This article presents a novel method for fabricating repeatable and uniform surface-enhanced Raman scattering (SERS) substrates. The proposed method consists of two steps: (1) the fabrication of nanohole arrays using advanced femtosecond laser-induced two-photon polymerization (TPP) technology; and (2) the deposition of 9 nm thick silver nanoparticles on the nanohole arrays. The proposed nanohole arrays were optimized at the diameter, and the thickness of the silver film at two parameters. Regarding SERS substrates, a limit of detection of 10⁻¹⁰ M (rhodamine 6G) and analytical enhancement factors up to 3.5 × 10⁴ were achieved. At 1361 cm⁻¹, the relative standard deviation (RSD) of the characteristic peak was 5.5%, demonstrating a highly reproducible SERS substrate. Full article

Photodetectors with broad spectral response and high responsivity demonstrate significant potential in optoelectronic applications. This study proposes a Si/Ge avalanche photodiode featuring nanostructures that enhance light absorption. By optimizing the device epitaxial structure and these nanostructures, a wide spectral responsivity from 0.4 to 1.6 μm is achieved. The results demonstrate that introducing surface photon-trapping nanoholes and SiO₂ reflective grating nanostructures increases the average light absorptivity from 0.64 to 0.84 in the 0.4–1.1 μm range and from 0.31 to 0.56 in the 1.1–1.6 μm range. At an applied bias of 0.95 V_br-apd, the responsivity reaches 17.24 A/W at 1.31 μm and 17.6 A/W at 1.55 μm. This research provides theoretical insights for designing high-responsivity photodetectors in the visible–near-infrared broadband spectrum. Full article

Quantum dot (QD)-based single-photon emitter devices today are based on self-assembled random position nucleated QDs emitting at random wavelengths. Deterministic QD growth in position and emitter wavelength would be highly appreciated for industry-scale high-yield device manufacturing from wafers. Local droplet etching during molecular beam epitaxy is an all in situ method that allows excellent density control and predetermines the nucleation site of quantum dots. This method can produce strain-free GaAs QDs with excellent photonic and spin properties. Here, we focus on the emitter wavelength homogeneity. By wafer rotation-synchronized shutter opening time and adapted growth parameters, we grow QDs with a narrow peak emission wavelength homogeneity with no more than 1.2 nm shifts on a 45 mm diameter area and a narrow inhomogeneous ensemble broadening of only 2 nm at 4 K. The emission wavelength of these strain-free GaAs QDs is <800 nm, attractive for quantum optics experiments and quantum memory applications. We can use a similar random local droplet nucleation, nanohole drilling, and now, InAs infilling to produce QDs emitting in the telecommunication optical fiber transparency window around 1.3 µm, the so-called O-band. For this approach, we demonstrate good wavelength homogeneity and excellent density homogeneity beyond the possibilities of standard Stranski–Krastanov self-assembly. We discuss our methodology, structural and optical properties, and limitations set by our current setup capabilities. Full article

We present a novel growth technique for fabricating low-density InAs/GaAs quantum dots that emit in the telecom O-band. This method combines local droplet etching on GaAs surfaces using gallium with Stranski–Krastanov growth initiated by InAs deposition. Quantum dots nucleate directly within nanoholes, avoiding the critical layer thickness typical of standard InAs Stranski–Krastanov growth, resulting in larger, low-density quantum dots. InGaAs strain reduction layers further redshift the emission into and beyond the telecom O-band. Photoluminescence spectra show a small energy difference between ground and excited states, while capacitance-voltage spectroscopy reveal small Coulomb blockade energy. Atomic force microscopy analysis indicates that quantum dots formed within nanoholes exhibit a larger volume compared to standard quantum dots. Additionally, these nanohole nucleated quantum dots require less indium to achieve O-band emission and demonstrate comparable or even better homogeneity, as indicated by the full-width at half-maximum. This improved homogeneity, low density, and increased size make these quantum dots particularly suitable for single-photon sources in quantum communication applications. Full article

In this paper, we investigate various graphene monolayer nanomesh structures (diodes) formed only by nanoholes, with a diameter of just 20 nm and etched from the graphene layer in different shapes (such as rhombus, bow tie, rectangle, trapezoid, and triangle), and their electrical properties targeting electromagnetic energy harvesting applications. In this respect, the main parameters characterizing any nonlinear device for energy harvesting are extracted from tens of measurements performed on a single chip containing the fabricated diodes. The best nano-perforated graphene structure is the triangle nanomesh structure, which exhibits remarkable performance in terms of its characteristic parameters, e.g., a 420 Ω differential resistance for optimal impedance matching to an antenna, a high responsivity greater than 10³ V/W, and a low noise equivalent power of 847 pW/√Hz at 0 V. Full article

Extrusion-based polymer three-dimensional (3D) printing, specifically fused deposition modeling (FDM), has been garnering increasing interest from industry, as well as from the research and academic communities, due to its low cost, high speed, and process simplicity. However, bed adhesion failure remains an obstacle to diversifying the materials and expanding the industrial applications of the FDM 3D-printing process. Therefore, this study focused on an investigation of the surface treatment methods for aluminum (Al) foil and their applications to 3D printer beds to enhance the bed adhesion of a 3D-printed polymer filament. Two methods of etching with sodium hydroxide and anodization with phosphoric acid were individually used for the surface treatment of the Al foil beds and then compared with an untreated foil. The etching process removed the oxide layer from the Al foil and increased its surface roughness, while the anodizing process enhanced the amount of hydroxide functional groups and contributed to the formation of nano-holes. As a result, the surface-anodized aluminum foil exhibited a higher affinity and bonding strength with the 3D-printed polymers compared with the etched and pristine foils. Through the increase in the success rate in 3D printing with various polymers, it became evident that utilizing surface-treated Al foil as a 3D printer bed presents an economical solution to addressing bed adhesion failure. Full article

Distant metastasis is the primary cause of unsuccessful treatment in nasopharyngeal carcinoma (NPC), suggesting the crucial need to comprehend this process. A tumor related to NPC does not have flat surfaces, but consists of confined microenvironments, proteins, and surface topography. To mimic the complex microenvironment, three-dimensional platforms with microwells and connecting channels were designed and developed with a fibronectin (FN) coating or nanohole topography. The potential of the transforming growth factor-β (TGF-β) inhibitor (galunisertib) for treating NPC was also investigated using the proposed platform. Our results demonstrated an increased traversing probability of NPC43 cells through channels with an FN coating, which correlated with enhanced cell motility and dispersion. Conversely, the presence of nanohole topography patterned on the platform bottom and the TGF-β inhibitor led to a reduced cell traversing probability and decreased cell motility, likely due to the decrease in the F-actin concentration in NPC43 cells. This study highlights the significant impact of confinement levels, surface proteins, nanotopography, and the TGF-β inhibitor on the metastatic probability of cancer cells, providing valuable insights for the development of novel treatment therapies for NPC. The developed platforms proved to be useful tools for evaluating the metastatic potential of cells and are applicable for drug screening. Full article

We analyzed a process to fabricate a superhydrophilic surface on copper by forming various laser-induced periodic surface structures (LIPSS) using a Ti/sapphire femtosecond laser. For these structured surfaces, the correlation between the surface structure and the wetting characteristics was analyzed by scanning electron microscopy, atomic force microscopy, and contact angle (CA) measurement. X-ray photoelectron spectroscopy (XPS) was also employed to analyze variation of the elemental composition of the surfaces. The laser treatment produced micro/nanostructures composed of ripples whose length and width are in microscale and nanoscale, respectively. At specific conditions, the CA of a water droplet was reduced to less than 1°. The superhydrophilcity is attributed to the effect of nanoholes and nanoclusters, which consist of copper (II) oxide and copper hydroxide, having a hydrophilic effect on LIPSS. However, the pristine superhydrophilic surface spontaneously became hydrophobic after being exposed to air at room temperature for about 10 days. According to XPS analysis, the surface’s transition to hydrophobic is attributed not only to the decomposition of Cu(OH)₂ but also to the adsorption of oxygen molecules and/or airborne organic molecules containing carbon, which further influences the wettability. Full article

This study investigates the oxygen (O₂) consumption of single cells during changes in their migration direction. This is the first integration of nanotopographies with an O₂ biosensor in a platform, allowing the real-time monitoring of O₂ consumption in cells and the ability to distinguish cells migrating in the same direction from those migrating in the opposite direction. Advanced nanofabrication technologies were used to pattern nanoholes or nanopillars on grating ridges, and their effects were evaluated using fluorescence microscopy, cell migration assays, and O₂ consumption analysis. The results revealed that cells on the nanopillars over grating ridges exhibited an enhanced migration motility and more frequent directional changes. Additionally, these cells showed an increased number of protrusions and filopodia with denser F-actin areas and an increased number of dotted F-actin structures around the nanopillars. Dynamic metabolic responses were also evident, as indicated by the fluorescence intensity peaks of platinum octaethylporphyrin ketone dye, reflecting an increased O₂ consumption and higher mitochondria activities, due to the higher energy required in response to directional changes. The study emphasizes the complex interplay between O₂ consumption and cell migration directional changes, providing insights into biomaterial science and regenerative medicine. It suggests innovative designs for biomaterials that guide cell migration and metabolism, advocating nanoengineered platforms to harness the intricate relationships between cells and their microenvironments for therapeutic applications. Full article

Local droplet-etched-based GaAs quantum dots are promising candidates for high-quality single and entangled photon sources. They have excellent optical and spin properties thanks to their size, shape and nearly strain-free matrix integration. In this study, we investigate the onset of aluminum nanodroplet formation for the local droplet etching process. Using molecular beam epitaxy, we grew several local droplet-etched quantum dot samples with different arsenic beam equivalent pressures. In each sample, we varied the etch material amount using a gradient technique and filled the nanoholes with GaAs to form optically active quantum dots after overgrowth. We repeated the local droplet etching process without the filling process, enabling us to characterize surface nanoholes with atomic force microscopy and compare them with photoluminescence from the buried quantum dots. We found a linear dependency on the arsenic beam-equivalent pressures for a critical aluminum amount necessary for nanohole formation and analyzed shape, density and optical properties close to this transition. Full article

The design and optimization of plasmonic nanohole arrays (NHAs) as transducers for efficient bioanalytical sensing is a rapidly growing field of research. In this work, we present a rational method for tailoring the optical and functional properties of Au NHAs realized on planar transparent substrates. Experimental and numerical results demonstrate how the far- and near-field properties of the NHAs can be controlled and optimized for specific sensing applications, proving a valuable insight into the distribution of electric fields generated on the nanostructured metal surface and the depth of penetration into the surrounding media. Metal thickness is found to play a crucial role in determining the sensing volume, while the diameter of the nanoholes affects the localization of the electromagnetic field and the extent of the decay field. The remarkable surface and bulk refractive index sensitivities observed a rival performance of more complex geometric designs reported in the recent literature, showcasing their outstanding potential for chemo-biosensing applications. Full article

In this paper, the contact resistance of AlGaN/GaN high electron mobility transistor (HEMT) was improved by introducing nanoscale hole arrays in ohmic regions, and the DC characteristics of the conventional structure and nanohole etching structure for HEMTs were measured for comparison. Sub-10 nm nanoholes were patterned on the ohmic area surface of AlGaN using electron beam lithography and a low-temperature short-time development. Various dwell times of e-beam exposure from 5 to 30 μs were investigated and the corresponding contact resistance of the nano hole etching structure and planar structure were compared by the transmission line model (TLM) method. We observed a reduced contact resistance from 1.82 to 0.47 Ω-mm by performing a dwell time of 5 μs of exposure for nanohole formation compared to the conventional structure. Furthermore, the DC characteristics demonstrate that the maximum drain current for HEMTs was enhanced from 319 to 496 mA/mm by utilizing this optimized ohmic contact. These results show that devices with sub-10 nm nanohole ohmic contacts exhibit an improved contact resistance over the conventional structure, optimizing device performance for HEMTs, including a lower on-resistance and higher maximum drain current. Full article

Gold nanohole arrays are periodic metasurfaces that are gathering huge interest in biosensing applications. The bi-dimensional grating-like structure defines their plasmonic response, together with the corresponding mode of angular dispersion. These properties can be used to investigate the interaction processes with the fluorescence features of a properly chosen emitting molecule. By employing a custom gold nanohole array alongside a commercial organic dye, we conducted an accurate angle-resolved optical characterization resorting to fluorescence, reflectance, and transmittance spectra. The coupling between the plasmonic modes and the fluorescence features was then identified as a modification of the dye fluorescence signal in terms of both spectral redistribution and enhancement. By carefully analyzing the results, different measurement efficiencies can be identified, depending on the set-up configuration, to be properly engineered for sensitivity maximization in plasmon-enhanced fluorescence-based applications. Full article

Plasmonic arrays are grating-like structures able to couple an incoming electromagnetic field into either localized or propagating surface plasmonic modes. A triangular array of elliptical holes in a gold layer were realized resorting to displacement Talbot lithography. Scanning electron microscopy was used to evaluate the geometrical features and finite time domain simulations were performed to verify the consistency of the design. The optical response was characterized by angle-resolved reflectance and transmittance measurements. The results demonstrate the good quality and uniformity of the array. Furthermore, the study on the dependence of the optical response on both the hexagonal lattice and the elliptical hole-defined symmetry properties was conducted allowing the distinction of their effects on both the localized and propagating plasmonic modes. The results indicate that the localized component of the plasmonic modes is mainly affected by the elliptical shape, while the propagating part is influenced by the hexagonal lattice symmetry. Full article

The selection of an affordable method to fabricate plasmonic metasurfaces needs to guarantee complex control over both tunability and reproducibility of their spectral and morphological properties, making plasmonic metasurfaces suitable for integration into different sensing devices. Displacement Talbot lithography could be a valid solution thanks to the limited fabrication steps required, also providing the highly desired industrial scalability. Fabricated plasmonic metasurfaces are represented by a gold nanohole array on a glass substrate based on a triangular pattern. Scanning electron microscopy measurements have been recorded, showing the consistency of the surface features with the optimized design parameters. Reflectance and transmittance measurements have also been carried out to test the reliability and standardization of the metasurface’s optical response. Furthermore, these plasmonic metasurfaces have also been successfully tested for probing refractive index variations in a microfluidic system, paving the way for their use in sensitive, real-time, label-free, and multiplexing detection of bio-molecular events. Full article
