This paper presents a novel dual-mode memristor-based ring oscillator designed for energy-efficient, wireless biomedical signal conditioning systems. The proposed architecture leverages a compact DTMOS memristor emulator, consisting of only two transistors and one capacitor, to replace the conventional NMOS pull-down devices in a three-stage PMOS ring oscillator. This integration enables two distinct operating modes within a single compact core: a fixed-frequency mode for stable clock generation and carrier synthesis, and a programmable chirp mode for frequency-modulated signal generation. The fixed-frequency mode achieves continuous tuning from 3.142 GHz to 4.017 GHz via varactor control, with an ultra-low power consumption of only 111 µW at 4.017 GHz. The chirp mode generates linear frequency sweeps starting from 0.8 GHz, with the sweep range independently controllable through the state capacitor value and the pulse width of the control signal (SW_Chirp). Designed in a standard 0.18 µm CMOS process, the oscillator exhibits a low phase noise of −87.82 dBc/Hz at a 1 MHz offset for the three-stage configuration, improving to −94.3 dBc/Hz for the five-stage design. The overall frequency coverage spans 0.8–4.017 GHz, representing a 133.6% fractional range. The calculated figure of merit (FoM) is −169.45 dBc/Hz. Experimental validation using a discrete CD4007 prototype confirms the oscillation principle, while comprehensive simulations demonstrate robust performance across process corners and temperature variations. With its zero-static-power memristor core, wide tunability, and dual-mode reconfigurability, the proposed oscillator is ideally suited for multi-standard wireless biomedical applications, including implantable telemetry, neural stimulation, ultra-wideband (UWB) transmitters, and non-contact vital sign monitoring. Full article

Multi-system integration (e.g., high-speed rail, intercity rail, suburban rail, and metro) in regional rail transit has become an important strategy for enhancing regional travel quality. Nevertheless, optimizing line plans for such integrated networks remains a challenging task. Existing approaches are typically limited to dual-system integration and rely on pre-specified line pools, while often overlooking rolling stock heterogeneity. These limitations inevitably constrain the flexibility of stopping patterns and hinder the achievement of global cost optimality for the entire system. To address these challenges, this study proposes a comprehensive optimization framework for multi-system line plans. First, a hierarchical decoupling of the multi-system physical network is performed to identify candidate train service routes. Second, a deeply coupled network consisting of train service and passenger travel is developed. Subsequently, a multi-commodity flow model is established, incorporating critical constraints such as flexible stopping rules, rolling stock-system compatibility, and connecting line capacities. This framework integrates decisions regarding flow distribution, frequency, route design, stop patterns, and rolling stock assignment. Validated via a real-world case study using Gurobi, the results indicate that the through operation mode reduces operator costs by 20.4% and passenger costs by 6.5% compared to independent operations. This research offers a quantitative tool for developing coordinated plans that improve operator efficiency and passenger experience. Full article

This work introduces the development and performance analysis of a hybrid fractal antenna combining a Koch snowflake outer geometry with a center slot patterned as a Sierpinski rectangular carpet. The antenna is fabricated on an FR4 board (${\epsilon }_r=4.7$, $\tan \delta =0.0197$) with dimensions $40\times 60\times 0.8$ mm³. Electromagnetic simulations are performed using Ansys HFSS v15, revealing seven distinct resonances at 2.11, 3.06, 5.78, 6.94, 8.48, 9.23, and 9.56 GHz. The corresponding impedance bandwidths are 90, 37, 67, 100, 90, 130, and 220 MHz, with return losses of −14, −12, −16, −10, −30, −16, and −17 dB, and VSWR values ranging from 1.06 to 1.80. The gains at these resonances are 3.92, 8.24, 6.90, 11.66, 19.38, 16.76, and 12.06 dBi. Frequency allocation analysis indicates compatibility with UMTS/LTE (2.11 GHz), S-band 5G and radar (3.06 GHz), ISM/UNII-3 Wi-Fi and ITS (5.78 GHz), C-band satellite uplink (6.94 GHz), and X-band radar/satellite downlink (8.48–9.56 GHz). The proposed geometry demonstrates wide multi-band coverage, making it a strong candidate for integration into multi-standard communication and radar platforms requiring compact, broadband, and high-directivity performance. Full article

In light of the global energy shortage, the development of renewable energy has become increasingly vital. With China’s commitment to achieving “carbon peak and carbon neutrality,” photovoltaic power generation has emerged as a focal point in new energy development. However, DC arc faults in photovoltaic systems pose significant safety hazards, potentially leading to electrical fires. While new detection technologies for DC arc faults in photovoltaic power generation systems have advanced rapidly, the diversity of international standards—such as UL 1699 B, GB/T 39750, IEC 63027, and CGC/GF 175—limits both the construction of experimental platforms and the universality of detection technologies. Current research often relies on a single standard to establish experimental platforms, resulting in detection methods with limited applicability and an inability to validate technological effectiveness fully. To address this issue, this paper conducts an in-depth study of four international and national standards (IEC 63027; UL 1699 B, GB/T 39750, and CGC/GF 175), focusing on the discrepancies in decoupling methods, impedance parameter settings, and experimental circuit topologies, including series and parallel arc scenarios. Through comprehensive comparative analysis of multiple standards, this study integrates major international and domestic specifications to develop a multi-standard compatible experimental platform. The platform is designed to accommodate diverse topologies and parameter requirements, enabling efficient collection of arc test data and performance evaluation of arc fault detection devices. It also provides a standardized foundation for the performance testing and classification of DC arc circuit breakers in photovoltaic power generation systems. Through a comprehensive multi-standard comparative analysis, we systematically analyze the technical differences in photovoltaic DC arc detection. We construct a multi-standard compatible experimental platform by integrating mainstream international and domestic standards. This platform is designed to accommodate various topological structures and parameter requirements, facilitating the collection of arcing experimental data and assessment of the performance of arc fault detection devices. The findings from this research provide both theoretical and experimental foundations for developing unified technical guidelines for photovoltaic DC arc protection. This will aid in standardizing the development of detection devices and enhancing the electrical safety of photovoltaic systems. Ultimately, this work is significant for promoting the safe utilization of new energy within the framework of the dual carbon goals. Moving forward, it is crucial to enhance the generalization abilities of detection algorithms further and foster the integration of standards and industrial applications. Full article

As wireless systems evolve toward multiband, multifunctional convergence and high-throughput services, the demand for ultra-wideband circularly polarized (CP) antennas for multi-standard terrestrial–satellite terminals continues to grow; however, because of the dispersive nature of the three-quarter-ring phase shifter, the relative bandwidth achievable with conventional crossed-dipole antennas rarely exceeds 100%. This paper presents a compact left-hand circularly polarized (LHCP) crossed-dipole antenna that combines a cavity-backed ground, ground-slot perturbations, and parasitic patches to simultaneously broaden the impedance and axial-ratio bandwidths. The fabricated prototype achieves an impedance bandwidth (IMBW) of 0.71–3.89 GHz (138%) and a 3 dB axial-ratio bandwidth (ARBW) of 0.98–3.27 GHz (108%), while maintaining gains above 3.5 dBic across most of the frequency range. The good agreement validates the multi-technique co-design and shows that the compact architecture (0.302 λ × 0.302 λ × 0.129 λ) breaks classical crossed-dipole limits. The antenna provides a scalable building block for wideband conformal arrays in next-generation integrated GNSS–SatCom systems. Full article

Accurate acne grading is critical in optimizing therapeutic decisions yet remains challenging due to lesion ambiguity and subjective clinical assessments. This study proposes the Feature Feedback-Based Pseudo-Label Learning (FF-PLL) framework to address these limitations through three innovations: (1) an acne feature feedback (AFF) architecture with iterative pseudo-label refinement to improve the training robustness, enhance the pseudo-label quality, and increase the feature diversity; (2) all-facial skin segmentation (AFSS) to reduce background noise, enabling precise lesion feature extraction; and (3) the AcneAugment (AA) strategy to foster model generalization by introducing diverse acne lesion representations. Experiments on the ACNE04 and ACNE-ECKH benchmark datasets demonstrate the superiority of the proposed framework, achieving accuracy of 87.33% on ACNE04 and 67.50% on ACNE-ECKH. Additionally, the model attains sensitivity of 87.31%, specificity of 90.14%, and a Youden index (YI) of 77.45% on ACNE04. These advancements establish FF-PLL as a clinically viable solution for standardized acne assessment, bridging critical gaps between computational dermatology and practical healthcare needs. Full article

This paper presents the design, simulation, prototyping, and measurement results of a digitally tunable fourth order Gm-C low-pass filter (LPF) for multi-standard radio receivers. The LPF cut-off frequency can be tunned by digitally selecting the transconductance of the basic reconfigurable operational transconductance amplifiers (OTAs) that compose the circuit. Four operation modes allow for control of the OTA transconductances and, consequently, the scaling of power consumption. The filter was designed and prototyped in a 1.8 V 180 nm CMOS process. The measurement results indicate that the configurability provides a cutoff frequency of 1.90/3.56/6.07/8.15 MHz with a power consumption ranging from 9.9 to 13.1 mW. The designed filter achieves an IIP3 of 8.17 dBm for a signal bandwidth of 8.15 MHz. The performance, in terms of power dissipation, noise, and cut-off frequency, is at the same order of magnitude compared to recent related works reported in the literature. The advantages are a compact area, small sensitivity to component mismatches, and low design complexity. The proposed filter presents electrical characteristics suitable for the application in radio receivers for multi-carrier WCDMA signals. Full article

This study investigated the suitability of X-ray fluorescence (XRF) analysis for routine multi-elemental composition analysis, checking its analytical capabilities by measuring a wide array of certified reference materials of soil and plant origin. A portable XRF analyzer was used to evaluate 32 soil and 12 plant standard materials, using both the Soil and Geochem mode, with sequential beams, allowing the detection of a wide range of elements. Recovery rates were calculated by comparing XRF measurements with certified values, and their correlations were verified through the Spearman coefficient. The results demonstrated the reliability of XRF measurements for soil samples, with a large number of elements showing a good or very good recovery and strong correlations with certified values. For plant samples, XRF largely overestimated the certified values, but the strong statistically significant correlations for almost all tested elements allowed us to correct this systematic bias, using the reported median value for dividing the value obtained via XRF. The Geochem mode emerged as more reliable for a larger number of elements. It was concluded that XRF may be a suitable alternative to ICP-MS in routine multi-elemental composition analysis. Full article

In this study, we designed a wideband CMOS power amplifier to support multi-band and multi-standard wireless communications. First, an input matching technique through LC network and a wideband design technique using a low Q-factor transformer were proposed. In addition, a design technique was proposed to improve output matching using RC feedback. To verify the feasibility of the proposed design methodology for wideband CMOS power amplifiers, the designed power amplifier was fabricated using a 180 nm RFCMOS process. The size including all of the matching network and test pads was 1.38 × 0.90 mm². In addition, the effectiveness of the proposed power amplifier was verified through the measured results using modulated signals of WCDMA, LTE, and 802.11n WLAN. Full article

As water flooding continues to advance in mature oil fields, conventional well logging curve responses exhibit anomalies, particularly in deep-seated beach-bar thin-layer sand bodies. These sand bodies exhibit strong vertical and planar heterogeneity, which hinders a clear understanding of their distribution and connectivity. This paper conducts a sensitivity analysis of the lower part of the 4th member of the Shahejie Formation in fault block C26, based on core data analysis and the integration of drilling, logging, recording, and production dynamic data. Natural potential and resistivity curves are selected as the sensitive curves for identifying sand bodies. Preliminary processing of well logging curves is carried out using the “standard layer constraint and multi-standardization method comparison” principle. Employing sedimentological research methods and the principles of wavelet transformation, the well logging curves within the study area undergo extraction of both high and low frequencies. This procedure accentuates details related to thin sand bodies and responses indicative of sedimentary cyclicity. Through a thoughtful amalgamation of multiple curves, the investigation achieves a systematic fusion of natural potential curves via multi-curve frequency division fusion, employing reconstruction optimization. This method adeptly mitigates interference stemming from water-flooded layers, effectively addressing challenges such as excessive calibration and ambiguous identification of sand bodies. As a result, a comprehensive analytical approach is established for assessing the distribution and connectivity of deep-seated, beach-bar thin sand bodies influenced by water-flooded layers, providing clarity on the connectivity relationships among the sand bodies. Additionally, in combination with the results of mercury injection experiments in the water-flooded layer segments, favorable reservoir criteria for the study area are determined, providing a scientific basis for adjusting future development plans. Full article

Long-Range Wide-Area Networks (LoRaWAN) allow the transmission of data via radio link from sensors, which are potentially isolated or difficult to access, to gateways and servers that are connected to cellular networks for data processing, exchange, or relay, with low transmission power. This concept employs Long-Range (LoRa) modulation and has led to the emergence of many applications for the monitoring and tracking of objects. However, due to its characteristic of a low data rate for low-power communication, the transmission of information with LoRa technology is not suitable for the fast real-time monitoring of data. Additionally, due to its narrow bandwidth, an attempt to perform localization through the LoRa modulation technique will result in very limited accuracy because of its inability to resolve multipath problems. Thus, in this paper, we propose a multi-standard Ultra-Wide Bandwidth (UWB) and LoRa end-device that is capable of measuring location with high accuracy using UWB technology and then transmitting the location information through LoRa method to gateways and the Internet of Things Network. The results of measurements in indoor and outdoor scenarios show a UWB localization accuracy that is of sub-meter level, being between 10 and 33 cm, and a UWB range of 124 m in Line-of-Sight (LOS) and 55 m in Non-Line-of-Sight (NLOS) applications, respectively. Full article

With the development of the economy and society, energy problems have become a great concern. The heat pump-coupled thermal energy storage (TES) system is a potential form of building heating, which can improve the stability of the grid and promote the consumption of renewable energy. Phase change materials (PCMs) are widely used in the field of building heating, but there are still some problems such as unsatisfactory melting points, low thermal conductivity, phase separation, and supercooling, which limit the application of PCMs in heat pump heating systems. Therefore, it is very important to improve PCMs by a performance improvement method. This work first summarizes the classification, advantages and disadvantages of PCMs, and introduces the connection between PCMs and heat pumps. Then, a detailed summary of PCMs applied in heat pump heating systems is presented, and a comprehensive review of the performance improvement methods for PCMs, which include additives, encapsulation, and eutectic compounds, is discussed. Finally, the existing problems, solutions, and future research directions are proposed. The emphasis of the research is to clarify the influence of PCMs on heat pump performance and the effect of different performance improvement methods on PCMs, and to illustrate the future development direction for PCMs in heat pump heating technologies, including the matching of heat pumps and PCMs, multi-standard decision methods and advanced control strategies. Full article

Thus far, the adoption of hydrogen fuel cell vehicles (HCEVs) has been hampered by the lack of hydrogen fueling infrastructure. This study aimed to determine the optimal location and prioritization of hydrogen fueling stations (HFSs) in Seoul by utilizing a multi-standard decision-making approach and optimization method. HFS candidate sites were evaluated with respect to relevant laws and regulations. Key factors such as safety, economy, convenience, and demand for HCEVs were considered. Data were obtained through a survey of experts in the fields of HCEV and fuel cells, and the Analytic Hierarchy Process method was applied to prioritize candidate sites. The optimal quantity and placement of HFSs was then obtained using optimization software, based on the acceptable travel time from intersections of popular roads in Seoul. Our findings suggest that compliance with legal safety regulations is the most important factor when constructing HFSs. Furthermore, sensitivity analysis revealed that the hydrogen supply cost currently holds the same weight as other elements. The study highlights the importance of utilizing a multi-standard decision-making approach and optimization methods when determining the optimal location and prioritization of HFSs and can help develop a systematic plan for the nationwide construction of HFSs in South Korea. Full article

Devices that can morph their functions on demand provide a rich yet unexplored paradigm for the next generation of electronic devices and sensors. For example, an antenna that can morph its shape can be used to adapt communication to different wireless standards or improve wireless signal reception. We utilize temperature-sensitive shape memory alloys (SMA) to realize a shape morphing antenna (ShMoA). In the designed architecture, multiple conjoined shape memory alloy sections form the antenna. The shape morphing of this antenna is achieved through temperature control. Different temperature threshold levels are used for programming the shape. Besides its conventional use for RF applications, ShMoA can serve as a multi-level temperature sensor, analogous to thermoreceptors in an insect antenna. ShMoA essentially combines the function of temperature sensing, embedded computing for detection of threshold crossings, and radio frequency readout, all in the single construct of a shape-morphing antenna (ShMoA) without the need for any battery or peripheral electronics. The ShMoA can be employed as bio-inspired wireless temperature sensing antennae on mobile robotic flies, insects, drones and other robots. It can also be deployed as programmable antennas for multi-standard wireless communication. Full article

This paper proposes a stacked field-effect transistor (FET) single-pole, double-throw (SPDT) RF switch which is capable of multi-standard. Negative voltage generator (NVG), logic controller, level shifter, and RF Switch branches are integrated. A PMOS self-biased strategy is proposed to improve linearity and simplify the design of the logic controller and level shifter. In order to reduce the influence of NVG, a new charge pump (CP) is proposed, and a low pass filter (LPF) is added to stabilize bias voltages. A new layout of the switch FET is proposed to minimize the product of on-state resistance and off-state capacitance (time constant). The RF switch proposed in this paper was implemented in the 0.18 μm silicon on insulator (SOI) process. The measured results show the P1 dB of 40 dBm, and the isolation (ISO) and insert loss (IL) at 1 GHz/5 GHz of 37 dB/22 dB, and 0.36 dB/0.55 dB. The operating frequency range is DC-6 GHz. Supply current is 37uA with the supply voltage of 2.6V. Full article
