Search Results (71)

This paper presents a fully integrated E-band (83/95 GHz) diplexer realized in STMicroelectronics’ BiCMOS 55 nm technology. The design directly addresses the critical trade-off between miniaturization and the performance required for high-frequency on-chip systems. The key innovation is a novel patch resonator optimally exploiting the multi-layer structure of the technology’s Back-End-Of-Line. It achieves significant compactness by jointly combining two distinct miniaturization techniques: slotted structures and mushroom-type capacitive loading. This method results in an impressive 77% size reduction compared to conventional designs. Furthermore, we introduce precisely controlled transmission zeros (TZs) to maximize inter-band isolation. The fabricated diplexer achieves a remarkably narrow fractional bandwidth (FBW) of 8.2%—the lowest reported to date for integrated BiCMOS/CMOS E-band implementations—and a robust inter-band isolation exceeding 25 dB, while demonstrating excellent return loss (better than 25 dB). Hence, this work validates a highly compact and scalable approach for integrated E-band transceivers, paving the way for future 6G front-end applications. Full article

This article presents an intelligent differential capacitive bioelectronic sensing system that provides an experimental foundation for future AI-assisted reliable microfluidic reagent delivery in automated pathology. The proposed platform integrates a slot-type microfluidic chamber, a differential slot-line capacitive sensor, embedded readout and signal-conditioning electronics, and a supervisory state assessment concept within a unified architecture. Its purpose is to support stable microliter-scale reagent exchange together with non-invasive process observability in automated staining workflows. The experimental study included flow calibration, analysis of feed direction and chamber tilt angle, preliminary vibration-assisted bubble mobilization, and evaluation of the sensing subsystem. The results showed that reliable operation is achieved only within a practically admissible regime in which fluidic stability and sensing informativeness overlap. In the investigated setup, upper-feed delivery and low chamber tilt angles provided the most favorable filling conditions, while the differential capacitive subsystem enabled stable detection of liquid-state changes in narrow microtubes. The reported results establish a foundation for future AI-assisted transport-state recognition and adaptive monitoring in automated pathology platforms. Full article

This paper presents a systematic qualification process for an electronic beam-steering antenna assembly for a low-Earth orbit (LEO) communication satellite. The transmitting/receiving antenna for the LEO communication satellite is based on a cavity-backed slot radiator, which has improved radiation efficiency and low mutual coupling compared to conventional PCB patch structures. In order to verify the electrical performance and reliability of the manual soldering process in a tightly spaced array structure with narrow element spacing and densely connected multi-channel RF modules, a reduced model was designed and fabricated and qualification tests were conducted under launch and on-orbit environments. The integration equipment was developed to ensure precise mechanical alignment and integration/disassembly between the radiating element arrays of the transmitting and receiving antenna modules and the RF modules, thereby establishing a manufacturability strategy for the antenna module and RF integrated module, which comprise a large array structure. Finally, the qualification tests of the transmitting and receiving antenna were performed to evaluate the structural and thermal stability considering the launch and orbital environments. The systematic qualification process proposed in this paper can be used in the development of the antenna system of the communication satellite. Full article

Ground-based scatterometers are widely used for quantitative microwave backscattering measurements in soil moisture retrieval, vegetation monitoring, and satellite scatterometer validation. However, low-cost software-defined radio (SDR) transceivers provide limited instantaneous bandwidth, making it difficult to transmit and process signals with bandwidths on the order of hundreds of MHz for fine range resolution, especially for systems requiring real-time onboard processing. To address this problem, this paper presents a vehicular, fully polarimetric, SDR-based scatterometer that achieves an equivalent wideband response by sequentially transmitting adjacent narrow subbands and coherently synthesizing them onboard. To enable real-time operation on a resource-limited field-programmable gate array/system-on-chip (FPGA/SoC) platform, we adopt a frequency-domain synthesis-pulse-compression pipeline that avoids interpolation and eliminates repeated matched filtering across subbands. A slot-based online phase calibration is performed within the settling window after each fast lock to estimate and compensate random local oscillator (LO) phase offsets, preserving coherent stitching. In addition, pulse repetition within each subband and coherent accumulation are integrated to improve the signal-to-noise ratio (SNR) under real-time throughput constraints. A Zynq-based implementation demonstrates deterministic onboard range-profile output, with a minimum processing latency of about 1.57 ms per frame. Loopback and outdoor experiments validate the equivalent 200 MHz bandwidth (five 40 MHz subbands), achieving approximately 0.75 m resolution and yielding sidelobe metrics consistent with the designed windowing, including a peak sidelobe ratio (PSLR) of −27.43 dB and an integrated sidelobe ratio (ISLR) of −12.38 dB. Field scans over farmland further show consistent ${\mathsf{\sigma }}_0$ trends across incidence angle and azimuth, indicating reliable onboard quantitative backscattering measurement. These results demonstrate that the proposed method provides a feasible solution for deterministic real-time equivalent wideband scatterometry on a low-cost SDR platform. Full article

An electrically tunable wide-beam-scanning metagratings leaky-wave antenna (MGs LWA) based on liquid crystal (LC) is proposed. Two-dimensional (2D) periodic slotted MGs with capacitive and inductive behaviors are etched on the bottom layer of the substrate and backed by a ground plane with an LWA framework. Two different slotted MG elements are adopted to suppress the open-stopband effects. A theoretical analysis is conducted to provide a conceptual framework for the equivalent electromagnetic fields generated by slotted MGs. Using LC, tunable beam scanning is achieved at a fixed frequency. The LC is placed between the inverted MGs LWA radiating metal and the ground plane to control the LC molecules’ orientation angle by applying a DC voltage across them, thereby adjusting the LC permittivity. Using the results obtained, the proposed antenna can be tuned up to 40° at a fixed frequency by applying a biased DC voltage ranging from 0 V to 10 V. The actual operating bandwidth is 40% for continuous beam scanning of 71°, with a scanned sensitivity of 8.35°/GHz at the zero voltage (V = 0 V), and beam scanning of 61°, with a scanned sensitivity of 7.17°/GHz at the saturation voltage (V = 10 V). The proposed MGs LWA has a realized gain of up to 13.84 dBi. Finally, the proposed antenna has excellent performance due to its potential to achieve wide tunable beam scanning with a narrow beamwidth compared to traditional LWAs’ limitation of radiation angle, depending on the excitation frequency, which makes the proposed antenna suitable in terms of range and sensing calibration for operation at a specific frequency in sensing communication and radar applications. Full article

To address the computational-efficiency bottlenecks of Hybrid A* and its bidirectional variant in long-distance parking and narrow-slot scenarios, an improved bidirectional Hybrid A* algorithm is presented. First, the cohesion cost is reformulated in a vector-space representation. Distance and heading-consistency terms are evaluated using dot products, which eliminates trigonometric operations and reduces the overhead of node evaluation. Second, an RS (Reeds–Shepp) cost template is constructed on a sparse grid of key nodes. Neighborhood costs are approximated with Euclidean-distance correction. In addition, a geometry reachability-based trigger is designed for analytic RS connections to avoid redundant analytic linking and unnecessary RS curve computations. Third, a KD-tree spatial index is introduced to accelerate nearest-neighbor queries in the Voronoi potential field, and vehicle corner coordinates are updated in a vectorized manner to improve the efficiency of potential-field evaluation. Simulation results in parallel and perpendicular parking show that, compared with the baseline bidirectional Hybrid A* algorithm, RS computations are reduced by 98.7% and 97.8%, respectively, while total planning time is shortened by 63.2% and 57.5%, with stable path quality. These results indicate that the proposed method effectively mitigates the dominant computational costs of bidirectional Hybrid A* in complex parking tasks and improves the efficiency and real-time performance of automatic parking path planning. Full article

Integrated satellite-terrestrial networks are crucial for critical communications, yet the initial access for user equipment (UE) is hampered by signal blockage and dynamic loads, challenging traditional random access (RA) mechanisms in achieving low latency and high success rates. To address this, we propose a Sensing-aware Random Access (SaRA) mechanism. SaRA introduces a lightweight sensing micro-slot before the standard RACH procedure, leveraging the sensing signal to jointly determine an optimal access decision threshold and a candidate beam set. This proactively filters users with poor channel conditions and narrows the beam search space. We formulate the resource allocation as a constrained optimization problem and propose a practical, low-complexity algorithm. Extensive simulations validate that SaRA provides substantial gains in access latency and system access capacity under high-load conditions compared with the standard 3GPP FR2 RACH baseline, while maintaining competitive first-attempt success probability with minimal additional overhead. Full article

Non-contact monitoring of human vital signs using microwave radar has attracted increasing attention due to its capability to operate unobtrusively and through clothing or light obstacles. In vector network analyzer (VNA)-based radar systems, vital signs can be extracted from phase variations in the forward transmission coefficient $S_{21}$, whose sensitivity strongly depends on the electromagnetic performance of the antenna system. This work presents the design, optimization, fabrication, and experimental validation of a high-gain 12 GHz 4 × 4 microstrip patch antenna array specifically developed for phase-based vital signs monitoring. The antenna array was progressively optimized through coaxial feeding, slot-based impedance control, stepped transmission line matching, and mitered bends, achieving a simulated gain of 17.8 dBi, a measured gain of 17.06 dBi, a reflection coefficient of −26 dB at 12 GHz, and a total efficiency close to 74%. The antenna performance was experimentally validated in an anechoic chamber and subsequently integrated into a continuous-wave VNA-based radar system. Comparative measurements were conducted against a commercial biconical antenna, a single patch radiator, and an MIMO antenna under identical conditions. Results demonstrate that while respiration can be detected with moderate-gain antennas, reliable heartbeat detection requires high-gain, narrow-beam antennas to enhance phase sensitivity and suppress environmental clutter. The proposed array significantly improves pulse detectability in the (1–1.5) Hz band without relying on advanced signal processing. These findings highlight the critical role of antenna design in $S_{21}$-based biomedical radar systems and provide practical design guidelines for high-sensitivity non-contact vital signs monitoring. Full article

This paper proposes a dual-band, full-polarized (dual-sense circular polarization and arbitrary linear polarization) annular-ring slot antenna centered at 2.4 GHz and 5.8 GHz, which effectively overcomes the limitations of narrow bandwidth and limited polarization diversity in conventional designs. By employing an eccentric annular-ring slot and two orthogonal 50-ohm patches, the antenna achieves dual-band circular polarization (CP) radiation with single-port feeding. Based on the theory of orthogonal dual-circular polarization synthesis, arbitrary linear polarization (LP) can be generated by adjusting the phase difference when both ports are fed. The measured results show that the 10 dB return loss bandwidth of LP spans 2–2.8 GHz (relative bandwidth of 33.3%) and 4.5–7.5 GHz (relative bandwidth of 50%), with polarization isolation exceeding 50 dB. For CP mode, the measured bandwidth (for 10 dB return loss and 3 dB axial ratio) ranges from 2.24 to 2.58 GHz (relative bandwidth of 14.1%) and from 5.1 to 6.6 GHz (relative bandwidth of 25.64%), with polarization isolation greater than 15 dB. The proposed antenna simultaneously features a high frequency ratio (2.42), full polarization, high polarization isolation, a low profile (0.008 λ₀), and bidirectional radiation, which can meet the urgent demand of modern information systems for dual-band, full-polarized antennas. Full article

The highly directional narrow-beam operation in mmWave networks, while effective at suppressing interference, lacks adaptability to dynamic traffic variations and blockages compared to D-TDD and JT schemes. D-TDD efficiently mitigates DL–UL cross-interference during asymmetric traffic. At the same time, joint transmission coordinates multiple base stations to deliver phase-aligned signals, converting interference into useful combined power and ensuring stable links under dynamic slot changes. However, these adaptive regimes are often overlooked in recent mmWave designs, leading to degraded communication performance. This work proposes D-TDD-based cooperative caching (DTCC) mmWave networks, where randomly distributed base stations with local caches enhance reliability and reduce backhaul load. Closed-form expressions for the cache hit probability and the average content success probability (ASP) are derived under the proposed DTCC framework. Popularity-based caching strategies with both equal and variable file sizes are analysed to maximise network-level performance. The simulation results validate that the proposed DTCC framework consistently enhances ASP in dense small-cell deployments, offering notable reliability gains over conventional single-BS (SBS) and static TDD (S-TDD)-based cooperative caching approaches. Full article

Radar-based water-level monitoring requires antennas with narrow beams, high gain, and low sidelobes. Existing horn and series-fed microstrip arrays either lack compactness or suffer from frequency-dependent beam deviation that reduces sensing accuracy. This paper presents a 256-element slot-coupled planar microstrip array operating in the K-band for water-level radar. The array combines large-scale integration with slot-coupled feeding, which provides inherent 180° phase correction and stabilizes the main beam across frequency. The fabricated array has overall dimensions of 140 mm × 160 mm × 1.12 mm. Simulated results show a peak gain of 22.8 dBi with beamwidths of 5.2° (E-plane) and 4.2° (H-plane), while beam deviation remains within 0.5° across 25.9–27.0 GHz. In comparison, a series-fed array of identical aperture exhibits up to 7.5° deviation and only 15.8 dBi broadside gain. These results demonstrate that the proposed slot-coupled array provides a compact antenna solution meeting regulatory requirements and improving the accuracy of radar-based water-level monitoring systems. Full article

This paper presents a novel 1-to-N power division architecture combining overmoded ${\mathrm{TE}}_{10}$ mode waveguides and modular N-way waveguide-to-microstrip mode converters. By decomposing the ${\mathrm{TE}}_{10}$ mode field distribution along the narrow wall of a rectangular waveguide, the proposed design enables flexible power splitting into arbitrary output ports (even or odd numbers) through uniform sub-${\mathrm{TE}}_{10}$-mode waveguide pathways. To achieve the above function using microwave transmission lines, a tapered transition structure ensures wideband excitation of the overmoded waveguide, while linearly tapered slot antennas (LTSAs) serve as N-way mode converters. Prototypes with two-, three-, and four-channel outputs demonstrate excellent amplitude-phase uniformity (≤0.5 dB amplitude imbalance and ≤$5^{\circ }$ phase deviation) across 6.5–12 GHz, with return loss <−10 dB. The modular 1-to-N power divider enables the rapid reconfiguration of output channels by simply replacing the mode converter module. Full article

Slurry-based additive manufacturing (AM) enables the fabrication of dense and complex ceramic components through the layer-by-layer deposition of high-solid-content slurries. However, the reliable formation of uniform, defect-free slurry layers remains a bottleneck for process stability and final part quality. In this study, the slot-die coating window for alumina slurry (50 wt%, viscosity = 34 Pa·s) was systematically investigated using volume-of-fluid simulations and experiments, with coating speed (0.7–2.8 mm/s), flow rate (0.6–0.8 mL/min), and coating gap (200–400 μm) as key variables. The coating process exhibited three distinct regimes, namely overflow, stable, and unstable, depending on process conditions. For a coating gap of 200 μm on a glass substrate, stable bead formation was observed over the widest coating speed range without overflow or air entrainment. At higher speeds, dynamic wetting failure induced air entrainment and bead breakage, while lower speeds led to overflow defects. When coating on a dried alumina layer (contact angle, CA = 137$°$), the stable window narrowed significantly compared to the glass substrate (CA = 66.7$°)$, highlighting the substantial influence of substrate wettability on coating stability and defect formation. The results derived in this work offer practical guidance for optimizing process parameters to achieve uniform, defect-free films in multilayer ceramic AM. Full article

This work presents a novel $C{O}_2$ gas sensor based on a slotted polymer-phaseshift Bragg grating (SP-PSBG) waveguide filled with polyhexamethylene biguanide (PHMB) as the sensing medium. The transmission resonance, characterized by a narrow peak with a full width at half maximum (FWHM) of 1.6 nm within the Bragg grating bandgap, is highly responsive to refractive index changes in PHMB caused by variations in $C{O}_2$ concentration. Numerical simulations demonstrate a sensitivity of 14.4 pm/ppm, outperforming conventional gas sensors based on functional material coatings. This enhanced performance comes from the direct interaction between the PHMB-filled resonant structure and the cladding that contains $C{O}_2$ molecules, eliminating the need for polymer-coated cladding layers. The optimization approach employed in this design focuses on maximizing the optical confinement factor within the PHMB-filled slot, leading to an effective overlap between the guided optical mode and the sensing material. Full article

Millimeter-wave antennas have become more important recently due to the diversity of applications in 5G and upcoming 6G technologies, of which automotive systems constitute a significant part. Two crucial indices, detection range and angular resolution, are used to distinguish the performance of the automotive antenna. Strong gains and narrow beamwidths of highly directive radiation beams afford longer detection range and finer spatial selectivity. Although conventionally used, patch antennas suffer from intrinsic path losses that are much higher when compared to the waveguide antenna. Designed at 77 GHz, presented in this article is an 8-element slot array on the narrow side wall of a rectangular waveguide, thus being readily extendable to planar arrays by adding others alongside while maintaining the element spacing requirement for grating lobe avoidance. Comprising tilted Z-shaped slots for higher gain while keeping constrained within the narrow wall, adjacent ones separated by half the guided wavelength are inclined with reversed tilt angles for cross-polar cancelation. An open-ended external waveguide is placed over each slot for polarization purification. Equivalent circuit models of slotted waveguides aid the design. An approach for sidelobe suppression using the Chebyshev distribution is adopted. Four types of arrays are proposed, all of which show potential for different demands and applications in automotive radar. Prototypes based on designs by simulations were fabricated and measured. Full article
