Search Results (1,985)

Speckle patterns generated by coherent illumination of random media are ubiquitous in optical imaging and information processing. However, most existing studies have primarily focused on isotropic or homogeneous speckle fields, while controlled manipulation of speckle patterns with customized geometric morphologies has received comparatively little attention. Here, we propose a random phase-coded array (RPA) as a general framework for generating geometrically reshaped speckle, enabling the formation of nonconventional random light fields whose ensemble-averaged intensity distributions follow prescribed geometric shapes. In this framework, the speckle geometry is determined by the unit-cell structure of the RPA, the unit-cell size governs the overall spatial extent of the speckle pattern, and the illuminating beam size sets the characteristic speckle grain size. These relationships are rigorously validated through theoretical derivations and numerical simulations. As a result, the global statistical envelope of the random light field can be intuitively and flexibly controlled without compromising the fully developed speckle characteristics. Our experimental framework offers a straightforward, scalable, and versatile approach for generating customized random light fields, with potential applications in optical information processing, secure optical communication, computational imaging, and speckle-based metrology. Full article

Additive manufacturing offers a promising route to low-cost, rapidly deployable X-ray focusing optics with geometries that are difficult to realize by conventional machining. Here, we report polymer compound refractive lenses (CRLs) for hard X-ray focusing fabricated by projection micro-stereolithography (PµSL, DLP-based) and by two-photon polymerization (2PP). Two-dimensional bi-parabolic CRL elements were produced in multiple photopolymer resins (HTL, Tough, ST1400 for PμSL; IP-S for 2PP) and evaluated by at-wavelength metrology at the Shanghai Synchrotron Radiation Facility. The single-lens residual phase errors (RMS) less than 0.1 $\mathsf{\lambda }$ were measured for PµSL-fabricated HTL, and Toughlenses, respectively, while 2PP-fabricated IP-S lenses achieved 0.008 $\mathsf{\lambda }$. And the analysis indicates that PµSL lenses are primarily limited by systematic mid-order aberrations, whereas 2PP substantially suppresses coma but shows residual spherical aberration attributable to process calibration and shrinkage. Leveraging the higher fidelity of 2PP, a 65-element parabolic CRL array (radius of curvature of 100 µm) was fabricated and demonstrated hard X-ray focusing at 15 keV with focal spot sizes of 6.4 ± 1 µm (H) and 6.8 ± 1 µm (V), and a flux gain of 220. The measured performance agrees with theoretical expectations when accounting for X-ray source properties, detector resolution and chromatic aberration. These results establish a practical pathway for additively manufactured polymer CRLs with DLP and 2PP techniques as compact, customization focusing optics for synchrotron beamlines. Full article

This work presents the development and experimental characterization of a compact ultraviolet (UV) telescope based on silicon photomultipliers (SiPMs) designed for the detection of faint atmospheric optical tracks. Such transient optical phenomena include meteors, transient luminous events (TLEs), space debris reentries, and other faint atmospheric emissions. Nuclearite-induced atmospheric emission is considered as a benchmark case for evaluating the expected signal levels of rare luminous track events. We detail the fabrication, assembly, and testing of the SiPM sensor array, comprising parallel Geiger-mode avalanche diodes with high fill factor and photon detection efficiency, alongside custom readout electronics using self-triggering ASICs, precision optical components, and a stable mechanical mount. This photon-counting telescope provides a compact and mechanically robust alternative to conventional PMT-based systems, with demonstrated capability for detecting low-light atmospheric tracks under controlled laboratory conditions. Full article

Optical coherence tomography (OCT) is a non-invasive, high-resolution imaging technique widely used in medical diagnosis, biomedical research and other fields. It plays an important role in the early detection and accurate diagnosis of diseases. The superluminescent light-emitting diode (SLED) is the ideal light source for OCT systems, where the stability of its drive current and operating temperature directly determines the imaging quality of OCT. Existing driving and temperature control schemes for similar light sources predominantly rely on microcontrollers or field programmable gate arrays (FPGAs), a reliance which often results in complex system architectures and difficulties in balancing simplicity with control precision. To address these issues, a stable and compact SLED source driver module designed for OCT was developed in this study, integrating both a constant-current drive circuit and a temperature control circuit. The negative feedback control and improved current-limiting protection are employed in the constant-current drive circuit to maintain stable SLED operation and reduce the circuit footprint. A miniature dedicated temperature control chip is adopted in the temperature control circuit. The operating temperature of the SLED is acquired by linearizing the negative temperature coefficient (NTC) thermistor value and regulated through a proportional-integral-derivative (PID) compensation circuit. The size of the fabricated module (including casing) is less than 10 × 8 × 3 cm³. Experimental results show that the driver module achieves a drive current control accuracy of 0.1% and a temperature control accuracy of 0.01 °C. The output optical power fluctuation is less than 0.005 mW and the average axial resolution for OCT is 6.5992 μm with a standard deviation of 0.0107 μm. This light source driver module successfully balances control precision with structural simplicity, demonstrating excellent applicability in OCT systems. Full article

The growing demand for high-fidelity, multi-parameter, distributed sensing in critical domains such as structural health monitoring, oil and gas exploration, and secure perimeter surveillance is pushing traditional optical fiber sensors (OFS) to their performance limits. Although conventional multiplexing techniques such as time-division and wavelength-division multiplexing (TDM, WDM) have been commercially successful, they are rapidly approaching fundamental bottlenecks in sensor density, spatial resolution, and data capacity. This review argues that the synergistic convergence of space-division multiplexing (SDM) and artificial intelligence (AI) represents a paradigm shift, enabling a new generation of intelligent, high-dimensional sensing networks. We comprehensively survey the state of the art in SDM-based OFS, detailing the operating principles and applications of multi-core fibers (MCFs) for ultra-dense sensor arrays and 3D shape sensing, as well as few-mode fibers (FMFs) for mode-division multiplexing and enhanced multi-parameter discrimination. However, the unprecedented spatial parallelism provided by SDM introduces significant challenges, including inter-channel crosstalk, complex signal demultiplexing, and massive data volumes. This paper systematically explores how AI, particularly machine learning (ML) and deep learning (DL), is being leveraged not merely as a tool but as an indispensable core technology to mitigate these impairments. We critically analyze AI’s role in digital crosstalk suppression, intelligent mode demultiplexing, signal denoising, and solving complex inverse problems for parameter estimation. Furthermore, we highlight how this AI–SDM synergy enables capabilities beyond the reach of either technology alone, such as super-resolution sensing and predictive analytics. The discussion is extended to include the critical supporting pillars of this ecosystem, such as advanced interrogation techniques and the associated data management challenges. Finally, we provide a forward-looking perspective on the trajectory of the field, outlining a path toward cognitive sensing networks that are self-calibrating, adaptive, and capable of autonomous decision-making. This review is intended to serve as a foundational reference for researchers and engineers at the intersection of photonics and intelligent systems, illuminating the pathway toward tomorrow’s intelligent sensing infrastructure. Full article

This study presents an all-optical artificial synapse based on 2D perovskite materials for neuromorphic visual simulation. While conventional optoelectronic synapses, which integrate memory and processing, are prevalent in this field, their inherent optical-to-electrical conversion during signal processing incurs significant energy costs. In contrast, our proposed device operates purely in the optical domain. Under ultraviolet–visible light control, the change in light transmittance of this device can simulate various key biological synaptic plasticity behaviors, including paired-pulse facilitation and learning ability. By integrating these devices into a 28 × 28 synaptic array, we constructed an artificial neural network that mimics the experience-driven enhancement characteristic of human visual perceptual learning. Under light-responsive regulation, the system optimized image recognition learning behavior, and after multiple training sessions, the recognition accuracy stabilized above 97%. This study is based on two-dimensional perovskite materials and provides a new material platform for realizing intelligent visual systems with adaptive learning capabilities. Full article

Surface plasmon resonance (SPR) sensors based on nanostructured metasurfaces offer enhanced sensitivity through engineered electromagnetic responses. In this study, we present an analytical and numerical investigation of the plasmonic behavior of gold nanopillar (Au-NP) and nanohole (Au-NH) arrays under both p- and s-polarized illumination, employing the Effective Medium Theory (EMT) in combination with the Transfer Matrix Method (TMM). The study combines Effective Medium Theory (EMT) and the Transfer Matrix Method (TMM) to describe the macroscopic optical response of multilayer plasmonic systems. For p-polarization, the nanostructure geometry strongly modulates the real and imaginary parts of the effective permittivity, with nanoholes supporting stronger SPR coupling and reduced optical losses compared to nanopillars. Under s-polarization, the effective permittivity remains largely invariant, primarily driven by the filling fraction. The analysis reveals that polarization-dependent behavior arises from boundary-condition-mediated coupling mechanisms governing surface plasmon excitation, aligning with classical plasmonic theory. Benchmarking against analytical dispersion relations and published experimental data for Au/BK7 systems shows close agreement within ±2°, confirming the physical consistency of the EMT–TMM framework. These results provide a systematic description of how polarization and filling fraction jointly modulate SPR coupling. The results offer a foundation for the rational design of plasmonic coatings and SPR-supporting metasurfaces by elucidating macroscopic coupling trends; however, no quantitative sensor performance metrics, such as refractive index sensitivity or figure of merit, are evaluated in this work. Full article

This paper presents the concept of a 2D m × n waveguide-based power combiner (PC) that is scalable with respect to the operating frequency band and number of input ports. To our knowledge, this work reports the first planar (2D) power combiner, where the input waveguide ports are distributed in two spatial dimensions to form an array, rather than arranged along a single linear (1D) axis as in conventional corporate or cascaded waveguide combiners. The novelty of the approach relies on using H-plane rectangular waveguide T-junctions and low-loss polarization twisters in between vertically stacked T-junctions to facilitate scalability. The work is motivated by the aim to coherently combine the output power of multiple modified uni-traveling carrier (MUTC) terahertz (THz) waveguide photodiodes (PDs) in a 2D array configuration. In the manuscript, the design of a 2 × 2 planar waveguide power combiner for the WR3 band (220–320 GHz) is reported, and it is also shown that this block can be further extended to m × n input ports. Full-wave numerical analysis of the proposed 2 × 2 power combiner shows a return loss of 11 dB at the output port and an average transmission coefficient of about −6.5 dB, i.e., an overall power combining efficiency of ~90%. Furthermore, to enable 2D photodiode array integration, the manuscript presents a new slot-bow tie antenna integrated MUTC photodiode for radiating the optically generated THz power from each PD vertically into the rectangular waveguide. The simulation results of reflection loss and insertion loss for the slot bow-tie antenna are shown to be better than 10 dB and 1.4 dB over the full WR3 band, respectively. To prove scalability of the power combiner concept w.r.t. the number of input ports, a 2 × 4 power combiner is also analyzed. Results reveal a return loss better than 10 dB from 225 to 318 GHz and a transmission coefficient of approximately −9.7 dB at 300 GHz, i.e., a power combining efficiency of ~85%. Full article

The 2x2 Demonstrator, a prototype for the Deep Underground Neutrino Experiment (DUNE) liquid argon (LAr) Near Detector, was exposed to the Neutrinos from the Main Injector (NuMI) neutrino beam at Fermi National Accelerator Laboratory (Fermilab). This detector is a prototype of a new modular design for a liquid argon time-projection chamber (LArTPC), comprising a two-by-two array of four modules, each further segmented into two optically isolated LArTPCs. The 2x2 Demonstrator features a number of pioneering technologies, including a low-profile resistive field shell to establish drift fields, native 3D ionization pixelated imaging, and a high-coverage dielectric light readout system. The 2.4-tonne active mass detector is flanked upstream and downstream by supplemental solid-scintillator tracking planes, repurposed from the MINERvA experiment, which track ionizing particles exiting the argon volume. The antineutrino beam data collected by the detector over a 4.5 day period in 2024 include over 30,000 neutrino interactions in the LAr active volume—the first neutrino interactions reported by a DUNE detector prototype. During its physics-quality run, the 2x2 Demonstrator operated at a nominal drift field of 500 V/cm and maintained good LAr purity, with a stable electron lifetime of approximately 1.25 ms. This paper describes the detector and supporting systems, summarizes the installation and commissioning, and presents the initial validation of collected NuMI beam and off-beam self-triggers. In addition, it highlights observed interactions in the detector volume, including candidate muon antineutrino events. Full article

The network traffic of 3D parallel training in large-scale deep learning, featuring burstiness, hot-spots, and periodic large-bandwidth patterns, severely challenges network efficiency, necessitating a high-performance and flexible optical network solution. To address this, this paper proposes Mercury, a hybrid optical network based on physical optical components: its optical timeslot switching (OTS) subnet uses an arrayed waveguide grating router (AWGR) and tunable lasers for dynamic traffic, while the optical circuit switching (OCS) subnet relies on wavelength selective switches (WSSs) for low-latency high-bandwidth transmission, which is coordinated by selective valiant load balancing (S-VLB) and most efficient path configuration (MEPC) mechanisms. Validated via simulations and FPGA-based testbed experiments, Mercury outperforms the Sirius network by reducing epoch training time (e.g., 179s with five jobs) and relieving OTS congestion through offloading large flows to OCS. This work demonstrates that Mercury provides a flexible, high-performance physical optical solution for 3D parallel training of large-scale deep learning models. Full article

To address the problems of insufficient light energy utilization and light leakage in existing concentrator lighting systems, this paper proposes a novel Stepped Integrated No-Leakage Concentrator Lighting System. This system adopts a design that combines a concentrator module array with a stepped light guide plate. By constructing a stepped integrated concentrator structure and a composite parabolic coupling configuration, the system enables efficient solar energy collection and delivery, significantly improving concentration efficiency and energy utilization. First, based on the principles of geometric optics, theoretical modeling of the concentrator modules and light guide plate was conducted. The relationships among the paraboloid coefficient, step height of the light guide plate, and the number of concentrator modules were analyzed to clarify their influence on the geometric concentration ratio and concentration efficiency of the system. Subsequently, optical performance simulations under varying structural parameters were performed using a joint simulation platform based on SolidWorks Premium 2024 SP5.0 and LightTools(64) 8.6.0 Copyright (c) 1994-2018 Synopsys, Inc. The results indicate that the proposed structure achieves excellent light-guiding performance and high optical efficiency, with a maximum concentration efficiency of 94% and a geometric concentration ratio of 50. On this basis, a physical prototype was fabricated, and experimental testing was carried out. The results validated the accuracy of the simulation, with the system reaching a concentration efficiency of 54.6% at noon, further confirming the feasibility and superior performance of the proposed design. This study demonstrates that the Stepped Integrated No-Leakage Concentrator Lighting System offers significant advantages in enhancing light energy utilization and reducing leakage losses, providing an efficient solution for natural daylighting and interior illumination in green buildings. Full article

High-resolution long-wave infrared imaging is critical for lunar mineralogy. However, it must balance a large FOV, a small F-number, chromatic aberration correction, optical efficiency, and system compactness. We introduce a push-broom multispectral imager employing a collaborative integrated filter array and an off-axis two-mirror Gregorian telescope. The system, utilizing an uncooled Vanadium Oxide detector, has an F-number of 1.0, an IFOV of 0.04943 mrad, and a 2.90° × 2.83° FOV that covers eight bands ranging between 7.38 and 14.3 μm. Optical simulation confirms that the modulation transfer function exceeds 0.25 at the Nyquist frequency of 42 lp/mm, with a maximum RMS spot radius of less than 12 μm. The system has remarkable versatility within an operating temperature range of 0 °C to 40 °C. Thermal background radiation analysis, stray light analysis, and detection sensitivity were conducted, which indicated that the system has good compliance with indicators and engineering feasibility. This high-throughput optical design meets the rigorous criteria for lunar remote sensing and provides a reliable device for site evaluation in future manned lunar missions. Full article

We report a versatile, CMOS-compatible fabrication module for sub-100 nm TiN and TaN pillar electrodes, a key building block for sandwich-type test structures. As a demonstration, the electrodes were integrated into carbon nanotube-based nonvolatile random-access memory (CRAM) test structures. High-resolution hydrogen silsesquioxane (HSQ) masks defined by electron beam lithography were transferred into TiN films using optimized Ar/Cl₂ inductively coupled plasma reactive ion etching. Optical emission spectroscopy was used for real-time endpoint detection, ensuring precise etch control. The process achieved a TiN-to-HSQ selectivity of ~1.6 and reproducible nanoscale features with smooth sidewalls and an average taper angle of ~77°. Buffered hydrogen fluoride treatment effectively removed residual HSQ, revealing sharp TiN features and preserving pillar geometry. Atomic force microscopy (AFM) confirmed pillar height and profile fidelity, while conductive AFM verified electrical conductivity after planarization. The module was further demonstrated through the fabrication of TiN pillar arrays, TaN pillars, and sub-100 nm TiN line arrays. A CRAM test structure incorporating TiN pillars exhibited preliminary switching, indicating that both the test structure and fabrication process are feasible. This fabrication module provides a reproducible platform for nanoscale TiN and TaN electrodes, supporting laboratory-scale research and providing a pathway toward future integration of emerging memory and nanoelectronic technologies. Full article

Present and future rare isotope accelerator facilities provide new opportunities to explore the structure of unstable nuclei. We report the measurements of the elastic scattering angular distributions of ²¹Na and ²²Na on the doubly magic ⁴⁰Ca above the Coulomb barrier energies, using high-purity post-accelerated ISOL beams from Beijing Radioactive Ion Beam Facility (BRIF). Angular distributions were measured with a silicon detector telescope array, and relative cross sections were determined with a CaF₂ target on Au backing. The data were well reproduced by optical model calculations with Woods–Saxon and USNP potentials, the latter giving better agreement. These results confirm the stable operation and performance of the BRIF ISOL production and post-acceleration system, demonstrate its capability to provide radioactive beams of useful intensity and purity for future investigations of reaction dynamics and astrophysically relevant processes involving proton-rich nuclei, and simultaneously extend proton-rich elastic scattering studies to heavier systems. Full article

Field-Programmable Gate Arrays (FPGAs) have become an important platform for accelerating real-time communication systems, and System-on-Chip (SoC) devices provide the flexibility to design and optimize architectures that support high data rates, different modulation formats, and channel equalization schemes. Selecting the appropriate architecture can be guided through Design Space Exploration (DSE) using high-level synthesis tools, which enables the identification of numerical representations that balance performance with reduced hardware resource consumption. Despite their relevance, recent developments in communication systems often overlook the impact of numerical precision in Digital Signal Processing algorithms, particularly the trade-offs between floating- and fixed-point arithmetic when targeting hardware implementations. In this work, two widely used blind equalization algorithms, the Constant Modulus Algorithm (CMA) and the Multi-Modulus Algorithm (MMA), were implemented on a low-cost Ultra96 SoC-FPGA to analyze the effect of a fixed-point representation. A multi-objective Design Space Exploration methodology was applied to minimize hardware utilization while maintaining reliable transmission performance. Resource consumption, latency, and throughput were measured across different binary formats using the Minimum Mean Square Error (MMSE) criterion. Parallelization techniques were incorporated to improve throughput. The DSE generated comprehensive performance surfaces quantifying latency, MMSE convergence, and FPGA resource utilization (DSP48E/FF/LUT/BRAM) across fixed-point formats, achieving optimal 4 MS/s throughput configurations. Although this throughput is naturally lower than the Gigabit speeds required in backbone optical networks, the results demonstrate the effectiveness of numerical representation optimization in resource-constrained SoC-FPGA devices, offering a practical approach for real-time Edge and IoT implementations where cost and hardware limitations are critical. Full article
