Search Results (161)

Structural colors, generated by the physical interaction of light with micro- and nanostructured architectures, have emerged as an important platform in nanophotonics owing to their high color saturation, exceptional photostability, and long-term color durability. This review provides a comprehensive overview of recent advances in structural colors and establishes a unified classification framework based on their macroscopic angular optical responses. The intrinsic angular characteristics of four fundamental color-generation mechanisms are first distinguished, providing the physical basis for classifying structural colors into iridescent and non-iridescent systems. Representative iridescent architectures, including thin films, one-dimensional (1D) to three-dimensional (3D) photonic crystals, and diffraction gratings, are systematically reviewed, together with non-iridescent strategies based on independent plasmonic and dielectric resonators, quasi-amorphous structures, and engineered metasurfaces. Strategies for enhancing structural color visibility and saturation through absorption management are further discussed, particularly for suppressing undesired broadband and multiple-scattering backgrounds. Additionally, this review systematically summarizes quantitative methodologies for evaluating structural colors, including spectral metrics, CIE 1931 and CIE1976 color spaces, CIEDE2000 color difference, quantitative angular-response metrics, spatial resolution and pixel limits, and structural-order characterization using orientation parameters and two-dimensional fast Fourier transform (2D FFT) analysis. Particular attention is given to the quantitative assessment of angular stability through wavelength shifts and perceptual color differences, while recognizing that a universally accepted numerical boundary between iridescent and non-iridescent coloration has not yet been established. Representative functional applications are also reviewed, including self-cleaning coatings, passive daytime radiative cooling, label-free chemical and gas sensing, reflectometric interference spectroscopy (RIfS), surface-enhanced Raman scattering (SERS), and anti-counterfeiting. By integrating color-generation mechanisms, angular optical responses, quantitative evaluation methods, and functional applications, this review provides a unified framework for objectively comparing structural color platforms and highlights key trade-offs among color quality, angular stability, structural precision, durability, scalability, and multifunctionality, thereby providing design guidance for next-generation optical materials and devices. Full article

Nanoplasmonic waveguides can efficiently manipulate the propagation characteristics of chiral light and hold great promise for integrated nano optics and on-chip optical information processing. Previous studies have demonstrated that gap plasmon structures composed of gold nanorod and silver nanowire can break the propagation symmetry of chiral light, thereby enabling asymmetric directional propagation. However, there remains considerable scope for enhancing the directional selectivity of these structures. In this work, we systematically investigate the mechanism of how the geometrical parameters of nanostructures regulate the directional propagation of chiral light. Based on the finite-difference time-domain method, the propagation behavior and evolution of directionality of chiral light in nanoplasmonic waveguides are analyzed in detail by changing the morphology and length of gold nanorods. The results show that the geometrically optimized nanostructures can significantly enhance the stability of directional chiral light propagation. At the same light-source position, the directionality of the gold nanorod with tips is approximately 56%, whereas that of the gold nanorod without tips remains approximately 89%. Further investigations show that structural modification of the silver nanowire or geometrical optimization of the structure can effectively reshape the local electromagnetic field distribution, enabling precise control over the propagation direction of chiral light. This work elucidates the physical mechanism underlying geometry-controlled chiral plasmonic propagation and provides a new design strategy for the structural design and performance optimization of high-performance chiral nanophotonic devices, with promising potential applications in chiral optical recognition, on-chip optical information processing, and nanoscale optical communication. Full article

Silicon carbide (SiC) is the leading wide-bandgap semiconductor material, providing mature doping and device fabrication. Additionally, SiC hosts a multitude of optically active point defects (color centers) and is relevant for many applications in quantum technologies. A crucial step towards harnessing the full potential of the SiC platform includes technologies to create color centers with defined localization and density, e.g., to facilitate their coupling to nano-photonic structures and to observe cooperative effects. Here, silicon vacancy centers and divacancies stand out, as no impurity atom is needed, and high-thermal budget annealing steps can be avoided. We characterize the effect of localized, femtosecond laser irradiation of SiC, investigating surface modifications and photoluminescence, including Raman spectroscopy and optical lifetime measurements. We employ commercial, high-purity, semi-insulating substrates and an industrial-grade laser system to explore broader applicability of the method. As a novel approach, we apply femtosecond laser irradiation to SiC substrates with an epitaxial graphene layer and find that the threshold for photoluminescence due to laser treatment is lowered. Full article

Strong chiral responses in planar dielectric metasurfaces are important for polarization-selective nanophotonic devices, but achieving large and reversible circular dichroism (CD) in simple dielectric structures remains challenging. This work proposes a symmetry-broken silicon metasurface that realizes near-infrared chiral response based on bound states in the continuum (BICs). The unit cell consists of a silicon nanoblock with two through-air grooves. The in-plane displacement of the air grooves breaks the C₂ rotational symmetry and splits the BIC-related polarization singularity into two circularly polarized points (C points) with opposite handedness. By further introducing out-of-plane tilting, one of the C points is shifted to the Г point, enabling spin-selective coupling between normally incident circularly polarized light and the quasi-BIC mode. Reversing the out-of-plane tilt switches the sign of CD, with values reaching −0.98 and 0.98, approaching the theoretical limits of ±1. Under oblique incidence, the structure can also exhibit near-limit CD responses. Finally, by introducing graphene, the structure achieves tunable circular-polarization-selective absorption, with the absorption of CD approaching the theoretical limits of ±0.5 for the coupled system. This work provides a new design idea for compact chiral nanophotonic materials by using symmetry breaking to control spin-selective quasi-BIC coupling and tunable chiral absorption. Full article

Smart manufacturing, Industry 4.0, and cyber-physical systems (CPSs) require sensing architectures capable of resolving both spatially distributed asset behavior and highly localized process states. This review examines optical fiber sensors (OFSs) and integrated photonic sensors for industrial monitoring through a deployment-oriented, multi-scale perspective. The discussion covers five major application regimes: continuous infrastructure surveillance, structural health monitoring (SHM) of load-bearing composites, dynamic condition monitoring of machinery, in situ observability in advanced manufacturing, and localized chemical or gas sensing. Extended fiber-optic networks, including distributed fiber-optic sensing (DFOS) based on Rayleigh, Raman, and Brillouin scattering, together with multiplexed fiber Bragg grating (FBG) sensors, provide passive, embeddable, and remotely interrogated monitoring for large-scale assets and harsh environments. Photonic integrated circuits (PICs) shift transduction to compact node-level devices for localized thermal, mechanical, refractive-index, absorption, vibration, and inertial measurements, while plasmonic and dielectric nanophotonic sensors extend optical monitoring toward surface-selective and chemically specific detection. Across these platforms, digital signal processing (DSP), machine learning (ML), sensor fusion, and digital-twin (DT) coupling are treated as artificial-intelligence-enabled (AI-enabled) layers for signal recovery, inverse mapping, uncertainty reduction, and predictive maintenance. The review argues that scalable industrial adoption is less limited by sensing physics than by the complete deployment chain: packaging, fiber–chip interfacing, calibration stability, interrogation robustness, and AI-enabled data interpretation. This manuscript is structured as a deployment-oriented narrative review of optical fiber and integrated photonic sensors for industrial monitoring and smart manufacturing. Full article

The design of photodetectors tailored to specific wavelengths in the mid-infrared (MIR) band serves as a foundational enabler for advancements in scientific research, industrial inspection, and environmental monitoring. Metasurfaces, composed of artificially engineered subwavelength unit cells, enable precise tailoring of light–matter interactions, achieving near-unity absorption at target wavelengths and thereby significantly boosting the sensitivity and spectral selectivity of MIR photodetectors. In this study, we developed a double-C open-loop metasurface and optimized its geometric parameters to realize high-efficiency absorption at 4 μm and 6 μm. Utilizing Te thin films fabricated via magnetron sputtering, we constructed a metasurface-enhanced mid-infrared photodetector based on Te thin films. The optimized metasurface structure enhances the light absorption of the Te thin film by a factor of eight within the target wavelength band. Ultimately, the metasurface-enhanced Te-based device achieved responsivities of 10.5 A/W and 13.7 A/W at 4 μm and 6 μm, respectively, representing enhancements of 3.6-fold and 3-fold compared to the initial Te thin-film device. This work provides a critical reference for enhancing the detection performance of infrared photodetectors at specific wavelengths through precise nanophotonic design. Full article

Metasurfaces, planar structures made on a subwavelength scale, enable state-of-the-art manipulation of light and have become a promising solution for compact optical devices. However, fabrication of these nanoscale structures relies on demanding processes, limiting their integration into diverse structures, including three-dimensional ones. In this study, we develop a manufacturing and transfer technique that renders the manipulation and deposition of metasurfaces achievable with high freedom by embedding the nanostructure into a flexible polymer matrix. A metasurface consisting of a TiO₂ nanoparticle array fabricated by nanoimprint lithography was encapsulated within a poly(methyl methacrylate) (PMMA) layer through spin-coating. The layer containing the metasurface was then detached from the original SiO₂ substrate using wet-etching, becoming a free-standing soft sheet carrying nanostructures that can be transferred onto various surfaces. After the transfer, the layer thickness was further tuned through reactive ion etching to modulate the optical response. Incident-angle-resolved transmittance exhibited no significant change in optical bands before and after transfer, confirming that the nanostructure, as well as the photonic band, was well preserved. Thickness reduction of the PMMA cladding induced a clear optical resonance shift, demonstrating controllability of the optical response. This approach provides a versatile route for the installation of metasurfaces and expands the design possibilities for nanophotonic devices. Full article

Nanophotonics, an interdisciplinary field merging nanotechnology and photonics, has enabled transformative advancements across diverse sectors, including green energy, biomedicine, and optical computing. This review comprehensively examines recent progress in nanophotonic principles and applications, highlighting key innovations in material design, device engineering, and system integration. In renewable energy, nanophotonics allows the use of light-trapping nanostructures and spectral control in perovskite solar cells, concentrating solar power systems, and thermophotovoltaics. This has significantly enhanced solar conversion efficiencies, approaching theoretical limits. In biosensing, nanophotonic platforms achieve unprecedented sensitivity in detecting biomolecules, pathogens, and pollutants, enabling real-time diagnostics and environmental monitoring. Medical applications leverage tailored light–matter interactions for precision photothermal therapy, image-guided surgery, and early disease detection. Furthermore, nanophotonics underpins next-generation optical neural networks and neuromorphic computing, offering ultrafast, energy-efficient alternatives to von Neumann architectures. Despite rapid growth, challenges in scalability, fabrication costs, and material stability persist. Future advancements will rely on novel materials, AI-driven design optimization, and multidisciplinary approaches to enable scalable, low-cost deployment. This review summarizes recent progress and highlights future trends, including novel material systems, multidisciplinary approaches, and enhanced computational capabilities, paving the way for transformative applications in this rapidly evolving field. Full article

Noble metal nanostructures provide versatile platforms for light manipulation through localized surface plasmon resonances (LSPRs). Among them, triangular silver nanoplates (AgNPTs) exhibit strong field-enhancement and spectral tunability, yet assembling them reproducibly on solids is challenging. We report a two-step functionalization strategy for constructing ordered AgNPT dimers on silica substrates, combining 3-aminopropyltriethoxysilane (APTES) anchoring with 1,4-butanedithiol bridging. AFM reveals face-to-face dimers with well-defined sub-nanometer gaps. Large-area AFM statistics collected over multiple regions (N = 80 nanoplates per condition) confirm reproducible and selective vertical dimerization. Extinction spectroscopy reveals sequential dielectric and coupling effects: thiol adsorption red-shifts the main resonance from 700 to 780 nm because of increased local refractive index and near-field damping, whereas dimerization partially restores it to ≈750 nm, consistent with plasmon hybridization within rigid ∼0.7 nm molecular gaps, where nonclassical moderation may occur but classical hybridization fully explains the observed shifts. Concomitantly, the extinction intensity doubles, following an exponential growth toward saturation during assembly. Surface-enhanced Raman scattering (SERS) measurements using 4-mercaptobenzoic acid (4-MBA) confirm a fourfold increase in the SERS enhancement factor from monolayer to bilayer, consistent with near-field coupling and hotspot formation at interplate junctions. Quantitative plasmon sensitivity analysis yields comparable results between experiments and finite-difference-time-domain simulations, confirming that the observed spectral shifts arise from near-field coupling and dielectric modulation rather than ensemble effects. This reproducible methodology enables precise tuning of NPT orientation, spacing, and optical response, providing a robust platform for enhanced sensing, SERS, and nanophotonic device engineering. Full article

Silver films are key building blocks for plasmonic and nanophotonic devices, whose optical performance and device reliability are highly sensitive to particulate contamination introduced during fabrication and operation. Herein, a non-destructive surface cleaning strategy specifically applicable to silver film systems is proposed, based on the synergistic regulation of the mechanical properties of a polymer layer and its interfacial adhesion to the silver film. Such regulation is achieved by tuning hydrogen-bond-mediated interactions within a modified poly(vinyl alcohol) (PVA) layer, enabling effective control over the locus of fracture during peeling, such that fracture preferentially occurs at the polymer/silver interface. Unlike conventional polymer-assisted cleaning methods that suffer from an inherent trade-off between bulk cohesion and interfacial adhesion, this approach decouples the two properties through molecular-level hydrogen-bond redistribution. As a result, particulate contaminants can be efficiently removed from the silver surface while preserving the structural integrity of the silver film. The proposed method achieves a particle removal efficiency of up to 98% for contaminants larger than 30 nm and can be stably applied to silver films with lateral dimensions ranging from 1 inch to 12 inches, demonstrating excellent scalability. By further adjusting the processing parameters and compositional ratios of the polymer layer, this strategy is expected to be adaptable to silver films with different thicknesses and structural configurations, providing a reliable surface cleaning solution for improving the performance and reliability of plasmonic and optoelectronic thin-film devices. Full article

Artificial intelligence (AI) has become a transformative tool in the field of molecular biosensing, enabling data-driven optimization in sensor design, signal processing, and real-time monitoring. AI promotes the discovery of biomarkers, the design of high-affinity receptors, and the rational engineering of sensing materials, thereby enhancing sensitivity, specificity, and detection accuracy. In the development of biosensors, AI-assisted strategies have accelerated the identification of novel molecular targets, guided the design of proteins and aptamers with enhanced binding performance, and optimized plasmonic and nanophotonic structures through forward prediction and inverse design frameworks. The integration of artificial intelligence has significantly enhanced the performance of various biosensing platforms, including optical, electrochemical, and microfluidic biosensors. It also enabled automatic feature extraction, noise reduction, dimensionality reduction, and multimodal data fusion, overcoming the challenges posed by complex signals, environmental interference, and device variations. These capabilities are particularly crucial for wearable molecular biosensors, as low signal strength, motion artifacts, and fluctuations in physiological conditions impose strict requirements on robustness and real-time reliability. This review systematically summarizes the latest advancements in AI-assisted molecular biosensors, highlighting representative sensing strategies and algorithms for wearable and real-time monitoring, and discusses the current challenges and future development opportunities of intelligent biosensing technologies. Full article

As nanofabrication advances toward atom-by-atom control of surface morphology, plasmonic electrodes and nanogap devices are being pushed into a regime where atomic-scale protrusions and sub-nanometer separations become accessible. In this extreme limit, classical electrodynamics becomes unreliable because it cannot capture quantum effects. To this end, we compute the optical response of metallic sub-nanometer nanogaps containing atomic-scale protrusions by employing quantum hydrodynamic theory (QHT), and benchmark the predictions against the classical local-response approximation (LRA). We revealed that atomic-scale variations in protrusion can leave the far-field scattering spectrum nearly unchanged while profoundly reshaping tnear-field nanofocusing. Upon a continuous decrease in the nanogap, QHT successfully predicts non-monotonic spectral evolution with a redshift-to-blueshift deflection point accompanied via a suppression of field enhancement, whereas LRA yields a continuous redshift and a monotonic increase in field enhancement. We further demonstrated that such an inflection point is tunable, as determined by the atomic morphology of the electrodes, which provide a theoretical foundation for the experimental observation of varied inflection points. These results provide a practical route to optically diagnose and engineer tunneling-enabled charge exchange and quantum-regulated nanofocusing in extreme plasmonic nanogaps, and offer design guidance for molecular-scale optoelectronic and nanophotonic devices. Full article

Negative refraction of nanolight (e.g., polaritons, hybrid light, and matter excitation) provides a promising building block for nanophotonics, as it paves the way for developing cutting-edge nanoscale applications, such as super-resolution and subwavelength imaging. In the visible regime, negative refraction of surface plasmon polaritons has been extensively studied in conventional plasmonic and metamaterial systems; however, the inherent metallic losses remain a challenge that hinders their practical applications. Herein, we demonstrate negative refraction of low-loss and highly confined hyperbolic plasmon polaritons (HPPs) in a lateral heterojunction of a natural hyperbolic van der Waals material, molybdenum dioxide chloride (MoOCl₂). Owing to the exotic and ray-like propagating properties of HPPs, the negative refraction-inspired superlens can easily reach into the deep subwavelength scale, with spatial confinement of 800 nm near-infrared light wavelengths to below 150 nm focal spots. By elaborately adjusting the orientation directions of two-sided MoOCl₂, the mirror-symmetric superlensing effect can be tilted, and therefore, the focal spots are tuned and steered to deviate from the vertical interfacial lines. Our results applying the concepts of in-plane negative refraction with vdW materials achieve deep subwavelength light confinement and manipulation, offering new possibilities for constructing efficient and compact nanophotonic and opto-electronic devices. Full article

Metasurface cut-off perfect absorbers (MCPAs) are of great significance in technology. Research on MCPAs is extensive, whereas that on metasurface dual-band cut-off absorbers (MDCPAs) remains relatively scarce. An MDCPA operating in the visible and near-infrared (NIR) bands is proposed. This absorber realizes dual-band cut-off perfect absorption by integrating a bottom silver (Ag) layer, a silicon nitride (Si₃N₄) layer, Ag cylinders embedded with alumina (Al₂O₃) cylinders, and Al₂O₃ fan-shaped pillars. Finite-difference time-domain (FDTD) simulation calculation indicates that the absorber achieves polarization-independent high absorption (average 0.956) in the 676 nm–872 nm band and low absorptions (averages: 0.075 and 0.019, respectively) in the 400–600 nm and 980–1400 nm bands. We also use electromagnetic multipole decomposition, which is combined with electromagnetic field diagrams, to explain the origin of the dual-band cut-off absorption. This work proposes an effective strategy for realizing a high-performance MDCPA in the visible and NIR bands. With high cut-off sharpness and absorption contrast, the proposed MDCPA exhibits significant application potential in advanced nanophotonic devices and systems. Full article

Fano resonance sensors based on metal–insulator–metal (MIM) waveguides often face the challenge of balancing high sensitivity (S) and a high figure of merit (FOM). In this work, a high-performance refractive index sensor is proposed, consisting of a straight MIM waveguide side-coupled to a novel ring–bridge–rounded square (RBS) resonator. The transmission characteristics and the formation mechanism of Fano resonance are systematically analyzed using the finite element method (FEM). The results demonstrate that the synergistic introduction of rounded square units and an internal bridge structure significantly enhances electromagnetic field localization and optimizes the coupling strength. The optimized device achieves a remarkable refractive index sensitivity of 3268 nm/RIU (refractive index unit, RIU) and a high FOM of 55.4. Furthermore, by employing ethanol as the filling medium, the proposed configuration functions as a temperature sensor, exhibiting a high linear sensitivity of 1.644 nm/°C over the range of −70 °C to 70 °C. The proposed RBS resonator holds promise for compact and high-precision nanophotonic sensing applications. Full article
