Search Results (10)

Magnetic gears offer an energy-efficient alternative to conventional mechanical gears through magnetic fields rather than physical contact. A non-contact operation eliminates frictional losses, mitigates wear, and reduces vibration, noise and maintenance requirements. In recent years, the development of magnetic gear technologies has accelerated, driven by advances in materials, innovative gear topologies, and emerging applications. This paper presents a comprehensive review of magnetic gear technologies with particular emphasis on their applications in battery electric vehicles and hybrid electric vehicles. First, the development of magnetic gears is reviewed from early converted magnetic analogues of mechanical gears to high-performance field-modulated variable gear designs. The review subsequently examines the use of magnetic gears in electric vehicle applications, including magnetic geared in-wheel motors, traction modules, and magnetic gears in hybrid electric vehicles, such as magnetic variable gears for hybrid vehicle applications, magnetic geared electric variable transmissions and power-splitting devices. The review also discusses novel and less-established MG applications before examining the challenges limiting their widespread adoption in EV and HEV drivetrains. Full article

The In-Wheel Motor represents a non-conventional propulsion architecture in which the electric motor is integrated into the wheel, offering advantages such as improved energy efficiency, individual torque control, and drivetrain simplification. In this study, two architectures, inboard and outboard, were developed using an original three-dimensional motor–brake–suspension–steering assembly model, in which disk brake position and In-Wheel Motor integration act as primary design drivers influencing vehicle dynamics. Both architectures were developed in CATIA V5 and exported to Altair Motion 2025 for multibody dynamics simulations. The study evaluates the impact of inboard versus outboard disk brake positioning on vehicle dynamics and provides a qualitative assessment of the associated architectures in terms of mechanical complexity, serviceability, sealing requirements, bearing load asymmetry, and packaging constraints. The results indicate that the inboard architecture exhibits more linear and stable kinematics and compliance (K&C) behavior compared to the outboard configuration, at the expense of increased mechanical complexity and reduced serviceability. By contrast, the outboard architecture preserves a simpler, more conventional MacPherson-like layout with a lower component count and improved service access but is dynamically outperformed under the imposed geometric constraints of the present study. Full article

A new type of transportation vehicle, the maglev car, is gaining attention in the automotive and maglev industries due to its potential to meet personalized urban mobility and future travel needs. To optimize the chassis layout of maglev cars, this paper proposes a compact powertrain integrating electrodynamic suspension with in-wheel motor technology, in which a permanent magnet electrodynamic in-wheel motor (PMEIM) enables integrated propulsion and levitation. First, the PMEIM external magnetic field distribution is characterized by analytical and finite element (FEM) approaches, revealing the magnetic field distortion of the contactless powertrain. Subsequently, the steady-state electromagnetic force is modeled and the operating states of the PMEIM powertrain are calculated and determined. Next, the PMEIM electromagnetic design is conducted, and its electromagnetic structure rationality is verified through magnetic circuit and parametric analysis. Finally, an equivalent prototype is constructed, and the non-contact electromagnetic forces of the PMEIM are measured in bench testing. Results indicate that the PMEIM powertrain performs propulsion and levitation functions, demonstrating 14.2 N propulsion force and 45.8 N levitation force under the rated condition, with a levitation–weight ratio of 2.52, which hold promise as a compact and flexible drivetrain solution for maglev cars. Full article

Inter-turn short-circuit (ITSC) faults in permanent magnet synchronous machines (PMSMs) present a significant reliability challenge in electric vehicle (EV) drivetrains, particularly under non-stationary operating conditions characterized by inverter-driven transients, variable loads, and magnetic saturation. Existing diagnostic approaches, including motor current signature analysis (MCSA) and wavelet-based methods, are primarily designed for steady-state conditions and rely on manual feature selection, limiting their applicability in real-time embedded systems. Furthermore, the lack of publicly available, high-fidelity datasets capturing the transient dynamics and nonlinear flux-linkage behaviors of PMSMs under fault conditions poses an additional barrier to developing data-driven diagnostic solutions. To address these challenges, this study introduces a simulation framework that generates a comprehensive dataset using finite element method (FEM) models, incorporating magnetic saturation effects and inverter-driven transients across diverse EV operating scenarios. Time-frequency features extracted via Discrete Wavelet Transform (DWT) from stator current signals are used to train a Transformer model for automated ITSC fault detection. The Transformer model, leveraging self-attention mechanisms, captures both local transient patterns and long-range dependencies within the time-frequency feature space. This architecture operates without sequential processing, in contrast to recurrent models such as LSTM or RNN models, enabling efficient inference with a relatively low parameter count, which is advantageous for embedded applications. The proposed model achieves 97% validation accuracy on simulated data, demonstrating its potential for real-time PMSM fault detection. Additionally, the provided dataset and methodology contribute to the facilitation of reproducible research in ITSC diagnostics under realistic EV operating conditions. Full article

Electric machines (EMs) of electrified vehicle drivetrains can be tested on drivetrain test benches at an early stage of development. In order to protect the EMs from premature damage or failure during testing, monitoring their thermal condition is important. Due to the package requirements of compact and powerful EMs with high-speed requirements and high-power densities, the heat build-up inside the motor during operation is particularly high. For this reason, fluid cooling with heat exchangers is increasingly being used in EMs. The EMs analysed in this work are water-cooled by a cooling jacket. This influences the heat flow inside the machine through heat transfer mechanisms, making it difficult to detect damage to the EMs. This paper presents a novel method for non-destructive and non-contact thermal condition monitoring of water-cooled EMs on drivetrain test benches using thermography. In an experimental setup, infrared images of an intact water-cooled EM are taken. A bearing of the EM’s rotor is then damaged synthetically, and the experiment is repeated. The infrared images are then processed and analysed using appropriate software. The analysis of the infrared images shows that the heat propagation of the motor with bearing damage differs significantly from the heat propagation of the motor without bearing damage. This means that thermography opens up another method of condition monitoring for water-cooled EMs. The results of the investigation serve as a basis for future condition monitoring of water-cooled EMs on powertrain test benches using artificial intelligence (AI). Full article

Motor railway vehicles necessitate enhanced control of wheel-rail contact mechanics to ensure optimal adhesion. During train running, driving wheelsets exhibit torsional vibrations that compromise adhesion and potentially lead to axle damage. Consequently, the development of dynamic models for analyzing driving wheelset stick-slip phenomena and control strategies is an area of significant research interest for traction control, studies on rail corrugation, and locomotive drivetrain design. Despite their application in various railway vehicle problems, non-smooth models have not been explored as an alternative for analyzing stick-slip, and existing research has focused on extensive computations based on Kalker’s theory or simplified models using constitutive friction laws. This work demonstrates the efficacy of non-smooth models in studying motor wheelset stick-slip. The non-smooth approach is suited for control systems, prioritizes simplicity while capturing the essential friction characteristics, and enables efficient dynamic simulations. The proposed model incorporates a set-valued friction law, and the equations of motion are formulated as a switch model. Numerical integration is achieved through an event-driven algorithm. The paper showcases application examples for the model. A direct comparison with an equivalent model using a constitutive friction law shows that the non-smooth integration is an order of magnitude more efficient in the stick phase. Full article

Electric and hybrid vehicles, similarly to combustion engine ones, can experience malfunctions, yet preventive diagnostics for their electric motors are underdeveloped. While many methods exist for testing electric motors in heavy industry, they are not commonly applied in the vehicle industry. Our study aims to develop a real-time, non-invasive fault detection procedure for electric motors in these vehicles. Previous research has focused on simulations, but our work involves real measurements conducted in a controlled laboratory using a two-axle chassis dyno. We present the hybrid vehicle’s drivetrain, our equipment, and the feasibility of simulated methods, and we also detail the evaluation method used. Full article

Rare earth element (REE) permanent magnets (NdFeB) are a critical element in a vast and growing number of industrial applications. In consumer electronics, a broad category encompassing computer, CD, and DVD hard drives, in addition to the ubiquitous cell phones, the nominal NdFeB magnet content may be small, but the global market share for this sector accounts for almost 30% of NdFeB demand, due to a large and continually increasing consumer base. It is estimated that wind turbines that primarily employ permanent magnets will add roughly 110 GW annually of on- and off-shore capability over the next few years. Electric vehicles (EVs) and E-bicycles (EBs) equipped with permanent magnet motors comprise the transportation contribution. Permanent magnet motors have garnered nearly 100% of the market share among EV manufacturers worldwide. Industrial, professional service, and personal robots, most using permanent magnets, are also included in the projected global need for rare earths, particularly Nd and Dy. The sector projects significant growth of approximately 10% across robotic categories. In this paper, we calculate the future demand for Nd and Dy through 2050 across these sectors using a compounded annual growth rate coupled with magnet weight and rare earth content. Uncertainties in the estimates, such as the true global production of Nd, a range of end-product scales and/or unit types in each sector, varied magnet compositions, and the variety of uses within a sector, are all considered. Full article

To offer point absorber wave energy converters (WECs) as a bankable product on the marine renewable energy market, multiple WECs will be installed together in an array configuration. The wave energy community (research and industrial) has identified the urgent need for available realistic and reliable data on WEC array tests in order to perform a better WEC array optimization approach and in order to validate recently developed (non-linear) numerical models. The ‘WECfarm’ project is initiated to cover this scientific gap on necessary experimental data. The ‘WECfarm’ experimental setup consists of an array of five generic heaving point-absorber WECs. The WECs are equipped with a permanent magnet synchronous motor (PMSM), addressing the need for WEC array tests with an accurate and actively controllable power take-off (PTO). The WEC array control and data acquisition are realized with a Speedgoat Performance real-time target machine, offering the possibility to implement advanced WEC array control strategies in the MATLAB-Simulink environment. The presented article describes the experimental setup, the performed tests and the results of the test campaign using a single, isolated ‘WECfarm’ WEC in April 2021 at the wave basin of Aalborg University (AAU), Denmark. A Coulomb and viscous friction model is determined to partly compensate for the drivetrain (motor, gearbox, rack and pinion) friction. A system identification (SID) approach is adopted considering the WEC system to be composed of two single input single output (SISO) models, the radiation and the excitation model. Radiation tests yield the intrinsic impedance. Excitation tests yield the excitation frequency response function. Adopting an impedance matching approach, the control parameters for the resistive and reactive controller are determined from the complex conjugate of the intrinsic impedance. Both controllers are tested for a selection of regular wave conditions. The performed experimental test campaign using an isolated ‘WECfarm’ WEC allows a full evaluation of the WEC design prior to extending the setup to five WECs. Within the ‘WECfarm’ project, an experimental campaign with a five-WEC array in the Coastal and Ocean Basin (COB) in Ostend, Belgium, is under preparation. Full article

In order to meet requirements in machine design, modularity is often brought forward as a way to cope with load variations and adaptability of the architecture. The considered modular drivetrain consists of several identical induction motors, called motor modules, in cascade on the same shaft. However, implementing a modular drivetrain design evidently has an impact on the performance of the application. New opportunities may arise, such as improved motion dynamics and tolerance to failures. However, on other aspects, e.g., torsional vibrations and synchronization, performance can be negatively influenced. By adding multiple actuators in the drivetrain, additional sources of torque ripple are introduced. The aim of this article is first to investigate the impact of using a modular design on the torsional vibrations in the drivetrain, and second to mitigate these vibrations via an interleaving strategy of the PWM (pulse-width modulation) signals. Simulations and experimental data show that the modular setup requires a proper control strategy in order to ensure that the torsional vibrations in the system remain within the range of a traditional non-modular design. Interleaving of the PWM carrier waveforms in the different motor modules is proposed as a control method to mitigate the torsional vibrations identified in the modular drivetrain. This strategy results in a drivetrain setup that slightly outperforms the benchmark in terms of torsional vibrations. Full article
