In this work, we present a gettering technique for multicrystalline silicon (mc-Si) by combining a nanowire structure with thermal treatment under nitrogen in an infrared lamp furnace. The silicon nanowires were elaborated using the Silver Nanoparticles Chemical Etching (Ag-NPsCE) technique. The optimal conditions for achieving effective gettering were determined based on the minority carrier lifetime (τ_eff) measurements. The results show τ_eff as a function of the gettering temperature and etching time, both before and after the removal of Ag nanoparticles using HNO₃. In both cases, the surface was identically treated with a 10% HF dip immediately prior to the carrier lifetime measurements. The highest τ_eff value, prior to Ag removal, was obtained after an etching duration of 3 min and was 6 µs at an excess carrier density Δn = 1 × 10¹⁴ cm⁻³. Moreover, τ_eff improves after silver removal. Therefore, removing Ag atoms using an aqueous HNO₃ solution is necessary to prevent this issue. Following Ag nanoparticle removal, τ_eff further increases, reaching 19 µs at a gettering temperature of 850 °C. Similarly, the electrical conductivity (ρ) and carrier mobility (μ) improve significantly after gettering, where the resistivity increases from 5.5 Ω·cm for the reference mc-Si to 1.9 Ω·cm, and the mobility rises from 122 cm²·V⁻¹·s⁻¹ to 253 cm²·V⁻¹·s⁻¹ after nanowire-based gettering at 850 °C. Overall, this method provides a scalable, practical, and cost-effective route to optimize mc-Si for high-performance photovoltaic applications. Full article

This study explored advancements in photovoltaic technologies by enhancing the electronic quality of multicrystalline silicon (mc-Si) through silicon nitride (SiN_x) and hydrogen (H₂) plasma deposition via plasma-enhanced chemical vapor deposition (PECVD). This innovative approach replaced toxic chemical wet processes with H₂ plasma and SiN_x. The key parameters of silicon solar cells, including the effective lifetime (τ_eff), diffusion length (L_diff), and iron concentration ([Fe]), were analyzed before and after this sustainable solution. The results show significant improvements, particularly in the edge region, which initially exhibited a low τ_eff and a high iron concentration. After the treatment, the τ_eff and L_diff increased to 7 μs and 210 μm, respectively, compared to 2 μs and 70 μm for the untreated mc-Si. Additionally, the [Fe] decreased significantly after the process, dropping from 60 ppt to 10 ppt in most regions. Furthermore, the treatment led to a significant decrease in reflectivity, from 25% to 8% at a wavelength of 500 nm. These findings highlight the effectiveness of the PECVD-SiN_x and H₂ plasma treatments for improving the optoelectronic performance of mc-Si, making them promising options for high-efficiency photovoltaic devices. Full article

Surface texturing is vital for enhancing light absorption and optimizing the optoelectronic properties of multicrystalline silicon (mc-Si) samples. Texturing significantly improves light absorption by minimizing reflectance and extending the effective path length of incident light. Furthermore, porous silicon treatment on textured mc-Si surfaces offers additional advantages, including enhanced carrier generation, reduced surface recombination, and improved light emission. In this study, a dual treatment combining porous silicon and texturing was employed as an effective approach to enhance the optical and optoelectronic properties of mc-Si. Both porous silicon and texturing were achieved through a chemical etching process. After these surface modifications, the morphology and structure of mc-Si were examined using Atomic Force Microscopy (AFM), Scanning Electron Microscopy (SEM), UV-Vis-IR spectroscopy, photoluminescence (PL), WCT-120 photo-conductance lifetime measurements, and Two-Internal Quantum Efficiency (IQE) analysis. The results reveal a substantial improvement in the material’s properties. The total reflectivity dropped from 35% to approximately 5%, while the effective minority carrier lifetime increased from 2 µs for bare mc-Si to 36 µs after treatment. Additionally, the two-dimensional IQE value rose from 35% for the untreated sample to 66% after treatment, representing an enhancement of around 31%. These findings highlight the potential of surface engineering techniques in optimizing mc-Si for photovoltaic applications. Full article

In this study, we investigated and compared the influence of alumina nanoparticles (Al-NPs) and silicon nitride (SiN_x) layers individually deposited on multi-crystalline silicon (mc-Si) on mc-Si’s structural, optical, and optoelectronic characteristics to improve surface quality. Alumina nanoparticle-covered multi-crystalline silicon, immersion in HF/H₂O₂/HNO₃, and porous silicon (PS) covered with a silicon nitride structure are key components in achieving high electronic quality in multi-crystalline silicon. Surface reflectivity decreased from 27% to a minimum value of 2% for alumina nanoparticles/PS and a minimum value of 5% for silicon nitride/PS at a wavelength of 930 nm. Meanwhile, the minority carrier diffusion length increased from 2 µm to 300 µm for porous silicon combined with silicon nitride and to 100 µm for alumina nanoparticles/porous silicon. Two-dimensional current mapping further demonstrated a considerable enhancement in the generated current, rising from 2.8 nA for untreated mc-Si to 34 nA for Al-NPs/PS and 66 nA for PS/SiN_x. These results confirm that the surface passivation of mc-Si using Al-NPs or PS combined with SiN_x is a promising and efficient method to improve the electrical quality of mc-Si wafers, contributing to the development of high-performance mc-Si-based solar cells. Full article

On the journey to reduce the cost of solar modules, several silicon-growing techniques have been explored to grow the wafers the cells are based on. The most utilized ones have been the multicrystalline silicon (mc-Si) and the monocrystalline ones, with monocrystalline grown by the Czochralski (Cz) technique being the current winner. Cast-mono (CM-Si) was also largely employed during the last decade, and there are several gigawatts (GWs) of modules on the field, but no data were shared on the performance of those modules. In this study, we put three small installations next to each other in the field consisting of 12 modules each, with the only difference being in the wafers technology employed: mc-Si, CM-Si, and CZ-Si. The first two systems have been manufactured with the same equipment and had their field performance closely monitored for three years, while the CZ-Si one has been monitored for 17 months. The performance data shared show that CM-Si performance on the field is better than mc-Si and is very similar to CZ-Si, with no abnormal degradation. CM-Si requires less energy than CZ-Si to be manufactured, and high efficiencies have been reported; the field performance suggests that it is a very valid technology that deserves further exploration. Full article

Photovoltaic research activities are related to material innovation that can be obtained at a comparatively low cost. Semiconductor p-type multi-crystalline Czochralskyc (CZ)-grown silicon wafers were used in this study. The effects of front surface recombination velocities and base thickness in solar cells’ quantum efficiency are theoretically calculated. The results denote that both the surface recombination velocities and the base widths significantly impact the quantum efficiency. The results are of universal technical importance in designing solar cells and their surface structures. The main goal of this paper was to confirm the validity of the above theoretical calculations; for this purpose, silicon solar cells with front-thin porous silicon and rear interdigitated contact have been produced. A good agreement was obtained between experimentally obtained solar cells’ quantum efficiency data and the theoretical results. Therefore, the quantum efficiency of the mc-Si solar cells with porous silicon and rear interdigitated contact was enhanced up to 25% at 580–1100 nm wavelength range and up to 50% at short wavelength (400–570 nm), compared to reference mc-Si solar cells. The obtained results indicate that the rear interdigitated contact maximizes the surface area of the metal contact and improves the current collection. At the same time, the porous silicon layer passivates the front surface and reduces recombination losses. Full article

Ingot multicrystalline silicon (Mc-Si) needs to be improved in quality and reduced in cost compared with Czochralski monocrystalline silicon. A uniform and dense quartz nucleation layer was obtained by the electrophoretic deposition of quartz powder on the surface of the silicon wafer. The deposited silicon wafer was annealed at 600 °C for 1 h, and one side of the silicon wafer with the quartz layer was glued to the crucible. During the growth of Mc-Si crystal, the dense quartz powder can play a nucleation role. The results show that the average lifetime of the minority carriers a of quartz-assisted silicon ingot is 7.4 μs. The overall dislocation density of an electrophoretic deposition quartz-assisted silica ingot is low, and the defect density in the middle of the silica ingot is 1.5%, which is significantly lower than that of spray quartz (3.1%) and silicon particle (4.2%). Moreover, electrophoretic deposited quartz-assisted mc-Si can obtain oriented grains, which offers a potential to apply alkaline texturing on mc-Si wafers. Full article

Most research about Light and elevated Temperature Induced Degradation (LeTID) is focused on multicrystalline silicon (mc-Si). In this work, the degradation kinetics of Czochralski-grown monocrystalline silicon (Cz-Si) induced by light at an elevated temperature were studied in detail. The lifetime evolutions over time during (1) light soaking (LS), (2) dark annealing–light soaking (DA–LS), and (3) DA–LS cycling experiments were analyzed. Ratios of the capture coefficients for the electrons and holes (k-values) were used to characterize the possible defects responsible for degradation. We found that the behavior of degradation and recovery under light soaking with or without a dark annealing treatment was mostly like boron–oxygen (BO)-related degradation but gave k-values from 19 to 25. In the DA–LS cycling experiment, the max degradation amplitudes hardly changed from the second cycle, and the k-values decreased with an increase in the cycling number. We then analyzed the possible reactions in Cz-Si and discuss the relationship between BO defects and LeTID. Full article

In a multicrystalline silicon (mc-Si) wafer, trapping effects frequently occur in the carrier lifetime measurement based on the quasi-steady-state photoconductance (QSSPC) technique. This affects the accurate measurement of the carrier lifetime of an mc-Si solar cell by causing distortions at a low injection level close to the P_max point. Therefore, it is necessary to understand this effect and effectively minimize the trapping-center density. In this study, the variations in the minority carrier-trapping effect of hydrogen at different annealing temperatures in an mc-Si were observed using QSSPC, time-of-flight secondary ion mass spectroscopy, and atom probe tomography. A trapping effect was confirmed and occurred in the grain boundary area, and the effect was reduced by hydrogen. Thus, in an mc-Si wafer, effective hydrogen passivation on the grain area and grain boundary is crucial and was experimentally proven to minimize the distortion of the carrier lifetime. Full article

The absence of an effective texturing technique for diamond-wire sawn multi-crystalline silicon (DWS mc-Si) solar cells has hindered commercial upgrading from traditional multi-wire slurry sawn silicon (MWSS mc-Si) solar cells. In this work, we present a novel method for the removal of diamond-wire-sawn marks in a multi-crystalline silicon wafer based on metal assisted chemical etching process with Cu/Ag dual elements and nano-structure rebuilding (NSR) treatment to make a uniform inverted pyramid textured structure. The temperature effect of NSR solution was systematically analyzed. It was found that the size of the inverted pyramid structure and the reflectance became larger with the increase of the NSR treatment temperature. Furthermore, the prepared unique inverted pyramid structure not only benefited light trapping, but also effectively removed the saw-marks of the wafer at the same time. The highest efficiency of 19.77% was obtained in solar cells with an inverted pyramid structure (edge length of 600 nm) fabricated by NSR treatment at 50 °C for 360 s, while its average reflectance was 16.50% at a 400–900 nm wavelength range. Full article

Over the past couple of decades, extensive research has been conducted on silicon (Si) based solar cells, whose power conversion efficiency (PCE) still has limitations because of a mismatched solar spectrum. Recently, a down-shifting effect has provided a new way to improve cell performances by converting ultraviolet (UV) photons to visible light. In this work, caesium lead bromide perovskite quantum dots (CsPbBr₃ QDs) are synthesized with a uniform size of 10 nm. Exhibiting strong absorption of near UV light and intense photoluminescence (PL) peak at 515 nm, CsPbBr₃ QDs show a potential application of the down-shifting effect. CsPbBr₃ QDs/multicrystalline silicon (mc-Si) hybrid structured solar cells are fabricated and systematically studied. Compared with mc-Si solar cells, CsPbBr₃ QDs/mc-Si solar cells have obvious improvement in external quantum efficiency (EQE) within the wavelength ranges of both 300 to 500 nm and 700 to 1100 nm, which can be attributed to the down-shifting effect and the anti-reflection property of CsPbBr₃ QDs through the formation of CsPbBr₃ QDs/mc-Si structures. Furthermore, a detailed discussion of contact resistance and interface defects is provided. As a result, the coated CsPbBr₃ QDs are optimized to be two layers and the solar cell exhibits a highest PCE of 14.52%. Full article

Life cycle metrics evolution specific to the climate zone of photovoltaic (PV) operation would give detailed insights on the environmental and economic performance. At present, vast literature is available on the PV life cycle metrics where only the output energies ignoring the degradation rate (DR) influence. In this study, the environ-economic analysis of three PV technologies, namely, multi-crystalline silicon (mc-Si), amorphous silicon (a-Si) and hetero-junction with an intrinsic thin layer (HIT) have been carried out in identical environmental conditions. The energy performance parameters and the DR rate of three PV technologies are evaluated based on the monitored real time data from the installation site in hot semi-arid climates. The assessment demonstrates that the HIT PV module technology exhibits more suitable results compared to mc-Si and a-Si PV systems in hot semi-arid climatic conditions of India. Moreover, energy metrices which includes energy payback time (EPBT), energy production factor (EPF) and life cycle conversion efficiency (LCCE) of the HIT technologies are found to be 1.0, 24.93 and 0.15 years, respectively. HIT PV system has higher potential to mitigate the CO₂ and carbon credit earned compared to mc-Si and a-Si PV system under hot semi-arid climate. However, the annualized uniform cost (UAC) for mc-Si (3.60 Rs/kWh) and a-Si (3.40 Rs/kWh) are more admissible in relation to the HIT (6.63 Rs/kWh) PV module type. We conclude that the approach of considering DR influenced life cycle metrics over the traditional approach can support to identify suitable locations for specific PV technology. Full article

Multicrystalline silicon (mc-Si) PERC (passivated emitter and rear cell) solar cells suffer from severe light-induced degradation (LID), which mainly consists of two mechanisms, namely, BO-LID (boron–oxygen complex-related LID) and LeTID (light and elevated temperature induced degradation). The impact of thermal treatment on the LID of a mc-Si PERC solar cell is investigated in this work. The LID of mc-Si PERC solar cells could be alleviated by lowering the peak temperature of thermal treatment (namely sintering), perhaps because fewer impurities present in mc-Si tended to dissolve into interstitial atoms, which have the tendency to form LeTID-related recombination active complexes. The LID could also be effectively restrained by partially replacing the boron dopant with gallium, which is ascribed to the decreased amount of boron–oxygen (B–O) complexes. This work provides a facile way to solve the severe LID problem in mc-Si PERC solar cells in mass production. Full article

Industrial Czochralski silicon (Cz-Si) photovoltaic (PV) efficiencies have routinely reached >20% with the passivated emitter rear cell (PERC) design. Nanostructuring silicon (black-Si) by dry-etching decreases surface reflectance, allows diamond saw wafering, enhances metal gettering, and may prevent power conversion efficiency degradation under light exposure. Black-Si allows a potential for >20% PERC cells using cheaper multicrystalline silicon (mc-Si) materials, although dry-etching is widely considered too expensive for industrial application. This study analyzes this economic potential by comparing costs of standard texturized Cz-Si and black mc-Si PERC cells. Manufacturing sequences are divided into steps, and costs per unit power are individually calculated for all different steps. Baseline costs for each step are calculated and a sensitivity analysis run for a theoretical 1 GW/year manufacturing plant, combining data from literature and industry. The results show an increase in the overall cell processing costs between 15.8% and 25.1% due to the combination of black-Si etching and passivation by double-sided atomic layer deposition. Despite this increase, the cost per unit power of the overall PERC cell drops by 10.8%. This is a significant cost saving and thus energy policies are reviewed to overcome challenges to accelerating deployment of black mc-Si PERC across the PV industry. Full article

In this work, the crystal growth of multi-crystalline silicon (mc-Si) during the directional solidification process was studied using the cellular automaton method. The boundary heat transfer coefficient was adjusted to get a suitable temperature field and a high-quality mc-Si ingot. Under the conditions of top adiabatic and bottom constant heat flux, the shape of the crystal-melt interface changes from concave to convex with the decrease of the heat transfer coefficient on the side boundaries. In addition, the nuclei form at the bottom boundary while columnar crystals develop into silicon melt with amzigzag-faceted interface. The higher-energy silicon grains were merged into lower energy ones. In the end, the number of silicon grains decreases with the increase of crystal length. Full article
