The downwelling light sensor (DLS) is the industry-standard solution for generating UAV-based digital orthophoto maps (DOMs). Current mainstream DLS correction methods primarily rely on angle compensation. However, due to the temporal mismatch between the DLS sampling intervals and the exposure times of multispectral cameras, as well as external disturbances such as strong wind gusts and abrupt changes in flight attitude, DLS data often become unreliable, particularly at UAV turning points. Building upon traditional angle compensation methods, this study proposes an improved correction approach—FIM-DC (Fitting and Interpolation Model-based Data Correction)—specifically designed for data collection under clear-sky conditions and stable atmospheric illumination, with the goal of significantly enhancing the accuracy of reflectance retrieval. The method addresses three key issues: (1) field tests conducted in the Qingpu region show that FIM-DC markedly reduces the standard deviation of reflectance at tie points across multiple spectral bands and flight sessions, with the most substantial reduction from 15.07% to 0.58%; (2) it effectively mitigates inconsistencies in reflectance within image mosaics caused by anomalous DLS readings, thereby improving the uniformity of DOMs; and (3) FIM-DC accurately corrects the spectral curves of six land cover types in anomalous images, making them consistent with those from non-anomalous images. In summary, this study demonstrates that integrating FIM-DC into DLS data correction workflows for UAV-based multispectral imagery significantly enhances reflectance calculation accuracy and provides a robust solution for improving image quality under stable illumination conditions. Full article

The accurate extraction of individual tree positions is key to forest structure quantification, and Unmanned Aerial Vehicle (UAV) visible light data have become the primary data source for extracting individual tree locations. Compared to deep learning methods, classical detection methods require lower computational resources and have stronger interpretability and applicability. However, in closed-canopy forests, challenges such as crown overlap and uneven light distribution hinder extraction accuracy. To address this, the study improves the existing Revised Local Maxima (RLM) method and proposes a Multi-Source Local Maxima (MSLM) method, based on UAV visible light data, which integrates Canopy Height Models (CHMs) and Digital Orthophoto Mosaics (DOMs). Both the MSLM and RLM methods were used to extract individual tree positions from three different types of closed-canopy stands, and the extraction results of the two methods were compared. The results show that the MSLM method outperforms the RLM in terms of Accuracy Rate (85.59%), Overall Accuracy (99.09%), and F1 score (85.21%), with stable performance across different forest stand types. This demonstrates that the MSLM method can effectively overcome the challenges posed by closed-canopy stands, significantly improving extraction precision. These findings provide a cost-effective and efficient approach for forest resource monitoring and offer valuable insights for forest structure optimization and management. Full article

Mapping the terrain and the Earth’s surface can be performed through non-contact methoYes, that is correct.ds such as laser scanning. This is one of the most dynamic and effective data collection methods. This case study aims to analyze the usability of spatial data from available sources and to choose the appropriate solutions and procedures for processing the point cloud of the area of interest obtained from available web applications. The processing of the point cloud obtained by airborne laser scanning results in digital terrain models created in selected software. The study also included modeling of different types of residential development, and the results were evaluated. Different data sources may have compatibility issues, which means that the position of the same object from different spatial data databases may not be identical. To address this, deviations of the corresponding points were determined from various data sources such as Real Estate Cadaster, ZBGIS Buildings, LiDAR point cloud, orthophoto mosaic, and geodetic measurements. These deviations were analyzed according to their size and orientation, with the average deviations ranging from 0.22 to 0.34 m and standard deviations from 0.11 to 0.20 m. The Real Estate Cadaster was used as the correct basis for comparison. The area of the building was also compared, with the slightest difference being present between the Real Estate Cadaster and geodetic measurement. The difference was zero after rounding the area to whole numbers. The maximum area difference was +5 m² for ZBGIS Buildings. Full article

Chang’e-6 (CE-6) is the first sample-return mission from the lunar farside and will be launched in May of 2024. The landing area is in the south of the Apollo basin inside the South Pole Aitken basin. Statistics and analyses of impact craters in the landing area are essential to support safe landing and geologic studies. In particular, the crater size–frequency distribution information of the landing area is critical to understanding the provenance of the CE-6 lunar samples to be returned and can be used to verify and refine the lunar chronology model by combining with the radioisotope ages of the relevant samples. In this research, a digital orthophoto map (DOM) mosaic with resolution of 3 m/pixel of the CE-6 landing area was generated from the 743 Narrow Angle Camera of the Lunar Reconnaissance Orbiter Camera. Based on the DOM, craters were extracted by an automated method and checked manually. A total of 770,731 craters were extracted in the whole area of 246 km × 135 km, 511,484 craters of which were within the mare area. Systematic analyses of the crater distribution, completeness, spatial density, and depth-to-diameter ratio were conducted. Geologic model age estimation was carried out in the mare area that was divided into three geologic units according to the TiO₂ abundance. The result showed that the east part of the mare had the oldest model age of $\mu {3.27}_{-0.045}^{+0.036}$ Ga, and the middle part of the mare had the youngest model age of $\mu {2.49}_{-0.073}^{+0.072}$ Ga. The crater catalogue and the surface model age analysis results were used to support topographic and geologic analyses of the pre-selected landing area of the CE-6 mission before the launch and will contribute to further scientific researches after the lunar samples are returned to Earth. Full article

Since 2018, the authors have been working on reconstructing the exterior of the Great Pitiunt Roman fortress in 3D. This article presents the results of the visualization of the exterior and interior of the temple complex. During the study, the dimensions and plans of the site were analyzed, revealing discrepancies in various sources. To clarify the complex’s dimensions, aerial photography using UAV was conducted, and photogrammetric models, orthophoto, and digital surface models were created. The research also uncovered previously unrecorded architectural features. During the reconstruction of the temples, much attention was paid to the structural design of the buildings, connections and load distribution. Engineering calculations have been carried out for the clarification of the structural solutions. The article presents the results of a detailed reconstruction of the exterior, interior and structural features of Temple Nos. 1–4, based on preserved archaeological evidence, excavation results, contemporaneous Early Christian sites, and an analysis of the materials and technologies used at the time. The reconstruction of the mosaic floor of Temple No. 2 allowed a realistic visualization of the interior. Full article

To generate an orthophoto mosaic from a collection of aerial images, the original images are first orthorectified individually using a Digital Surface Model (DSM). Then, they are stitched together along some determined seamlines to form the orthophoto mosaic. Determining appropriate seamlines is a critical process, as it affects the visual and geometric quality of the results. The stitching process can usually be done in frame-to-frame or multi-frame modes. Although the latter is more efficient, both still involve a lot of pre-processing, such as creating individual orthophotos, image registration, and overlap extraction. This paper presents a novel coarse-to-fine approach that directly determines the seamline network without such pre-processing. Our method has been specifically applied for UAV photogrammetry projects where, due to the large number of images and the corresponding overlaps, the orthophoto mosaic generation can be very challenging and time-consuming. We established the seamlines simultaneously for all the images through a two-step process. First, a DSM was generated, and a low-resolution grid was overlayed. Then, for each grid point, an optimal image was selected. Then, the grid cells are grouped into polygons based on their corresponding optimal image. Boundaries of these polygons established our seamline network. Thereafter, to generate the orthophoto mosaic, we overlayed a higher/full resolution grid on the top of the DSM, the optimal image of each point of which was quickly identified via our low-resolution polygons. In this approach, not only seamlines were automatically generated, but also were the need for the creation, registration, and overlap extraction of individual orthophotos. Our method was systematically compared with a conventional frame-to-frame (CF) technique from different aspects, including the number of double-mapped areas, discontinuities across the seamlines network, and the amount of processing time. The outcomes revealed a 46% decrease in orthophoto generation time and a notable reduction in the number of double-mapped areas, sawtooth effects, and object discontinuities within the constructed orthophoto mosaic. Full article

Due to a lack of geographical reference information, complex panoramic camera models, and intricate distortions, including radiation, geometric, and land cover changes, it can be challenging to effectively apply the large number (800,000+) of high-resolution Corona KH-4B panoramic images from the 1960s and 1970s for surveying-related tasks. This limitation hampers their significant potential in the remote sensing of the environment, urban planning, and other applications. This study proposes a method called 2OC for the automatic and accurate orientation and orthorectification of Corona KH-4B images, which is based on generalized control information from reference images such as Google Earth orthophoto. (1) For the Corona KH-4B panoramic camera, we propose an adaptive focal length variation model that ensures accuracy and consistency. (2) We introduce a robust multi-source remote sensing image matching algorithm, which includes an accurate primary orientation estimation method, a multi-threshold matching enhancement strategy based on scale, orientation, and texture (MTE), and a model-guided matching strategy. These techniques are employed to extract high-accuracy generalized control information for Corona images with significant geometric distortions and numerous weak texture areas. (3) A time-iterative Corona panoramic digital differential correction method is proposed. The orientation and orthorectification results of KH-4B images from multiple regions, including the United States, Russia, Austria, Burkina Faso, Beijing, Chongqing, Gansu, and the Qinghai–Tibet Plateau in China, demonstrate that 2OC not only achieves automation but also attains a state-of-the-art level of generality and accuracy. Specifically, the standard deviation of the orientation is less than 2 pixels, the mosaic error of orthorectified images is approximately 1 pixel, and the standard deviation of ground checkpoints is better than 4 m. In addition, 2OC can provide a longer time series analysis of data from 1962 to 1972, benefiting various fields such as environmental remote sensing and archaeology. Full article

Mangrove forests provide valuable ecosystem services to coastal communities across tropical and subtropical regions. Current anthropogenic stressors threaten these ecosystems and urge researchers to create improved monitoring methods for better environmental management. Recent efforts that have focused on automatically quantifying the above-ground biomass using image analysis have found some success on high resolution imagery of mangrove forests that have sparse vegetation. In this study, we focus on stands of mangrove forests with dense vegetation consisting of the endemic Pelliciera rhizophorae and the more widespread Rhizophora mangle mangrove species located in the remote Utría National Park in the Colombian Pacific coast. Our developed workflow used consumer-grade Unoccupied Aerial System (UAS) imagery of the mangrove forests, from which large orthophoto mosaics and digital surface models are built. We apply convolutional neural networks (CNNs) for instance segmentation to accurately delineate (33% instance average precision) individual tree canopies for the Pelliciera rhizophorae species. We also apply CNNs for semantic segmentation to accurately identify (97% precision and 87% recall) the area coverage of the Rhizophora mangle mangrove tree species as well as the area coverage of surrounding mud and water land-cover classes. We provide a novel algorithm for merging predicted instance segmentation tiles of trees to recover tree shapes and sizes in overlapping border regions of tiles. Using the automatically segmented ground areas we interpolate their height from the digital surface model to generate a digital elevation model, significantly reducing the effort for ground pixel selection. Finally, we calculate a canopy height model from the digital surface and elevation models and combine it with the inventory of Pelliciera rhizophorae trees to derive the height of each individual mangrove tree. The resulting inventory of a mangrove forest, with individual P. rhizophorae tree height information, as well as crown shape and size descriptions, enables the use of allometric equations to calculate important monitoring metrics, such as above-ground biomass and carbon stocks. Full article

Individual tree counting (ITC) is a popular topic in the remote sensing application field. The number and planting density of trees are significant for estimating the yield and for futher planing, etc. Although existing studies have already achieved great performance on tree detection with satellite imagery, the quality is often negatively affected by clouds and heavy fog, which limits the application of high-frequency inventory. Nowadays, with ultra high spatial resolution and convenient usage, Unmanned Aerial Vehicles (UAVs) have become promising tools for obtaining statistics from plantations. However, for large scale areas, a UAV cannot capture the whole region of interest in one photo session. In this paper, a real-time orthophoto mosaicing-based tree counting framework is proposed to detect trees using sequential aerial images, which is very effective for fast detection of large areas. Firstly, to guarantee the speed and accuracy, a multi-planar assumption constrained graph optimization algorithm is proposed to estimate the camera pose and generate orthophoto mosaicing simultaneously. Secondly, to avoid time-consuming box or mask annotations, a point supervised method is designed for tree counting task, which greatly speeds up the entire workflow. We demonstrate the effectiveness of our method by performing extensive experiments on oil-palm and acacia trees. To avoid the delay between data acquisition and processing, the proposed framework algorithm is embedded into the UAV for completing tree counting tasks, which also reduces the quantity of data transmission from the UAV system to the ground station. We evaluate the proposed pipeline using sequential UAV images captured in Indonesia. The proposed pipeline achieves an F1-score of 98.2% for acacia tree detection and 96.3% for oil-palm tree detection with online orthophoto mosaicing generation. Full article

This study investigates the generation of spatially distributed roughness coefficient maps based on image analysis and the extent to which those roughness coefficient values affect the flood inundation modeling using different hydraulic/hydrodynamic modeling approaches ungauged streams. Unmanned Aerial Vehicle (UAV) images were used for the generation of high-resolution Orthophoto mosaic (1.34 cm/px) and Digital Elevation Model (DEM). Among various pixel-based and object-based image analyses (OBIA), a Grey-Level Co-occurrence Matrix (GLCM) was eventually selected to examine several texture parameters. The combination of local entropy values (OBIA method) with Maximum Likelihood Classifier (MLC; pixel-based analysis) was highlighted as a satisfactory approach (65% accuracy) to determine dominant grain classes along a stream with inhomogeneous bed composition. Spatially distributed roughness coefficient maps were generated based on the riverbed image analysis (grain size classification), the size-frequency distributions of river bed materials derived from field works (grid sampling), detailed land use data, and the usage of several empirical formulas that used for the estimation of Manning’s n values. One-dimensional (1D), two-dimensional (2D), and coupled (1D/2D) hydraulic modeling approaches were used for flood inundation modeling using specific Manning’s n roughness coefficient map scenarios. The validation of the simulated flooded area was accomplished using historical flood extent data, the Critical Success Index (CSI), and CSI penalization. The methodology was applied and demonstrated at the ungauged Xerias stream reach, Greece, and indicated that it might be applied to other Mediterranean streams with similar characteristics and flow conditions. Full article

The paper addresses an image processing problem in the field of fine arts. In particular, a deep learning-based technique to classify geometric forms of artworks, such as paintings and mosaics, is presented. We proposed and tested a convolutional neural network (CNN)-based framework that autonomously quantifies the feature map and classifies it. Convolution, pooling and dense layers are three distinct categories of levels that generate attributes from the dataset images by introducing certain specified filters. As a case study, a Roman mosaic is considered, which is digitally reconstructed by close-range photogrammetry based on standard photos. During the digital transformation from a 2D perspective view of the mosaic into an orthophoto, each photo is rectified (i.e., it is an orthogonal projection of the real photo on the plane of the mosaic). Image samples of the geometric forms, e.g., triangles, squares, circles, octagons and leaves, even if they are partially deformed, were extracted from both the original and the rectified photos and originated the dataset for testing the CNN-based approach. The proposed method has proved to be robust enough to analyze the mosaic geometric forms, with an accuracy higher than 97%. Furthermore, the performance of the proposed method was compared with standard deep learning frameworks. Due to the promising results, this method can be applied to many other pattern identification problems related to artworks. Full article

It is common practice for unmanned aerial vehicle (UAV) flight planning to target an entire area surrounding a single rooftop’s photovoltaic panels while investigating solar-powered roofs that account for only 1% of the urban roof area. It is very hard for the pre-flight route setting of the autopilot for a specific area (not for a single rooftop) to capture still images with high overlapping rates of a single rooftop’s photovoltaic panels. This causes serious unnecessary data redundancy by including the surrounding area because the UAV is unable to focus on the photovoltaic panel installed on the single rooftop. The aim of this research was to examine the suitability of a UAV video stream for building 3-D ortho-mosaics focused on a single rooftop and containing the azimuth, aspect, and tilts of photovoltaic panels. The 3-D position accuracy of the video stream-based ortho-mosaic has been shown to be similar to that of the autopilot-based ortho-photo by satisfying the mapping accuracy of the American Society for Photogrammetry and Remote Sensing (ASPRS): 3-D coordinates (0.028 m) in 1:217 mapping scale. It is anticipated that this research output could be used as a valuable reference in employing video stream-based ortho-mosaics for widely scattered single rooftop solar panels in urban settings. Full article

Bathymetry is considered an important component in marine applications as several coastal erosion monitoring and engineering projects are carried out in this field. It is traditionally acquired via shipboard echo sounding, but nowadays, multispectral satellite imagery is also commonly applied using different remote sensing-based algorithms. Satellite-Derived Bathymetry (SDB) relates the surface reflectance of shallow coastal waters to the depth of the water column. The present study shows the results of the application of Stumpf and Lyzenga algorithms to derive the bathymetry for a small area using an Unmanned Aerial Vehicle (UAV), also known as a drone, equipped with a multispectral camera acquiring images in the same WorldView-2 satellite sensor spectral bands. A hydrographic Multibeam Echosounder survey was performed in the same period in order to validate the method’s results and accuracy. The study area was approximately 0.5 km² and located in Tuscany (Italy). Because of the high percentage of water in the images, a new methodology was also implemented for producing a georeferenced orthophoto mosaic. UAV multispectral images were processed to retrieve bathymetric data for testing different band combinations and evaluating the accuracy as a function of the density and quantity of sea bottom control points. Our results indicate that UAV-Derived Bathymetry (UDB) permits an accuracy of about 20 cm to be obtained in bathymetric mapping in shallow waters, minimizing operative expenses and giving the possibility to program a coastal monitoring surveying activity. The full sea bottom coverage obtained using this methodology permits detailed Digital Elevation Models (DEMs) comparable to a Multibeam Echosounder survey, and can also be applied in very shallow waters, where the traditional hydrographic approach requires hard fieldwork and presents operational limits. Full article

Orthophoto generation is a popular topic in aerial photogrammetry and 3D reconstruction. It is generally computationally expensive with large memory consumption. Inspired by the simultaneous localization and mapping (SLAM) workflow, this paper presents an online sequential orthophoto mosaicing solution for large baseline high-resolution aerial images with high efficiency and novel precision. An appearance and spatial correlation-constrained fast low-overlap neighbor candidate query and matching strategy is used for efficient and robust global matching. Instead of estimating 3D positions of sparse mappoints, which is outlier sensitive, we propose to describe the ground reconstruction with multiple stitching planes, where parameters are reduced for fast nonconvex graph optimization. GPS information is also fused along with six degrees of freedom (6-DOF) pose estimation, which not only provides georeferenced coordinates, but also converges property and robustness. An incremental orthophoto is generated by fusing the latest images with adaptive weighted multiband algorithm, and all results are tiled with level of detail (LoD) support for efficient rendering and further disk cache for reducing memory usages. Public datasets are evaluated by comparing state-of-the-art software. Results show that our system outputs orthophoto with novel efficiency, quality, and robustness in real-time. An android commercial application is developed for online stitching with DJIdrones, considering the excellent performance of our algorithm. Full article

In producing orthophoto mosaic in a large area from spaceborne synthetic aperture radar (SAR) images, SAR image matching from adjacent orbits is a technical difficulty due to the speckle noise and different imaging mechanism between azimuth and range direction. In this paper, an area-based method, SAR-Moravec, is proposed for SAR orthophoto matching from adjacent orbits in a large area. Compared with the classical area-based Moravec, the template of SAR-Moravec is characterized by more directions for speckle noise restraint and a main direction consistent with the azimuth. In order to get evenly distributed matching points with high accuracy, the grid control mechanism and Gaussian pyramid from coarse to fine are introduced in matching. The whole process contains three steps. First, the pyramid images are constructed by the down-sampling process. Second, under grid control, the feature points are evenly extracted by the modified template. Third, the transformation model is iteratively calculated from the first to the last layer of the pyramid. After the matching process layer-by-layer, the final matching points and transformation model can be obtained. In the experiments, we compare the SAR-Moravec with three widely used methods, including the Moravec, the SAR-scale invariant feature transform (SAR-SIFT), and the SAR-features from an accelerated segment test (SAR-FAST). The results indicate that the proposed method has the best global matching accuracy among these methods and the matching efficiency is better than SAR-SIFT and SAR-FAST methods in large area. Full article
