During the development of multi-layer tight sandstone gas reservoirs in Ordos Basin, China, it has not been easy to calculate accurately the production of each individual layer in gas wells. However, production allocation provides a vital basis for evaluating dynamic reserves and drainage areas of gas wells and remaining gas distributions of gas layers. To improve the accuracy and reliability of production allocation of gas wells, a new model was constructed based on the seepage equation, material balance equation, and pipe string pressure equation. In particular, this new model introduced the seepage equation with an elliptical boundary to accurately capture the fluid flow characteristics within a lenticular tight gas reservoir. The new model can accurately calculate the production and reservoir pressure of each individual layer in gas wells. In addition, the new model was validated and applied in the Sulige gas field, Ordos Basin. The following conclusions were drawn: First, The gas production contribution rates of pay zones based on the new model are fairly close to the measurements of the production profile logging, with errors less than 10%. Second, The overall drainage area of a gas well lies among those of each pay zone, and the total dynamic reserves of the well are close to the sum of the dynamic reserves of pay zones. Third, Higher permeability may lead to higher initial gas production of the pay zone, but the ultimate gas production contributions of pay zones are affected jointly by permeability and dynamic reserves. Finally, The new model has been successfully applied to the SZ block of the Sulige gas field, in which the fine evaluation of dynamic reserves, drainage areas, gas production, recovery factors, and remaining gas distributions of different layers was delivered, and the application results provide technical support for the future well placement and enhanced gas recovery of the block. Full article

In this study, a practical and comprehensive experimental technique has been proposed to investigate the interlayer interference characteristics in multilayer tight sandstone gas reservoirs with multi-pressure systems and different reserves. Firstly, single-layer depletion simulation experiments were conducted to measure the gas flow rate and gas extraction efficiency for each of the six layers. A series of physical simulation experiments were then conducted to monitor gas production and pressure variations in commingled multilayer production scenarios under various conditions. Finally, interlayer interference characteristics and gas extraction efficiencies and the main controlling factors were evaluated, analyzed, and identified. The interlayer pressure differential is found to be the primary factor dictating both interference and gas production, followed by initial gas production rates, and permeability variations in the order of positive significance. A higher interlayer pressure differential, a lower initial gas production rate, and a larger permeability variation result in an increase in interlayer interference and a reduction in gas production during commingled production. Increasing the number of commingled layers leads to an overall increase in gas production losses of 10.95% for two layers to 13.35% for four layers. Layers exhibiting small interlayer pressure difference are positively compatible for commingled production. Full article

During the operation of commingled production wells, inter-layer interference is a key factor affecting the recovery rate and flooding extraction efficiency. This study proposes a well deliverability equation that is characterized by a multi-parameter coupled inter-layer interference coefficient, which is applied to quantify the commingled production wells in a multi-layer reservoir. This study used principal component analysis (PCA) to study the combined effects of correlation parameters for inter-layer interference. The results show that the starting pressure gradient and the crude oil viscosity contrast have the most significant impact on inter-layer interference. Changes in these two parameters directly enhance the heterogeneity between different oil layers, thereby intensifying inter-layer interference. Additionally, the positive correlation between permeability and permeability contrast also highlights the contribution of physical property differences in the oil layers to the interference. The sensitivity analysis shows the main influencing factors of inter-layer interference in commingled production wells. providing references for subsequent improvements and optimization of the exploitation schemes and adjustments in reservoir management measures. The results not only enhance the understanding of the mechanisms of inter-layer interference in the exploitation of multi-layer oil reservoirs but also provide scientific evidence and technical support for oilfield development. Full article

Increasing oil production is crucial for multilayer co-production. When there are significant differences in the permeability of each layer, an interlayer contradiction arises that can impact the recovery efficiency. After a number of tests and the establishment of a mathematical model, the effects of permeability contrast on oil production for water flooding were revealed. In the meantime, the developed mathematical model was solved using the Buckley–Lever seepage equation. Ultimately, the accuracy of the established model was confirmed by comparing the simulated outcomes of the mathematical model with the experimental results. The findings indicate that when permeability contrast increases, the production ratio of the high-permeability layer will improve. This is primarily due to the low-permeability layer’s production contribution rate decreasing. The accuracy of the established model is ensured by an error of less than 5% between the results of the experiment and the simulation. When the permeability contrast is less than three, the low-permeability layer can be effectively used for three-layer commingled production. However, when the permeability contrast exceeds six, the production coefficient of the low-permeability layer will be less than 5%, which has a significant impact on the layer’s development. Full article

Multilayer commingled production is a widely used development method to improve the production capacity of gas reservoirs. However, there is currently limited research on the gas production characteristics of multilayer commingled production in hydrate reservoirs with underlying gas. The objective of this study was to analyze the characteristics of multilayer commingled production in order to determine suitable hydrate reservoirs for such a development method. Firstly, we employed analytical solutions to the equations of fluid flow in porous media to determine the factors affecting the production capacity. Then, by employing numerical simulation and depressurization methods, the rates of gas production and gas release from hydrate dissociation in a single production well were estimated. Additionally, the production capacity ratio of multilayer commingled production and separated-layer production was proposed. The influence of different reservoir characteristics on multilayer commingled production yield was determined and plotted. When there is an interlayer between hydrates and the underlying gas, the formation pressure ratio is the decisive factor affecting the multilayer commingled production yield. When there is no interlayer, the multilayer commingled production rate will increase with an increase in the permeability ratio, hydrate saturation, and underlying gas saturation. This study provides a theoretical foundation for predicting the production capacity of hydrate reservoirs, as well as assistance in selecting the hydrate reservoirs most suitable for multilayer commingled production. Full article

Gas drainage radius is the most important parameter for determining reasonable well spacing. However, the drainage radius of both single-layer and multi-layer commingled gas production wells cannot be directly obtained through reservoir well tests. In order to address the above challenge, for single-layer gas production wells in a closed constant-volume gas reservoir, a calculation model for drainage radius is derived using the modified flowing material balance method. The results indicate that the calculated error of this model is only 0.73% and much smaller than that of the flowing material balance method (5.78%), implying its high accuracy. For multi-layer commingled gas production wells, another calculation model of drainage radius is established by coupling the pseudo-steady-state production capacity equation with the material balance principle. The research results demonstrate that the novel calculation model has a maximum relative error of only 2.33% and requires only two production profile tests to rapidly calculate the drainage radius of each layer within the gas reservoir, suggesting its satisfactory simplicity, significant efficiency and high precision. The proposed calculation models of drainage radius achieve a convenient and rapid calculation for both single-layer and multi-layer commingled gas production wells, and fill the theoretical gap in efficient calculation of drainage radius for a closed constant-volume gas reservoir. Full article

Multilayered reservoirs with coexisting free gas and hydrates are primary targets for commercialization, nevertheless, the extremely low permeability greatly limits their extraction efficiency. Herein, multilayer commingled production using horizontal wells stimulated by hydraulic fracturing and thermal fluid injection was proposed to enhance productivity, and the effects of key factors on co-production performance were numerically examined, with the reservoir located in the Shenhu Area as the geological background. The results indicated that due to severe interlayer contradictions, the stimulation capabilities of using fracturing or thermal fluid injection alone were limited, in particular, the extraction of hydrates severely lagged behind. However, their combination exhibited tantalizing productivity due to strengthened inter-well interaction. Reducing the fracture spacing was more effective than increasing fracture conductivity in shortening the production cycle, and intensive fractures with adequate flow capacity were suggested for gas enhancement and water control. When the fracture spacing was reduced from 30 to 5 m and the fracture conductivity increased from 10 to 100 D·cm, the horizontal section length for commercial production (average daily gas production of 50,000 m³ and recovery ratio of 0.7) was reduced from 1758 to 146 m, which is lower than the on-site horizontal section length of 250–300 m. Therefore, the proposed development mode is promising for the commingled production of gas and hydrates. Full article

The majority of China’s multi-layer low permeability tight gas reservoirs are currently being extracted through the method of multi-layer co-production. However, due to the significant disparity in physical properties and varying degrees of pressure depletion among the production layers, elucidating the primary factors influencing the productivity contribution of each gas layer remains challenging. A multi-factor analytical model is proposed for commingled gas wells with multiple layers. An unstable model is established for the production of commingled layers, and the problem of flow distribution is addressed using the Duhamel convolution principle. The Laplace transform is subsequently employed to derive the solution in the Laplace domain, which can be inverted utilizing the Stehfest inversion algorithm to obtain a real-time domain solution. The influence of reservoir factors on the stratification contribution rate has been comprehensively analyzed, encompassing permeability, porosity, initial pressure, drainage radius, and layer thickness. The orthogonal test design was employed to conduct range analysis and variance analysis separately, yielding the primary and secondary order as well as influence weight of the five factors. The findings demonstrate that, within this gas reservoir, the discharge radius, thickness, and porosity are identified as the primary factors influencing gas well productivity. Furthermore, seven horizontal flow charts illustrating the double-layer gas reservoir and five horizontal flow charts depicting single-factor variations in the double-layer gas reservoir were constructed. These charts provide a clear visualization of the impact of each reservoir factor on stratification’s contribution rate. In contrast to previous studies, this novel approach presents a comprehensive optimization framework that ranks the influence weights of individual factors and identifies the most significant factors impacting multi-layer gas reservoirs. The presented method also serves as a foundation for the subsequent selection of multi-layer gas reservoirs, formulation of gas well stimulation measures, and efficient development. Full article

Cyclic steam stimulation (CSS) is a typical enhanced oil recovery method for heavy oil reservoirs. In this paper, a new model for the productivity of a CSS well in multilayer heavy oil reservoirs is proposed. First, for the steam volume of each formation layer, it is proposed that the total steam injection volume will be split by the formation factor (Kh) for the commingled steam injection mode. Then, based on the equivalent flow resistance principle, the productivity model can be derived. In this model, the heavy oil reservoir is composed of a cold zone, a hot water zone, and a steam zone. Next, using the energy conservation law, the equivalent heating radius can be calculated with the consideration of the steam overlay. Simultaneously, a correlation between the threshold pressure gradient (TPG) and oil mobility is also applied for the productivity formula in the cold zone and the hot water zone. Afterward, this model is validated by comparing the simulation results with the results of an actual CNOOC CSS well. A good agreement is observed, and the relative error of the cumulative oil production is about 2.20%. The sensitivity analysis results indicate that the effect of the bottom hole pressure is the most significant, followed by the TPG, and the effect of the steam overlay is relatively slight. The formation factor can affect the splitting of the steam volume in each layer; thus, the oil production rate will be impacted. The proposed mathematical model in this paper provides an effective method for the prediction of preliminary productivity of a CSS well in a multilayer heavy oil reservoir. Full article

Transient behavior analysis, including rate transient analysis (RTA) and pressure transient analysis (PTA), is a powerful tool to investigate the production performance of the vertical commingled well from long-term production data and capture the formation parameters of the multilayer reservoir from transient well testing data. Current transient behavior analysis models hardly consider the effect of vertical non-uniform boundary radii (VNBR) on transient performances (rate decline and pressure response). The VNBR may cause an obvious novel radial flow regime and rate decline type, which can easily be mistaken as a radial composite reservoir. In this paper, we present a VNBR transient behavior analysis model, the extended vertical uniform boundary radii (VUBR), to investigate the rate decline behavior and pressure response characteristics through diagnostic type curves. Results indicate that the dimensionless production integral derivative curve or pressure derivative curve can magnify the differences so that we can diagnose the outer-convex shape and size of the VNBR. Therefore, it is significant to incorporate the effects of VNBR into the transient behavior analysis models of the vertical commingled well, and the model proposed in this paper enables us to better evaluate well performance, capture formation characteristics and diagnose flow regimes based on rate/pressure transient data. Full article

Good polymer flood performance evaluation requires an understanding of polymer injectivity. Offshore reservoirs are characterized by unfavorable water–oil mobility ratios, strong heterogeneity, and multilayer production, which collectively contribute to unique challenges. Accordingly, this article presents a semi-analytical model for the evaluation of commingled and zonal injectivity in the entire development phase, which consists of primary water flooding, secondary polymer flooding, and subsequent water flooding. First, we define four flow regions with unique saturation profiles in order to accurately describe the fluid dynamic characteristics between the injector and the producer. Second, the frontal advance equation of polymer flooding is built up based on the theory of polymer–oil fractional flow. The fluid saturation distribution and the injection–production pressure difference are determined with the method of equivalent seepage resistance. Then, the zonal flow rate is obtained by considering the interlayer heterogeneity, and the semi-analytical model for calculating polymer injectivity in a multilayer reservoir is established. The laboratory experiment data verify the reliability of the proposed model. The results indicate the following. (1) The commingled injectivity decreases significantly before polymer breakthrough and increases steadily after polymer breakthrough. The change law of zonal injectivity is consistent with that of commingled injectivity. Due to the influence of interlayer heterogeneity, the quantitative indexes of the zonal flow rate and injection performance are different. The injectivity of the high-permeability layer is better than that of the low-permeability layer. (2) The higher the injection rate and the lower the polymer concentration, the better the injectivity is before polymer breakthrough. An earlier injection time, lower injection rate, larger polymer injection volume, and lower polymer concentration will improve the injectivity after polymer breakthrough. The polymer breakthrough time is a significant indicator in polymer flooding optimization. This study has provided a quick and reasonable model of injectivity evaluation for offshore multilayer reservoirs. Full article

Recently, commingling production has been widely used for the development of offshore heavy oil reservoirs with multilayers. However, the differences between layers in terms of reservoir physical properties, oil properties and pressure have always resulted in interlayer interference, which makes it more difficult to evaluate the producing degree of commingled production. Based on the Buckley–Leverett theory, this paper presents two theoretical models, a one-dimensional linear flow model and a planar radial flow model, for water-flooded multilayer reservoirs. Through the models, this paper establishes a dynamic method to evaluate seepage resistance, sweep efficiency and recovery percent and then conducts an analysis with field data. The result indicates the following: (1) the dynamic difference in seepage resistance is an important form of interlayer interference during the commingled production of an offshore multilayer reservoir; (2) the difference between commingled production and separated production is small within a certain range of permeability ratio or viscosity ratio, but separated production should be adopted when the ratio exceeds a certain value. Full article
