The design and optimization of plasmonic nanohole arrays (NHAs) as transducers for efficient bioanalytical sensing is a rapidly growing field of research. In this work, we present a rational method for tailoring the optical and functional properties of Au NHAs realized on planar transparent substrates. Experimental and numerical results demonstrate how the far- and near-field properties of the NHAs can be controlled and optimized for specific sensing applications, proving a valuable insight into the distribution of electric fields generated on the nanostructured metal surface and the depth of penetration into the surrounding media. Metal thickness is found to play a crucial role in determining the sensing volume, while the diameter of the nanoholes affects the localization of the electromagnetic field and the extent of the decay field. The remarkable surface and bulk refractive index sensitivities observed a rival performance of more complex geometric designs reported in the recent literature, showcasing their outstanding potential for chemo-biosensing applications. Full article

Gold nanohole arrays, hybrid metal/dielectric metasurfaces composed of periodically arranged air holes in a thick gold film, exhibit versatile support for both localized and propagating surface plasmons. Leveraging their capabilities, particularly in surface plasmon resonance-oriented applications, demands precise optical tuning. In this study, a customized particle swarm optimization algorithm, implemented in Ansys Lumerical FDTD, was employed to optically tune gold nanohole arrays treated as bidimensional gratings following the Bragg condition. Both square and triangular array dispositions were considered. Convergence and evolution of the particle swarm optimization algorithm were studied, and a mathematical model was developed to interpret its outcomes. Full article

Localized Surface Plasmon Resonance (LSPR) is an optical method for detecting changes in refractive index by the interaction between incident light and delocalized electrons within specific metal thin films’ localized “hot spots”. LSPR-based sensors possess advantages, including their compact size, enhanced sensitivity, cost-effectiveness, and suitability for point-of-care applications. This research focuses on the development of LSPR-based nanohole arrays (NHAs) as a platform for monitoring probe/target binding events in real time without labeling, for low-level biomolecular target detection in biomedical diagnostics. To achieve this objective, this study involves creating a liquid-phase setup for capturing target molecules. Finite-difference time-domain simulations revealed that a 75 nm thickness of gold (Au) is ideal for NHA structures, which were visually examined using scanning electron microscopy. To illustrate the functionality of the liquid-phase sensor, a PDMS microfluidic channel was fabricated using a 3D-printed mold with a glass slide base and a top glass cover slip, enabling reflectance-mode measurements from each of four device sectors. This study shows the design, fabrication, and assessment of NHA-based LSPR sensor platforms within a PDMS microfluidic channel, confirming the sensor’s functionality and reproducibility in a liquid-phase environment. Full article

Refractive index sensing based on surface plasmon resonance (SPR) is a highly efficient label-free technique for biomolecular detection. The performance of this method is defined by the dielectric properties of a sensing layer and its structure. Nanohole arrays in thin metal films provide good refractive index sensitivity but often suffer from a large resonance linewidth, which limits their broad practical application in biosensorics. Coupling the broad plasmon modes to sharp resonances can reduce the peak widths, but at the same time it can also degrade the sensitivity. Here, we use Finite-Difference Time Domain simulations to study the factors affecting the sensing performance of gold-silica-gold optical cavities with nanohole arrays in the dielectric and top metal layers. We demonstrate that by tuning resonator size and inter-hole spacing, the performance of the biosensor can be optimized and the figure of merit of the order of 5–7 is reached. Full article

This study aims to develop a refractive-index sensor operating in the visible region using an all-dielectric metasurface, which was chosen for its advantages of low optical loss and narrow spectral bandwidth, compared to those of conventional metallic metasurfaces. COMSOL software was utilized as a calculation tool to simulate the resonant properties of an all-dielectric metasurface composed of a circular nanohole-structured titanium oxide (TiO₂) thin film, with the aim of enhancing the sensitivity of the refractive index for sensing targets. The simulation focused on finding the best geometrical conditions for the all-dielectric metasurface to achieve high sensitivity. Two resonance modes observed in this metasurface were considered: the quasi-bound-state-in-the-continuum (qBIC) mode and the perfect-reflection (PR) mode. The simulated results demonstrated that high sensitivities of 257 nm/RIU at the PR mode and 94 nm/RIU at the qBIC mode in the visible spectral range could be obtained by periodically constructing the metasurface with a unit cell having a lattice constant of 350 nm, a nanohole radius of 160 nm, and a nanohole depth of 250 nm. Furthermore, the study showed that the resonance mode that enabled high sensitivity was the PR mode, with a sensitivity nearly three times larger than that of the qBIC mode and the ability to reach the highest reflectance at the resonance wavelength. The optimized feature had the highest reflectance at a resonant wavelength of 570.19 nm, and although the quality factor was 25.50, these designed parameters were considered sufficient for developing a refractive index biosensor with high sensitivity and optical efficiency when operating in the visible spectral range. Full article

Circular dichroism (CD) effects have broad applications in fields including biophysical analysis, analytical chemistry, nanoscale imaging, and nanosensor design. Herein, a novel design of a tilted F-type chiral metal nanostructure composed of circular nanoholes with varying radii has been proposed to achieve remarkable CD effects, and the results demonstrate the generation of a significant current oscillation at the sharp edges where the nanoholes overlap under circularly polarized light, resulting in a strong CD effect. The CD effect can reach up to 7.5%. Furthermore, spectral modulation of the resonant wavelength can be achieved by adjusting the structural parameters, which enhances the tunability of the structure. Overall, these results provide theoretical or practical guidance for enhancing the circular dichroism signal strength of chiral metal nanostructures and designing new types of two-dimensional chiral structures. Full article

Ultra-short 230 fs laser pulses of 515 nm wavelength were tightly focused into 700 nm focal spots and utilised in opening ∼400 nm nano-holes in a Cr etch mask that was tens-of-nm thick. The ablation threshold was found to be 2.3 nJ/pulse, double that of plain silicon. Nano-holes irradiated with pulse energies below this threshold produced nano-disks, while higher energies produced nano-rings. Both these structures were not removed by either Cr or Si etch solutions. Subtle sub-1 nJ pulse energy control was harnessed to pattern large surface areas with controlled nano-alloying of Si and Cr. This work demonstrates vacuum-free large area patterning of nanolayers by alloying them at distinct locations with sub-diffraction resolution. Such metal masks with nano-hole opening can be used for formation of random patterns of nano-needles with sub-100 nm separation when applied to dry etching of Si. Full article

The fabrication of nanostructures usually involves chemical processes that have in certain steps. Especially, it is necessary to use the chemical etching method to release the as-patterned structures from the substrate in most of the transfer techniques. Here, a novel scheme of template transfer as developed for the fabrication of freestanding Au nanomembranes and nanowires by using a soluble PVP adhesive. The nanomembranes feature the periodic nanohole arrays with high uniformity. Without the substrates, these plasmonic nanohole arrays show symmetric and antisymmetric resonance modes with bright and dark spectral features, respectively, in transmission. Through the spectral analysis for reflection, we have disclosed that the usual dark mode in transmission is not really dark, but it reveals a distinct feature in reflection. Two coupling modes present distinct spectral features in transmission and reflection due to their different loss channels. To show their versatility, the freestanding nanomembranes were also employed as secondary templates to form Si nanowire arrays by the metal-assisted chemical etching method. Full article

In this work, we present and explore the characteristics of a plasmonic metamaterial absorber based on a metal–insulator–metal functional stack. The proposed structure consists of glass “sandwiched” between a silver reflector and a titanium metallic disc, embedded inside a Ti periodic nano-hole array, as an outside layer. In the visible and infrared regimes, the optical absorption spectra of such structures have been investigated using the finite difference time domain method. The impact of modifying nano-hole and embedded disc diameters on the absorber’s performance has been investigated. Changing these two distinct structural parameters tunes the coupling effect between the localized and propagating surface plasmons. The adequate bandwidth, average spectral absorption rate, and short circuit current density are calculated to determine the performance of the designated absorber. The proposed structure of the plasmonic metamaterial absorber reaches an average absorption of over 94% in a bandwidth of 0.81 µm and near-perfect absorption of 98% around the wavelength of 0.7 µm, with an almost 100% relative absorption bandwidth and 41 mA/cm² short circuit current density. In addition, the results show that the disc-in-hole absorber’s structural parameters can be changed precisely and facilely to tailor to the absorption spectra. Full article

Harvesting energetic carriers from plasmonic resonance has been a hot topic in the field of photodetection in the last decade. By interfacing a plasmonic metal with a semiconductor, the photoelectric conversion mechanism, based on hot carrier emission, is capable of overcoming the band gap limitation imposed by the band-to-band transition of the semiconductor. To date, most of the existing studies focus on plasmonic structural engineering in a single metal-semiconductor (MS) junction system and their responsivities are still quite low in comparison to conventional semiconductor, material-based photodetection platforms. Herein, we propose a new architecture of metal-semiconductor-metal (MSM) junctions on a silicon platform to achieve efficient hot hole collection at infrared wavelengths with a photoconductance gain mechanism. The coplanar interdigitated MSM electrode’s configuration forms a back-to-back Schottky diode and acts simultaneously as the plasmonic absorber/emitter, relying on the hot-spots enriched on the random Au/Si nanoholes structure. The hot hole-mediated photoelectric response was extended far beyond the cut-off wavelength of the silicon. The proposed MSM device with an interdigitated electrode design yields a very high photoconductive gain, leading to a photocurrent responsivity up to several A/W, which is found to be at least 1000 times higher than that of the existing hot carrier based photodetection strategies. Full article

The highly localized and uneven spatial distribution of the subwavelength light field in metal metasurfaces provides a promising means for the generation of optical vortices (OVs) with arbitrary topological charges. In this paper, a simple and reliable way for generating multichannel OVs on gold nanoporous metasurfaces is reported. The instantaneous field of arbitrary-order OVs can be regulated and concentrated on the same focal surface by adapting photonic spin–orbit interaction (SOI) and geometric phase. The focal ring energy distribution of OVs along the conical propagation path is accurately calculated, and the double phase of units induced by spin rotation is confirmed. Based on the parameter optimization of the nanohole arrangement, the simultaneous amplitude and phase modulation of multichannel OVs has been realized. Furthermore, the average multichannel signal-to-noise ratio exceeds 15 dB, which meets the requirements of high resolution and low crosstalk. Our study obtains broadband and efficient OVs, which can contribute to improving the capacity storage and security of optical information and possess great application prospects in beam shaping, optical tweezers, and communication coding. Full article

Reliable gas sensors are very important for hydrogen (H₂) gas detection and storage. Detection methods based on palladium (Pd) metal are cost-effective and widely studied. When Pd is exposed to H₂, it turns into palladium hydride with modified optical properties, which thus can be monitored for H₂ sensing. Here, we fabricated large-area Pd nanostructures, including Pd nanotriangles and nanohole arrays, using colloidal lithography and systematically studied their H₂-sensing performance. After hydrogen absorption, both the Pd nanoholes and nanotriangles showed clear transmittance changes in the visible–near infrared range, consistent with numerical simulation results. The influences of the structural parameters (period of the array P and diameter of the nanohole D) of the two structures are further studied, as different structural parameters can affect the hydrogen detection effect of the two structures. The nanohole arrays exhibited bigger transmittance changes than the nanotriangle arrays. Full article

Extraordinary Optical Transmission Plasmonic Color Filters (EOT-PCFs) with nanostructures have the advantages of consistent color, small size, and excellent color reproduction, making them a suitable replacement for colorant-based filters. Currently, the color gamut created by plasmonic filters is limited to the standard red, green, blue (sRGB) color space, which limits their use in the future. To address this limitation, we propose a surface plasmon resonance (SPR) color filter scheme, which may provide a RGB-wide color gamut while exceeding the sRGB color space. On the surface of the aluminum film, a unique nanopattern structure is etched. The nanohole functions as a coupled grating that matches photon momentum to plasma when exposed to natural light. Metals and surfaces create surface plasmon resonances as light passes through the metal film. The plasmon resonance wavelength can be modified by modifying the structural parameters of the nanopattern to obtain varied transmission spectra. The International Commission on Illumination (CIE 1931) chromaticity diagram can convert the transmission spectrum into color coordinates and convert the spectrum into various colors. The color range and saturation can outperform existing color filters. Full article

Metallic nanoparticles (MNPs) and metallic nanostructures are both commonly used, independently, as SERS substrates due to their enhanced plasmonic activity. In this work, we introduce and investigate a hybrid nanostructure with strong SERS activity that benefits from the collective plasmonic response of the combination of MNPs and flow-through nanohole arrays (NHAs). The electric field distribution and electromagnetic enhancement factor of hybrid structures composed of silver NPs on both silver and gold NHAs are investigated via finite-difference time-domain (FDTD) analyses. This computational approach is used to find optimal spatial configurations of the nanoparticle positions relative to the nanoapertures and investigate the difference between Ag-NP-on-Ag-NHAs and Ag-NP-on-Au-NHAs hybrid structures. A maximum G_SERS value of 6.8 × 10⁹ is achieved with the all-silver structure when the NP is located 0.5 nm away from the rim of the NHA, while the maximum of 4.7 × 10¹⁰ is obtained when the nanoparticle is in full contact with the NHA for the gold-silver hybrid structure. These results demonstrate that the hybrid nanostructures enable hotspot formation with strong SERS activity and plasmonic enhancement compatible with SERS-based sensing applications. Full article

Conventional nano-sphere lithography techniques have been extended to the fabrication of highly periodic arrays of sub-wavelength nanoholes in a thin metal film. By combining the dry etching processes of self-assembled monolayers of polystyrene colloids with metal physical deposition, the complete transition from increasing size triangular nanoprism to hexagonally distributed nanoholes array onto thin metal film has been gradually explored. The investigated nano-structured materials exhibit interesting plasmonic properties which can be precisely modulated in a desired optical spectral region. An interesting approach based on optical absorbance measurements has been adopted for rapid and non-invasive inspections of the nano-sphere monolayer after the ion etching process. By enabling an indirect and accurate evaluation of colloid dimensions in a large area, this approach allows the low-cost and reproducible fabrication of plasmonic materials with specifically modulated optical properties suitable for many application in biosensing devices or Raman enhanced effects. Full article
