This paper introduces a digital interface application-specific integrated circuit (ASIC) for a micro-electromechanical systems (MEMS) vibratory gyroscope. The driving circuit of the interface ASIC uses an automatic gain circuit (AGC) module instead of a phase-locked loop to realize a self-excited vibration, which gives the gyroscope system good robustness. In order to realize the co-simulation of the mechanically sensitive structure and interface circuit of the gyroscope, the equivalent electrical model analysis and modeling of the mechanically sensitive structure of the gyro are carried out by Verilog-A. According to the design scheme of the MEMS gyroscope interface circuit, a system-level simulation model including mechanically sensitive structure and measurement and control circuit is established by SIMULINK. A digital-to-analog converter (ADC) is designed for the digital processing and temperature compensation of the angular velocity in the MEMS gyroscope digital circuit system. Using the positive and negative diode temperature characteristics, the function of the on-chip temperature sensor is realized, and the temperature compensation and zero bias correction are carried out simultaneously. The MEMS interface ASIC is designed using a standard 0.18 μM CMOS BCD process. The experimental results show that the signal-to-noise ratio (SNR) of sigma-delta (ΣΔ) ADC is 111.56 dB. The nonlinearity of the MEMS gyroscope system is 0.03% over the full-scale range. Full article

Microelectromechanical Systems (MEMS) vibratory gyroscopes are one of the integral inertial sensors of the inertial measurement unit (IMU). The usage of MEMS vibratory gyroscopes as inertial sensors has risen enormously in many applications, from household to automotive, smartphones to space applications, smart gadgets to military applications, and so on. This paper presents the mathematical modelling and initial development of the starfish structure with C-shaped springs for a MEMS vibratory ring gyroscope (VRG). The symmetric design methodology of VRGs corroborates higher sensitivity, mode matching, good thermal stability, better resolution, and shock resistance in extreme conditions. The proposed VRG has been designed and investigated using ANSYS^TM software. This novel design incorporates a two-ring structure, with inner and outer rings, and with 16 C-shaped springs. The outer ring’s radius is 1000 μm and the whole VRG structure is supported by the outer eight small square pillars. The gyroscope structure’s wine-glass mode driving and sensing resonant frequencies were recorded at 51.50 kHz and 52.16 kHz. The mode mismatch between driving and sensing resonant frequency was measured at 0.66 kHz, which is relatively low compared to the other structures of vibratory gyroscopes. The proposed design provides high shock absorption with higher sensitivity for space applications for the control and manoeuvring of mini satellites for space applications. Full article

The surge in fabrication techniques for micro- and nanodevices gave room to rapid growth in these technologies and a never-ending range of possible applications emerged. These new products significantly improve human life, however, the evolution in the design, simulation and optimization process of said products did not observe a similarly rapid growth. It became thus clear that the performance of micro- and nanodevices would benefit from significant improvements in this area. This work presents a novel methodology for electro-mechanical co-optimization of micro-electromechanical systems (MEMS) inertial sensors. The developed software tool comprises geometry design, finite element method (FEM) analysis, damping calculation, electronic domain simulation, and a genetic algorithm (GA) optimization process. It allows for a facilitated system-level MEMS design flow, in which electrical and mechanical domains communicate with each other to achieve an optimized system performance. To demonstrate the efficacy of the methodology, an open-loop capacitive MEMS accelerometer and an open-loop Coriolis vibratory MEMS gyroscope were simulated and optimized—these devices saw a sensitivity improvement of 193.77% and 420.9%, respectively, in comparison to their original state. Full article

With the development of the designing and manufacturing level for micro-electromechanical system (MEMS) gyroscopes, the control circuit system has become a key point to determine their internal performance. Nevertheless, the phase delay of electronic components may result in some serious hazards. This study described a real-time circuit phase delay correction system for MEMS vibratory gyroscopes. A detailed theoretical analysis was provided to clarify the influence of circuit phase delay on the in-phase and quadrature (IQ) coupling characteristics and the zero-rate output (ZRO) utilizing a force-to-rebalance (FTR) closed-loop detection and quadrature correction system. By deducing the relationship between the amplitude-frequency, the phase-frequency of the MEMS gyroscope, and the phase relationship of the whole control loop, a real-time correction system was proposed to automatically adjust the phase reference value of the phase-locked loop (PLL) and thus compensate for the real-time circuit phase delay. The experimental results showed that the correction system can accurately measure and compensate the circuit phase delay in real time. Furthermore, the unwanted IQ coupling can be eliminated and the ZRO was decreased by 755% to 0.095°/s. This correction system realized a small angle random walk of 0.978°/√h and a low bias instability of 9.458°/h together with a scale factor nonlinearity of 255 ppm at room temperature. The thermal drift of the ZRO was reduced to 0.0034°/s/°C at a temperature range from −20 to 70 °C. Full article

This paper proposes a solution for sensing spatial angular velocity. A high-performance digital interface application specific integrated circuit (ASIC) for triple-axis micro-electromechanical systems (MEMS) vibratory gyroscopes is presented. The technique of time multiplexing is employed for synergetic stable drive control and precise angular velocity measurement in three separate degrees of freedom (DOF). Self-excited digital closed loop drives the proof mass in sensing elements at its inherent resonant frequency for Coriolis force generation during angular rotation. The analog front ends in both drive and sense loops are comprised of low-noise charge-voltage (C/V) converters and multi-channel incremental zoom analog-to-digital converters (ADC), so that capacitance variation between combs induced by mechanical motion is transformed into digital voltage signals. Other circuitry elements, such as loop controlling and accurate demodulation modules, are all implemented in digital logics. Automatic amplitude stabilization is mainly realized by peak detection and proportion-integration (PI) control. Nonlinear digital gain adjustment is designed for rapid establishment of resonance oscillation and linearity improvement. Manufactured in a standard 0.35-μm complementary metal-oxide-semiconductor (CMOS) technology, this design achieves a bias instability of 2.1°/h and a nonlinearity of 0.012% over full-scale range. Full article

This paper proposes an interface application-specific-integrated-circuit (ASIC) for micro-electromechanical systems (MEMS) vibratory gyroscopes. A closed self-excited drive loop is employed for automatic amplitude stabilization based on peak detection and proportion-integration (PI) controller. A nonlinear multiplier terminating the drive loop is designed for rapid resonance oscillation and linearity improvement. Capacitance variation induced by mechanical motion is detected by a differential charge amplifier in sense mode. After phase demodulation and low-pass filtering an analog signal indicating the input angular velocity is obtained. Non-idealities are further suppressed by on-chip temperature drift calibration. In order for better compatibility with digital circuitry systems, a low passband incremental zoom sigma-delta (ΣΔ) analog-to-digital converter (ADC) is implemented for digital output. Manufactured in a standard 0.35 μm complementary metal-oxide-semiconductor (CMOS) technology, the whole interface occupies an active area of 3.2 mm². Experimental results show a bias instability of 2.2 °/h and a nonlinearity of 0.016% over the full-scale range. Full article

This paper proposes an effective method to calibrate the microelectromechanical systems (MEMS) vibratory gyroscope based on the virtual Coriolis force. This method utilizes a series of voltage signals to simulate the Coriolis force input, and the gyroscope output is monitored to obtain the scale factor characteristics of the gyroscopes. The scale factor and bias parameters of the gyroscope can be calibrated conveniently and efficiently in the sense-mode open loop. The calibration error of the scale factor based on the turntable and the virtual Coriolis force method is only 1.515%, which proves the correction of the method proposed in this paper. Meanwhile, the non-linearity and bias value of the turntable and the virtual Coriolis force method are 742 ppm and 42.04 mV and 3389 ppm and 0.66 mV, respectively. Full article

Recently, consumer applications have dramatically created the demand for low-cost and compact gyroscopes. Therefore, on the basis of microelectromechanical systems (MEMS) technology, many gyroscopes have been developed and successfully commercialized. A MEMS gyroscope consists of a MEMS device and an electrical circuit for self-oscillation and angular-rate detection. Since the MEMS device and circuit are interactively related, the entire system should be analyzed together to design or test the gyroscope. In this study, a MEMS vibratory gyroscope is analyzed based on the system dynamic modeling; thus, it can be mathematically expressed and integrated into a circuit simulator. A behavioral simulation of the entire system was conducted to prove the self-oscillation and angular-rate detection and to determine the circuit parameters to be optimized. From the simulation, the operating characteristic according to the vacuum pressure and scale factor was obtained, which indicated similar trends compared with those of the experimental results. The simulation method presented in this paper can be generalized to a wide range of MEMS devices. Full article

This paper presents a theoretical analysis of mechanical and electrical noise in the sense channel of micro-electromechanical systems (MEMS) vibratory gyroscopes. Closed-form expressions for the power spectral density (PSD) of the noise equivalent rate (NER) of gyroscopes in the open-loop and the force-rebalance operations are derived by using an averaged PSD model and an equivalent transfer function. The obtained expressions are verified through numerical simulations, demonstrating close agreements between the analytic and the numerical models. Based on the derived expressions for the PSD of the NER, the impacts of the modal frequency split, quality factor, and the gain of the feedback forcer, as well as the gain of the signal conditioning circuit, on the gyroscope noise characteristics are theoretically analyzed. In addition, the angle random walk (ARW) and the standard deviation of the NER are also discussed through the PSD models. Finally, the effects of the loop closing, the mode matching, and the gain of the feedback forcer on the PSD of the NER were verified via a MEMS vibratory gyroscope with a tunable modal frequency split. Full article

This paper reports on the design, fabrication and preliminary test results of a novel microelectromechanical systems (MEMS) device—the acoustic gyroscope. The unique operating mechanism is based on the “acoustic version” of the Sagnac effect in fiber-optic gyros. The device measures the phase difference between two sound waves traveling in opposite directions, and correlates the signal to the angular velocity of the hosting frame. As sound travels significantly slower than light and develops a larger phase change within the same path length, the acoustic gyro can potentially outperform fiber-optic gyros in sensitivity and form factor. It also promises superior stability compared to vibratory MEMS gyros as the design contains no moving parts and is largely insensitive to mechanical stress or temperature. We have carried out systematic simulations and experiments, and developed a series of processes and design rules to implement the device. Full article

The time-average method currently available is limited to analyzing the specific performance of the automatic gain control-proportional and integral (AGC-PI) based velocity-controlled closed-loop in a micro-electro-mechanical systems (MEMS) vibratory gyroscope, since it is hard to solve nonlinear functions in the time domain when the control loop reaches to 3rd order. In this paper, we propose a linearization design approach to overcome this limitation by establishing a 3rd order linear model of the control loop and transferring the analysis to the frequency domain. Order reduction is applied on the built linear model’s transfer function by constructing a zero-pole doublet, and therefore mathematical expression of each control loop’s performance specification is obtained. Then an optimization methodology is summarized, which reveals that a robust, stable and swift control loop can be achieved by carefully selecting the system parameters following a priority order. Closed-loop drive circuits are designed and implemented using 0.35 μm complementary metal oxide semiconductor (CMOS) process, and experiments carried out on a gyroscope prototype verify the optimization methodology that an optimized stability of the control loop can be achieved by constructing the zero-pole doublet, and disturbance rejection capability (D.R.C) of the control loop can be improved by increasing the integral term. Full article
