Search Results (20)

Solid State Transformers (SSTs) represent an emerging technology that seeks to improve upon traditional Low-Frequency Transformers (LFTs) with Medium-Frequency Transformers (MFTs) of reduced core size while incorporating modular converter structures as their input and output stages. In addition to magnetic circuit reduction, SSTs provide enhanced functionalities such as power factor correction, voltage regulation, and the capability to interface with various sources and loads. However, owing to the novelty of SSTs and the various proposed implementations, a general review would difficult to follow and might not be able to adequately analyze each aspect of SST structures. This complexity underscores the need for a new division of information and classification based on the number of conversion stages, which is the main contribution of this study. Converter functionalities are derived based on the number of stages. Utilizing these functionalities along with existing and proposed implementations, converter topologies are identified and then detailed in terms of their respective functionalities, advantages, disadvantages, and control schemes. The subsequent chapters provide a comparative analysis of the different topologies and present existing SST implementations. For this analysis, metrics such as the number of SST stages, power flow, voltage control, power quality, and component count are used. Based on the resulting analysis, single-stage SSTs are a promising solution that emphasize economy and high power density, while multi-stage SSTs are also a viable solution thanks to their ease of control and flexible design. This paper constitutes the first part of a two-part review. The second part will focus on the degrees of design freedom (such as multilevel structures/cells) and provide a generalized approach to modularity within SST systems. Full article

The Solid-State Transformer (SST) is a complex conversion device that intends to replace the Low-Frequency Transformers (LFTs) used in various power applications with Medium- or High-Frequency Transformers (MFTs/HFTs) that integrate modular converter structures as their input and output stages. The purpose is to obtain additional capabilities, such as power factor correction, voltage control, and interconnection of distributed supplies, among others, while reducing the overall volume. Given the expansive research conducted in this area in the past years, the volume of information available is large, so the main contribution of this paper is a new method of classification based on the modular construction of the SST derived from its applications and available constructive degrees of freedom. This paper can be considered the second part of a broader review in which the first part presented the fundamental converter roles and topologies. As a continuation, this paper aims to expand the definition of modularity to the entire SST structure and analyze how the converters can be combined in order to achieve the desired SST functionality. Three areas of interest are chosen: partitioning of power, phase modularity, and port configuration. The partitioning of power analyzes the fundamental switching cells and the arrangement of the converters across stages. Phase modularity details the construction of multiphase-system SSTs. Finally, the types of input/output ports, their placements, and roles are discussed. These characteristics are presented together with the applications in which they were suggested to give a broader context. Full article

This paper presents the closed-loop control of a single-switch high-gain multicell boost DC-DC converter working in a continuous conduction mode (CCM). This converter is particularly designed for applications in photovoltaic systems. One of the main advantages of the proposed converter is that it only employs one active semiconductor switch, which decreases the converter losses and cost, increases the efficiency, and simplifies the control circuit. Moreover, the multicell nature of the proposed converter offers the possibility of obtaining the required voltage gain by selecting the number of cells. State space average (SSA) modeling and small-signal analysis are used to model the switching converter power stages of the proposed converter. The parasitic series resistances of the passive elements of the converter circuit are considered to improve the accuracy of the modeling. Small-signal analysis is used to derive the open-loop transfer functions, input-to-output and control-to-output transfer functions of the proposed converter to examine its dynamic performance. The stability of the converter is analyzed to design the parameters of the voltage controller using the proposed modeling method. The experimental prototype of the proposed single-switch two-cell boost DC-DC converter was implemented. The simulation and experimental results proved the effectiveness of the proposed boost DC-DC converter under different working conditions. It has a fast dynamic response without overshoots. A comprehensive comparison between the proposed converter and previous boost converters is provided. It guarantees a required variable and constant high voltage gain with a wider duty ratio range. It compromises between the required performance, the low number of components, low voltage stress on the components, and cost-effectiveness. The experimental efficiency of the proposed converter is about 96% at a 100 W load. Full article

A multi-mode active balancing circuit based on a forward converter with resonant reset is proposed to deal with unbalanced states of lithium-ion battery packs. The balancing circuit utilizes the forward converter, enabling high-power balancing. SPST relays are selected to constitute the switching matrix, and the proposed balancing circuit completes the connection of serial battery clusters to the main circuit by controlling the SPST relays, realizing the Multi-Cell-to-Multi-Cell (MC2MC) balancing method. An “adaptive selection mode based on the state of high energy battery” balancing strategy is proposed. The proposed balancing strategy allows the proposed balancing circuit to have multiple balancing modes, flexible balancing paths, and switching between different balancing processes in real time, significantly improving the balancing speed. The inherent LC resonant reset structure of the forward converter is employed to achieve MOSFET zero-voltage switching (ZVS). To optimize the balancing performance, the circuit model is built and the balancing parameters in the circuit are analyzed. An experiment with an eight-cell lithium-ion battery pack was performed to verify the balancing effect of the proposed circuit, and comparison with a typical balancing circuit was carried out. Experimental results show that the proposed balancing circuit has a faster balancing speed. Full article

Cascaded H-bridge drives require using a significant-size capacitor on each cell to deal with the oscillatory power generated by the H-bridge inverter in the DC-link. This results in a bulky cell with reduced reliability due to the circulating second harmonic current through the DC-link capacitors. In this article, a control strategy based on a finite control set model predictive control and a proportional-resonant controller is proposed to compensate for the oscillatory power required by the H-bridge inverter through the cell’s input rectifier. With the proposed strategy, a DC-link second harmonic free operation is achieved, allowing for the possibility of reducing the capacitor size and, in consequence, the cell dimensions. The feasibility of the proposed control scheme is verified by experimental results in one cell of a cascade H-bridge inverter achieving an operation with a capacitance 141 times smaller than required by conventional control approaches for the same voltage ripple. Full article

Many methods have been developed to aid in achieving the maximum power point (MPP) generated by PV fields in order to improve photovoltaic (PV) production. The optimized steepest gradient technique (OSGM), which is used to extract the maximum power produced by a PV field coupled to a multicell series converter, is one such promising methodology. The OSGM uses the power function’s first and second derivatives to find the optimal voltage ($V_{p}v$) and converge to the voltage ($V_{r}ef$) that secures the MPP. The mathematical model was developed in Matlab/Simulink, and the MPPT algorithm’s performance was evaluated in terms of reaction time, oscillations, overshoots, and stability. The OSGM has a faster response time, fewer oscillations around the MPP, and minimal energy loss. Furthermore, the numerical calculation of the gradient and Hessian of the power function enables accurate modeling, improving the system’s precision. These findings imply that the OSGM strategy may be a more efficient way of obtaining MPP for PV fields. Future research can look into the suitability of this method for different types of PV systems, as well as ways to improve the algorithm’s performance for specific applications. Full article

Many battery equalizers have been proposed to achieve voltage consistency between series connected battery cells. Among them, the multicell-to-multicell (MC2MC) equalizers, which can directly transfer energy from consecutive more-charged cells to less-charged cells, can enable fast balancing and a high efficiency. However, due to the limitations of the equalizers, it is not possible to achieve fast equalization and reduce the size of the circuit at the same time. Therefore, a MC2MC equalizer based on a full-bridge bipolar-resonant LC Converter (FBBRLCC) is proposed in this paper, which not only implements MC2MC equalization, but also greatly reduces the circuit size by reducing the number of switches by nearly half. A mathematical model and simulation comparison with conventional equalizers are used to illustrate the high-speed equalization performance of the proposed equalizer and excellent balancing efficiency. An experimental prototype for eight cells is built to verify the performance of the proposed FBBRLCC equalizer and the balancing efficiencies in different operating modes are from 85.19% to 88.77% with the average power from 1.888 W to 14.227 W. Full article

The use of controlled power converters has been extended for high power applications, stacking off-the-shelve semiconductors, and allowing the implementation of, among others, AC drives for medium voltages of 2.3 kV to 13.8 kV. For AC drives based on power cells assembled with three-phase diode rectifiers and cascaded H-bridge inverters, a sophisticated input multipulse transformer is required to reduce the grid voltage, provide isolation among the power cells, and compensate for low-frequency current harmonics generated by the diode-based rectifiers. However, this input multipulse transformer is bulky, heavy, and expensive and must be designed according to the number of power cells, not allowing total modularity of the AC drives based on cascade H-bridges. This study proposes and evaluates a control strategy based on a finite control set-model predictive control that emulates the harmonic cancellation performed by an input multipulse transformer in a cascade H-bridge topology. Hence, the proposed method requires conventional input transformers and replaces the three-phase diode rectifiers. As a result, greater modularity than the conventional multicell converter and improved AC overall input current with a THD as low as 2% with a unitary displacement power factor are achieved. In this case, each power cell manages its own DC voltage using a nonlinear control strategy, ensuring stable system operation for passive and regenerative loads. The experimental tests demonstrated the correct performance of the proposed scheme. Full article

This paper proposes a decentralized control structure and method for a multilevel single-phase power converter using space vector pulse width modulation (SVPWM). The focus of this paper is on the decentralized control structure for the power converter cells that will exchange information with neighboring cells in order to adjust the switching vector and switching time for each cell. In this study, the switching vectors and the corresponding switching times of each cell will be self-determined based on the phase angle of two neighboring cells. Normally, SVPWM applied to the multilevel power converters need complete information about the total cells and cell’s position to build a control algorithm. Meanwhile, a decentralized space vector pulse width modulation (DSVPWM) method is proposed that can be applied to power converters with any number of cells and can be considered as a multilevel SVPWM method. In addition, the decentralized multilevel single-phase power converter has high flexibility with which it is possible to easily adjust the number of active cells, so that the output voltage can be adjusted quickly; this provides the ability to dynamically reconfigure without interrupting the power energy supply process. The proposed control structure and method are effectively verified based on simulation and experimental results. Experimental results are evaluated based on a 9-level single-phase power converter, which has an RL load with rated parameters 220 V/500 W. Full article

The rapid growth of the Information and Communications Technology (ICT) sector requires additional infrastructure, such as more micro-datacenters and telecom stations, to support the higher internet speeds and low latency requirements of 5G networks. The increased power requirements of the new ICT technologies necessitate the proposal of new power supplies, in an attempt to support the increase in energy demand and running costs. This work provides an in-depth theoretical analysis on the losses of the individual stages of commercially available PSU and proposes a new multicell PSU, the buck PFC converter, which offers a higher overall efficiency at varying load levels. The theoretical results are verified using simulation results, via a PSIM Thermal Module, and using experimental data. The results indicate that multicell structures can improve the overall PSU efficiency by 1.2% at 50% rated power and more than 2.1% at full power. Finally, taking into consideration the economic implications of this study, it is shown that the proposed multicell structure may increase the PSU costs by 10.78%, but the payback period is in the order of just 3.3 years. Full article

Multi-cell converters are widely used in medium-voltage AC drives. This equipment is based on power cells that operate with low-voltage-rating semiconductors and require an input multipulse transformer. This transformer cancels the low-frequency current harmonics generated by the three-phase diode-based rectifier. Unfortunately, this transformer is bulky, heavy, expensive, and does not extend the existing power cell (three-phase rectifier—Direct Current (DC) voltage-link—single-phase inverter) to the transformer. In this study, a harmonic cancelation method based on finite control set-model predictive control (FCS–MPC), extending the power cell’s modularity to the input transformer. On the other hand, it considers treating the two disadvantages of the FCS–MPC: High switching frequency and spread spectrum. The details were developed in theory and practice to obtain satisfactory experimental results. Full article

The cascaded connection of power converters in a DC microgrid may cause instabilities. Indeed, power converters operating as external loads exhibit constant power load (CPL) behaviors. In this study, the design of the feedback controller of a multi–cell interleaved fuel cell (FC) step–up power circuit is based on the adaptive Hamiltonian control law. It includes two integral terms to confirm that there is no steady-state error in the DC bus voltage, and to guarantee the current balancing of each input inductor current. The design confirms that the desired equilibrium point is (locally) asymptotically stable by using the Lyapunov stability proof. The control approach is validated via digital simulations and experimental tests performed with a 2500 W FC converter supplied by an FC/reformer size of 2500 W and 50 V. Full article

This paper focuses on the analysis and design of two multilevel–multicell converters (MMCs), named 3-phase 5-Level E-Type Multilevel–Multicell Rectifier (3Φ5L E-Type MMR) and 3-phase 5-Level E-Type Multilevel–Multicell Inverter (3Φ5L E-Type MMI) to be used in microgrid applications. The proposed 3-phase E-Type multilevel rectifier and inverter have each phase being accomplished by the combination of two I-Type topologies connected to the T-Type topology. The two cells of each phase of the rectifier and inverter are connected in interleaving using an intercell transformer (ICT) in order to reduce the volume of the output filter. Such an E-Type topology arrangement is expected to allow both the high efficiency and power density required for microgrid applications, as well as being capable of providing good performance in terms of quality of the voltage and current waveforms. The proposed hardware design and control interface are supported by the simulation results performed in Matlab/Simulink. The analysis has been then validated in terms of an experimental campaign performed on the converter prototype, which presented a power density of 8.4 kW/dm³ and a specific power of 3.24 kW/kg. The experimental results showed that the proposed converter can achieve a peak efficiency of 99% using only silicon power semiconductors. Full article

In a battery management system (BMS), battery equalizer is used to achieve voltage consistency between series connected battery cells. Recently, serious inconsistency has been founded to exist in retired batteries, and traditional equalizers are slow or inefficient to handle the situation. The multicell-to-multicell (MC2MC) topology, which can directly transfer energy from consecutive strong cells to consecutive weak cells, is promising to solve the problem, but its performance is limited by the existing converter. Therefore, this paper proposes an enhanced MC2MC equalizer based on a novel bipolar-resonant LC converter (BRLCC), which supports flexible and efficient operation modes with stable balancing power, can greatly improve the balancing speed without much sacrificing the efficiency. Mathematical analysis and comparison with typical equalizers are provided to illustrate its high balancing speed and good efficiency. An experimental prototype for 8 cells is built, and the balancing powers under different operation modes are from 1.426 W to 12.559 W with balancing efficiencies from 84.84% to 91.68%. Full article

This work proposes a methodology for designing power electronic converters called “Automatic Design for Manufacturing” (ADFM). This methodology proposes creating Power Converter Arrays (PCAs) using standardized converter cells. The approach is greatly inspired by the microelectronics integrated circuit design flow, power electronics building blocks, and multicell converters. To achieve the desired voltage/current specifications, the PCA conversion stage is made from the assembly of several Conversion-Standard Cells (CSCs) in series and/or parallel. The ADFM uses data-based models to simulate the behavior of a PCA with very little computational effort. These models require a special characterization approach to maximize the amount of knowledge while minimizing the amount of data. This approach consists of establishing an experiment plan to select the relevant measurements that contain the most information about the PCA technology, building an experimental setup that is capable of acquiring data automatically and using statistical learning to train models that can yield precise predictions. This work performed over 210 h of tests in nine different PCAs in order to gather data to the statistical models. The models predict the efficiency and converter temperature of several PCAs, and the accuracy is compared with real measurements. Finally, the models are employed to compare the performance of PCAs in a specific battery charging application. Full article
