those fields likely to adapt to laser employment for transmission and receipt. Full article

Next generation 5G networks generate a need for broadband, low latency and power efficient backhauling and data-relay services. In this paper, optical satellite communications links, as an integrated component of 5G networks, are studied. More specifically, the Geostationary (GEO) satellite-to-ground optical communication link is investigated. Long-term irradiance statistics based on experimental measurements from the ARTEMIS program are presented and a new time series generator related to the received irradiance/power fluctuations due to atmospheric turbulence is reported. The proposed synthesizer takes into consideration the turbulence-induced scintillation effects that deteriorate the laser beam propagation, on the assumption of the Kolmogorov spectrum. The modeling is based on Rytov theory regarding weak turbulence conditions with the incorporation of first order stochastic differential equations. Summing up, the time series synthesizer is validated in terms of first and second order statistics with experimental results from the European Space Agency‘s ARTEMIS experimental optical downlink and simulated received power statistics for various weather conditions are presented using the proposed validated methodology. Some important conclusions are drawn. Full article

The satellite-to-ground optical communication system suffers from atmosphere turbulence severely. It is well-known that the coherent detection can increase the receiver sensitivity and performing aperture averaging can reduce the scintillation caused by the atmosphere turbulence. In this paper, the bit error rate, the outage probability and the average capacity of a coherent satellite-to-ground optical communication downlink with aperture averaging are analyzed. The Log-normal atmosphere turbulence model and BPSK (Binary Phase Shift Keying) modulation is employed. The analyzing focuses on the improvement of aperture averaging with different atmospheric conditions and zenith angles of the satellite. The bit error rate performance based on measuring data is given too. The results demonstrate the bit error rate and the outage probability can be reduced and the average capacity can be improved by aperture averaging efficiently. When the turbulence is stronger and the zenith angle is larger, the effect of aperture averaging is more obvious. The aperture averaging effect on BER (Bit Error Rate) is better than the effect on average capacity. Full article
