Search Results (30)

Numerical simulation has played a crucial role in modeling the behavior of natural gas hydrate (NGH). However, the existing numerical simulators worldwide have exhibited limitations in functionality, convergence, and computational efficiency. In this study, we present a novel numerical simulator, GPSFlow/Hydrate, for modeling the behavior of hydrate-bearing geologic systems and for addressing the limitations in the existing simulators. It is capable of simulating multiphase and multicomponent flow in hydrate-bearing subsurface reservoirs under ambient conditions. The simulator incorporates multiple mass components, various phases, as well as heat transfer, and sand is treated as an independent non-Newtonian flow and modeled as a Bingham fluid. The CH₄ or binary/ternary gas hydrate dissociation or formation, phase changes, and corresponding thermal effects are fully accounted for, as well as various hydrate formation and dissociation mechanisms, such as depressurization, thermal stimulation, and sand flow behavior. In terms of computation, the simulator utilizes a domain decomposition technology to achieve hybrid parallel computing through the use of distributed memory and shared memory. The verification of the GPSFlow/Hydrate simulator are evaluated through two 1D simulation cases, a sand flow simulation case, and five 3D gas production cases. A comparison of the 1D cases with various numerical simulators demonstrated the reliability of GPSFlow/Hydrate, while its application in modeling the sand flow further highlighted its capability to address the challenges of gas hydrate exploitation and its potential for broader practical use. Several successful 3D gas hydrate reservoir simulation cases, based on parameters from the Shenhu region of the South China Sea, revealed the correlation of initial hydrate saturation and reservoir condition with hydrate decomposition and gas production performance. Furthermore, multithread parallel computing achieved a 2–4-fold increase in efficiency over single-thread approaches, ensuring accurate solutions for complex physical processes and large-scale grids. Overall, the development of GPSFlow/Hydrate constitutes a significant scientific contribution to understanding gas hydrate formation and decomposition mechanisms, as well as to advancing multicomponent flow migration modeling and gas hydrate resource development. Full article

This study proposes a MPL (microporous layer)–GDL (gas diffusion layer) microstructure reconstruction method based on a novel random reconstruction algorithm. Then the Shan–Chen multi-component and multi-phase lattice Boltzmann method (SC-LBM) is used to systematically describe the influence of different contact angle distributions on the drainage characteristics of the GDL of proton exchange membrane fuel cells (PEMFCs). Meanwhile, the breakthrough time of liquid water, steady-state time, and liquid water saturation are compared. The results show that with the increase in contact angle, the time for the first droplet breakthrough and the steady-state time are significantly shortened, and the saturation of liquid water gradually decreases at the steady state, indicating that increasing hydrophobicity can effectively improve the drainage capacity of the GDL. Several double-gradient and three-gradient contact angle distribution schemes are studied, and it is found that the gradient structure with increasing contact angles along the direction of water flow will lead to prolonged steady-state time and elevated water saturation, which is not conducive to drainage. This study analyzes the drainage process under different wettability gradients considering aspects such as the droplet morphology evolution, flow path, and water distribution mechanism, clarifying the key role of gradient design in GDL water management. This work also provides a theoretical basis and design guidelines for wettability optimization in the GDL of PEMFCs. Full article

Efficient simulation of multiphase, multicomponent fluid flow in heterogeneous reservoirs is critical for optimizing hydrocarbon recovery. In this study, we investigate advanced linearization techniques for fully implicit compositional reservoir simulations, a problem characterized by highly nonlinear governing equations that challenge both accuracy and computational efficiency. We implement four methods—finite backward difference (FDB), finite central difference (FDC), operator-based linearization (OBL), and residual accelerated Jacobian (RAJ)—within an MPI-based parallel framework and benchmark their performance against a legacy simulator across three test cases: (i) a five-component hydrocarbon gas field with CO₂ injection, (ii) a ten-component gas field with CO₂ injection, and (iii) a ten-component gas field case without injection. Key quantitative findings include: in the five-component case, OBL achieved convergence with only 770 nonlinear iterations (compared to 841–843 for other methods) and reduced operator computation time to 9.6 of total simulation time, highlighting its speed for simpler systems; in contrast, for the more complex ten-component injection, FDB proved most robust with 706 nonlinear iterations versus 723 for RAJ, while OBL failed to converge; in noninjection scenarios, RAJ effectively captured nonlinear dynamics with comparable iteration counts but lower overall computational expense. These results demonstrate that the optimal linearization strategy is context-dependent—OBL is advantageous for simpler problems requiring rapid solutions, whereas FDB and RAJ are preferable for complex systems demanding higher accuracy. The novelty of this work lies in integrating these advanced linearization schemes into a scalable, parallel simulation framework and providing a comprehensive, quantitative comparison that extends beyond previous efforts in reservoir simulation literature. Full article

Resonance Acoustic Mixing (RAM) is an efficient mixing technique and holds significant application value in many fields, especially in the mixing of high-viscosity materials. Due to the one-time loading feature, different material structures formed during the feeding process may cause undesired irregularities in the mixing process, which is not conducive to maintaining the mixing consistency between different batches. However, in the analysis of multi-component mixtures, previous studies have often overlooked the impact of the initial material structure. This study delved into the mixing mechanism of RAM in viscous solid–liquid mixtures. By constructing a numerical model based on the Mixture model, simulations of gas–solid–liquid multiphase flows under different initial structures were conducted, and the reliability of the model was verified through experiments. The research results indicate that the mixing processes with different initial structures share similar temporal characteristics of being intense at first and then moderating, but their development trends vary. The mixing time of the structure with the solid on the upper part is shortened by about 10% compared with that of the structure with the solid on the lower part. The double-interface structure exhibits a significantly higher mixing efficiency than the single-interface structure, with the mixing time reduced by up to 41%. This study offers a theoretical basis for optimizing the parameters of resonant acoustic mixing and holds significant reference value for the refined operation of resonant acoustic mixing in the future. Full article

The Embedded Discrete Fracture Model (EDFM) has emerged as a prominent piece of technology used for embedding the hydraulic behavior of rock joints in reservoir numerical models. This paper critically reviews its fundamentals, the latest developments, and opportunities for further research. The literature is extensive regarding novel algorithms attempting to reach more accurate and computationally effective estimates. While hydraulic fracture models seem suitable for their purposes, their assumptions might be excessively simplistic and unrealistic when assessing naturally fractured reservoirs. The paper begins by examining fractures as physical characteristics and the key mechanisms to be considered when integrating them into numerical flow simulators. The use of the EDFM technique shows promise for simulating capillary continuity and buoyancy effects in multiphase and multicomponent cases. However, there are significant limitations that hinder its widespread field-scale adoption for reservoir performance evaluation. In this regard, the lack of public-domain realistic benchmarks to validate and compare the potential of each method reinforces the difficulties of performing broader applications of the EDFM techniques in large-scale models. Full article

Advancing the modeling of evaporation and salt precipitation is essential in CO₂ storage processes in aquifers. OpenFOAM provides a platform for computational fluid dynamics (CFD) modeling with its open-source C++ object-oriented architecture that can especially be used in the development of fluid flow models in porous media. Some OpenFOAM packages have been developed in this area, and their codes are available for use. Despite this, the existing OpenFOAM literature does not include a model that incorporates multicomponent interactions in multi-phase flow systems, referred to as compositional modeling, at the Darcy scale. This existing gap is addressed in this paper, where a new simple model in OpenFOAM is introduced that aims to model the interaction of CO₂ and H₂O components in CO₂ storage processes in aquifers at the Darcy scale. The model, named compositionalIGFoam, incorporates a compositional solver by extending the impesFoam solver of the porousMultiphaseFoam package, while assuming some simplifications, to account for CO₂/water mutual dissolution, relevant to carbon capture and storage (CCS) processes in aquifers. The functionality of the compositionalIGFoam solver was assessed by showcasing its ability to reproduce the outcomes of existing examples. In addition to that, the process of gas injection into a water-saturated core sample was simulated using the developed model to mimic CO₂ injection into aquifers. The CMG-GEM commercial compositional simulator was used to compare its results with the coreflood model of this study. Phenomenal agreement was achieved with the GEM model, showing only 1.8% and 0.4% error for both components. This confirms the accuracy and reliability of the developed model. In conclusion, this study enhances the state of the art in porous media modeling using OpenFOAM 10, providing a valuable tool for examining fluid interactions in subsurface environments, especially within the context of CCS processes. Full article

In recent years, CO₂ flooding has become an important technical measure for oil and gas field enterprises to further improve oil and gas recovery and achieve the goal of “dual carbon”. It is also one of the concrete application forms of CCUS. Numerical simulation based on CO₂-EOR plays an indispensable role in the study of the mechanism of CO₂ flooding and buried percolation, allowing for technical indicators to be selected and EOR/EGR prediction to be improved for reservoir engineers. This paper discusses the numerical simulation techniques related to CO₂ flooding and storage, including mathematical models and solving algorithms. A multiphase and multicomponent mathematical model is developed to describe the flow mechanism of hydrocarbon components–CO₂–water underground and to simulate the phase diagram of the components. The two-phase P-T flash calculation with SSI (+DEM) and the Newton method is adopted to obtain the gas–liquid phase equilibrium parameters. The extreme value judgment of the TPD function is used to form the phase stability test and miscibility identification model. A tailor-made multistage preconditioner is built to solve the linear equation of the strong-coupled, multiphase, multicomponent reservoir simulation, which includes the variables of pressure, saturation, and composition. The multistage preconditioner improves the computational efficiency significantly. A numerical simulation of CO₂ injection in a carbonate reservoir in the Middle East shows that it is effective for researching the recovery factor and storage quantity of CO₂ flooding based on the above numerical simulation techniques. Full article

Cavitation resulting from underwater explosions in compressible multiphase or multicomponent flows presents significant challenges due to the dynamic nature of shock–cavitation–structure interactions, as well as the complex and discontinuous nature of the involved interfaces. Achieving accurate resolution of interfaces between different phases or components, in the presence of shocks, cavitating regions, and structural interactions, is crucial for modeling such problems. Furthermore, pressure convergence in simulations involving shock–cavitation–structure interactions requires accurate algorithms. In this research paper, we employ the diffuse interface method, also known as the interface-capturing scheme, to investigate cavitation in various underwater explosion test cases near different surfaces: a free surface and a rigid surface. The simulations are conducted using the unstructured compressible Navier–Stokes (UCNS3D) finite-volume framework employing central-weighted essentially non-oscillatory (CWENO) reconstruction schemes, utilizing the five-equation diffuse interface family of methods. Quantitative comparisons are made between the performance of both models. Additionally, we examine the effects of cavitation as a secondary loading source on structures, and evaluate the ability of the CWENO schemes to accurately capture and resolve material interfaces between fluids with minimal numerical dissipation or smearing. The results are compared with existing high-order methods and experimental data, where possible, to demonstrate the robustness of the CWENO schemes in simulating cavitation bubble dynamics, as well as their limitations within the current implementation of interface capturing. Full article

Flash evaporation processes are widely used in petroleum, food, chemical, power, and other industries to separate products or extract heat. The liquid is often entrained by non-condensing gas components. This study develops a multiphase, multicomponent, and pressure-driven phase-change-coupled model to numerically study water flash evaporation with non-condensing CO₂. The model includes the mass, momentum, energy, volume of fluid (VOF), species transport, turbulence (RNG k-ε), modified phase-change Lee, and non-condensing CO₂ release governing equations. The steam generation rate and mechanism for pure water and different concentrations of CO₂ are considered. The results show that the numerical model can accurately predict the flash evaporation process and has high accuracy compared with the experimental data. Both the dissolved and entrained CO₂ that are released can severely disturb the flow field, leading to an increase in the steam generation rate. Under a 1–10% volume concentration of dissolved CO₂ and 0.0661–0.1688% mass concentration of entrained CO₂, the maximum increase ratio of steam generation can reach 20%. Full article

The regularities of microstructure formation in samples of multiphase composites obtained by additive electron beam manufacturing on the basis of aluminum alloy ER4043 and nickel superalloy Udimet-500 have been studied. The results of the structure study show that a multicomponent structure is formed in the samples with the presence of Cr₂₃C₆ carbides, solid solutions based on aluminum -Al or silicon -Si, eutectics along the boundaries of dendrites, intermetallic phases Al₃Ni, AlNi₃, Al₇5Co₂₂Ni₃, and Al₅Co, as well as carbides of complex composition AlCCr, Al₈SiC₇, of a different morphology. The formation of a number of intermetallic phases present in local areas of the samples was also distinguished. A large amount of solid phases leads to the formation of a material with high hardness and low ductility. The fracture of composite specimens under tension and compression is brittle, without revealing the stage of plastic flow. Tensile strength values are significantly reduced from the initial 142–164 MPa to 55–123 MPa. In compression, the tensile strength values increase to 490–570 MPa and 905–1200 MPa with the introduction of 5% and 10% nickel superalloy, respectively. An increase in the hardness and compressive strength of the surface layers results in an increase in the wear resistance of the specimens and a decrease in the coefficient of friction. Full article

The interfacial instability of a complex fluid in a multiphase flow system is ubiquitous in both nature and industry. We experimentally investigated the spreading and interfacial instability dynamics of a binary droplet (a water and 2-propanol (IPA) mixture) on an immiscible (sunflower oil) pool. For droplets of 40 wt% IPA solution on sunflower oil, fingering instability occurred at the spreading liquid front. To reveal the interfacial characteristics of the spreading and fingering processes, we analyzed the interplay among the speed, diameter, and number of fingers on the spreading front. Based on our observations, the finger length, wavelength between the fingers, head length, and neck length were quantified. Our experimental results clearly demonstrate that fingering instability can be driven by the capillary effect for a liquid–liquid system as well as the Plateau–Rayleigh instability. We hope that our results will inspire further experimental and numerical investigations to provide deeper insights into the interfacial dynamics of multicomponent droplets in a liquid pool. Full article

The evaporation characteristics of n-decane-based bi-component or multi-component droplets have been veiled for application in advanced combustion. This paper proposes to experimentally investigate the evaporation of n-decane/ethanol bi-component droplets settled in the convective hot air, and numerically simulate the key parameters affecting the evaporation charactersitics. It was found that the evaporation behavior was interactively affected by the mass fraction of ethanol and the ambient temperature. For mono-component n-decane droplets, the evaporation process included the transient heating (non-isothermal) and steady evaporation (isothermal) stages. In the isothermal stage, the evaporation rate followed d²-law. The evaporation rate constant linearly increased as the ambient temperature enhanced (573~873 K). For n-decane/ethanol bi-component droplets, at low mass fractions (≤0.2), the isothermal evaporation processes were steady due to the good miscibility between n-decane and ethanol, like mono-component n-decane, whereas at high mass fractions (≥0.4), the evaporation process experienced ultrashort heating and fluctuating evaporation stages. During the fluctuating evaporation, the bubbles formed inside the bi-component droplets and expanded, resulting in the occurrence of the microspray (secondary atomization) and the microexplosion. The evaporation rate constant of bi-component droplets increased as the ambient temperature enhanced, and showed a “V-shaped” trend with the increase of the mass fraction, and the evaporation rate constant was the smallest at 0.4. The evaporation rate constants based on the numerical simulation by using the multiphase flow model and Lee model showed reasonable agreement with the experimental ones, suggesting a potential of application in practical engineering. Full article

Liquid foams exist in a wide variety of chemical and industrial processes, and they can contaminate the end-product and cause time and economical losses. Understanding and simulating foam is not a straightforward task, due to the highly dispersed time and length scales where the physical phenomena occur. Surfactants’ or proteins’ length scales are far beyond the capability of macroscopic and even mesoscopic numerical fluid solvers, yet the macroscales are still required to be resolved. Meanwhile, the lattice Boltzmann method (LBM) has gained much attention and success as a mesoscopic approach which can deal with complex multiphase multicomponent systems. The aim of this study is to implement LBM to simulate liquid foams while considering the accompanying thermal effects. A coupled multiphase multicomponent thermal flow model and its selected add-ons from the literature are tuned and explained, limitations and future suggestions are fairly discussed. Validations and a final study case are shown as an example for the proposed model and its applicability in thermal liquid foams. Finally, a delicate treatment to back couple the effect of temperature on the surface tension is proposed, hence considering one aspect of the Marangoni effect. Initial results show promising behavior, which can be material for future investigations. Full article

This work presents the numerical modeling of a droplet’s sessile and dynamic behavior on a grooved surface. A droplet is placed on horizontal and vertical sliding conditions to observe its behavior under wettable and non-wettable conditions. The numerical analysis uses the multicomponent multiphase Shan-Chen Lattice Boltzmann Model (SC-LBM). The Cassie–Baxter and Wenzel states are reproduced for the sessile condition, and the enhancement of the contact angle is appreciated under the action of the grooved-ridged horizontal surface. The sliding droplet is analyzed through the Bond number by varying the ratio between the body force and the surface tension number. For Cassie–Baxter and Wenzel wettability conditions, a critical Bond number was discovered above which the sliding droplet will continue to deform indefinitely. The numerical model proved its suitability to predict the gradual deformation of a droplet over a grooved vertical surface subject to a tangential body force until the droplet eventually reaches a sessile condition or a breakup. Full article

2D numerical modeling algorithms of multi-component, multi-phase filtration processes of mass transfer in frost-susceptible rocks using nonlinear partial differential equations are a valuable tool for problems of subsurface hydrodynamics considering the presence of free gas, free water, gas hydrates, ice formation and phase transitions. In this work, a previously developed one-dimensional numerical modeling approach is modified and 2D algorithms are formulated through means of the support-operators method (SOM) and presented for the entire area of the process extension. The SOM is used to generalize the method of finite difference for spatially irregular grids case. The approach is useful for objects where a lithological heterogeneity of rocks has a big influence on formation and accumulation of gas hydrates and therefore it allows to achieve a sufficiently good spatial approximation for numerical modeling of objects related to gas hydrates dissociation in porous media. The modeling approach presented here consistently applies the method of physical process splitting which allows to split the system into dissipative equation and hyperbolic unit. The governing variables were determined in flow areas of the hydrate equilibrium zone by applying the Gibbs phase rule. The problem of interaction of a vertical fault and horizontal formation containing gas hydrates was investigated and test calculations were done for understanding of influence of thermal effect of the fault on the formation fluid dynamic. Full article
