A lightweight and high-efficiency microwave-absorbing material was developed via an in situ solvothermal pyrolysis strategy by anchoring sphere-like Fe₃O₄ nanostructures onto bamboo-derived porous carbon (BPC). The resulting composites preserve the intrinsic anisotropic honeycomb architecture of bamboo while introducing uniformly distributed magnetic nanoparticles, enabling synergistic dielectric–magnetic loss. Electromagnetic parameters, alongside impedance matching, were successfully modulated through the optimization of precursor concentrations. Of the evaluated materials, BPC-0.9 stood out for its intense attenuation, recording an RL_min of −45.17 dB at a 1.8 mm thickness. Furthermore, a significant effective absorption bandwidth of 6.65 GHz was attained by the BPC-0.6 sample at only 2.2 mm. Several factors contribute to the boosted efficiency, starting with conductive and interfacial polarization losses paired with multiple scattering events. Furthermore, magnetic loss components, encompassing eddy current effects as well as natural and exchange resonances, play a pivotal role in optimizing the material’s response. Furthermore, radar cross-section (RCS) modeling reveals a substantial reduction of 19.9 dB·m², verifying the material’s viability for real-world stealth technologies. Our findings offer a straightforward methodology for fabricating magnetic carbon structures from biomass with adjustable dielectric responses, underscoring their potential in high-performance energy conversion and low-density microwave absorption. Full article

Electrospun composites are desirable materials for drug delivery applications. Regarding microbial infections as a case study, the antibacterial effect is enhanced by physical attributes of electrospun meshes, namely, a high surface area-to-volume ratio and porosity, 3D topography, and customized surface functions. Beyond mimicking nanostructured fibers, the delivery of antibiotics from such composites enhances antibacterial efficacy, sustained release kinetics, and reduced wound infection while minimizing side effects. Concern over antibiotic resistance and the insufficient availability of pharmaceutical agents for effective infection treatment is increasing worldwide. A significant number of publications have reported the fabrication of electrospun composites to mitigate bacterial pathogenesis. However, from a structural and morphological perspective, the implications of electrospinning approaches for antibiotic delivery have not been reviewed. This proposal presents a comparative study of the different assemblies induced by electrospinning, enabling the development of platforms for administering antibacterial agents. The primary objective is to conduct a comprehensive examination of the considerations involved in electrospinning-based manufacturing of drug delivery systems and antibiotic loading, ensuring a thorough design process that accounts for composite processability, monitoring methods for kinetic behavior analysis and modeling, and biological considerations for pre-clinical in vitro characterization. Full article

Noble metal nanostructures based on localized surface plasmon resonance (LSPR) can induce metal-enhanced fluorescence (MEF) and surface-enhanced Raman scattering (SERS), significantly improving trace detection sensitivity for biomedical and chemical analysis. While self-assembly of noble metal nanoparticles offers simplicity and low equipment dependence, achieving large-area, uniform, and controllable nanostructures remains challenging. In this study, angle-dependent dip coating (ADDC) technology was employed to achieve efficient, controllable self-assembly of silver nanoparticles (AgNPs) on glass slides, establishing a fabrication process for MEF/SERS dual-functional substrates. A stable AgNPs-anhydrous ethanol suspension was prepared and extracted from an inclined substrate reservoir using a microfluidic syringe pump, enabling large-area uniform nanostructure assembly. Systematic investigation revealed that substrate inclination angle provides better morphology and fluorescence enhancement control than withdrawal flow rate. The silver nanostructured surface fabricated under a withdrawal flow rate of 16 mL/h and a substrate inclination angle of 30° exhibited a Cy3 detection limit as low as ${10}^{-1}$ nM, with an enhancement factor ranging from 19.14 to 28.66, as well as an R6G SERS detection limit of ${10}^{-10}$ M with an enhancement factor of 4.07 × ${10}^8$. This study confirms that ADDC technology enables simple, efficient, large-area uniform AgNPs self-assembly for superior dual-function enhancement substrates, offering a cost-effective and efficient strategy for highly sensitive trace detection. Full article

In this study, poly(vinylidene fluoride-co-hexafluoropropylene) (PVDF-HFP) films embedded with silver nanoparticles were fabricated to investigate their antibacterial performance against Escherichia coli (E. coli) and Staphylococcus aureus (S. aureus). Inspired by the nanoscale topographies of natural antibacterial surfaces, such as dragonfly and cicada wings, microstructured pillars were introduced onto the polymer surface to enhance its bactericidal activity by increasing the effective contact area. Surface morphology was characterised using scanning electron microscopy (SEM), including higher-magnification imaging of micropillar surfaces, while energy-dispersive X-ray spectroscopy confirmed the presence of silver. Higher-magnification SEM revealed nanoscale surface features on the micropillars, attributed to embedded or surface-associated silver nanoparticles. Antibacterial performance was evaluated using confocal laser scanning microscopy with live/dead staining. The PVDF-HFP/Ag films exhibited a significant reduction in bacterial viability, particularly against S. aureus (reducing viability to 0.6% ± 1.1%), while showing moderate activity against E. coli (41.0% ± 3.7% viability). While the fabricated micropillars (~5 µm) are larger than bacterial cells and unlikely to induce direct mechanical rupture, they increase surface interaction. To further investigate the theoretical antibacterial mechanism of scaled-down features, finite element analysis (FEA) was performed to model the mechanical interaction between bacterial cells and nanostructured pillars. The simulation results indicated localised stress concentrations that could compromise bacterial membrane integrity, suggesting a possible mechanobactericidal contribution if the microstructures are further reduced to the nanoscale, in addition to the primary biochemical effects of silver nanoparticles. FEA results do not aim to explain the experimentally observed antibacterial performance and should be interpreted only as a conceptual investigation. These findings demonstrate the potential of bio-inspired PVDF-HFP/Ag films as antibacterial materials for food packaging and related applications, subject to future comprehensive toxicity and quantitative microbiological evaluations. Full article

This review describes a process design concept suitable for the fine and specialty chemicals sector. Experimental design and optimization methodologies are powerful tools for developing and improving a wide range of products, processes, and engineering systems. The research articles thoroughly analyzed in this review demonstrate that, regardless of the analytical techniques employed or the specific processes used in the fabrication of fine and specialty chemicals, the systematic implementation of the Design of Experiments and Response Surface Methodology consistently enables the development of high-quality and reproducible outcomes. Across all the studies discussed, comparing newly developed or modified processes with conventional approaches, the application of statistically designed experiments and structured multivariate analysis resulted in significant improvements in key performance indicators. These include increased product yield, reduced process times, enhanced purity, and more precise control over the targeted functional properties of specialty and fine chemicals. Good examples that illustrate the above problem are three studies supported by data from our previously published work and our current research project, in which experimental design and process optimization play major roles in obtaining valuable nanostructured materials. These case studies—rational liquid-in-liquid nanodispersions (ND) for ecological graffiti-coating detergents, solid-in-solid nanodispersions for functionalized sustainable cementitious composites, and solid-in-liquid multicharge cationic surfactant-capped silver nanoparticles (AgNPs)—are deliberately selected to illustrate how the same systematic design and optimization principles can be applied across distinct types of dispersed systems. Together, they demonstrate a coherent methodological progression from formulation to functional material development, highlighting the versatility of this approach across different material states and application domains. The findings of this review provide a solid foundation for the optimized manufacture of novel custom-designed nanoproducts. Full article

We present the development of an infrared sensor based on a meta surface utilizing Dolmen plasmonic nanostructures. This meta surface is engineered to enhance the absorption of infrared light at a specific wavelength. The sensor is optimized for high sensitivity and selectivity in the infrared spectrum. This straightforward meta surface sensor shows promise for various applications, including gas sensing, biosensing, and security. The design is compact and easy to fabricate with studied fabrication tolerance ensuring reliable performance. The sensor was tested for water-based sensing applications, and we tested its performance by using different materials such as ZrN, TiN, Cr, and Au on silicon dioxide. In a separate configuration, a gold nanostructure was fabricated on a silicon layer over a silicon dioxide base to examine the resulting plasmonic response. The results surpass those of other water quality sensors, underscoring the potential of this design for high-performance sensing. The sensor’s high sensitivity and low fabrication costs make it a promising technology for future sensing and monitoring applications. Full article

The transition toward sustainable food packaging requires the integration of biodegradable materials with functional bioactivity. Chlorogenic acid (CGA), a naturally abundant polyphenol, has emerged as a multifunctional compound with the capacity to simultaneously modulate polymer structure and impart active and intelligent functionalities. This review critically examines recent advances in CGA-containing packaging systems, covering fabrication strategies from physical incorporation and chemical grafting to nanostructured and stimuli-responsive architectures. The analysis reveals that CGA plays a dual role. At the molecular level, it regulates the polymer network structure through hydrogen bonding, covalent interactions, and conformational rearrangement. This, in turn, influences mechanical strength, barrier performance, and optical properties. Functionally, CGA provides antioxidant and antimicrobial activity, although its effectiveness depends strongly on the incorporation strategy and concentration. Notably, nanostructured systems and conjugation approaches enable controlled release and enhanced stability. These methods overcome limitations associated with rapid diffusion and environmental degradation, including oxidation, UV exposure, and pH-related instability. Despite these advances, key challenges remain, including CGA instability, uncontrolled release behavior, and limited regulatory and scalability data. Furthermore, while CGA is well established in active packaging, its application in intelligent systems remains limited in the literature, with only a few studies reported on its intelligent applications. Overall, this review highlights the structure–function relationships governing CGA-containing packaging systems and outlines future directions for the rational design of cost-effective, scalable, and multifunctional packaging systems, positioning CGA as a promising component in sustainable strategies for food preservation and waste reduction. Full article

Metasurfaces, planar structures made on a subwavelength scale, enable state-of-the-art manipulation of light and have become a promising solution for compact optical devices. However, fabrication of these nanoscale structures relies on demanding processes, limiting their integration into diverse structures, including three-dimensional ones. In this study, we develop a manufacturing and transfer technique that renders the manipulation and deposition of metasurfaces achievable with high freedom by embedding the nanostructure into a flexible polymer matrix. A metasurface consisting of a TiO₂ nanoparticle array fabricated by nanoimprint lithography was encapsulated within a poly(methyl methacrylate) (PMMA) layer through spin-coating. The layer containing the metasurface was then detached from the original SiO₂ substrate using wet-etching, becoming a free-standing soft sheet carrying nanostructures that can be transferred onto various surfaces. After the transfer, the layer thickness was further tuned through reactive ion etching to modulate the optical response. Incident-angle-resolved transmittance exhibited no significant change in optical bands before and after transfer, confirming that the nanostructure, as well as the photonic band, was well preserved. Thickness reduction of the PMMA cladding induced a clear optical resonance shift, demonstrating controllability of the optical response. This approach provides a versatile route for the installation of metasurfaces and expands the design possibilities for nanophotonic devices. Full article

X-band copper resonating cavities are key components of future pulsed GHz normal-conductive multi-TeV accelerators. High electric field gradients are required for emerging applications; however, as gradients increase, components’ lifetime decreases, primarily due to radiofrequency (RF) breakdown. Coating technologies are being investigated in several laboratories to improve RF structure, performance and lifetime. To this end, we investigated the feasibility of fabricating nanometer-periodic Cu/Mo metallic multilayers on three-dimensional (3D) aluminum mandrels designed to replicate X-band copper resonating cavities. These nanometer-period multilayers are proposed to mitigate surface degradation due to electric breakdown at high accelerating gradients by stabilizing inner cavity surfaces against dislocation evolution and roughening caused by thermo-mechanical fatigue. High-Power Impulse Magnetron Sputtering (HiPIMS) in a bias-controlled dual closed-field magnetron configuration was employed to deposit alternating Mo and Cu nano-layers onto the 3D geometries. Given the complexity of HiPIMS technology, plasma pulse evolution was studied by combining time-resolved optical emission spectroscopy with electrical measurements of the pulse discharge. The influence of the process parameters, particularly the applied DC bias, on film growth was studied using non-destructive microprobe α-particle elastic backscattering spectrometry (µEBS) and scanning transmission electron microscopy (STEM). STEM and µEBS analyses confirmed that Mo layers with thicknesses of approximately 5–35 nm were successfully deposited repeatedly on thicker Cu layers (30–150 nm), preserving individual layer properties with minimal interdiffusion and alloying. The layers were deposited inside trenches with an aspect ratio of 5:1 representative of X-band irises. This technology, coupled with the replica process, could be applied to highly engineered nanostructured coatings for X-band cavity treatment in compact particle accelerator prototypes, as it may improve electrical breakdown lifetime under high accelerating fields, at least for degradation processes driven by the high mobility of copper dislocations. Full article

This communication discusses the problem of depositing equiatomic metal alloy films. It is shown that this problem can be solved using a magnetron equipped with a target constructed using a new “multilayer target” paradigm. This target, sputtered in an argon environment, consists of several parallel metal plates mounted on the magnetron axis. A method based on the equality of the sputtered fluxes generated by the plates is proposed for calculating the geometric dimensions of the plates. This equality leads to a system of algebraic equations, which are proposed to be solved under the assumption of a uniform discharge current density distribution in the sputtering region of the target. The communication describes two types of targets in which the plates have slots of different shapes. In one case, the slots are shaped as sectors of a ring with a given angle. In the other, the plates are shaped as rings. As examples, the geometric dimensions of targets for a balanced magnetron system intended for the deposition of films of equiatomic Ti_0.33Ta_0.33Nb_0.33 and Ti_0.25Ta_0.25Nb_0.25Mo_0.25 alloys are calculated. The presentation is accompanied by the results of individual experiments. This report is preliminary in nature; experimental verification is ongoing. The application of the new paradigm in magnetron target design facilitates the fabrication of films of nanostructured medium- and high-entropy alloys with specified chemical compositions, which is the central theme of the Special Issue devoted to functional nanomaterials. Full article

With the rapid advancement of artificial intelligence and wearable technologies, the demand for soft, multifunctional electronic materials has grown substantially. Hydrogels have emerged as a promising platform due to their intrinsic softness, stretchability, and biocompatibility. Among them, cellulose-based conductive hydrogels uniquely integrate the sustainability of natural polymers with tunable electrical functionality, offering significant potential for flexible and biointegrated electronics. This review provides a comprehensive and critical perspective on the recent progress in cellulose-based conductive hydrogels. We systematically summarize key design strategies, including physical and chemical crosslinking and interpenetrating network engineering. More importantly, we present a comparative analysis of distinct conductive mechanisms, including ionic conduction, conductive polymers, metallic nanostructures, and carbon-based fillers, highlighting the inherent trade-offs among electrical conductivity, mechanical robustness, and environmental stability. Emerging applications in flexible electronics, energy storage, bioelectronics, and self-powered systems are discussed through structure–property relationships. Finally, we outline current challenges and future directions, emphasizing multifunctional integration, scalable fabrication, and long-term operational stability, thereby providing a framework for the rational design of next-generation sustainable electronic materials. Full article

Superhydrophobic coatings are regarded as a promising passive anti-icing strategy; however, their practical engineering application, particularly in electrical insulation, is severely hindered by the performance deterioration caused by mechanical damage and a lack of theoretical understanding of microscopic ice adhesion mechanisms. In this study, a layered polymer composite coating was designed to resolve the trade-off between abrasion resistance and low ice adhesion. The chemistry of the coating relies on a synergistic “primer–topcoat” design: the primer consists of an epoxy resin matrix chemically modified by amino silicone oil to lower its surface energy and improve toughness, while the topcoat features hierarchical SiO₂ clusters functionalized with hexamethyldisilazane (HMDS) and silane coupling agents. This architecture was fabricated via a controllable layer-by-layer spraying method. Systematic investigations revealed that the hierarchical micro/nanostructure, composed of microscale protrusions and nanoscale SiO₂ clusters, provides excellent superhydrophobicity (contact angle of 155.2°, sliding angle of 2°). Crucially, the crosslinked polymer network and stable siloxane (Si-O-Si) covalent bonding ensure that the coating maintains its functionality after a cumulative sand impact of 3 kg, demonstrating superior mechanical durability. Furthermore, differentiated theoretical models for ice adhesion in Cassie–Baxter and Wenzel states were established based on intermolecular interactions, identifying that maintaining a stable Cassie–Baxter state is key to reducing adhesion. This study offers a robust approach to balancing functionality and durability in polymer composites through synergistic structural design, providing both a scalable fabrication strategy and a quantitative theoretical framework for understanding interfacial ice adhesion. Full article

Self-powered photodetectors have attracted widespread attention in Internet of Things applications due to their low power consumption and high sensitivity. In this study, plasmonic self-powered poly(3-hexylthiophene)/zinc oxide (P3HT/ZnO) heterojunction photodetectors incorporating silver triangular nanoplates (AgTNPs) were fabricated using sol–gel and spin-coating techniques. The experimental results demonstrate that the incorporation of AgTNP nanostructures significantly enhances the photoelectric conversion efficiency of the plasmonic P3HT/AgTNPs/ZnO photodetectors across both the ultraviolet and visible spectral regions. The responsivity enhancement ratio of the plasmonic devices reached its maximum under illumination at a wavelength of 525 nm. Compared with the reference P3HT/ZnO device, the responsivity values of the P3HT/AgTNPs-1/ZnO and P3HT/AgTNPs-2/ZnO devices increased by factors of 3.24 and 4.21, respectively. The optimal P3HT/AgTNPs-2/ZnO device exhibited responsivity values of 9.49, 10.80, and 10.47 mA/W under irradiation at wavelengths of 440 nm, 460 nm, and 525 nm, respectively. The mechanism of performance enhancement induced by the plasmonic AgTNPs is also discussed. This work demonstrates that embedding triangular plasmonic metal nanoplates within semiconductor heterojunctions constitutes an effective strategy for performance enhancement, providing new insights for the rational design of high-performance optoelectronic devices. Full article

Porous thin-film getters are extensively utilized in the field of MEMS vacuum packaging. Nevertheless, their effectiveness is frequently constrained by the comparatively modest effective surface area of conventional planar structures. In this work, a porous Au/Ti thin-film getter based on a three-dimensional black silicon scaffold is developed to enhance the effective surface area and improve gettering performance. The fabrication of black silicon nanostructures is achieved through an SF₆/O₂-based inductively coupled plasma (ICP) etching process, followed by the deposition of Au/Ti bilayer films by DC magnetron sputtering. The morphological evolution of the Ti film on the nanostructured substrate and the activation behavior of the Au/Ti bilayer are systematically investigated using scanning electron microscopy (SEM) and X-ray photoelectron spectroscopy (XPS). The results demonstrate that the shadowing effect during sputtering leads to the formation of a porous film with increased surface roughness and an open structure. XPS analysis demonstrates that there is a significant increase in the oxygen content on the surface at higher activation temperatures. This suggests that effective sorption capability is achieved following activation. In comparison with planar substrates, the three-dimensional black silicon scaffold has been demonstrated to promote the formation of a more open and functional structure. The results obtained from this study indicate that the proposed fabrication strategy offers a feasible and MEMS-compatible approach for the construction of porous thin-film getters, thereby enhancing their effective surface area. Full article

Nanotechnology has emerged as a key driver in radioisotope batteries, which offer unique advantages for long-term, maintenance-free energy supply in deep space exploration, medical implants, and nuclear waste utilization. This review summarizes recent progress in applying nanomaterials and nanostructures to overcome the limitations of nuclear batteries, including low energy conversion efficiency and poor stability. The main content focuses on the three primary conversion mechanisms of thermoelectric, radio-voltaic, and radio-photovoltaic batteries, discussing high-performance thermoelectric nanomaterials such as SiGe alloys, wide-bandgap semiconductors including diamond and SiC for enhanced carrier collection, and nanoscale radionuclide ources to mitigate self-absorption losses. This review further elaborates on how nanostructure regulation and interface engineering have significantly improved carrier collection efficiency and device stability. These advances have enabled notable civilian applications, such as the BV100 and “Zhulong No.1” nuclear batteries. Despite this progress, challenges remain in ensuring long-term material stability under extreme environments, maintaining performance consistency during macroscopic device integration, and addressing the high fabrication costs. The review concludes by outlining future research directions, including the development of novel nanomaterial systems, innovative nanostructure designs, scalable manufacturing processes, and enhanced device stability and safety, to further advance next-generation radioisotope batteries. Full article
