Search Results (129)

This paper presents a five-coil array integrated wireless power transfer (WPT) system designed for implantable medical devices. The proposed structure features a collaborative design of driving and radiating coils, where each driving coil excites its corresponding radiating coil to emit power. All coil units are precisely tuned to operate at the 13.56 MHz ISM band. The unique array configuration generates a highly uniform magnetic field distribution within the target area, enabling excellent tolerance to lateral misalignment. System analysis based on scattering parameters (S-parameters) confirms the design’s outstanding power transfer efficiency at the operating frequency. By integrating the five-coil array onto a double-layer printed circuit board, the system achieves the miniaturization and high integration level required for implantable applications. The experimental results demonstrate that the system reaches a maximum transfer efficiency of 55% under ideal alignment conditions (with a transfer distance of 10–20 mm). Notably, even with a lateral displacement of 5–10 mm at a 10 mm transfer distance, the system maintains stable performance, with efficiency consistently exceeding 50%. These results validate the system’s capability for reliable and efficient wireless power delivery in clinical settings. Full article

This paper proposed an ultra-miniaturized four-port dual-band multi-input multi-output (MIMO) antenna designed for wireless biomedical implantable devices, including wireless capsule endoscopy (WCE) and cardiac leadless pacemakers. The antenna supports operation in the wireless medical telemetry service (WMTS) band of 1.395–1.4 GHz and the industrial, scientific, and medical (ISM) band of 2.4–2.4835 GHz for wireless power transfer and data telemetry applications. Miniaturization is achieved through a partial meandered structural configuration, yielding an overall size of 8 × 6.4 × 0.5 mm³. The antenna is encapsulated within implantable biomedical devices containing batteries, sensors, and electronic components, and evaluated in both homogeneous and realistic heterogeneous body phantoms, including the large intestine and heart. The full-wave electromagnetic simulation results demonstrate good performance, including reflection coefficients of −31.19 dB and −30.07 dB, gains of −27.5 dBi and −17.5 dBi, −10 dB impedance bandwidths of 170 MHz and 370 MHz, mutual coupling below 20 dB, and fractional bandwidths of 12.2% and 15.1% at 1.4 GHz and 2.45 GHz, respectively. Specific absorption rate (SAR) analysis satisfies implantation safety limits. Link budget analysis confirms reliable communication over distances more than 20 m in both frequency bands with high-data rates up to 100 Mbps. MIMO channel parameters such as envelope correlation coefficient (ECC), diversity gain (DG), channel capacity loss (CCL), and total active reflection coefficient (TARC) confirm the usefulness of the proposed MIMO antenna. Consequently, the proposed MIMO antenna emerges as a highly promising candidate with, ultra-miniaturization, isolation, multiband operation ability with omnidirectional-like radiation pattern characteristics for several biomedical implants in wireless health monitoring systems. Full article

This paper proposes a small size meander-line patch antenna which is designed to have biomedical telemetry applications using the Industrial, Scientific and Medical (ISM) band from 2.40 to 2.48 GHz supported by the equivalent circuit model (ECM). Antenna miniaturization is realized by the effective use of several slot structures placed in the rectangular microstrip patch structure, in order to realize electrical length extension and reduce the physical size. The antenna has overall dimensions of 12 × 22 × 0.787 mm³ and is made on a low-loss Arlon AD 450 (ε_r = 4.50 and tanδ = 0.0035) dielectric substrate, which has the desired stable electrical behavior and, importantly, can be used in implantable environments. Experimental validation is done by implanting the fabricated prototype into a laboratory-manufactured tissue-mimicking phantom, and it showed good agreement with simulated results. The designed antenna has a peak gain of 1.29 dBi in free space and −24.99 dBi at a frequency of 2.45 GHz and a fractional impedance bandwidth of about 250 MHz, which will guarantee reliable operation in the face of diversity and fluctuation in the surrounding environment (biological tissues). Furthermore, specific absorption rate (SAR) analysis is carried out in order to comply with international safety standards with peak SAR values kept within the permissible level of 2 W/kg for 10 g averaging tissue. The results show that the proposed antenna provides a good trade-off between the reduction in size, radiation performance and safety to the patient, making it a good candidate for short-range in-body wireless communication, implantable medical devices, and biomedical monitoring systems. Full article

This work presents a highly compact triple-band multi-input-multi-output (MIMO) implantable antenna for wireless capsule endoscopy (WCE) and leadless cardiac pacemakers. The proposed antenna operates at industrial, scientific, and medical (ISM) bands of 2.400 to 2.480 GHz and 5.725 to 5.875 GHz for data telemetry and the wireless medical telemetry service (WMTS) band of 1.395 to 1.432 GHz for efficient wireless power transfer. The four-element design measures 8.5 × 8.5 × 0.26 mm³ and achieves low mutual coupling through a planar four-port configuration with optimized inter-element spacing. The antenna is integrated within realistic capsule devices containing batteries, sensors, and electronic components, and evaluated in both homogeneous and realistic heterogeneous body phantoms, including the large intestine and heart. The design yields maximum reflection coefficients of −26.15 dB, −15 dB, and −36.32 dB, −10 dB bandwidths of 260 MHz, 160 MHz, and 160 MHz, mutual coupling of −37.74 dB, −44.55 dB, −26.48 dB, and peak realized gains of −35 dBi, −25 dBi, and −15 dBi at 1.4 GHz, 2.45 GHz, and 5.8 GHz, respectively. Specific absorption rate (SAR) analysis satisfies implantation safety limits. Link budget analysis confirms reliable communication over distances > 20 m in all bands with data rates up to 100 Mbps. MIMO channel parameters such as envelope correlation coefficient (ECC) and diversity gain (DG) remain within acceptable limits. Owing to its multi-band operation, miniaturization, and isolation, the proposed four-port antenna is a good candidate for next-generation WCE and leadless pacemaker systems. Full article

Wireless Power Transfer (WPT) has become a pivotal technology, enabling the battery-free operation of Internet of Things (IoT) and biomedical devices while supporting environmental sustainability. This review provides a comprehensive analysis of microstrip patch antennas (MPAs) operating at the 5.8 GHz Industrial, Scientific, and Medical (ISM) band, emphasizing their advantages over the more commonly used 2.4 GHz band. A detailed and systematic classification framework for MPA architectures is introduced, covering single-element, multi-band, ultra-wideband, array, MIMO, wearable, and rectenna systems. The review examines advanced optimization methodologies, including Defected Ground Structures (DGS), Electromagnetic Bandgap (EBG) structures, Metamaterials (MTM), Machine Learning (ML), and nanomaterials, each contributing to improvements in gain, bandwidth, efficiency, and device miniaturization. Unlike previous surveys, this work offers a performance-benchmarked classification specifically for 5.8 GHz MPAs and provides a quantitative assessment of key trade-offs, such as efficiency versus substrate cost. The review also advocates for a shift toward Power Conversion Efficiency (PCE)-centric co-design strategies. The analysis identifies critical research gaps, particularly the ongoing disparity between simulated and experimental performance. The review concludes by recommending multi-objective optimization, integrated antenna-rectifier co-design to maximize PCE, and the use of advanced materials and computational intelligence to advance next-generation, high-efficiency 5.8 GHz WPT systems. Full article

This paper presents a compact, dual-band, dual-polarization button antenna for Wireless Body Area Networks (WBANs) that operates in the 2.45 GHz and 5.8 GHz Industrial, Scientific, and Medical (ISM) bands. The antenna is engineered in the lower band from 2.33 to 2.8 GHz (18.3% fractional bandwidth) as a linearly polarized, top-loaded monopole, which provides an omnidirectional radiation pattern for on-body communication. In contrast, it functions as a cross-dipole in the higher band, achieving a fractional bandwidth of 66.4% (4.8–9.57 GHz) and a 3 dB axial ratio (AR) bandwidth of 57.4%, producing a broadside radiation with circular polarization for off-body communications. Prototype measurements in both free-space and on-body settings confirm the antenna’s robust performance, successfully validating its dual-band operation, dual-polarization characteristics. Furthermore, Specific Absorption Rate (SAR) simulations conducted on a human model demonstrate that the values are significantly below the established safety limits, confirming the antenna’s suitability for practical wearable applications. Full article

This article presents the design of a dual-mode resonant, dual-band textile microstrip patch antenna for bent sensing applications. The antenna has a simple, slit-perturbed circular sector patch configuration. Unlike traditional single-mode resonant bending sensor antennas, dual-mode resonance brings a unique dual-band sensing characteristic to textile antennas. It effectively covers 2.45 GHz and 5.8 GHz Industrial, Scientific and Medical (ISM) frequency bands. Experimental results demonstrate that the proposed antenna achieves −10 dB impedance bandwidths of 1.4% (2.43–2.465 GHz) and 2.4% (5.775–5.915 GHz), with maximum peak gains of 8.8 dBi and 9.1 dBi, respectively. As experimentally validated on flannel substrates, the antenna achieves maximum bent sensing sensitivities of 1.1 MHz/mm and 1.78 MHz/mm at 2.45 GHz and 5.8 GHz bands, respectively. Furthermore, the antenna is able to provide stable E-plane broadside radiation patterns in bending situations. It would be an ideal candidate for radio frequency identification (RFID), health monitoring systems, and flexible communication applications. Full article

This work presents the design and experimental validation of a high-performance 6-port MIMO antenna array designed for radar applications in the 24 GHz Industrial, Scientific, and Medical (ISM) band. The proposed design, configured as a 1 × 10 series-fed microstrip patch array on an RT/Duroid 5880 substrate, is engineered to meet the demanding requirements of automotive and industrial radar systems, where high resolution and target discrimination are critical. A key challenge in such dense MIMO arrays is mutual coupling, which was addressed by integrating novel metamaterial structures between the radiating elements. These structures effectively suppress surface waves, resulting in exceptional inter-port isolation exceeding 46 dB at 24.3 GHz. The antenna achieves a peak gain of 17.4 dBi, ensuring sufficient range for sensing applications. Furthermore, the radiation pattern exhibits a simulated low side lobe level (SLL) of −24.6 dB in the E-plane, and −15.8 dB in the H-plane, a critical parameter for minimizing false detections and enhancing accuracy in cluttered environments. With an operational bandwidth of 0.71 GHz, the proposed design demonstrates comprehensive performance metrics—high gain, outstanding isolation, and low SLL—that surpass many existing MIMO solutions. The results confirm the antenna’s strong potential for advanced MIMO radar systems operating in the 24 GHz-ISM band, paving the way for reliable high-resolution sensing. Full article

Deeply implanted biomedical devices like leadless pacemakers require an antenna with minimal volume and high radiation efficiency to ensure reliable in-body communication and long operational time within the human body. This paper introduces a novel implantable antenna designed to significantly reduce the spatial requirements within an implantable capsule while maintaining high radiation efficiency in lossy media like heart tissue. The design principles of the proposed antenna are outlined, followed by antenna parameters and an equivalent circuit study that demonstrates how to fine-tune the antenna’s resonant frequency. The radiation characteristics of the antenna are thoroughly investigated, revealing a radiation efficiency of up to 28% at the Medical Implant Communication System (MICS) band and 56% at the 2.4 GHz ISM band. The transmission efficiency between two deeply implanted antennas within heart tissue has been improved by more than 15 dB compared to the current state of the art. The radiation and transmission performance of the proposed antennas has been validated through comprehensive simulations using anatomical human body models, phantom measurements, and in vivo animal experiments, confirming their superior radiation performance. Full article

A novel dual-band dual-mode wearable button antenna for wireless body area network (WBAN) applications is proposed in this paper. The antenna ingeniously integrates a monopole structure and an optimized planar inverted-F antenna (PIFA) configuration in a shared radiator, enabling dual-mode operation with a compact size. In the low-frequency band, the monopole structure generates an omnidirectional radiation pattern, facilitating efficient on-body communication. Meanwhile, the PIFA structure in the high-frequency band exhibits directed radiation, optimizing off-body communication. To enhance bandwidth, a parasitic structure is incorporated into the design. Both numerical simulations and experimental measurements are conducted to evaluate the antenna’s bandwidth and radiation performance in free space and on-body environments, with results showing excellent agreement. The measured bandwidth of the antenna on the human tissue is 300 MHz (2.3–2.6 GHz) in the low-frequency band and 4.5 GHz (5.5–10 GHz) in the high-frequency band. The maximum radiation efficiency reaches 76% in the low band (2.4–2.4835 GHz) and 93% in the upper band (5.725–5.875 GHz). Additionally, the peak gain on the human body can achieve 2.5 dB and 6.9 dB for the low and upper bands, respectively. The results confirm that the antenna meets the design requirements for Industrial, Scientific, and Medical (ISM) band applications, making it a promising candidate for WBAN systems. Full article

This study presents a compact and high-efficiency microstrip antenna integrated with a square electromagnetic band-gap (EBG) structure for radio frequency energy harvesting to power battery-less Internet of Things (IoT) sensors and medical devices in the 5.8 GHz Industrial, Scientific, and Medical (ISM) band. The proposed antenna features a compact design with reduced physical dimensions of 36 × 40 mm² (0.69λ_o × 0.76λ_o) while providing high-performance parameters such as a reflection coefficient of −27.9 dB, a voltage standing wave ratio (VSWR) of 1.08, a gain of 7.91 dBi, directivity of 8.1 dBi, a bandwidth of 188 MHz, and radiation efficiency of 95.5%. Incorporating EBG cells suppresses surface waves, enhances gain, and optimizes impedance matching through 50 Ω inset feeding. The simulated and measured results of the designed antenna show a high correlation. This study demonstrates a robust and promising solution for high-performance wireless systems requiring a compact size and energy-efficient operation. Full article

This paper presents an enhanced circularly polarized (CP) all-textile antenna using a metasurface (MS) and slot-patterned ground (SPG) for 5.8 GHz industry, scientific, and medical (ISM)-band applications in off-body communications. The 3 × 3 MS, capable of converting the incident wave into an orthogonal direction with equal magnitude and a 90° phase difference, converts the linearly polarized (LP) wave, radiated from the fundamental radiator with a corner-truncated slot square-patch configuration, into being CP. The SPG, consisting of periodic slots with two different sizes of corner-truncated slots, redistributes the surface current on the ground plane, enhancing the axial ratio bandwidth (ARBW) of the proposed antenna. The novel combination of MS and SPG not only enables the generation and enhancement of CP characteristics but also significantly improves the impedance bandwidth (IBW), gain, and radiation efficiency by introducing additional surface wave resonances. The proposed antenna is composed of a conductive textile and a felt substrate, offering comfort and flexibility for applications where the antenna is placed in close proximity to the human body. The proposed antenna is simulated under bending in various directions, showing exceptionally similar characteristics to a flat condition. The proposed antenna is fabricated and is then verified by measurements in both free space and a human body environment. The measured IBW is 36.3%, while the ARBW is 18%. The measured gain and radiation efficiency are 6.39 dBic and 64.7%, respectively. The specific absorption rate (SAR) is simulated, and the results satisfy both US and EU safety standards. Full article

A novel dual-band multi-linear polarization reconfigurable (MLPR) antenna for body-centric wireless communication systems (BWCS) is presented in this paper. The design comprises five symmetrically arranged multi-branch radiating units, each integrating an elliptical patch and curved spring branch for the Medical Implant Communication Service (MICS) band (403–405 MHz), and a pair of orthogonal strip patches for the Industrial, Scientific and Medical (ISM) $2.45$ GHz band (2.40–2.48 GHz). By selectively biasing PIN diodes between each unit and a central pentagonal feed, five distinct LP states with polarization directions of $0^{\circ }$, ${72}^{\circ }$, ${144}^{\circ }$, ${216}^{\circ }$, and ${288}^{\circ }$ are achieved. A dual-line isolation structure is introduced to suppress mutual coupling between radiating units, ensuring cross-polarization levels (XPLs) better than $-15.0$ dB across the operation bands. Prototypes fabricated on a $160\times 160\times 1.5$ mm³ substrate demonstrate measured $|S_{11}|<-10$ dB across 401–409 MHz and 2.34–2.53 GHz and stable omnidirectional patterns despite biasing circuitry perturbations. The compact form and robust dual-band, multi-polarization performance make the proposed antenna a promising candidate for implantable device wake-up signals and on-body data links in dense indoor environments. Full article

This paper presents a novel Spiral Slot Planar Inverted-F Antenna (SSPIFA) specifically designed for telemedicine and healthcare applications, featuring compact size, biocompatible safety, and high integration suitability. By replacing the conventional top metal patch of a Planar Inverted-F Antenna (PIFA) with a slot spiral radiator whose geometry is precisely matched to the ground plane, the proposed antenna achieves a significant size reduction, making it ideal for encapsulation in miniaturized medical devices—a critical requirement for implantation scenarios. Tailored for the ISM 915 MHz band, the antenna is fabricated with a four-turn slot spiral etched on a 30 mm-diameter dielectric substrate, achieving an overall height of 22 mm and an electrically small profile of approximately 0.09λ × 0.06λ (λ: free-space wavelength at the center frequency). Simulation and measurement results demonstrate a −16 dB impedance matching (S11 parameter) at the target frequency, accompanied by a narrow fractional bandwidth of 1% and stable right-hand circular polarization (RHCP). When implanted in a layered biological tissue model (skin, fat, muscle), the antenna exhibits a near-omni directional radiation pattern in the azimuthal plane, with a peak gain of 2.94 dBi and consistent performance across the target band. These characteristics highlight the SSPIFA’s potential for reliable wireless communication in implantable medical systems, balancing miniaturization, radiation efficiency, and biocompatible design. Full article

Time synchronization between geographically separated equipment, such as, for example, that required in sensor networks for radio localization, is often based on global navigation satellite systems (GNSSs). However, in environments that are GNSS-denied due to signal blockage or interference, alternative timing synchronization methods are necessary. In this work, an experimental wireless time synchronization system based on long-range (LoRa) modulation has been developed and tested in the field. LoRa modulation operating in the license-free 2.4 GHz industrial, scientific and medical (ISM) band was chosen due to the potentially large coverage area of several kilometers and the availability of a ranging engine in the SX1280 transceiver by Semtech, which facilitates the implementation of time synchronization. The prototype system was tested over 170 m, where it achieved a time deviation (TDEV) of 30 ps for an average time of 1 s and a maximum TDEV of 3 ns over one day of measurement, improving over existing work on time synchronization with LoRa modulation by around three orders of magnitude. The field tests showed that ns accuracy can be achieved using LoRa modulation, making it suitable for the synchronization of remote sites, for example, for radio localization. Full article
