Search Results (41)

Search Parameters:
Keywords = mobile terminal antenna

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
20 pages, 2352 KiB
Article
Three-Dimensional Physics-Based Channel Modeling for Fluid Antenna System-Assisted Air–Ground Communications by Reconfigurable Intelligent Surfaces
by Yuran Jiang and Xiao Chen
Electronics 2025, 14(15), 2990; https://doi.org/10.3390/electronics14152990 - 27 Jul 2025
Viewed by 205
Abstract
Reconfigurable intelligent surfaces (RISs), recognized as one of the most promising key technologies for sixth-generation (6G) mobile communications, are characterized by their minimal energy expenditure, cost-effectiveness, and straightforward implementation. In this study, we develop a novel communication channel model that integrates RIS-enabled base [...] Read more.
Reconfigurable intelligent surfaces (RISs), recognized as one of the most promising key technologies for sixth-generation (6G) mobile communications, are characterized by their minimal energy expenditure, cost-effectiveness, and straightforward implementation. In this study, we develop a novel communication channel model that integrates RIS-enabled base stations with unmanned ground vehicles. To enhance the system’s adaptability, we implement a fluid antenna system (FAS) at the unmanned ground vehicle (UGV) terminal. This innovative model demonstrates exceptional versatility across various wireless communication scenarios through the strategic adjustment of active ports. The inherent dynamic reconfigurability of the FAS provides superior flexibility and adaptability in air-to-ground communication environments. In the paper, we derive and study key performance characteristics like the autocorrelation function (ACF), validating the model’s effectiveness. The results demonstrate that the RIS-FAS collaborative scheme significantly enhances channel reliability while effectively addressing critical challenges in 6G networks, including signal blockage and spatial constraints in mobile terminals. Full article
Show Figures

Figure 1

21 pages, 4628 KiB
Article
Design and Performance Evaluation of a Sub-6 GHz Multi-Port Coupled Antenna for 5G NR Mobile Applications
by Cheol Yoon, Yunsub Lee, Wonmo Seong and Woosu Kim
Appl. Sci. 2025, 15(14), 7804; https://doi.org/10.3390/app15147804 - 11 Jul 2025
Viewed by 289
Abstract
This paper describes a compact multi-port sub-6 GHz multiple-input multiple-output (MIMO) antenna system tailored for 5G NR mobile terminals operating in the n77 (3.3–4.2 GHz), n78 (3.3–3.8 GHz), and n79 (4.4–5.0 GHz) frequency bands. The proposed design leverages a shared coupling approach that [...] Read more.
This paper describes a compact multi-port sub-6 GHz multiple-input multiple-output (MIMO) antenna system tailored for 5G NR mobile terminals operating in the n77 (3.3–4.2 GHz), n78 (3.3–3.8 GHz), and n79 (4.4–5.0 GHz) frequency bands. The proposed design leverages a shared coupling approach that exploits the smartphone metal frame as the radiating element, facilitating efficient integration within the spatial constraints of modern mobile devices. A two-stage method is used to mitigate the mutual coupling and correlation issues typically encountered when designing compact MIMO configurations. Initially, a four-port structure is used to evaluate broadband impedance and spatial feasibility. Based on the observed limitations in terms of isolation and the envelope correlation coefficient (ECC), the final configuration was reconfigured as an optimized two-port layout with a refined coupling geometry and effective current path control. The fabricated two-port prototype exhibited a measured voltage standing wave ratio below 3:1 across the n78 band on both ports, with the isolation levels attaining –12.4 dB and ECCs below 0.12. The radiation efficiency exceeded −6 dB across the operational band, and the radiation patterns were stable at 3.3, 3.5, and 3.8 GHz, confirming that the system was appropriate for MIMO deployment. The antenna supports asymmetric per-port efficiency targets ranging from −4.5 to −10 dB. These are the realistic layout constraints of commercial smartphones. In summary, this study shows that a metal frame integrated two-port MIMO antenna enables wideband sub-6 GHz operation by meeting the key impedance and system-level performance requirements. Our method can be used to develop a scalable platform assisting future multi-band antenna integration in mass-market 5G smartphones. Full article
(This article belongs to the Special Issue Antennas for Next-Generation Electromagnetic Applications)
Show Figures

Figure 1

19 pages, 8785 KiB
Article
Design of a 5G MIMO Mobile Intelligent Terminal Antenna with Metasurface Loading
by He Xia, Heming Fan, Zhulin Liu, Hongxiang Miao and Zhiwei Song
Sensors 2025, 25(9), 2927; https://doi.org/10.3390/s25092927 - 6 May 2025
Cited by 1 | Viewed by 587
Abstract
To achieve multi-band coverage within limited space, reduce antenna types, and enhance communication capabilities, an eight-unit dual-band 5G MIMO antenna array is proposed based on a monopole structure. The antenna operates in two frequency bands (3.23–4.14 GHz and 4.31–5.3 GHz), covering the n78 [...] Read more.
To achieve multi-band coverage within limited space, reduce antenna types, and enhance communication capabilities, an eight-unit dual-band 5G MIMO antenna array is proposed based on a monopole structure. The antenna operates in two frequency bands (3.23–4.14 GHz and 4.31–5.3 GHz), covering the n78 and n79 bands for 5G applications. The dual-band and miniaturized design of the antenna elements is achieved through the slotting and branch-loading techniques. The orthogonal placement of corner antenna elements is implemented to reduce coupling and optimize spatial utilization, achieving isolation of over 16 dB between elements. The introduction of a metasurface structure further improved isolation by 2 dB and increased the peak gain of the antenna array to 11.95 dBi. A prototype is fabricated and tested, demonstrating the following performance metrics: isolation exceeding 18 dB, gain ranging from 6 to 12 dBi, envelope correlation coefficient below 0.05, channel capacity greater than 41 bps/Hz, diversity gain of approximately 10 dB, total active reflection coefficient below −24 dB, and radiation efficiency exceeding 72%. These results confirm the superior performance of the proposed antenna design. Full article
Show Figures

Figure 1

21 pages, 4121 KiB
Article
Design of an Integrated System for Spaceborne SAR Imaging and Data Transmission
by Qixing Wang, Peng Gao, Zhuochen Xie and Jinpei Yu
Sensors 2024, 24(19), 6375; https://doi.org/10.3390/s24196375 - 1 Oct 2024
Viewed by 1207
Abstract
In response to the conflicting demands between real-time satellite communication and high-resolution synthetic aperture radar (SAR) imaging, we propose a method that aligns the data transmission rate with the imaging data volume. This approach balances SAR performance with the requirements for real-time data [...] Read more.
In response to the conflicting demands between real-time satellite communication and high-resolution synthetic aperture radar (SAR) imaging, we propose a method that aligns the data transmission rate with the imaging data volume. This approach balances SAR performance with the requirements for real-time data transmission. To meet the need for mobile user terminals to access real-time SAR imagery data of their surroundings without depending on large traditional ground data transmission stations, we developed an application system based on filter bank multicarrier offset quadrature amplitude modulation (FBMC-OQAM). To address the interference problem with SAR signals’ transmission and reception, we developed a signal sequence based on spaceborne SAR echo and data transmission and reception. This system enables SAR and data transmission signals to share the same frequency band, radio frequency transmission system, and antenna, creating an integrated sensing and communication system. Simulation experiments showed that, compared to the equal power allocation scheme for subcarriers, the echo image signal-to-noise ratio (SNR) improved by 2.79 dB and the data transmission rate increased by 24.075 Mbps. Full article
(This article belongs to the Special Issue 6G Space-Air-Ground Communication Networks and Key Technologies)
Show Figures

Figure 1

39 pages, 20241 KiB
Article
Simulation and Design of Three 5G Antennas
by Keyu Li, Dongsheng Wu, Dapeng Chu and Lanlan Ping
Appl. Sci. 2024, 14(17), 8032; https://doi.org/10.3390/app14178032 - 8 Sep 2024
Cited by 2 | Viewed by 2621
Abstract
In the context of 5G networks, this paper investigates microstrip array antennas and mobile terminal MIMO array antennas. It introduces two innovative designs and, based on these, develops and fabricates a mobile terminal antenna. The first of these designs, a 4 × 4 [...] Read more.
In the context of 5G networks, this paper investigates microstrip array antennas and mobile terminal MIMO array antennas. It introduces two innovative designs and, based on these, develops and fabricates a mobile terminal antenna. The first of these designs, a 4 × 4 microstrip array antenna operating in the LTE band 42 (3.4–3.6 GHz), is researched and fabricated and an innovative approach, combining embedded and coaxial feeding methods, is proposed and employed. Measurement results indicate a bandwidth of 373 MHz (3.321–3.694 GHz), achieving a relative bandwidth of 10.7%. The antenna exhibits a high gain of 12.7 dBi, with an undistorted radiation pattern, demonstrating excellent directional characteristics. The second of these designs, a “loop-slot” MIMO antenna designed for 5G mobile devices with metal frames, is investigated. By opening slots in the metal frame and integrating them into the antenna’s feeding structure, the decoupling principle is analyzed from the perspective of characteristic mode theory. This design shares resonant modes between the loop and slot antennas, allowing for the overlapping placement of the two antenna units. Experimental results confirm an isolation level exceeding 21 dB, with significantly reduced dimensions. Finally, an eight-unit MIMO antenna is designed and fabricated for 5G mobile devices with metal frames. Continuous optimization of the “loop-slot” module layout and unit spacing leads to a compact and miniaturized antenna structure. Measurement results show an isolation level exceeding 17 dB, radiation efficiency ranging from 65.8% to 73.7%, and an envelope correlation coefficient (ECC) below 0.03. Finally, an analysis of specific absorption rate (SAR) demonstrates excellent MIMO performance in terms of human body radiation exposure. Full article
Show Figures

Figure 1

17 pages, 4473 KiB
Article
A Deep Learning Framework for Evaluating the Over-the-Air Performance of the Antenna in Mobile Terminals
by Yuming Chen, Dianyuan Qi, Lei Yang, Tongning Wu and Congsheng Li
Sensors 2024, 24(17), 5646; https://doi.org/10.3390/s24175646 - 30 Aug 2024
Cited by 3 | Viewed by 1173
Abstract
This study introduces RTEEMF (Real-Time Evaluation Electromagnetic Field)-PhoneAnts, a novel Deep Learning (DL) framework for the efficient evaluation of mobile phone antenna performance, addressing the time-consuming nature of traditional full-wave numerical simulations. The DL model, built on convolutional neural networks, uses the Near-field [...] Read more.
This study introduces RTEEMF (Real-Time Evaluation Electromagnetic Field)-PhoneAnts, a novel Deep Learning (DL) framework for the efficient evaluation of mobile phone antenna performance, addressing the time-consuming nature of traditional full-wave numerical simulations. The DL model, built on convolutional neural networks, uses the Near-field Electromagnetic Field (NEMF) distribution of a mobile phone antenna in free space to predict the Effective Isotropic Radiated Power (EIRP), Total Radiated Power (TRP), and Specific Absorption Rate (SAR) across various configurations. By converting antenna features and internal mobile phone components into near-field EMF distributions within a Huygens’ box, the model simplifies its input. A dataset of 7000 mobile phone models was used for training and evaluation. The model’s accuracy is validated using the Wilcoxon Signed Rank Test (WSR) for SAR and TRP, and the Feature Selection Validation Method (FSV) for EIRP. The proposed model achieves remarkable computational efficiency, approximately 2000-fold faster than full-wave simulations, and demonstrates generalization capabilities for different antenna types, various frequencies, and antenna positions. This makes it a valuable tool for practical research and development (R&D), offering a promising alternative to traditional electromagnetic field simulations. The study is publicly available on GitHub for further development and customization. Engineers can customize the model using their own datasets. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

17 pages, 6231 KiB
Article
Design of Miniaturized and Wideband Four-Port MIMO Antenna Pair for WiFi
by Yao Hu, Yongshun Wang, Lijun Zhang and Mengmeng Li
Micromachines 2024, 15(7), 850; https://doi.org/10.3390/mi15070850 - 29 Jun 2024
Cited by 1 | Viewed by 1240
Abstract
A miniaturized and wideband four-port multiple-input multiple-output (MIMO) antenna pair for Wi-Fi mobile terminals application is proposed. The proposed antenna pair consists of four multi-branch antenna elements arranged orthogonally, with an overall size of 40 × 40 × 3.5 mm3 and each [...] Read more.
A miniaturized and wideband four-port multiple-input multiple-output (MIMO) antenna pair for Wi-Fi mobile terminals application is proposed. The proposed antenna pair consists of four multi-branch antenna elements arranged orthogonally, with an overall size of 40 × 40 × 3.5 mm3 and each antenna element size of 15.2 × 3.5 mm × 0.8 mm3. The performance of the proposed antenna shows the advantages of a wide frequency band, low mutual coupling, high efficiency, and a compact structure. The wideband characteristics of the antenna elements are achieved through multi-mode resonance. The suppression of coupling is accomplished by strategically positioning the four compact antenna elements to ensure their maximum radiation directions are orthogonal, thus eliminating the need for an additional decoupling structure. In this paper, the proposed antenna is optimized in terms of the parameters then simulated and measured. The simulated results illustrate that an impedance bandwidth of the antenna is about 15% (5.06~5.88 GHz) with S11 < −10 dB, excellent port isolation exceeds 20 dB between all ports, a high radiation efficiency ranges from 51.2% to 89.9%, the maximum gain is 4.5 dBi, and the ECCs are less than 0.04. The measured results show that the −10 dB impedance bandwidth of the antenna is about 13% (5.13~5.80 GHz), the isolation between the antenna elements is better than 21 dB, the radiation efficiency ranges from 51.8% to 92.3%, the maximum gain is 5.3 dBi, and the ECCs are less than 0.05. The proposed four-port MIMO antenna works on the 5G LTE band 46 and Wi-Fi 6E operating bands. As a mobile terminal antenna, the proposed design scheme demonstrates excellent performance and applicability, fulfilling the requirements for 5G mobile terminal applications. Full article
Show Figures

Figure 1

11 pages, 2465 KiB
Article
Behind the Door: Practical Parameterization of Propagation Parameters for IEEE 802.11ad Use Cases
by Luciano Ahumada, Erick Carreño, Albert Anglès, Diego Dujovne and Pablo Palacios Játiva
Technologies 2024, 12(6), 85; https://doi.org/10.3390/technologies12060085 - 7 Jun 2024
Cited by 2 | Viewed by 1762
Abstract
The integration of the 60 GHz band into the IEEE 802.11 standard has revolutionized indoor wireless services. However, this band presents unique challenges to indoor wireless communication infrastructure, originally designed to handle data traffic in residential and office environments. Estimating 60 GHz signal [...] Read more.
The integration of the 60 GHz band into the IEEE 802.11 standard has revolutionized indoor wireless services. However, this band presents unique challenges to indoor wireless communication infrastructure, originally designed to handle data traffic in residential and office environments. Estimating 60 GHz signal propagation in indoor settings is particularly complicated due to dynamic contextual factors, making it essential to ensure adequate coverage for all connected devices. Consequently, empirical channel modeling plays a pivotal role in understanding real-world behavior, which is characterized by a complex interplay of stationary and mobile elements. Given the highly directional nature of 60 GHz propagation, this study addresses a seemingly simple but important question: what is the impact of employing highly directive antennas when deviating from the line of sight? To address this question, we conducted an empirical measurement campaign of wireless channels within an office environment. Our assessment focused on power losses and distribution within an angular range while an indoor base station served indoor users, simulating the operation of an IEEE 802.11ad high-speed WLAN at 60 GHz. Additionally, we explored scenarios with and without pedestrian movement in the vicinity of wireless terminals. Our observations reveal the presence of significant antenna lobes even in obstructed links, indicating potential opportunities to use angular combiners or beamformers to enhance link availability and the data rate. This empirical study provides valuable information and channel parameters to simulate 60 GHz millimeter wave (mm-wave) links in indoor environments, paving the way for more efficient and robust wireless communication systems. Full article
(This article belongs to the Section Information and Communication Technologies)
Show Figures

Figure 1

16 pages, 6123 KiB
Article
High Isolation MIMO Antenna System for 5G N77/N78/N79 Bands
by Xuanhe Wei, Jiaping Lu, Youming Miao, Jianlin Huang, Zhizhou Chen and Gui Liu
Micromachines 2024, 15(6), 721; https://doi.org/10.3390/mi15060721 - 29 May 2024
Cited by 3 | Viewed by 2963
Abstract
This paper presents a symmetric dual-band multiple-input multiple-output (MIMO) antenna system tailored for fifth-generation (5G) mobile terminals. Operating within the 5G frequency bands N77/N78 (3.4–3.6 GHz) and N79 (4.8–5.0 GHz), the proposed MIMO system achieves high isolation between adjacent antenna elements through slotting [...] Read more.
This paper presents a symmetric dual-band multiple-input multiple-output (MIMO) antenna system tailored for fifth-generation (5G) mobile terminals. Operating within the 5G frequency bands N77/N78 (3.4–3.6 GHz) and N79 (4.8–5.0 GHz), the proposed MIMO system achieves high isolation between adjacent antenna elements through slotting and self-decoupling technologies. Antenna elements are strategically positioned on two frames perpendicular to the smartphone’s main board. Each antenna element integrates a rectangular microstrip radiator on the inner frame surface, accompanied by a grounded rectangular ring on the outer frame surface. The feed line, situated atop the main board, connects to an external SMA connector located at the main board’s bottom. Measurement results reveal isolations exceeding 20 dB for the lower band and 24 dB for the higher band. The fabricated and tested MIMO antenna system demonstrates excellent agreement between simulation and measurement outcomes. Full article
Show Figures

Figure 1

15 pages, 4326 KiB
Article
Dual-Band Nested Circularly Polarized Antenna Array for 5G Automotive Satellite Communications
by Umais Tayyab, Ashish Kumar, Hans-Peter Petry, Muhammad Ehtisham Asghar and Matthias A. Hein
Appl. Sci. 2023, 13(21), 11915; https://doi.org/10.3390/app132111915 - 31 Oct 2023
Cited by 6 | Viewed by 2136
Abstract
Currently, 5G low-earth orbit satellite communications offer enhanced wireless coverage beyond the reach of 5G terrestrial networks, with important implications, particularly for automated and connected vehicles. Such wireless automotive mass-market applications demand well-designed compact user equipment antenna terminals offering non-terrestrial jointly with terrestrial [...] Read more.
Currently, 5G low-earth orbit satellite communications offer enhanced wireless coverage beyond the reach of 5G terrestrial networks, with important implications, particularly for automated and connected vehicles. Such wireless automotive mass-market applications demand well-designed compact user equipment antenna terminals offering non-terrestrial jointly with terrestrial communications. The antenna should be low-profile, conformal, and meet specific parameter values for gain and operational frequency bandwidth, tailored to the intended applications, in line with the aesthetic design requirements of passenger cars. This work presents an original concept for a dual-band nested circularly polarized automotive user terminal that operates at the S-band frequencies around 3.5 GHz and Ka-band frequencies around 28 GHz, namely within the 5G new-radio bands n78 and n257, respectively. The proposed terminal is designed to be integrated into the plastic components of a passenger vehicle. The arrays consist of 2 × 2 aperture-coupled corner-truncated microstrip slot patch antenna elements for the n78 band and of 4 × 4 single-layer edge-truncated microstrip circular slot patch antenna elements for the n257 band. The embedded arrays offer, across the two bands, respectively, 9.9 and 13.7 dBi measured realized gain and 3-dB axial ratio bandwidths of 100 and 1500 MHz for the n78 and n257 bands along the broadside direction. Detailed link budget calculations anticipate uplink data rates of 21 and 6 Mbit/s, respectively, deeming it suitable for various automotive mobility and Internet-of-Things applications. Full article
Show Figures

Figure 1

13 pages, 4677 KiB
Article
Suitability of Dual-Band, Dual-Polarized Patch Antennas with a Superstrate for the Miniaturization of Ku-Band Antenna Arrays for Automotive Applications
by Roslin Francis, Safwat Irteza Butt, Jasmeet Singh, Peter Guelzow, Ralf Eimertenbrink and Matthias A. Hein
Appl. Sci. 2023, 13(19), 10867; https://doi.org/10.3390/app131910867 - 29 Sep 2023
Cited by 2 | Viewed by 2200
Abstract
The extension of low-earth orbit (LEO) services to non-terrestrial mobile communications has huge potential for eliminating network white spots and providing high-speed, low-latency links with worldwide geographic coverage. State-of-the-art user terminals for mobile platforms are too large for integration into a passenger vehicle. [...] Read more.
The extension of low-earth orbit (LEO) services to non-terrestrial mobile communications has huge potential for eliminating network white spots and providing high-speed, low-latency links with worldwide geographic coverage. State-of-the-art user terminals for mobile platforms are too large for integration into a passenger vehicle. Antenna elements loaded with a dielectric superstrate could potentially lead to a considerable miniaturization of the user terminal. As per link budget calculations, an array with a gain of 27 dBi is necessary to ensure a throughput of 25 Mbps in the downlink at the Ku-band. A conventional array with a gain of 6 dBi per element, assuming a 12 × 12 arrangement with half-wavelength spacing, would require a footprint of 36 λ2 at 10 GHz to achieve this target and appears unsuitable for automotive integration. This paper proposes a low-profile, dual-band, dual-polarized, vertically stacked patch antenna with superstrate loading and shows that the inclusion of the superstrate improves the antenna’s gain by at least 3 dB. Therefore, compared to a conventional array, a superstrate-loaded array would need only half of the number of elements to meet the target gain, thus occupying only half of the surface area, and offers better integration for automotive applications. Requiring half of the number of elements also implies considerably reduced design complexity and cost. Full article
Show Figures

Figure 1

14 pages, 3719 KiB
Article
Ten-Port MIMO Inverted-F Antenna for LTE Bands 43/48/49 Bands Smartphone Applications
by Muhammad Zahid, Aliya Khalid, Hira Moazzam, Hajra Sadaqat, Sultan Shoaib and Yasar Amin
Electronics 2023, 12(19), 4005; https://doi.org/10.3390/electronics12194005 - 22 Sep 2023
Cited by 4 | Viewed by 1586
Abstract
This paper presents a design and performance analysis of a 10-element 5G massive Multiple Input Multiple Output (m-MIMO) antenna array for sub-6 GHz mobile handsets, specifically for Long Term Evolution (LTE) bands 43 (3600–3800 MHz) and 48/49 (3550–3700 MHz) applications. The proposed antenna [...] Read more.
This paper presents a design and performance analysis of a 10-element 5G massive Multiple Input Multiple Output (m-MIMO) antenna array for sub-6 GHz mobile handsets, specifically for Long Term Evolution (LTE) bands 43 (3600–3800 MHz) and 48/49 (3550–3700 MHz) applications. The proposed antenna array consists of ten closely spaced inverted-F antennas with a compact size of 20 × 9 mm2 of a single element. The proposed antenna array provides high efficiency and low correlation between the antenna elements, which result in increased data rate and enhanced signal quality. The performance of the antenna array is evaluated in terms of the radiation pattern, diversity gain, efficiency, and correlation coefficient. The simulation and measured results show that the proposed antenna array achieves an approximate peak gain of 2.8 dBi and a total efficiency of 65% at the resonance frequency of 37 GHz and a low correlation coefficient of 0.07 between the adjacent antenna elements. Moreover, the single and two-hand modes are also given in order to highlight the potential of such a structure as a smart mobile terminal. The simulated results are discovered to be in excellent agreement with the measured values. We think this structure has a bright future in the next generation of smart mobile phones based on the performance and the measured findings. Full article
(This article belongs to the Collection MIMO Antennas)
Show Figures

Figure 1

16 pages, 13663 KiB
Article
Design of Wideband Decoupling Antenna Array for 5G Smartphones at N77/N78/N79/WLAN 5 GHz Bands
by Zhao Liu, Yongshun Wang, Yao Hu and Lijun Zhang
Appl. Sci. 2023, 13(16), 9370; https://doi.org/10.3390/app13169370 - 18 Aug 2023
Cited by 2 | Viewed by 1855
Abstract
We propose a broadband decoupled antenna pair for 5G mobile terminals. The broadband decoupled design of this antenna pair is based on the characteristic mode theory (CMA) and defective ground structure. First, CMA is applied to obtain the characteristic current distribution of the [...] Read more.
We propose a broadband decoupled antenna pair for 5G mobile terminals. The broadband decoupled design of this antenna pair is based on the characteristic mode theory (CMA) and defective ground structure. First, CMA is applied to obtain the characteristic current distribution of the antenna, then the characteristic current sensitive regions are optimized to make the antenna introduce new modes and obtain a wide bandwidth. After that, an antenna pair is added with defective ground structure to obtain a wideband decoupled antenna pair that has small size and high isolation. Next, an eight-element MIMO antenna system is constructed with the obtained broadband decoupled antenna pair, and a composite decoupling technique consisting of defective ground structure (DGS) and decoupling strip is applied to the two antenna pairs on the same side of the bezel to improve the isolation. The simulation and prototype test results show that the eight-element MIMO antenna with −10 dB bandwidth of 3.28~5.85 GHz mainly covers the N77/N78/N79/WLAN 5 GHz band, and the antenna pair are only 1.6 mm apart with good isolation (−16.7 dB), the ECC is less than 0.01, and it has a good total efficiency at the main operating frequency. Finally, the effect of a user’s hand on the antenna is briefly analyzed to verify the robustness of the proposed MIMO antenna system. Full article
Show Figures

Figure 1

12 pages, 19873 KiB
Communication
A Compact Aperture-Sharing Sub-6 GHz/Millimeter-Wave Dual-Band Antenna
by Qinghu Zhang, Bitian Chai, Jianxin Chen and Wenwen Yang
Sensors 2023, 23(9), 4400; https://doi.org/10.3390/s23094400 - 30 Apr 2023
Cited by 6 | Viewed by 2645
Abstract
In this article, a microwave (MW)/millimeter wave (MMW) aperture-sharing antenna is proposed. The antenna is constructed using two orthogonal columns of grounded vias from a 3.5 GHz slot-loaded half-mode substrate-integrated waveguide (HMSIW) antenna. These vias are reused to create two sets of 1 [...] Read more.
In this article, a microwave (MW)/millimeter wave (MMW) aperture-sharing antenna is proposed. The antenna is constructed using two orthogonal columns of grounded vias from a 3.5 GHz slot-loaded half-mode substrate-integrated waveguide (HMSIW) antenna. These vias are reused to create two sets of 1 × 4 MMW substrate-integrated dielectric resonator antenna (SIDRA) arrays. With this proposed partial structure reuse strategy, the MW antenna and MMW arrays can be integrated in a shared-aperture manner, improving space utilization and enabling dual-polarized beam steering capability in the MMW band, which is highly desirable for multiple-input multipleoutput (MIMO) applications. The integrated antenna prototype was manufactured and measured for verification. The 3.5 GHz antenna has a relative bandwidth of 3.4% (3.44–3.56 GHz) with a peak antenna gain of 5.34 dBi, and the 28 GHz antenna arrays cover the frequency range of 26.5–29.8 GHz (11.8%) and attain a measured peak antenna gain of 11.0 dBi. Specifically, the 28 GHz antenna arrays can realize dual-polarization and ±45° beam steering capability. The dual-band antenna has a very compact structure, and it is applicable for 5G mobile communication terminals. Full article
(This article belongs to the Special Issue MIMO Technologies in Sensors and Wireless Communication Applications)
Show Figures

Figure 1

18 pages, 1474 KiB
Article
On the Performance of Decode-and-Forward Equal-Gain-Combining Relay Systems over Weibull Fading Channels
by Paula Tilleria Lucero, Henry Carvajal Mora, Nathaly Orozco Garzón and Fernando Almeida García
Sensors 2023, 23(6), 3174; https://doi.org/10.3390/s23063174 - 16 Mar 2023
Cited by 2 | Viewed by 2123
Abstract
Relay-assisted wireless communications, where both the relay and the final destiny employ diversity-combining techniques, represent a compelling strategy for improving the signal-to-noise ratio (SNR) for mobile terminals, mainly at millimeter-wave (mmWave) frequency bands. In this sense, this work considers a wireless network that [...] Read more.
Relay-assisted wireless communications, where both the relay and the final destiny employ diversity-combining techniques, represent a compelling strategy for improving the signal-to-noise ratio (SNR) for mobile terminals, mainly at millimeter-wave (mmWave) frequency bands. In this sense, this work considers a wireless network that employs a dual-hop decode-and-forward (DF) relaying protocol, in which the receivers at the relay and at the base station (BS) use an antenna array. Moreover, it is considered that the received signals are combined at reception using equal-gain-combining (EGC). Recent works have enthusiastically employed the Weibull distribution so as to emulate the small-scale fading behavior in mmWave frequencies, which also motivates its use in the present work. For this scenario, exact and asymptotic expressions for the system’s outage probability (OP) and average bit error probability (ABEP) are derived in closed form. Useful insights are gained from these expressions. More precisely, they illustrate how the system and fading parameters affect the performance of the DF-EGC system. Monte Carlo simulations corroborate the accuracy and validity of the derived expressions. Furthermore, the mean achievable rate of the considered system is also evaluated via simulations. Useful insights regarding the system performance are obtained from these numerical results. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1
