Gradient refractive index (GRIN) lenses have been widely used for many applications. However, the traditional manufacturing methods of GRIN lenses are very time-consuming and only suitable for macro-scale operations. In addition, those methods do not have the ability to produce other GRIN optical components with complex refractive index profiles like aspheric or freeform components. We report here an approach to produce GRIN micro-optical components in chalcogenide glass based on a direct laser writing technique. Using this approach, we are able to locally modulate the refractive index of the glass subtrates and create an arbitrary refractive index profile. To prove the flexibility of the method for the production of GRIN micro-optics, we fabricated GRIN micro-lenses and a micro-Fresnel axicon (Fraxicon). The optical properties of micro-lenses can be controlled by varying the writing parameters or the substrate thickness. As a result, the working distance of the micro-lenses can extend from 0 to more than 1000 $\mathsf{\mu }$m. Also, the micro-Fraxicon exhibits the ability to convert a Gaussian beam to a Bessel-like beam which concentrates the mid-infrared light into an approximately 1200 $\mathsf{\mu }$m long confinement zone. Full article

The thermal and optical properties of 60TeO₂-20K₂TeO₃-10WO₃-10Nb₂O₅ (in mol%) glasses doped with Ho₂O₃, Er₂O₃, and Tm₂O₃ were explored in the present work. The thermal stability, refractive index n, extinction coefficient k, absorption coefficient α, and optical band gap of the glasses were evaluated. The UV–Vis–NIR absorption spectra, the Judd–Ofelt intensity parameter, the spectroscopic quality factor, and the emission and absorption cross-sections were calculated to investigate the effects of Er³⁺ and Tm³⁺, respectively, on the band spectroscopic properties of Ho³⁺ ions. The results showed that the maximum emission cross-section was approximately $8\times {10}^{-21} {\mathrm{c}\mathrm{m}}^2$, and the values of the full width at half maximum ($FWHM)$, quality factor (${\sigma }_e\times FWHM)$, and gain coefficient of Ho³⁺: ⁵I₇$\to$⁵I₈ were also reported. The value of the $FWHM\times {\sigma }_e$ was $1200\times {10}^{-28} {\mathrm{c}\mathrm{m}}^3$, which showed greater gain characteristics than earlier study results. For $2 \mathsf{\mu }\mathrm{m}$ mid-infrared solid-state lasers, the glasses that were examined might be a good host material. Full article

A large core size and bending resistance are very important properties of mid-infrared energy transfer fibers, but large core sizes usually lead to the deterioration of bending properties. A negative-curvature nested node-free anti-resonant hollow-core fiber (AR-HCF) based on quartz is proposed. It was made by adding a nested layer to a previous AR-HCF design to provide an additional anti-resonance region while keeping the gap between adjacent tubes strictly correlated with the core diameter to produce a node-free structure. These features improve the fiber’s bending resistance while achieving a larger core diameter. The simulation results show that the radial air–glass anti-resonant layer is increased by the introduction of the nested anti-resonant tube, and the weak interference overlap between the fiber core and the cladding mode is reduced, so the fiber core’s limiting loss and sensitivity to bending are effectively reduced. When the capillary wall thickness t of the fiber is 0.71 μm, the core diameter D is 70 μm, the ratio of the inner diameter of the cladding capillary to the core diameter d/D is 0.62, the diameter of the nested tube is d₀ = 29 μm, the fiber has a lower limiting loss at the wavelength of 2.79 μm, and the limiting loss is 3.28 × 10⁻⁴ dB/m. At the same time, the optimized structure also has good bending resistance. When the bending radius is 30 mm, the bending loss is only 4.72 × 10⁻² dB/m. An anti-bending low-loss micro-structure hollow fiber with a bending radius of less than 30 mm was successfully achieved in the 2.79 μm band. An anti-bending low-loss anti-resonant hollow-core fiber with this structure constitutes a reliable choice for the light guiding system of a 2.79 μm band Er, Cr: YSGG laser therapy instrument. Full article

High-power laser delivery in infrared optical fiber has received much attention due to the urgent needs in the fields of national defense security, biomedicine, advanced manufacturing, and so on. In recent decades, there has been extensive research aimed at enhancing the capabilities of infrared laser power delivery through the purification of infrared glass or the optimization of fiber structures. This article provides an overview of common passive mid-infrared (MIR) optical fibers with numerous glasses and fiber structures, as well as their characteristics in laser power delivery. This review also highlights potential research directions and analyzes the challenges of passive mid-infrared fibers in the current applications. Full article

We fabricated a core-cladding Ge–Sb–Se glass fiber with a Ge_12.5Sb₁₅Se_72.5 core and Ge₁₅Sb₁₀Se₇₅ cladding, achieved a supercontinuum spectrum spanning from 2 μm to 9 μm by pumping the Ge–Sb–Se fiber with a core diameter of 11 μm using a femtosecond laser pump at 3.8 μm, and numerically simulated the supercontinuum generation using the generalized nonlinear Schrödinger equation. In particular, we investigate the effect of the different Raman response functions that were calculated using the traditional single Lorentzian model and a multiple vibrational mode model on the evolution of the supercontinuum by comparing the supercontinua obtained from simulation and experimental results. We demonstrate that the Raman response function generated by the multiple vibrational mode model captures the actual response behavior of the material, and the supercontinuum generated using this model has more accuracy. To the best of our knowledge, this is the first reported study on supercontinuum generation in Ge–Sb–Se fiber utilizing a Raman response function calculated using the multiple vibrational mode model. This significant advancement enables more accurate simulation of supercontinuum generation in fibers with a multi-peaked structured Raman gain spectrum and holds great potential for optimizing the performance of various mid-infrared supercontinuum sources. Full article

This paper provides an overview of mid-infrared lasers based on rare-earth-ion-doped selenide glasses. Laser action was demonstrated at the transitions between the first excited and the ground levels of Ce³⁺, Pr³⁺, Nd³⁺ and Tb³⁺ ions. The highest output parameters for bulk glass lasers (over 40 mJ of output energy) and wavelength tuning in the range of 4.6–5.6 microns were obtained with Ce³⁺-doped glass. The highest output parameters for fiber lasers (150 mW at 5.1–5.3 μm under continuous pumping) were demonstrated with Tb³⁺ ions. The longest lasing wavelengths for any glass laser and tunability within the 5.56–6.01 µm spectral band were shown with Nd³⁺ ions in a Tb³⁺-Nd³⁺ co-doped system. Full article

TeO₂-BaF₂-Er₂O₃-Dy₂O₃ laser glasses were prepared using the melt-quenching method. The bound water that can capture the excited state energy was reduced by physical and chemical methods. We did not observe a significant Er³⁺ emission peak at 2.7 μm in fluorescence spectra, which may be due to the efficient energy transfer process (ET2). Meanwhile, we found a broadband gain span of approximately 400 nm in fluorescence spectra at the 2.85 μm band, attributed to the ‘vector summation’ of the energy level radiation transition and the change of the glass network. Subsequently, we explored the structural properties of the glass. The results indicated that the Gaussian peak located at 250 cm⁻¹ drifts toward 370 cm⁻¹, which may be caused by the fracture or recombination of Te-O-Te and a decrease in the bridge oxygen content with the increasing concentration of Er₂O₃. The topology cage structure around the luminescence center of rare earth ions is changed and the stability of the optically active center is enhanced, finally contributing to the enhancement of luminescence. Meanwhile, the maximum σ_emi and gain coefficient of Dy³⁺ reach up to 7.22 × 10⁻²¹ cm² and 7.37 cm⁻¹, respectively. The comprehensive results show that the fluorotellurite glass designed in this study is expected to be a gain medium for mid-infrared lasers in remote sensing monitoring, military, and other fields. Full article

Amorphous germanium films on nonrefractory glass substrates were annealed by ultrashort near-infrared (1030 nm, 1.4 ps) and mid-infrared (1500 nm, 70 fs) laser pulses. Crystallization of germanium irradiated at a laser energy density (fluence) range from 25 to 400 mJ/cm² under single-shot and multishot conditions was investigated using Raman spectroscopy. The dependence of the fraction of the crystalline phase on the fluence was obtained for picosecond and femtosecond laser annealing. The regimes of almost complete crystallization of germanium films over the entire thickness were obtained (from the analysis of Raman spectra with excitation of 785 nm laser). The possibility of scanning laser processing is shown, which can be used to create films of micro- and nanocrystalline germanium on flexible substrates. Full article

Silicon–germanium multilayer structures consisting of alternating Si and Ge amorphous nanolayers were annealed by ultrashort laser pulses at near-infrared (1030 nm) and mid-infrared (1500 nm) wavelengths. In this paper, we investigate the effects of the type of substrate (Si or glass), and the number of laser pulses (single-shot and multi-shot regimes) on the crystallization of the layers. Based on structural Raman spectroscopy analysis, several annealing regimes were revealed depending on laser fluence, including partial or complete crystallization of the components and formation of solid Si–Ge alloys. Conditions for selective crystallization of germanium when Si remains amorphous and there is no intermixing between the Si and Ge layers were found. Femtosecond mid-IR laser annealing appeared to be particularly favorable for such selective crystallization. Similar crystallization regimes were observed for both single-shot and multi-shot conditions, although at lower fluences and with a lower selectivity in the latter case. A theoretical analysis was carried out based on the laser energy absorption mechanisms, thermal stresses, and non-thermal effects. Full article

In recent years, 3D printing glass optics has gained massive attention in industry and academia since glass could be an ideal material to make optical elements, including the lens. However, the limitation of materials and printing methods has prevented 3D printing glass optics progress. Therefore, we have developed a novel printing strategy for germanate glass printing instead of pure silica. Moreover, compared with traditional multi-component quartz glass, germanate glass has unmatched advantages for its mid-infrared (MIR) transparency and outstanding visible light imaging performance. Furthermore, compared with non-oxide glass (fluoride glass and chalcogenide glass), germanate glass has much better mechanical, physical, and chemical properties and a high refractive index. Germanate glass has been widely applied in remote sensing, ranging, environmental detection, and biomedical detection. However, it is difficult to shape, cast, polish, and grind for optical and photonics applications such as imaging optics and laser-collimation optics. These drawbacks have made germanate glass inaccessible to complex optical elements and greatly increased their cost. In this report, we use germanate glass fibers with a diameter of 125 µm based on fiber-fed laser heating technology to fabricate an mm-size optical application. In this paper, we combine the fiber-fed laser heating technology with an optimized temperature control process to manufacture high-precision optical elements. Germanate glass optics can be printed with excellent visible light and IR transparency and a smooth surface with roughness under 4 nm. By optimizing the layer-by-layer 3D printing process and the thermal feedback in the printing process, we avoid cracks and minimize surface deformation. This work shows the possibility of the mm-size glass optical elements 3D printing and widens its application for IR optics. Full article

Special pure chalcogenide glass is the material of choice for many mid-infrared optical fibers and fiber lasers. In this paper, the thermo-optical lensing and laser-induced damage were studied in Ge₃₅As₁₀S₅₅ and Ge₂₀As₂₂Se₅₈ glasses and compared with the well-studied As₂S₃ glass. The thermal Z-scan technique with the quasi-CW Tm-doped fiber laser at 1908 nm was applied to study thermal lensing in chalcogenide glass. The laser-induced damage of various chalcogenide glasses was determined using the one-on-one procedure. The thermal nonlinear refractive index of the Ge₃₅As₁₀S₅₅ and Ge₂₀As₂₂Se₅₈ glasses was found to be lower than that of the As₂S₃ glass. The laser-induced damage threshold of the Ge₂₀As₂₂Se₅₈ glass was determined to be higher than that of the Ge₃₅As₁₀S₅₅ glass. The difference in the thermal damage threshold of the Ge₃₅As₁₀S₅₅ and Ge₂₀As₂₂Se₅₈ glasses and their lower value in comparison with the As₂S₃ glass were explained by a deviation from the stoichiometry of glass compositions and their tendency to crystallize. Full article

Chalcogenide glass is an optical material with excellent mid-infrared and far-infrared penetration properties. The silver-doped Ge₂₈Sb₁₂Se₆₀ (GSS) chalcogenide films in this paper were deposited on a glass substrate by the co-evaporation technique. A continuous laser with different power outputs was then used to scan the glass material at a constant speed, and the photobleaching (PB) effects were observed using optical microscopy. The results show that silver doping can speed up the PB of GSS film only under high-power laser irradiation. While silver doping helps to speed up the PB effect, it also increases the risk of film damage. This study is beneficial in the development of embedded optical waveguide structures. Full article

We demonstrate the fabrication process and coherent supercontinuum (SC) generation of fluorotellurite step−index fibers with a high numerical aperture (0.56 and 0.64 at 1552 nm). Two compatible fluorotellurite glass pairs were first explored for fiber fabricating with built−in casting and rod−in−tube techniques in a glovebox. Coherent SC sources from 1200 nm to 2400 nm were generated from the fluorotellurite step−index fibers pumped by a femtosecond fiber laser at 1560 nm. Owing to the excellent dehydration of the fluoride, such fibers are available and promising nonlinear media for achieving coherent mid−infrared (MIR) SC. Full article

Chalcogenide glasses are increasingly being developed for photonic applications, particularly in the field of mid-infrared optical imaging. In this paper, we study the photosensitivity of one chalcogenide to direct femtosecond laser writing and its possible applications to micro-optics. Particular attention has been paid to the creation of phase changes and related refractive index variations. This chalcogenide glass was compared with two commercial heavy oxide glasses: Schott SF10 and Corning 9754. We observed different types of permanent modifications depending on the writing speed and the laser pulse energy. Index variations were measured at $\mathsf{\Delta }n>+0.055$ in the chalcogenide glass while maintaining spectral transmission similar to the pristine materials before irradiation. This provides a good candidate to design optical components for infrared application and helps to unlock the potential of the femtosecond laser direct writing technique to implement at high writing speed and high index changes with low optical losses. Full article

Chalcogenide glasses have attracted growing interest for their potential to meet the demands of photonic applications in the Mid-Wavelength InfraRed (MWIR) and Long-Wavelength InfraRed (LWIR) transmission windows. In this work, we investigated the photosensitivity to femtosecond laser irradiation of a dedicated chalcogenide glass, along with its possible applications in micro-optics. In order to address the SWaP problem (Size, Weight and Power), this work took advantage of recent techniques in femtosecond laser direct writing to imprint flat and integrated optical systems. Here, we wanted to simplify an infrared multispectral imaging system which combines a lens array and a filter array. Each channel has a focal length of 7 mm and an f-number of 4. We show in this paper that the chosen GeS₂-based chalcogenide glass is very promising for the fabrication of graded index optics by fs-laser writing, and particularly for the fabrication of Fresnel lenses. We note a very important phase variation capacity in this infrared material corresponding to refractive index variations up to +0.055. A prototype of Fresnel GRIN lens with a refractive index gradient was fabricated and optically characterized in the Vis range. Full article
