Search Results (31)

With the continuous advancement of optical fiber micromachining technology, C-type optical fibers have demonstrated significant potential in the field of optical fiber sensing. By partially or completely removing specific regions of the cladding, a “leakage window” is created, enabling interaction between the optical field and external substances. This structure has facilitated the development of various sensors. This paper reviews recent progress in the research and applications of C-type optical fibers in optical sensing. Based on sensing principles and application scenarios, C-type optical fiber sensors can be categorized into two main types: interferometric and photonic crystal types. This article discusses the fundamental operating principles and structural characteristics of each type, and provides a detailed comparison of their respective advantages and disadvantages. Studies have shown that sensors based on C-type fiber structures offer notable benefits such as simple fabrication, excellent mechanical performance, strong anti-interference capability, and high sensitivity. Therefore, they hold great promise for applications in intelligent monitoring, environmental detection, and healthcare. Finally, this review outlines future research directions for C-type fiber sensors. As technology continues to evolve, future studies are expected to focus on improving sensor stability, expanding application scenarios, and addressing challenges in current fabrication techniques. Full article

Optical fiber Raman and surface-enhanced Raman scattering (SERS) probes hold great promise for in vivo biosensing and in situ monitoring of hostile environments. However, the silica Raman scattering background generated within the optical fiber increases in proportion to the length of the fiber, and it can swamp the signal from the target analyte. While filtering can be applied at the distal end of the fiber, the use of bulk optical elements has limited probe miniaturization to a diameter of 600 µm, which in turn limits the potential applications. To overcome this limitation, femtosecond laser micromachining was used to fabricate a prototype micro-optical filter, which was directly integrated on the tip of a 125 µm diameter double-clad fiber (DCF) probe. The outer surface of the microfilter was further modified with a nanostructured, SERS-active, plasmonic film that was used to demonstrate proof-of-concept performance with thiophenol as a test analyte. With further optimization of the associated spectroscopic system, this ultra-compact microprobe shows great promise for Raman and SERS optical fiber sensing. Full article

This article developed a micromachining system of arcing helical fiber with four electrodes to address the issues with conventional approaches to processing helical fibers, which have several uses. The technique may be utilized to create several types of helical fibers. First, the simulation demonstrates that the four-electrode arc’s constant-temperature heating area is larger than the two-electrode arc’s size. A large constant-temperature heating area is not only beneficial to the stress release of fiber, but also reduces the influence of fiber vibration and reduces the difficulty of device debugging. Then, a variety of helical fibers with various pitches were processed using the system presented in this research. By using a microscope, it can be observed that the cladding and core edges of the helical fiber are constantly smooth and the central core is tiny and off-axis, both of which are favorable for the propagation of optical waveguides. A low off-axis has been shown to minimize optical loss through modeling of energy coupling in spiral multi-core optical fibers. The transmission spectrum findings indicated that the device’s insertion loss and transmission spectrum fluctuation were both minimal for four different types of multi-core spiral long-period fiber gratings with intermediate cores. These prove that the spiral fibers prepared by this system have excellent quality. Full article

Studies about adding graphene reinforcement to improve the microfabrication performance of alumina (Al₂O₃) ceramic materials are still too rare and incomplete to satisfy sustainable manufacturing requirements. Therefore, this study aims to develop a detailed understanding of the effect of graphene reinforcement to enhance the laser micromachining performance of Al₂O₃-based nanocomposites. To achieve this, high-density Al₂O₃ nanocomposite specimens were fabricated with 0 wt.%, 0.5 wt.%, 1 wt.%, 1.5 wt.%, and 2.5 wt.% graphene nanoplatelets (GNPs) using a high-frequency induction heating process. The specimens were subjected to laser micromachining. Afterward, the effects of the GNP contents on the ablation depth/width, surface morphology, surface roughness, and material removal rate were studied. The results indicate that the micro-fabrication performance of the nanocomposites was significantly affected by the GNP content. All nanocomposites exhibited improvement in the ablation depth and material removal rate compared to the base Al₂O₃ (0 wt.% GNP). For instance, at a higher scanning speed, the ablation depth was increased by a factor of 10 times for the GNP-reinforced specimens compared to the base Al₂O₃ nanocomposites. In addition, the MRRs were increased by 2134%, 2391%, 2915%, and 2427% for the 0.5 wt.%, 1 wt.%, 1.5 wt.%, and 2.5 wt.% GNP/Al₂O₃ nanocomposites, respectively, compared to the base Al₂O₃ specimens. Likewise, the surface roughness and surface morphology were considerably improved for all GNP/Al₂O₃ nanocomposite specimens compared to the base Al₂O₃. This is because the GNP reinforcement reduced the ablation threshold and increased the material removal efficiency by increasing the optical absorbance and thermal conductivity and reducing the grain size of the Al₂O₃ nanocomposites. Among the GNP/Al₂O₃ nanocomposites, the 0.5 wt.% and 1 wt.% GNP specimens showed superior performance with minimum defects in most laser micromachining conditions. Overall, the results show that the GNP-reinforced Al₂O₃ nanocomposites can be machined with high quality and a high production rate using a basic fiber laser system (20 Watts) with very low power consumption. This study shows huge potential for adding graphene to alumina ceramic-based materials to improve their machinability. Full article

The vibration of the micro-milling tool presents a significant chaotic vibration phenomenon, which has a great influence on the tool life and part machining precision, and is one of the basic problems restricting the improvement of machining efficiency and machining accuracy in micro-milling. To overcome the difficulty of the traditional vibration measurement method with the online measurement of micro-milling tool multi-dimensional vibration, a three-dimensional (3D) measurement method of the micro-milling tool is proposed based on multi-fiber array coding, which converts the tool space motion into a decoding process of the optical coding array employing the tool modulating the multi-fiber array encoding. A 6 × 6 optical fiber array was designed, and a 3D motion platform for micro-milling tools was built to verify the characteristics of the optical fiber measurement system. The measurement results show that the measuring accuracy of the system reached 1 µm, and the maximum linear error in x-, y-, and z-direction are 1.5%, 2.58%, and 2.43%, respectively; the tool space motion position measurement results show that the maximum measurement error of the measuring system was 3.4%. The designed system has unique coding characteristics for the tool position in the space of 100 µm³. It provides a new idea and realization means for the online vibration measurement of micro-milling tools. Full article

High temperature detection is a constant challenge for condition monitoring under harsh environments in optical fiber sensors research. In this study, the temperature response characteristics of guided acoustic wave Brillouin scattering (GAWBS) spectra in silica single-mode fiber (SMF) up to 800 °C are experimentally investigated, demonstrating the feasibility of the method for high-temperature monitoring. With increasing temperature, the resonance frequency of GAWBS spectra increases in a nearly linear manner, with linearly fitted temperature-dependent frequency shift coefficients of 8.19 kHz/°C for TR_2,7 mode and 16.74 kHz/°C for R_0,4 mode. More importantly, the linewidth of the GAWBS spectra is observed to narrow down with increasing temperature with a linearly fitted rate of −6.91 × 10⁻⁴/°C for TR_2,7 modes and −8.56 × 10⁻⁴/°C for R_0,4 modes. The signal-to-noise ratio of the GAWBS spectra induced by both modes increase by more than 3 dB when the temperature rises from 22 °C to 800 °C, which indicates that the proposed sensing scheme has better performance in high-temperature environments, and are particularly suitable for sensing applications in extreme environments. This study confirms the potential of high-temperature sensing using only GAWBS in silica fibers without any complex micromachining process, which has the advantages of strong mechanical strength, simple structure, easy operation, and low cost. Full article

Sapphire is a robust and wear-resistant material. However, efficient and high-quality micromachining is still a challenge. This contribution demonstrates and discusses two novels, previously unreported approaches for femtosecond laser-based micromachining of rotational-symmetric sapphire workpieces, whereas both methods are in principal hybrids of laser scanning and laser turning or laser lathe. The first process, a combination of a sequential linear hatch pattern in parallel to the workpiece’s main axis with a defined incremental workpiece rotation, enables the fabrication of sapphire fibers with diameters of 50 μm over a length of 4.5 mm. Furthermore, sapphire specimens with a diameter of 25 μm over a length of 2 mm can be fabricated whereas an arithmetical mean height, i.e., S_a parameter, of 281 nm is achieved. The second process combines a constant workpiece feed and orthogonal scanning with incremental workpiece rotation. With this approach, workpiece length limitations of the first process are overcome and sapphire fibers with an average diameter of 90 µm over a length of 20 cm are manufactured. Again, the sapphire specimen exhibits a comparable surface roughness with an average S_a value of 249 nm over 20 cm. Based on the obtained results, the proposed manufacturing method paves an innovative and flexible, all laser-based way towards the fabrication or microstructuring of sapphire optical devices, and thus, a promising alternative to chemical processes. Full article

High-accuracy temperature measurement plays a vital role in biomedical, oceanographic, and photovoltaic industries. Here, a highly sensitive temperature sensor is proposed and demonstrated based on cascaded polymer-infiltrated Mach–Zehnder interferometers (MZIs), operating near the dispersion turning point. The MZI was constructed by splicing a half-pitch graded index fiber (GIF) and two sections of single-mode fiber and creating an inner air cavity based on femtosecond laser micromachining. The UV-curable polymer-infiltrated air cavity functioned as one of the interference arms of MZI, and the residual GIF core functioned as the other. Two MZIs with different cavity lengths and infiltrated with the UV-curable polymers, having the refractive indexes on the different sides of the turning point, were created. Moreover, the effects of the length and the bending way of transmission SMF between the first and the second MZI were studied. As a result, the cascaded MZI temperature sensor exhibits a greatly enhanced temperature sensitivity of −24.86 nm/°C based on wavelength differential detection. The aforementioned result makes it promising for high-accuracy temperature measurements in biomedical, oceanographic, and photovoltaic applications. Full article

Additive manufacturing is an emerging technology and provides high design flexibility to customers. Fused deposition modeling (FDM) is an economical and promising additive manufacturing method. Due to its many advantages, FDM received great attention in recent years, and comprehensive studies are being undertaken to investigate the properties of FDM-printed polymers and polymer composites. As a result of the manufacturing technology employed in FDM, inner structures are changed with different process parameters, and thus, anisotropic properties are observed. Moreover, composite filaments such as particle- or fiber-reinforced polymers already have anisotropy before FDM printing. In this study, we investigate the effect of different process parameters, namely layer thickness and raster width on FDM-printed copper-reinforced poly(lactic acid) (PLA). Mechanical characterizations with a high-resolution camera are carried out for analyzing the deformation behaviors. Optical microscopy characterizations are performed to observe the mesostructural changes with various process parameters. Scanning electron microscopy (SEM) and an energy-dispersive X-ray spectroscopy (EDS) analysis are conducted for investigating the microstructure, specifically, copper particles in the PLA matrix. A 2D digital image correlation code with a machine learning algorithm is applied to the optical characterization and SEM-EDS images. In this way, micro- and mesostructural features, as well as the porosity ratios of the specimens are investigated. We prepare the multiscale homogenization by finite element method (FEM) simulations to capture the material’s response, both on a microscale and a mesoscale. We determined that the mesostructure and, thereby, the mechanical properties are significantly changed with the aforementioned process parameters. A lower layer thickness and a greater raster width led to a higher elasticity modulus and ultimate tensile strength (UTS). The optical microscopy analysis verified this statement: Decreasing the layer thickness and increasing the raster width result in larger contact lines between adjacent layers and, hence, lower porosity on the mesoscale. Realistic CAD images were prepared regarding the mesostructural differences and porosity ratios. Ultimately, all these changes are accurately modeled with mesoscale and multiscale simulations. The simulation results are validated by laboratory experiments. Full article

Blood glucose concentration is important for metabolic homeostasis in humans and animals. Many diabetic patients need to detect blood glucose daily which burdens community hospitals and family healthcare. Optical fiber sensors are widely used in biomedical detection because of their compact structure, fast response, high sensitivity, low cost, and ease of operation. In this work, we constructed a Fabry-Perot (FP) cavity biosensor for the fast detection of glucose concentration in serum. The femtosecond laser micromachining was applied to fabricate the FP cavity by printing the fiber-tip fixed-supported bridge at the end face of the optical fiber. An additional hemisphere was printed at the center of the outer surface of the bridge to avoid multi-beam interference. The results demonstrated that the proposed biosensor had high refractive index (RI) detection sensitivity, roughly 1039 nm/RIU at a wavelength of 1590 nm, and the detection sensitivity for glucose was around 0.185 nm/ (mg/mL) at a wavelength of 1590 nm. Due to its high sensitivity, compact structure, and fast response, the FP cavity biosensor has great potential to be applied in family healthcare for glucose concentration detection of diabetic patients. Full article

We present a combination of micromachined optofluidic platforms equipped with a fiber-optic sensing configuration based on a three-path Mach–Zehnder interferometer (MZI) for simultaneous measurement of the refractive index of liquids and the autocalibration in dynamic regime. The sensing principle is based on the low-coherence interferometry, characterized by a generation of Gaussian enveloped interferograms, for which the position of its maximum depends on the optical path difference (OPD) between the sensing and reference arm of the MZI. When liquid flows through the central microchannel of the optofluidic platform it crosses the light beam between the two optical fibers in the sensing arm causing the OPD change. An algorithm has been applied for the calculation of the refractive index of liquids out of the raw interference signals. We obtained a very good agreement between the experimental results and literature data of refractive indices of subjected fluids. The accuracy of refractive index measurement is approximately 1%, predominantly determined by the accuracy of reading the position of the mechanical scanner. The proposed sensor is attractive for the label-free biological, biochemical, and chemical sensing owing autocalibration and high sensitivity yet consuming a very small sample volume of 1 µL. It is capable to measure the refractive index of various liquids and/or gases simultaneously in the process. Full article

As the final flow channel of the liquid rocket engine, the manufacturing of impinging atomization nozzles has become a critical link in the manufacture of impinging atomization components. At present, the high-precision machining of millimeter nozzles in large-scale production is quite difficult, which inevitably leads to the diversity of internal flow field and atomization field parameters. In this investigation, the influence of the diameter deviation of impinging nozzles on the atomization field is analyzed by experiment. The transparent nozzle is installed in a typical colliding atomizer. The ultra-precision measurement is carried out by the optical fiber measurement system and the flow field in the nozzle is visualized. The information of atomized droplets in the atomization field is assembled by the laser interferometric particle imaging technology (IPI). The experimental results indicate that the micro-deviations of the collision aperture have a profound influence on the cavitation state of the flow field in the nozzles and the atomization characteristics (droplet diameter and atomization cone angle) of the atomization field. Full article

We experimentally report fiber Bragg gratings (FBGs) in a single mode step-index polymer optical fiber (POF) with a core made of TOPAS and cladding made of ZEONEX using 520 nm femtosecond pulses and a point-by-point (PbP) inscription method. With different pulse energies between 9.7 nJ and 11.2 nJ, 12 FBGs are distributed along the cores of two pieces of POFs with negative averaged effective index change up to ~6 × 10⁻⁴ in the TOPAS. For POF 1 with FBGs 1–6, the highest reflectivity 45.1% is obtained with a pulse energy of 10.6 nJ. After inscription, good grating stability is reported. Thanks to the post-annealing at 125 °C for 24 h, after cooling the grating reflectivity increases by ~10%. For POF 2 with FBGs 7–12, similar FBG data are obtained showing good reproducibility. Then, the FBGs are annealed at 125 °C for 78 h, and the average reflectivity of the FBGs during the annealing process increases by ~50% compared to that before the annealing, which could be potentially applied to humidity insensitive high temperature measurement. Full article

This paper proposes a high-temperature optical fiber Fabry–Perot pressure sensor based on the micro-electro-mechanical system (MEMS). The sensing structure of the sensor is composed of Pyrex glass wafer and silicon wafer manufactured by mass micromachining through anodic bonding process. The separated sensing head and the gold-plated fiber are welded together by a carbon dioxide laser to form a fiber-optic Fabry–Perot high temperature pressure sensor, which uses a four-layer bonding technology to improve the sealing performance of the Fabry–Perot cavity. The test system of high temperature pressure sensor is set up, and the experimental data obtained are calculated and analyzed. The experimental results showed that the maximum linearity of the optical fiber pressure sensor was 1% in the temperature range of 20–400 °C. The pressure sensor exhibited a high linear sensitivity of about 1.38 nm/KPa at room temperature at a range of pressures from approximarely 0-to 1 MPa. The structure of the sensor is characterized by high consistency, which makes the structure more compact and the manufacturing process more controllable. Full article

Tissues affected by neoplastic lesions differ from healthy tissues in terms of functionality and anatomy. These changes affect light’s propagation in tissue by modifying the refractive index, and scattering and absorption coefficients. The primary purpose of this research was to create a system to detect local changes in the refractive index using a fiber optic sensor. A prototype of a micromachine for biomedical applications has been developed. The measurements were performed using the low-coherence interferometry method, i.e., a measurement technique based on the interference of light waves from a broadband light source. The constructed optical system uses a light source with a central wavelength of 1550 nm, a spectrum analyzer, a fiber optic sensor operating on the basis of a Fabry–Perot interferometer and a silver mirror acting as a reflective layer. Measurements of the interference spectrum of reference oils, used for calibration due to the high stability of their parameters, were performed. It has been shown that the developed fiber optic sensor is able to detect changes in the refractive index based on a shift in the position of the central peak in the interference spectrum. It is also sensitive to changes of the absorption coefficient. Full article
